Inkjet printing technology shows significant potential for producing high-performance conductive circuits in printed electronics. However, conventional silver nanoparticle (Ag NP) inks often face challenges such as nozzle clogging, poor stability, and low conductivity after low-temperature sintering. While most existing studies focus solely on dispersant selection or individual process optimization, few have systematically explored the synergistic effects of particle size distribution, dispersion methods, and dispersant dosage. This study proposes a sequential optimization approach involving centrifugal classification to identify an optimal Ag NPs source and size distribution, followed by comparison and optimization of different dispersion methods. Furthermore, the effects of dispersant (a PEO-PPO-PEO triblock copolymer) concentration and application strategy (individual or combined use) on the rheological properties and conductivity of the ink were systematically investigated. The optimized Ag NP ink demonstrated excellent jetting stability with no nozzle clogging, exhibiting a surface tension of 19.60 mN/m and a viscosity of 6.83 mPa·s. After low-temperature sintering at 260 °C on glass or polyimide (PI) substrates, the printed patterns achieved a high electrical conductivity of 1.506 × 10⁷ S/m. Printing on polyethylene terephthalate (PET) at 150 °C confirmed compatibility with heat-sensitive flexible substrates. This work offers a comprehensive and practical strategy for developing highly reliable and conductive Ag NP inks, facilitating their application in next-generation printed electronics. Full article

Electronic quick response (e-QR) codes provide access to real-time sensor data using smartphone readers and internet connectivity. Printed electronics and hybrid integration on flexible substrates is a promising solution for wide-scale and low-cost deployment of sensor systems. This paper presents a 21 × 21-pixel e-QR display implemented on black Kapton using hybrid additive and subtractive microfabrication techniques. The process flow for the double-sided circuit allows for layer alignment using multiple fiducial markers. The steps include inkjet printing of tracks on both sides of the substrate, laser-cut via holes, stencil-aided via filling, solder paste dispensing, and final integration of discrete surface-mount components by semi-automatic pick-and-place. Full article

Paper-based electronics have emerged as a sustainable, low-cost, and flexible alternative to traditional substrates for electronics, particularly for disposable and wearable applications. This review outlines recent developments in paper-based devices, focusing on sensors and paper-based field-effect transistors (PFETs). Key fabrication techniques such as laser-induced graphene, inkjet printing, and screen printing have enabled the creation of highly sensitive and selective devices on various paper substrates. Material innovations, especially the integration of graphene, carbon-based materials, conductive polymers, and other novel micro- and nano-enabled materials, have significantly enhanced device performance. This review discusses modern applications of paper-based electronics, with a particular emphasis on biosensors, electrochemical and physical sensors, and PFETs designed for flexibility, low power, and high sensitivity. Advances in PFET architectures have further enabled the development of logic gates and memory systems on paper, highlighting the potential for fully integrated circuits. Despite challenges in durability and performance consistency, the field is rapidly evolving, driven by the demand for green electronics and the need for decentralized, point-of-care diagnostic tools. This paper also identifies detection strategies used in paper-based sensors, reviews limitations in the current fabrication methods, and outlines opportunities for the scalable production of multifunctional paper-based systems. This review addresses a critical gap in the literature by linking device-level innovation with real-world sensor applications on paper substrates. Full article

Inkjet-printed circuits on flexible substrates are rapidly emerging as a key technology in flexible electronics, driven by their minimal fabrication process, cost-effectiveness, and environmental sustainability. Recent advancements in inkjet-printed devices and circuits have broadened their applications in both sensing and computing. Building on this progress, this work has developed a nonlinear computational element coined as mTanh to serve as an activation function in neural networks. Activation functions are essential in neural networks as they introduce nonlinearity, enabling machine learning models to capture complex patterns. However, widely used functions such as Tanh and sigmoid often suffer from the vanishing gradient problem, limiting the depth of neural networks. To address this, alternative functions like ReLU and Leaky ReLU have been explored, yet these also introduce challenges such as the dying ReLU issue, bias shifting, and noise sensitivity. The proposed mTanh activation function effectively mitigates the vanishing gradient problem, allowing for the development of deeper neural network architectures without compromising training efficiency. This study demonstrates the feasibility of mTanh as an activation function by integrating it into an Echo State Network to predict the Mackey–Glass time series signal. The results show that mTanh performs comparably to Tanh, ReLU, and Leaky ReLU in this task. Additionally, the vanishing gradient resistance of the mTanh function was evaluated by implementing it in a deep multi-layer perceptron model for Fashion MNIST image classification. The study indicates that mTanh enables the addition of 3–5 extra layers compared to Tanh and sigmoid, while exhibiting vanishing gradient resistance similar to ReLU. These results highlight the potential of mTanh as a promising activation function for deep learning models, particularly in flexible electronics applications. Full article

In the quest for sustainable and efficient solutions for modern electronics, flexible electronic devices have garnered global attention due to their potential to revolutionize various technological applications. The manufacturing of these devices poses significant challenges, particularly regarding environmental sustainability and ease of production. A novel method employing direct inkjet printing of silver nanoparticle (npAg) ink onto cellulose nanocrystal (CNC) substrates is presented, offering a promising alternative to conventional methods. This study demonstrates the ability of CNCs to serve as a flexible and biodegradable substrate that does not require complex post-printing treatments to achieve adequate electrical performance. This method was implemented in the fabrication of an electrowetting-on-dielectric (EWOD) device, achieving circuit patterns with high resolutions and reduced resistances. The findings not only validate the use of CNCs in flexible electronic applications but also underscore the potential of advanced printing techniques to develop flexible electronics that are environmentally sustainable and technically feasible. Full article

With the rapid development of integrated circuits, glass substrates are frequently utilized for prototyping various functional electronic circuits due to their superior stability, transparency, and signal integrity. In this experiment, copper wire was printed on a glass substrate using inkjet printing, and the electronic circuit was sintered through laser irradiation with a 532 nm continuous green laser. The relationship between resistivity and microstructure was analyzed after laser sintering at different intensities, scanning speeds, and iterations. The experimental results indicate that the conductivity of the sintered lines initially increases and then decreases with an increase in laser power and scanning speed. At the same power level, multiple sintering runs at a lower scanning speed pose a risk of increased porosity leading to reduced conductivity. Conversely, when the scanning speed exceeds the optimal sintering speed, multiple sintering runs have minimal impact on porosity and conductivity without altering the power. Full article

The development of e-textiles necessitates the creation of highly conductive inks that are compatible with precise inkjet printing, which remains a key challenge. This work presents an innovative, syringe-based method to optimize a novel bio-sourced silver ink for inkjet printing on textiles. We investigate the relationships between inks’ composition, rheological properties, and printing behavior, ultimately assessing the electrical performance of the fabricated circuits. Using Na–alginate and polyethylene glycol (PEG) as the suspension matrix, we demonstrate their viscosity depends on the component ratios. Rheological control of the silver nanoparticle-laden ink has become paramount for uniform printing on textiles. A specific formulation (3 wt.% AgNPs, 20 wt.% Na–alginate, 40 wt.% PEG, and 40 wt.% solvent) exhibits the optimal rheology, enabling the printing of 0.1 mm thick conductive lines with a low resistivity (8 × 10⁻³ Ω/cm). Our findings pave the way for designing eco-friendly ink formulations that are suitable for inkjet printing flexible antennas and other electronic circuits onto textiles, opening up exciting possibilities for the next generation of E-textiles. Full article

The functionalization of conductive inks has been carried out through the decomposition of hydrogen peroxide (H₂O₂) onto the surface of silver nanoparticles (AgNPs). The ink prepared using this eco-friendly chemical reagent has been characterized structurally, chemically, and morphologically, showing the presence of stable AgNPs with suitable properties as well as the absence of residual contamination. The electrical conductivity of such a solution-processable ink is evidenced for patterns designed on flexible photographic paper substrates, using a refillable fountain pen that is implemented as a printing mechanism for the fabrication of simple printed circuit boards (PCBs). The functionality and durability of the tested systems are demonstrated under various mechanical constraints, aiming to basically reproduce the normal operation conditions of flexible electronic devices. The obtained results indicate that the implementation of these AgNP-based inks is relevant for direct applications in inkjet printing technology, thus paving the way for the use of greener chemicals in ink preparation. Full article

In recent years, inkjet printing has emerged as a promising advanced fabrication technology in the field of electronics, offering remarkable advantages in terms of cost-effectiveness, design flexibility, and rapid prototyping. For these reasons, inkjet printing technology has been widely adopted in various applications, including printed circuit board fabrication, sensor development (e.g., temperature, humidity, and pressure sensing), and antenna and filter production, up to the microwave frequency range. The present paper is focused on the investigation of a methodology based on Monte Carlo simulations for quantitatively assessing the influence of fabrication tolerances on the performance of inkjet-printed microwave devices. In particular, the proposed methodology is applied to an inkjet-printed hairpin band pass filter specifically tailored for operation in the L band (i.e., from 1 GHz to 2 GHz). The initial design phase involved the use of computer aided design (CAD) software to optimize the geometric dimensions of the designed filter to closely match the desired performance specifications in terms of bandwidth, insertion loss, and return loss. Later, a Monte Carlo analysis was conducted to evaluate the propagation of tolerances in the fabrication process throughout the design and to estimate their effects on device performance. The fabrication process exploited the advanced capabilities of the Voltera inkjet printer, which was used to deposit a silver-based conductive ink on a commercial Rogers substrate. The device’s performance was evaluated by comparing the simulated scattering parameters with those measured on the developed filter using a vector network analyzer (VNA), thus ensuring accurate validation of real-world performance. Full article

Printing electronics is emerging as one of the fastest-growing engineering technologies that are increasingly used and reliable. It provides an alternative to manufacturing electronics devices based on silicon compounds. This article discusses its challenges, problems, and ways of obtaining desired features efficiently and inexpensively. The influence of the most important parameters of the drop-on-demand (DOD) inkjet printing process on the quality of the conductive layers, together with the results of their ageing tests, is illustrated and discussed in terms of their applicability to general-purpose electronics circuits. Full article

Zinc-ion batteries (ZIBs) are currently being studied as an alternative to lithium-ion batteries (LIBs). The nucleation and growth of the zinc deposition mechanism is a critical field of research in ZIBs, as it directly affects the battery efficiency and lifespan. It is of paramount importance in mitigating the formation of porous, dendritic Zn structures that may cause cell inefficiency and, eventually, short-circuiting failures. Interfacial engineering plays a key role in providing reversible plating and stripping of metallic Zn in ZIBs through the proper regulation of the electrode–electrolyte interface. In this work, we investigated the behavior and characteristics of Zn plating on inkjet-printed Ti₃C₂T_x MXene-coated substrates according to the different electrolyte compositions. Specifically, ZnCl₂ and ZnSO₄ solutions were employed, evaluating the effect of a relatively low-molecular-weight polyethylene glycol (PEG400) addition to the electrolyte as additive. Electrochemical analyses demonstrated higher deposition kinetics in chloride-based electrolytes rather than sulfate ones, resulting in lower nucleation overpotentials. However, the morphology and microstructure of the plated Zn, investigated via scanning electron microscopy (SEM) and X-ray diffraction (XRD), revealed that the electrolytic solution played a predominant role in the Zn crystallite formation rather than the Ti₃C₂T_x MXene coating. Specifically, the preferential Zn [002] orientation could be favored when using additive-free ZnSO₄ solution, and a PEG addition was found to be an efficient texturing agent only in ZnCl₂ solution. Full article

In recent years, researchers prepared composite conductive inks with high conductivity, high thermal conductivity, strong stability, and excellent comprehensive mechanical properties by combining carbon-based materials such as graphene and carbon nanotubes with metal-based materials. Through new electronic printing technologies, conductive inks can be used not only to promote the development of integrated circuits but also in various new electronic products. The conductive mechanism and the main types of conductive inks are introduced in this review. The advantages of electronic printing technology for preparing integrated circuits are analyzed. The research progress of fabricating integrated circuits with different electronic printing processes, such as screen printing, gravure printing, flexographic printing, and inkjet printing, are summarized. The development trend of carbon-based composite conductive ink for integrated circuits is prospected. Full article

Transparent supercapacitors find a large number of applications as components of many electronic devices and circuits. Mixed Ni–Co oxides (NCOs) are among the most promising supercapacitor electrode materials exhibiting high pseudo-capacitance and good electronic conductivity, while inkjet printing is a low cost and versatile technique for electrode printing. Surprisingly, although there have been many studies of NCO supercapacitor films on ITO glass substrates, these have not been prepared by the inkjet technique, and their optical properties were not fully characterized. Hereby, we report the fabrication and characterization of thin (295 and 477 nm thick; 0.017 and 0.035 mg cm⁻² NCO loading) semi-transparent NiCo₂O₄/ITO supercapacitor electrodes, showing transparency to visible light (60–30%, from the thinner to the thicker electrode layers tested), typical mass specific capacitance for NCO-based supercapacitor electrodes (1294–829 Fg⁻¹ at 1 mA cm⁻² discharge current density) and high volumetric capacitance (746–608 F cm⁻³ at 1 mA cm⁻²). The NCO nanoparticles were prepared by hydrothermal synthesis followed by thermal treatment and ball milling (ZrO₂ balls, 0.5 mm diameter), resulting in a cubic nickel–cobalt oxide structure and particle size in the 30–150 nm range, whereas the electrode layers were printed from water-propylene glycol solutions using a Dimatix DMP-2850 drop-on-demand (DoD) inkjet printer. Constant current charge–discharge experiments of the supercapacitor electrode (at ca 0.5 mA cm⁻²) for 1000 cycles confirmed stability of performance. Full article

The field of printed electronics for highly integrated circuits and energy devices demands very fine and highly conductive electric interconnections. In this study, conductive lines having a high cross-sectional aspect ratio were printed via the inkjet printing of Ag nanoparticle inks assisted by a laser-induced selective surface wetting technique: a hydrophobic layer of self-assembled monolayer-treated ZnO nanorods was coated on a glass substrate and selectively ablated by a laser to form micro-channels for the inkjet, whose surface energy changed from 36.3 mJ/m² to 51.5 mJ/m² before and after the laser irradiation. With the varying width of the laser-ablated channels and pitch of jetted ink drops, the 3D shapes of the printed silver lines were measured to investigate their effects on the widths, heights, and uniformities of the printed patterns. The results showed that the present technique realized a uniform line of 35 μm width and 0.46 μm average thickness, having an aspect ratio of 0.013, which is 7.6 times higher than that printed on bare glass. Full article

Increasing demands for precision electronics require individual components such as resistors to be specified, as they can be the limiting factor within a circuit. To specify quality and long-term stability of resistors, noise measurements are a common method. This review briefly explains the theoretical background, introduces the noise index and provides an insight on how this index can be compared to other existing parameters. It then focuses on the different methods to measure excess noise in resistors. The respective advantages and disadvantages are pointed out in order to simplify the decision of which setup is suitable for a particular application. Each method is analyzed based on the integration of the device under test, components used, shielding considerations and signal processing. Furthermore, our results on the excess noise of resistors and resistor networks are presented using two different setups, one for very low noise measurements down to 20 µHz and one for broadband up to 100 kHz. The obtained data from these measurements are then compared to published data. Finally, first measurements on commercial strain gauges and inkjet-printed strain gauges are presented that show an additional 1/f^α component compared to commercial resistors and resistor networks. Full article
