Search Results (26)

Due to their high damping and the associated low dynamic excitation of the machine tool, hydrodynamic guideways are necessary for precision machines such as grinding machines. This article summarizes the development of the measuring system that was integrated into the guiding rail of a linear hydrodynamic bearing and presents the experimental evaluation. The measuring system is aimed at providing a better understanding of the actual transient hydrodynamic pressure and lubrication condition during the reversing sliding motion in the liquid friction range. The system was checked for its frequency response to ensure that the expected pressure rise during the stroke motion can be measured both in relation to the rail width and to the point. The evaluation is based on Reynolds’ analytical hydrodynamic theory, as numerical calculation approaches themselves are also subject to considerable uncertainties, particularly with regard to the actual geometry of the lubrication gap. The novelty of the results lies in the possibility of analyzing the instationary behavior of a reversing linear bearing of a carriage in machine tools at very low pressures as a quasi-2D and 3D pressure curve. Finally, the new possibilities are demonstrated by analyzing the behavior of a carriage with concave sliding surfaces. Full article

To investigate the heat-generation mechanisms of journal bearings under different whirl motion and to clarify the corresponding temperature distribution characteristics, a computational fluid dynamics-based method was developed. The model incorporates temperature-dependent lubricant viscosity and employs an unsteady dynamic-mesh updating approach based on structured grids, enabling the automatic iterative tracking of the journal center during whirl motion. A thermal-effect analysis model that accounts for journal whirl trajectories was thereby established. The whirl orbit shape is characterized using elliptical eccentricity, and the effects of whirl direction, elliptical eccentricity, and whirl frequency on the circumferential temperature and pressure distributions of the journal are examined. Results show that under forward whirl, increasing whirl frequency and elliptical eccentricity initially enhances and then weakens local hydrodynamic pressure and viscous shear dissipation in the oil-film convergent region, producing pronounced first-order circumferential temperature nonuniformity and a high risk of thermal bending at intermediate frequencies. Under backward whirl, hydrodynamic effects are reduced and heat generation shifts from localized concentration to global shear dissipation, forming a relatively uniform second-order circumferential temperature field. Increasing elliptical eccentricity causes the whirl orbit to become more linear, improving load-carrying capacity and heat-transfer performance and thereby mitigating thermally induced vibration and oil-film whirl instability. Full article

Nonlinear vibration phenomena, such as oil whirl and oil whip, are common indicators of oil film instability in hydrodynamic bearings and are key signs of potential faults in rotating machinery. Excessive vibrations caused by oil film instability can accelerate bearing wear and lead to the failure of the rotating system. This paper presents a model for nonlinear dynamic coefficients, aimed at providing a quantitative approach for monitoring and predicting oil film instability. The impact of operational parameters and perturbation values on both linear and nonlinear stiffness and damping coefficients is investigated. Simulation results and experimental rotor vibration signals demonstrate that the nonlinear dynamic coefficient model effectively characterizes oil film instability and accurately predicts rotor trajectory, while traditional linear models are only applicable under low-speed and small-disturbance conditions. Compared to traditional analytical models and numerical solutions, the nonlinear dynamic coefficients have higher accuracy and efficiency and can reliably identify the onset frequency of oil film instability. This study clarifies the relationship between nonlinear dynamic coefficients and rotor dynamic response, laying a theoretical foundation for the monitoring and prediction of oil film instability. Full article

Using the Rabinowitsch fluid model, the effects of dilatant fluids (a non-Newtonian factor less than 0) and pseudo-plastic fluids (a non-Newtonian factor greater than 0) on the non-linear stability of hydrodynamic journal bearings is discussed. The modified Reynolds equation is solved by the small perturbation method, and the stiffness and damping coefficients and threshold speed of hydrodynamic bearings are obtained. Through the fourth-order Runge–Kutta method, the trajectory of the journal center is traced and the non-linear stability boundary of hydrodynamic bearings with different non-Newtonian lubricants could be confirmed. The results show that the dilatant fluids could increase the threshold speed and enlarge the non-linear stability region of the hydrodynamic bearing, while the influence of pseudo-plastic fluids is positive. And for the lubricants with a larger non-Newtonian factor, the effect is more obvious. It could be confirmed that the stability of hydrodynamic bearings lubricated with dilatant fluids is better than that of bearings with Newtonian and pseudo-plastic lubricants. The results illustrate that selecting a more appropriate lubricant can enhance the stability of hydrodynamic bearings. Full article

This paper presents an analysis of the dynamic characteristics observed and studied during the startup process of a gas foil radial bearing. It utilizes a comparison of both experimental data and three-dimensional fluid–solid interaction computational fluid dynamics simulations to investigate a gas foil bearing with three bump-type pads. The analytical model employs the fluid–structure interaction finite element method to examine the relationship between the components and the thin working fluid film within the bearing. This analysis was conducted under various operational conditions, including ambient pressure and temperature, shaft rotational speed, and the load applied to the shaft within the bearing. The foil structure of the bearing was modeled by representing the top and bump foils as a series of linear springs that are interconnected with the rigid housing. Meanwhile, the hydrodynamic pressure distribution acting on the top foil was modeled as a gas film operating under steady-state lubrication conditions. The comprehensive three-dimensional multi-physics model was developed using a commercial computer-aided engineering package, enabling independent finite element calculations for both fluid and solid domains. Following these calculations, the model exchanged analysis results across the interface between domains, allowing simulations to continue until the system achieved a quasi-steady state. An in-house experimental system was designed to evaluate the performance of the gas foil bearing under different working conditions, including the load applied to the shaft and the rotational speed. The experiment investigated the operational state of a gas foil radial bearing under ambient pressure (1 bar), ambient temperature (303 K), rotational speeds ranging from 1.5 to 9.5 krpm, and a load of 0.5602 kgw. Some operational conditions of the bearing were defined as boundary condition inputs for the simulation model. The model’s results, notably the predicted lift-off rotational speed of the bearing, show strong alignment with results from in-house experiments. Full article

A pump-turbine may generate high-amplitude hydraulic excitations during operation, wherein the flow-induced response of the spiral case and concrete is a key factor affecting the stable and safe operation of the unit. The preloading spiral case can enhance the combined bearing capacity of the entire structure, yet there is still limited research on the impact of the preloading pressure on the hydrodynamic response. In this study, the pressure fluctuation characteristics and dynamic behaviors of preloading a steel spiral case and concrete under different preloading pressures at rated operating conditions are analyzed based on fluid–structure interaction theory and contact model. The results show that the dominant frequency of pressure fluctuations in the spiral case is 15 $f_n$, which is influenced by the rotor–stator interaction with a runner rotation of short and long blades. Under preloading pressures of 0.5, 0.7, and 1 times the maximum static head, higher preloading pressures reduce the contact regions, leading to uneven deformation and stress distributions with a near-positive linear correlation. The maximum deformation of the PSSC can reach 2.6 mm, and the stress is within the allowable range. The preloading pressure has little effect on the dominant frequency of the dynamic behaviors in the spiral case (15 $f_n$), but both the maximum and amplitudes of deformation and stress increase with higher preloading pressure. The high-amplitude regions of deformation and stress along the axial direction are located near the nose vane, with maximum values of 0.003 mm and 0.082 MPa, respectively. The contact of concrete is at risk of stress concentrations and cracking under high preloading pressure. The results can provide references for optimizing the structural design and the selection of preloading pressure, which improves operation reliability. Full article

Electrical conductimetry and dynamic light scattering (DLS) were used to investigate the aggregation behaviors of four amino acid-based surfactants (AABSs; undecanoyl-glycine, undecanoyl-l-alanine, undecanoyl-l-valine, undecanoyl-l-leucine) in the presence of five linear diamine counterions (1,2-diaminoethane, 1,3-diaminopropane, 1,4-diaminobutane, 1,5-diaminopentane, 1,6-diaminohexane). Electrical conductimetry was used to measure the CMCs for each system, which ranged from 5.1 to 22.5 mM. With respect to counterions, the obtained CMCs decreased with increases in the interamine spacer length; this was attributed to the improved torsional binding flexibility in longer counterions. Strong linear correlations (mean R² = 0.9443) were observed between the CMCs and predicted surfactant partition coefficients (logP; water/octanol), suggesting that micellization is primarily driven by the AABS’s hydrophobicity for these systems. However, significant deviations in this linear relationship were observed for systems containing 1,2-diaminoethane, 1,4-diaminobutane, and 1,6-diaminohexane (p = 0.0774), suggesting altered binding dynamics for these counterions. pH measurements during the CMC determination experiments indicated the full deprotonation of the AABSs but did not give clear insights into the counterion protonation states, thus yielding an inconclusive evaluation of their charge stabilization effects during binding. However, DLS measurements revealed that the micellar size remained largely independent of the counterion length for counterions longer than 1,2-diaminoethane, with hydrodynamic diameters ranging from 2.2 to 2.8 nm. This was explained by the formation of charge-stabilized noncovalent dimers, with each counterion bearing a full +2 charge. Conductimetry-based estimates of the degrees of counterion binding (β) and free energies of micellization (ΔG°_M) revealed that bulky AABSs exhibit preferential binding to counterions with an even number of methylene groups. It is proposed that when these counterions form noncovalent dimers, perturbations in their natural geometries result in the formation of a binding pocket that accommodates the AABS steric bulk. While the direct application of these systems remains to be seen, this study provides valuable insights into the structure–property relationships that govern AABS aggregation. Full article

Rotating machines are an important part of industrial equipment. It is essential to improve their performance while reducing the manufacturing, operating, and maintenance costs. Ensuring their reliability is also crucial because a machine breakdown can result in significant costs and potential environmental and safety damage. Reliability-based optimization is an approach that aims to find an optimal and robust design that guarantees a machine’s reliability. In this study, we focused on optimizing the shaft diameter and oil temperature of a rotor supported by hydrodynamic bearings. We considered the materials’ elastic moduli, density, and bearing clearance as uncertain parameters. Our goal was to ensure 99% reliability regarding both the vibration amplitude and stability threshold. To model the machine, we used the finite element method and represented the bearings using stiffness and damping coefficients, considering the linear short bearing model. Due to the complexity of the model, we employed surrogate models to solve the reliability-based optimization problem. Our results showed that the optimization problem could be solved successfully using Kriging, polynomial chaos expansion, and polynomial chaos Kriging. Full article

Fretting fatigue is a well-known and dangerous damage mode that occurs on the mating surfaces of mechanical components, mainly promoted by a combination of stress distribution, contact pressure distribution, and relative sliding (micro)motion between the surfaces. However, predicting this mechanism is challenging, necessitating specific studies for each assembly due to variable influences. This article presents a methodology for evaluating fretting fatigue damage at the contact between a titanium connecting rod big end and the bearing, adopting the Ruiz parameter as a quantifying damage index. For this purpose, a thermal-structural finite element model is prepared. In particular, the machining and assembly of the split conrod big end are simulated, considering thermal effects. A full engine cycle is first simulated, and results are used for identifying critical instants to be considered for accurate yet computationally efficient calculations. The dependence of fretting fatigue on three factors is studied: bearing crush, bolts tightening torque, and friction coefficient between the big end and the bearing. In summary, the damage increases with a higher crush and friction, while tightening torque has marginal effects. Following a 20% increase in crush height, a corresponding 10% rise in the Ruiz parameter is observed. Conversely, reducing the crush height by 20% leads to an approximately 8% decrease in the Ruiz parameter. When the influence of the bolt preload is taken into account, only a marginal 1% increase of the Ruiz parameter is recorded despite a 30% rise in preload. Evaluating the impact of the friction coefficient on the Ruiz parameter reveals an almost linear relationship. These findings suggest that adjusting the screw preload can enhance the hydrodynamic behavior of the bearing without exacerbating fretting. Furthermore, exploiting the linear correlation between Ruiz and the friction coefficient allows for the generalization of results obtained with specific coefficient values. This methodology can, therefore, serve as a valuable reference for adjusting different variables during the initial design phases of a four-stroke internal combustion engine’s dismountable connecting rod. Full article

Ocean waves contain the highest energy density among renewable energy sources. However, harnessing the energy from ocean waves represents a challenge because wave energy converters (WECs) must be designed to have great survivability and efficiency. The power production challenge of any WEC depends on the power take-off (PTO) system efficiency. Maximum power point tracking (MPPT) algorithms have been widely applied in renewable energy from photovoltaic and wind sources, and have subsequently been adapted to wave energy converters (WECs). Energy extraction is optimized by applying MPPT, resulting in an increase in efficiency. This study aims to address the analysis of the influence of the perturb and observe MPPT in the electrical power performance of a WEC composed of a point absorber, a hinged arm and a direct mechanical drive PTO system. The PTO is characterized by a pulley system, a counterweight, one-way bearings, a gearbox, a flywheel and an electric generator; in the present study it is considered to be a cylindrical point absorber. The linear theory and the viscous damping effect are applied to analyze the hydrodynamic behavior of the point absorber. Regarding the two generators considered in the present study, the contribution of MPPT is greater for the low power generator; the high values of the capture width ratio (CWR) occur at low values of period and wave height, showing the maximum value in the high-power generator. Full article

Wear is one of the most common failures of hydrodynamic bearings. The main purpose of the present work was to investigate the effects of wear on lubrication performance and acquire efficient vibration signatures for fault diagnosis. In this paper, a finite element model (FEM) for a two-disk rotor supported on worn hydrodynamic bearings is presented in which the oil film force is evaluated by linear and nonlinear models. Numerical and experimental results indicate that the static and dynamic characteristics of the bearing are significantly changed by wear, leading to a drop in system critical speeds due to the deterioration of the constraint status provided by the bearings to the rotor. As the wear depth increases, the onset speed of oil whirl increases, while that of oil whip becomes lower, and large amplitudes of resonance and oil whip are more likely to be excited. More notably, all of the above vibration signatures in the y-direction are more sensitive to wear compared to those in the x-direction, which means that wear faults can be diagnosed by differences in vibration characteristics between the x- and y-directions. This research can provide a theoretical foundation and engineering guidance for the hydrodynamic bearing wear fault diagnosis. Full article

Journal bearings in typical applications are subjected to misalignment due to several causes, such as shaft deformation under load and errors related to the installation and manufacturing processes. Misalignment has well-known severe negative consequences on the performance of the bearings. This paper deals with the bearing chamfer to reduce these consequences of misalignment, and two forms of bearing edge modification are considered in the analysis. These forms are linear and curved chamfering of the bearing edges, where the height of the chamfer in the circumferential direction and the length of the modification in the longitudinal direction are considered as geometrical design parameters. The investigation includes a numerical solution of the hydrodynamic lubrication problem of finite length journal bearing, considering 3D misalignment cases using the finite difference method. This includes the assessment of the chamfer forms and their effects on the bearing performance in terms of the main bearing design parameters. Furthermore, the stability of the chamfered bearings is also investigated under impact load. Results showed that both chamfer forms are beneficial for a certain limit of the design parameters in reducing the maximum pressure and coefficient of friction and in elevating the film thickness levels, extending the range of misalignment in which the journal bearing can operate safely. In addition, the chamfered bearings in both forms showed more stability range in terms of the critical speed and shaft center trajectories under impact load. The bearings with the curved chamfer, where the slope is continuous at the start of modification, showed more uniform film thickness levels, and their shaft center trajectories were closer to the perfectly aligned bearing in the stable operating range of the system. Full article

In the working process of the gas bearings, the unbalanced force of the rotor will increase nonlinearly with the increase in the rotating speed, resulting in an increase in the rotor’s vibration amplitude. On the other hand, with the increase in the rotating speed, the hydrodynamic effect will increase, and the nonlinear increase in the gas film force and stiffness will inhibit the increase in the vibration amplitude. In order to deeply study the influence of the unbalanced force and nonlinear gas film force on the vibration amplitude of the ultra-precision aerostatic motorized spindle, taking the double slit throttling gas bearing as an example, according to the equilibrium equation of the rotor under the combined action of gravity, the gas film force, and the unbalanced force, a calculation program based on the finite difference method for solving the rotor’s equilibrium position is completed. The calculation results show that: the hydrodynamic effect can significantly increase the bearing capacity and cause the change of the static equilibrium position of the rotor, but the offset amplitude of the static equilibrium position of the rotor gradually slows down with the increase in the rotating speed. The hydrodynamic effect improves the stiffness near the static equilibrium position of the rotor, making the rotor vibration track tend to be more “round”. Although the unbalanced force of the rotor increases nonlinearly as the rotating speed increases, the maximum offset between the dynamic equilibrium position and the static equilibrium position of the rotor under the action of the rotating unbalanced force is approximately linear with the rotating speed. Compared with the air supply pressure, the rotor unbalance and rotating speed are the main factors affecting the rotor dynamic equilibrium position offset. This study has a reference role in the in-depth study of the influence of rotating speed and rotor unbalance on the rotor static equilibrium position and dynamic equilibrium position offset, as well as in the design of gas bearings and the prediction of rotor vibration amplitude. Full article

This paper presents a method to simulate the dynamic operating characteristics of a gas foil thrust bearing based on linear elastic support and constant ambient temperature to mimic the transient structure–fluid interactions. In the physical model, the top and bump foils are simply represented by an infinite number of Hookean springs attached to a solid wall with a small amount of deformation, whereas the gas film in the bearing is under quasi-steady lubrication flow conditions with hydrodynamic pressure distributed on the little-deformed top foil. A three-dimensional multi-physics model in a cylindrical coordinate system is established via a commercial computer-aided engineering software package to predict the nominal dynamic characteristics of the gas foil thrust bearing. To verify the multi-physics model, an experimental bench was built in-house to measure the thrust force on the support of the bearing. With the pertinent bearing parameters being entered into the package, the simulations agree well with the experimental thrust forces. As a further step, a simulation model of a clamped-rotor gas foil thrust bearing design was thoroughly investigated under nominal operating conditions, resulting in predictions of underdamped oscillations in rotor motions. The phenomenon could be described using a linear mass–spring–damper model that is dependent on the gas film thickness. The stiffness and damping coefficients could serve as a base reference for rotor dynamics analysis. This concludes the potential development of a digital twin for gas foil thrust bearing systems. Full article

The water-lubricated tilting pad thrust bearings (WTTBs) of the reactor coolant main pump and high-power RDT operate at a large linear velocity, heavy load, and low viscosity. On the basis of the performance prediction of WTTBs in the mixing flow pattern, a hypothesis of the regional flow pattern is proposed. To compare the lubrication performance under four kinds of flow pattern modes, a thermo-elasto-hydrodynamic lubrication model of the WTTB considering the flow pattern is established, and a partition iteration algorithm for the mixing flow pattern is provided. Moreover, a method for controlling the flow pattern by changing the pad surface morphology is proposed. A simulation is used to indicate that the bearing performance under the mixing flow pattern calculated by the regional flow pattern mode is between that of the laminar and turbulent flows. The regional mixing flow pattern mode can automatically retrogress to the single flow pattern mode by changing the operation conditions. Both the circumferential bulge and radial concave pad surfaces are beneficial for increasing the turbulent area and thereby improving the load-carrying capacity of the WTTB. Full article
