With China’s high-speed rail network undergoing rapid expansion, turnouts constitute critical elements whose safety and stability are essential to railway operation. At present, the efficiency of wheel–rail force safety monitoring conducted in the small hours reserved for the construction and maintenance of operating lines without marking train operation lines is relatively low. To enhance the efficiency of turnout safety monitoring, in this study, a three-dimensional BIM model of the No. 42 turnout was established and a corresponding wheel–rail force monitoring scheme was devised. Collision detection for monitoring equipment placement and construction process simulation was conducted using Navisworks, such that the rationality of cable routing and the precision of construction sequence alignment were improved. A train wheel–rail force analysis program was developed in MATLAB R2022b to perform signal filtering, and static calibration was applied to calculate key safety evaluation indices—namely, the coefficient of derailment and the rate of wheel load reduction—which were subsequently analyzed. The safety of the No. 42 turnout and the effectiveness of the proposed monitoring scheme were validated, theoretical support was provided for train operational safety and turnout maintenance, and technical guidance was offered for whole-life-cycle management and green, sustainable development of railway infrastructure. Full article

To lighten the workload of train drivers and enhance railway transportation safety, a novel and intelligent method for railway turnout identification is investigated based on semantic segmentation. More specifically, a railway turnout scene perception (RTSP) dataset is constructed and annotated manually in this paper, wherein the innovative concept of side rails is introduced as part of the labeling process. After that, based on the work of Deeplabv3+, combined with a lightweight design and an attention mechanism, a railway turnout identification network (RTINet) is proposed. Firstly, in consideration of the need for rapid response in the deployment of the identification model on high-speed trains, this paper selects the MobileNetV2 network, renowned for its suitability for lightweight deployment, as the backbone of the RTINet model. Secondly, to reduce the computational load of the model while ensuring accuracy, depth-separable convolutions are employed to replace the standard convolutions within the network architecture. Thirdly, the bottleneck attention module (BAM) is integrated into the model to enhance position and feature information perception, bolster the robustness and quality of the segmentation masks generated, and ensure that the outcomes are characterized by precision and reliability. Finally, to address the issue of foreground and background imbalance in turnout recognition, the Dice loss function is incorporated into the network training procedure. Both the quantitative and qualitative experimental results demonstrate that the proposed method is feasible for railway turnout identification, and it outperformed the compared baseline models. In particular, the RTINet was able to achieve a remarkable mIoU of 85.94%, coupled with an inference speed of 78 fps on the customized dataset. Furthermore, the effectiveness of each optimized component of the proposed RTINet is verified by an additional ablation study. Full article

The incompleteness of the existing knowledge graphs in the railway domain creates information gaps, impacting their quality and effectiveness in the operation and maintenance of high-speed railway turnout switch machines. To address this, we propose a multi-layer model (KBGC) that combines KG-BERT, graph attention network (GAT), and Convolutional Embedding Network (ConvE) for knowledge graph completion in railway maintenance. KG-BERT fine-tunes a pre-trained BERT model to extract deep semantic features from entities and relationships, converting them into graph structures. GAT captures key structural relationships between nodes using an attention mechanism, producing enriched semantic and structural embeddings. Finally, ConvE reshapes and convolves these embeddings to learn complex entity interactions, enabling accurate link prediction. Extensive experiments on the HRTOM dataset, containing triplet data from high-speed railway turnout switch machines, demonstrate the model’s effectiveness, achieving an MRR of 50.8% and a Hits@10 of 60.7%. These findings show that the KBGC model significantly improves knowledge graph completion, aiding railway maintenance personnel in decision making and preventive maintenance, and providing new tools for railway maintenance applications. Full article

The fault diagnosis of a switch machine is vital for high-speed railway operations because switch machines play an important role in the safe operation of high-speed railways, which often have faults because of their complicated working conditions. To improve the accuracy of turnout fault diagnosis for high-speed railways and prevent accidents from occurring, a combination of bi-directional long short-term memory (BiLSTM) with the multiple learning classification based on associations (MLCBA) model using the operation and maintenance text data of switch machines is proposed in this research. Due to the small probability of faults for a switch machine, it is difficult to form a diagnosis with the small amount of sample data, and more fault text features can be extracted with feedforward in a BiLSTM model. Then, the high-quality rules of the text data can be acquired by replacing the SoftMax classification with MLCBA in the output of the BiLSTM model. In this way, the identification of switch machine faults in a high-speed railway can be realized, and the experimental results show that the Accuracy and Recall of the fault diagnosis can reach 95.66% and 96.29%, respectively, as shown in the analysis of the ZYJ7 turnout fault text data of a Chinese railway bureau from five recent years. Therefore, the combined BiLSTM and MLCBA model can not only realize the accurate diagnosis of small-probability turnout faults but can also prevent high-speed railway accidents from occurring and ensure the safe operation of high-speed railways. Full article

Turnouts are the weak spot in high-speed rail systems, and it is simple for the phenomenon of the wheel–rail force and the carbody lateral acceleration over-limit to arise when the train passes through, which affects the service life of the rail and the running stability of the train. In this paper, the turnout with wheel–rail force over-limit and carbody lateral acceleration over-limit is selected for analysis, and the profiles of the wheel and rail are monitored. Then, the vehicle–turnout coupled multi-body dynamics model is simulated. Additionally, the portable vibration analyzer, the comprehensive inspection train, and the wheel–rail contact dynamic stress tester monitors the data and evaluates the impact of rail grinding on high-speed railway. The results of this study demonstrated that the turnout profiles are in good agreement with the standard wheel profiles following grinding, and the wheel–rail contact point and equivalent conicity both improved. When the train passes the ground turnout at high speed with and without the wheel polygonal wear, the wheel–rail force and the carbody acceleration were clearly improved. Using the wheel–rail contact dynamic stress tester, the comprehensive inspection train, and the portable vibration analyzer monitoring the changes in the carbody acceleration, the wheel–rail force and the carbody acceleration are definitely better after grinding. Similar to the pattern in the simulation, the train’s running steadiness increased by grinding. Full article

With the development of high-speed and heavy-haul railway transportation, the surface failure of rail turnouts has become increasingly severe due to insufficient high hardness-toughness combination. In this work, in situ bainite steel matrix composites with WC primary reinforcement were fabricated via direct laser deposition (DLD). With the increased primary reinforcement content, the adaptive adjustments of the matrix microstructure and in situ reinforcement were obtained at the same time. Furthermore, the dependence of the adaptive adjustment of the composite microstructure on the composites’ balance of hardness and impact toughness was evaluated. During DLD, the laser induces an interaction among the primary composite powders, which leads to obvious changes in the phase composition and morphology of the composites. With the increased WC primary reinforcement content, the dominant sheaves of the lath-like bainite and the few island-like retained austenite are changed into needle-like lower bainite and plenty of block-like retained austenite in the matrix, and the final reinforcement of Fe₃W₃C and WC is obtained. In addition, with the increased primary reinforcement content, the microhardness of the bainite steel matrix composites increases remarkably, but the impact toughness decreases. However, compared with conventional metal matrix composites, the in situ bainite steel matrix composites manufactured via DLD possess a much better hardness-toughness balance, which can be attributed to the adaptive adjustment of the matrix microstructure. This work provides a new insight into obtaining new materials with a good combination of hardness and toughness. Full article

Based on the research and development demand of the 400 km/h high-speed turnout, a new type of elastic iron tie plate based on stiffness optimization is proposed. The new elastic iron tie plate is expected to reduce the stiffness unevenness and effectively solve the problems in the use of existing elastic iron tie plates. However, the new plate uses rubber bosses instead of rubber washers. There are certain differences in the force transmission mechanism from the original tie plate because of the change in structure of the new tie plate. In this paper, a series of experiments are designed to quantitatively compare and analyze the overall stiffness characteristics of different tie-plate structures and the differences in bolt force transmission and distribution laws. The main conclusions are as follows. The laws of vertical load transfer and distribution in the new tie plate are remarkably different from those for the original tie plate because of the differences in their structures. Under the rated bolt torque, the force transferred to the upper surface of the tie plate through the rubber boss in the new tie plate is less than that in the original tie-plate structure by 5.18 kN in the assembled state. Further, the new structure also has lower tie plate precompression; hence, the influence on the stiffness characteristics of the tie plate is less than that in the original structure. However, the steel sleeve deflection in the new tie plate is greater than that in the original tie plate; that is, a larger proportion of the bolt preload force is borne by the steel sleeve, thus making the vulcanized rubber under the steel sleeve more vulnerable to shear damage. If put into actual use, the tie plate bolt torque will be somewhat different from the rated torque; because of the difference in the torques coupled with the different vertical load transfer mechanisms between the new and the original tie-plate structures, the precompression and the proportion of the bolt preload force borne by the steel sleeves of the two tie plates will also show different degrees of deviation corresponding to different deviations of the tie plate bolt torque. Therefore, the new tie plate structure needs to be further optimized to make the transfer mechanism of preload force of bolt as consistent with the original tie plate as possible. In addition, the vibration and deformation characteristics and long-term service performance of the new type of plate under the condition of vehicle passing will be studied through a small-scale field trial and systematic dynamic tests. Full article

A turnout switch machine is key equipment in a railway, and its fault condition has an enormous impact on the safety of train operation. Electrohydraulic switch machines are increasingly used in high-speed railways, and how to extract effective fault features from their working condition monitoring signal is a difficult problem. This paper focuses on the sectionalized feature extraction method of the oil pressure signal of the electrohydraulic switch machine and realizes the fault detection of the switch machine based on this method. First, the oil pressure signal is divided into three stages according to the working principle and action process of the switch machine, and multiple features of each stage are extracted. Then the max-relevance and min-redundancy (mRMR) algorithm is applied to select the effective features. Finally, the mini batch k-means method is used to achieve unsupervised fault diagnosis. Through experimental verification, this method can not only derive the best sectionalization mode and feature types of the oil pressure signal, but also achieve the fault diagnosis and the prediction of the status of the electrohydraulic switch machine. Full article

The article presents a few issues related to the technical condition of a railway turnout, an important element of the railway network where about 90% of railway accidents occur. In the first part of the article, the results of railway turnout wear are presented. A comparison of normal forces (in wheel–rail contact) in vehicle traffic on straight track without a turnout and normal forces occurring when a rail vehicle passes a turnout is presented. Then, turnout wear processes for selected speeds are presented. In the next part of the paper, the possibilities of using a vision system are presented, which, in combination with tools for image processing analysis, makes it possible to detect wear and distances between the key elements of a railway turnout. The main idea of the proposed online diagnostic system solution is to use the analysis of received images (photos) with the help of a vision system. The basic problem to be solved in the proposed system was to develop algorithms responsible for generating wear areas from high-resolution images. The algorithms created within the work were implemented and tested in the MATLAB software environment. The presented method is an original procedure for diagnosing turnout elements for each time instant. The proposed system is compatible with railway traffic control systems. Full article

Cracks could attenuate the service life of concrete structures because of the intrusion of hazardous substances such as water. In this study, different proportions of Duras S500 fibre were employed to investigate the self-sealing capacity of environmentally friendly, highly damped, fibre-reinforced concrete (EFHDFRC) containing 5% crumb rubber. The workability of EFHDFRC with different proportions of the fibre was investigated by mechanical properties test. The self-sealing capacity was first measured by introducing the ultrasonic pulse velocity (UPV) test combined with the damage degree in a time-dependent manner. In addition, the regained compressive strength test and visual inspection were applied as additional measures of the self-sealing capacity. The experimental results show that EFHDFRC with different proportions of fibre showed the maximum sealing degree between the 42nd and 51st days after casting the concrete. EFHDFRC with 0.1% fibre had the best performance and the maximum self-sealing degree (2.82%). In summary, it has been proven that 0.1% fibre could stimulate the self-sealing capacity of EFHDFRC by bridging cracked concrete. Moreover, it is noted that sufficient space in cracks is essential for precipitation formation, which could seal the cracks. The new insights of this innovative self-healing, high-damping material are essential for industrial applications exposed to dynamic load conditions such as railway turnout bearers and sleepers, highspeed rail track slabs, blast-resistant walls and columns, and so on. Full article

Railway switch and crossing (S&C) systems have a very complex structure that requires not only a large number of components (such as rails, check rails, switches, crossings, turnout bearers, slide chair, etc.) but also different types of components and technologies (mechanical devices to operate switches, electrical and/or electronic devices for control, etc.). This complexity of railway S&C systems makes them vulnerable to failures and malfunctions that can ultimately cause delays and even fatal accidents. Thus, it is crucial to develop suitable condition monitoring techniques to deal with fault detection and diagnosis (FDD) in railway S&C systems. The main contribution of this paper is to present a comprehensive review of the existing FDD techniques for railway S&C systems. The aim is to overview the state of the art in rail S&C and in doing so to provide a platform for researchers, railway operators, and experts to research, develop and adopt the best methods for their applications; thereby helping ensure the rapid evolution of monitoring and fault detection in the railway industry at a time of the increased interest in condition based maintenance and the use of high-speed trains on the rail network. Full article

A railway turnout is an essential infrastructure for managing railway traffic flexibility. In contrast, it imposes restrictions on train operations such as lower operational speeds through the turnout due to the complex movements of trains over the turnout. This results in the large-amplitude dynamic responses of the train-turnout interaction. Previous studies have focused on the train-turnout interactions entailing the wheel-rail contact forces and stresses. Very few of the studies considered the effects of the contact forces on the turnout structure and its components such as sleepers and bearers. Those previous studies neglected the dynamic forces and estimated the behavior of train-turnout interactions based on quasi-static calculations. In reality, turnouts are subjected to high impact forces, which can be higher than the permissible track forces. Consequently, a numerical model capable of determining impact forces was developed here, to evaluate the dynamic behaviors of a railway turnout and their effects on such turnout components as bearers, ballast, and so on. The model consists of a structured beam grillage laying on an elastic foundation with rigid wheelsets and a bogie. The model was verified by field measurements. The new insight stemmed from this study shows that neglecting the contribution of dynamic forces can result in the unsafe underestimation of train turnout behaviors. Full article

Development of railway infrastructure at the turn of the 20th and 21st centuries, as well as the speeds of trains in passenger and freight traffic are the result of improving the structure of modern rail vehicles and railway infrastructure optimization. The structure of the railway surface, which enables high speeds and transferring ever greater loads and pressures of up to 25–30 t/vehicle axis, must meet very strict strength and durability requirements. This paper discusses mathematical and numerical tools used in simulation and experimental tests of railway surfaces, as well as its selected elements. Issues addressed in this paper concern, among others, modeling of the railway track, calculations related to its static and dynamic loading, and simulation of the technological process of selected elements of railway turnout. Selected results of the simulation tests on numerical models showing their behavior under different loads are also presented in this paper. The concept of symmetry is included in the possibility of applying the method described in the article both for testing other sections of railway lines, as well as for testing other elements in which stresses occur. Full article
