Endoscopy has made a significant and noteworthy contribution to the field of medical science and technology. Nevertheless, its potential remains constrained due to the limited availability of rigid or flexible endoscopes. This paper introduces a novel hydraulic actuator based on electrorheological fluid (ERF) as a pivotal advancement in bridging the existing gap within the realm of endoscopy. Following a comprehensive introduction that briefly outlines the electrorheological effect, the subsequent section is dedicated to the elucidation of the actuator’s development process. Challenges arise, particularly in terms of miniaturization and the realization of a hydraulically sealed system with integrated valve electrodes. An internal electrorheological valve system consisting of four valves that are controlled using a pulse-width modulated high voltage was suitable for position control of the antagonistic hydraulic actuators. High-precision stereolithography (SLA) printing has proven practical for manufacturing actuator components. For functional testing, a test bench was set up in which the actuator follows a setpoint through a PI control loop. The control deviation ranged from 0.6 to 1 degree, with a response time between 6 and 8 s. The experiments have demonstrated that through the use of ERF and integrated valve electrodes, a miniaturized functional actuator can be constructed. Full article

The electro-hydrostatic actuator (EHA) is a new type of high-performance servo actuator that originated in the field of aerospace, and it is gradually becoming a common basic component for various types of large equipment. A miniature EHA, mainly composed of a micro two-dimensional (2D) piston pump and a brushless DC motor, is designed in this article by simplifying the system structure. This paper analyzes the structure and working principle of this EHA and establishes the mathematical models of the brushless DC motor, micro two-dimensional pump, and hydraulic cylinder. Field-oriented control (FOC) is used to drive the brushless DC motor, and the models of the controller are established in Simulink. Furthermore, the models of the mechanical and hydraulic systems of the miniature EHA are established in AMESim. In addition to this, a prototype of this miniature EHA was fabricated in this paper and an experimental platform was built for experiments. In the joint simulation environment, the rise time of the EHA system at 6000 r/min is 0.158 s and the frequency response amplitude attenuation to −3 dB has a bandwidth of 20 Hz. On the other hand, the constructed miniature EHA prototype was dynamically characterized to obtain a rise time of 0.242 s at 6000 r/min and a bandwidth of 13 Hz. In this paper, the feasibility of the design scheme of the miniature EHA system is verified, and its excellent dynamic properties are verified with simulation and experiment. Full article

Aligned with the medical device industry’s trend of miniaturization, academic and commercial researchers are constantly attempting to reduce device sizes. Many applications require miniature actuators (2 mm range) to perform mechanical work; however, biocompatible micromotors are not readily available. To that end, a hydraulic motor-driven cutting module that aims to combine cutting and drug delivery is presented. The hydraulic motor prototype developed has an outside diameter (OD) of ~4 mm (twice the target size) and a 1 mm drive shaft to attach a cutter. Four different designs were explored and fabricated using additive manufacturing. The benchtop experimental data of the prototypes are presented herein. For the prototype motor with fluid inlet perpendicular to the blades, the average angular velocity was 10,593 RPM at a flowrate of 3.6 mL/s and 42,597 RPM at 10.1 mL/s. This design was numerically modeled using 3D-transient simulations in ANSYS CFX (version 2022 R2) to determine the performance characteristics and the internal resistance of the motor. Simplified mathematical models were also used to compute and compare the peak torque with the simulation estimates. The viability of current design represents a crucial milestone in scaling the hydraulic motor to a 2 mm OD to power a microcutter. Full article

Palpation is a simple but effective method to distinguish tumors from healthy tissues. The development of miniaturized tactile sensors embedded on endoscopic or robotic devices is key to achieving precise palpation diagnosis and subsequent timely treatment. This paper reports on the fabrication and characterization of a novel tactile sensor with mechanical flexibility and optical transparency that can be easily mounted on soft surgical endoscopes and robotics. By utilizing the pneumatic sensing mechanism, the sensor offers a high sensitivity of 1.25 mbar and negligible hysteresis, enabling the detection of phantom tissues with different stiffnesses ranging from 0 to 2.5 MPa. Our configuration, combining pneumatic sensing and hydraulic actuating, also eliminates electrical wiring from the functional elements located at the robot end-effector, thereby enhancing the system safety. The optical transparency path in the sensors together with its mechanical sensing capability open interesting possibilities in the early detection of solid tumor as well as in the development of all-in-one soft surgical robots that can perform visual/mechanical feedback and optical therapy. Full article

Miniature hydraulic actuators are especially suitable for narrow-space and harsh environment arrangement. However, when using thin and long hoses to connect components, the volume expansion caused by pressurized oil inside can have significant adverse effects on the performance of the miniature system. Moreover, the volumetric variation relates to many uncertain factors that are difficult to describe quantitatively. This paper conducted an experiment to test the hose deformation characteristics and presents the Generalized Regression Neural Network (GRNN) to describe the hose behavior. On this basis, a system model of a miniature double-cylinder hydraulic actuation system was established. To decrease the impact of nonlinearity and uncertainty on the system, this paper proposes a Model Predictive Control (MPC) based on Augmented Minimal State-Space (AMSS) model and Extended State Observer (ESO). The extended state space acts as the prediction module model for the MPC, and the disturbance of the ESO estimates is fed to the controller to improve the anti-disturbance capability. The full system model is validated by comparison between the experiment and the simulation. For a miniature double-cylinder hydraulic actuation system, the proposed MPC-ESO control strategy contributes to a better dynamic than conventional MPC and fuzzy-PID. In addition, the position response time can be reduced by 0.5 s and achieves a 4.2% reduction in steady-state error, especially for high-frequency motion. Moreover, the actuation system with MPC-ESO exhibits better performance in suppressing the influence of the load disturbance. Full article

Digital hydraulic drives are known for their superior efficiency, power density, and robustness. Such advantages make them an attractive alternative (to electric drives) for actuation of exoskeleton devices. This work presents development of a prototype for such a digital hydraulically driven knee exoskeleton and its experimental testing. The device uses two miniature hydraulic cylinders and a novel mechanism to translate the linear motion to rotary motion. The device is controlled via a passive control method in the stance phase and a simplified model predictive control method in the swing phase. In this work, the design of the exoskeleton device is optimized with respect to compactness and weight. Next, the features of the design are further refined to ensure that the device is able to support the operational loads. This design is then realized into a prototype with a mixture of inhouse manufactured parts and procured components. Finally, via experimental tests, the performance of the design and the control strategy are investigated. Certain drawbacks related to valve size and overall weight are observed in the prototype, which will be addressed in future studies. Full article

Low-cost small-scale (<100 W) electrohydrostatic actuators (EHAs) are not available on the market, largely due to a lack of suitable components. Utilizing plastic 3D printing, a novel inverse shuttle valve has been produced which, when assembled with emerging small-scale hydraulic pumps and cylinders from the radio-controlled hobby industry, forms a low-cost and high-performance miniature EHA. This paper presents experimental test results that characterize such a system and highlight its steady, dynamic, and thermal performance capabilities. The results indicate that the constructed EHA has good hydraulic efficiency downstream of the pump and good dynamic response but is limited by the efficiency of the pump and the associated heat generated from the pump’s losses. The findings presented in this paper validate the use of a 3D printed plastic inverse shuttle valve in the construction of a low-cost miniature EHA system. Full article

Electro hydrostatic actuator (EHA) has been successfully developed for flight control applications to replace the cumbersome centralized hydraulic system. It also has excellent potential for ocean applications due to its advantages on miniaturization and energy-savings. One of the special technologies for EHA’s underwater application is pressure compensation, which is used to equalize the return pressure of the hydraulic system and the seawater pressure. This paper investigates the modeling and control design of underwater EHA to improve performance, especially considering the effect of additional pressure compensator and uncertain external load. The nonlinear hydraulic model is extended by the dynamic characteristics of the pressure compensator. Two low-order extended state observers were constructed to cope with the external load fore and the effect of the pressure compensator, respectively. The backstepping methods were designed to guarantee the robust stability of the entire high-order nonlinear hydraulic system. Finally, the theoretical proving and simulation on Matlab/Simulink are conducted to demonstrate the high tracking performance of the proposed control strategy. Full article

In this paper, the design and testing of a novel valve for the intuitive spatial control of soft or continuum manipulators are presented. The design of the valve is based on the style of a hydraulic flapper valve, but with simultaneous control of three pressure feed points, which can be used to drive three antagonistically arranged hydraulic actuators for positioning soft robots. The variable control orifices are arranged in a rotationally symmetric radial pattern to allow for an inline mounting configuration of the valve within the body of a manipulator. Positioning the valve ring at various 3D configurations results in different pressurizations of the actuators and corresponding spatial configurations of the manipulator. The design of the valve is suitable for miniaturization and use in applications with size constraints such as small soft manipulators and surgical robotics. Experimental validation showed that the performance of the valve can be reasonably modeled and can effectively drive an antagonistic arrangement of three actuators for soft manipulator control. Full article

As the power sources in hydraulic systems, variable displacement axial piston pumps generate flow fluctuation. Unfortunately, it results in pressure pulsation which excites the system vibration and emitted noise. The majority of studies try to eliminate the pulsation via a passive technique and the active control methodology has not been discussed in detail. In this research, the feasibility of reducing the pressure ripple by properly controlling the proportional valve has been investigated, which also supports the miniaturization of the active control system. A mathematical model of the self-supplied variable displacement pump including the control system has been developed. The filtered-X least mean square algorithm with time-delay compensation is utilized to calculate the active control signal. Simulation results show the effectiveness of the active control technique. The effect of the active control signal on the flow rate from different chambers of the pump has been analyzed. It demonstrates that the variation of the pressure pulsation should be ascribed to the comprehensive reaction of different flow rates. The major reason is that the flow of the actuator piston neutralizes the peak value of the flow ripple, generated by the nine pistons. Full article

The technology for stepper drive that can achieve accurate motion in the hydraulic field has always been urgently needed in the industry. This paper proposes a hydraulic stepper drive based on five high speed on/off valves and two miniature plunger cylinders. The stepper drive discretizes the continuous flow medium into fixed small steps through the miniature plunger cylinder and realizes the state control of the drive through the logic action of the high speed on/off valve. This paper improves the current stepper drive and establishes a mathematical model to analyze the error of the drive and calculate the position of the actuator. In addition, through simulation research, the performance parameters such as the single-step step characteristic and pressure characteristic of the stepper drive are studied. The results show that, compared with the technology of current stepper drive, this stepper drive can effectively remove the “post step” phenomenon, greatly improve the stepper accuracy of the stepper drive, and have a more excellent performance. Full article

Hydraulic linear actuators dominate in high power applications but are much less common in low power (<100 W) systems. One reason for this is the cost: electric actuators in this power range generally exhibit lower performance but are also much less expensive than hydraulic systems. However, in recent years, some miniature hydraulic components have been mass produced, driving down prices. This paper presents the application of these low-cost components, together with a novel very low-cost 3D-printed valve to create an electrohydrostatic actuator. Capable of very high power and force density, this system is competitive on cost with lower-performing electric actuators. This paper presents models for the system’s performance, as well as experimental validation data. Full article

When exposed to viscous heating, hydraulic valve orifices experience thermal deformation, which causes spool clamping and actuator disorder. Quantitative research on thermal deformation can help reveal the micro-mechanism of spool clamping. In this study, miniature thermocouples are embedded into a valve orifice with an opening size of 1 mm to measure temperature distribution. An optimization algorithm based on measurement data (M-OA) for the thermal deformation of the valve orifice is proposed. The temperature and thermal deformation of the valve orifice are calculated through Fluent and Workbench joint simulation, with the measurement data serving as boundary conditions. Results show that, for a valve orifice with a valve wall length of 18 mm, when the temperature of the sharp edge is at 60 °C, thermal deformation measures 7.7 μm via observation and 7.62803 μm via M-OA, indicating that the M-OA method is reliable. The results of the joint simulation can be accepted because measurements of temperature reached an accuracy rate of 95%, and that of deformation reached 82.7%. A large drop in pressure led to a rapid increase in temperature, causing serious thermal deformation of the valve orifice. With an inlet pressure of 3 MPa, the temperature of the sharp edge reached 72.9 °C within 110 min, and radial thermal deformation can reach 8.3 μm. Such deformation poses great risk of spool clamping for a spool valve of Φ36 mm. Full article

During recent decades, strain gauge-based joint torque sensors have been commonly used to provide high-fidelity torque measurements in robotics. Although measurement of joint torque/force is often required in engineering research and development, the gluing and wiring of strain gauges used as torque sensors pose difficulties during integration within the restricted space available in small joints. The problem is compounded by the need for a scalable geometric design to measure joint torque. In this communication, we describe a novel design of a strain gauge-based mono-axial torque sensor referred to as square-cut torque sensor (SCTS), the significant features of which are high degree of linearity, symmetry, and high scalability in terms of both size and measuring range. Most importantly, SCTS provides easy access for gluing and wiring of the strain gauges on sensor surface despite the limited available space. We demonstrated that the SCTS was better in terms of symmetry (clockwise and counterclockwise rotation) and more linear. These capabilities have been shown through finite element modeling (ANSYS) confirmed by observed data obtained by load testing experiments. The high performance of SCTS was confirmed by studies involving changes in size, material and/or wings width and thickness. Finally, we demonstrated that the SCTS can be successfully implementation inside the hip joints of miniaturized hydraulically actuated quadruped robot-MiniHyQ. This communication is based on work presented at the 18th International Conference on Climbing and Walking Robots (CLAWAR). Full article
