Landslides are a major natural hazard capable of causing severe damage to infrastructure, ecosystems, and human life. They result from complex interactions of geological, hydrological, and environmental factors, with soil properties playing a crucial role by influencing the mechanical behavior and moisture dynamics of slope materials that drive initiation and progression. In South Africa, few studies have examined soil influences on landslide susceptibility, and none have been conducted in the Eastern Cape Province. This study investigated the role of soil physical and chemical properties in landslide susceptibility by comparing profiles from landslide scars and stable sites in the Port St. Johns and Lusikisiki region. Samples from topsoil and subsoil horizons were analyzed for soil organic matter (SOM), cation exchange capacity (CEC), saturated hydraulic conductivity (Ksat), exchangeable sodium adsorption ratio (SARexc), and texture. Statistical analyses included the Shapiro–Wilk test to evaluate data normality. For inter-profile comparisons, Welch’s t-test was applied to normally distributed data, while the Mann–Whitney U test was used for non-normal distributions. Intra-profile differences across more than two groups were assessed using the Kruskal–Wallis test for the non-normally distributed data. Results showed that landslide-prone soils had higher SOM, CEC, and Ksat in topsoil, promoting moisture retention and rapid infiltration, which favor pore pressure build-up and slope failure. Non-landslide soils displayed higher sodium-related indices and finer textures, suggesting more uniform water retention and resilience. Vertical variation in landslide soils indicated hydraulic discontinuities, fostering perched saturation zones. Findings highlight landslide initiation as a product of interactions between hydromechanical gradients and chemical dynamics. Full article

This article is devoted to the design of a real-time gain scheduling (adaptive) proportional–integral (PI) controller for the displacement volume regulation of a swash plate-type axial piston pump. The pump is intended for open circuit hydraulic drive applications without “secondary control”. In this type of pump, the displacement volume depends on the swash plate swivel angle. The swash plate is actuated by a hydraulic-driven mechanism. The classical control device is a hydro-mechanical type, which can realize different control laws (by pressure, flow rate, or power). In the present development, it is replaced by an electro-hydraulic proportional spool valve, which controls the swash plate-actuating mechanism. The designed digital gain scheduling controller evaluates control signal values applied to the proportional valve. The digital controller is based on the new linear parameter-varying mathematical model. This model is estimated and validated from experimental data for various loading modes by an identification procedure. The controller is implemented by a rapid prototyping system, and various real-time loading experiments are performed. The obtained results with the gain scheduling PI controller are compared with those obtained by other classical PI controllers. The developed control system achieves appropriate control performance for a wide working mode of the axial piston pump. The comparison analyses of the experimental results showed the advantages of the adaptive PI controller and confirmed the possibility for its implementation in a real-time control system of different types of variable displacement pumps. Full article

The practice of operating hydraulic machines and equipment shows that failures can occur earlier than the specified lifespan. At the same time, at the stage of carrying out strength calculations of the designed machines and equipment, significant safety margins are incorporated into parts and units. That is, calculated machine lifespans often exceed actual values. Accurate data require full-scale lifespan testing or observations of operation. However, resource tests are economically expensive, since they require a significant amount of energy, and, as a result, lead to a negative impact on the environment. It is possible to level out the listed shortcomings during resource tests by using energy-efficient and energy-saving technologies, such as energy recovery. This study enhances energy efficiency and assesses engineering systems during equipment design. In particular, we present a hydromechanical drive design for testing reciprocating hydraulic machines. The study analyzes energy-saving and energy recovery methods during operation. On the basis of the analysis and previously conducted studies, we developed a mathematical model for hydraulic equipment testing. The developed model is based on the volumetric stiffness theory, enabling analysis of the design and functional characteristics of test stand components on their dynamic behavior and energy efficiency. Full article

Rocks with multi-shaped fractures in engineering activities like mining, underground energy storage, and hydropower construction are often exposed to environments where stress and seepage fields interact, which heightens the uncertainty of instability and failure mechanisms. This has long been a long-standing challenge in the field of rock mechanics. Current research mainly focuses on the mechanical behavior, seepage, and energy evolution characteristics of single-fractured rocks under hydro-mechanical coupling. However, studies on the effects of multi-shaped fractures (such as T-shaped fractures, Y-shaped fractures, etc.) on these characteristics under hydro-mechanical coupling are relatively scarce. This study aims to provide new insights into this field by conducting hydro-mechanical coupling tests on multi-shaped fractured sandstones (single fractures, T-shaped fractures, Y-shaped fractures) with different inclination angles. The results show that hydro-mechanical coupling significantly reduces the peak strength, damage stress, crack initiation stress, and closure stress of fractured sandstone. The permeability jump factor (ξ) demonstrates the permeability enhancement effects of different fracture shapes. The ξ values for single fractures, T-shaped fractures, and Y-shaped fractures are all less than 2, indicating that fracture shape has a relatively minor impact on permeability enhancement. Fracture inclination and shape significantly affect the energy storage capacity of the rock mass, and the release of energy exhibits a nonlinear relationship with fracture propagation. An in-depth analysis of energy evolution characteristics under the influence of fracture shape and inclination reveals the transition pattern of the dominant role of energy competition in the progressive failure process. Microstructural analysis of fractured sandstone shows that elastic energy primarily drives fracture propagation and the elastic deformation of grains, while dissipative energy promotes particle fragmentation, grain boundary sliding, and plastic deformation, leading to severe grain breakage. The study provides important theoretical support for understanding the failure mechanisms of multi-shaped fractured sandstone under hydro-mechanical coupling. Full article

Fractures are widely distributed in karst areas, and when flow rates are high, they exhibit complex nonlinear behavior that cannot be accurately described by Darcy’s law. In this work, a hydro-mechanical coupling model based on a discrete fracture network is proposed to predict tunnel water inflow, accounting for the impact of non-Darcy flow. The model’s feasibility has been validated by comparing it with experimental results and the field measurements of flow rates at the Bodaoling Tunnel in Guizhou, China. The results show that Darcy flow tends to overestimate water inflow by approximately 25% compared to non-Darcy flow. The non-Darcy effect grows with the increase in initial fracture width and empirical constant q. When q exceeds 8.77 × 10⁻⁶, the growth rate of the Forchheimer number along the fracture width slowed down, and the inhibitory effect of non-Darcy flow on flow became gentle. Additionally, in a complex fracture network, the inflow rate limited by non-Darcy flow at one point drives the water flow through a connect fracture to another point, which increases the difficulty in water inflow prediction. This work highlights the importance of non-Darcy flow and fracture networks when accurately predicting water inflow in tunnels. Full article

Volumetric hydraulic drive systems are quite widespread in many industrial sectors. To determine the degree of reliability of hydraulic machines, it is necessary to conduct resource tests. The main requirement for such tests is the compliance of the load level with the operating mode of the hydraulic machine. Analysis of existing methods of creating such a load showed a significant drawback of bench tests—the lack of useful work. Therefore, a number of authors suggest the use of stands with a regenerative drive system. One peculiarity of the work of such stands is the possibility of returning part of the spent energy back to the test system. However, such systems are insufficiently studied and have significant drawbacks. The purpose of this work is to increase the efficiency of the regenerative drive system of the test bench of volumetric hydraulic machines of rotational action by improving the theory and methodology of its calculation and design. This article describes the principle of operation of the circuit of the regenerative drive of the test bench of rotary hydraulic machines. A model of the elastic-dissipative state of the sections of the elements of the hydro-mechanical drive system of the stand is also proposed, which allows for the calculation of the structural and energy parameters of the regenerative hydro-mechanical system. The main structural and functional parameters affecting the operational performance of the system as a whole are also identified. A “test efficiency coefficient” is proposed, which allows for evaluation of the energy efficiency of the test process. Full article

MEMS gyroscopes are widely applied in consumer electronics, aerospace, missile guidance, and other fields. Reliable packaging is the foundation for ensuring the survivability and performance of the sensor in harsh environments, but gas leakage models of wafer-level MEMS gyroscopes are rarely reported. This paper proposes a gas leakage model for evaluating the packaging reliability of wafer-level MEMS gyroscopes. Based on thermodynamics and hydromechanics, the relationships between the quality factor, gas molecule number, and a quality factor degradation model are derived. The mechanism of the effect of gas leakage on the quality factor is explored at wafer-level packaging. The experimental results show that the reciprocal of the quality factor is exponentially related to gas leakage time, which is in accordance with the theoretical analysis. The coefficients of determination (R²) are all greater than 0.95 by fitting the curves in Matlab R2022b. The stable values of the quality factor for drive mode and sense mode are predicted to be 6609.4 and 1205.1, respectively, and the average degradation characteristic time is 435.84 h. The gas leakage time is at least eight times the average characteristic time, namely 3486.72 h, before a stable condition is achieved in the packaging chamber of the MEMS gyroscopes. Full article

The aim of this work is to design a power split transmission for an urban street sweeper in order to reduce fuel consumption. The design process starts with the comparison between a hydrostatic and a hydromechanical power split transmission. Both transmissions have been tested through an acceleration test considering 30, 50, 70 and 100 percent of the rated engine power. The results of both models developed in the Simcenter Amesim^TM environment show that the power split transmission presents a higher efficiency, which justifies the adoption of this type of transmission with respect to the hydrostatic system. Then, a pure mechanical gear is added to the base concept of the power split transmission. The mechanical gear is managed by a lockup clutch, which can be engaged during the working phase of the street sweeper, similar to an adaptive cruise control. In this case, both transmissions are tested through a regulated cycle, UNI-EN 151429-2, highlighting the advantage of using a pure mechanical branch. At the end, both transmissions are tested with a driving cycle acquired through an experimental setup consisting of a control unit, a GPS and a tablet for the monitoring of the speed profile. The results show that the adoption of a lockup clutch allows an increase in the system efficiency during the working phase, hence reducing the average fuel consumption during the mission test. Full article

This paper proposes an alternative model for describing the hydro-mechanical drive operation of the automatic transmissions. The study is aimed at preparing a reliable model that meets the requirements of sufficient informativeness and rapidity to, basically, be used as a model for optimized control. The study relevance is stipulated by the need for simple and precise models ensuring minimal computational costs in model predictive control (MPC) procedures. The paper proposes a method for coordinating the engine’s control and operating modes, with the torque converter (TC) operating mode, based on the criteria of angular acceleration derivative (jerk), which fosters including the angular acceleration in the state vector for using the optimal control. The latter provides stronger prediction quality than using only the crankshaft angular speed criterion. This moment comprises a study novelty. Additionally, the proposed approach can be helpful in tasks of powertrain automation, autonomous vehicles’ integrated control, elaboration of control algorithms, co-simulations, and real-time applications. The paper material is structured by the modeling stages, including mathematics and simulations, data preparation, testing and validation, virtual experiments, analysis of results, and conclusions. The essence of the problem, goals, and objectives are first presented, followed by the overview of main approaches in modeling the automatic transmission elements. The internal combustion engine (ICE), torque converter, drivetrain, tires, and translational dynamics mathematical models are determined and discussed in detail. The proposed approach convergence on decomposing the indicators of powertrain aggregates by derivatives is demonstrated. The considered method was simulated by using the data of the Audi A4 Quattro. The gear shifting control algorithm was described in detail, and a series of virtual tests for the composed model were carried out. The comparative analysis of the results for the conventional and advanced models of the automatic transmission’s hydro-mechanical drive were performed. The differences of the model outputs were discussed. The approach advantages were noted, as well as the options for extending the proposed technique. Full article

Vibratory pile diving with resonance-free technique is an advanced construction approach that can play an important part in underground engineering. This paper aims to propose a numerical model for this construction approach, which commonly involves soils below the groundwater table. Such simulations are still challenging tasks as dynamic analyses considering hydro-mechanical interactions are very complicated. Several simulations have been performed by constructing a user-defined element in the finite element code ABAQUS or developing an inhouse finite-element program for this issue. These simulations have some limitations and pay less attention to open-ended piles. This paper presents a way to simulate the vibratory open-ended pile driving in saturated sand using the finite difference code FLAC3D. The model computation efficiency is increased around 67 times by the density scaling method and this method has little effect on the numerical stability. The proposed model can generally replicate the pore pressure results of a model test. The maximum excess pore pressures are predicted with a percent error of 2–22%, and these maximums occur near the pile toe. The excess pore pressure of an observation point slowly decreases after the pile toe passes the point. This work could provide an efficient and effective method for simulating vibratory open-ended pile driving in saturated sand. Full article

Tractors are usually applied in field operations, road transport, and other operations. Modern agriculture has higher design requirements for tractor powertrains due to the complicated working environments and various operations. To meet the driving requirements of the tractor under multiple operations, a mechanic-electronic-hydraulic powertrain system (MEH-PS) for tractors has been designed according to the characteristics of the hydro-mechanical composite transmission and electromechanical hybrid system. The principle of multiple driven and transmission modes of MEH-PS are introduced, the speed regulation characteristic curve of hydro-mechanical transmission (HMT) is given, and the related power element model, tractor model, and efficiency model are established. The HMT optimal economy transmission ratio control strategy and hybrid rule-based optimization energy management strategy were developed. Take three typical tractor operations for analysis: ploughing, harvesting, and transport. The results show that the engine operating points are mainly distributed in the higher load area, the tractor maintains high system efficiency, and the relative error between simulated and tested fuel consumption is within 5%, which further proves the reliability of the model. The solution also showed lower fuel consumption in all three operations compared to DLG’s announced PowerShift tractors and CVT tractors. Thus, the powertrain system can meet the tractor’s drive requirements under complex operating conditions and maintain high efficiency and is therefore suitable for tractors that need to operate frequently in the field and on the road. Full article

It is difficult to describe precisely, and thus control satisfactorily, the dynamics of an electro-hydraulic actuator to drive a high thrust liquid launcher engine, whose structural resonant frequency is usually low due to its heavy inertia and complicated mass distribution, let alone one to drive a heavy kerolox engine with high-order dynamics. By transforming classic control block diagrams, a baseline two-mass-two-spring load model and a normalized actuator-engine system model were developed for understanding the basic physics and methodology, where a fourth-order transfer function is used to model the multi-resonance-frequency engine body outside of the rod position loop, another fourth-order transfer function with two pairs of conjugated zeros and poles to represent the composite hydro-mechanical resonance effect in the closed rod position loop. A sixth-order model was thereafter proposed for even higher dynamics. The model parameters were identified and optimized by a full factor search approach. To meet the stringent specification of static and dynamic performances, it was demonstrated that a notch filter network combined with other controllers is needed since the traditional dynamic pressure feedback (DPF) is difficult to handle the high-order dynamics. The approach has been validated by simulation, experiments and successful flights. The models, analysis, data and insights were elaborated. Full article

It is difficult to describe precisely, and thus control satisfactorily, the dynamics of an electrohydraulic actuator to drive a high thrust liquid launcher engine, whose structural resonant frequency is usually low due to its heavy inertia and its complicated mass distribution. A generalized model is therefore put forward for maximum simplification and sufficient approximation, where a second-order transfer function is used to model the heavy mass-spring nature of the large engine body outside of the rod position loop, another second-order transfer function with two zeros and two poles representing the hydro-mechanical composite resonance effect in the closed rod position loop. A combined control strategy is applied to meet the stringent specification of static and dynamic performances, including a notch filter, a piecewise or nonlinear proportional, integral and differential (PID) controller and a feed-forward compensation. The control algorithm is implemented in digital signal processors with the same software structure but different parameters for different aerospace actuators. Compared to other approaches, this one makes it easier to grasp the system resonance nature, and, most importantly, the traditional dynamic pressure feedback (DPF) is replaced with the convenient digital algorithm, bringing prominent benefits such as a simplified design, reduced hardware cost and inherent higher reliability. The approach has been validated by simulation, experiments and successful flights. Full article

Fuel efficiency has become an increasingly important property of heavy mobile working machines. As a result, Hybrid Hydromechanical Transmissions (HMTs) are often considered for the propulsion of these vehicles. The introduction of hybrid HMTs does, however, come with a number of control-related challenges. To date, a great focus in the literature has been on high-level control aspects, concerning optimal utilization of the energy storage medium. In contrast, the main topic of this article is low-level control, with the focus on dynamic response and the ability to realize requested power flows accurately. A static decoupled Multiple-Input-Multiple-Output (MIMO) control strategy, based on a linear model of a general hybrid HMT, is proposed. The strategy is compared to a baseline approach in Hardware-In-the-Loop (HWIL) simulations of a reference wheel loader for two drive cycles. It was found that an important benefit of the decoupled control approach is that the static error caused by the system’s cross-couplings is minimized without introducing integrating elements. This feature, combined with the strategy’s general nature, motivates its use for multiple-mode transmissions in which the transmission configuration changes between the modes. Full article

To study the dynamic response of saturated asphalt pavement under moving load and temperature load, 3-D finite element models for asphalt pavements with hydro-mechanical coupling and thermal-hydro-mechanical coupling were built based on the porous media theory and Biot theory. First, the asphalt pavement structure was considered as an ideal saturated fluid–solid biphasic porous medium. Following this, the spatial distribution and the change law of the pore-water pressure with time, the transverse stress, and the vertical displacement response of the asphalt pavement under different speeds, loading times, and temperatures were investigated. The simulation results show that both the curves of the effective stress and the pore-water pressure versus the external loads have similar patterns. The damage of the asphalt membrane is mainly caused by the cyclic effect of positive and negative pore-water pressure. Moreover, the peak value of pore-water pressure is affected by the loading rate and the loading time, and both have positive exponential effects on the pore-water pressure. In addition, the transverse stress of the upper layer pavement is deeply affected by the temperature load, which is more likely to cause as transverse crack in the pavement, resulting in the formation of temperature cracks on the road surface. The vertical stress at the middle point in the upper layer of the saturated asphalt pavement, under the action of the temperature load and the driving load, shows a single peak. Full article
