The distribution of the magnetic field generated by an electromagnetic device can provide insights into their operational condition. This paper focuses on diagnosing electrolyzers through magneto-tomography, a method which involves mapping the magnetic field generated by electrical devices. Since current density and magnetic field are directly linked, this study can characterize the normal and abnormal operation of an electrolyzer. To achieve this, a two-dimensional (2-D) Biot–Savart model in polar coordinates is developed. To validate this model for electrolyzer diagnostics, an experimental setup was established to replicate the electrolyzer operation. The purely analytical model was successfully validated, with the average difference between the analytical results and experimental measurements established. The model validation is performed by comparing the experimental data to the theoretical results, and it is observed that the difference does not exceed 5%. Full article

This review examines the use of magneto-acoustic methods to measure electrical conductivity. It focuses on two techniques developed in the last two decades: Magneto-Acoustic Tomography with Magnetic Induction (MAT-MI) and Magneto-Acousto-Electrical Tomography (MAET). These developments have the potential to change the way medical doctors image biological tissue. Full article

An original innovative two-dimensional (2D) multi-layer model based on the Maxwell–Fourier method for the diagnosis of a polymer exchange membrane (PEM) fuel cell (FC) stack is presented. It is possible to determine the magnetic field distribution generated around the PEMFC stack from the (non-)homogenous current density distribution inside the PEMFC stack. Analysis of the magnetic field distribution can indicate whether the FC is healthy or faulty. In this way, an explicit, accurate and fast analytical model can allow the health state of an FC to be studied. To evaluate the capacity and the efficiency of the 2D analytical model, the distribution of local quantities (i.e., magnetic vector potential and magnetic field) in a PEMFC stack has been validated with those obtained by the 2D finite-element analysis (FEA). The comparisons demonstrate excellent results both in terms of amplitude and waveform. The validation of this 2D analytical model is essential for the subsequent generation of an inverse model useful for the diagnosis of a PEMFC. Full article

Background. A new instrumentation exploiting magneto-dynamic technology (mallet) proposed for implant site preparation was investigated. Methods. In the tibias of three minipigs, two sites were prepared by mallet and two by drill technique. Primary stability (ISQ) was detected after implant positioning (T0) and at 14 days (T14). X-rays and computed tomography were performed. At T14, bone samples were utilized for histological and biomolecular analyses. Results. In mallet sites, histological evaluations evidenced a significant increase in the newly formed bone, osteoblast number, and a smaller quantity of fibrous tissue. These results agree with the significant BMP-4 augmentation and the positive trend in other osteogenic factors (biological and radiological investigations). Major, albeit IL-10-controlled, inflammation was present. For both techniques, at T14 a significant ISQ increase was evidenced, but no significant difference was observed at T0 and T14 between the mallet and drill techniques. In mallet sites, lateral bone condensation was observed on computed tomography. Conclusions. Using biological, histological, clinical, and radiological analyses, this study first shows that the mallet technique is effective for implant site preparation. Based on its ability to cause osseocondensation and improve newly formed bone, mallet technology should be chosen in all clinical cases of poor bone quality. Full article

Research Infrastructures (RIs) are essential to achieve excellence in innovative scientific research. However, because of limited land availability and specific geological requirements, evaluating the viability of a site for a new RI can be a challenging task. Stringent safety construction requirements include developing site-specific architectural and geoengineering solutions, minimizing construction disturbances, and reinforcing rock and soil in a timely fashion. For successful development of the RIs in China, such as the Daya Bay Neutrino Laboratory (DBNL) and the China Spallation Neutron Source (CSNS), an integrated approach of joint geophysical methods including the electrical resistivity tomography (ERT), controlled-source audio-frequency magneto telluric (CSAMT)), gravity and seismic refraction methods, and geological mapping and surveys were carried out. Geophysical parameters, such as electrical resistivity, density, and seismic velocity, show inverse proportion to the degree of rock fracturing or weathering. The results show that the low values of geophysical parameters suggest the weathered/fractured rock, while high values reveal the fresh bedrock. The Engineering Geological Suitability Index (EGSI) value can represent the individual EGSI values at a constant and summed over varying depths. EGSI methodology is an improvement on the existing siting process and has been applied to CSNS. Our integrated approach provides clearer insight into the subsurface for site suitability of RIs in challenging geological engineering conditions and removes any ambiguity caused by a single geophysical parameter. The obtained geological knowledge of the area not only provides engineers with much-needed information about the construction conditions of a potential site but also gives scientists the opportunity to explore the local geology. In this study, we demonstrate our innovative approach for siting RIs, as demonstrated by the synthetic evaluation of the site location and utilization for two established RIs (DBNL and CSNS). Full article

In this paper, we present results of tectonic and geophysical investigations in the Kenya Rift valley, in the Nakuru area. We compiled a detailed geological map of the area based on published earlier works, well data and satellite imagery. The map was then integrated with original fieldwork and cross sections were constructed. In key areas, we then performed geophysical survey using Electrical Resistivity Tomography (ERT), Hybrid Source Audio MagnetoTelluric (HSAMT), and single station passive seismic measurements (HVSR). In the study area, a volcano-sedimentary succession of the Neogene-Quaternary age characterized by basalts, trachytes, pyroclastic rocks, and tephra with intercalated lacustrine and fluvial deposits crops out. Faulting linked with rift development is evident and occurs throughout the area crosscutting all rock units. We show a rotation of the extension in this portion of the Kenya rift with the NE–SW extension direction of a Neogene-Middle Pleistocene age, followed by the E–W extension direction of an Upper Pleistocene-Present age. Geophysical investigations allowed to outline main lithostratigraphic units and tectonic features at depth and were also useful to infer main cataclasites and fractured rock bodies, the primary paths for water flow in rocks. These investigations are integrated in a larger EU H2020 Programme aimed to produce a geological and hydrogeological model of the area to develop a sustainable water management system. Full article

The development of magnetic field sensors for biomedical applications primarily focuses on equivalent magnetic noise reduction or overall design improvement in order to make them smaller and cheaper while keeping the required values of a limit of detection. One of the cutting-edge topics today is the use of magnetic field sensors for applications such as magnetocardiography, magnetotomography, magnetomyography, magnetoneurography, or their application in point-of-care devices. This introductory review focuses on modern magnetic field sensors suitable for biomedicine applications from a physical point of view and provides an overview of recent studies in this field. Types of magnetic field sensors include direct current superconducting quantum interference devices, search coil, fluxgate, magnetoelectric, giant magneto-impedance, anisotropic/giant/tunneling magnetoresistance, optically pumped, cavity optomechanical, Hall effect, magnetoelastic, spin wave interferometry, and those based on the behavior of nitrogen-vacancy centers in the atomic lattice of diamond. Full article

The magneto-rheological effects in iron-elastomer composites (IEC) were investigated by simulation, surface topography, and 3D representation. The simulated behavior of magneto-rheological elastomeric composites in the presence of an external magnetic field was determined and the influence of magnetic intensity on the isotropic distribution of iron filler particles in IECs was investigated. The magnetic intensity distribution was analyzed from the edge of the surface towards the center of the IEC. The samples were characterized for microstructural images after experimental tests using both micro-computed tomography (µCT) and scanning electron microscopy (SEM). The adhesion of filler particles within the matrix of the magneto-rheological elastomer (MRE) composite and their distributions were also investigated. µCT showed the overall 3D representation of IEC and the inner distribution of filler particles revealed the presence of some porosity which may be due to bubbles and voids in the matrix of the composite. Finally, a mechanism was established governing particle–particle interactions on the basis of dipole–dipole interactions. Full article

As magneto-acoustic-electrical tomography (MAET) combines the merits of high contrast and high imaging resolution, and is extremely useful for electrical conductivity measurement, so it is expected to be a promising medical imaging modalities for diagnosis of early-stage cancer. Based on the Verasonics system and the MC600 displacement platform, we designed and implemented a MAET system with a chirp pulse stimulation (MAET-CPS) method and a focal probe was utilized for stepscan focus excitation to enhance the imaging resolution. The relevant experiments were conducted to explore the influence of excitation positions of the single-focus point, and the effect of the excitation position on the amplitudes of the conductivity variation was clearly demonstrated. In order to take advantage of the merits of multifocus imaging, we firstly proposed a single focus MAET system with a chirp pulse stimulation (sfMAET-CPS) method and a multifocus MAET system with a chirp pulse stimulation (mfMAET-CPS) method for high-resolution conductivity imaging, and a homogenous gelatin phantom with a cuboid-shaped hole was used to investigate the accuracy of mfMAET-CPS. Comparative experiments were carried out on the same uniform phantom by the sfMAET-CPS and the mfMAET-CPS, respectively. The results showed that: (1) the electrical conductivity distributions of the homogenous phantom with a cuboid-shaped hole were detected by the sfMAET-CPS but were easily affected by the focal point, which demonstrated that the sfMAET-CPS had a low imaging resolution. (2) Compared with the sfMAET-CPS, the imaging effect of the mfMAET-CPS was much better than that of the sfMAET-CPS. (3) A linear interpolation algorithm was used to process the 2D conductivity distribution; it increased the smoothness of the conductivity distribution and improved the imaging effect. The stepscan focus excitation and the linearly frequency-modulated theory provide an alternative scheme for the clinical application of MAET. Full article
