This paper develops a system–component integrated design method for a closed Brayton cycle in a nuclear-powered emergency power vehicle, optimizing the thermodynamic performance by varying the maximum operating temperature and pressure, minimum operating temperature, helium–xenon gas molar mass, and PCHE parameters to maximize the specific power and thermal efficiency. The key results are as follows: (1) The maximum allowable pressure decreases with the temperature, and the specific power increases for both the SRC and the IRC without considering the ultimate heat sink. (2) The PCHE weight is minimized at a helium–xenon gas molar mass of 25 g/mol, while the turbomachine’s weight decreases with an increasing molar mass, leading to an overall system weight reduction. (3) The thermal efficiency decreases with lower minimum operating temperatures, optimizing at 350 K due to a precooler weight increase. (4) The thermal efficiency plateaus after a certain number of PCHE channels, with the recuperator effectiveness significantly impacting the performance. (5) The SRC, with a specific power and a thermal efficiency of 194.38 kW/kg and 39.19%, is preferred over the IRC for the SIMONS due to its mobility and rapid deployment. This study offers a comprehensive analysis for optimizing closed Brayton cycle systems in emergency power applications. Full article

The burning chamber wall of the ramjet engine is facing an extremely thermal environment during normal conditions. Thermal protection measures must be taken on the wall surface of the combustion chamber. At the same time, the aircraft faces high-power electrical demand problems under high-speed cruising states. To address these issues, a second fluid-closed Brayton cycle system was introduced in this paper. Helium was utilized as the secondary fluid medium, while kerosene was used as the final heat sink. The ramjet engine chamber wall was cooled by the helium cycle system. At the same time, part of the heat absorbed by the helium cycle was transformed into electric power by a generator. This work proposes a new method of thermal management in a closed cycle. Unlike traditional methods, this proposal can regulate the mass flow rate of helium based on the requirement of heat load. A zero-dimensional numerical calculation method was established for thermodynamic analysis. The results show that as the equivalence ratio of 0.8~1.5 for the kerosene flow rate, the system can suffer the thermal load of 200~350 kJ/kg on the combustion chamber wall at the maximum kerosene allowable temperature. To ensure the normal operation of the circulating system, the mass flow ratio between the helium and the air changes from 0.02 to 0.045. Compared with the direct kerosene cooling method, the second fluid circulation method leads to the kerosene equivalent saving ratio by 2% to 14%; at the same time, such a system could generate 160~500 kJ/kg of electrical energy. This new thermal management method can achieve kerosene saving, electric power generating and suffering more thermal loads under the premise of satisfying normal work. Full article

New aerodynamic aircraft concepts enable the storage of volumetric liquid hydrogen (LH2). Additionally, the low temperatures of LH2 enable technologies such as the superconductivity of electrical fan drives and power distribution components. An increased power density of the onboard wiring harness and the electrical machine can be expected. The highest system efficiency and the smallest fuel and tank weight will be achieved with a highly efficient energy conversion by the fuel cell from LH2 to electrical energy. This publication shows a comprehensive study for cryogenic fan drives based on experimental-driven tape superconductor investigations, mission profile-based considerations, design analyses of superconducting electrical machines, and studies of the cooling concepts. A cryogenic system cannot be considered without a feasible cooling concept. Here, an approach with a safe He-based cooling system is proposed, using the LH2 flow to the fuel cell as a heat sink for the losses in the electrical system. Full article

Helium-xenon (HeXe)-cooled mobile nuclear reactors have promising potential in future low-carbon energy systems. However, there is currently a lack of fast and reliable tools for analyzing the complicated dynamic characteristics of such systems. In this study, we developed a comprehensive dynamic modeling approach for a HeXe-cooled nuclear power system coupled with a closed Brayton cycle (CBC). The system’s key components, including the reactor, printed circuit heat exchanger (PCHE), and turbomachinery, are lumped-modeled to capture their time-varying behavior. A step-solving algorithm that incorporates HeXe mass conservation iteration is designed. The verification results demonstrate that the dynamic program is robust and reliable, with each time step converging within 25 iterations and the HeXe mass remaining within the range of 3.755 ± 0.01 kg throughout the simulation meeting the law of mass conservation. Then, a 1500 s frozen start-up simulation for the coupled system is conducted, in which the CBC is started in the first 500 s by increasing the main shaft speed to 40% of the rated value, and then the reactor is started by inserting external reactivity between 500 and 800 s. Both the dynamic process and the steady-state performance after the start-up are analyzed. The results show that the system achieved a stable electrical output of 5.7 MWe with a thermal efficiency of 32.5%. This study lays a solid foundation for future work aimed at improving the overall efficiency and performance of HeXe-cooled nuclear power systems. Full article

One of the primary parts of a closed Brayton cycle that uses a helium–xenon mixture as the working medium is a centrifugal compressor. Nowadays, there has been minimal research on the theoretical underpinnings and design procedures of a helium–xenon mixture centrifugal compressors, and the internal flow mechanisms remain poorly understood. In this study, we present a redesign of the 15 g/mol helium–xenon centrifugal compressor originally developed by Bruno M, utilizing a helium–xenon mixture as the working fluid to enhance compressor performance and facilitate an in-depth analysis of the internal flow dynamics. The findings indicate a significant expansion of the stable operating range of the redesigned compressor under identical outlet conditions, with a 33.27% increase in flow margin and substantial improvements in the pressure ratio. Furthermore, under consistent inlet conditions, at an operational flow rate of 0.8657 kg/s, the redesigned compressor exhibits a pressure ratio that is 2.11% greater than that of the original design, along with a variable efficiency increase of 1.1%. Full article

In recent years, fusion energy has assumed an important role in the energy scenario, being a sustainable, environmentally friendly, and practically inexhaustible energy source. Fusion energy could play a crucial role in fully decarbonized electricity production in the second half of this century, helping to meet the increasing energy demand. One of the studied reactors is ARC, a tokamak fusion device characterized by a compact and high-field design initially conceived by researchers at the Massachusetts Institute of Technology, which the Commonwealth Fusion System (CFS) plans to construct in the next decade. This paper is focused on the analysis and development of different configurations for the ARC Balance of Plant Power Conversion System, with the aim of improving the thermodynamic efficiency, which is one of the pillars of sustainability. Three cycles were studied by using the General Electric GateCycle^TM software: a supercritical steam Rankine cycle, a supercritical CO₂ Brayton cycle, and a supercritical helium Brayton cycle. The thermal efficiency of the three options was compared to select the most promising solution. The results showed that the supercritical steam cycle is the best configuration in terms of cycle efficiency for the ARC FNSF Pilot phase. Full article

Small nuclear power plants can provide a stable, carbon-free energy supply to civil infrastructure and industrial enterprises in remote regions isolated from unified energy systems. More than 70 projects of small modular reactors are currently being developed by IAEA member countries; several low-power power units are already supplying thermal and electrical energy to consumers. One of the main limitations standing in the way of widespread dissemination of this technology is the high specific capital cost of a low-power nuclear power plant; therefore, new scientific and technical solutions are needed in this industry. Increasing the thermodynamic efficiency of power cycles of small modular reactors can become a driver for reducing the cost of supplied electrical energy. This paper presents the results of a comprehensive thermodynamic analysis of existing and promising power cycles for small modular reactors. In addition to traditional steam power cycles, cycles using non-traditional working fluids, including carbon dioxide, freons, and helium cycles, are considered. Optimal sets of thermodynamic parameters were determined to ensure maximum net efficiency of electricity production. For water-cooled reactor plants, a maximum efficiency of 33.5% at an initial temperature of 300 °C could be achieved using a steam turbine cycle. It was revealed that for reactor plants with liquid metal and liquid salt coolant in the range of initial temperatures above 550–700 °C, the maximum thermal efficiency was provided by the Brayton recompression cycle with a carbon dioxide coolant: the net electrical efficiency exceeded the level of steam turbine plants, with intermediate superheating of the steam, and could reach a value of 49.4% at 600 °C. This makes the use of these cycles promising for low-power nuclear power plants with a high initial temperature. In small gas-cooled reactor plants with a helium coolant, the use of a binary cycle consisting of a helium Brayton cycle and a steam-powered Rankine cycle provided an efficiency of 44.3% at an initial helium temperature of 700 °C and 52.9% at 1000 °C. This was higher than in the Brayton cycle with a recuperator, with a minimum temperature difference in the heat exchanger of 20 °C: the efficiency was 40.2% and 52%, respectively. Also, the transition to power cycles with non-traditional working fluids will lead to a change in the operating conditions of turbomachines and heat exchangers. Full article

The growing demand for electricity in long-duration space missions has become a pressing concern. The space nuclear closed-Brayton-cycle (CBC) power generation system offers advantages in power output, operational lifespan, and range. However, a significant speed disparity exists between its compressor and alternator. To address this challenge, this paper proposes a double-rotor CBC configuration. A corresponding dynamic model that couples the nuclear reactor and radiator is formulated, and dynamic analysis is conducted to facilitate system control. The study delves into the dynamic start-up process of the double-rotor CBC system and examines how various component parameters impact its power generation performance. The findings indicate that through the introduction of suitable reactivity to regulate reactor power and the incorporation of a PID controller to manage flow distribution between two turbines, the system can achieve start-up within 5200 s. Moreover, the innovative double-rotor structure suggested in this paper enables the separation of compressor and alternator speeds. Consequently, the compressor and alternator can operate within their optimal speed ranges independently, which is a feature that holds potential benefits for the system’s practical implementation. In addition, the steady-state operation of the system showcases the recuperator’s heat transfer power at around 1127.60 kW, a parameter of significant importance. Following steady-state operation, the double-rotor CBC system demonstrated an electrical power output of 175.99 kW and a thermal efficiency of 32.38%. Full article

He–Xe, with a 40 g/mol molar mass, is considered one of the most promising working media in a space-confined Brayton cycle. The thermodynamic performance of He–Xe in different configuration channels is investigated in this paper to provide a basis for the optimal design of printed circuit board plate heat exchanger (PCHE). In this paper, the factors affecting the temperature distribution of the He–Xe flow field are analyzed based on the flow heat transfer mechanism. It is found that the flow patterns in the logarithmic and outer zones determine the temperature distribution pattern of the flow field. A series of numerical simulations verify the above conclusions, and it is found that reasonable channel structure and operating conditions can significantly improve the thermodynamic performance of the He–Xe flow. Based on the above findings, the Zig channel is optimized, obtaining Sine and Serpentine channels with different structural characteristics. Comprehensive thermodynamic comparisons of the helium–xenon flow domains inside channels are performed, and the Serpentine channel with a shape factor of tan 52.5° is found with the best performance. This work aims to improve the understanding of the thermodynamic performance of He–Xe in microchannels and provide theoretical support for further optimization of PCHE employing He–Xe. Full article

Detailed thermodynamic, exergoeconomic, and multi-objective analysis are performed for a supercritical recompression Brayton cycle in which the advanced working medium mixture of nitrous oxide and helium (N₂O–He) is utilized for power generation. The thermodynamic and exergoeconomic models are propitious based on the standard components’ mass and energy conservation, exergy balance equation, and exergy cost calculation equation. An investigation of the sensitivity parametric is considered for judging the impact of crucial decision variable parameters on the performance of the proposed Brayton cycle. The proposed cycle’s performance is evaluated by systematic analysis of the thermal efficiency (η_th), exergy efficiency (η_ex), total cost rate ($\stackrel{.}{C}$_total), levelized cost of electricity (LCOE), and the total heat transfer area (A_total). Furthermore, multi-objective optimization is adopted from the viewpoint of the first and second laws of exergoeconomics to find the optimum operating parameters and to improve the circular’s exergoeconomic performance. The final results illustrate that the optimization calculation is based on the fact of the exergoeconomics method; the whole system produces electrical power of 0.277 MW with $\stackrel{.}{C}$_total of USD 18.37/h, while the η_th, η_ex, A_total, and LCOE are 49.14%, 67.29%, 165.55 m² and USD 0.0196/kWh, respectively. It is concluded that the work exergy destruction for the reactor and turbine is higher than that of other components; then, after the multi-objective optimization analysis, the η_th and η_ex improved by 2.08% and 5.07%, respectively, and the $\stackrel{.}{C}$_total, A_total, and LCOE decreased by 13.99%, 0.01%, and 5.13%, respectively. Full article

Hybrid solar thermal power plants using the Brayton cycle are currently of great interest as they have proven to be technically feasible. This study evaluates mechanisms to reduce fuel consumption and increase the power generated, improving plant efficiency. An energy and exergy model for the hybrid solar plant is developed using an estimation model for the solar resource to determine the plant operation under specific environmental conditions. The effect of using different working fluids in the Brayton cycle, such as air, and helium in transcritical conditions and carbon dioxide in subcritical and supercritical conditions, is evaluated. Additionally, the plant’s exergy destruction and exergy efficiency are evaluated. In those, it can be highlighted that the helium cycle in the same operating conditions compared to other working fluids can increase the power by 160%, increasing fuel consumption by more than 390%. Full article

The compressor of closed Brayton cycle (CBC) plant operating with working fluid other than air is a vital element of the energy conversion unit. However, due to insufficient understanding of the influence of the physical properties of working fluids on the performance of the compressor, the actual working conditions and design conditions of the compressor’s performance deviate greatly. In this paper, the objective is to analyze the influence mechanism of the physical properties on the performance of the cascade of compressor (static pressure ratio and total pressure loss coefficient). Therefore, the impact of a specific heat ratio on the performance of the compressor cascade is studied utilizing carbon dioxide (γ = 1.29), air and carbon monoxide (γ = 1.4), argon and helium (γ = 1.667). Moreover, the relationships of static pressure ratio and total pressure loss coefficient with physical properties of the working fluids are analyzed in the compressor cascade. It is established that a higher specific heat ratio fluid gives a higher coefficient of total pressure loss and static pressure ratio in contrast to smaller specific heat ratio at matching inlet Reynolds number and Mach number. Full article

The unique design features of the molten salt fast reactor (MSFR) should enable higher coolant temperatures than in conventional water reactors, with a significant improvement in the achievable thermodynamic performance. The use of a molten salt as both fuel and coolant, however, poses several advanced heat transfer challenges, such as the design of innovative heat exchangers and energy conversion systems. In this work, we address a preliminary but quantitative analysis of the energy conversion system for the MSFR, based on reference design data from the SAMOFAR H2020-EURATOM project. We consider three main technologies, i.e., the supercritical steam cycle, the closed helium cycle and the helium/steam combined cycle. Preliminary design results are presented for each technology, based on a simplified modelling approach. The considered cycles show promising efficiency improvements, with the best performance being proven by the supercritical steam cycle. The analysis also highlights the critical issue related to the risk of freezing of the molten salts within the secondary heat exchangers, due to the low inlet temperatures of the working fluids. Results show potential incompatibility between the freezing point of molten salts and the temperatures typical of steam cycles, while helium cycles offer the best chances of freezing avoidance. The combined cycle promises intermediate performance in terms of thermodynamic efficiency and thermal compatibility with molten salts comparable with closed helium cycles. Full article
