We analyze the power of the recently proposed Lorentz quantum computer (LQC), a theoretical model leveraging hyperbolic bits (hybits) governed by complex Lorentz transformations. We define the complexity class BLQP (bounded-error Lorentz quantum polynomial-time) and demonstrate its equivalence to the complexity class ${\mathrm{P}}^{♯\mathrm{P}}$ (the class of problems solvable by a deterministic polynomial-time Turing machine with access to a $♯\mathrm{P}$ oracle). LQC algorithms are shown to solve NP-hard problems, such as the maximum independent set (MIS), in polynomial time, thereby placing NP and co-NP within BLQP. Furthermore, we establish that LQC can efficiently simulate quantum computing with postselection (PostBQP), while the reverse is not possible, highlighting LQC’s unique “super-postselection” capability. By proving BLQP $={\mathrm{P}}^{♯\mathrm{P}}$, we situate the entire polynomial hierarchy (PH) within BLQP and reveal profound connections between computational complexity and physical frameworks like Lorentz quantum mechanics. These results underscore LQC’s theoretical superiority over conventional quantum computing models and its potential to redefine boundaries in complexity theory. Full article

In a biological nervous system, neurons are connected to each other via synapses to transmit information. Synaptic crosstalk is the phenomenon of mutual interference or interaction of neighboring synapses between neurons. This phenomenon is prevalent in biological neural networks and has an important impact on the function and information processing of the neural system. In order to simulate and study this phenomenon, this paper proposes a memristor model based on hyperbolic tangent function for simulating the activation function of neurons, and constructs a three-neuron HNN model by coupling two memristors, which brings it close to the real behavior of biological neural networks, and provides a new tool for studying complex neural dynamics. The intricate nonlinear dynamics of the MHNN are examined using techniques like Lyapunov exponent analysis and bifurcation diagrams. The viability of the MHNN is confirmed through both analog circuit simulation and FPGA implementation. Moreover, an image encryption approach based on the chaotic system and a dynamic key generation mechanism are presented, highlighting the potential of the MHNN for real-world applications. The histogram shows that the encryption algorithm is effective in destroying the features of the original image. According to the sensitivity analysis, the bit change rate of the key is close to 50% when small perturbations are applied to each of the three parameters of the system, indicating that the system is highly resistant to differential attacks. The findings indicate that the MHNN displays a wide range of dynamical behaviors and high sensitivity to initial conditions, making it well-suited for applications in neuromorphic computing and information security. Full article

Light has been intensively investigated as a computing medium due to its high-speed propagation and large operation bandwidth. Since the invention of the first laser in 1960, the development of optical computing technologies has presented both challenges and opportunities. Recent advances in artificial intelligence over the past decade have opened up new horizons for optical computing applications. This study presents an end-to-end truth table direct mapping approach using on-chip deep diffractive neural network (D²NN) technology to achieve highly parallel optical logic operations. To enable precise logical operations, we propose an on-chip nonlinear solution leveraging the similarity between the hyperbolic tangent (tanh) function and reverse saturable absorption characteristics of quantum dots. We design and demonstrate a 4-bit on-chip D²NN full adder circuit. The simulation results show that the proposed architecture achieves 100% accuracy for 4-bit full adders across the entire dataset. Full article

The increasing demand for energy-efficient hardware platforms to support artificial intelligence (AI) and machine learning (ML) algorithms in edge computing has driven the adoption of system-on-chip (SoC) architectures. Implementing neural network (NN) activation functions, such as the hyperbolic tangent (tanh), on hardware presents challenges due to computational complexity, high resource requirements, and power consumption. This paper aims to optimize the hardware implementation of the tanh function using continued fraction and polynomial approximations to minimize resource consumption and power usage while preserving computational accuracy. Five models of the tanh function, including continued fraction and quadratic approximations, were implemented on Intel field-programmable gate arrays (FPGAs) using VHDL and Intel’s ALTFP toolbox, with 32-bit floating-point outputs validated against MATLAB’s 64-bit floating-point results. Detailed analyses of resource utilization, power optimization, clock latency, and bit-level accuracy were conducted, focusing on minimizing logic elements and digital signal processing (DSP) blocks while achieving high precision and low power consumption. The most optimized model was further integrated into a four-input, two-output recurrent neural network (RNN) structure to assess real-time performance. Experimental results demonstrate that the continued fraction-based models significantly reduce resource usage, computation time, and power consumption, enhancing FPGA performance for AI/ML applications in resource-constrained and power-sensitive environments. Full article

The occurrence of downhole high-frequency torsional oscillations (HFTO) can lead to the significant damage of drilling tools and can adversely affect drilling efficiency. Therefore, establishing a reliable HFTO identification model is crucial. This paper proposes an improved whale algorithm optimization support vector machine (TSWOA-SVM) for accurate HFTO identification. Initially, the population is initialized using Fuch chaotic mapping and a reverse learning strategy to enhance population quality and accelerate the whale optimization algorithm (WOA) convergence. Subsequently, the hyperbolic tangent function is introduced to dynamically adjust the inertia weight coefficient, balancing the global search and local exploration capabilities of WOA. A simulated annealing strategy is incorporated to guide the population in accepting suboptimal solutions with a certain probability, based on the Metropolis criterion and temperature, ensuring the algorithm can escape local optima. Finally, the optimized whale optimization algorithm is applied to enhance the support vector machine, leading to the establishment of the HFTO identification model. Experimental results demonstrate that the TSWOA-SVM model significantly outperforms the genetic algorithm-SVM (GA-SVM), gray wolf algorithm-SVM (GWO-SVM), and whale optimization algorithm-SVM (WOA-SVM) models in HFTO identification, achieving a classification accuracy exceeding 97%. And the 5-fold crossover experiment showed that the TSWOA-SVM model had the highest average accuracy and the smallest accuracy variance. Overall, the non-parametric TSWOA-SVM algorithm effectively mitigates uncertainties introduced by modeling errors and enhances the accuracy and speed of HFTO identification. By integrating advanced optimization techniques, this method minimizes the influence of initial parameter values and balances global exploration with local exploitation. The findings of this study can serve as a practical guide for managing near-bit states and optimizing drilling parameters. Full article

We propose a neural-network-based watermarking method that introduces the quantized activation function that approximates the quantization of JPEG compression. Many neural-network-based watermarking methods have been proposed. Conventional methods have acquired robustness against various attacks by introducing an attack simulation layer between the embedding network and the extraction network. The quantization process of JPEG compression is replaced by the noise addition process in the attack layer of conventional methods. In this paper, we propose a quantized activation function that can simulate the JPEG quantization standard as it is in order to improve the robustness against the JPEG compression. Our quantized activation function consists of several hyperbolic tangent functions and is applied as an activation function for neural networks. Our network was introduced in the attack layer of ReDMark proposed by Ahmadi et al. to compare it with their method. That is, the embedding and extraction networks had the same structure. We compared the usual JPEG compressed images and the images applying the quantized activation function. The results showed that a network with quantized activation functions can approximate JPEG compression with high accuracy. We also compared the bit error rate (BER) of estimated watermarks generated by our network with those generated by ReDMark. We found that our network was able to produce estimated watermarks with lower BERs than those of ReDMark. Therefore, our network outperformed the conventional method with respect to image quality and BER. Full article

With the rapid development of technologies like artificial intelligence, high-performance computing chips are playing an increasingly vital role. The inverse hyperbolic sine and inverse hyperbolic cosine functions are of utmost importance in fields such as image blur and robot joint control. Therefore, there is an urgent need for research into high-precision, high-performance hardware Intellectual Property (IP) for arcsinh and arccosh functions. To address this issue, this paper introduces a novel 128-bit low-latency floating-point hardware IP for arcsinh and arccosh functions, employing an enhanced Coordinate Rotation Digital Computer (CORDIC) algorithm, achieving a computation precision of 113 bits in just 32 computation cycles. This significantly enhances computational efficiency while reducing hardware implementation latency. The results indicate that, when compared to Python standard results, the calculated error of the proposed hardware IP does not exceed $8\times {10}^{-34}$. Furthermore, this paper synthesizes the completed IP using the TSMC 65 nm process, with a total IP area of 2.1056 mm${}^2$. Operating at a frequency of 300 MHz, its power is 22.4 mW. Finally, hardware implementation and resource analysis are conducted and compared on an Field Programmable Gate Array (FPGA). The results show that the improved algorithm trades a slight area increase for lower latency and higher accuracy. The designed hardware IP is expected to provide a more accurate and efficient computational tool for applications like image processing, thereby advancing technological development. Full article

Atrial Fibrillation (AF) is one of the most common heart arrhythmias. It is known to cause up to 15% of all strokes. In current times, modern detection systems for arrhythmias, such as single-use patch electrocardiogram (ECG) devices, have to be energy efficient, small, and affordable. In this work, specialized hardware accelerators were developed. First, an artificial neural network (NN) for the detection of AF was optimized. Special attention was paid to the minimum requirements for the inference on a RISC-V-based microcontroller. Hence, a 32-bit floating-point-based NN was analyzed. To reduce the silicon area needed, the NN was quantized to an 8-bit fixed-point datatype (Q7). Based on this datatype, specialized accelerators were developed. Those accelerators included single-instruction multiple-data (SIMD) hardware as well as accelerators for activation functions such as sigmoid and hyperbolic tangents. To accelerate activation functions that require the e-function as part of their computation (e.g., softmax), an e-function accelerator was implemented in the hardware. To compensate for the losses of quantization, the network was expanded and optimized for run-time and memory requirements. The resulting NN has a 7.5% lower run-time in clock cycles (cc) without the accelerators and 2.2 percentage points (pp) lower accuracy compared to a floating-point-based net, while requiring 65% less memory. With the specialized accelerators, the inference run-time was lowered by 87.2% while the F1-Score decreased by 6.1 pp. Implementing the Q7 accelerators instead of the floating-point unit (FPU), the silicon area needed for the microcontroller in 180 nm-technology is below 1 mm${}^2$. Full article

In this paper, we propose an optimized method for nonlinear function approximation based on multiplierless piecewise linear approximation computation (ML-PLAC), which we call OML-PLAC. OML-PLAC finds the minimum number of segments with the predefined fractional bit width of input/output, maximum number of shift-and-add operations, user-defined widths of intermediate data, and maximum absolute error (MAE). In addition, OML-PLAC minimizes the actual MAE as much as possible by iterating. As a result, under the condition of satisfying the maximum number of segments, the MAE can be minimized. Tree-cascaded 2-input and 3-input multiplexers are used to replace multi-input multiplexers in hardware architecture as well, reducing the depth of the critical path. The optimized method is applied to logarithmic, antilogarithmic, hyperbolic tangent, sigmoid and softsign functions. The results of the implementation prove that OML-PLAC has better performance than the current state-of-the-art method. Full article

Phylogenetic placement, used widely in ecological analyses, seeks to add a new species to an existing tree. A deep learning approach was previously proposed to estimate the distance between query and backbone species by building a map from gene sequences to a high-dimensional space that preserves species tree distances. They then use a distance-based placement method to place the queries on that species tree. In this paper, we examine the appropriate geometry for faithfully representing tree distances while embedding gene sequences. Theory predicts that hyperbolic spaces should provide a drastic reduction in distance distortion compared to the conventional Euclidean space. Nevertheless, hyperbolic embedding imposes its own unique challenges related to arithmetic operations, exponentially-growing functions, and limited bit precision, and we address these challenges. Our results confirm that hyperbolic embeddings have substantially lower distance errors than Euclidean space. However, these better-estimated distances do not always lead to better phylogenetic placement. We then show that the deep learning framework can be used not just to place on a backbone tree but to update it to obtain a fully resolved tree. With our hyperbolic embedding framework, species trees can be updated remarkably accurately with only a handful of genes. Full article

This paper proposes a novel architecture for the computation of X^Y-like functions based on the QH CORDIC (Quadruple-Step-Ahead Hyperbolic Coordinate Rotation Digital Computer) methodology. The proposed architecture converts direct computing of function X^Y to logarithm, multiplication, and exponent operations. The QH CORDIC methodology is a parallel variant of the traditional CORDIC algorithm. Traditional CORDIC suffers from long latency and large area, while the QH CORDIC has much lower latency. The computation of functions lnx and e^x is accomplished with the QH CORDIC. To solve the problem of the limited range of convergence of the QH CORDIC, this paper employs two specific techniques to enlarge the range of convergence for functions lnx and e^x, making it possible to deal with high-precision floating-point inputs. Hardware modeling of function X^Y using the QH CORDIC is plotted in this paper. Under the TSMC 65 nm standard cell library, this paper designs and synthesizes a reference circuit. The ASIC implementation results show that the proposed architecture has 30 more orders of magnitude of maximum relative error and average relative error than the state-of-the-art. On top of that, the proposed architecture is also superior to the state-of-the-art in terms of latency, word length and energy efficiency (power × latency × period /efficient bits). Full article

CORDIC algorithm is used for low-cost hardware implementation to calculate transcendental functions. This paper proposes a low-latency high-precision architecture for the computation of hyperbolic functions sinhx and coshx based on an improved CORDIC algorithm, that is, the QH-CORDIC. The principle, structure, and range of convergence of the QH-CORDIC are discussed, and the hardware circuit architecture of functions sinhx and coshx using the QH-CORDIC is plotted in this paper. The proposed architecture is implemented using an FPGA device, showing that it has 75% and 50% latency overhead over the two latest prior works. In the synthesis using TSMC 65 nm standard cell library, ASIC implementation results show that the proposed architecture is also superior to the two latest prior works in terms of total time (latency × period), ATP (area × total time), total energy (power × total time), energy efficiency (total energy/efficient bits), and area efficiency (efficient bits/area/total time). Comparison of related works indicates that it is much more favorable for the proposed architecture to perform high-precision floating-point computations on functions sinhx and coshx than the LUT method, stochastic computing, and other CORDIC algorithms. Full article

Orthogonal frequency division multiplexing (OFDM) is the key technology used in high-speed communication systems. One of the major drawbacks of OFDM systems is the high peak-to-average power ratio (PAPR) of the transmitted signal. The transmitted signal with a high PAPR requires a very large linear range of the Power Amplifier (PA) on the transmitter side. In this paper, we propose and study a new clipping method named Palm Clipping (Palm date leaf) based on hyperbolic cosine. To evaluate and analyze its performance in terms of the PAPR and Bit Error Rate (BER), we performed some computer simulations by varying the Clipping Ratio (CR) and modulation schemes. The obtained results show that it is possible to achieve a gain of between 7 and 9 dB in terms of PAPR reduction depending on the type of modulation. In addition, comparison with several techniques in terms of PAPR and BER shows that our method is a strong alternative that can be adopted as a PAPR reduction technique for OFDM-based communication systems. Full article

With increasing real-time constraints being put on the use of Deep Neural Networks (DNNs) by real-time scenarios, there is the need to review information representation. A very challenging path is to employ an encoding that allows a fast processing and hardware-friendly representation of information. Among the proposed alternatives to the IEEE 754 standard regarding floating point representation of real numbers, the recently introduced Posit format has been theoretically proven to be really promising in satisfying the mentioned requirements. However, with the absence of proper hardware support for this novel type, this evaluation can be conducted only through a software emulation. While waiting for the widespread availability of the Posit Processing Units (the equivalent of the Floating Point Unit (FPU)), we can already exploit the Posit representation and the currently available Arithmetic-Logic Unit (ALU) to speed up DNNs by manipulating the low-level bit string representations of Posits. As a first step, in this paper, we present new arithmetic properties of the Posit number system with a focus on the configuration with 0 exponent bits. In particular, we propose a new class of Posit operators called L1 operators, which consists of fast and approximated versions of existing arithmetic operations or functions (e.g., hyperbolic tangent (TANH) and extended linear unit (ELU)) only using integer arithmetic. These operators introduce very interesting properties and results: (i) faster evaluation than the exact counterpart with a negligible accuracy degradation; (ii) an efficient ALU emulation of a number of Posits operations; and (iii) the possibility to vectorize operations in Posits, using existing ALU vectorized operations (such as the scalable vector extension of ARM CPUs or advanced vector extensions on Intel CPUs). As a second step, we test the proposed activation function on Posit-based DNNs, showing how 16-bit down to 10-bit Posits represent an exact replacement for 32-bit floats while 8-bit Posits could be an interesting alternative to 32-bit floats since their performances are a bit lower but their high speed and low storage properties are very appealing (leading to a lower bandwidth demand and more cache-friendly code). Finally, we point out how small Posits (i.e., up to 14 bits long) are very interesting while PPUs become widespread, since Posit operations can be tabulated in a very efficient way (see details in the text). Full article

The purpose of this paper was to propose a complete analysis and parameter estimations of a new simplified and highly nonlinear hafnium dioxide memristor model that is appropriate for high-frequency signals. For the simulations; a nonlinear window function previously offered by the author together with a highly nonlinear memristor model was used. This model was tuned according to an experimentally recorded current–voltage relationship of a HfO₂ memristor. This study offered an estimation of the optimal model parameters using a least squares algorithm in SIMULINK and a methodology for adjusting the model by varying its parameters overbroad ranges. The optimal values of the memristor model parameters were obtained after minimizing the error between the experimental and simulated current–voltage characteristics. A comparison of the obtained errors between the simulated and experimental current–voltage relationships was made. The error derived by the optimization algorithm was a little bit lower than that obtained by the used methodology. To avoid convergence problems; the step function in the considered model was replaced by a differentiable tangent hyperbolic function. A PSpice library model of the HfO₂ memristor based on its mathematical model was created. The considered model was successfully applied and tested in a multilayer memristor neural network with bridge memristor–resistor synapses Full article
