During the excavation of tunnels in deeply buried underground hydropower stations, complex geological and construction conditions significantly increase the risk of sudden groundwater inflow, and the accuracy of groundwater inflow calculations remains low. This study takes the deeply buried underground powerhouse of a hydropower station as the engineering background and meticulously characterizes the underground powerhouse chamber group and its associated drainage facilities. On this basis, the study couples the geological model with the water flow model to systematically simulate the seepage field characteristics under complex conditions, including the pre-excavation, excavation, and operational phases. The water inflow at different parts of the powerhouse during the excavation phase is predicted. The results show that different rainfall conditions significantly affect the water inflow, with the inflow increasing as rainfall intensity rises. The maximum water inflow occurs in the storage reservoir area under heavy rainfall conditions, reaching 13,043.7 m³/d. During the operation phase, the external water pressure is greatly influenced by rainfall conditions, with the maximum pressure head of the water delivery pipeline from the underground powerhouse area to the reservoir section reaching 882.78 m under heavy rainfall. These findings provide a reference for future engineering construction. The results of this study offer theoretical and engineering references for groundwater inflow prediction and comprehensive control in deeply buried underground powerhouses under complex conditions. Full article

During partial-load operation, hydroelectric units are frequently subjected to hydraulic vibrations caused by pressure fluctuations within the turbine. These vibrations can result in deformation of the runner blades and, in severe instances, lead to crack formation. Over the years, research efforts have primarily focused on specific operating conditions, with relatively insufficient attention paid to the study of operational stability under broad-load operation. This study investigates the recurrent occurrence of crack damage in the runner blades of a Francis turbine installed at a major hydropower station. The issue emerges in response to the operational requirements of a modern power system, which mandates wide-load operation across varying heads (154.6 m, 197 m, 229.4 m) and guide vane openings (10%, 25%, 50%, 70%, 100%). To inform the development of optimized operational control strategies, this work examines the deformation and von Mises stress distribution patterns on the runner blades under these wide-load conditions. The findings reveal that the maximum blade deformation predominantly occurs in the mid-section of the trailing edge under most operating scenarios, while the peak von Mises stress consistently appears near the band at the trailing edge. Both peak deformation (1.99 mm) and peak von Mises stress (170.92 MPa) were observed at the maximum head (229.4 m) under 100% guide vane opening. Notably, significant deformation and stress levels were also encountered at openings below 25% under low-head conditions. On the basis of the research results, suggestions for ensuring the safe and stable operation of power station units under wide-load conditions were proposed. Full article

The water flow within the turbine passage of a hydropower station exhibits high-speed closed-pressure flow. The flow field characteristics will directly affect the turbine’s operational efficiency and safety. To ensure the safe operation of the turbine and accurately monitor its flow state, the relationship between the flow characteristics in the turbine passage and its discharge noise must be established. In this study, the relationship between the flow field and the noise field of the turbine is explored using a combination of a model turbine passage discharge noise test and numerical simulation of flow field characteristics. Results show that the operating parameters are closely related to the discharge noise’s characteristics, in which the operating head and discharge of the unit’s operating parameters greatly influence the discharge noise in the flow passage. Hydrodynamic factors, such as fluctuation pressure and pressure in the flow field, show a strong correlation with the discharge noise characteristics. As the pressure and fluctuation pressure in the inlet area of the spiral case intensify, the sound pressure level (SPL) of the discharge noise increases and the main frequency decreases. A large-scale vortex easily forms in the spiral case and draft tube area, thereby causing low-frequency fluctuation and forming high-decibel noise. Also, the runner area is the main sound source region of the turbine passage. The research results will provide technical and theoretical support for the safe operation and accurate fault diagnosis of hydropower stations. Full article

The demand for energy is gradually increasing; governments are looking for affordable and long-lasting solutions. Hydropower is crucial for addressing this issue. Low-head hydropower stations are necessary in certain regions due to their geographical position. Gravitational water vortex turbines are an alternative for these low-head turbines. They use the water’s tangential flow to create a vortex, converting mechanical energy to kinetic energy. The design of turbine blades and basins using SolidWorks and CFD analysis was carried out during this research. CFD investigation showed that the conical basin had a higher exit velocity than the cylindrical basin, indicating a successful design. Full article

During the flood season, Francis turbines often operate under low-head and full-load conditions, frequently experiencing significant pressure pulsations, posing potential threats to the safe and stable operation of the units. However, the factors contributing to substantial pressure pulsations in Francis turbines are multifaceted. This paper focuses on a mixed-flow hydroelectric generating unit at a specific hydropower station. Field tests were conducted to investigate abnormal vibrations and hydraulic pressure pulsations under low-head and full-load conditions. Utilizing the Navier–Stokes equations and the RNG k-ε turbulence model, the unsteady flow field within the turbine under these conditions was calculated. The results indicate that the abnormal pressure pulsations detected in the bladeless zone between the wicket gates and the turbine inlet are due to operational points deviating from the normal operating range of the turbine. When water flows at a large inflow angle, striking the turbine blade heads, it leads to significant flow separation and vortex formation at the back of the blade inlet edges, causing severe vibrations in the hydroelectric generating unit. These findings provide a basis and assurance for the safe and stable operation of the power station. Full article

China has a vast scale of hydropower, and the small hydropower stations account for a large proportion. In flood season, the excessive inflow keeps these stations at a high reservoir level, leading to a worse condition of hindered power output and a great error in the calculation of power generation. Therefore, this paper proposes a mid-term optimal scheduling model for low-head cascaded hydropower stations considering inflow unevenness, in which the power output is controlled by the expected power output curve and daily inflow–maximum power output curve. A case study of nine hydropower stations on the Guangxi power grid shows that, regardless of considering the fitted curve or not, there are different degrees of error between the planned and actual situations. However, the error and power generation are decreased when considering the fitted curve, which reflects the impact of hindered power output. Meanwhile, according to the comparison, the weekly plan is more in line with the real condition when using this model to solve the problem. The results indicate that this model improves the accuracy of power output calculation for low-head hydropower stations with uneven inflow, playing a key role in the process of scheduling. Full article

The roadway of an abandoned mine is an ideal site for the construction of underground pumped storage hydropower, but the operation of the power station is deeply restricted by the structural characteristics of the roadway. With the common double-bend roadway of an abandoned mine as the research object, this study conducted numerical simulations based on the theory of mass conservation and momentum conservation and explored the law of the flow field characteristics and energy loss of a double-bend roadway with the roadway structure and angle. The results showed that a velocity gradient and a pressure gradient form from the outer wall to the inner wall when the fluid flows through the two bends of the roadway. The low-speed zone and maximum positive pressure appeared at the outside of the bend, while the high-speed zone and maximum negative pressure appeared at the inside of the bend. As the angle rose, the peak value of positive pressure increased correspondingly when the fluid flowed through Model A, whereas the negative pressure displayed a fluctuating trend of increasing first and then decreasing and reached its peak when β = 45°. By contrast, when the fluid flowed through Model B, the velocity gradient was symmetrically distributed at the two bends. The peak value of the positive pressure of the first bend increased, and the other positive and negative pressures displayed a trend of “first increasing and then decreasing” when the angle increased, and they reached their peak when β = 45°. When β ≥ 60°, the fluid formed a backflow zone when it flowed through each bend. With an increase in the angle, the area of the backflow zone increased correspondingly. The head loss of the two models increased with the angle. At the same angle, the head loss of Model B was greater than that of Model A. According to the requirement of abandoned mine pumped storage, the roadways with a bend angle of 15° or 30° in Model A and 15° in Model B can be used. The research results can provide some reference for the underground space exploitation and utilization of abandoned mine pumped storage. Full article

Trash racks are usually composed of an array of bars installed in a hydropower scheme to safeguard the turbines by collecting water-borne detritus. However, current design approaches for the design of trash racks focus on structural criteria. A little attention renders the proper evaluation of hydraulic criteria, which causes a significant hydraulic head loss in low head hydropower schemes with an integral intake. This study investigates the head loss through trash racks by employing computational fluid dynamics (CFD) for several design combinations. A three-dimensional model of trash racks using fractional area/volume obstacle representation (FAVOR) method in FLOW-3D is set up to define the effects of the meshing on the geometry and several simulations are carried out considering various approach velocities and different bar spacings, inclination angles, and blockage ratios. The results indicate that head loss increases with an increase in approach velocity, the inclination angle of the rack with channel bed, and blockage ratio. It is noticed that a clear spacing between vertical bars greater than or equal to 0.075 m has a minimum head loss before it becomes significantly high for lower spacing. In addition, the head loss coefficient increases for screen angles greater than 60°, which can be considered as an optimal parameter for design purpose. Full article

The creation of reservoirs in water streams leads to significant changes in the hydrological regime of water bodies: it allows smoothing the peaks of maximum water discharge during a flood period and regulating low-water flow. The creation of reservoirs with significant storage capacity makes it possible to solve a wide range of water-management problems, including the use of falling water energy for hydropower purposes, and maintenance of the uninterrupted water supply and navigation. Since constructed dams are usually operated by hydropower companies, the regulatory regime for the discharge of water into the lower pool is often determined by the daily electricity consumption regime. Intra-day variations in the volume of water discharges through hydroelectric power stations generate multidirectional streams in the upper pool, which can affect the operation of other water withdrawal systems. This paper considers the effect of intraday variations in water discharges into the lower pool on the dynamic and physical properties of the water mass in the region of the location of drinking water-intake heads of Perm city and the quality of the withdrawn water. Full article

The traditional calculation method for a transient process has high accuracy when the pipeline only contains liquid, but when the pipeline contains both gas and liquid the accuracy is greatly reduced. The coupling characteristics of gas–liquid interface movement in hydraulic transient processes are not clear due to the lack of high-precision mathematical model and experimental verification. This paper proposes a novel mathematical model of a gas–liquid pipeline system in a hydropower station based on Preissman’s implicit difference scheme and the method of characteristics. The solving mechanism of the transient process of gas–liquid movement was developed on the gas–liquid interface tracking method. Subsequently, the models proposed in this paper were applied in two typical scenarios of a gas–liquid transient process in a hydropower system, and their accuracy were verified in a field experiment. The comparison results showed that the novel model could accurately capture the movement of the gas–liquid interface, and the average relative error of the characteristic parameter was about 7.2%. Under the load rejection condition, the change speed of characteristic parameters was positively correlated with the pipeline slope. Under the pump failure after low-head startup condition, the maximum pumping discharge was negatively correlated with startup water level and the maximum reversal discharge and speed were positively correlated with the pump failure water level. Compared with the conventional method, the proposed model has advantages in solving the complex transient process coupling gas–liquid. It has potential value in applications such as the safe operation of hydropower stations, the transient process of water diversion projects and in urban pipe network operation. Full article

Dangerous runner lifting-up (RLU) accidents regarding Kaplan turbines, which are widely used in low-head hydropower stations, were frequently reported. Three-dimensional (3D) computational fluid dynamics (CFD) was used to simulate the load rejection transients with guide-vane closing to predict the RLU possibility of the fixed-blade Kaplan turbine in an under-construction hydropower station. It was found that using any linear closing rule, the upward axial water force on the runner was larger than the weight of rotating parts that started before the guide-vanes were closed, which indicated a RLU possibility. It was the pumping effect that caused the imbalance, during which the high rotational speed runner propels water downstream with a low discharge. We proposed a piecewise closing rule based on this finding. By keeping the opening unchanged in a period in the closing process, the rotational speed can be reduced by using the braking effect, and the concurrence of high speed and low discharge can be prevented. Simulations verified this effective measure and accepted by the manufacturer. Although this study used a fixed-blade Kaplan turbine, the revealed mechanism and verified solution to the RLU problem have reference value for all of the Kaplan turbines. Full article
