Search Results (105)

Enhancing the resilience of renewable energy systems in ultra-weak grids is crucial for promoting sustainable energy adoption and ensuring a reliable power supply during disturbances. Ultra-weak grids characterized by a very low Short-Circuit Ratio, less than 2, and high grid impedance significantly impair voltage and frequency stability, imposing challenging conditions for Inverter-Based Resources. To address these challenges, this paper considers a 110 KVA, three-phase, two-level Voltage Source Converter, interfacing a 700 V DC link to a 415 V AC ultra-weak grid. X/R = 1 is controlled using Sinusoidal Pulse Width Modulation, where the Grid-Connected Converter operates in Grid-Forming Mode to maintain voltage and frequency stability under a steady state. During symmetrical and asymmetrical faults, the converter transitions to Grid-Following mode with current control to safely limit fault currents and protect the system integrity. After fault clearance, the system seamlessly reverts to Grid-Forming Mode to resume voltage regulation. This paper proposes an improved control strategy that integrates voltage feedforward reactive power support and virtual capacitor-based virtual inertia using Active Disturbance Rejection Control, a robust, model-independent controller, which rapidly rejects disturbances by regulating d and q-axes currents. To test the practicality of the proposed system, real-time implementation is carried out using the OPAL-RT OP4610 platform, and the results are experimentally validated. The results demonstrate improved fault current limitation and enhanced DC link voltage stability compared to a conventional PI controller, validating the system’s robust Fault Ride-Through performance under ultra-weak grid conditions. Full article

The energy transition toward greater electrification leads to incentives in public transportation fed by catenary-powered networks. In this context, emerging technological devices such as in-motion-charging vehicles and electric vehicle charging points are expected to be operated while connected to trolleybus networks as part of new electrification projects, resulting in a significant demand for power. To enable a significant increase in electric transportation without compromising technical compliance for voltage and current at grid systems, the implementation of stationary battery energy storage systems (BESSs) can be essential for new electrification projects. A key challenge for BESSs is the selection of the optimal converter topology for charging their batteries. Ideally, the chosen converter should offer the highest efficiency while minimizing size, weight, and cost. In this context, a modular dual-active-bridge converter, considering its operation as a full-power converter (FPC) and a partial-power converter (PPC) with module-shedding control, is analyzed in terms of operation efficiencies and thermal behavior. The goal is to clarify the advantages, disadvantages, challenges, and trade-offs of both power-processing techniques following future trends in the electric transportation sector. The results indicate that the PPC achieves an efficiency of 98.58% at the full load of 100 kW, which is 1.19% higher than that of FPC. Additionally, higher power density and cost effectiveness are confirmed for the PPC. Full article

Driven by the environmental benefits associated with reduced greenhouse gas emissions, oil companies have intensified research efforts into reassessing the strategies used to meet the electrical demands of offshore production platforms. Among the various alternatives available, the deployment of onshore–offshore interconnections via High-Voltage Direct Current (HVDC) transmission systems has emerged as a promising solution, offering both economic and operational advantages. In addition to reliably meeting the electrical demand of offshore facilities, this approach enables enhanced operational flexibility due to the advanced control and regulation capabilities inherent to HVDC converter stations. Based on the use of interconnection through an HVDC link, aiming to evaluate the operation of the electrical system as a whole, this study focuses on evaluating dynamic events using the PSCAD software version 5.0.2 to analyze the direct online starting of a large induction motor and the sudden loss of a local synchronous generating unit. The simulation results are then analyzed to assess the effectiveness of both Grid-Following (GFL) and Grid-Forming (GFM) control strategies for the converters, while the synchronous generators are evaluated under both voltage regulation and constant power factor control operation, with a particular focus on system stability and restoration of normal operating conditions in the sequence of events. Full article

Dual Maximum Power Point Tracking (MPPT) inverters are essential in residential and small commercial solar power systems, optimizing power extraction from two independent solar panel arrays to enhance efficiency and energy harvesting. On the other hand, the Three-Level T-Type Voltage Source Inverter (3L T-Type VSI) is known for its reduced switching losses, improved harmonic distortion, and reduced part count in comparison to other three-level topologies. In this paper, a novel architecture is proposed to integrate the dual MPPT structure directly to each DC-side split capacitor of the 3L T-Type VSI, taking advantage of the intrinsic characteristics of the inverter’s topology. Further performance enhancement is achieved by integrating a classical MPPT strategy to the control framework to make it feasible for a real-case grid integration. The combination of these methods ensures faster and stable tracking under dynamic irradiance conditions. Considering that strategies dedicated to balancing the DC-link capacitor’s voltage slightly affect the AC-side current waveform, an enhanced sliding mode control (SMC) strategy tailored for dual MPPT and 3L T-Type VSI is deployed, combining the simplicity of conventional PI controllers used in the independent MPPT-based DC-DC converters with the superior robustness and dynamic performance of SMC. Real-time results obtained using the OPAL-RT Hardware-in-the-Loop platform validated the performance of the proposed control strategy under realistic test scenarios. The current THD was maintained below 4.8% even under highly distorted grid conditions, and the controller achieved a steady state within approximately 15 ms following perturbations in the DC-link voltage, sudden irradiance variations, and voltage sags and swells. Additionally, the power factor remained unitary, enhancing power transfer from the renewable source to the grid. The proposed system was able to achieve efficient power extraction while maintaining high power quality (PQ) standards for the output, positioning it as a practical and flexible solution for advanced solar PV systems. Full article

Virtual inertia is a measure of the capability of distributed sources and loads within power supply units to resist system frequency variations through additional control strategies applied to converters. The reasonable allocation of virtual inertia is beneficial for enhancing system stability. In response to the insufficient consideration of multi-regional coordination and difficulties in balancing frequency change rates in existing virtual inertia allocation methods, this paper proposes a neural network-based coordinated virtual inertia allocation method for multiple regions. First, a data-driven model is constructed based on the RBFNN neural networks to map the feasible region boundaries of virtual inertia for distributed resources under different disturbance scenarios. Second, a multi-area virtual inertia optimization allocation model is established, aiming to minimize both the inter-area frequency change rates and the differences between them, while considering the regulation capabilities of grid-forming PV systems and ESS. Following this, a genetic algorithm-based solving strategy is designed to achieve the global optimal allocation of virtual inertia. Finally, simulations verify the effectiveness of the coordinated allocation strategy in enhancing frequency stability across multiple autonomous regions. This optimization method reduces the frequency variation rate in both regions and maintains relative stability between the regions, thereby enhancing the system’s disturbance rejection capability. The results showed that after optimizing the virtual inertia allocation using the method proposed in this paper, the frequencies of the two regions increased by 0.11 Hz and 0.14 Hz, respectively, and the dynamic rate of frequency change decreased by 50.2% and 52.1%. Therefore, this study provides a foundational method and a feasible approach to multi-area virtual inertia optimization allocation in the new distribution system, contributing to frequency support via virtual inertia in distribution network optimization operation. Full article

The increasing deployment of renewable energy sources is reshaping power systems and presenting new challenges for the integration of distributed generation and energy storage. Power converters have become essential to manage energy flows, coordinate storage systems, and maintain grid stability. This study presents a literature review following the PRISMA 2020 methodology, covering 71 peer-reviewed articles published between 2014 and 2024. The analysis organizes current research into five main areas: converter topologies, storage integration, grid interaction, advanced control strategies, and renewable energy applications. Recent developments include progress in multilevel and bidirectional converter designs, the use of wide-bandgap semiconductors (SiC, GaN), and the application of advanced control techniques such as model predictive control, fuzzy logic, and reinforcement learning. However, several challenges remain unresolved, including the lack of standardized validation protocols, limited implementation of modular and scalable converter solutions, and insufficient integration of hybrid storage technologies such as hydrogen and second-life batteries. Future efforts should focus on developing interoperable control platforms, extending field validation studies, and incorporating digital twins and AI-based supervisory systems to improve the reliability, efficiency, and scalability of converter-based energy storage solutions under high renewable energy scenarios. Full article

Weak grid stability is crucial for grid-following voltage source converter (GFL-VSC) systems. Current studies primarily focus on the interaction analyses between active-power loops, whereas the influence of reactive-power loops remains unclear. To address this problem, this study focuses on terminal-voltage control (TVC) and analyzes its impact on equilibrium points (EPs) and small-signal stability by varying the TVC response speed, including three different cases: considering TVC dynamics, considering TVC rapid responses, and considering TVC slow responses. Firstly, the models of the GFL-VSC system under different scenarios are established and compared. In the EP analysis, for both TVC dynamics and TVC rapid responses, the EP of an active current remains constant and it becomes unstable in a weak grid, whereas for TVC slow responses, the EP undergoes trans-critical bifurcation; specifically, the other EP becomes stable after this bifurcation. Further, in the small-signal stability analysis, three equivalent Heffron–Phillips models based on the phase-locked loop synchronization dynamics with additional synchronization and damping coefficients are constructed and studied. By these systematical studies, the impacts of different TVC response speeds are clarified and summarized, and these analytical results are well supported by MATLAB/Simulink simulations and hardware-in-the-loop experiments. Full article

By integrating the grid-following control and grid-forming control, the adaptability of grid-connected converters to the grid impedance fluctuation can be effectively improved, and a stable operation in a wide short circuit ratio range can be realized. The existing fusion control schemes focus on the influence of the short circuit ratio on the stability of the converter, ignoring the influence of the active power fluctuation of the renewable energy in the design of the fusion scheme. In order to improve this shortcoming, an adaptive switching control of voltage source converters in the renewable energy station is proposed in this paper. Based on the oscillation characteristics of the grid-following converter and the grid-forming converter, this method selects the operating short circuit ratio as the switching index of the grid-following mode and the grid-forming mode. Compared with the current switching schemes based on the short circuit ratio, the operating short circuit ratio replaces the rated capacity of the station with the active output of the station, so it can more reasonably reflect changes in stability caused by active power fluctuations and then give the appropriate switching command, which means that unnecessary switching can be reduced and the control mode can be correctly converted to enhance stability when the system state changes. Full article

This paper explores how different control strategies—grid-forming and grid-following—impact the transient stability of modular multilevel converters (MMCs) interfacing with AC power grids. By employing electromagnetic transient simulation tools (PSCAD/EMTDC) on an adapted IEEE three-machine, nine-bus system, various scenarios are analyzed, including faults of differing types and locations. In the simulation, traditional synchronous generators (SGs) are replaced by MMCs configured under distinct control modes. Results indicate that grid-forming (GFM) control enhances the receiving-end grid’s transient stability by providing superior phase support and extended fault-clearing times compared to grid-following (GFL) control, with hybrid approaches yielding intermediate performance. These findings underline the importance of converter control selection in achieving robust dynamic operation in modern power systems with a high penetration of renewable energy. Full article

This paper investigates the transient synchronization stability mechanisms and technological advancements associated with grid-following (GFL) converters, providing a systematic review of the current research landscape and future directions in this field. The current literature lacks a comprehensive understanding of how outer-loop control dynamics and grid-converter interactions critically influence transient stability mechanisms. This oversight often leads to incomplete or overly simplistic stability assessments, particularly under high penetration of renewable energy sources. Furthermore, existing stability criteria and analytical methodologies do not adequately address the compounded challenges arising from multi-control-loop coupling effects and systems with multiple parallel converters. These limitations underscore the inability of conventional methodologies to holistically model the transient synchronization behavior of GFL converters in modern power-electronics-dominated grids. To address these gaps, this work synthesizes a comprehensive review of modeling frameworks, analytical methodologies, transient stability mechanisms, and influence factors specific to GFL converters. First, based on the fundamental differences between synchronous generators and GFL, this paper summarizes the second-order equivalent model derived from phase-locked loop (PLL) dynamic. It conducts a comparative analysis of the applicability and limitations of conventional stability assessment methods, such as the equal-area criterion, phase portrait method, and Lyapunov functions, within power-electronics-dominated systems. It highlights potential mechanistic misinterpretations arising from neglecting outer-loop control and grid interactions. Second, the paper delineates the principal challenges inherent in the transient synchronization stability analysis of GFL converters. These challenges encompass the dynamic influences of multi-control-loop coupling effects and the imperative for advancing stability criterion research in systems with multiple parallel converters. Building on existing studies, the paper further explores innovative applications of artificial intelligence (AI) in transient stability assessment, including stability prediction based on deep learning, data-physics hybrid modeling, and human–machine collaborative optimization strategies. It emphasizes that enhancing model interpretability and dynamic generalization capabilities will be critical future directions. Finally, by addressing these gaps, this work provides theoretical foundations and technical references for transient synchronization stability analysis and control in high-penetration inverter-based resources (IBRs) grids. Full article

This paper focuses on the development and experimental validation of a single-phase modular multilevel converter (MMC) based on a battery energy storage system (BESS) for residential uninterruptible power supply (UPS) with two-level active SoC balancing control. The configuration and mathematical modeling of the single-phase MMC-BESS are first presented, followed by the details of the control strategies, including dual-loop output voltage and current control in islanded mode, grid-connected control, circulating current control, and two-level active state-of-charge (SoC) balancing control. The design and optimization of the quasi-proportional-resonant (QPR) controllers were investigated by using particle swarm optimization (PSO). Simulation models were built to explore the operating characteristics of the UPS under islanded mode with an RL load and grid-connected mode and assess the control performance. A 500 W experimental prototype was developed and is herein presented, including results under different operating conditions of the MMC-BESS. The experimental results show that for both RL load and grid-connected tests, balancing was achieved. The response time to track the reference value was two grid periods (0.04 s). In the islanded mode test, the THD was 1.37% and 4.59% for the voltage and current, respectively, while in the grid-connected mode test, these values were 1.72% and 4.24% for voltage and current, respectively. Full article

The optimization of low-level control for DC–AC power converters is crucial for enhancing efficiency, stability, and adaptability in modern power systems. With the increasing penetration of renewable energy sources and the shift toward decentralized grid architectures, advanced control strategies are needed to address challenges such as reduced system inertia and dynamic operating conditions. This paper provides a concise review of key optimization techniques for low-level control, highlighting their advantages, limitations, and applicability. Additionally, emerging trends, such as artificial intelligence (AI)-based real-time control algorithms and hybrid optimization approaches, are explored as potential enablers for the next generation of power conversion systems. Notably, no single optimized control technique universally outperforms others, as each involves trade-offs in mathematical complexity, robustness, computational burden, and implementation feasibility. Therefore, selecting the most appropriate control strategy requires a thorough understanding of the specific application and system constraints. Full article

The transition to inverter-dominated power systems with novel control strategies has created weak grid scenarios, prompting extensive research into grid-forming (GFM) converters and advanced GFM control schemes. This study evaluates two GFM control strategies for their stabilizing effects in weakly interconnected and islanded power systems: the established Virtual Synchronous Machine (VSM) control and the newly developed Phase-Restoring Principle (PRP). The evaluation is conducted using a real-time electromagnetic transient (EMT) simulation testbed with Hardware-in-the-Loop (HiL) capabilities. The system includes a multi-terminal medium-voltage (MVDC) and high-voltage direct current (HVDC) network weakly coupled to a network equivalent, represented by a scaled synchronous machine (SynM) to replicate grid inertia. Modular multilevel converters (MMCs) model the converters, while Power Hardware-in-the-Loop (PHiL) experiments integrate real power hardware. Dynamic interactions, including islanded conditions, are emulated to assess the performance of GFM controls and their interactions in HV/MV and AC/DC systems. The results demonstrate the compatibility of diverse GFM schemes with grid-following controls and synchronous machines, emphasizing their positive contributions to system stability. This modular demonstrator, as a realistic prototype of future power systems, provides a flexible platform for testing emerging GFM strategies and hardware, supporting the development of robust and stable inverter-based grids. Full article

In recent years, continuous efforts have been made for the modelling and stability analysis of converter-dominated grids. Ensuring stability in converter-dominated grids presents a unique challenge, primarily due to the manufacturers’ intellectual property (IP) protections. Determining the robust stability boundary of a grid incorporating converters from various manufacturers remains an area requiring extensive research. Recently, a grey-box modelling approach for studying interoperability has been proposed in the literature. However, the existing methodology is solely suitable for grid-following converters. This study bridges the gap by proposing a GFM converters model which aligns with the methodology for analysing the interoperability of GFL converters. The model is designed to represent a range of control system implementations across different manufacturers. Using robust control theory, this approach assesses the grid’s stability margin and sensitivity analysis of the control loops under various conditions considering a single GFM converter. The results are validated both analytically and through real-time hardware-in-the-loop (HIL) tests to demonstrate the model accuracy in predicting robust stability margin and sensitivity of the control loops in GFM converter-dominated grids. Full article

Offshore wind farms are increasingly being commissioned farther from shore, and high voltage alternating current (HVAC) transmission systems are preferred because of their maturity and reliability. However, as cable length increases, ensuring system stability becomes more challenging, making it essential to investigate shunt reactor compensation configurations and converter control strategies. This study examines three different shunt reactor compensation arrangements and two control strategies, grid-forming (GFM) and grid-following (GFL), across three cable lengths (80 km, 120 km, and 150 km). The systems were evaluated based on small-signal stability using disk margins for different active power operating points, and later for different short-circuit ratios (SCR) and X/R. The results demonstrate that the GFM is preferable for longer cables and enhanced stability. The most robust configuration includes a shunt reactor placed in the mid-cable with additional reactors at both ends of the cable, followed by an arrangement with reactors at the beginning and end. The GFM converter control maintained stability across all operating points, cable lengths, and configurations, whereas the stability of the GFL unit was highly dependent on active power injection and struggled under weaker grid conditions. Thus, for longer HVAC cables, it is necessary to employ GFM control units, and it is recommended to use shunt reactors at the cable start and end, as well as at mid-cable, for optimal stability. Full article
