An active damping control technique based on improved linear active disturbance rejection control (LADRC) is suggested to address the inadequate damping of doubly fed induction generator (DFIG) systems coupled to the grid using series compensation capacitors. Conventional LADRC still has certain limitations under complicated operating conditions, primarily because of its inadequate periodic disturbance estimate capabilities, which limit the system’s dynamic performance and disturbance-rejection capability. An enhanced LADRC scheme is created for the inner current loop of the rotor-side converter (RSC) in the DFIG system in order to lessen these restrictions. To enable a real-time estimate and adjustment of sub-synchronous disturbances, a decoupled linear extended state observer (LESO) is first proposed. In order to effectively attenuate both sub-synchronous oscillation and periodic disturbances, a composite control structure with enhanced suppression capability is constructed by incorporating an improved repetitive control scheme into the linear state error feedback law. The results show that the improved LADRC significantly enhances damping performance and disturbance rejection capability in the subsynchronous frequency range, suppressing active power oscillations within approximately 0.3 s based on a ±10% settling band. Compared with the conventional LADRC, the average THD of the grid current is reduced from 3.43% to 0.56%. Full article

Roll autopilots of small fixed-wing unmanned aerial vehicles (UAVs) should reject roll disturbances and compensate for parameter variations during flight. This study investigates an active disturbance rejection control (ADRC) architecture based on an extended state observer (ESO), with emphasis on a reduced-order ESO (RESO), for the roll channel of a small fixed-wing UAV. The roll axis is represented by a first-order roll-rate model augmented with actuator and rate-gyro dynamics; a proportional–derivative law is applied to the tracking error, while an extended state observer estimates a lumped total disturbance, and this estimate is fed forward for real-time disturbance compensation. Two observer designs are considered: a second-order linear ESO (LESO) and a first-order RESO using roll-rate and actuator feedback. Frequency-domain and time-domain analyses are carried out under aerodynamic uncertainty, actuator limits, sensor noise, and sinusoidal roll disturbances, and the RESO-based ADRC is compared with LESO-ADRC, a linear quadratic integral (LQI) controller, and a classical proportional–integral–derivative (PID) design. The simulations show that the RESO implementation retains the disturbance rejection and robustness of LESO-ADRC while reducing the observer order, and it offers improved disturbance rejection capability with acceptable noise sensitivity. These properties make RESO-based ADRC a promising candidate for real-time roll autopilots in small fixed-wing UAV applications. Full article

Active disturbance rejection control (ADRC) is attractive because it estimates and compensates a lumped “total disturbance” with limited plant information, but privacy-sensitive networked deployment, measurement-noise amplification, and actuator saturation remain insufficiently addressed together. This paper proposes a Differentially Private Probabilistic ADRC (DP-PADRC) framework for nonlinear SISO systems under saturation. In contrast to adaptive ADRC schemes that schedule gains from raw residuals, and unlike model-based differentially private filters that rely on explicit stochastic plant models, the proposed method combines a linear ESO with a lightweight uncertainty surrogate computed from clipped and privatized innovations. The resulting controller is not Bayesian; rather, it is probabilistic in the sense that second-moment information from the released innovation stream is explicitly used to calibrate observer bandwidth and disturbance compensation. We further incorporate a saturation-aware gate so that scheduling remains well behaved when the commanded and applied inputs differ. An ISS-type mean-square bound is derived for the closed loop, making the dependence on the disturbance derivative, measurement-noise variance, clipping level, and privacy parameters $(\epsilon ,\delta )$ explicit. We also discuss the composition of privacy loss across repeated tuning windows and quantify the privacy-induced perturbation of the scheduling signal. Simulation-based nonlinear servo benchmarks show improved tracking/noise robustness over fixed-gain LADRC and a nonlinear ADRC baseline, while clarifying the privacy–performance trade-off and the scope of the method. Full article

This paper proposes a generalized high-order linear active disturbance rejection control (GHO-LADRC) method to suppress non-stationary disturbances in VICTS antenna direct-drive motors during high-dynamic scanning. First, a fourth-order generalized extended state observer is constructed, in which the derivative of the total disturbance is explicitly modeled as an extended state. This configuration enables real-time observation of the disturbance rate of change and suppresses the phase lag inherent in traditional ADRC during rapid disturbance variations through disturbance feedforward compensation. Secondly, drawing on singular perturbation theory and the motor’s dual-time-scale characteristics, this work precisely decouples and explicitly extracts the nonlinear friction and electromagnetic damping terms during the modeling stage. By integrating the extracted electromagnetic damping terms and the disturbance variation rate, an improved model-assisted control law is formulated, enabling active compensation for intense dynamic interference. Theoretical analysis and experimental results demonstrate that the proposed method significantly enhances disturbance rejection capability and satellite communication accuracy. As the first application of GHO-LADRC in the field of direct-drive VICTS antenna control, this work validates its effectiveness in improving system robustness within complex dynamic environments. Full article

This paper proposes an adaptive augmented anti-disturbance load relief control scheme for a solid launch vehicle. It can effectively satisfy the composite control requirements including high-precision attitude control, resistance to elastic frequency deviations, sudden wind disturbances, and active load relief. Firstly, the dynamic model of the elastic solid launch vehicle was established and subjected to small-perturbation linearization. Based on the state-space approach, the open-loop transfer function of the system was derived, and a basic PD controller with correction networks was presented. Subsequently, an adaptive augmented control law was designed to achieve adaptive variation in open-loop gain. Furthermore, a load relief control law was designed to address the launch vehicle’s need for load mitigation during the ascent phase through high-wind regions. Simultaneously, to further enhance disturbance rejection capability, a linear extended state observer was developed. Finally, frequency-domain methods and sinusoidal function analysis were applied to the four designed modules to evaluate the system’s stability margins, and the overall stability margin of the whole control system was calculated. Comprehensive time-domain simulation results and frequency-domain analysis examples demonstrate the effectiveness of the proposed method, which offers a novel solution for launch vehicle ascent control and facilitates meeting multi-constraint control requirements. Full article

In petroleum drilling, conventional automatic drilling systems still rely heavily on manual intervention, which often leads to poor stability, limited multivariable coordination, and large fluctuations in drilling pressure. To address this problem, this study develops a hydraulic drawworks-based autodriller system with integrated power, drive, actuation, and control units, and establishes a mechanical-hydraulic-control co-simulation model for the coordinated regulation of drill-string hoisting speed and surface weight-on-bit (SWOB). Based on this platform, a dual-loop control framework is developed in which the inner loop uses linear active disturbance rejection control (LADRC) for rapid disturbance estimation and compensation, while the outer loop uses PID control for tracking regulation. Feedforward compensation is introduced to handle predictable load variation, and PSO-assisted fuzzy tuning is used to improve adaptability under varying operating conditions. Simulation results show that, compared with conventional cascaded PID control, the proposed controller reduces drawworks speed and SWOB overshoot by 12.5% and 40%, respectively, while the corresponding settling times are shortened by 1.805 s and 2.443 s. Prototype experiments on a scaled test platform further show that the proposed controller can be implemented on physical hardware and can maintain stable real-time regulation under laboratory conditions. These results support the feasibility of the proposed framework for coordinated hydraulic drawworks control under the simulated and laboratory-scale conditions considered in this study. Full article

Bidirectional AC/DC converters in hybrid microgrids are prone to DC-bus voltage instability caused by source-side, grid-side, and load-side disturbances. Conventional linear active disturbance rejection control (LADRC) suffers from a trade-off between transient overshoot suppression and disturbance rejection capability, which limits its practical application. To address this issue, an improved LADRC strategy for bidirectional AC/DC converters is proposed in this paper. First, a linear tracking differentiator (LTD) is introduced to smooth the DC-bus voltage reference and suppress overshoot caused by abrupt command changes. Second, a proportional-derivative (PD) term is embedded into the linear extended state observer (LESO) to introduce phase lead compensation, thereby improving the observer phase characteristics without excessively increasing the observation bandwidth or amplifying high-frequency noise. Frequency domain analysis, MATLAB/Simulink simulations, and full-hardware prototype experiments are carried out to validate the proposed method. The simulation study covers grid voltage sag, photovoltaic-side source fluctuation, and DC-side load disturbance conditions. To further strengthen the experimental verification, hardware tests are conducted under grid voltage dip, PV-side voltage reduction, and DC-side load-switching conditions. The results consistently show that the proposed strategy can effectively reduce DC-bus voltage fluctuation and improve transient recovery performance compared with conventional LADRC. Therefore, the improved LADRC provides a practical and robust control solution for stabilizing bidirectional converters in AC/DC hybrid microgrids. Full article

Servo electric cylinders have been widely adopted in high-performance linear drive applications such as aerospace systems, robotic servo systems, medical equipment, advanced manufacturing, precision testing, and high-end equipment due to their advantages, including high cleanliness, compact structure, high transmission efficiency, and ease of achieving precise control. However, under complex operating conditions, system performance is influenced not only by control strategies but also closely related to factors such as friction, clearance, transmission flexibility, structural vibrations, and modeling accuracy. This paper reviews mainstream control strategies and dynamic simulation methods for servo electric cylinders, providing structured analysis and systematic evaluation of representative research. In terms of control strategies, key approaches, including classical PID control, robust nonlinear control, intelligent and learning-based control, and active disturbance rejection control, are discussed, with comparative analysis of their characteristics and limitations in tracking accuracy, robustness, adaptability, and engineering feasibility. Regarding dynamic modeling and simulation, methods such as multibody dynamics, finite element analysis, rigid-flexible coupling, and multi-domain collaborative simulation are reviewed, examining their applicability in nonlinear mechanism characterization, local structural response assessment, and high-fidelity system modeling. Current research indicates that servo cylinder control is evolving from single-method improvements toward integrated and composite approaches, while dynamic modeling has progressed from low-order simplified analyses to system-level, multi-level, and high-fidelity descriptions. Existing studies still face challenges, including insufficient unified evaluation criteria, inadequate cross-method comparisons, and insufficient integration between control design and high-fidelity models. Future research should focus on enhancing control-model co-design, experimental validation under complex conditions, and system-level optimization oriented toward intelligent and high-reliability systems. Full article

A dynamic analysis of a compressor system is presented to characterize its behavior and establish a mathematical framework for identifying stable and unstable operating regions. The study is grounded in the nonlinear Moore–Greitzer model, which describes compressor dynamics in terms of mass flow and pressure rise as functions of rotor speed. To predict the onset of surge and system instability, advanced nonlinear techniques are employed, including the Jacobian matrix, linear parameter-varying (LPV) modeling, Bendixson’s criterion, and phase plane analysis. These tools enable the identification of both stable and unstable regions, as well as the limit cycle associated with surge phenomena. All of these analyses of the compressor are innovative. Accurate prediction of compressor surge and instability is essential for defining and designing effective control strategies, as surge can damage the compressor, interrupt downstream flow, and inherently represents an unstable operating condition. However, analysis alone is insufficient for practical compressor operation. Therefore, three active control methods are considered: Proportional–Integral–Derivative (PID), Linear Quadratic Regulator (LQR), and Model Predictive Control (MPC). The comparative analysis reveals that insufficient consideration of varying system conditions in LQR design may lead to inferior performance relative to MPC and PID control, particularly under changing disturbances. In contrast, MPC and PID exhibit stronger robustness to disturbance variations and provide effective disturbance rejection. In the proposed approach, MPC simulations are conducted to evaluate controller performance. Due to disturbances in the closed-loop model, the LQR controller demonstrates reduced robustness compared to PID and MPC. Under surge-related disturbances, the minimum input mass flow by both PID and MPC controllers is 0.495 (very close to setpoint), and both controllers exhibit an overshoot of 33% and a rise time of 3 s. Full article

To address the issues of poor control performance, synchronization defects, and instability in existing multi-pole permanent magnet synchronous motor (PMSM) control systems using PI control, this paper proposes an optimized control strategy combining Linear Active Disturbance Rejection Control (LADRC) with Capuchin Search Algorithm (CapSA). The proposed approach first implements LADRC in the PMSM speed loop, where the CapSA algorithm is applied to tune LADRC parameters, significantly reducing overshoot, enhancing the disturbance rejection capability, and improving the system stability. Secondly, by modifying the traditional deviation coupling structure and introducing an error factor to strengthen dynamic synchronization performance among multiple motors, the system’s control accuracy and robustness are effectively enhanced. Finally, a simulation model is established using MATLAB/Simulink for comparative experiments under various operating conditions. The results demonstrate that the proposed CapSA-LADRC control strategy significantly reduces speed overshoot and synchronization errors while exhibiting superior dynamic response and disturbance rejection capabilities, providing a reliable solution for practical engineering applications. Full article

Small rotorcraft unmanned aerial vehicles (UAVs) are highly susceptible to wind disturbances when performing tasks such as fixed-point hovering, low-altitude inspection, and aggressive maneuvers. Under complex, variable meteorological conditions, attitude stability and position-holding accuracy are particularly critical. Although quadrotor UAVs exhibit structural and dynamic symmetry, real wind disturbances are often asymmetric, disrupting the original balance and leading to intensified attitude oscillations, position drift, and degraded data quality. To effectively address the challenges of wind-induced oscillation and positional deviation, this paper proposes a fuzzy logic-based linear active disturbance rejection control (Fuzzy-LADRC) strategy. This approach employs a hybrid algorithm combining particle swarm optimization and gray wolf optimization to optimize controller parameters and incorporates fuzzy logic to enhance the adaptive capability of the linear active disturbance rejection controller (LADRC). Simulation experiments conducted in MATLAB/Simulink under complex wind-field conditions demonstrate that the proposed method significantly outperforms traditional PID controllers: in the regulation of roll and pitch angles, control performance improves by approximately 5%, while in yaw angle control, the improvement reaches up to 30%. Furthermore, this method can significantly suppress position deviation and fluctuation in the X and Y directions, and reduce the overshoot in the Z-axis during the UAV’s takeoff phase by 75%. Full article

Active vibration control is crucial for mitigating harmful resonant vibrations in structures subjected to harmonic loads. While antiresonant (zero-placement) methods are effective for this purpose, existing state-feedback solutions require full state measurement, and output-feedback approaches often prioritize resonance assignment over direct harmonic cancellation. This work bridges this gap by proposing a novel systematic design for a proportional–derivative (PD) output-feedback controller to achieve antiresonance for second-order linear systems with a time delay in the actuators. The method first computes a homogeneous gain solution. It then leverages the parametrization of all antiresonant solutions as a constraint within a genetic algorithm optimization. The algorithm optimizes both the stability margin, characterized by an $M_s$-disk criterion, and the number of encirclements of the critical point $(-1,0)$ in the complex plane, as assessed by the Generalized Nyquist Stability Criterion. The proposed approach provides a practical, optimized output-feedback strategy for precise rejection of harmonic disturbances, as demonstrated through a collection of numerical examples from real-world applications. The results confirm the method’s effectiveness in synthesizing stabilizing controllers that enforce antiresonance while ensuring robust stability margins. Full article

Sub-synchronous oscillation problems may be induced when direct-drive wind turbines are connected to a weak AC power grid, and then it is necessary to analyze the mechanism of sub-synchronous oscillation and study effective suppression methods. In this paper, the disturbance of direct-drive wind turbines connected to the grid is analyzed firstly. The result indicates that the regulation ability of traditional current inner-loop PI controller is limited and may even exacerbate oscillation. Then a new current inner-loop controller is designed which is based on linear active disturbance rejection control. To address the difficulty in tuning the parameters of the disturbance rejection controller, the particle swarm optimization algorithm is applied. Finally, a simulation model of a direct-drive wind turbine grid connected to the power grid is built and simulated. The results show that, compared with the bandwidth method for tuning controller parameters, the particle swarm optimization algorithm has stronger adaptability to various operating conditions; the proposed linear active disturbance rejection controller based on particle swarm optimization can block the propagation of sub-synchronous frequency disturbance components strongly compared to traditional control, and the sub-synchronous oscillations are suppressed effectively. Full article

This study proposes a systematic approach for implementing discrete-time Linear Active Disturbance Rejection Control in the closed-loop regulation of power converters. The continuous-time Linear Extended State Observer was discretized using the zero-order hold method to obtain a current estimator-based Linear Extended State Observer that is suitable for real-time implementation. The design considerations for discrete-time Linear Active Disturbance Rejection Control, including the selection of observer and controller parameters and the sampling period, are addressed. For performance comparison, a PI controller was designed and implemented in discrete time. The control schemes were evaluated via MATLAB/Simulink (2025b) simulations and real-time closed-loop experiments on a microcontroller to assess the transient response, disturbance rejection capability, and steady-state accuracy of the buck converter. The simulation and experimental results demonstrate that the discrete-time Linear Active Disturbance Rejection Control incorporating a current-estimator-based Linear Extended State Observer significantly outperforms the PI controller in terms of transient response and disturbance rejection capability. From this perspective, this study provides a meaningful contribution to the limited literature on linear extended state observer-based discrete-time Active Disturbance Rejection Control methods. Full article

Dual linear motor-driven systems (DLMDS) are widely used in industrial manufacturing due to their high dynamic stability and robust performance, typically featuring a symmetric Y1–Y2 axis structure. High-precision synchronization control of the motion platform is crucial for overall system performance. However, in practice, such systems are inevitably affected by mechanical installation errors, load disturbances, and nonlinear friction, which lead to the asymmetry of the Y1–Y2, severely degrading the synchronization accuracy between the two symmetric axes. To address these challenges, this paper proposes an EtherCAT-enabled active disturbance rejection control (ADRC) strategy for high-performance gantry synchronization systems. To cope with strong coupling effects, external disturbances, and high-speed operation, a master–slave synchronization architecture is developed based on ADRC and the EtherCAT cyclic synchronous torque (CST) mode. An extended state observer (ESO) is employed to estimate and compensate for lumped disturbances in real time, enabling precise synchronization without relying on an accurate mechanical model. Experimental results under both low-speed and high-speed operating conditions show that the proposed method significantly improves the synchronization stability and robustness compared with conventional cross-coupling control and master–slave control strategies. Specifically, the ADRC-based approach reduces synchronization errors by more than 20% under disturbance-free conditions and suppresses approximately 80% of disturbance-induced errors during high-speed operation. These results confirm the effectiveness and practical applicability of the proposed control strategy for high-precision gantry motion systems. Unlike conventional torque-mode implementations that merely replace the position loop with torque regulation, the proposed method introduces a disturbance-estimation-driven synchronization architecture co-designed with deterministic EtherCAT cyclic timing, which enables distributed real-time compensation beyond classical torque feedforward strategies. Full article
