Search Results (21)

We propose a hybrid-integrated III–V-silicon optical-phased-array (OPA) based on passive alignment flip–chip bonding technology and provide new solutions for LiDAR. To achieve a large range of vertical beam steering in a hybrid-integrated OPA, a multi-lines OPA in a single chip is introduced. The system allows parallel hybrid integration of multiple dies onto a single wafer, achieving a multi-fold improvement in tuning efficiency. In order to increase the range of horizontal beam steering, we propose a half-wavelength pitch waveguide emitter with non-uniform width to reduce the crosstalk, which can remove the higher-order grating lobes in free space. In this work, we simulate OPA individually for four-lines and eight-lines. As a result, we simultaneously achieved a beam steering with nearly ±90° (horizontal) × 17.2° (vertical, when four-line OPA) or 39.6° (vertical, when eight-line OPA) field of view (FOV) and a high tuning efficiency with 1.13°/nm (when eight-line OPA). Full article

Polarimetric measurement has been proven to be of great importance in various applications, including remote sensing in agriculture and forest. Polarimetric full waveform LiDAR is a relatively new yet valuable active remote sensing tool. This instrument offers the full waveform data and polarimetric information simultaneously. Current studies have primarily used commercial non-polarimetric LiDAR for tree species classification, either at the dominant species level or at the individual tree level. Many classification approaches combine multiple features, such as tree height, stand width, and crown shape, without utilizing polarimetric information. In this work, a customized Multiwavelength Airborne Polarimetric LiDAR (MAPL) system was developed for field tree measurements. The MAPL is a unique system with unparalleled capabilities in vegetation remote sensing. It features four receiving channels at dual wavelengths and dual polarization: near infrared (NIR) co-polarization, NIR cross-polarization, green (GN) co-polarization, and GN cross-polarization, respectively. Data were collected from several tree species, including coniferous trees (blue spruce, ponderosa pine, and Austrian pine) and deciduous trees (ash and maple). The goal was to improve the target identification ability and detection accuracy. A machine learning (ML) approach, specifically a decision tree, was developed to classify tree species based on the peak reflectance values of the MAPL waveforms. The results indicate a re-substitution error of 3.23% and a k-fold loss error of 5.03% for the 2106 tree samples used in this study. The decision tree method proved to be both accurate and effective, and the classification of new observation data can be performed using the previously trained decision tree, as suggested by both error values. Future research will focus on incorporating additional LiDAR data features, exploring more advanced ML methods, and expanding to other vegetation classification applications. Furthermore, the MAPL data can be fused with data from other sensors to provide augmented reality applications, such as Simultaneous Localization and Mapping (SLAM) and Bird’s Eye View (BEV). Its polarimetric capability will enable target characterization beyond shape and distance. Full article

Light Detection and Ranging (LiDAR) is a well-established active technology for the direct acquisition of 3D data. In recent years, the geometric information collected by LiDAR sensors has been widely combined with optical images to provide supplementary spectral information to achieve more precise results in diverse remote sensing applications. The emergence of active Multispectral LiDAR (MSL) systems, which operate on different wavelengths, has recently been revolutionizing the simultaneous acquisition of height and intensity information. So far, MSL technology has been successfully applied for fine-scale mapping in various domains. However, a comprehensive review of this modern technology is currently lacking. Hence, this study presents an exhaustive overview of the current state-of-the-art in MSL systems by reviewing the latest technologies for MSL data acquisition. Moreover, the paper reports an in-depth analysis of the diverse applications of MSL, spanning across fields of “ecology and forestry”, “objects and Land Use Land Cover (LULC) classification”, “change detection”, “bathymetry”, “topographic mapping”, “archaeology and geology”, and “navigation”. Our systematic review uncovers the potentials, opportunities, and challenges of the recently emerged MSL systems, which integrate spatial–spectral data and unlock the capability for precise multi-dimensional (nD) mapping using only a single-data source. Full article

Single-pixel imaging lidar is a novel technology that leverages single-pixel detectors without spatial resolution and spatial light modulators to capture images by reconstruction. This technique has potential imaging capability in non-visible wavelengths compared with surface array detectors. An avalanche photodiode (APD) is a device in which the internal photoelectric effect and the avalanche multiplication effect are exploited to detect and amplify optical signals. An encapsulated APD detector, with an APD device as the core, is the preferred photodetector for lidar due to its high quantum efficiency in the near-infrared waveband. However, research into APD detectors in China is still in the exploratory period, when most of the work focuses on theoretical analysis and experimental verification. This is a far cry from foreign research levels in key technologies, and the required near-infrared APD detectors with high sensitivity and low noise have to be imported at a high price. In this present study, an encapsulated APD detector was designed in a linear mode by integrating a bare APD tube, a bias power circuit, a temperature control circuit and a signal processing circuit, and the corresponding theoretical analysis, circuit design, circuit simulation and experimental tests were carried out. Then, the APD detector was applied in the single-pixel imaging lidar system. The study showed that the bias power circuit could provide the APD with an operating voltage of DC 1.6 V to 300 V and a ripple voltage of less than 4.2 mV. Not only that, the temperature control circuit quickly changed the operating state of the Thermo Electric Cooler (TEC) to stabilize the ambient temperature of the APD and maintain it at 25 ± 0.3 °C within 5 h. The signal processing circuit was designed with a multi-stage amplification cascade structure, effectively raising the gain of signal amplification. By comparison, the trial also suggested that the encapsulated APD detector and the commercial Licel detector had a good agreement on the scattered signal, such as a repetition rate and pulse width response under the same lidar environment. Therefore, target objects in real atmospheric environments could be imaged by applying the encapsulated APD detector to the near-infrared single-pixel imaging lidar system. Full article

Three-dimensional LiDAR systems that capture point cloud data enable the simultaneous acquisition of spatial geometry and multi-wavelength intensity information, thereby paving the way for three-dimensional point cloud recognition and processing. However, due to the irregular distribution, low resolution of point clouds, and limited spatial recognition accuracy in complex environments, inherent errors occur in classifying and segmenting the acquired target information. Conversely, two-dimensional visible light images provide real-color information, enabling the distinction of object contours and fine details, thus yielding clear, high-resolution images when desired. The integration of two-dimensional information with point clouds offers complementary advantages. In this paper, we present the incorporation of two-dimensional information to form a multi-modal representation. From this, we extract local features to establish three-dimensional geometric relationships and two-dimensional color relationships. We introduce a novel network model, termed MInet (Multi-Information net), which effectively captures features relating to both two-dimensional color and three-dimensional pose information. This enhanced network model improves feature saliency, thereby facilitating superior segmentation and recognition tasks. We evaluate our MInet architecture using the ShapeNet and ThreeDMatch datasets for point cloud segmentation, and the Stanford dataset for object recognition. The robust results, coupled with quantitative and qualitative experiments, demonstrate the superior performance of our proposed method in point cloud segmentation and object recognition tasks. Full article

In order to conduct more thorough research on the structural characteristics of the atmosphere and the distribution and transmission of atmospheric pollution, the use of remote sensing technology for multi-dimensional detection of the atmosphere is needed. A light-weight, low-volume, low-cost, easy-to-use and low-maintenance mini Infrared Lidar (mIRLidar) sensor is developed for the first time. The model of lidar is established, and the key optical parameters of the mIRLidar are optimized through simulation, in which wavelength of laser, energy of pulse laser, diameter of telescope, field of view (FOV), and bandwidth of filter are included. The volume and weight of the lidar system are effectively reduced through optimizing the structural design and designing a temperature control system to ensure the stable operation of the core components. The mIRLidar system involved a 1064 nm laser (the pulse laser energy 15 μJ, the repetition frequency 5 kHz), a 100 mm aperture telescope (the FOV 1.5 mrad), a 0.5 nm bandwidth of filter and an APD, where the lidar has a volume of 200 mm × 200 mm × 420 mm and weighs about 13.5 kg. It is shown that the lidar can effectively detect three-dimensional distribution and transmission of aerosol and atmospheric pollution within a 5 km detection range, from Horizontal, scanning and navigational atmospheric measurements. It has great potential in the field of meteorological research and environmental monitoring. Full article

Numerical simulations are performed to determine the angular dependence of the MIe scattering cross-section intensities of pure water droplets and pollutants such as contaminated water droplets and black carbon as a function of the wavelength of the incident laser light, complex refractive index, and size of the scatterer. Our results show distinct scattering features when varying the various scattering parameters, thereby allowing the identification of the scattering particle with specific application to the identification of atmospheric pollutants including black carbon. Regardless of the type of scatterer, the scattering intensity is nearly uniform with a slight preference for forward scattering when the size of the particle is within 20% of the incident laser’s wavelength. The scattering patterns start to exhibit distinguishable features when the size parameter equals 1.77, corresponding to an incident laser wavelength of 0.355 μm and a particle radius of 0.1 μm. The patterns then become increasingly unique as the size parameter increases. Based on these calculations, we propose a time-gated lidar scheme consisting of multiple detectors that can rotate through a telescopic angle and be placed equidistantly around the scattering particles to collect the backscattered light and a commercially available Q-switched laser system emitting at tunable laser wavelengths. By using a pulsed laser with 10-ns pulse duration, our scheme could distinguish scattering centers that are at least 3 m apart. Our scheme called MIe Scattering Time-gated multi-Static LIDAR (MISTS–LIDAR) would be capable of identifying the type of atmospheric pollutant and mapping its location with a spatial resolution of a few meters. Full article

Lidar plays an essential role in monitoring the vertical variation of atmospheric aerosols. However, due to the limited information that lidar measurements provide, ill-posedness still remains a big challenge in quantitative lidar remote sensing. In this study, we describe the Basic algOrithm for REtrieval of Aerosol with Lidar (BOREAL), which is based on maximum likelihood estimation (MLE), and retrieve aerosol microphysical properties from extinction and backscattering measurements of multi-wavelength Mie–Raman lidar systems. The algorithm utilizes different types of a priori constraints to better constrain the solution space and suppress the influence of the ill-posedness. Sensitivity test demonstrates that BOREAL could retrieve particle volume size distribution (VSD), total volume concentration (V_t), effective radius (R_eff), and complex refractive index (CRI = n − ik) of simulated aerosol models with satisfying accuracy. The application of the algorithm to real aerosol events measured by LIlle Lidar AtmosphereS (LILAS) shows it is able to realize fast and reliable retrievals of different aerosol scenarios (dust, aged-transported smoke, and urban aerosols) with almost uniform and simple pre-settings. Furthermore, the algorithmic principle allows BOREAL to incorporate measurements with different and non-linearly related errors to the retrieved parameters, which makes it a flexible and generalized algorithm for lidar retrieval. Full article

In this work, heterogeneous integration of both two-dimensional (2D) optical phased arrays (OPAs) and on-chip laser arrays based on a silicon photonic platform is proposed. The tunable multi-quantum-well (MQW) laser arrays, active switching/shifting arrays, and grating antenna arrays are used in the OPA module to realize 2D spatial beam scanning. The 2D OPA chip is composed of four main parts: (1) tunable MQW laser array emitting light signals in the range of 1480–1600 nm wavelengths; (2) electro-optic (EO) switch array for selecting the desired signal light from the on-chip laser array; (3) EO phase-shifter array for holding a fixed phase difference for the uniform amplitude of specific optical signal; and (4) Bragg waveguide grating antenna array for controlling beamforming. By optimizing the overall performances of the 2D OPA chip, a large steering range of 88.4° × 18° is realized by tuning both the phase and the wavelength for each antenna. In contrast to the traditional thermo-optic LIDAR chip with an external light source, the overall footprint of the 2D OPA chip can be limited to 8 mm × 3 mm, and the modulation rate can be 2.5 ps. The ultra-compact 2D OPA assembling with on-chip tunable laser arrays using hybrid integration could result in the application of a high-density, high-speed, and high-precision lidar system in the future. Full article

A multispectral light detection and ranging (LiDAR) system, which simultaneously collects spatial geometric data and multi-wavelength intensity information, opens the door to three-dimensional (3-D) point cloud classification and object recognition. Because of the irregular distribution property of point clouds and the massive data volume, point cloud classification directly from multispectral LiDAR data is still challengeable and questionable. In this paper, a point-wise multispectral LiDAR point cloud classification architecture termed as SE-PointNet++ is proposed via integrating a Squeeze-and-Excitation (SE) block with an improved PointNet++ semantic segmentation network. PointNet++ extracts local features from unevenly sampled points and represents local geometrical relationships among the points through multi-scale grouping. The SE block is embedded into PointNet++ to strengthen important channels to increase feature saliency for better point cloud classification. Our SE-PointNet++ architecture has been evaluated on the Titan multispectral LiDAR test datasets and achieved an overall accuracy, a mean Intersection over Union (mIoU), an F₁-score, and a Kappa coefficient of 91.16%, 60.15%, 73.14%, and 0.86, respectively. Comparative studies with five established deep learning models confirmed that our proposed SE-PointNet++ achieves promising performance in multispectral LiDAR point cloud classification tasks. Full article

Lidar observations are very useful to analyse dispersed volcanic clouds in the troposphere mainly because of their high range resolution, providing morphological as well as microphysical (size and mass) properties. In this work, we analyse the volcanic cloud of 18 May 2016 at Mt. Etna, in Italy, retrieved by polarimetric dual-wavelength Lidar measurements. We use the AMPLE (Aerosol Multi-Wavelength Polarization Lidar Experiment) system, located in Catania, about 25 km from the Etna summit craters, pointing at a thin volcanic cloud layer, clearly visible and dispersed from the summit craters at the altitude between 2 and 4 km and 6 and 7 km above the sea level. Both the backscattering and linear depolarization profiles at 355 nm (UV, ultraviolet) and 532 nm (VIS, visible) wavelengths, respectively, were obtained using different angles at 20°, 30°, 40° and 90°. The proposed approach inverts the Lidar measurements with a physically based inversion methodology named Volcanic Ash Lidar Retrieval (VALR), based on Maximum-Likelihood (ML). VALRML can provide estimates of volcanic ash mean size and mass concentration at a resolution of few tens of meters. We also compared those results with two methods: Single-variate Regression (SR) and Multi-variate Regression (MR). SR uses the backscattering coefficient or backscattering and depolarization coefficients of one wavelength (UV or VIS in our cases). The MR method uses the backscattering coefficient of both wavelengths (UV and VIS). In absence of in situ airborne validation data, the discrepancy among the different retrieval techniques is estimated with respect to the VALR ML algorithm. The VALR ML analysis provides ash concentrations between about 0.1 μg/m³ and 1 mg/m³ and particle mean sizes of 0.1 μm and 6 μm, respectively. Results show that, for the SR method differences are less than <10%, using the backscattering coefficient only and backscattering and depolarization coefficients. Moreover, we find differences of 20–30% respect to VALR ML, considering well-known parametric retrieval methods. VALR algorithms show how a physics-based inversion approaches can effectively exploit the spectral-polarimetric Lidar AMPLE capability. Full article

This paper aims to quantify the improvement obtained with a purely rotational Raman (PRR) channel over a vibro-rotational Raman (VRR) channel, used in an aerosol lidar with elastic and Raman channels, in terms of signal-to-noise ratio (SNR), effective vertical resolution, and absolute and relative uncertainties associated to the retrieved aerosol optical (extinction and backscatter) coefficients. Measurements were made with the European Aerosol Research Lidar Network/Universitat Politècnica de Catalunya (EARLINET/UPC) multi-wavelength lidar system enabling a PRR channel at 353.9 nm, together with an already existing VRR (386.7 nm) and an elastic (354.7 nm) channels. Inversions were performed with the EARLINET Single Calculus Chain (SCC). When using PRR instead of VRR, the measurements show a gain in SNR of a factor 2.8 and about 7.6 for 3-h nighttime and daytime measurements, respectively. For 3-h nighttime (daytime) measurements the effective vertical resolution is reduced by 17% (20%), the absolute uncertainty (associated to the extinction) is divided by 2 (10) and the relative uncertainty is divided by 3 (7). During daytime, VRR extinction coefficient is retrieved in a limited height range (<2.2 km) preventing the SCC from finding a suitable calibration range in the search height range. So the advantage of using PRR instead of VRR is particularly evidenced in daytime conditions. For nighttime measurements, decreasing the time resolution from 3 to 1 h has nearly no effect on the relative performances of PRR vs. VRR. Full article

Volcanic emissions are a well-known hazard that can have serious impacts on local populations and aviation operations. Whereas several remote sensing observations detect high-intensity explosive eruptions, few studies focus on low intensity and long-lasting volcanic emissions. In this work, we have managed to fully characterize those events by analyzing the volcanic plume produced on the last day of the 2018 Christmas eruption at Mt. Etna, in Italy. We combined data from a visible calibrated camera, a multi-wavelength elastic/Raman Lidar system, from SEVIRI (EUMETSAT-MSG) and MODIS (NASA-Terra/Aqua) satellites and, for the first time, data from an automatic sun-photometer of the aerosol robotic network (AERONET). Results show that the volcanic plume height, ranging between 4.5 and 6 km at the source, decreased by about 0.5 km after 25 km. Moreover, the volcanic plume was detectable by the satellites up to a distance of about 400 km and contained very fine particles with a mean effective radius of about 7 µm. In some time intervals, volcanic ash mass concentration values were around the aviation safety thresholds of 2 × 10⁻³ g m⁻³. Of note, Lidar observations show two main stratifications of about 0.25 km, which were not observed at the volcanic source. The presence of the double stratification could have important implications on satellite retrievals, which usually consider only one plume layer. This work gives new details on the main features of volcanic plumes produced during low intensity and long-lasting volcanic plume emissions. Full article

We report on the retrieval of stratospheric aerosol particle size and extinction coefficient profiles from multi-color backscatter measurements with the Rayleigh–Mie–Raman lidar operated at the Arctic Lidar Observatory for Middle Atmosphere Research (ALOMAR) in northern Norway. The retrievals are based on a two-step approach. In a first step, the median radius of an assumed monomodal log-normal particle size distribution with fixed width is retrieved based on a color index formed from the measured backscatter ratios at the wavelengths of 1064 nm and 532 nm. An intrinsic ambiguity of the retrieved aerosol size information is discussed. In a second step, this particle size information is used to convert the measured lidar backscatter ratio to aerosol extinction coefficients. The retrieval is currently based on monthly-averaged lidar measurements and the results for March 2013 are discussed. A sensitivity study is presented that allows for establishing an error budget for the aerosol retrievals. Assuming a monomodal log-normal aerosol particle size distribution with a geometric width of S = 1.5, median radii on the order of below 100 nm are retrieved. The median radii are found to generally decrease with increasing altitude. The retrieved aerosol extinction profiles are compared to observations with the OSIRIS (Optical Spectrograph and InfraRed Imager System) and the OMPS-LP (Ozone Mapping Profiling Suite Limb Profiler) satellite instruments in the 60${}^{\circ }$ N to 80${}^{\circ }$ N latitude band. The extinction profiles that were retrieved from the lidar measurements show good agreement with the observations of the two satellite instruments when taking the different wavelengths of the instruments into account. Full article

Comprehensive and accurate vegetation monitoring is required in forestry and agricultural applications. The optical remote sensing method could be a solution. However, the traditional light detection and ranging (LiDAR) scans a surface to create point clouds and provide only 3D-state information. Active laser-induced fluorescence (LIF) only measures the photosynthesis and biochemical status of vegetation and lacks information about spatial structures. In this work, we present a new Multi-Wavelength Fluorescence LiDAR (MWFL) system. The system extended the multi-channel fluorescence detection of LIF on the basis of the LiDAR scanning and ranging mechanism. Based on the principle prototype of the MWFL system, we carried out vegetation-monitoring experiments in the laboratory. The results showed that MWFL simultaneously acquires the 3D spatial structure and physiological states for precision vegetation monitoring. Laboratory experiments on interior scenes verified the system’s performance. Fluorescence point cloud classification results were evaluated at four wavelengths and by comparing them with normal vectors, to assess the MWFL system capabilities. The overall classification accuracy and Kappa coefficient increased from 70.7% and 0.17 at the single wavelength to 88.9% and 0.75 at four wavelengths. The overall classification accuracy and Kappa coefficient improved from 76.2% and 0.29 at the normal vectors to 92.5% and 0.84 at the normal vectors with four wavelengths. The study demonstrated that active 3D fluorescence imaging of vegetation based on the MWFL system has a great application potential in the field of remote sensing detection and vegetation monitoring. Full article
