Harmful gases produced by diesel locomotives tend to accumulate within tunnels, posing risks such as dizziness, vomiting, coma, and even death to the working staff, particularly in long tunnels with high traffic density. As the number of such structures increases, ventilation in extra-long tunnels represents a critical challenge within the engineering area. In this study, the ventilation of an extra-long single-bore double-track tunnel operating with diesel locomotives is investigated. Through scale model tests and based on the inspection sensor data, the natural diffusion patterns of harmful gases under various operating conditions were elucidated. Based on the local resistance coefficient optimization theory and numerical simulations, the ventilation shafts of the tunnel were optimally designed, and an overall ventilation scheme was developed. The ventilation effect of the tunnel was verified through improved scale model tests. The results show that harmful gases primarily diffuse towards the higher elevation tunnel entrance, with only gases near the lower entrance escaping from it. Under the same operating conditions, NO₂ diffuses more slowly than CO, making it harder to discharge. Applying the local resistance coefficient optimization theory, the inclined and vertical shafts of the tunnel can be effectively optimized. The optimized ventilation shafts, coupled with jet fans, can reduce harmful gas concentrations below safety limits within one minute. The methodologies and findings presented here can offer valuable guidance for the ventilation design of similar infrastructures. Full article

To address the frequent failure of anti-falling devices in inclined shaft tunnel boring machines caused by cyclic loading and fatigue during construction, this study proposes an optimized self-responsive anti-falling device design. Based on the operational conditions of the “Tianyue” tunnel boring machine, a three-dimensional model was constructed using SolidWorks. Finite element static analysis was employed to validate structural integrity, revealing a maximum stress of 461.19 MPa with a safety factor of 1.71. Explicit dynamic simulations further demonstrated the dynamic penetration process of propellant-driven telescopic columns through concrete lining walls, achieving a penetration depth exceeding 500 mm. The results demonstrate that the device can respond to falling signals within 12 ms and activate mechanical locking. The Q690D steel structure exhibits a deformation of 5.543 mm with favorable stress distribution, meeting engineering safety requirements. The energy release characteristics of trinitrotoluene propellant and material compatibility were systematically verified. Compared to conventional hydraulic support systems, this design offers significant improvements in response speed, maintenance cost reduction, and environmental adaptability, providing an innovative solution for fall protection in complex geological environments. Full article

To accurately investigate the stress and deformation behavior of support structures during mechanical shaft construction, this study proposes an analytical method for active earth pressure calculation based on limit equilibrium theory, incorporating both the radial variation of the circumferential stress coefficient and the spatial arching effect. Considering the entire sliding soil mass behind the shaft wall as the analytical object, the inclination angle of the sliding surface under active limit conditions is derived. Subsequently, by incorporating interlayer shear forces, a horizontal layer analysis is employed to establish the vertical and radial force equilibrium equations, leading to the formulation of an active earth pressure model for circular shafts. Furthermore, based on elastic mechanics theory, a corresponding method is developed to calculate the internal forces of the shaft structure. The theoretical predictions show good agreement with existing model test results and field monitoring data, demonstrating the accuracy and reliability of the proposed approach. The findings provide a theoretical basis for optimizing the design of circular shafts and assessing the structural stability of shaft walls. Full article

Labyrinth seals, extensively used in aerospace and turbomachinery as non-contact sealing devices, undergo accelerated wear and enhanced leakage due to repeated rub-impact between rotating shafts and sealing rings. To address the problem of increased leakage under rub-impact conditions, this research integrates experimental and numerical methods to investigate the deformation mechanisms and leakage characteristics of thermoplastic labyrinth seals. A custom designed rub-impact test rig was constructed to measure dynamic forces and validate finite element analysis (FEA) models with an error of 5.1% in predicting tooth height under mild interference (0.25 mm). Computational fluid dynamics (CFD) simulations further demonstrated that thermoplastic materials, such as PAI and PEEK, displayed superior resilience (with rebound ratios of 57% and 70.3%, respectively). Their post-impact clearances were 4.8–18.3% smaller than those of PTFE and F500. Leakage rates were predominantly correlated with interference, causing a substantial increase compared to the original state; at 0.25 mm interference (reverse flow), increases ranged from 151% (PAI) to 217% (PTFE), highlighting material-dependent performance degradation. Meanwhile, tooth orientation modulated leakage by 0.5–3% through the vena contracta effect. Based on these insights, two optimized inclined-tooth geometries were designed, reducing leakage by 28.2% (Opt1) and 28.1% (Opt2) under rub-impact. These findings contribute to the development of high-performance labyrinth seals suitable for extreme operational environments. Full article

To address the issues of roadway instability and severe air leakage in goaf areas during overlapping coal pillar mining in shallow multi-seam coalfields, this study takes the 22,209 working face of Huojitu Shaft in the Shendong Daliuta Mine as the research object. Using the discrete element method (DEM), the optimal layout of roadways in the lower coal seam and the corresponding evolution of overburden fractures were simulated. In addition, the effectiveness of goaf backfilling in controlling overburden air leakage channels was analyzed and verified. The results indicate that the width of coal pillars in the upper seam should be greater than approximately 23 m to ensure that roadways remain in a stress-stable zone. Roadways in the lower seam should be horizontally arranged within a range of 35–55 m from the center of the overlying coal pillar. This layout effectively avoids placing the roadway beneath the high-stress concentration zone or the pressure-relief area of the goaf. After mining the upper coal seam, the overburden collapse zone takes on a “trapezoidal” shape, and mining-induced fractures develop upward to the surface, forming vertical and inclined fracture channels that penetrate to the surface, resulting in severe air leakage in the goaf. Following the mining of the lower seam, the interlayer strata are completely fractured, leading to secondary development of fractures in the overlying old goaf. This results in the formation of a connected fracture network spanning from the surface through the seam goaf linkage. Implementing goaf backfilling measures significantly reduces the vertical settlement of the overburden, prevents the formation of through-layer air leakage channels, and effectively mitigates interlayer air leakage problems during lower-seam mining. Full article

The inclined shaft lining cross-section is prone to severe issues such as shaft lining cracking and even structural failure due to geometric irregularity and mechanical complexity, posing significant engineering safety hazards. To address these safety concerns, this study introduces Optical Frequency Domain Reflectometry (OFDR) as a novel monitoring approach for inclined shaft linings. OFDR was implemented to measure strain distributions across both the inner and outer surfaces of a model shaft lining, with validation through comparative analysis against strain gauge measurements and numerical simulations. The findings indicate that: (1) OFDR provides accurate strain measurements consistent with conventional methods, and (2) has the ability to detect cracks that cannot be identified by the human eye. This study preliminarily achieved full-section monitoring of strain distribution on both the inner and outer edges of inclined shaft lining using OFDR technology, which holds significant implications for underground construction projects. Full article

Aiming at the problem that rotary tiller knife rollers are prone to entanglement with straw in the wet and sticky soil environment of rice fields in the middle and lower reaches of the Yangtze River in China, an antitangling and sticking cutter was designed. The cutter reduces knife roller entanglement in order to reduce rotary tiller energy consumption and improve work efficiency, and its effectiveness was verified through theoretical analysis, discrete element simulation, and field trials. The design’s validity was verified through theoretical analysis, discrete element simulation, and field tests. The blade inclination design was completed through motion force analysis, and the tool geometry was optimized with a 36.87° inclination baffle and staggered arrangement. A simulation model of the soil–straw–rotary tillage knife interaction was established and we used the discrete element method to analyze the variation in torque between the antisticking knife and the China standard rotary tillage knife (IT245) at four different cutter shaft rotational speeds. In the simulation, the average torque for the antisticking knives was smaller than that of the national standard rotary tillage knives, with reductions of 37.1%, 52.1%, 52.8%, and 50.0%, respectively, demonstrating a remarkable effect. Field tests showed that the average operational efficiency of the antisticking knife was 0.57 hm²/h, with an operation qualification rate of 95.72%. The average torque results from simulation (with and without the antisticking knife) and field tests were analyzed, yielding correlation coefficients of 0.994 and 0.973 for the change curves of average torque between the antisticking knife and the national standard rotary tillage knife. This result confirms the accuracy of the simulation model and the consistency between the simulation and field test results. This study can provide some references for the design and test of antisticking of rotary tillers. Full article

Efficient sugarcane ratooning management requires maintaining soil organic carbon (SOC) balance and improving soil physical properties. Retaining agricultural residues and applying organic fertilizers are essential for sustaining SOC levels. However, excessive soil compaction caused by heavy machinery remains a challenge, and no existing implements are specifically designed to alleviate soil compaction and apply organic fertilizers in sugarcane ratoon fields. This study aimed to design, develop, and evaluate an organic fertilizer applicator capable of performing a single-step operation that integrates subsoiling, fertilizer application, and soil mixing. The developed implement consists of four main components: (1) a pyramid-shaped hopper, (2) a two-way horizontal screw conveyor, (3) a subsoiler, and (4) a disk harrow set. The results indicated that the specific mass flow rate is directly proportional to screw size and inversely proportional to PTO shaft speed. The optimal configuration for the organic fertilizer applicator included an 18-inch harrow set, a 10-degree harrow angle, an inclined-leg subsoiler, and the Low3 gear at 1900 rpm, which required a draft force of 12.75 kN. Field performance tests demonstrated an actual field capacity of 0.89 ha·h⁻¹ and a field efficiency of 66.17%, confirming the implement’s effectiveness in improving soil conditions and integrating tillage with fertilizer application. Full article

This study explores the design and construction methods for auxiliary workings for the deepening of Shaft II at the Borynia Mine. The shaft, an essential intake structure for personnel and material transport, is being extended from 980 m to 1150 m to provide access to a new mining level at 1120 m. Given the challenging geological and operational conditions, a top-to-bottom deepening method was adopted, with excavation from a sub-level accessed via an auxiliary incline. The study details the planning and implementation of key auxiliary workings, including hoisting machine chamber and technological shaft inset. A comprehensive geotechnical analysis was conducted to assess rock mass properties, classify geological formations, and estimate mechanical parameters affecting excavation stability. The support system design was carried out using both analytical and numerical methods, ensuring safe and efficient construction. The applied primary and secondary support structures have successfully maintained excavation stability. The findings demonstrate the reliability of the adopted engineering solutions and their applicability in deep mining environments. Full article

The main shaft seal of offshore wind power equipment is one of the key components of wind power systems. However, wear issues between the seals and the main shaft caused by the intrusion of particulate matter in the environment have become a key factor affecting the service life of the equipment. To improve the surface performance of the main shaft, this study used laser cladding technology to prepare an Fe55 coating on the surface of QT-500 components. Through the wear experiments on HNBR seal pairs with the main shaft under different load conditions, this study thoroughly investigated the impact of the coating on frictional coefficients, wear mechanisms, and the wear morphology of metal surfaces. The experimental results show that the average hardness of the Fe55 coating is 533 HV, which is about 2.3 times the hardness of the substrate, and as the loading force increases, the wear form of the QT-500 metal changes from being dominated by pits to being dominated by furrows. In contrast, the wear form of the Fe55 coating is more inclined to furrows, and no pit formation is observed, indicating that the coating has improved the wear resistance of the surface. The frictional coefficient of the HNBR pair with the metal decreases with increasing load, and the frictional coefficient of the coating is lower than that of the substrate. As the loading increases, the wear morphology of the rubber surface transitions from furrows to pits, and the wear mechanism becomes abrasive wear. Full article

To address the complex challenge of identifying the contact state between a shaft and a hole and to improve the efficiency of robotic shaft-hole assembly tasks, a robotic shaft-hole assembly method based on variable admittance control is proposed. In this method, admittance control serves as the foundational force controller for shaft-hole assembly. On this basis, the Twin Delayed Deep Deterministic policy gradient (TD3) algorithm from deep reinforcement learning is utilized to optimize the parameters of the admittance controller. Additionally, a nonlinear reward function is designed, which not only prevents the assembly strategy from converging to local optima but also further accelerates the training speed of the assembly task. Experiments conducted with a collaborative robotic arm performing 15° inclined hole assembly demonstrated that the assembly efficiency of the variable admittance method was 9.6% higher than that of the fixed admittance parameter method, validating the feasibility and effectiveness of the proposed variable admittance shaft-hole assembly method. Full article

To enhance the stability and safety of marine aquaculture facilities by addressing the limited uplift resistance capacity and susceptibility to deflection of conventional straight-shafted piles, this study introduces an improved H-pile anchor and conducted laboratory experiments. The new anchor incorporates resized H-piles with wing plates added to both sides, optimized for area and placement, as well as an adjusted loading angle. The findings demonstrate a positive correlation between the uplift resistance capacity of the H-pile anchor and its length and width, indicating that while increased pile length significantly enhances resistance, widening has a minimal impact. Additionally, enlarging the wing plate area improves the resistance; however, efficiency (δ) decreases with the increase in the area, suggesting the existence of an optimal size. The optimal wing plate dimensions (L = 80 mm, W = 25 mm) improve uplift resistance by at least 10.6% compared to non-wing pile anchors. Furthermore, positioning the wing plates at the base of the pile anchor rather than the top enhances resistance by approximately 13.8%. Setting the anchor layout angle to 45° reduced the displacement under inclined loads. This research provides essential theoretical support and practical guidance for strengthening the safety and stability of marine aquaculture facilities. Full article

The article presents the results of an experimental study on driven reinforced concrete piles with hybrid shaft, which incorporates several wedge-shaped elements with inclined side faces. A technology for the installing of these piles, involving the addition of loose materials to enhance soil compaction, is herein proposed. Field experiments were conducted to determine the energy intensity of driving and the uplift load resistance of these piles. It was found that the energy intensity of a driving hybrid pile with loose materials addition is 1.4–3.5 times greater compared to conventional driven piles. However, the uplift bearing capacity was 1.5–4.4 times higher than that of piles with a traditional shape. The efficiency of the experimental piles is attributed to an increase in the volume of wedge-shaped elements on the pile shaft and the incorporation of loose materials, such as gravel and sand. The uplift capacity of hybrid shaft piles improves with the increasing volume of the aforementioned parameters. The obtained correlation dependencies enable a reliable calculation of the energy intensity and uplift resistance of hybrid shaft piles installed with the addition of loose materials. These findings hold significant practical importance for foundation design using piles with non-traditional shaft shapes in variant design assessments. Full article

The effect of the epikarst on the development of drawdown dolines and subsidence dolines is described. For this, the resistivity values of the bedrock determined by Vertical Electrical Sounding (VES) measurements were used. The higher resistivities below drawdown dolines are explained by the deeper position of the piezometric surface, while the low resistivity values below subsidence dolines can be traced back to the more elevated position of the piezometric surface. Resistivities increasing towards the centre of drawdown dolines refer to cavity heterogeneity increasing towards the centre and increasing vertical percolation rate, while decreasing resistivity values indicate an increasing degree of cavity fill above the piezometric level. At their asymmetrical variety, the bedrock of their opposite slope is of asymmetric resistivity, which is explained by the different elevations of the piezometric surface and the latter by different infiltration that took place on slopes with different inclinations. The same resistivity values of the doline with a flat floor indicate the homogeneous cavity formation of the epikarst. This latter results in homogeneous vertical infiltration, which favours horizontal dissolution. The piezometric surface is not deflecting below the subsidence dolines because resistivity differences are small between the bedrock below the doline and the bedrock of its environment. Below subsidence doline, above the piezometric surface, cavities develop (the resistivity is higher relative to the resistivity of the environment), and then the cavities become filled by suffosion (therefore, the resistivity below the doline is lower relative to its environment). The passage below the doline develops into a shaft as a result of its concentrated water supply and the epikarst is separated into parts. Full article

In this study, a leading–drawing–cutting–type profiled root–trimming device was designed to address the problems of high impurity and damage rates that occur with the operation of a pull–cut garlic harvester. The main components of the designed device include a pull–clamp mechanism, roll–pulling mechanism, root–trimming knife mechanism, lifter, gearbox, universal drive shaft, motor, and frame that, together, can complete the root–trimming operation for a pull–cut garlic harvester. An orthogonal regression test was carried out by taking the roller diameter, the roller inclination angle, the knife rotation speed, and the working speed as factors and by taking the impurity rate and the damage rate as indices. The results of the orthogonal regression test showed that the impurity rate was most strongly affected by the roller diameter, followed by the knife rotation speed, the working speed, and the roller inclination angle. Meanwhile, the damage rate was most strongly affected by the knife rotation speed, followed by the roller diameter, the working speed, and the roller inclination angle. The regression analysis showed that when the roller diameter was 100 mm, the roller inclination angle was 25°, the knife rotation speed was 200 r·min⁻¹, and the working speed was 1.22 km·h⁻¹, the comprehensive trimming quality reached its maximum value of 97.82%. The verification result of the parallel test gave a value of 97.52%, which was mainly affected by the irregular sizes of the bulbs, but it showed no significant difference from the regression analysis results. The tests verified that the profiled root–trimming device could be applied to develop the technology of garlic pull–cut harvesters. Full article
