Search Results (16)

Digital holographic microscopes provide a microscopy solution with a resolution in the low-micrometre range that offers similar performance to optical microscopy, but as a relatively low-cost alternative. The most significant cost saving is due to the ability to reconstruct microscopic images from holograms using low-cost components without the need for an optical stack. The cost saving opens up the avenue towards a feasible solution for geographically distributed in situ microscopic sensing in rural areas for problems like air and water pollution monitoring. The most significant contributors to cost are the camera sensor module, the pinhole, and the processing platform. The latter two components are addressed, at least in part, in this work. We successfully manufactured sub-100 $\mu$m diameter pinholes using ultraviolet (UV) laser cutting with an LPKF printed circuit board (PCB) prototyping platform and present the low-cost micromachining method. The pinholes were utilised within a prototype field-programmable gate array (FPGA) demonstrator that successfully reconstructed the holographic images. The choice for the FPGA approach as the initial step, albeit more complex, lends itself towards the easier development of a dedicated reconstructed application-specific integrated circuit (ASIC) to ultimately drive the cost down even further. Full article

The identification of Aspergillus flavus (A. flavus), a fungus known for producing aflatoxins, poses a taxonomic challenge due to its morphological plasticity and similarity to closely related species. This article proposes a computational approach for its characterization across four culture media, using ultraviolet (UV) radiation imaging and radiomic analysis. Images were acquired with a camera controlled by a Raspberry Pi and processed to extract 408 radiomic features (102 per color channel and grayscale). Shapiro–Wilk and Levene’s tests were applied to verify normality and homogeneity of variances as prerequisites for an analysis of variance (ANOVA). Nine features showed statistically significant differences and, together with the culture medium type as a categorical variable, were used in a supervised classification stage with cross-validation. Classification using Support Vector Machines (SVM) achieved 97% accuracy on the test set. The results showed that the morphology of A. flavus varies significantly depending on the medium under UV radiation, with malt extract agar being the most discriminative. This non-invasive and low-cost approach demonstrates the potential of radiomics combined with machine learning to capture morphological patterns useful in the differentiation of fungi with optical response under UV radiation. Full article

Tropical rock lobsters (Panulirus ornatus) are a highly cannibalistic species with intermoult animals predominantly attacking animals during ecdysis (moulting). Rapid, positive characterisation of pre-ecdysis lobsters may open a pathway to disrupt cannibalism. Ecdysial suture line development is considered for pre-ecdysis recognition with suture line definition compared for intermoult and pre-ecdysis lobsters emerged and immerged, using white, near ultraviolet (365 nm), near infrared (850 nm), and specialty SFH 4737 broadband IR LEDs against a reference of intermoult lobsters with no suture line development. Difficulties in acquiring suture line images prompted research into pre-ecdysis characterisation from the lobster’s dorsal carapace, due to its accessibility through a culture vessel’s surface. In this study, a novel low-cost spectral camera was developed by coordinating an IMX219 image sensor, an AS7265x spectral sensor, and four SFH 4737 broadband infrared LEDs through a single-board computer. Images and spectral data from the lobster’s dorsal carapace were acquired from intermoult, pre-ecdysis, and post-ecdysis lobsters. For the first time, suture line definition was found to be enhanced under 850 nm, 365 nm, and SFH 4737 LEDs for immerged lobsters, while the 850 nm LED achieved the best suture line definition of emerged lobsters. Although the spectral camera was unable to characterise pre-ecdysis, its development was validated when a least squares regression for binary classification decision boundary successfully separated 86.7% of post-ecdysis lobsters. Achieving post-ecdysis characterisation is the first time the dorsal carapace surface has been used to characterise a moult stage for palinurid lobsters. Full article

One of the key challenges in Multi-Spectral Automatic Diagnostic (MAD) robot design is the precise targeting of narrow-angle cameras on a specific part of the equipment. The paper shows that a low-cost MAD robot, whose navigation system is based on open-source ArduRover firmware and a pair of low-cost Ublox F9P GNSS receivers, can inspect the 8 × 4 degree ultraviolet camera bounding the targeting error within 0.5 degrees. To achieve this result, we propose a new targeting procedure that can be implemented without any modifications in ArduRover firmware and outperforms more expensive solutions based on LiDAR SLAM and UWB. This paper will be interesting to the developers of robotic systems for power equipment inspection because it proposes a simple and effective solution for MAD robots’ camera targeting and provides the first quantitative analysis of the GNSS reception conditions during power equipment inspection. This analysis is based on the experimental results collected during the inspection of the overhead power transmission lines and equipment inspections on the open switchgear of different power plants. Moreover, it includes not only satellite, dilution of precision, and positioning/heading estimation accuracy but also the direct measurements of angular errors that could be achieved on operating power plants using GNSS-only camera targeting. Full article

Rapid detection of fish freshness is of vital importance to ensuring the safety of aquatic product consumption. Currently, the widely used optical detecting methods of fish freshness are faced with multiple challenges, including low detecting efficiency, high cost, large size and low integration of detecting equipment. This research aims to address these issues by developing a low-cost portable fluorescence imaging device for rapid fish freshness detection. The developed device employs ultraviolet-light-emitting diode (UV-LED) lamp beads (365 nm, 10 W) as excitation light sources, and a low-cost field programmable gate array (FPGA) board (model: ZYNQ XC7Z020) as the master control unit. The fluorescence images captured by a complementary metal oxide semiconductor (CMOS) camera are processed by the YOLOv4-Tiny model embedded in FPGA to obtain the ultimate results of fish freshness. The circuit for the YOLOv4-Tiny model is optimized to make full use of FPGA resources and to increase computing efficiency. The performance of the device is evaluated by using grass carp fillets as the research object. The average accuracy of freshness detection reaches up to 97.10%. Moreover, the detection time of below 1 s per sample and the overall power consumption of 47.1 W (including 42.4 W light source power consumption) indicate that the device has good real-time performance and low power consumption. The research provides a potential tool for fish freshness evaluation in a low-cost and rapid manner. Full article

The use of ultraviolet fluorescence markers in medical simulations has become popular in recent years, especially during the COVID-19 pandemic. Healthcare workers use ultraviolet fluorescence markers to replace pathogens or secretions, and then calculate the regions of contamination. Health providers can use bioimage processing software to calculate the area and quantity of fluorescent dyes. However, traditional image processing software has its limitations and lacks real-time capabilities, making it more suitable for laboratory use than for clinical settings. In this study, mobile phones were used to measure areas contaminated during medical treatment. During the research process, a mobile phone camera was used to photograph the contaminated regions at an orthogonal angle. The fluorescence marker-contaminated area and photographed image area were proportionally related. The areas of contaminated regions can be calculated using this relationship. We used Android Studio software to write a mobile application to convert photos and recreate the true contaminated area. In this application, color photographs are converted into grayscale, and then into black and white binary photographs using binarization. After this process, the fluorescence-contaminated area is calculated easily. The results of our study showed that within a limited distance (50–100 cm) and with controlled ambient light, the error in the calculated contamination area was 6%. This study provides a low-cost, easy, and ready-to-use tool for healthcare workers to estimate the area of fluorescent dye regions during medical simulations. This tool can promote medical education and training on infectious disease preparation. Full article

Asini Corii Colla (ACC; donkey-hide glue) is one of the most valuable tonic traditional Chinese medicines. Because of the large demand for gelatinous Chinese medicines, bovine or swine skin was sometimes used to make adulterated gelatine in recent decades. Food chemicals can greatly harm people’s health, and detecting chemicals in foods is extremely important. A loop-mediated isothermal amplification (LAMP) device with smartphone detection is demonstrated in this study for detecting the DNA of Asini Corii Colla. The complete system is composed of a hand-held box equipped with a smartphone, a cartridge heater, an ultraviolet LED, a disposable reaction tube, and a homemade thermal module. All the processes are powered by a set of rechargeable batteries. Comprehensive experiments of measuring temperature profiles are presented, which showed the accuracy of temperature under thermal control is less than 0.5 °C. By implementing one heating module with an ATmega328p-au microcontroller in the device, the DNA mixture is heated directly up to the reaction temperature within 5 min. Next, a DNA segment of Asini Corii Colla is utilized to evaluate the sensitivity of the DNA amplification in the portable device. A limit of detection to a concentration of 10⁻⁴ ng/μL is achieved. Real-time detection of Asini Corii Colla by a smartphone camera can be achieved using this portable device. The unique architecture utilized in this device is ideal for a low-cost DNA analysis system. Full article

Plant stresses have been monitored using the imaging or spectrometry of plant leaves in the visible (red-green-blue or RGB), near-infrared (NIR), infrared (IR), and ultraviolet (UV) wavebands, often augmented by fluorescence imaging or fluorescence spectrometry. Imaging at multiple specific wavelengths (multi-spectral imaging) or across a wide range of wavelengths (hyperspectral imaging) can provide exceptional information on plant stress and subsequent diseases. Digital cameras, thermal cameras, and optical filters have become available at a low cost in recent years, while hyperspectral cameras have become increasingly more compact and portable. Furthermore, smartphone cameras have dramatically improved in quality, making them a viable option for rapid, on-site stress detection. Due to these developments in imaging technology, plant stresses can be monitored more easily using handheld and field-deployable methods. Recent advances in machine learning algorithms have allowed for images and spectra to be analyzed and classified in a fully automated and reproducible manner, without the need for complicated image or spectrum analysis methods. This review will highlight recent advances in portable (including smartphone-based) detection methods for biotic and abiotic stresses, discuss data processing and machine learning techniques that can produce results for stress identification and classification, and suggest future directions towards the successful translation of these methods into practical use. Full article

In this paper, an endlessly single mode microstructured polymer optical fiber (mPOF) in a Mach–Zehnder (M–Z) interferometer configuration is demonstrated for temperature and strain measurement. Because there is no commercial splicer applied for POF-silica optical fiber (SOF) connectorization, prior to the M–Z interferometric sensing, we introduce an imaging projecting method to align a polycarbonate mPOF to a SOF and then the splice is cured permanently using ultraviolet (UV) glue. A He-Ne laser beam at 632.8 nm coupled in a SOF is divided by a 1 × 2 fiber coupler to propagate in two fiber arms. A piece of mPOF is inserted in one arm for sensing implementation and the interference fringes are monitored by a camera. For non-annealed fiber, the temperature sensitivity is found to be 25.5 fringes/°C for increasing temperature and 20.6 fringes/°C for decreasing temperature. The converted sensitivity per unit length is 135.6 fringes/°C/m for increasing temperature, which is twice as much as the silica fiber, or 852.2 rad/°C/m (optical phase change versus fiber temperature), which is more than four times as much as that for the PMMA fiber. To solve the sensitivity disagreement, the fiber was annealed at 125 °C for 36 h. Just after the thermal treatment, the temperature measurement was conducted with sensitivities of 16.8 fringes/°C and 21.3 fringes/°C for increasing and decreasing process, respectively. One month after annealing, the linear response was improved showing a temperature sensitivity of ~20.7 fringes/°C in forward and reverse temperature measurement. For the strain measurement based on non-annealed fiber, the sensitivity was found to be ~1463 fringes/%ε showing repeatable linear response for forward and reverse strain. The fiber axial force sensitivity was calculated to be ~2886 fringes/N, showing a force measurement resolution of ~3.47 × 10⁻⁴ N. The sensing methodology adopted in this work shows several advantages, such as very low cost, high sensitivity, a straightforward sensing mechanism, and ease of fabrication. Full article

Measurement of solar ultraviolet radiation (UVR) is important for the assessment of potential beneficial and adverse impacts on the biosphere, plants, animals, and humans. Excess solar UVR exposure in humans is associated with skin carcinogenesis and immunosuppression. Several factors influence solar UVR at the Earth’s surface, such as latitude and cloud cover. Given the potential risks from solar UVR there is a need to measure solar UVR at different locations using effective instrumentation. Various instruments are available to measure solar UVR, but some are expensive and others are not portable, both restrictive variables for exposure assessments. Here, we compared solar UVR sensors commercialized at low or moderate cost to assess their performance and quality of measurements against a high-grade Bentham spectrometer. The inter-comparison campaign took place between March 2018 and February 2019 at Saint-Denis, La Réunion. Instruments evaluated included a Kipp&Zonen UVS-E-T radiometer, a Solar Light UV-Biometer, a SGLux UV-Cosine radiometer, and a Davis radiometer. Cloud fraction was considered using a SkyCamVision all-sky camera and the Tropospheric Ultraviolet Visible radiative transfer model was used to model clear-sky conditions. Overall, there was good reliability between the instruments over time, except for the Davis radiometer, which showed dependence on solar zenith angle. The Solar Light UV-Biometer and the Kipp&Zonen radiometer gave satisfactory results, while the low-cost SGLux radiometer performed better in clear sky conditions. Future studies should investigate temporal drift and stability over time. Full article

Wafer-level packaging (WLP) based camera module production has attracted widespread industrial interest because it offers high production efficiency and compact modules. However, suppressing the surface Fresnel reflection losses is challenging for wafer-level microlens arrays. Traditional dielectric antireflection (AR) coatings can cause wafer warpage and coating fractures during wafer lens coating and reflow. In this paper, we present the fabrication of a multiscale functional structure-based wafer-level lens array incorporating moth-eye nanostructures for AR effects, hundred-micrometer-level aspherical lenses for camera imaging, and a wafer-level substrate for wafer assembly. The proposed fabrication process includes manufacturing a wafer lens array metal mold using ultraprecise machining, chemically generating a nanopore array layer, and replicating the multiscale wafer lens array using ultraviolet nanoimprint lithography. A 50-mm-diameter wafer lens array is fabricated containing 437 accurate aspherical microlenses with diameters of 1.0 mm; each lens surface possesses nanostructures with an average period of ~120 nm. The microlens quality is sufficient for imaging in terms of profile accuracy and roughness. Compared to lenses without AR nanostructures, the transmittance of the fabricated multiscale lens is increased by ~3% under wavelengths of 400–750 nm. This research provides a foundation for the high-throughput and low-cost industrial application of wafer-level arrays with AR nanostructures. Full article

The aim of this work is to present a new practical approach to digital photogrammetry to obtain 3D models of polychromatic sculptures under ultraviolet fluorescence and near-infrared by starting from photographic images. This digital photogrammetry was applied recently to a 17th-century reliquary bust representing St. Rodonio, a saint particularly venerated by the Orthodox Church, presently under restoration in the Laboratories of University of Tuscia and belonging to the Museum of Colle del Duomo of Viterbo (Italy). The acquisitions of ultraviolet fluorescence and infrared frames were performed using a Nikon D5300 digital SLR camera and a modified low-cost digital camera (Samsung Model NX3300), respectively. The three-dimensional UV and IR models were obtained using Agisoft PhotoScan^® software. The generated ultraviolet 3D model of the bust makes visible, in a single file, the fluorescence induced by UV radiation on the entire sculpture, highlighting surface abrasions, organic dyes, and ancient protective features. The infrared 3D model allowed for better definition of the details of the drawing used for eyes, nose and mouth definition. In conclusion, the ultraviolet fluorescence and IR 3D models of Saint Rodonio were particularly useful as documentation tools for the conservation status and for the painting construction, allowing us to perfectly map the original and restoration materials and to detect the drawing in single dynamic 3D files following a totally non-invasive, cost-effective, and rapid approach. Full article

We propose and demonstrate a simple, low-cost, three-dimensional (3D) shape acquisition method for transparent 3D printed microscopic objects. Our method uses ultraviolet (UV) illumination to obtain high-contrast silhouette images of transparent 3D printed polymer objects. Multiple silhouette images taken from different viewpoints make it possible to reconstruct the 3D shape of this transparent object. A 3D shape acquisition system consisting of a UV light-emitting diode, charge-coupled device camera and a rotation stage was constructed and used to successfully reconstruct the 3D shape of a transparent bunny model produced using micro-stereolithography. In addition, 3D printed pillar array models, with different diameters on the order of several hundred micrometers, were reconstructed. This method will be a promising tool for the 3D shape reconstruction of transparent 3D objects on both the micro- and macro-scale by changing the imaging lens. Full article

Water vapour (H₂O) is the dominant species in volcanic gas plumes. Therefore, measurements of H₂O fluxes could provide valuable constraints on subsurface degassing and magmatic processes. However, due to the large and variable concentration of this species in the background atmosphere, little attention has been devoted to monitoring the emission rates of this species from volcanoes. Instead, the focus has been placed on remote measurements of SO₂, which is present in far lower abundances in plumes, and therefore provides poorer single flux proxies for overall degassing conditions. Here, we present a new technique for the measurement of H₂O emissions at degassing volcanoes at high temporal resolution (≈1 Hz), via remote sensing with low cost digital cameras. This approach is analogous to the use of dual band ultraviolet (UV) cameras for measurements of volcanic SO₂ release, but is focused on near infrared absorption by H₂O. We report on the field deployment of these devices on La Fossa crater, Vulcano Island, and the North East Crater of Mt. Etna, during which in-plume calibration was performed using a humidity sensor, resulting in estimated mean H₂O fluxes of ≈15 kg·s⁻¹ and ≈34 kg·s⁻¹, respectively, in accordance with previously reported literature values. By combining the Etna data with parallel UV camera and Multi-GAS observations, we also derived, for the first time, a combined record of 1 Hz gas fluxes for the three most abundant volcanic gas species: H₂O, CO₂, and SO₂. Spectral analysis of the Etna data revealed oscillations in the passive emissions of all three species, with periods spanning ≈40–175 s, and a strong degree of correlation between the periodicity manifested in the SO₂ and H₂O data, potentially related to the similar exsolution depths of these two gases. In contrast, there was a poorer linkage between oscillations in these species and those of CO₂, possibly due to the deeper exsolution of carbon dioxide, giving rise to distinct periodic degassing behaviour. Full article

Recently, we reported on the development of low-cost ultraviolet (UV) cameras, based on the modification of sensors designed for the smartphone market. These units are built around modified Raspberry Pi cameras (PiCams; ≈USD 25), and usable system sensitivity was demonstrated in the UVA and UVB spectral regions, of relevance to a number of application areas. Here, we report on the first deployment of PiCam devices in one such field: UV remote sensing of sulphur dioxide emissions from volcanoes; such data provide important insights into magmatic processes and are applied in hazard assessments. In particular, we report on field trials on Mt. Etna, where the utility of these devices in quantifying volcanic sulphur dioxide (SO₂) emissions was validated. We furthermore performed side-by-side trials of these units against scientific grade cameras, which are currently used in this application, finding that the two systems gave virtually identical flux time series outputs, and that signal-to-noise characteristics of the PiCam units appeared to be more than adequate for volcanological applications. Given the low cost of these sensors, allowing two-filter SO₂ camera systems to be assembled for ≈USD 500, they could be suitable for widespread dissemination in volcanic SO₂ monitoring internationally. Full article
