Search Results (36)

Offshore wind power has a broad development prospect, but with the development of offshore wind farms to the deep sea, the traditional high-voltage AC transmission has been difficult to adapt to the offshore wind power transmission distance and transmission capacity needs. A flexible DC transmission system applying modular multilevel converter is a common scheme for offshore wind power, which has been put into use in actual projects, but it is still facing the problems of high cost of offshore converter station platforms and high loss of collector systems. In order to improve the economy and reliability of the medium- and long-distance offshore wind power delivery systems, this paper proposes a diode rectifier-based medium-frequency AC pooling soft-direct low-cost delivery system for medium- and long-distance offshore wind power. Firstly, the mid-frequency equivalent model of the diode converter is established, and the influence of topology and frequency enhancement on the parameters of the main circuit equipment is analysed; then, the distribution parameters and transmission capacity of the mid-frequency cable are calculated based on the finite element modelling of the marine cable, and the transmission losses of the mid-frequency AC pooling system are then calculated, including the collector losses, converter valve losses, and transformer losses, etc. Finally, an economic analysis is carried out based on a specific example, comparing with the Jiangsu Rudong offshore wind power transmission project, in order to verify the economy of the medium-frequency AC flexible and direct transmission system of the medium- and long-distance offshore wind power using diode rectifier technology. Full article

Power cables transmit electricity from offshore wind turbines (OWTs) to consumers. The configuration, design, and optimization of power cables for floating offshore wind turbines (FOWTs) are subject to various objectives, variables, and constraints. These components are outlined, and existing research gaps that need to be addressed for a more sustainable and robust design for future developments are highlighted. The main aim of power cable configuration design is to optimize performance and minimize costs. This can be achieved through thoughtful consideration of variables like power cable selection, configuration design, and the integration of specialized components and ancillaries. An extensive overview of constraints for power cable configuration design is provided, and the most important ones are identified. The local conditions determine which constraints are of key importance in optimization. Environmental factors like wind, waves, and especially currents significantly influence design processes, introducing uncertainties when comprehensive data are lacking. Marine growth posed a significant challenge in prior FOWT projects and must be considered carefully. Considering the potential impact of climate change is crucial, especially for extreme weather events. Early integration of environmental considerations and assessment of effects on socio-economic impacts is essential for a successful project. The power cable response is also influenced by its inherent limitations, including tension and compression thresholds, curvature constraints, and the necessary minimum fatigue life. A flowchart is provided to aid in choosing variables and constraints in the design and optimization processes. Full article

Distributed Acoustic Sensing (DAS) technology presents an innovative method for marine monitoring by adapting existing underwater optical fiber networks. This paper examines the use of DAS with the Istituto Nazionale di Fisica Nucleare–Laboratori Nazionali del Sud (INFN-LNS) optical fiber infrastructure in the Gulf of Catania, Eastern Sicily, Italy. This region in the Western Ionian Sea provides a unique natural laboratory due to its tectonic and volcanic activity, proximity to Mount Etna, diverse marine ecosystems and significant human influence through maritime traffic. By connecting a 28 km long optical cable to an Alcatel Submarine Network OptoDAS interrogator, DAS successfully detected a range of natural and human–made signals, including a magnitude 3.5 ML earthquake recorded on 14 November 2023, and acoustic signatures from vessel noise. The earthquake–induced Power Spectral Density (PSD) increased to up to 30 dB above background levels in the 1–15 Hz frequency range, while vessel noise exhibited PSD peaks between 30 and 60 Hz with increases of up to 5 dB. These observations offered a detailed spatial and temporal resolution for monitoring seismic wave propagation and vessel acoustic noise. The results underscore DAS’s capability as a robust tool for the continuous monitoring of the rich underwater environments in the Gulf of Catania. Full article

The marine controlled source electromagnetic (MCSEM) transmitter can transmit high currents near the seabed to detect the electrical structure of the seafloor. The use of three-phase alternating current (AC) transmission can lead to three-phase imbalance, which results in an excessive current in one phase’s power line and affects the safety of the tow cable. This paper proposes an MCSEM underwater constant high-voltage direct-current (DC) switching scheme that replaces AC transmission with DC transmission. This scheme can fundamentally avoid three-phase imbalance and the AC loss caused by inductance. After establishing a simulation model to analyze the effect of the scheme, the relevant hardware units were designed. The hardware unit mainly consists of three parts: a DC switching inverter unit, a filter unit, and a step-down rectification unit. The DC inverter unit controls six insulated gate bipolar transistor (IGBT) modules with sinusoidal pulse width modulation (SPWM) signals to convert DC to three-phase AC power; the filter unit filters out extra harmonic components; and the step-down rectification unit converts high-voltage three-phase AC to low-voltage DC. The scheme ultimately achieved an adjustable DC output of 48.3–73.4 V under a constant DC input voltage of 3000 V and effectively reduced the current on the cable. This scheme has the potential to replace the previous AC transmission, reducing the risk of tow cable burnout and enhancing the safety of MCSEM operations. Full article

Greece is expanding its energy grid system with submarine power and fiber optic cables between the mainland and the Aegean Sea islands. Additionally, pipelines have been installed to support natural gas facilities, and sites are being demarcated for the development of offshore wind parks. The above developments have necessitated extensive geotechnical surveying of the seabed; however, the survey data cannot be accessed for academic inspection or for desktop studies of future developments. This is further hindered by the limited geotechnical information in the Aegean and Ionian Seas. This review examines the existing information concerning the geotechnical behavior of the surficial sedimentary layers, including certain challenges associated with geotechnical sampling and CPTu interpretation. Certain prospects are discussed regarding marine geotechnical research in Greece, with examples from other European countries. The marine geotechnical data in Greece include geotechnical analyses of sediments cores and slope stability estimations, which are commonly associated with the seismic profiling of unstable slope areas. Underlying mechanisms of slope failure have mainly been attributed to the interbedded presence of weak layers (e.g., sapropels, tephra and underconsolidated sediments), the presence of gas and the cyclic loading from earthquake activity. Due to the limited geotechnical information, geological studies have contributed considerably to describing the distributions of gravity-induced events and lithostratigraphy. Within this context, a geological/geotechnical database is suggested where data can be collated and utilized for future studies. Full article

With the development of the social economy and the improvement of electrification, cables and wires play an important role in people’s lives and industrial development. Meanwhile, the large-scale laying of cables has also made them a fire hazard that cannot be ignored in land construction such as residential buildings, utility tunnels, nuclear power plants, refineries, marine systems such as submarines and ships, and airborne systems such as spacecrafts and aircrafts. In this work, studies on fire the characteristics of cables and wires over the last decades have been reviewed. Based on different experimental forms and objects (laboratory wires and commercial cables), this paper summarizes the theories of the fire dynamics in wire combustion, including the models of ignition and flame propagation, the criteria for blowing off and quenching, and the critical conditions for dripping behavior. The effects of materials, layouts, and environments on wire combustion phenomena such as airflow, ambient pressure, oxygen, gravity, and orientation angle have been discussed in detail according to the theories of heat transfer and combustion. In addition, test standards and studies on the fire behavior and release of toxic gases of commercial cables have also been fully described. Through the summary of the above content, it is expected to build a preliminary theoretical framework and future research directions for researchers in the field of cable fires. Full article

In order to address the requirements of scientific multidisciplinary observation in diverse small-scale regions, we have introduced the Buoy-based Cable Seafloor Observatory System (BCSOS). This system offers a distinct advantage in contexts where the use of shorter cables is feasible, contrasting with the lengthy cables typically necessary for conventional observatories. The BCSOS consists of three primary components: the Real-Time Electric Communication (RTEC) Buoy, the Power Information Transmission System (PITS), and the Seafloor Observation Subsystem (SOS). The RTEC Buoy is equipped with instruments for measuring sea surface parameters and serves as a data and power hub. The PITS, comprising a robust EM cable, connects the buoy to the SOS, which houses instruments for seafloor observations. The system is designed for a maximum water depth of 100 m and has an expected lifespan of about 5 years. The BCSOS prototypes were deployed at the Huangqi Peninsula, Fujian Province, and successfully documented the process during Typhoon Doksuri (international code 2305) at the end of July 2023. The recorded data from the BCSOS revealed a significant increase in wave height and period as the storm approached the Huangqi Peninsula. Additionally, the RTEC buoy exhibited a notable response to the large waves. The data analysis revealed a distinct pattern between the buoy response and the direction of wave propagation across various sea conditions, that the buoy’s angular movement in pitch and roll directions follows a regular elliptical distribution corresponding to different wave propagation directions. Upon thorough evaluation, future enhancements to the system are slated to concentrate on refining its design, with a particular emphasis on bolstering stability and enhancing corrosion resistance. These improvements are aimed at cementing the system’s long-term viability and performance within the challenging marine environment. Full article

This research aims to develop an inexpensive ocean observation instrument with the project name NOBEL (Nusantara Oceanography Backdoor Experiment Laboratory)-BOX. The device can be installed on all types of vessels for mapping the water conditions, providing accurate data for managing a marine area, particularly regarding water quality. The principle of NOBEL-BOX is to attach six sensors in a container connected to a microcontroller and then measure specific data directly and automatically. The methodology employed included experimental design, laboratory and field tests, and data evaluation to develop the necessary system and instruments. The design process encompassed the construction of the instrument and the fabrication, involving the creation of three-dimensional drawings and the design of microcontrollers and data transmission systems and power capacity. This instrument is box-shaped with a microcontroller, sensors, a battery, and cables located inside. The testing phase included data validation, testing of the device in the laboratory, and field testing showed that the device worked. The data provided from this instrument could meet the specific criteria for seawater analysis. Full article

The exploitation and harnessing of offshore marine renewable energy have led to an increased demand for reliable marine power cables with long service lives. These cables constitute a considerable share of the total installation cost of offshore renewable energy facilities and have high maintenance and repair costs. The critical characteristics of these power cables must be determined to reduce the risk of exceeding their ultimate strength or fatigue life, which can result in unwanted and unexpected failures. This study investigates dynamic marine power cables that are suitable for application in devices that harness energy from ocean currents, waves, and tides. Tension, bending, torsion, and fatigue tests were conducted on three dynamic power cables (1 kV, 3.6 kV, and 24 kV) that have high flexibility, i.e., low mechanical stiffness. The specimen lengths and axial pretension force were varied during the tests. The results are discussed in terms of the mechanical fatigue degradation and ultimate design load, and the key observations and lessons learned from the tests are clarified. The study’s main contribution is the results from physical component testing of the dynamic marine power cables without metallic armors, which can be used to calibrate numerical models of this type of dynamic marine power cable in the initial design of, e.g., inter-array cables between floating wave energy converters. The benefits offered by this type of cable and the importance of the results for creating reliable numerical simulation models in the future are highlighted. Full article

During manufacture, handling, transportation, installation and operation, mechanical overstress can affect the electrical and thermal properties of the conductor. As the wires in general are made of copper, which is a very plastically deforming material, these stresses will gradually generate plastic deformations of the copper until the wires start to fail. The objective of this article is to study, by numerical modeling (using Comsol and Abaqus), the impact of damage mechanisms on the electrical and thermal properties of a submarine cable phase. The influence of plasticity and gradual copper wire failure on the physical behavior (electric and thermal) of the phase was assessed. The heat differences between a healthy conductor vs. a damaged one (either deformed plastically and/or with failed wires) derived from the numerical model may be an accurate indicator of the level of damage of wires, thus furthering advanced warning before being obliged to stop the exploitation because a mandatory heavy maintenance of the cables must be scheduled. Note that this can also be achieved by using an optical fiber as a sensor for structural health monitoring. This study will then make it possible to evaluate the impact of the modification of the resistance on the thermal behavior of the cable. All of these simulations will be carried out on one phase of a 36 kV 120 mm² copper submarine cable. Colloquially these are called “copper cables”, meaning cables with Cu conductors (120 mm² is the smallest conductor cross-section for array cables, which are usually 3-phase cables). Full article

Determining reliable cable ampacities for marine High Voltage Cables is currently the subject of significant industry and academic reassessment in order to optimize (maximizing load while maintaining safe operating temperatures) design and reduce costs. Ampacity models can be elaborate, and inaccuracies are increasingly predicated on the uncertainty in environmental inputs. A stark example is the role of ambient temperature at cable depth, which, due to the scale of cables and the inaccessibility of the seafloor, is commonly estimated at 15 °C. Oceanographic models incorporating ocean bottom temperature are increasingly available, and they achieve coverage and spatiotemporal resolutions for cable applications without the requirement for project specific measurements. Here, a rudimental validation of the AMM15 and AMM7 mean monthly ocean bottom temperature models for the NW European Shelf indicates encouraging accuracies (MBE ≤ 1.48 °C; RMSE ≤ 2.2 °C). A series of cable case studies are used to demonstrate that cable ratings can change between −4.1% and +7.8% relative to ratings based on a common static (15 °C) ambient temperature value. Consideration of such variations can result in both significant ratings (and hence capital expenditure and operating costs) gains and/or the avoidance of cable overheating. Consequently, validated modelled ocean bottom temperatures are deemed sufficiently accurate, providing incomparable coverage and spatiotemporal resolutions of the whole annual temperature signal, thereby facilitating much more robust ambient temperatures and drastically improving ampacity estimates. Full article

Marine submersible buoy systems hold significant value as critical equipment in marine science research. This study examines a marine submersible buoy system that includes an anchor block, mooring line, battery compartment, power supply cable, and submersible buoy. The anchor-last deployment method is a conventional strategy for deploying marine submersible systems. Initially, the other components are positioned on the sea surface, followed by the deployment of the anchor block from the ship’s deck. The anchor block will pull the battery compartment and submersible buoy into the water and eventually sink to the seabed. In this deployment process, ocean currents have a relatively large impact on the anchor block’s landing position. Increasing the weight of the anchor block will make the anchor block land on the seabed sooner, which can minimize the impact of ocean currents. However, an overabundance of weight can generate a significant strain on both the cables, potentially resulting in cable breakage. In order to find the parameters that can make the anchor block reach the seabed as soon as possible and ensure that the tension force of the cables does not exceed the maximum, a dynamic model of the deployment process is established based on computational fluid dynamics (CFD) and solved using the Runge–Kutta method of the fourth order. Particle swarm optimization is employed to optimize the key parameters. The penalty function is used to constrain the particle space. The findings indicate that the utilization of particle swarm optimization is efficacious for optimizing the parameters of submersible buoy systems for marine applications. Optimized parameters allow the anchor block to reach the seafloor quickly and the tension on the cables to not exceed the given value. Full article

The relevance of the work is connected to the energy efficiency of specialized vessels of the technical fleet. The purpose of the study was to determine and evaluate the power quality indicators associated with the non-sinusoidal shape of the voltage and current curves in the electrical power system of the marine platform support vessel, which contains powerful semiconductor propulsion electric drives, taking into account the inherent and parasitic parameters of the power three-phase cable lines. A simplified one-line diagram of an electric power system with a DC main bus was the object of the study, which was compiled as a result of the analysis of analog systems typical for the indicated type of vessels. The phenomenon of voltage and current distortion caused by the presence of higher harmonics generated by power semiconductor converters in a three-phase ship network was the subject of the research. For the experimental study of the quality of electric power according to the simplified one-line scheme of the electric power system in MATLAB Simulink, its model was created. Based on the proven methods of calculating the ship’s electrical equipment, a methodology was developed for the reliable determination of model parameters. According to the results of the experiment in MATLAB Simulink, qualitative and quantitative indicators were obtained regarding the non-sinusoidality of the linear voltage and current of the three-phase network (curve shapes, amplitude spectra, distortion coefficients), and their comparative analysis with the current norms and standards was performed. In contrast to the previous ones, the methodology for assessing the quality of electricity in the studied electric power system takes into account its circuit, mode features, and the presence of a parasitic capacitance “phase to ground” of a three-phase network, and it can be used in solving similar non-trivial tasks for various similar structurally modified systems. Full article

The marine environment in which offshore wind turbines are located is very complex and subjected to a variety of random loads that vary with time and space. As an important component of offshore wind power, the cable also bears the impact of the environment in which most of the turbines are located. Under the long-term action of mechanical stresses such as tension, torsion, and vibration, the cable insulation will crack due to stress fatigue leading to partial discharge, which seriously affects its electrical performance. The study of the mechanism of the change of electrical properties of cable insulation due to mechanical behavior is of great theoretical guidance to improve the reliable operation of cables. This paper first introduces the basic characteristics and operating conditions of torsion-resistant cables and submarine cables. Then the mechanical behavior of the cables is summarized, and the deterioration mechanism and deterioration effect of wind power cable insulation under the influence of multiple factors such as heat, oxygen, and mechanical stress are sorted out. Then, the basic principles of wind power cable operation condition monitoring methods and their characteristics are described. Finally, the relevant methods for the detection of hidden defects inside the insulation are summarized. Full article

Marine submersible buoy systems are widely-used equipment for ocean resource development. The marine submersible buoy system studied in this paper consists of the submersible buoy, the battery compartment, the anchor block, the mooring line, and the power supply cable. To study the mechanical behavior and obtain the speed variation of each component during the anchor last deployment, this paper establishes the free surface computational fluid dynamics model of marine submersible buoy systems based on the VOF method. This model includes the incompressible Navier–Stokes equations, the Renormalization-Group turbulence model, and the fractional areas/volume obstacle representation method. The free fluid surface is tracked using the VOF method. The lumped mass method is used to simulate the mooring line and power supply cable. The results showed that the tension forces increase when the mooring lines were straightened. Subsequently, the tension forces gradually decrease with oscillations. After the anchor block sinks to the sea floor, the positive buoyancy of the battery compartment and the buoy will cause large tension on the mooring line and power supply cable. Full article
