28 pages, 42589 KiB
Article
A Subimage Autofocus Bistatic Ground Cartesian Back-Projection Algorithm for Passive Bistatic SAR Based on GEO Satellites
by Te Zhao, Jun Wang, Zuhan Cheng, Ziqian Huang and Xueming Song
Remote Sens. 2025, 17(9), 1576; https://doi.org/10.3390/rs17091576 - 29 Apr 2025
Cited by 1 | Viewed by 423
Abstract
As an evolutionary advancement to conventional synthetic aperture radar (SAR), passive bistatic SAR (PBSAR) utilizing geostationary orbit (GEO) satellite signals demonstrates significant potential for high-resolution imaging. However, PBSAR faces dual challenges in computational efficiency and phase error compensation. Traditional accelerated back-projection (BP) variants [...] Read more.
As an evolutionary advancement to conventional synthetic aperture radar (SAR), passive bistatic SAR (PBSAR) utilizing geostationary orbit (GEO) satellite signals demonstrates significant potential for high-resolution imaging. However, PBSAR faces dual challenges in computational efficiency and phase error compensation. Traditional accelerated back-projection (BP) variants developed from monostatic SAR are incompatible with PBSAR’s geometry, and autofocus BP (AFBP) methods exhibit prohibitive computational costs and inadequate space-variant phase error handling. This study first develops a bistatic ground Cartesian back-projection (BGCBP) algorithm through subimage wavenumber spectrum correction, specifically adapted to GEO-satellite-based PBSAR. Compared to conventional BP, the BGCBP achieves an order-of-magnitude complexity reduction without resolution degradation. Building upon this foundation, we propose a subimage autofocus BGCBP (SIAF-BGCBP) methodology, synergistically integrating autofocus processing with BGCBP’s accelerated framework. SIAF-BGCBP reduces phase estimation’s complexity by 90% through subimage pixel density optimization while maintaining estimation accuracy. Further enhancement of SIAF-BGCBP via geometric inversion would enable the precise compensation of space-variant phase errors while remaining efficient. Simulations and real-environment experiments verify the effectiveness of the proposed methods. Full article
Show Figures

Graphical abstract

23 pages, 4910 KiB
Article
Synthetic Aperture Radar Processing Using Flexible and Seamless Factorized Back-Projection
by Mattia Giovanni Polisano, Marco Manzoni and Stefano Tebaldini
Remote Sens. 2025, 17(6), 1046; https://doi.org/10.3390/rs17061046 - 16 Mar 2025
Viewed by 1100
Abstract
This paper describes a flexible and seamless processor for Unmanned Aerial Vehicle (UAV)-borne Synthetic Aperture Radar (SAR) imagery. When designing a focusing algorithm for large-scale and high-resolution SAR images, efficiency and accuracy are two mandatory aspects to consider. The proposed processing scheme is [...] Read more.
This paper describes a flexible and seamless processor for Unmanned Aerial Vehicle (UAV)-borne Synthetic Aperture Radar (SAR) imagery. When designing a focusing algorithm for large-scale and high-resolution SAR images, efficiency and accuracy are two mandatory aspects to consider. The proposed processing scheme is based on a modified version of Fast Factorized Back-Projection (FFBP), in which the factorization procedure is interrupted on the basis of a computational cost analysis to reduce the number of complex operations at its minimum. The algorithm gains efficiency in the case of low-altitude platforms, where there are significant variations in azimuth resolution, but not in the case of conventional airborne missions, where the azimuth resolution can be considered constant in the swath. The algorithm’s performance is derived by assessing the number of complex operations required to focus an SAR image. Two scenarios are tackled in a numerical simulation: a UAV-borne SAR with a short synthetic aperture and a wide field of view, referred to as the ground-based-like (GBL) scenario, and a classical stripmap scenario. In both cases, we consider mono-static and bi-static radar configurations. The results of the numerical simulations show that the proposed algorithm outperforms FFBP in the stripmap scenario while achieving the same performance as FFBP in the GBL scenario. In addition, the algorithm is validated thanks to an experimental UAV-borne SAR campaign in the X-band. Full article
Show Figures

Figure 1

24 pages, 21508 KiB
Article
A Multiple-Input Multiple-Output Synthetic Aperture Radar Echo Separation and Range Ambiguity Suppression Processing Framework for High-Resolution Wide-Swath Imaging
by Haonan Zhao, Zhimin Zhang, Zhen Chen, Huaitao Fan, Zongsen Lv and Jianzhong Bi
Remote Sens. 2025, 17(4), 609; https://doi.org/10.3390/rs17040609 - 11 Feb 2025
Cited by 1 | Viewed by 678
Abstract
Multiple-input multiple-output (MIMO) synthetic aperture radar (SAR) is a promising scheme for high-resolution wide-swath (HRWS) imaging. After echo separation processing, a MIMO-SAR system can provide many equivalent phase centers (EPCs) in azimuth. However, EPC duplication occurs for traditional monostatic systems with uniform antenna [...] Read more.
Multiple-input multiple-output (MIMO) synthetic aperture radar (SAR) is a promising scheme for high-resolution wide-swath (HRWS) imaging. After echo separation processing, a MIMO-SAR system can provide many equivalent phase centers (EPCs) in azimuth. However, EPC duplication occurs for traditional monostatic systems with uniform antenna arrays, leading to system resource waste. Moreover, range ambiguity suppression is a necessary process for wide-swath SAR systems. In this paper, a novel MIMO-SAR echo separation and range ambiguity suppression processing framework is proposed for HRWS imaging. A set of transmission delays is introduced to the transmit channels to displace the repetitive EPCs. The transmission delays can also be used to flexibly control the performance of echo separation. A wide-null beamformer is employed to accomplish echo separation and ambiguity suppression simultaneously. The proposed framework is designed for real-time processing and therefore does not require frequency-domain operations. Finally, the proposed framework is verified through point target and distributed scene simulation experiments. Full article
(This article belongs to the Special Issue SAR-Based Signal Processing and Target Recognition (Second Edition))
Show Figures

Figure 1

29 pages, 4808 KiB
Article
Multi-Baseline Bistatic SAR Three-Dimensional Imaging Method Based on Phase Error Calibration Combining PGA and EB-ISOA
by Jinfeng He, Hongtu Xie, Haozong Liu, Zhitao Wu, Bin Xu, Nannan Zhu, Zheng Lu and Pengcheng Qin
Remote Sens. 2025, 17(3), 363; https://doi.org/10.3390/rs17030363 - 22 Jan 2025
Viewed by 693
Abstract
Tomographic synthetic aperture radar (TomoSAR) is an advanced three-dimensional (3D) synthetic aperture radar (SAR) imaging technology that can obtain multiple SAR images through multi-track observations, thereby reconstructing the 3D spatial structure of targets. However, due to system limitations, the multi-baseline (MB) monostatic SAR [...] Read more.
Tomographic synthetic aperture radar (TomoSAR) is an advanced three-dimensional (3D) synthetic aperture radar (SAR) imaging technology that can obtain multiple SAR images through multi-track observations, thereby reconstructing the 3D spatial structure of targets. However, due to system limitations, the multi-baseline (MB) monostatic SAR (MonoSAR) encounters temporal decorrelation issues when observing the scene such as forests, affecting the accuracy of the 3D reconstruction. Additionally, during TomoSAR observations, the platform jitter and inaccurate position measurement will contaminate the MB SAR data, which may result in the multiplicative noise with phase errors, thereby leading to the decrease in the imaging quality. To address the above issues, this paper proposes a MB bistatic SAR (BiSAR) 3D imaging method based on the phase error calibration that combines the phase gradient autofocus (PGA) and energy balance intensity-squared optimization autofocus (EB-ISOA). Firstly, the signal model of the MB one-stationary (OS) BiSAR is established and the 3D imaging principle is presented, and then the phase error caused by platform jitter and inaccurate position measurement is analyzed. Moreover, combining the PGA and EB-ISOA methods, a 3D imaging method based on the phase error calibration is proposed. This method can improve the accuracy of phase error calibration, avoid the vertical displacement, and has the noise robustness, which can obtain the high-precision 3D BiSAR imaging results. The experimental results are shown to verify the effectiveness and practicality of the proposed MB BiSAR 3D imaging method. Full article
(This article belongs to the Section Engineering Remote Sensing)
Show Figures

Figure 1

23 pages, 5405 KiB
Article
Integrated Modeling and Target Classification Based on mmWave SAR and CNN Approach
by Chandra Wadde, Gayatri Routhu, Mark Clemente-Arenas, Surya Prakash Gummadi and Rupesh Kumar
Sensors 2024, 24(24), 7934; https://doi.org/10.3390/s24247934 - 12 Dec 2024
Viewed by 1346
Abstract
This study presents a numerical modeling approach that utilizes millimeter-wave (mm-Wave) Frequency-Modulated Continuous-Wave (FMCW) radar to reconstruct and classify five weapon types: grenades, knives, guns, iron rods, and wrenches. A dataset of 1000 images of these weapons was collected from various online sources [...] Read more.
This study presents a numerical modeling approach that utilizes millimeter-wave (mm-Wave) Frequency-Modulated Continuous-Wave (FMCW) radar to reconstruct and classify five weapon types: grenades, knives, guns, iron rods, and wrenches. A dataset of 1000 images of these weapons was collected from various online sources and subsequently used to generate 3605 samples in the MATLAB (R2022b) environment for creating reflectivity-added images. Background reflectivity was considered to range from 0 to 0.3 (with 0 being a perfect absorber), while object reflectivity was set between 0.8 and 1 (with 1 representing a perfect electric conductor). These images were employed to reconstruct high-resolution weapon profiles using a monostatic two-dimensional (2D) Synthetic Aperture Radar (SAR) imaging technique. Subsequently, the reconstructed images were classified using a Convolutional Neural Network (CNN) algorithm in a Python (3.10.14) environment. The CNN architecture consists of 10 layers, including multiple convolutional, pooling, and fully connected layers, designed to effectively extract features and perform classification. The CNN model achieved high accuracy, with precision and recall values exceeding 98% across most categories, demonstrating the robustness and reliability of the model. This approach shows considerable promise for enhancing security screening technologies across a range of applications. Full article
(This article belongs to the Section Radar Sensors)
Show Figures

Figure 1

15 pages, 19899 KiB
Article
Assessment of Hongtu-1 Multi-Static X-Band SAR Constellation Interferometry
by Urs Wegmüller, Christophe Magnard and Othmar Frey
Remote Sens. 2024, 16(19), 3600; https://doi.org/10.3390/rs16193600 - 27 Sep 2024
Cited by 3 | Viewed by 2769
Abstract
In 2023, the Chinese company PIESAT launched the multi-static X-band SAR constellation Hongtu-1 (HT1). HT1 consists of the active monostatic SAR sensor HT1-A and the three additional passive SAR receivers HT1-B, HT1-C and HT1-D. The passive sensors are arranged as a cartwheel in [...] Read more.
In 2023, the Chinese company PIESAT launched the multi-static X-band SAR constellation Hongtu-1 (HT1). HT1 consists of the active monostatic SAR sensor HT1-A and the three additional passive SAR receivers HT1-B, HT1-C and HT1-D. The passive sensors are arranged as a cartwheel in a circle around the active sensor. For our SAR interferometric investigation, we were able to use a multi-static HT1 recording. After a brief introduction of HT1, we describe the processing performed. Based on the phases of the six single-pass interferometric pairs, we calculated height differences relative to the Copernicus DEM. Larger deviations were observed mainly for mining areas and for forest areas. Thanks to the simultaneous acquisition of the interferometric pairs, the high spatial resolution and the good signal quality, the necessary processing was relatively easy to perform. Besides the interferometric phase, we also investigated possible applications of multi-static coherence. Forest can be recognized by its reduced single-pass coherence values. Based on our results, we expect that the multi-static HT1 coherence and its dependence on the interferometric baseline can be used to estimate parameters such as forest biomass. Full article
Show Figures

Figure 1

28 pages, 1183 KiB
Article
Generalization of the Synthetic Aperture Radar Azimuth Multi-Aperture Processing Scheme—MAPS
by Daniele Mapelli, Pietro Guccione, Davide Giudici, Martina Stasi and Ernesto Imbembo
Remote Sens. 2024, 16(17), 3170; https://doi.org/10.3390/rs16173170 - 27 Aug 2024
Cited by 1 | Viewed by 1141
Abstract
This paper analyzes the advantages and the drawbacks of using the Synthetic Aperture Radar (SAR) azimuth multichannel technique known as Multi-Aperture Processing Scheme (MAPS), in a set of relevant application cases that are far from the canonical ones. In the scientific literature on [...] Read more.
This paper analyzes the advantages and the drawbacks of using the Synthetic Aperture Radar (SAR) azimuth multichannel technique known as Multi-Aperture Processing Scheme (MAPS), in a set of relevant application cases that are far from the canonical ones. In the scientific literature on this topic, equally distributed azimuth channels with the quasi-monostatic deployment are assumed. With this research, we aim at extending the models from the current literature to (i) a generic bistatic acquisition geometry, (ii) a set of cases where the number of receiving tiles is not the same for each channel, or (iii) the tiles are shared between adjacent channels thus creating an overlapping configuration. The paper introduces the mathematical models for the listed non-conventional MAPS cases. Dealing with the bistatic MAPS, we first solve the problem by interpreting multichannel acquisition as a bank of Linear Time Invariant (LTI) filters. Then, a more physical approach, based on discrimination of the direction of arrivals (DoAs) is pursued. The effectiveness of the two methods and the advantages of the second approach on the first are proved by using a simplified 1D end-to-end simulation. Even limiting to the monostatic configuration, the azimuth antenna tiles have always been supposed equally partitioned among the RX channels. Overcoming this limit has two advantages: (i) more MAPS possible solutions in case few azimuth tiles are available, as in the ROSE-L mission; (ii) the number of channels can be designed independently of the number of tiles, also allowing asymmetric solutions, useful for a phase array antenna with an odd number of tiles such as in the SAOCOM-1 mission. Conversely, sharing one or more receiving tiles in different receiving channels makes the input noise partially correlated. The drawback is an increase in the noise level. A trade-off is determined for the different solutions obtained using simulations with real mission parameters. The theoretical performance and the end-to-end simulations are compared. Full article
Show Figures

Figure 1

24 pages, 5746 KiB
Article
A Novel SAR Imaging Method for GEO Satellite–Ground Bistatic SAR System with Severe Azimuth Spectrum Aliasing and 2-D Spatial Variability
by Jingjing Ti, Zhiyong Suo, Yi Liang, Bingji Zhao and Jiabao Xi
Remote Sens. 2024, 16(15), 2853; https://doi.org/10.3390/rs16152853 - 3 Aug 2024
Cited by 1 | Viewed by 1580
Abstract
The satellite–ground bistatic configuration, which uses geosynchronous synthetic aperture radar (GEO SAR) for illumination and ground equipment for reception, can achieve wide coverage, high revisit, and continuous illumination of interest areas. Based on the analysis of the signal characteristics of GEO satellite–ground bistatic [...] Read more.
The satellite–ground bistatic configuration, which uses geosynchronous synthetic aperture radar (GEO SAR) for illumination and ground equipment for reception, can achieve wide coverage, high revisit, and continuous illumination of interest areas. Based on the analysis of the signal characteristics of GEO satellite–ground bistatic SAR (GEO SG-BiSAR), it is found that the bistatic echo signal has problems of azimuth spectrum aliasing and 2-D spatial variability. Therefore, to overcome those problems, a novel SAR imaging method for a GEO SG-BiSAR system with severe azimuth spectrum aliasing and 2-D spatial variability is proposed. Firstly, based on the geometric configuration of the GEO SG-BiSAR system, the time-domain and frequency-domain expressions of the signal are derived in detail. Secondly, in order to avoid the increasing cost caused by traditional multi-channel reception technology and the processing burden caused by inter-channel errors, the azimuth deramping is executed to solve the azimuth spectrum aliasing of the signal under the special geometric structure of GEO SG-BiSAR. Thirdly, based on the investigation of azimuth and range spatial variability characteristics of GEO SG-BiSAR in the Range Doppler (RD) domain, the azimuth spatial variability correction strategy is proposed. The signal corrected by the correction strategy has the same migration characteristics as monostatic radar. Therefore, the traditional chirp scaling function (CSF) is also modified to solve the range spatial variability of the signal. Finally, the two-dimensional spectrum of GEO SG-BiSAR with modified chirp scaling processing is derived, followed by the SPECAN operation to obtain the focused SAR image. Furthermore, the completed flowchart is also given to display the main composed parts for GEO SG-BiSAR imaging. Both azimuth spectrum aliasing and 2-D spatial variability are taken into account in the imaging method. The simulated data and the real data obtained by the Beidou navigation satellite are used to verify the effectiveness of the proposed method. Full article
Show Figures

Graphical abstract

22 pages, 8344 KiB
Article
Impact Analysis and Compensation Methods of Frequency Synchronization Errors in Distributed Geosynchronous Synthetic Aperture Radar
by Xiaoying Sun, Leping Chen, Zhengquan Zhou, Huagui Du and Xiaotao Huang
Remote Sens. 2024, 16(8), 1470; https://doi.org/10.3390/rs16081470 - 21 Apr 2024
Cited by 2 | Viewed by 1545
Abstract
Frequency synchronization error, as one of the inevitable technical challenges in distributed synthetic aperture radar (SAR), has different impacts on different SAR systems. Multi-monostatic SAR is a typical distributed configuration where frequency synchronization errors are tiny in distributed airborne and low earth orbit [...] Read more.
Frequency synchronization error, as one of the inevitable technical challenges in distributed synthetic aperture radar (SAR), has different impacts on different SAR systems. Multi-monostatic SAR is a typical distributed configuration where frequency synchronization errors are tiny in distributed airborne and low earth orbit (LEO) SAR systems. However, due to the long time delay and long synthetic aperture time, the imaging performance of a multi-monostatic geosynchronous (GEO) SAR system is affected by frequency oscillator errors. In this paper, to investigate the frequency synchronization problem in this configuration, we firstly model the echo signals with the frequency synchronization errors, which can be divided into fixed frequency errors and random phase noise. Secondly, we talk about the impacts of the two kinds of errors on imaging performance. To solve the problem, we thirdly propose an autofocus back-projection (ABP) algorithm, which adopts the coordinate descent method and iteratively adjusts the phase error estimation until the image reaches its maximum sharpness. Based on the characteristics of the frequency synchronization errors, we further propose the Node ABP (NABP) algorithm, which greatly reduces the amount of storage and computation compared to the ABP algorithm. Finally, simulations are carried out to validate the effectiveness of the ABP and NABP algorithms. Full article
Show Figures

Figure 1

13 pages, 1367 KiB
Technical Note
Wide-Angle Repeat Pass Bistatic SAR Interferometry: A Geometrical Introduction
by Fabio Rocca
Remote Sens. 2024, 16(8), 1339; https://doi.org/10.3390/rs16081339 - 11 Apr 2024
Viewed by 1241
Abstract
Positioning a Synthetic Aperture Radar (SAR) receiver at a significant distance from an illuminator in a Low Earth Orbit (LEO) enables wide-angle repeat-pass bistatic interferometry. It’s crucial to define the positioning limits of the receiver with respect to the illuminator to ensure reasonable [...] Read more.
Positioning a Synthetic Aperture Radar (SAR) receiver at a significant distance from an illuminator in a Low Earth Orbit (LEO) enables wide-angle repeat-pass bistatic interferometry. It’s crucial to define the positioning limits of the receiver with respect to the illuminator to ensure reasonable coherences, altitudes of ambiguity, and a suitable common wavenumber support. I extended the standard monostatic formula, which yields the change in the interferometric travel path due to the vertical baseline. In the wide-angle bistatic case, the range-azimuth coordinate system is no longer orthogonal and we must consider the full 2D vector nature of the LOS orthogonal components. The two vertical baselines and the horizontal baseline of the receiver are needed to parameterize the system. Their impact on the interferometric coherence is quantified and bistatic limits are seen to be more flexible than those in the monostatic case due to the combination of independent baselines. I estimated the coherence, and then extended the analysis to the wavenumber domain, to quantify the common spectral support due to the wavenumber shifts due to the three baselines. The analysis carried out geometrically allows for combining together the effects of the transmitter’s and receiver’s vertical baselines and thus representing the residual spectral fraction with two instead of three parameters. Finally, I examined the achievable spatial resolution of the position of the interferer obtainable from the delay of the arrival of the interference between the illuminator (supposed to be silent) and the receiver. Full article
(This article belongs to the Section Engineering Remote Sensing)
Show Figures

Figure 1

24 pages, 13657 KiB
Article
Unmanned Airborne Bistatic Interferometric Synthetic Aperture Radar Data Processing Method Using Bi-Directional Synchronization Chain Signals
by Jinbiao Zhu, Bei Lin, Jie Pan, Yao Cheng, Xiaolan Qiu, Wen Jiang, Yuquan Liu and Mingqian Liu
Remote Sens. 2024, 16(5), 769; https://doi.org/10.3390/rs16050769 - 22 Feb 2024
Viewed by 1703
Abstract
The bistatic Interferometric Synthetic Aperture Radar (InSAR) system can overcome the physical limitations imposed by the baseline of monostatic dual-antenna InSAR. It provides greater flexibility and can enhance elevation measurement accuracy through a well-designed baseline configuration. Unmanned aerial vehicles (UAVs) equipped with bistatic [...] Read more.
The bistatic Interferometric Synthetic Aperture Radar (InSAR) system can overcome the physical limitations imposed by the baseline of monostatic dual-antenna InSAR. It provides greater flexibility and can enhance elevation measurement accuracy through a well-designed baseline configuration. Unmanned aerial vehicles (UAVs) equipped with bistatic InSAR, having relatively low cost and high flexibility, are useful for mapping and land resource exploration. However, due to challenges including spatiotemporal synchronization and motion errors, there are limited reports on UAV-borne bistatic InSAR. This paper proposes a comprehensive method for processing data from small UAV-borne bistatic InSAR by integrating two-way synchronization chain signals. The proposed method includes compensation for time and phase synchronization errors, trajectory refinement with synchronized chain and Position and Orientation System (POS) data, high-precision bistatic InSAR imaging, and interferometric processing. Height inversion results based on the proposed method are also provided, which demonstrate the effectiveness of the proposed method in improving the accuracy of interferometric measurement at calibration points from 0.66 m to 0.42 m. Full article
(This article belongs to the Special Issue Advances in Synthetic Aperture Radar Data Processing and Application)
Show Figures

Graphical abstract

21 pages, 33199 KiB
Article
Mining Deformation Monitoring Based on Lutan-1 Monostatic and Bistatic Data
by Yanan Ji, Xiang Zhang, Tao Li, Hongdong Fan, Yaozong Xu, Peizhen Li and Zeming Tian
Remote Sens. 2023, 15(24), 5668; https://doi.org/10.3390/rs15245668 - 8 Dec 2023
Cited by 17 | Viewed by 2094
Abstract
Coal mining leads to surface subsidence, landslides, soil erosion and other problems that seriously threaten the life and property safety of residents in mining areas, and it is urgent to obtain mining subsidence information using high-frequency, high-precision and large-scale monitoring methods. Therefore, this [...] Read more.
Coal mining leads to surface subsidence, landslides, soil erosion and other problems that seriously threaten the life and property safety of residents in mining areas, and it is urgent to obtain mining subsidence information using high-frequency, high-precision and large-scale monitoring methods. Therefore, this paper mainly studies the deformation monitoring of the Datong mining area using Lutan-1 monostatic and bistatic SAR data. Firstly, the latest Lutan-1 bistatic data are used to reconstruct the DSM, and the interferometric calibration method is used to improve the accuracy of the DSM. Then, the surface deformation monitoring of the mining area is implemented by using DInSAR, SBAS-InSAR and Stacking-InSAR with the reconstructed DSM data and Lutan-1 monostatic SAR data. Finally, the deformation monitoring results are compared with the surface deformation results based on the TanDEM data, and both the results are evaluated using the filed leveling data. Taking 20 images covering the Datong mining area as the data sources, the surface deformation results obtained using different InSAR methods in the mining area were quantitatively evaluated and analyzed. The results indicated that: (1) the DSM obtained using the Lutan-1 bistatic SAR data was assessed and demonstrated with the ICESat laser altimetry data an error of 2.8 m, which meets the Chinese 1:50,000 scale DEM cartographic accuracy standard, and the difference analysis with the TanDEM data shows that the terrain changes are mainly distributed in mountainous areas; (2) Due to the improvement in resolution, the registration accuracy of the SAR images and LT-DSM is higher than that of the TanDEM data in the range direction and azimuth direction; (3) Via evaluation with the filed leveling data, it is found that the surface deformation measurement results based on LT-DSM are less affected by terrain, and the accuracy of LT-DSM-SBAS and LT-DSM-DInSAR is improved by 11.5% and 16.3%, respectively, compared with TanDEM-SBAS and TanDEM-DInSAR, which demonstrates the effectiveness of the Lutan-1 bistatic and monostatic data for mine deformation monitoring. Full article
(This article belongs to the Topic Radar Signal and Data Processing with Applications)
Show Figures

Figure 1

24 pages, 24233 KiB
Article
First Assessment of Bistatic Geometric Calibration and Geolocation Accuracy of Innovative Spaceborne Synthetic Aperture Radar LuTan-1
by Jingwen Mou, Yu Wang, Jun Hong, Yachao Wang, Aichun Wang, Shiyu Sun and Guikun Liu
Remote Sens. 2023, 15(22), 5280; https://doi.org/10.3390/rs15225280 - 7 Nov 2023
Cited by 7 | Viewed by 1987
Abstract
LuTan-1 (LT-1) is a bistatic synthetic aperture radar (BiSAR) system consisting of two identical L-band SAR satellites. The bistatic mode of LT-1 plays a critical role in generating high-precision digital elevation models (DEMs), which requires precise geometric calibration of initial range and azimuth [...] Read more.
LuTan-1 (LT-1) is a bistatic synthetic aperture radar (BiSAR) system consisting of two identical L-band SAR satellites. The bistatic mode of LT-1 plays a critical role in generating high-precision digital elevation models (DEMs), which requires precise geometric calibration of initial range and azimuth times for both SARs to ensure the reliability and quality of geolocation. However, existing geometric calibration methods predominantly focus on monostatic SAR systems, with limited literature on slave SAR calibration in bistatic systems. This research addresses this gap by establishing geometric calibration models for both SARs based on signal echo history and the range–Doppler model. The geometric errors are effectively resolved using corner reflector data from Xinjiang, China. Through statistical analysis of LT-1 SAR images acquired between July and November in bistatic mode, this paper has demonstrated range delay accuracy of better than 5 ns and azimuth time accuracy of better than 0.1 ms. This level of precision translates into a positional accuracy better than 0.8 m. The proposed models have been successfully applied to geometric calibration, providing precise geolocation for LT-1, thus enhancing its utility for a wide range of Earth observation applications. This paper is the first endeavor to present the assessment of the geometric calibration and geolocation accuracy of LT-1 and discuss the results of the bistatic geometric calibration of the master and slave SARs in a BiSAR formation. Full article
(This article belongs to the Special Issue Spaceborne SAR Calibration Technology)
Show Figures

Figure 1

23 pages, 19153 KiB
Article
A Modified NLCS Algorithm for High-Speed Bistatic Forward-Looking SAR Focusing with Spaceborne Illuminator
by Yuzhou Liu, Yachao Li, Xuan Song and Xuanqi Wang
Remote Sens. 2023, 15(6), 1699; https://doi.org/10.3390/rs15061699 - 21 Mar 2023
Cited by 2 | Viewed by 2027
Abstract
The coupling and spatial variation of range and azimuth parameters is the biggest challenge for bistatic forward-looking SAR (BFSAR) imaging. In contrast with the monostatic SAR and translational invariant bistatic SAR (TI-BSAR), the range cell migration (RCM), and Doppler parameters of high-speed bistatic [...] Read more.
The coupling and spatial variation of range and azimuth parameters is the biggest challenge for bistatic forward-looking SAR (BFSAR) imaging. In contrast with the monostatic SAR and translational invariant bistatic SAR (TI-BSAR), the range cell migration (RCM), and Doppler parameters of high-speed bistatic forward-looking SAR (HS-BFSAR) have two-dimensional spatial variation characteristics, which makes it difficult to obtain SAR images with satisfactory global focusing. Firstly, based on the configuration of the spaceborne illuminator and high-speed forward-looking receiving platform, the accurate range-Doppler domain expression of the echo signal is derived in this paper. Secondly, using this analytical expression, a range nonlinear chirp scaling (NLCS) is proposed to equalize the RCM and equivalent range frequency modulation (FM) rate so that they can be uniformly processed in the two-dimensional frequency domain. Next, in the azimuth processing, the proposed method decomposes the Doppler contribution of the transmitter and receiver, respectively. Then, an azimuth NLCS is used to eliminate the spatial variation of the azimuth FM rate. Finally, a range-dependent azimuth filter is constructed to achieve azimuth compression. Simulation results validate the efficiency and effectiveness of the proposed algorithm. Full article
(This article belongs to the Special Issue Breakthroughs in Passive Radar Technologies)
Show Figures

Figure 1

18 pages, 4187 KiB
Review
Real Representation of the Polarimetric Scattering Matrix for Monostatic Radar
by Madalina Ciuca, Gabriel Vasile, Andrei Anghel, Michel Gay and Silviu Ciochina
Remote Sens. 2023, 15(4), 1037; https://doi.org/10.3390/rs15041037 - 14 Feb 2023
Cited by 1 | Viewed by 2658
Abstract
Synthetic aperture radar with polarimetric diversity is a powerful tool in remote sensing. Each pixel is described by the scattering matrix corresponding to the emission/reception polarization states (usually horizontal and vertical). The algebraic real representation, a block symmetric matrix form, is introduced to [...] Read more.
Synthetic aperture radar with polarimetric diversity is a powerful tool in remote sensing. Each pixel is described by the scattering matrix corresponding to the emission/reception polarization states (usually horizontal and vertical). The algebraic real representation, a block symmetric matrix form, is introduced to adopt a more comprehensive framework (non-restricted by reciprocity assumptions) in mapping the scattering matrix by the consimilarity equivalence relation. The proposed representation can reveal potentially new information. For example, its eigenvalue decomposition, which is itself a necessary step in obtaining the consimilarity transformation products, may be useful in characterizing the degree of reciprocity/nonreciprocity. As a consequence, it can be employed in testing the reciprocity compliance assumed with monostatic PolSAR data. Full-wave simulated polarimetric data confirm that oriented scatterers can present complex eigenvalues, even with the monostatic geometry. Full article
Show Figures

Figure 1
