Search Results (33)

With the enhancement of thermodynamic cycle parameters and heat dissipation constraints in aero-engines, effective thermal management has become a critical challenge to ensure safe and stable engine operation. This study developed a transient temperature evaluation model applicable to the entire flight envelope, considering fluid–solid coupling heat transfer on both the main flow path and fuel systems. Firstly, the impact of heat transfer on the acceleration and deceleration performance of a low-bypass-ratio turbofan engine was analyzed. The results indicate that, compared to the conventional adiabatic model, the improved model predicts metal components absorb 4.5% of the total combustor energy during cold-state acceleration, leading to a maximum reduction of 1.42 kN in net thrust and an increase in specific fuel consumption by 1.18 g/(kN·s). Subsequently, a systematic evaluation of engine thermal management performance throughout the complete flight mission was conducted, revealing the limitations of the existing thermal management design and proposing targeted optimization strategies, including employing Cooled Cooling Air technology to improve high-pressure turbine blade cooling efficiency, dynamically adjusting low-pressure turbine bleed air to minimize unnecessary losses, optimizing fuel heat sink utilization for enhanced cooling performance, and replacing mechanical pumps with motor pumps for precise fuel supply control. Full article

High-precision and real-time modeling are crucial for accelerating the research cycle of next-generation aero-engines. The volumetric dynamics method is acknowledged as the most accurate approach to capture the engine’s transition state process. Nevertheless, the traditional volumetric method encounters challenges, such as neglecting static pressure equilibrium within the mixer and complexities in ascertaining the component volume size when the dynamic simulation time step varies. To address these issues, an improved volumetric dynamics modeling method featuring pressure ratio collaborative updating and the adaptive virtual volume method has been proposed, and a real-time component-level model of a variable cycle engine is established based on this method. The pressure ratio collaborative updating method dynamically updates the pressure ratio of rotating components by inversely calculating the internal and external bypass pressure of the mixer according to static pressure equilibrium constraints and the momentum conservation principle. The adaptive virtual volume method determines the optimal virtual volume size using the particle swarm optimization algorithm, with cosine similarity serving as the evaluation metric. The simulation results indicate that the model based on an improved volumetric dynamics method achieves high accuracy and superior real-time performance. Moreover, compared to traditional modeling methods, the co-operating line of the improved volumetric dynamic method exhibits a smoother transition, signifying a closer resemblance to the real physical process. Full article

Innovative structures technologies can contribute to increasing the sustainability of next-generation aircraft. Advanced multi-disciplinary physics models, combined with data-based models, are needed to obtain optimized structures with maximum contributions to sustainability throughout the life cycle. Such models are needed for next-generation aircraft products, for better production of their parts, and for representative testing of their innovative systems. Modeling challenges addressed recently will be presented and illustrated in their industrial context. In particular, fast in-line detection of defects in large composite aircraft parts during their high-rate production, induction welding of thermoplastic carbon-fiber reinforced parts, and accurate design of composite fan blades for wind tunnel testing of fuel-efficient Ultra-High Bypass Ratio (UHBR) turbofan engines will be presented. Full article

Aviation accounts for a significant share of global CO₂ emissions, necessitating efficient propulsion technologies to achieve net-zero emissions by 2050. Geared turbofan architectures offer a promising solution by enabling higher bypass ratios and improved fuel efficiency. However, geared turbofans introduce significant aerodynamic and structural challenges, particularly in the low-pressure turbine. Current understanding of high-speed low-pressure turbine behavior under engine-representative conditions is limited, especially regarding unsteady wake interactions, secondary flows, and compressibility effects. To address these gaps, this work presents a novel test case of high-speed low-pressure turbines, the SPLEEN C1. The test case and experimental methodology are depicted. The study includes the commissioning and characterization of a transonic low-density linear cascade capable of testing quasi-3D flows. The rig’s operational stability, periodicity, and inlet flow characterization are assessed in terms of loss and turbulence quantities to ensure an accurate representation of engine conditions. These findings provide a validated experimental platform for studying complex flow interactions in high-speed low-pressure turbines, supporting future turbine design and efficiency advancements. Full article

The present work demonstrates a comparative study of hydrogen fuel cells and combustion aircraft to investigate the potential of fuel cells as a visionary propulsion system for radically more sustainable medium- to long-range commercial aircraft. The study, which considered future airframe and propulsion technologies under the Se2A project, was conducted to quantify potential emissions and costs associated with such aircraft and to determine the benefits and drawbacks of each energy system option for different market segments. Future technologies considered in the present work include laminar flow control, active load alleviation, new materials and structures, ultra-high bypass ratio turbofan engines, more efficient thermal management systems, and superconducting electric motors. A multi-fidelity initial sizing framework with coupled constraint and mission analysis blocks was used for parametric airplane sizing and calculations of all necessary characteristics. Analyses performed for three reference aircraft of different sizes and ranges concluded that fuel-cell aircraft could have operating cost increases in the order of 30% compared to hydrogen combustion configurations and were caused by substantial weight and fuel burn increases. In-flight changes in emissions of fuel cell configurations at high altitudes were progressively reduced from medium-range to long-range segments from being similar to hydrogen combustion for medium-range to 24% for large long-range aircraft, although fuel cell aircraft consume 22–30% more fuel than combustion aircraft. Results demonstrate a positive environmental impact of fuel cell propulsion for long-range applications, the possibilities of being a more emission-universal solution, if desired optimistic technology performance metrics are satisfied. The study also demonstrates progressively increasing technology requirements for larger aircraft, making the long-range application’s feasibility more challenging. Therefore, substantial development of fuel cell technologies for long-range aircraft is imperative. The article also emphasizes the importance of airframe and propulsion technologies and the necessity of green hydrogen production to achieve desired emissions. Full article

Designing a combustion chamber for gas turbines is considered both a science and an art. This study presents a comprehensive methodology for designing an annular combustion chamber tailored to the operating conditions of a CFM-56 engine, a widely used high bypass ratio turbofan engine. The design process involved calculating the basic criteria and dimensions for the casing, liner, diffuser, and swirl, followed by an analysis of the cooling sections of the liner. Numerical simulations using NUMECA software and the HEXPRESS meshing tool were conducted to predict the combustion chamber’s behavior and performance, employing the κ-ε turbulence model and the Flamelet combustion model. Methane was used as the fuel, and simulations were performed for three fuel injection angles: axial, 45°, and 60°. Results demonstrate that the combustion chamber is properly dimensioned and achieves complete combustion for all configurations. The pressure ratio is 0.96, exceeding the minimum design criteria. Additionally, the emissions of unburned hydrocarbons are zero, while nitrogen oxides and carbon monoxide levels are below regulatory limits. These findings validate the proposed design methodology, ensuring efficient and environmentally compliant combustion chamber performance. Full article

Future UHBR (Ultra-High Bypass-Ratio) engines might cause serious ‘turbine noise storms’ but, at present, turbine noise prediction capability is lacking. The large turning angle of the turbine blade is the first major factor deserving special attention. The RANS (Reynold Averaged Navier–Stokes equation)-informed (here called RI) method and LINSUB (the bound vorticity 2D model LINearized SUBsonic flow in cascade), developed to predict fan broadband noise, coupled with a two-flat-plates (here called TP) assumption for the turbine blade, is applied here, and one autonomous rapid RI-TP model for predicting turbine wake interaction broadband noise has been developed. Firstly, taking the single axial turbine test rig NPU-Turb as the object, both the experimental data and the DDES/AA (delayed Detached Eddy Simulation/Acoustic Analogy) hybrid model have been used to validate the RI-TP model. High consistency in the medium and high frequencies among the three designed and off-designed rotation speeds indicates that the RI-TP model has the ability to predict turbine broadband noise rapidly. And compared with the original RANS-informed method, with one thin-flat-plate assumption on the blade, the RI-TP model can enhance the PWL (sound power level) in almost the whole spectral range below 10 KHz, which, in turn, is closer to the experimental data and the DDES/AA prediction results. The PWL trend with a ‘dividing point’ position is also studied. The spectrum would move up or down if the location is away from true value. In addition, the extraction location for turbulence as an input for the RI-TP model is negligible. In the future, multi-stage characteristics and the blade thickness effect should be further considered when predicting turbine noise. Full article

The next-generation variable cycle engine imposes stricter requirements on a fan’s flow capacity at the middle speed. To tackle this challenge, the implementation of split fans presents as a potential solution. In the present study, we conducted numerical simulations using the commercial software NUMECA to investigate the aerodynamic performance variation with bypass ratios for variable cycle split fans in “1 + 2” and “2 + 1” configurations at 80% rpm. The results indicate that the flow capacity of the split fans exhibits an increasing trend with a rise in the bypass ratio at 80% rpm and subsequently stabilizes upon reaching a certain bypass ratio. Specifically, the flow capacity of the “2 + 1” split fans is particularly stronger at the small bypass ratios, whereas the “1 + 2” split fans exhibit superior maximum flow capacity at the high bypass ratios. Additionally, there is a significantly faster increase in the flow capacity of the “1 + 2” split fans compared to that of the “2 + 1” split fans. Furthermore, when the flow capacity of the split fans reaches its maximum, both the efficiency and stall margin achieve their optimal values, indicating that the corresponding bypass ratio is optimal. Full article

The aim of this review paper is to collect and discuss the most relevant and updated contributions in the literature regarding studies on new or non-conventional technologies for propulsion–airframe integration. Specifically, the focus is given to both evolutionary technologies, such as ultra-high bypass ratio turbofan engines, and breakthrough propulsive concepts, represented in this frame by boundary layer ingestion engines and distributed propulsion architectures. The discussion focuses mainly on the integration effects of these propulsion technologies, with the aim of defining performance interactions with the overall aircraft, in terms of aerodynamic, propulsive, operating and mission performance. Hence, this work aims to analyse these technologies from a general perspective, related to the effects they have on overall aircraft design and performance, primarily considering the fuel consumption as a main metric. Potential advantages but also possible drawbacks or detected showstoppers are proposed and discussed with the aim of providing as broad a framework as possible for the aircraft design development roadmap for these emerging propulsive technologies. Full article

Composite shells find diverse applications across industries due to their high strength-to-weight ratio and tailored properties. Optimizing parameters such as matrix-reinforcement ratio and orientation of the reinforcement is crucial for achieving the desired performance metrics. Stochastic optimization, specifically genetic algorithms, offer solutions, yet their computational intensity hinders widespread use. Surrogate models, employing neural networks, emerge as efficient alternatives by approximating objective functions and bypassing costly computations. This study investigates surrogate models in multi-objective optimization of composite shells. It incorporates deep neural networks to approximate relationships between input parameters and key metrics, enabling exploration of design possibilities. Incorporating mode shape identification enhances accuracy, especially in multi-criteria optimization. Employing network ensembles strengthens reliability by mitigating model weaknesses. Efficiency analysis assesses required computations, managing the trade-off between cost and accuracy. Considering complex input parameters and comparing against the Monte Carlo approach further demonstrates the methodology’s efficacy. This work showcases the successful integration of network ensembles employed as surrogate models and mode shape identification, enhancing multi-objective optimization in engineering applications. The approach’s efficiency in handling intricate designs and enhancing accuracy has broad implications for optimization methodologies. Full article

Present work investigates the potential of a long-range commercial blended wing body configuration powered by hydrogen combustion engines with future airframe and propulsion technologies. Future technologies include advanced materials, load alleviation techniques, boundary layer ingestion, and ultra-high bypass ratio engines. The hydrogen combustion configuration was compared to the configuration powered by kerosene with respect to geometric properties, performance characteristics, energy demand, equivalent CO₂ emissions, and Direct Operating Costs. In addition, technology sensitivity studies were performed to assess the potential influence of each technology on the configuration. A multi-fidelity sizing methodology using low- and mid-fidelity methods for rapid configuration sizing was created to assess the configuration and perform robust analyses and multi-disciplinary optimizations. To assess potential uncertainties of the fidelity of aerodynamic analysis tools, high-fidelity aerodynamic analysis and optimization framework MACH-Aero was used for additional verification. Comparison of hydrogen and kerosene blended wing body aircraft showed a potential reduction of equivalent CO₂ emission by 15% and 81% for blue and green hydrogen compared to the kerosene blended wing body and by 44% and 88% with respect to a conventional B777-300ER aircraft. Advancements in future technologies also significantly affect the geometric layout of aircraft. Boundary layer ingestion and ultra-high bypass ratio engines demonstrated the highest potential for fuel reduction, although both technologies conflict with each other. However, operating costs of hydrogen aircraft could establish a significant problem if pessimistic and base hydrogen price scenarios are achieved for blue and green hydrogen respectively. Finally, configurational problems featured by classical blended wing body aircraft are magnified for the hydrogen case due to the significant volume requirements to store hydrogen fuel. Full article

The mandatory implementation of the standards laid out in the Energy Efficiency Existing Ship Index (EEXI) and the Carbon Intensity Indicator (CII) requires ships to improve their efficiency and thereby reduce their carbon emissions. To date, the steam Rankine cycle (RC) has been widely used to recover wasted heat from marine main engines to improve the energy-conversion efficiency of ships. However, current marine low-speed diesel engines are usually highly efficient, leading to the low exhaust gas temperature. Additionally, the temperature of waste heat from exhaust gas is too low to be recovered economically by RC. Consequently, a solution has been proposed to improve the overall efficiency by means of waste heat recovery. The exhaust gas is bypassed before the turbocharger, which can decrease the air excess ratio of main engine to increase the exhaust gas temperature, and to achieve high overall efficiency of combined cycle. For quantitative assessments, a semi-empirical formula related to the bypass ratio, the excess air ratio, and the turbocharging efficiency was developed. Furthermore, the semi-empirical formula was verified by testing and engine model. The results showed that the semi-empirical formula accurately represented the relationships of these parameters. Assessment results showed that at the turbocharging efficiency of 68.8%, the exhaust temperature could increase by at least 75 °C, with a bypass ratio of 15%. Moreover, at the optimal bypass ratio of 11.1%, the maximum overall efficiency rose to 54.84% from 50.34%. Finally, EEXI (CII) decreased from 6.1 (4.56) to 5.64 (4.12), with the NOx emissions up to Tier II standard. Full article

Gas turbine fuel burn for an aircraft engine can be obtained analytically using thermodynamic cycle analysis. For large-diameter ultra-high bypass ratio turbofans, the impact of nacelle drag and propulsion system integration must be accounted for in order to obtain realistic estimates of the installed specific fuel consumption. However, simplified models cannot fully represent the complexity of installation effects. In this paper, we present a method that combines thermodynamic cycle analysis with detailed Computational Fluid Dynamics (CFD) modelling of the installation aerodynamics to obtain the fuel consumption at a given mission point. The flow field and propulsive forces arising in a transport aircraft powered by an ultra-high bypass ratio turbofan at cruise are first examined to characterise the operating conditions and measure the sensitivity to variations of the incidence at transonic flight. The proposed methodology, in which dynamic balance of the vehicle is achieved at each integration point, is then applied along a cruise segment to calculate the cumulative fuel burn and the change in the specific fuel consumption. Full article

Most large commercial vessels are propelled by low-speed two-stroke diesel engines due to their fuel economy and reliability. With increasing international concern about emissions and the rise in oil prices, improvements in engine efficiency are urgently needed. In the present work, a zero-dimensional model for a low-speed two-stroke diesel engine is developed that considers the exhaust gas bypass and geometry structures for the gas exchange model. The model was applied to a low-speed two-stroke 7G80 ME-C9 marine diesel engine and validated with engine shop test data, which consisted of the main engine performance parameters and cylinder pressure diagrams at different loads. The simulation results were in good agreement with the experimental data. Thus, the model has the ability to predict engine performance with good accuracy. After model validation, the variations in compression ratio, fuel injection timing, exhaust gas bypass valve opening portion, exhaust valve opening timing, and exhaust valve closing timing effects on engine performance were tested. Finally, the influence level of different parameters on engine performance was summarized, which can be used as a reference to determine the reasons for high fuel consumption in some cases. The developed engine performance model is considerable in digital twins for performance simulation, health management, and optimization. Full article

To accommodate the next generation of adaptive/variable cycle engines and gas turbine power, the variable geometry turbine (VTG) is widely acknowledged as a most essential component. VGT consists of an adjustable vane to address the combined goals of high dry thrust and low specific fuel consumption (SFC) at subsonic cruises for aero-engines. This concept allows an engine to operate at a constant bypass ratio over a wide range of pressure ratios. To avoid scraping during rotation for guide vanes, a typical gap is deliberately left, which leads to significant leakage loss. In this research work, a novel spherical convex plat with a pivot shaft is proposed, which can be obtained by additive manufacturing. The plat is sophisticatedly designed according to the aggressive tip/hub pressure gradient. This design naturally generates a blockage for the gas from the pressure side towards the suction side. As a result, the most aggressive pressure gradient is removed, and maximum leakage flow is eliminated. The overall leakage loss is reduced. This simple rotating structure design can improve the efficiency by 0.4–3.0% within the wide range considered. Based on the understanding of the loss mechanism, a radially restacked vane is designed and another extra 0.2% improvement is achieved. This universal design philosophy is also verified on different loading blade profiles, i.e., front-, middle- and aft-loaded turbine vane. The improved aerodynamic performance is achieved with this novel idea. Full article
