Search Results (21)

This paper analyzes the influence of the number of ignition coils and spark discharge energy on the Coefficient of Variation of Indicated Mean Effective Pressure (COV_IMEP) of an SI internal combustion piston engine. A modern electronically controlled induction ignition system is used during the test. Two fuels are used in the experiment. The reference fuel is gasoline and the tested fuel is ammonia. For the traditional fuel, using an additional ignition coil does not improve COV_IMEP. This parameter for gasoline has an almost constant value for different ignition system charging times. The situation is different for ammonia. This fuel requires high ignition energy. The use of one ignition coil demands a long charging time. For short charging times, unrepeatability of the engine cycles is unacceptable. The use of an additional ignition coil allowed to the charging coil timing to be shortened and the unrepeatable engine cycles to be reduced. This paper determined the maximum charging time of the used ignition coil, above which the spark parameters are worse. In addition, the influence of charging time and number of ignition coils on total spark energy, spark discharge duration, maximum spark power, and voltage during spark discharge for ammonia is presented. The data presented in this paper are developed based on measurements of current and voltage in the secondary winding of the ignition coil. A self-developed electronic device enabling the change in spark energy is used to control the ignition system. This paper also presents the construction of modern ignition systems, describes the functions of selected components, and briefly discusses their diagnostics. Full article

This paper presents the design and development of a proof of concept (PoC) open-source data logger system for wireless data acquisition via Wi-Fi aimed at bench testing and fault detection in combustion and electric engines. The system integrates multiple sensors, including accelerometers, microphones, thermocouples, and gas sensors, to monitor critical parameters, such as vibration, sound, temperature, and CO₂ levels. These measurements are crucial for detecting anomalies in engine performance, such as ignition and combustion faults. For combustion engines, temperature sensors detect operational anomalies, including diesel engines operating beyond the normal range of 80 °C to 95 °C and gasoline engines between 90 °C and 110 °C. These readings help identify failures in cooling systems, thermostat valves, or potential coolant leaks. Acoustic sensors identify abnormal noises indicative of issues such as belt misalignment, valve knocking, timing irregularities, or loose parts. Vibration sensors detect displacement issues caused by engine mount failures, cracks in the engine block, or defects in pistons and valves. These sensors can work synergistically with acoustic sensors to enhance fault detection. Additionally, CO₂ and organic compound sensors monitor fuel combustion efficiency and detect failures in the exhaust system. For electric motors, temperature sensors help identify anomalies, such as overloads, bearing problems, or excessive shaft load. Acoustic sensors diagnose coil issues, phase imbalances, bearing defects, and faults in chain or belt systems. Vibration sensors detect shaft and bearing problems, inadequate motor mounting, or overload conditions. The collected data are processed and analyzed to improve engine performance, contributing to reduced greenhouse gas (GHG) emissions and enhanced energy efficiency. This PoC system leverages open-source technology to provide a cost-effective and versatile solution for both research and practical applications. Initial laboratory tests validate its feasibility for real-time data acquisition and highlight its potential for creating datasets to support advanced diagnostic algorithms. Future work will focus on enhancing telemetry capabilities, improving Wi-Fi and cloud integration, and developing machine learning-based diagnostic methodologies for combustion and electric engines. Full article

In order to produce reliable and reproducible ignition of lean fuel–air mixtures and highly stratified mixtures, it is necessary to ensure a high concentration of spark discharge energy and to provide a strong energy impulse for the triggering of chain processes of chemical decomposition of fuel molecules. For this reason, studies have been undertaken on the flow of electrical energy from the ignition system to the spark plug and on the formation of an electric discharge arc with a high concentration of thermal energy. The experimental results were obtained using an ignition coil energy test stand and a constant volume chamber with high-speed spark discharge recording capability. It was confirmed that increasing the charging time of the ignition coil from 0.5 ms to 5.0 ms increases the energy delivered to the coil from 9.5 mJ to 330 mJ. In the same range, the energy generated by the coil was recorded to range from 4.2 mJ to 70 mJ. The coil’s efficiency was found to decrease with increasing charging time from 45% up to 20.5%. Further energy losses were presented when the spark discharge energy was analyzed. In the paper, the results of investigations concerning electric discharge arc development have been presented, illustrated by a few exemplary photos, and discussed. The mathematical interpretation of the electrical energy flux in the ignition system resulting from the energy of the discharge arc has been conducted and illustrated by some functional independences and relationships. Full article

To determine the timing of inflammation in gas and gasoline combustion engines, the point of 10% mass fraction conversion of fuel (MFB10) is commonly used. The MFB10 can be determined from the heating curve, which in turn is calculated from the in-cylinder pressure curve. However, the cylinder pressure is an indirect parameter with regard to inflammation, as it is the result of the combustion that follows the inflammation. An attempt is made to derive a new, direct parameter of inflammation based on optical measurements in order to detect inflammation more rapidly and accurately. The background-oriented Schlieren technique (BOS) in combination with high-magnification optics and a high-speed camera is used to detect local density changes coming from the particle wave around the ignition kernel of a hydrogen combustion inside a combustion chamber. Via BOS and regular high-magnification high-speed imaging, the influence of ignition coil dwell time and in-cylinder pressure on the spark phases and the inflammation itself are evaluated. As a potential direct parameter for inflammation, the size of the particle wave resulting from the expanding ignition kernel is evaluated. It was found that a higher coil energy supports a faster propagation of the particle wave at ambient pressure. At higher pressures, general combustion effects override the effect of the influence of the coil energy on the propagation speed of the particle wave. In addition, the presence of successful inflammation was found to influence the spark phases. A directly measurable parameter for ignition could be found at a basic level, which will serve as a starting point for further detailed investigations. Full article

The article presents the results of research in the field of limiting the effects of overvoltages and improving the conditions for the self-extinguishing of transient faults in medium voltage networks with earth fault current compensation. The aim of the research was to estimate the level of overvoltages generated by an earth fault during re-ignition of the electric arc and to assess the possibility of reducing them by increasing the attenuation of the earth fault circuit. The results of the conducted tests show that to increase the attenuation, which ensures a significant effect of limiting such overvoltages, it is enough to change the way of operation of the devices forcing an additional active component of the earth fault current (AWSCz/ACFA). In Poland, such devices are commonly used to improve the effectiveness of earth fault protection. It was also found that the proposed solution enables accurate tuning of the Petersen coil in networks with natural asymmetry of earth capacitances. Therefore, changes in the operation of AWSCz/ACFA devices may have a beneficial effect on the limiting the effects of repeated ignitions during earth faults and, at the same time, enable the accurate tuning of the Petersen coil and increase its ability to extinguish arc-fed faults. Research and theoretical analysis of the issue were carried out on the basis of data characterizing the parameters of the earth fault circuits of the real 15 kV network. Full article

With an increase in the international trade of agricultural and non-agricultural products, there is an increase in the possibility of introducing hitchhiking insect pests such as Halyomorpha halys, which has been detected on imported vehicles and agricultural machinery. Although methyl bromide (MB) is provisionally used to control invasive pests, it is classified as a restricted chemical owing to its potential to deplete the ozone layer and pose health risks to humans in cases of inadequate ventilation, as well as concerns regarding consumer safety. Therefore, this study investigated ethyl formate’s (EF’s) efficacy against H. halys and its efficacy and sorption, as an alternative to MB, on main electronic components, including alternators, ignition coils, and motors. Fumigation with 35 and 70 g/m³ EF for 4 h at 15 °C had no damage on the main electronic components as evaluated using various operation tests. In a commercial trial, H. halys infestation was effectively controlled with 35 g/m³ EF fumigated for 4 h at 23 °C using a 30 m³ polyvinyl chloride tarpaulin fumigation chamber. After ventilation, the EF concentration decreased below the safety level within 10 min and reached the zero level within 40 min for worker safety. This novel sanitary treatment using EF fumigation on imported agricultural machinery could be an effective method without causing mechanical damage. Full article

This paper presents an empirical study of a spark-ignition internal combustion engine with modifications made to increase its effectiveness. The modification was implemented bi-directionally in terms of changes to the compression ratio and changes to the engine’s valve train. The compression ratio was increased by 2.3 units by design and a hybrid intake valve opening control was used in the engine’s valve train. The hybrid control involved autonomous control of one of the inlet valves with a dedicated electromagnetic actuator. The designed electromagnetic actuator was mounted downstream of the single-cylinder engine’s intake system’s modified camshaft to control the effective compression pressure build-up. Field calculations were carried out for the electromagnetic actuator’s design variants and its current characteristics were determined. The multivariate calculations were carried out in order to find the quasi-optimal geometry of the actuator. The width and height of magnetic field coils and the dimensions of the stator poles were changed, while maintaining the same external dimensions of the actuator to enable its mounting in the cylinder head system. In the next step, the prototype of the actuator was made and placed on the combustion engine in order to conduct the experimental investigations. The work was aimed at improving the internal combustion engine’s efficiency at the low load range, as this is load range in which it has low efficiency despite it being the most often used during normal vehicle operation. The original measurement stand was prepared, and many tests were carried out in order to investigate the influence of the electromagnetic valve on the combustion engine characteristic. This improved the internal combustion engine’s efficiency at its low-load range by up to 25%. Both calculation and measurement results are presented in form of graphs. Full article

When designing a new type of power plants operating on pulsed detonations of gaseous or liquid fuels, the concept of fast deflagration-to-detonation transition (FDDT) is used. According to the concept, a flame arising from a weak ignition source must accelerate so fast as to form an intense shock wave at a minimum distance from the ignition source so that the intensity of the shock wave is sufficient for fast shock-to-detonation transition by some additional arrangements. Hence, the FDDT concept implies the use of special means for flame acceleration and shock wave amplification. In this work, we study the FDDT using a pulsed detonation tube comprising a Shchelkin spiral and a helical tube section with ten coils as the means for flame acceleration and shock amplification (focusing), respectively. To attain the FDDT at the shortest distances for fuels of significantly different detonability, the diameter of the pulsed detonation tube is taken close to the limiting diameter of detonation propagation for air mixtures of regular hydrocarbon fuels (50 mm). Experiments are conducted with air mixtures of individual gaseous fuels (hydrogen, methane, propane, and ethylene) and binary fuel compositions (methane–hydrogen, propane–hydrogen, and ethylene–hydrogen) at normal pressure and temperature conditions. The use of a helical tube with ten coils is shown to considerably extend the fuel-lean concentration limits of detonation as compared to the straight tube and the tube with a helical section with two coils. Full article

Nuclear fusion experiments are becoming one of the most interesting focuses of research, given the hope of generating programmable, safe, and green energy. Among them, ASDEX (axially symmetric divertor experiment) upgrade has been operating at the Max Planck Institute for Plasma Physics (IPP) research center since 1991. To ignite and confine the plasma, several coils must be supplied through controllable high-current pulsed power supplies. The toroidal field magnets are here considered and a modular multilevel converter (MMC)-like system was designed and tested thanks to a small-scale prototype in previous works. The MMC-like topology, consisting of full-bridge submodules (SMs) with IGBTs and supercapacitor and exploitable also for other industrial applications, was chosen because of its modularity, redundancy, fault tolerance, and large amount of stored energy. The prototype, made of four SMs, was necessary to highlight critical key points in the design process. However, its scalability must be further tested before building a full-scale power supply, meant to reach almost 2400 SMs to guarantee the energy required by the load. This paper aims at validating hardware-in-the-loop (a powerful, safe, and relatively inexpensive real-time simulation environment that enables testing with real control boards) as a useful technology for power supply scalability studies and not only for control strategy tests. The results obtained previously from the prototype will allow us to finally increase the number of SMs and test the MMC-like scalability. Full article

The scale up of nonthermal plasma (NTP) reactors requires the simultaneous operation in parallel of a large number of units supplied from the same power supply. The present paper aims to demonstrate the feasibility of parallel operation of multiple mini-NTP reactors. In order to demonstrate the parallel operation of a large number of NTP reactors, three different types of power supplies are considered. In addition to the most simple and common solution, which involves the use of individual, independent power supply for each reactor (an ignition coil driven by a pulse generator), two other configurations of supplies (capacitive AC and capacitive DC), simpler and less expensive, are tested. The capacitive pulsed power supplies allow the generation of HV pulses by an AC power supply (usually an AC transformer), as well as by a DC power supply using an R–C circuit. For the DC resistive–capacitive configuration, the frequency can be adjusted. For all configurations, the power of the discharge can be modified by changing the value of capacitors or resistors. The feasibility of the proposed systems was demonstrated by assessing the concentration of hydrogen peroxide induced in water after plasma treatment. The obtained results reveal that the proposed capacitive AC and DC power supplies allow a large number of plasma reactors to operate in parallel independently. Full article

The current study focuses on minimising the bubbles in polyester-insulated ignition coils, which were produced with a defect level of ~21–25% or 210–250 coils per 1000 batch size by using the potting method. This high-level rejection makes a substantial financial impact by increasing waste material, manufacturing, and after-sales costs. Hence, to control the bubbled problem without using expensive and maintenance-heavy techniques, the process parameters in the potting method were alternated and investigated using one factor at a time, which played a vital role in the formation/reduction of bubbles in the ignition coil insulation. Process parameters, including pre/process heating, the appropriate MEKP/cobalt naphthenate ratio, the pouring amount/increments, and the stirring speeds, reduced the bubble formation per lot from 205 ± 30 to 146 ± 25, 108 ± 21, 61 ± 17, and 10 ± 2 per 1000 lot accordingly. In addition, a comparative study was conducted in terms of performance and life cycle endurance, using Japanese and Indian standards. Furthermore, an after-sale warranty claim also supports the proposed changes in the potting technique. This modification may reduce the after-sales rejection within two years to approximately ~85%. This modification in the potting technique is extremely cost-effective in comparison to expensive processes, i.e., vacuum-pressure impregnation and vacuum impregnation, which require extensive labour and maintenance. Full article

This study presents a combined carbon footprint (CF) and environment damage assessment with a cradle-to-gate approach for an ignition coil. The process considers a data flow of product as the phases: raw materials preparation, part processing, final-product finishing, and packaging. The assessment was performed to explore an automotive ignition pencil coil during its developing phase. This study illustrated that a green product problem could be evaluated as a carbon footprint and environmental hazard. By using the conceptual flow to set up the assessment procedure, a product can be decomposed into several material ingredients to specify the input parameters in a Life Cycle Assessment. A total CF of an ignition coil can be investigated individually by each of the materials. The total CF of an ignition pencil coil equal to 0.5254 kgCO₂eq was calculated. The insulated filling and copper winding of an ignition coil generated the two most impacting processes in terms of CF (21.83% and 17.50%, respectively). EPS (Environmental Priority Strategies) methodology evaluates the environmental damage of the product in the product design process. As a result, the metal material has a seriously damaging impact on human health and inanimate resources, especially inanimate resources. The total CF generated by the newly devised ignition coil is over 39~62 percent less than a general type one that exists in the current market. The new ignition pencil coil also uses fewer raw materials and therefore reduces environmental damage to the Earth. Full article

Advanced combustion technologies, like highly boosted and lean or dilute combustion, have been employed to meet the demands of high efficiency and low emissions in SI engines, which have increased the challenges of ignition control. It is essential to find a suitable ignition strategy due to the need to develop a next-generation spark ignition system. In this study, simultaneous visualization by a high-speed infrared camera (FLIR X6900sc) and a conventional high-speed camera (FASTCAM SA-X) is carried out to obtain deeper insights into the ignition process in a constant volume combustion chamber (CVCC). Infrared images have provided a more accurate way of measuring the initial flame and are able to analyze quantitatively. Ignition performance is studied with various mixture dilutions, flow conditions, and discharge characteristics. Two types of ignition coils that have the same discharge energy were analyzed in particular. The results show that extending the discharge duration is more helpful in improving the ignition performance under the increasing dilution ratio, compared to the enhanced discharge current at the same discharge energy. However, the discharge current plays a more vital role in perfecting the ignition performance under the increasing local flow velocity than the discharge duration. Full article

This paper discusses the research and analysis of the dynamics of high-voltage generating systems. The test subject is an ignition system modelled by a set of two induction coils with an open ferromagnetic core that constitutes an ignition coil. The essence of the tests involved the application of magnetic coupling of the fractional order that enabled taking into account the non-idealities of the coils and the connector that implements the ignition point. The paper contains the results of a theoretical analysis, supported by digital simulations. The conducted experiments confirm the purposefulness of the conducted analyses and the possibility of modeling real objects based on circuits with fractional-order elements. Full article

The miniaturization of electrical equipment and popularization of portable devices is an appealing motivation for the development of small-scale heat engines. However, the in-cylinder charge leaks severely as the engine dimension shrinks. The free-piston engine on a small scale provides better sealing than other miniature heat engines. Therefore, a miniature free-piston generator (MFPG) with a single-piston internal combustion engine (ICE) and a voice coil motor (VCM) was proposed in this work. A dynamic model with special attention on the heat transfer and leakage was established accordingly, upon which parametric studies of leakage and its effects on the performance of the MFPG system were performed. Four key parameters, including scavenging pressure, ignition position, combustion duration and piston mass, were considered in the model. The results showed that the mass leakage during the compression decreases with the rise of the motoring current. The indicated thermal efficiency can be improved by boosting scavenging pressure and increase motoring current. The critical ignition position is 2 mm before the top dead center. When ignition occurs later than that, the MFPG system is incapable of outputting power. The chemical to electric energy conversion efficiency is about 5.13%, with an output power of 10~13 W and power density around 4.7~5.7 W/cc. Full article
