The application of fluidized bed reactors to biomass fast pyrolysis is regarded as a promising technology for enabling high-value utilization of biomass. This work established a three-dimensional numerical model of an industrial-scale fluidized bed reactor for biomass catalytic pyrolysis, employing the multiphase particle-in-cell method (MP-PIC) and coupling catalytic pyrolysis kinetics. Primary gas flow rate and biomass–catalyst injection modes were optimized to further improve the performance of the reactor. The model received additional validation from experimental data, primarily to ensure prediction accuracy. The results revealed that an optimal primary gas flow rate of 4 kg/s achieved a peak catalytic efficiency of 71.3%. Using maximum high-quality liquid fuels and adopting a relatively dispersed inlet mode with opposite jetting for biomass and catalyst promoted uniform particle distribution and thermal homogeneity in the dense phase zone, further increasing the catalytic efficiency to 75.6%. With the integration of the multiphase particle-in-cell (MP-PIC) method with catalytic pyrolysis kinetics at the industrial-scale, this work could provide theoretical guidance for designing fluidized bed catalytic pyrolysis reactors and optimizing biomass catalytic pyrolysis processes. Full article

In this work, a statistical method is applied to a multiphase CFD simulation of concrete mixing performed in a truck mixer. The numerical model is based on an Eulerian–Eulerian approach in a transient regime. The aggregate materials are simulated as dispersed solid particles of various diameters, while the cement paste is simulated as a non-Newtonian continuous fluid. The first ten drum revolutions are analyzed from the condition of the completely segregated materials. The cell mixing index, defined by a statistical method in terms of mean, variance, and density probability function, is applied to the analysis of the simulation results. The statistical variables are implemented using the fluid dynamics code in the post-processing result analyses. The method predicts the distribution efficiency of the materials within a truck mixer as a function of its internal geometry, rotation speed, and mixture composition. As the number of revolutions increases, the distribution qualitatively improves, as shown by the motion fields, velocities, and vortices of the various materials, quantified through the calculation of the mixing index. The illustrated method can be used to predictively calculate the distribution effectiveness of new truck mixer designs before prototyping them and can be applied to other types of mixers. Furthermore, this study can be applied to liquid–solid mixing processes analyzed via the Eulerian multiphase numerical approach. Full article

Solid–liquid two-phase flow often occurs when pumping proppant or temporary plugging agents into hydraulically fractured wells. The final distribution of these injected particles in the fracture has an important influence on the well productivity after hydraulic fracturing. This paper focuses on simulating and analyzing particle migration within slug injection hydraulic fractures in the Sulige gas reservoir. In this study, a particle migration and settlement model in hydraulic fractures is established based on the Multiphase Particle-in-Cell (MP-PIC) method, allowing for effective simulation of particle migration and settlement in fractures. This model is validated by the results of particle-pumping experiments. The influences of fluid viscosity, injection rate, particle density, particle diameter, and particle concentration on the distribution of particles are studied. The results indicate that keeping the viscosity of the particle-carrying liquid above 50 mPa·s is necessary. It is recommended to keep the liquid viscosity above 200 mPa·s so that the particles can move farther in the fractures. For pulse fracturing, a lower flow rate leads to a more dispersed distribution of particles, but for temporary plugging with particles, a lower flow rate can lead to a decrease in particle concentration and reduce the success rate of temporary plugging. Low particle density can lead to more dispersed particles, but the amount of particle settlement will be less, so from the perspective of pulse fracturing, it is recommended that the particle density should not be lower than 2200 $\mathrm{kg}/{\mathrm{m}}^3$. Similarly, the particle size should not be too large for pulse fracturing, and the initial particle concentration should be maintained above $18\%$. Full article

In recent years, the fast growth of computational power has allowed the application of computational fluid dynamics (CFD) in a wide range of areas of interest, such as gas–solid unit operations. In this context, the multiphase particle-in-cell (MP-PIC) method appears as an option to represent fluid–particle and particle–particle interactions, avoiding the complexity of tracking each particle and the high computational cost derived from this. The MP-PIC method can represent the particles as a group with the same characteristics, allowing the simulation of gas–solid systems at different scales. To achieve this, the particle–particle interactions are simplified using the solid stress tensor to represent them; this does not require explicit expressions. This approach has a low computational cost, allowing the simulation of industrial cases using just workstations. This paper provides a review of the literature on the solid stress tensor and its commercial and non-commercial applications, including its historical and mathematical development in the description of particle–particle interactions. In addition, to consolidate the knowledge and advancing understanding in this crucial aspect of multiphase flow simulations, this review identifies the current challenges and opportunities for future research in multiphase systems based on the solid stress tensor. In addition, this review identifies the current challenges and opportunities for future research in multiphase systems based on the solid stress tensor. Full article

For the optimization of ventricular assist devices (VADs), flow simulations are crucial. Typically, these simulations assume single-phase flow to represent blood flow. However, blood consists of plasma and blood cells, making it a multiphase flow. Cell migration in such flows leads to a heterogeneous cell distribution, significantly impacting flow dynamics, especially in narrow gaps of less than 300 $\mathsf{\mu }$m found in VADs. In these areas, cells migrate away from the walls, forming a cell-free layer, a phenomenon not usually considered in current VAD simulations. This paper addresses this gap by introducing a viscosity model that accounts for cell migration in microchannels under VAD-relevant conditions. The model is based on local particle distributions measured in a microchannels with a blood analog fluid. We developed a local viscosity distribution for flows with particles/cells and a cell-free layer, applicable to both blood and analog fluids, with particle volume fractions of up to 5%, gap heights of 150 $\mathsf{\mu }$m, and Reynolds numbers around 100. The model was validated by comparing simulation results with experimental data of blood and blood analog fluid flow on wall shear stresses and pressure losses, showing strong agreement. This model improves the accuracy of simulations by considering local viscosity changes rather than assuming a single-phase fluid. Future developments will extend the model to physiological volume fractions up to 40%. Full article

Many protein expression systems are primarily utilised to produce a single, specific recombinant protein. In contrast, most biological processes such as virus assembly rely upon a complex of several interacting proteins rather than the activity of a sole protein. The high complexity of the baculovirus genome, coupled with a multiphase replication cycle incorporating distinct transcriptional steps, made it the ideal system to manipulate for high-level expression of a single, or co-expression of multiple, foreign proteins within a single cell. We have developed and utilised a series of recombinant baculovirus systems to unravel the sequential assembly process of a complex non-enveloped model virus, bluetongue virus (BTV). The high protein yields expressed by the baculovirus system not only facilitated structure–function analysis of each viral protein but were also advantageous to crystallography studies and supported the first atomic-level resolution of a recombinant viral protein, the major BTV capsid protein. Further, the formation of recombinant double-shelled virus-like particles (VLPs) provided insights into the structure–function relationships among the four major structural proteins of the BTV whilst also representing a potential candidate for a viral vaccine. The baculovirus multi-gene expression system facilitated the study of structurally complex viruses (both non-enveloped and enveloped viruses) and heralded a new generation of viral vaccines. Full article

Hierarchical structures of many agglomerated primary crystals are often employed as cathode materials, especially for layered-oxide compounds. The anisotropic nature of these materials results in a strong correlation between particle morphology and ion transport. In this work, we present a multiphase-field framework that is able to account for strongly anisotropic diffusion in polycrystalline materials. Various secondary particle structures with random grain orientation as well as strongly textured samples are investigated. The observed ion distributions match well with the experimental observations. Furthermore, we show how these simulations can be used to mimic potentiostatic intermittent titration technique (PITT) measurements and compute effective diffusion coefficients for secondary particles. The results unravel the intrinsic relation between particle microstructure and the apparent diffusivity. Consequently, the modeling framework can be employed to guide the microstructure design of secondary battery particles. Furthermore, the phase-field method closes the gap between computation of diffusivities on the atomistic scale and the effective properties of secondary particles, which are a necessary input for Newman-type cell models. Full article

Utilization of bioenergy with carbon capture can realize carbon-negative syngas production. The quadruple fluidized bed gasifier (QFBG) integrates a chemical looping oxygen generation process and a dual fluidized bed gasifier with limestone as bed material. It is one promising device that can convert biomass to H₂-rich syngas whilst capturing CO₂ with little energy penalty. However, experimental or numerical simulation of QFBG is rarely reported on due to its complex structure, hindering the further commercialization and deployment of QFBG. In this work, a new computational fluid dynamics (CFD) solver is proposed to predict the complex physicochemical processes in QFBG based on the multi-phase particle in cell (MPPIC) methodology with the assistance of the open source software, OpenFOAM. The solver is first validated against experimental data in terms of hydrodynamics and reaction kinetics. Then, the solver is used to investigate the QFBG property. It is found that the QFBG can operate stably. The cold gas efficiency, H₂ molar fraction, and CO₂ capture rate of the QFBG are predicted to be 87.2%, 93.3%, and 90.5%, respectively, which is promising. It is believed that the solver can give reliable predictions for similar fluidized bed reactors. Full article

Attention to photovoltaic (PV) cells to convert solar irradiation into electricity is significantly growing for domestic usage and large-scale projects such as solar farms. However, PV efficiency decreases on hot days. This paper proposes an effective cooling technique consisting of a 2% nano encapsulated phase change material (NEPCM) slurry and impinging jets (IJs) in a PV system. The impact of five influencing parameters on PV efficiency is studied using a multi-phase volume of fluid (VOF) model encompassing the effects of solar irradiation, latent heat, mass flow rate, number of nozzles, and jet-to-surface distance. The maximum efficiency of 15.82% is achieved under irradiation of 600 W/m². The latent heat shows a slight improvement at the low particle concentration. Increasing the mass flow rate to 0.12 kg/s enhances the PV output power by 17.32%. While the PV performance is shown to be improved over the increment of the number of nozzles, the jet-to-surface spacing of 5.1 mm records a remarkable PV surface temperature reduction to 33.8 °C, which is the ideal operating temperature for the PV panel. Full article

The drying process of electrodes might seem to be a simple operation, but it has profound effects on the microstructure. Some unexpected changes can happen depending on the drying conditions. In prior work, we developed the multiphase-smoothed-particle (MPSP) model, which predicted a relative increase in the carbon additive and binder adjacent to the current collector during drying. This motivated us to undertake the present experimental investigation of the relationship between the drying rate and microstructure and transport properties for a typical anode and cathode. Specifically, the drying rate was controlled by means of temperature for both an NMC532 cathode and graphite anode. The material distribution was analyzed using a combination of cross-section SEM images and the energy-dispersive X-ray spectroscopy elemental maps. The binder concentration gradients were developed in both the in- and through-plane directions. The through-plane gradient is evident at a temperature higher than 150 °C, whereas the in-plane variations resulted at all drying temperatures. The measurements identified an optimum temperature (80 °C) that results in high electronic conductivity and low ionic resistivity due to a more uniform binder distribution. Trends in transport properties are not significantly altered by calendering, which highlights the importance of the drying rate itself on the assembled cell properties. Full article

Biomass chemical looping gasification (BCLG) is a complex process for the conversion of biomass using an oxygen carrier, which is influenced by various operating parameters. For a better understanding of this process, biomass steam gasification using ilmenite as an oxygen carrier is numerically investigated in this work using the multiphase particle-in-cell (MP-PIC) method, which is a modified Euler–Lagrange approach. As a first step, a reduced reaction network for biomass gasification is investigated in a spouted bed. As a second step, the reaction network is coupled with oxygen carrier kinetics of ilmenite for the simulation of BCLG in a lab-scale fluidized bed. For both steps, the influence of the main operating parameters, such as reactor temperature, steam-to-biomass ratio, and oxidation degree of the oxygen carrier, are investigated and compared with experimental data from the literature. In general, the simulations show satisfying results and the predicted syngas compositions with varied operating parameters are in good agreement with the experimental data. Furthermore, the main trends for the syngas composition are predicted correctly and the oxidation degree of the oxygen carrier has a significant influence on the resulting syngas composition confirming the experimental results. Full article

Discriminating multiphase methane (adsorbed and free phases) in coals is crucial for evaluating the optimal gas recovery strategies of coalbed methane (CBM) reservoirs. However, the existing volumetric-based adsorption isotherm method only provides the final methane adsorption result, limiting real-time dynamic characterization of multiphase methane in the methane adsorption process. In this study, via self-designed nuclear magnetic resonance (NMR) isotherm adsorption experiments, we present a new method to evaluate the dynamic multiphase methane changes in coals. The results indicate that the T₂ distributions of methane in coals involve three different peaks, labeled as P1 (T₂ < 8 ms), P2 (T₂ = 20–300 ms), and P3 (T₂ > 300 ms) peaks, corresponding to the adsorbed phase methane, free phase methane between particles, and free phase methane in the sample cell, respectively. The methane adsorption Langmuir volumes calculated from the conventional volumetric-based method qualitatively agree with those obtained from the NMR method, within an allowable limit of approximately ~6.0%. Real-time dynamic characterizations of adsorbed methane show two different adsorption rates: an initial rapid adsorption of methane followed by a long stable state. It can be concluded that the NMR technique can be applied not only for methane adsorption capacity determination, but also for dynamic monitoring of multiphase methane in different experimental situations, such as methane adsorption/desorption and CO₂-enhanced CBM. Full article

In the computational mechanics of multiphase dispersed flows, there is an issue of computing the interaction between phases in a mixture of a carrier fluid and dispersed inclusions. The problem is that an accurate dynamics simulation of a mixture of gas and finely dispersed solids with intense interphase interaction requires much more computational power compared to pure gas or a mixture with moderate interaction between phases. To tackle this problem, effective numerical methods are being searched for to ensure adequate computational cost, accuracy, and stability of the results at an arbitrary intensity of momentum and energy exchange between phases. Thus, to assess the approximation, dispersive, dissipative, and asymptotic properties of numerical methods, benchmark solutions of relevant test problems are required. Such solutions are known for one-dimensional problems with linear plane waves. We introduce a novel analytical solution for the nonlinear problem of spherically symmetric expansion of a gas and dust ball into a vacuum. Therein, the dynamics of carrier and dispersed phases are modeled using equations for a compressible inviscid gas. Solid particles do not have intrinsic pressure and are assumed to be monodisperse. The carrier and dispersed phases exchange momentum. In the derived solution, the velocities of gas and dust clouds depend linearly on the radii. The results were reproduced at high, moderate, and low momentum exchange between phases using the SPH-IDIC (Smoothed Particle Hydrodynamics with Implicit Drag in Cell) method implemented based on the open-source OpenFPM library. We reported an example of using the solution as a benchmark for CFD (computational fluid dynamics) models verification and for the evaluation of numerical methods. Our benchmark solution generator developed in the free Scilab environment is publicly available. Full article

CeO₂ is an important energy storage material that can be used in solid fuel cells. Adding citric acid can improve the particle distribution of the pyrolytic preparation of CeO₂ inside the reactor. Through Fluent, this paper investigated the pyrolysis preparation of CeO₂ with the addition of citric acid by adopting the Eulerian multiphase flow model, component transportation model, and standard k-ε turbulence model. The experimental and simulation results suggest that the addition of citric acid can alter the pressure, temperature, and component distributions inside the reactor. When the mass fraction of O₂ is 0.3, the concentration distribution effect of the CeO₂ component is optimal and its conversation rate is the highest. When the mass fraction of citric acid is 0.04, the concentration distribution effect of the CeO₂ component is the best, as witnessed by the high CeO₂ concentration at the exit. It was found that an O₂ content of 30 wt % and citric acid content of 4 wt % were optimal operating conditions for this technology. Full article

In this paper, we present a methodological study of modelling red blood cells (RBCs) in shear-induced flows based on the discrete multiphysics (DMP) approach. The DMP is an alternative approach from traditional multiphysics based on meshless particle-based methods. The proposed technique has been successful in modelling multiphysics and multi-phase problems with large interfacial deformations such as those in biological systems. In this study, we present the proposed method and introduce an accurate geometrical representation of the RBC. The results were validated against available data in the literature. We further illustrate that the proposed method is capable of modelling the rupture of the RBC membrane with minimum computational difficulty. Full article
