Search Results (76)

This paper, based on the Johnson–Cook damage model, investigates the damage mechanism of high-strength steel tailor welded blanks (TWBs) (Usibor1500P and Ductibor500) during the forming process. Initially, specimens with varying notch sizes were designed and fabricated to perform uniaxial tensile tests to determine their mechanical properties. Then, the deformation process of the notched specimens was simulated using finite element software, revealing the distribution and variation of stress triaxiality at the fracture surface. By combining both experimental and simulation data, the parameters of the Johnson–Cook (J–C) damage model were calibrated, and the effects of temperature, strain rate, and stress triaxiality on material fracture behavior were further analyzed. Based on finite element analysis, the relevant coefficients for stress triaxiality, strain rate, and temperature were systematically calibrated, successfully establishing a J–C fracture criterion for TWB welds, Usibor1500P, and Ductibor500 high-strength steels. Finally, the calibrated damage model was further validated through the Nakajima-type bulge test, and the simulated Forming Limit Diagram (FLD) closely matched the experimental data. The results show that the analysis based on the J–C damage model can effectively predict the fracture behavior of tailor welded blanks (TWB) during the forming process. This study provides reliable numerical predictions for the damage behavior of high-strength steel laser-customized welded sheets and offers a theoretical basis for engineering design and material performance optimization. Full article

This study examines the impact of laser power on the microstructure and fracture behavior of IN718 specimens fabricated using laser powder bed fusion. Single-edge notched bend specimens were fabricated with varying laser power from 140 W to 260 W, and their fracture behavior was analyzed following the ASTM E1820-23b standard. The porosity and grain morphology remained unaffected by the presence of a notch parallel to the build direction. An elastic–plastic fracture mechanics approach was used to measure J-R curves, which quantify the energy required for crack propagation. Crack initiation and growth during quasistatic loading were monitored using image analysis. The results revealed a strong correlation between crack initiation and propagation, type of porosity, and relative density. The specimen printed with the optimal laser power of 180 W demonstrated the highest relative density and the greatest resistance to crack propagation. Large non-spherical defects formed due to lack-of-fusion at lower laser power are more detrimental to the crack propagation resistance. Full article

WC-Co cemented carbides, commonly known as hardmetals, are composite materials constituted by hard ceramic particles embedded in a ductile metal matrix. Due to their unique microstructural assemblage, these materials exhibit excellent combinations of hardness, strength, and toughness, consolidating them as a first choice for tools, structural and wear components. During recent decades, extensive research and technological advancements have driven the development of alternative cemented carbide grades, where traditionally used WC or Co are partially or entirely replaced. Within this context, hardmetals containing a third γ-phase (mixed cubic carbides) represent an interesting alternative. However, accurate evaluation of their fracture toughness remains a significant issue, especially as conventional methods using either indentation or precracking approaches are limited by either restricted implementation of fracture mechanics analysis or testing challenges. Within this context, this study proposes, implements, and validates the use of a novel laser-micronotching methodology to evaluate the fracture toughness of a γ-phase containing cemented carbide grade. For comparison purposes, the investigation also includes assessment of such a property by means of two other well-established testing methodologies. Moreover, similar experimental work was conducted in a plain WC-Co system with similar microstructural features. It is shown that machining of a through-thickness micronotch by means of ultra-short pulsed laser ablation is a reliable and efficient method for fracture toughness evaluation of γ-phase containing hardmetals. The main reason behind this is its capability for providing a precise and reproducible micronotch, with minimal thermal damage, that finally acts as a real through-thickness crack for which a stress-intensity factor is well-defined under flexural testing. Furthermore, toughness values obtained are in satisfactory agreement with those determined using precracked specimens with machined large notches and/or indentation techniques. Full article

As the correlation between design rules and process limitations is of the upmost importance for the full exploitation of any manufacturing technology, we report a design guide for hybrid-additive manufacturing of Inconel 718. Basic limitations need to be evaluated for this particular hybrid approach that combines laser powder bed fusion (PBF-LB/M) and in situ high-speed milling. Fundamental geometric limitations are examined with regard to the minimum feasible wall thickness, cylinders, overhanging structures, and chamfers. Furthermore, geometrical restrictions due to the integrated three-axis milling process with respect to inclinations, inner angles, notches, and boreholes are investigated. From these findings, we derive design guidelines for a reliable build process using this hybrid manufacturing. Additionally, a design guideline for the hybrid-additive manufacturing approach is presented, depicting a step-to-step guide for the adjustment of constructions. To demonstrate this, a powder nozzle for a direct energy deposition (DED-LB/M) process is redesigned following the previously defined guidelines. This redesign encompasses analysis of the existing component and identification of problematic areas such as flat angles, leading to a new construction that is suitable for a hybrid-additive manufacturing approach. Full article

The hybridization of additive manufacturing (AM) with conventional manufacturing processes in tooling applications allows the customization of the tool. Examples include weight reduction, improving the vibration-dampening properties, or directing the coolant to the critical zones through intricate conformal cooling channels aimed at extending the tool life. In this regard, metallurgical challenges like the need for a post-processing heat treatment in the AM segment to meet the thermal and mechanical properties requirements persist. Heat treatment can destroy the dimensional accuracy of the pre-manufactured heat-treated wrought segment, on which the AM part is built. In the case of dissimilar joints, heat treatment may further impact the interface properties through the ease of diffusional reactions at elevated temperatures or buildup of residual stresses at the interface due to coefficient of thermal expansion (CTE) mismatch. In this communication, we report on the laser powder bed fusion (L-PBF) processing of MAR 60, a weldable carbon-free maraging powder, to manufacture a hybrid tool holder for general turning applications, comprising a wrought segment in 25CrMo4 low-alloy carbon-bearing tool steel. After L-PBF process optimization and manipulation, as-built (AB) MAR 60 steel was characterized with a hardness and tensile strength of ~450 HV (44–45 HRC) and >1400 MPa, respectively, matching those of pre-manufactured wrought 25CrMo4 (i.e., 42–45 HRC and 1400 MPa). The interface was defect-free with strong metallurgical bonding, showing slight microstructural and hardness variations, with a thickness of less than 400 µm. The matching strength and high Charpy V-notch impact energy (i.e., >40 J) of AB MAR 60 eliminate the necessity of any post-manufacturing heat treatment in the hybrid tool. Full article

The aim of this study was to develop a concept for an angular positioning method for a round cutting insert in a torus cutter body dedicated to the multi-axis milling process under high-speed machining cutting conditions. The method concept is based on a developed wear model using a non-linear estimation method adopting a quasi-linear function. In addition, a tool life model was developed, taking into account the cutting blade work angle parameter, the laser marking method for the round cutting insert, and a wear measurement methodology. The developed tool wear model provides an accuracy of 90% in predicting the flank wear of the cutting blade. The developed procedure for angular positioning of the round cutting insert enables the entire cutting edge to be fully utilized, extending the total tool life. In addition, the measured largest defect values between the worn cutting edge and the nominal outline of the round cutting insert indicate the location of notching-type wear. Full article

A complementary characterisation of the Al-alloy EN AW-5454 was carried out, intended for obtaining the laser hybrid welding parameters of subassemblies in the automotive industry. The investigation included a microstructural examination and the determination of the alloy’s properties using several analytical methods (HV5 hardness measurement, tensile test, Charpy impact toughness, fracture mechanics analysis). Samples were prepared in the longitudinal and transverse directions of a cold-rolled sheet of EN AW-5454 with thicknesses of 3.5 mm and 4 mm. The measured hardness on the thinner sheet was 5% higher than on the thicker sheet. The tensile and yield strength were nominal, while the elongations were smaller by 2.2–3.2% for the longitudinal samples and by 2.7–13.7% for the transverse samples. The smaller deviations from the nominal values are for the thinner sheet metal. A precise topographical analysis showed the brittle fractures of the samples. The Charpy impact toughness results on the thicker plate showed a 20% greater work needed to break it in the longitudinal direction than in the transverse direction. With the thinner sheet metal, 40% greater work was needed. SEM (scanning electron microscope) analysis has shown that the intermetallic Al₆(Mn,Fe) particles in the longitudinal samples were mostly intact, with evidence of tough areas on the upper part of the fracture, indicating a better toughness than the specimens in the transverse direction. More crushed intermetallic particles were observed at the fractures of the transverse samples, and their distribution appeared to be more oriented in the direction of rolling. Fracture mechanics SENB (single edge notch bending) tests and their analysis showed that the resistance of the material to crack propagation in the longitudinal sample was about 50% greater than that in the transverse sample. SEM analysis of the fractures showed that the state of the intermetallic particles in the fracture mechanics testing and the fracture mechanism differed from the one in the Charpy fractures. Full article

Pore and crack formation in parts produced by additive manufacturing (AM) processes, such as laser powder bed fusion, is one of the issues associated with AM technology. Surface and subsurface cracks and pores are induced during the printing process, undermining the printed part durability. In-situ detection of defects will enable the real-time or intermittent control of the process, resulting in higher product quality. In this paper, a new eddy current-based probe design is proposed to detect these defects in parts with various defects that mimic pores and cracks in additively manufactured parts. Electromagnetic finite element analyses were carried out to optimize the probe geometry, followed by fabricating a prototype. Artificial defects were seeded in stainless steel plates to assess the feasibility of detecting various flaws with different widths and lengths. The smallest defect detected had a 0.17 mm radius for blind holes and a 0.43 mm notch with a 5 mm length. All the defects were 0.5 mm from the surface, and the probe was placed on the back surface of the defects. The surface roughness of the tested samples was less than 2 µm. The results show promise for detecting defects, indicating a potential application in AM. Full article

In this work, a two-parameter inversion problem is analyzed, related to surface crack widths for measuring depths of normal surface notches, based on a laser-based ultrasonic measurement method in the time domain. In determining the depth measurement formulas, the main technique is the time delay between reflected and scattered waves. Scattered waves are generated by two reflections along the bottom and three mode transformations at the surface of the crack tips. Moreover, the scattering angle of the mode-conversion waves is 30°. These two key factors lead to corrected item “2wβ” in the depth measurement formula. A laser-based ultrasonic experimental platform is built to generate and receive surface waves in a non-contact manner on aluminum and steel specimens with surface cracks. The depth measurement method proposed in this paper has been validated through theoretical, simulation, and experimental methods. Finally, in this paper, an effective approach for quantitatively measuring crack depths, based on laser ultrasound, using the time-domain properties of surface wave propagation is provided. Full article

To solve the problems of poor surface quality and low tool life in conventional machining (CM) of AerMet100 steel, an experimental study was conducted in laser-assisted machining (LAM) of AerMet100 steel. The effects of laser power, cutting speed, feed rate, and depth of cut on the surface roughness of AerMet100 steel were studied based on a single-factor experiment. The degree of influence of each factor on the surface roughness was evaluated by analyses of variance and range in the orthogonal experiment, and the combination of process parameters for the optimal surface roughness was obtained. The order of influence was as follows: laser power > cutting speed > depth of cut > feed rate; the optimal combination of process parameters was laser power 200 W, cutting speed 56.5 m/min, feed rate 0.018 mm/rev, and depth of cut 0.3 mm. Compared to CM, the surface morphology of the workpiece under the optimization of LAM was relatively smooth and flat, the surface roughness Ra was 0.402 μm, which was reduced by 62.11%, the flank wear was reduced from 208.69 μm to 52.17 μm, there were no tipping or notches, and the tool life was significantly improved. The study shows that the LAM of AerMet100 steel has obvious advantages in improving surface quality and reducing tool wear. Full article

The detection of defects in aluminium alloys using eddy current testing (ECT) can be restricted by higher electrical conductivity. Considering the occurrence of discontinuities during the selective laser melting (SLM) process, checking the ability of the ECT method for the mentioned purpose could bring simple and fast material identification. The research described here is focused on the application of three ECT probes with different frequency ranges (0.3–100 kHz overall) for the identification of artificial defects in SLM aluminium alloy AlSi10Mg. Standard penetration depth for the mentioned frequency range and identification abilities of used probes expressed through lift-off diagrams precede the main part of the research. Experimental specimens were designed in four groups to check the signal sensitivity to variations in the size and depth of cavities. The signal behavior was evaluated according to notch-type and hole-type artificial defects’ presence on the surface of the material and spherical cavities in subsurface layers, filled and unfilled by unmolten powder. The maximal penetration depth of the identified defect, the smallest detectable notch-type and hole-type artificial defect, the main characteristics of signal curves based on defect properties and circumstances for distinguishing between the application of measurement regime were stated. These conclusions represent baselines for the creation of ECT methodology for the defectoscopy of evaluated material. Full article

The unusual combination of the fundamentally contradictory properties of high tensile strength and high fracture toughness found in maraging steel makes it well suited for safety-critical applications that require high strength-to-weight materials. In certain instances, additive manufacturing (AM) has produced materials that may be desirable for safety-critical applications where impact toughness is a key property, such as structural parts for the aerospace industry or armor plates for military applications. Understanding the influence of process parameters and defect structure on the properties of maraging steel parts produced via laser powder bed fusion (LPBF) is a fundamental step towards the broader use of AM technologies for more demanding applications. In this research, the impact energy of V-notched specimens made of 1.2709 maraging steel produced by LPBF was determined via Charpy impact testing. Specimens were produced using different processing parameter sets. By combining the process parameters with the porosity values of the parts, we demonstrate that an almost full prediction of the impact properties can be achieved, paving the way for significantly reducing the expenses of destructive testing. Full article

The article describes the results of the study on laser welding of armor plates with a nominal thickness of 3.0 mm. The plates were made of Armox 500T steel characterized by a hardness of up to 540 HB, a minimum yield strength of 1250 MPa, an ultimate strength of up to 1750 MPa, and an elongation A5 minimum of 8%. The laser used for the welding tests was a solid state Yb:YAG laser. The influence of basic parameters such as laser output power, welding speed, and focal plane position on the weld geometry was determined during bead-on-plate welding tests. The optimal conditions for butt joint welding were determined, and the test joints were subjected to mechanical and impact tests, metallographic analysis, and hardness measurements. It has been shown that it is possible to laser weld Armox 500T armor plates, and at the same time it is possible to provide high quality butt joints, but this requires precise selection of welding parameters. A decrease in HAZ hardness of about 22–35% in relation to the hardness of the base material, ranging from 470 to 510 HV0.2, was found. The ultimate tensile strength of the test joints was approx. 20% lower than the Armox 500T steel. The bending tests revealed the low plasticity of the tested joints because the bending angle was just 25–35°. The results of Charpy V–notch test revealed that the impact toughness of the weld metal at −20 °C was approx. 30% lower than at room temperature. Full article

In the present work, a study of the fatigue strength of two materials widely used in the production of molds, namely, the AISI P20 and AISI H13 steels, is presented. The tests were performed at a constant amplitude with a stress ratio of R = 0 using samples where U-shaped notches were filled with laser beam fusion deposition. Three different sets of deposition parameters for each material were analyzed. Fatigue strength results are presented as S-N curves obtained for filled and non-filled materials. In addition to the assessment of the fatigue strength, metallography, hardness, and the fracture surface of the specimens tested were also evaluated. In general, a high number of metallurgic defects was detected, and consequently, a decrease in the mechanical properties of the materials was observed, especially the fatigue strength. However, the parameter optimization of the repairing laser process produced repaired zones with good metallurgical quality, leading to higher fatigue strength in both of the high-strength steels analyzed. Full article

Laser cladding (LC) is a versatile additive manufacturing process where strands of metallic material are deposited and melted by a laser. However, there are some limitations associated with this process that may affect the performance of the final manufactured parts. In the present work, the influence of laser shock peening (LSP) on the fatigue life of 304 stainless steel flat specimens with a cobalt-based alloy (Stellite 6) coating applied by LC was investigated. The analysis was carried out both experimentally and numerically. In the LSP simulation, the ABAQUS/Explicit code was used to determine the residual stress distribution of specimens with double central notches with a radius of curvature of 5, 10, 15, and 20 mm. From the numerical results, an improvement was found regarding fatigue life up to 48% in samples with LSP. Experimentally, 14% in fatigue life enhancement was observed. The residual stress, determined by the contour method, showed good agreement with the LSP simulation. The SEM images revealed that the fatigue failure started at the Stellite 6 coating and propagated towards the center of the specimen. LSP has been shown to be a suitable postprocessing alternative for laser-cladded parts that will be subjected to fatigue loading since it led to fatigue improvement through the introduction of compressive residual stresses on clad coatings. Full article
