Under the dual challenges of global energy crisis and climate change, the building sector, as a major carbon emitter consuming 33% of global primary energy, has seen its energy efficiency optimization become a critical pathway towards achieving carbon neutrality goals. The Window-to-Wall Ratio (WWR), serving as a core parameter in building envelope design, directly influences building energy consumption, with its optimized design playing a decisive role in balancing natural daylighting, ventilation efficiency, and thermal comfort. This study focuses on the traditional One-Seal dwellings (Yikeyin) in Kunming, China, establishing a dynamic wind field-thermal environment coupled analysis framework to investigate the impact mechanism of window dimensions (WWR and aspect ratio) on indoor thermal comfort under natural wind conditions in transitional climate zones. Utilizing the Grasshopper platform integrated with Ladybug, Honeybee, and Butterfly plugins, we developed parametric models incorporating Kunming’s Energy Plus Weather meteorological data. EnergyPlus and OpenFOAM were employed, respectively, for building heat-moisture balance calculations and Computational Fluid Dynamic (CFD) simulations, with particular emphasis on analyzing the effects of varying WWR (0.05–0.20) on temperature-humidity, air velocity, and ventilation efficiency during typical winter and summer weeks. Key findings include, (1) in summer, the baseline scenario with WWR = 0.1 achieves a dynamic thermal-humidity balance (20.89–24.27 °C, 65.35–74.22%) through a “air-permeable but non-ventilative” strategy, though wing rooms show humidity-heat accumulation risks; increasing WWR to 0.15–0.2 enhances ventilation efficiency (2–3 times higher air changes) but causes a 4.5% humidity surge; (2) winter conditions with WWR ≥ 0.15 reduce wing room temperatures to 17.32 °C, approaching cold thresholds, while WWR = 0.05 mitigates heat loss but exacerbates humidity accumulation; (3) a symmetrical layout structurally constrains central ventilation, maintaining main halls air changes below one Air Change per Hour (ACH). The study proposes an optimized WWR range of 0.1–0.15 combined with asymmetric window opening strategies, providing quantitative guidance for validating the scientific value of vernacular architectural wisdom in low-energy design. Full article

The research and development of the next generation of supersonic transports (SSTs) meets economic and environmental problems. An SST encounters critical challenges, including the need for low fuel consumption, low noise, and low gas emissions. Currently, the feasibility of developing SSTs is increasing through the application of cutting-edge technologies, such as composite materials, advanced electric systems, sustainable aviation fuel, and innovative design methodologies. The object of this study was to perform the conceptual design of a 50-seat supersonic transport utilizing general conceptual design methods. In estimating weight and flight performance, statistical formulae were correlated with data from civil supersonic and subsonic jet transports. For wing sizing, carpet plots were created to explore the optimal combination of wing aspect ratio and wing loading. The results suggested that by utilizing advanced technologies, such as the use of a composite material for the structure, the maximum takeoff weight can potentially be reduced while still meeting design requirements. The constraint of climb gradient largely affects the maximum takeoff weight, and it is anticipated that flight performance at low speeds will be improved. Full article

This paper presents a multi-fidelity optimization procedure for aircraft wing design, implemented in the early stages of the aircraft design process. Since wing shape is a key factor that influences aerodynamic performance, having an accurate estimate of its efficiency at the conceptual design phase is highly beneficial for aircraft designers. This study introduces a comprehensive optimization framework for designing the wing of a Class I fixed-wing mini-UAV with electric propulsion, focusing on maximizing aerodynamic efficiency and operational performance. Utilizing Class-Shape Transformation (CST) in combination with Surrogate-Based Optimization (SBO) techniques, the research first optimizes the airfoil shape to identify the most suitable airfoil for the UAV wing. Subsequently, SBO techniques are applied to generate wing geometries with varying characteristics, including aspect ratio ($AR$), taper ratio ($\lambda$), quarter-chord sweep angle (${\mathrm{\Lambda }}_{0.25}$), and tip twist angle ($\epsilon$). These geometries are then evaluated using both low- and high-fidelity aerodynamic simulations. The integration of SBO techniques enables an efficient exploration of the design space while minimizing the computational costs associated with iterative simulations. Specifically, the proposed SBO framework enhances the wing’s aerodynamic characteristics by optimizing the lift-to-drag ratio and reducing drag. Full article

This study examines the aerodynamic performance of a joined-wing (JW) aircraft design based on the NASA Common Research Model (CRM), aiming to assess its potential for efficient commercial transport or cargo aircraft at transonic speed (Mach 0.85). The CRM wing, optimised for transonic flight, was transformed into a JW design featuring a high-aspect-ratio main wing. An initial parametric study using the vortex lattice minimum drag panel method identified viable designs. The selected JW configuration, comprising front and rear wings joined by a vertical fin, was analysed using ANSYS Fluent to understand flow interactions and aerodynamic performance. At an angle of attack (AoA) of −1°, the JW design achieved a peak lift-to-drag ratio (L/D) of 17.45, close to the CRM’s peak L/D of 19.64 at 2°, demonstrating competitive efficiency. The JW’s L/D exceeded the CRM’s between AoA −3° and 0.8°, but the CRM performed better above 0.8°, with differences decreasing at a higher AoA. Based on induced drag alone, the JW outperformed the CRM across AoA −3° to 8°, but flow complications restricted its L/D advantage to a small, low AoA range. A strong shock on the vertical fin’s inboard side due to high incoming flow speed delayed shock formation on the main wing near the joint. Optimising the vertical fin shape slightly improved L/D, suggesting potential for further enhancements or that other design factors significantly affect JW performance. This study provides insights into JW aerodynamics at transonic speeds, revealing its potential benefits and challenges compared to the CRM design. Full article

In this work, micro air vehicles (MAVs) equipped with bio-inspired wings are investigated experimentally in wind tunnel. The starting point is that insects such as dragonflies, butterflies and locusts have wings with rigid tubular elements (corrugation) connected by flexible parts (profiling). So far, it is important to understand the specific aerodynamic effects of corrugation and profiling as applied to conventional wings for the optimization of low-Reynolds-number aerodynamics. The present study, in comparison to previous investigations on the topic, considers whole MAVs rather than isolated wings. A planform with a low aperture-to-chord ratio is employed in order to investigate the interaction between large tip vortices and the flow over the wing surface at large angles of incidence. Comparisons are made by measuring global aerodynamic loads using force balance, specifically drag and lift, and detailed local velocity fields over wing surfaces, by means of particle image velocimetry (PIV). This type of combined global–local investigation allows describing and relating overall MAV performance to detailed high-resolution flow fields. The results indicate that the combination of wing corrugation and profiling gives effective enhancements in performance, around 50%, in comparison to the classical flat-plate configuration. These results are particularly relevant in the framework of low-aspect-ratio MAVs, undergoing beneficial interactions between tip vortices and large-scale separation. Full article

The effect of spanwise wing non-planarity, employed in conjunction with a Gurney flap, is presented. Testing was undertaken in a low-speed wind tunnel using a rectangular wing with an aspect ratio of three. The outer one-third of the wing was non-planar, which took the form of either dihedral or a circular arc. A 2% high Gurney flap was implemented such that it could extend over the entire span or the planar inboard section. The loads were measured using a sting balance. The data show that non-planarity increases the maximum lift coefficient and the wing’s lift curve slope. Gurney flap lift modulation was enhanced in the presence of non-planarity. The addition of Gurney flaps caused a greater increment in the minimum drag coefficient for the non-planar wings. The Gurney flaps reduced the lift-dependent drag of the wings. As a whole, the Gurney flaps reduced the maximum lift-to-drag ratio (L/D)_max for the non-planar wings; however, the flat wing exhibited a small L/D increment with flap addition. Full article

Computational simulations of three-dimensional flow around a NACA 0018 wing with an aspect ratio of $AR=5$ were carried out by using the Unsteady Reynolds-Averaged Navier–Stokes (URANS) equations with the Shear-Stress Transport turbulence model closure. Simulations were performed to capture aerodynamic stall hysteresis by using the developed pseudo-transient continuation (PTC) method based on a dual-time step approach in CFD OpenFOAM code. The flow was characterized by incompressible Mach number $M=0.12$ and moderate Reynolds number $Re=0.67\times {10}^6$. The results obtained indicate the presence of noticeable aerodynamic hysteresis in the static dependencies of the force and moment coefficients, as well as the manifestation of bi-stable flow separation patterns, accompanied by the development of asymmetry in the stall zone. The URANS simulation results are in good agreement with the experimental data obtained for the NACA 0018 finite-aspect-ratio wing in the low-speed wind tunnel under the same test conditions. A new phenomenological bifurcation model of aerodynamic stall hysteresis under static and dynamic conditions is formulated and is proven to be able to closely match the experimental data. Full article

The aerodynamic performance of wings degrades severely at low Reynolds number; lift often becomes non-linear, while drag increases significantly, caused by large extents of separation. Consequently, a non-conventional wing design approach is implemented to assess its ability to enhance performance. The design methodology is that of wing segmentation, where the wing is divided into spanwise panels that can be separated, thereby yielding small gaps between the panels. A moderate aspect ratio wing comprised of four separate wing panels was manufactured and wind tunnel tested through a Re range from 40,000 to 80,000. Force balance data and surface flow visualization were used to characterize performance. The results indicate that segmentation is effective in significantly augmenting efficiency at Reynolds numbers at which the fused wing (i.e., no gaps) shows large extents of open separation. Drag is greatly reduced, while lift is increased, and stall is delayed. The benefit of segmentation was noted to diminish at higher Re where the fused wing’s performance improves markedly. Wing segmentation could find application in micro-unmanned-aerial-vehicle and drone design. Further study would entail the effects of AR and the number of spanwise panels on performance. Full article

Eddy-viscosity-based turbulence models provide the most commonly used modeling approach for computational fluid dynamics simulations in the aerospace industry. These models are very accurate at a relatively low cost for many cases but lack accuracy in the case of highly rotational leading edge vortex flows for mid to low aspect-ratio wings. An enhanced adaptive turbulence model based on the one-equation Spalart–Allmaras turbulence model is fundamental to this work. This model employs several additional coefficients and source terms, specifically targeting vortex-dominated flow regions, where these coefficients can be calibrated by an optimization procedure based on experimental or high-fidelity numerical data. To extend the usability of the model from single or cluster-wise calibrated cases, this work presents a preconditioning approach of the turbulence model via a neural network. The neural network provides a case-unspecific calibration approach, enabling the use of the model for many known or unknown cases. This extension enables aircraft design teams to perform low-cost Reynolds-averaged Navier–Stokes simulations with increased accuracy instead of complex and costly high-fidelity simulations. Full article

The aeroelastic response of lightweight low-speed aircrafts with slender wings under extreme flow turbulence intensity is not well understood. Experiments on a commercial unmanned aerial vehicle (UAV) with a 3 m wingspan and aspect ratio of 13.6 were performed in a large open-return wind tunnel with extreme flow turbulence intensity of ≈10%. The wing bending displacement and the flow beneath the wing were measured by using laser-displacement sensors and tomographic particle image velocimetry (PIV) techniques, respectively. The unsteady lift produced by the wing was also measured by using a high-capacity load cell at an angle of attack of two degrees for three freestream velocities of 13.4 m/s, 17.9 m/s, and 26.8 m/s, representing the UAV’s stall speed, a speed approximately equal to the cruise speed, and a speed considerably higher than the cruise speed, respectively. It was found that a high flow turbulence intensity with large integral length scales relative to the wing chord plays a dominant role in the large unsteady lift and wing displacements measured. The power spectral density (PSD) of the wing structural vibration shows that flow shedding from the wing and the integral length scales have a significant impact on the overall power inherent in the bending vibration of the wing. Computations of the vorticity isosurfaces in the flow measurement volume surrounding the aileron reveal a striking observation: an aileron deflection of 10° becomes less effective in producing additional spanwise vorticity, which is proportional to circulation and lift at 26.8 m/s since the freestream already has elevated levels of vorticity. A paradigm shift in design is suggested for light aircraft structures with slender wings operating in highly turbulent flow, which is to employ multiple control surfaces in order to respond to this flow and mitigate large bending or torsion displacements and the probability of structural failure. Full article

Contrails are responsible for a significant proportion of aviation’s climate impact. This paper uses data from the European Centre for Medium-Range Weather Forecasts to identify the altitudes and latitudes where formed contrails will not persist. This reveals that long-lived contrails may be prevented by flying lower in equatorial regions and higher in non-equatorial regions. Subsequently, it is found that the lighter fuel and reduced seating capacity of hydrogen-powered aircraft lead to a reduced aircraft weight, which increases the optimal operating altitude by about 2 km. In non-equatorial regions, this would lift the aircraft’s cruise point into the region where long-lived contrails do not persist, unlocking hydrogen-powered, low-contrails operation. The baseline aircraft considered is an A320 retrofitted with in-fuselage hydrogen tanks. The impacts of the higher-altitude cruise on fuel burn and the benefits unlocked by optimizing the wing geometry for this altitude are estimated using a drag model based on theory proposed by Cavcar, Lock, and Mason, and verified against existing aircraft. The weight penalty associated with optimizing wing geometry for this altitude is estimated using Torenbeek’s correlation. It is found that thinner wings with higher aspect ratios are particularly suited to this high-altitude operation and are enabled by the relaxation of the requirement to store fuel in the wings. An example aircraft design for the non-equatorial region is provided, which cruises at a 14 km altitude at Mach 0.75 with a less than 1% average probability of generating long-lived contrails when operating at latitudes more than 35° from the equator. Compared to the A320, this concept design is estimated to have a 20% greater cruise lift–drag ratio, due to the 33% thinner wings with a 50% larger aspect ratio, enabling just 5% more energy use per passenger-km, despite fitting 40% fewer seats. Full article

An investigation of the lift components present over low aspect ratio rectangular wings is presented. Wing aspect ratios ranging from 0.5 to 3 are examined using published experimental results and analytic analysis methods. The methods are based on the fundamental decomposition of Polhamus; that is, lift is attributed to a potential flow lift component coupled with a vortical lift component stemming from the leading and side edges of the flat plate wing. The analysis suggests a low sensitivity to Reynolds numbers spanning three orders of magnitude and brings into doubt the realization of a leading edge vortex lift component for wings with unswept leading edges under steady state conditions. The analytic prediction method of Purvis is shown to provide close accord with all experimental data sets when lift contributions caused by a leading edge vortex are excluded. Full article

The race towards cleaner and more efficient commercial aviation demands novel designs featuring improved aerodynamic and structural characteristics, the main pillars that drive aircraft efficiency. Among the many proposed and introduced, the increase in the aspect ratio of the wings enables greater fuel efficiency by reducing induced drag. Nevertheless, such structures are characterised by elevated flexibility, aggravating static and dynamic aeroelastic phenomena. Consequently, the preliminary and conceptual design and optimization stages using high-fidelity numerical tools is rendered extremely intricate and prohibitive in terms of computational cost. Low-fidelity tools, contrastingly, enable computational-burden alleviation. In our approach, a computational framework for the low-fidelity steady-state static aeroelastic optimization of a composite high-aspect-ratio commercial aircraft wing via surrogate modelling is proposed. The methodology starts with the development of the 3D panel method as well of the elements of the surrogate model. The design variables, objective function and constraints which formulate the optimization problem are then provided. Moreover, comparison against rigid aerodynamics indicate the significant load-alleviation capabilities of the present case study. The effect of structural nonlinearities is also explored. The optimization framework is executed and optimal laminates for the structural members are obtained. The optimal structure was deemed critical in panel buckling. Full article

This work discusses the experimental challenges and processing of unsteady experiments for a pitching wing in the low-speed wind tunnel of the Vrije Universiteit Brussel. The setup used for unsteady experiments consisted of two independent devices: (a) a position control device to steer the pitch angle of the wing, and (b) a pressure measurement device to measure the aerodynamic loads. The position control setup can pitch the wing for a range of frequencies, amplitude, and offset levels. In this work, a NACA-0018 wing profile was used with an aspect ratio of 1.8. The position control and the pressure measurement setups operate independently of each other, necessitating advanced signal processing techniques to synchronize the pitch angle and the lift force. Furthermore, there is a (not well-documented) issue with the (sampling) clock frequency of the pressure measurement setup, which was resolved using a fully automated spectral analysis technique. The wing was pitched using a simple harmonic sine excitation signal at eight different offset levels (between 6° and 21°) for a fixed amplitude variation (std) of 6°. At each offset level, the wing was pitched at five different frequencies between 0.1 Hz and 2 Hz (that correspond to reduced frequencies k ranging from 0.006 to 0.125). All the experiments were conducted at a fixed chord-based Reynolds number of 2.85 × 10⁵. The choice of operating parameters invokes the linear and nonlinear behavior of the wing. The linear unsteady measurements agreed with the analytical results. The unsteady pressure measurements at higher offset levels revealed the nonlinear aerodynamic phenomenon of dynamic stall. This confirms that a nonlinear and dynamic model is required to capture the salient characteristics of the lift force on a pitching wing. Full article

The internal weapon bay is widely used in modern aircraft; however, because the unsteady flows of the cavity would cause dangerous store separation and intense aerodynamic noise, the leading-edge spoiler is an easy and efficient passive flow-control method. The flow control of the leading-edge flat spoiler before the cavity of a low-aspect-ratio flying-wing aircraft is investigated based on numerical simulation. Numerical results show that the leading-edge flat spoiler completely changes the cavity flow; it obviously lifts up the shear layer and reduces the pressure inside the cavity. For the store separation from the weapon bay, the leading-edge flat spoiler is a very good passive flow-control method that curbs the nose-up trend of the store and produces a safe and stable store separation. Besides, the leading-edge spoiler reduces the noise in the rear of the cavity (max 8.2 dB), but increases the noise in the middle of the cavity (max 11.3 dB). In addition, the leading-edge spoiler brings in a large drag increase to the aircraft (39.41% when the height of spoiler is 0.2 m), which would affect the operational stability of the aircraft. The results of this paper could provide a reference for the flow control of weapon bays and the design of aircraft. Full article
