Search Results (198)

To solve the low efficiency of traditional sheet metal measurement, this paper proposes a digital inspection method for sheet metal parts based on 3D point clouds. The 3D point cloud data of sheet metal parts are collected using a 3D laser scanner, and the topological relationship is established by using a K-dimensional tree (KD tree). The pass-through filtering method is adopted to denoise the point cloud data. To preserve the fine features of the parts, an improved voxel grid method is proposed for the downsampling of the point cloud data. Feature points are extracted via the intrinsic shape signatures (ISS) algorithm and described using the fast point feature histograms (FPFH) algorithm. After rough registration with the sample consensus initial alignment (SAC-IA) algorithm, an initial position is provided for fine registration. The improved iterative closest point (ICP) algorithm, used for fine registration, can enhance the registration accuracy and efficiency. The greedy projection triangulation algorithm optimized by moving least squares (MLS) smoothing ensures surface smoothness and geometric accuracy. The reconstructed 3D model is projected onto a 2D plane, and the actual dimensions of the parts are calculated based on the pixel values of the sheet metal parts and the conversion scale. Experimental results show that the measurement error of this inspection system for three sheet metal workpieces ranges from 0.1416 mm to 0.2684 mm, meeting the accuracy requirement of ±0.3 mm. This method provides a reliable digital inspection solution for sheet metal parts. Full article

Over three decades of research has been undertaken on point cloud registration algorithms, resulting in mature theoretical frameworks and methodologies. However, among the numerous registration techniques used, the impact of point cloud scanning quality on registration outcomes has rarely been addressed. In most engineering and industrial measurement applications, the accuracy and density of LiDAR point clouds are highly dependent on laser scanners, leading to significant variability that critically affects registration quality. Key factors influencing point cloud accuracy include scanning distance, incidence angle, and the surface characteristics of the target. Notably, in short-range scanning scenarios, incidence angle emerges as the dominant error source. Building on this insight, this study systematically investigates the relationship between scanning incidence angles and point cloud quality. We propose an incident-angle-dependent weighting function for point cloud observations, and further develop an improved weighted Iterative Closest Point (ICP) registration algorithm. Experimental results demonstrate that the proposed method achieves approximately 30% higher registration accuracy compared to traditional ICP algorithms and a 10% improvement over Faro SCENE’s proprietary solution. Full article

The precise characterization of surface rupture zones and associated co-seismic displacement fields from large earthquakes provides critical insights into seismic rupture mechanisms, earthquake dynamics, and hazard assessments. Stereo-photogrammetric digital elevation models (DEMs), produced from high-resolution satellite stereo imagery, offer reliable global datasets that are suitable for the detailed extraction and quantification of vertical co-seismic displacements. In this study, we utilized pre- and post-event WorldView-2 stereo images of the 2024 Ms7.1 Wushi earthquake in Xinjiang to generate DEMs with a spatial resolution of 0.5 m and corresponding terrain point clouds with an average density of approximately 4 points/m². Subsequently, we applied the Iterative Closest Point (ICP) algorithm to perform differencing analysis on these datasets. Special care was taken to reduce influences from terrain changes such as vegetation growth and anthropogenic structures. Ultimately, by maintaining sufficient spatial detail, we obtained a three-dimensional co-seismic displacement field with a resolution of 15 m within grid cells measuring 30 m near the fault trace. The results indicate a clear vertical displacement distribution pattern along the causative sinistral–thrust fault, exhibiting alternating uplift and subsidence zones that follow a characteristic “high-in-center and low-at-ends” profile, along with localized peak displacement clusters. Vertical displacements range from approximately 0.2 to 1.4 m, with a maximum displacement of ~1.46 m located in the piedmont region north of the Qialemati River, near the transition between alluvial fan deposits and bedrock. Horizontal displacement components in the east-west and north-south directions are negligible, consistent with focal mechanism solutions and surface rupture observations from field investigations. The successful extraction of this high-resolution vertical displacement field validates the efficacy of satellite-based high-resolution stereo-imaging methods for overcoming the limitations of GNSS and InSAR techniques in characterizing near-field surface displacements associated with earthquake ruptures. Moreover, this dataset provides robust constraints for investigating fault-slip mechanisms within near-surface geological contexts. Full article

Before the development of 3D cadastre, cadastral systems were based on 2D representations, which now require transformation or updating. In this context, the first issue is that existing 2D rights are not aligned with recent 3D data acquired using advanced technologies such as Unmanned Aerial Vehicle–Light Detection and Ranging (UAV-LiDAR). The second issue is that point clouds of objects captured by UAV-LiDAR, such as fences and exterior building walls—are often neglected. However, these point cloud objects can be utilized to adjust 2D rights to correspond with recent 3D data and to update 3D building models with a higher level of detail. This research leverages such point cloud objects to automatically generate 3D rights and building models. By combining several algorithms, such as Iterative Closest Point (ICP), Random Forest (RF), Gaussian Mixture Model (GMM), Region Growing, the Polyfit method, and the orthogonality concept—an automatic workflow for generating 3D cadastral models is developed. The proposed workflow improves the horizontal accuracy of the updated 2D parcels from 1.19 m to 0.612 m. The floor area of the 3D models improves by approximately ±3 m². Furthermore, the resulting 3D building models provide approximately 43% to 57% of the elements required for 3D property valuation. The case study of this research is in Indonesia. Full article

This work presents the development of a functional real-time SLAM system designed to enhance the perception capabilities of an Automated Guided Vehicle (AGV) using only a 2D LiDAR sensor. The proposal aims to address recurring gaps in the literature, such as the need for low-complexity solutions that are independent of auxiliary sensors and capable of operating on embedded platforms with limited computational resources. The system integrates scan alignment techniques based on the Iterative Closest Point (ICP) algorithm. Experimental validation in a controlled environment indicated better performance using Gauss–Newton optimization and the point-to-plane metric, achieving pose estimation accuracy of 99.42%, 99.6%, and 99.99% in the position ($x$, $y$) and orientation ($\theta$) components, respectively. Subsequently, the system was adapted for operation with data from the onboard sensor, integrating a lightweight graphical interface for real-time visualization of scans, estimated pose, and the evolving map. Despite the moderate update rate, the system proved effective for robotic applications, enabling coherent localization and progressive environment mapping. The modular architecture developed allows for future extensions such as trajectory planning and control. The proposed solution provides a robust and adaptable foundation for mobile platforms, with potential applications in industrial automation, academic research, and education in mobile robotics. Full article

Point clouds acquired by mobile laser scanners (MLS) are widely used for generating as-built building information models (BIM), particularly in indoor construction environments and existing buildings. While MLS offers fast and efficient scanning through SLAM technology, its accuracy and precision remains lower than that of terrestrial laser scanners (TLS). This study investigates the potential to improve MLS-based as-built BIM accuracy by analyzing and utilizing error distribution patterns inherent in MLS point clouds. Based on the assumption that each MLS device exhibits consistent and unique error distribution patterns, an experiment was conducted using three MLS devices and TLS-derived reference data. The analysis employed iterative closest point (ICP) registration and cloud-to-mesh (C2M) distance measurements on mock-ups with closed shapes. The results revealed that error patterns were stable across scans and could be leveraged as correction factors. In other words, the results indicate that when using MLS for as-built BIM generation, robust fitting methods have limitations in obtaining realistic object dimensions, as they do not account for the unique error patterns present in MLS point clouds. The proposed method provides a simple and repeatable approach for enhancing MLS accuracy, contributing to improved dimensional reliability in MLS-driven BIM applications. Full article

Significant morphological transformations resulting from open-pit mining activities always present major problems with site safety and slope stability. This study investigates an active marble quarry in Dinar, Türkiye by combining geospatial analysis and photogrammetry based on unmanned aerial vehicles (UAV). Acquired in 2024 and 2025, high-resolution images were combined with dense point clouds produced by Structure from Motion (SfM) methods. Iterative Closest Point (ICP) registration (RMSE = 2.09 cm) and Multiscale Model-to-Model Cloud Comparison (M3C2) analysis was used to quantify the surface changes. The study found a volumetric increase of 7744.04 m³ in the dump zones accompanied by an excavation loss of 8359.72 m³, so producing a net difference of almost 615.68 m³. Surface risk factors were evaluated holistically using a variety of morphometric criteria. These measures covered surface variation in several respects: their degree of homogeneity, presence of any unevenness or texture, verticality, planarity, and linearity. Surface variation > 0.20, roughness > 0.15, and verticality > 0.25 help one to identify zones of increased instability. Point cloud modeling derived from UAVs and GIS-based spatial analysis were integrated to show that morphological anomalies are spatially correlated with possible failure zones. Full article

To address the demands for accuracy and completeness in engineering drawing dimension annotation, this paper presents an intelligent dimensioning method that integrates Case-Based Reasoning (CBR), K-Dimensional Tree (KD-Tree), and an enhanced Iterative Closest Point (ICP) algorithm. The proposed approach leverages a historical case database to extract key features from similar cases, providing high-quality initial references for the ICP algorithm. By combining KD-Tree’s efficient spatial search capabilities with ICP’s precise point cloud alignment, the method achieves both efficient mapping and accurate alignment of dimension information. Applied to creating engineering drawings of refrigerated van design as a case study, the results demonstrate that this method significantly enhances the efficiency and precision of dimension annotation, minimizes manual intervention and error rates, and showcases broad application potential in complex engineering design scenarios. The contributions include an innovative intelligent dimensioning method, the MKD-ICP algorithm for dimension mapping and alignment, and empirical validation of the approach’s effectiveness. Full article

To optimize the structure and workflow of the 3D measurement robot system, reduce the dependence on specific calibration targets or high-precision calibration objects, and improve the versatility of the system’s self-calibration, this paper proposes a robot hand–eye calibration algorithm based on irregular targets. By collecting the 3D structural information of an object in space at different positions, a random sampling consistency evaluation based on the fast point feature histogram (FPFH) is adopted, and the iterative closest point (ICP) registration algorithm with the introduction of a probability model and covariance optimization is combined to iteratively solve the spatial relationship between point clouds, and the hand–eye calibration equation group is constructed through spatial relationship analysis to solve the camera’s hand–eye matrix. In the experiment, we use arbitrary objects as targets to execute the hand–eye calibration algorithm and verify the effectiveness of the method. Full article

The absence of standardized evaluation methodologies for single-layer dimensional accuracy significantly hinders the broader implementation of direct ink writing (DIW) technology. Addressing the critical need for precision non-contact assessment in DIW fabrication, this study develops a novel machine vision-based framework for dimensional accuracy evaluation. The methodology encompasses three key phases: (1) establishment of an optimized hardware configuration with integrated image processing algorithms; (2) comprehensive investigation of camera calibration protocols, advanced image preprocessing techniques, and high-precision contour extraction methods; and (3) development of an iterative closest point (ICP) algorithm-enhanced evaluation system. The experimental results demonstrate that our machine vision system achieves 0.04 mm × 0.04 mm spatial resolution with the ICP convergence threshold optimized to 0.001 mm. The proposed method shows an 80% improvement in measurement accuracy (0.001 mm) compared to conventional approaches. Process parameter optimization experiments validated the system’s effectiveness, showing at least 76.3% enhancement in printed layer dimensional accuracy. This non-contact evaluation solution establishes a robust framework for quantitative quality control in DIW applications, providing critical insights for process optimization and standardization efforts in additive manufacturing. Full article

To address the inefficiency and significant errors in the manual measurement of phenotypic parameters of Phoebe zhennan seedlings, a non-destructive automated method based on a 3D point cloud was proposed for extracting phenotypic parameters of stem and leaves following stem and leaf segmentation. First, the processed point cloud image was aligned using the Sample Consensus Initial Aligment (SAC-IA) and Iterative Closest Point (ICP) algorithms to generate a three-dimensional model of the seedlings. The stem point cloud was extracted from the model using the median normalized growth vector-based search (MNVG) method, with the current growth vector refined based on previous growth points and vectors. These corrective processes enhanced the accuracy of stem extraction. The leaves were separated from the stem through streamlined projection, after which the remaining leaf point cloud was individually extracted using the density-based spatial clustering of applications with noise (DBSCAN) algorithm. The extracted stem data were used to measure stem length and stem diameter, and for each extracted leaf, leaf length, width, and area were measured, yielding accuracies of 97.7%, 93.2%, 96.4%, 88.02%, and 85.84%, respectively. The results of this study provide a valuable reference for forest breeding and the cultivation of high-quality tree seedlings. Full article

In order to detect the abrasion of rails, a new point cloud alignment method combining 4-points congruent sets (4PCS) coarse alignment based on internal shape signature (ISS) and K-dimensional iterative closest points (KD-ICP) fine alignment is proposed, and for the first time, the combined algorithm is applied to the detection of rail wear. Due to the large amount of 3D rail point cloud data collected by the 3D line laser sensor, the original data are first downsampled by voxel filtering. Then, ISS feature points are extracted from the processed point cloud data for 4PCS coarse alignment, and the feature points are quantitatively analyzed, which in turn provides good alignment conditions for fine alignment. Then, the K-dimensional tree structure is used for the near-neighbor search to improve the alignment efficiency of the ICP algorithm. Finally, the total rail wear is calculated by combining the fine alignment results with the wear calculation formula. The experimental results show that when the number of ISS feature points extracted is 4496, the 4PCS coarse alignment algorithm based on ISS feature points is higher than the original 4PCS algorithm as well as the other algorithms in terms of alignment accuracy; the ICP fine alignment algorithm based on the kd-tree is less than the original ICP algorithm as well as the other algorithms in terms of the time consumed. Further, the proposed new ISS-4PCS + KD-ICP two-stage point cloud alignment method is superior to the original 4PCS + ICP algorithm both in terms of alignment accuracy and runtime. The combined algorithm is applied to the detection of rail wear for the first time, which provides a reference for the non-contact rail wear detection method. The high accuracy and low time consumption of the proposed algorithm lays a good foundation for the calculation of rail wear in the next step. Full article

Bore deterioration phenomena, such as surface ablation, wear, aluminum deposition, and structural bending, severely restrict the service life and performance of electromagnetic launchers. Efficient bore inspection is necessary to study the deterioration mechanism, guide design, and health management. In this paper, an inspection system for electromagnetic launchers is presented which utilizes structured light scanning, time-of-flight, and laser alignment methods to acquire bore laser point clouds, and ultimately extracts the surface deformation of rails and insulators, as well as the straightness of the bore, through the registration of point cloud data. First, the system composition and detection principles are introduced. Second, the impacts of the detection device’s attitude deflection are analyzed. Next, focusing on the key registration issue of laser point clouds, a coarse registration method is proposed which utilizes the arc features of the rail by combining circle and parabola equations, thereby maximizing registration efficiency. Finally, the trimmed iterative closest-point (TrICP) algorithm is employed for fine registration to handle non-axisymmetric bore deformations. The experimental results show that the proposed method can detect bore surface deformation and straightness efficiently and precisely. Full article

In response to the issues of slow convergence and the tendency to fall into local optima in traditional iterative closest point (ICP) point cloud registration algorithms, this study presents a fast registration algorithm for laser point clouds based on 3D scale-invariant feature transform (3D-SIFT) feature extraction. First, feature points are preliminarily extracted using a normal vector threshold; then, more high-quality feature points are extracted using the 3D-SIFT algorithm, effectively reducing the number of point cloud registrations. Based on the extracted feature points, a coarse registration of the point cloud is performed using the fast point feature histogram (FPFH) descriptor combined with the sample consensus initial alignment (SAC-IA) algorithm, followed by fine registration using the point-to-plane ICP algorithm with a symmetric target function. The experimental results show that this algorithm significantly improved the registration efficiency. Compared with the traditional SAC−IA+ICP algorithm, the registration accuracy of this algorithm increased by 29.55% in experiments on a public dataset, and the registration time was reduced by 81.01%. In experiments on actual collected data, the registration accuracy increased by 41.72%, and the registration time was reduced by 67.65%. The algorithm presented in this paper maintains a high registration accuracy while greatly reducing the registration speed. Full article

This study presents an innovative method for estimating the height of feature points through shaded area analysis, to enhance the performance of iterative closest point (ICP)-based algorithms for matching scanning sonar images. Unlike other sensors, such as forward looking sonar (FLS) or BlueView, scanning sonar has an extended data acquisition period, complicating data collection while in motion. Additionally, existing ICP-based matching algorithms that rely on two-dimensional scanning sonar data suffer from matching errors due to ambiguities in the nearest-point matching process, typically arising when the feature points demonstrate similarities in size and spatial arrangement, leading to numerous potential connections between them. To mitigate these matching ambiguities, we restrict the matching areas in the two images that need to be aligned. We propose two strategies to limit the matching area: the first utilizes the position and orientation information derived from the navigation algorithm, while the second involves estimating the overlapping region between the two images through height assessments of the feature points, facilitated by shaded area analysis. This latter strategy emphasizes preferential matching based on the height information obtained. We propose integrating these two approaches and validate the proposed algorithm through simulations, experimental basin tests, and real-world data collection, demonstrating its effectiveness. Full article
