Devices that measure the presence of instability in the pulse shapes in trains of ultrashort laser pulses do not exist, so this task necessarily falls to pulse-measurement devices, like Frequency-Resolved Optical Gating (FROG) and its variations, which have proven to be a highly reliable class of techniques for measuring stable trains of ultrashort laser pulses. Fortunately, multi-shot versions of FROG have also been shown to sensitively distinguish trains of stable from those of unstable pulse shapes by displaying readily visible systematic discrepancies between the measured and retrieved traces in the presence of unstable pulse trains. However, the effects of pulse-shape instability and algorithm stagnation can be indistinguishable, so a never-stagnating algorithm—even when instability is present—is required and is generally important. In previous work, we demonstrated that our recently introduced Retrieved-Amplitude N-grid Algorithmic (RANA) approach produces highly reliable (100%) pulse-retrieval in the second-harmonic-generation (SHG) version of FROG for thousands of sample trains of pulses with stable pulse shapes. Further, it does so even for trains of unstable pulse shapes and thus both reliably distinguishes between the two cases and provides a rough measure of the degree of instability as well as a reasonable estimate of most typical pulse parameters. Here, we perform the analogous study for the polarization-gating (PG) and transient-grating (TG) versions of FROG, which are often used for higher-energy pulse trains. We conclude that PG and TG FROG, coupled with the RANA approach, also provide reliable indicators of pulse-shape instability. In addition, for PG and TG FROG, the RANA approach provides an even better estimate of a typical pulse in an unstable pulse train than SHG FROG does, even in cases of significant pulse-shape instability. Full article

This study investigates the feasibility of using fiber Bragg grating (FBG) sensors for multipoint thermal monitoring of several power semiconductor devices (PSDs), such as insulated gate bipolar transistors (IGBTs), and rectifiers assembled on a common heatsink in a three-phase inverter. A novel approach is proposed to integrate FBG sensors beneath the baseplates of the IGBT modules, avoiding the need for invasive modifications to the device structure. By strategically positioning multiple FBG sensors, accurate temperature profiles of critical components can be obtained. The experimental results demonstrate the effectiveness of the proposed method, with the temperature measurements from FBG sensors closely matching those obtained using thermal infrared (IR) cameras within ±1.1 °C. This research highlights the potential of FBG sensors for reliable and precise thermal management in power electronic systems, contributing to improved performance and reliability. Full article

In multi-source fusion deformation-monitoring methods that utilize fiber Bragg grating (FBG) data and other data types, the lack of FBG constraint points in edge regions often results in inaccuracies in fusion results, thereby impacting the overall deformation-monitoring accuracy. This study proposes a multi-source fusion deformation-monitoring calibration method and develops a calibration model that integrates vision and FBG multi-source fusion data. The core of this model is a normal distribution transform (NDT)–convolutional neural network (CNN)–self-attention (SA) calibration network. This network enhances continuity between points in point clouds using the NDT module, thereby reducing outliers at the edges of the fusion results. Experimental validation shows that this method reduces the absolute error to below 0.2 mm between multi-source fusion calibration results and high-precision measured point clouds, with a confidence interval of 99%. The NDT-CNN-SA network offers significant advantages, with a performance improvement of 36.57% over the CNN network, 14.39% over the CNN–gated recurrent unit (GRU)–convolutional block attention module (CBAM) network, and 9.54% over the CNN–long short term memory (LSTM)–SA network, thereby demonstrating its superior generalization, accuracy, and robustness. This calibration method provides smoother and accurate structural deformation data, supports real-time deformation monitoring, and reduces the impact of assembly deviation on product quality and performance. Full article

Ultrathin titanium nitride (TiN) is a novel material platform for constructing active metasurfaces in the near-infrared region (NIR). Here, we realized tunable polarization-selective absorption by gating ultrathin TiN in an Ultrathin TiN Grating Metasurface (UTGM) and a gold resonator/TiN film Hybrid Metasurface (GTHM), respectively. The TM wave absorption (0.96) was much larger than that of the TE wave in the UTGM. When the carrier density decreased by 12%, the near-perfect TM absorption peak blue-shifted by 0.3 μm. Similarly, the linear dichroism (0.96) peak in GTHM blue-shifted by 0.12 μm when gating ultrathin TiN film. Active metasurfaces with tunable polarization-selective absorption have huge potential in dynamic integrated electro-optic devices in NIR. Full article

A fiber Bragg grating (FBG) pulse and systolic blood pressure (SBP) measurement system based on the edge-filtering method is proposed. The edge filter is the Mach–Zehnder interferometer (MZI) fabricated by two fiber couplers with a linear slope of 52.45 dBm/nm. The developed system consists of a broadband light source, an edge filter, fiber Bragg gratings (FBGs), a coarse wavelength-division multiplexer (CWDM), and signal-processing circuits based on a field-programmable gate array (FPGA). It can simultaneously measure pulse pulsations of the radial artery in the wrist at three positions: Cun, Guan and Chi. The SBP can be calculated based on the pulse transit time (PTT) principle. The measurement results compared to a standard blood pressure monitor showed the mean absolute error (MAE) and standard deviation (STD) of the SBP were 0.93 ± 3.13 mmHg. The system meets the requirements of the Association for the Advancement of Medical Instrumentation (AAMI) equipment standards. The proposed system can achieve continuous real-time measurement of pulse and SBP and has the advantages of fast detection speed, stable performance, and no compression sensation for subjects. The system has important application value in the fields of human health monitoring and medical device development. Full article

Absorption spectra of AlGaN/GaN grating-gate plasmonic crystals with a period from 1 µm to 2.5 µm were studied experimentally at T = 70 K using Fourier-transform infrared spectrometry. The plasmonic crystals exhibit distinct absorption lines of various plasmon harmonics across the 0.5 to 6 THz frequency range, tunable by gate voltage. Cumbersome and time-consuming electromagnetic simulations are usually needed to interpret or predict the grating-gate crystal spectra. In this work, we examine an analytical model and show that it can successfully describe the majority of existing experimental results. In this way, we demonstrate a new analytical platform for designing plasmonic crystals for THz filters, detectors, and amplifiers. Full article

The temperature and strain fields monitoring during the preparation process of buoyancy materials, as well as the health status after molding, are important for mastering the mechanical properties of buoyancy materials and ensuring the safety of operators and equipment. This paper proposes a short and high-density femtosecond fiber Bragg grating (fs-FBG) array based on different temperature coefficients fibers. By optimizing the parameters of femtosecond laser point-by-point writing technology, high-performance fs-FBG arrays with millimeter level gating length and millimeter level spatial resolution were prepared on two types of fibers. These were successfully embedded in buoyancy materials to achieve in-situ online monitoring of the curing process and after molding. The experimental results show that the fs-FBG array sensor has good anti-chirp performance and achieves online monitoring of millimeter-level spatial resolution. Intelligent buoyancy materials can provide real-time feedback on the health status of equipment in harsh underwater environments. The system can achieve temperature monitoring with an accuracy of 0.56 °C and deformation monitoring with sub-millimeter accuracy; the error is in the order of micrometers, which is of great significance in the field of deep-sea exploration. Full article

An asymmetric dual-grating gate bilayer graphene-based field effect transistor (ADGG-GFET) with an integrated bowtie antenna was fabricated and its response as a Terahertz (THz) detector was experimentally investigated. The device was cooled down to 4.5 K, and excited at different frequencies (0.15, 0.3 and 0.6 THz) using a THz solid-state source. The integration of the bowtie antenna allowed to obtain a substantial increase in the photocurrent response (up to 8 nA) of the device at the three studied frequencies as compared to similar transistors lacking the integrated antenna (1 nA). The photocurrent increase was observed for all the studied values of the bias voltage applied to both the top and back gates. Besides the action of the antenna that helps the coupling of THz radiation to the transistor channel, the observed enhancement by nearly one order of magnitude of the photoresponse is also related to the modulation of the hole and electron concentration profiles inside the transistor channel by the bias voltages imposed to the top and back gates. The creation of local n and p regions leads to the formation of homojuctions ($np$, $pn$ or $p{p}^{+}$) along the channel that strongly affects the overall photoresponse of the detector. Additionally, the bias of both back and top gates could induce an opening of the gap of the bilayer graphene channel that would also contribute to the photocurrent. Full article

This contribution quantifies the birefringence within injection-molded cyclic olefin copolymer plates and discusses its impact on the mechanical properties of the plates. It also focuses on the impact of birefringence on integrated waveguides and Bragg gratings and provides fabrication guidelines for such structures. The anisotropy in all three dimensions of the workpiece is examined by means of polarimetry and a prism coupler. It is found that the birefringence is inhomogenously distributed within the workpieces, whereas the maximum birefringence not only varies locally, but also depends on the observation direction. Overall, a maximum birefringence of 10 × 10⁻⁴ is found at the plate’s surface near the injection gate. The anisotropy then reduces exponentially towards the center of the workpiece and saturates at 1.8 × 10⁻⁴, in a depth of 0.4 mm. Thus, the birefringence strongly affects near-surface photonic structures. It is found that, depending on their orientation and the local birefringence of the substrate, waveguides and Bragg gratings fabricated with comparable parameters behave completely differently in terms of polarization-dependent optical attenuation, cross-sectional intensity distribution and Bragg reflection signal. For example, the support of the TM mode can vary between total loss and an optical attenuation of 0.9 dB × cm⁻¹. In consequence, this study underlines the importance of quantifying the birefringent state of an injection-molded cyclic olefin copolymer workpiece if it is supposed to serve as a substrate for integrated photonic structures. The study furthermore demonstrates that birefringence effects can be omitted by burying the photonic structures deeper into the volume of the thermoplastic. Full article

“Three straight and two flat” is the inevitable demand when realizing the intelligent mining of a fully mechanized mining face. To address the crucial technical issue of lacking accurate perception of the shape of the scraper conveyor during intelligent coal mining, a three-dimensional curvature sensor involving fiber Bragg grating (FBG) is used as a perceptive tool to conduct curve reconstruction research based on different local motion frames and to reconstruct the shape of the scraper conveyor. Firstly, the formation process of the ‘S’-shaped bending section of the scraper conveyor during the pushing process is determined. Based on the FBG sensing principle, a mathematical model between the variation in the central wavelength and the strain and curvature is established, and the cubic B-spline interpolation method is employed to continuously process the obtained discrete curvature. Secondly, based on differential geometry, a spatial curve reconstruction algorithm based on the Frenet moving frame is derived, and the shape curve prediction interpolation model is built based on a gated recurrent unit (GRU) model, which reduces the impact of the decrease in curve reconstruction accuracy caused by damage to some grating measuring points. Finally, an experimental platform was designed and built, and sensors with curvature radii of 6 m, 7 m, and 8 m were tested. The experimental results showed that the reconstructed curve was essentially consistent with the actual shape, and the absolute error at the end was about 2 mm. The feasibility of this reconstruction algorithm in engineering has been proven, and this is of great significance in achieving shape curve perception and straightness control for scraper conveyors. Full article

This paper introduces a new bidirectional integration approach that combines fiber sensor/free space optics (FSO) communication using an intensity and wavelength division multiplexer (IWDM) techniques-based long-distance fiber Bragg grating (FBG) sensor strain-sensing system. By implementing coarse wavelength division multiplexing (CWDM), the system achieves the simultaneous transmission of optical communication and fiber optical sensor (FOS) sensing signals, resulting in a highly capable, flexible, and cost-effective solution. The proposed FSO transmission technique addresses complex fiber cable installation concerns with topographical limitations. This bidirectional structure ensures the reliability and stability of the long-distance FBG sensor system, supported by extensive research and experimentation. A hybrid stacked gated recurrent units and long short-term memory (SGRU-LSTM) model is proposed to enhance strain measurement accuracy by predicting and measuring the central wavelength of overlapped strain-sensing FBG sensor signals. The results demonstrate the superiority of the proposed model in peak wavelength detection accuracy. The primary benefit of integrating communication and sensing is the significant reduction in construction costs by eliminating the requirement for two individual fiber optic systems, as the integration allows for a single system to fulfill both functions, resulting in more efficient and cost-effective implementation. Overall, this paper contributes to advancing long-distance FBG sensor systems by integrating fiber sensor/FSO communication and deep learning techniques, improving transmission distance, multiplexing capacity, measurement accuracy, system survivability, and cost-effectiveness. Full article

Recent advancements in power electronic switches provide effective control and operational stability of power grid systems. Junction temperature is a crucial parameter of power-switching semiconductor devices, which needs monitoring to facilitate reliable operation and thermal control of power electronics circuits and ensure reliable performance. Over the years, various junction temperature measurement techniques have been developed, engaging both non-optical and optical-based methods, highlighting their advancements and challenges. This review focuses on several optical sensing-based junction temperature measuring techniques used for power-switching devices such as metal-oxide-semiconductor field-effect transistors (MOSFETs) and insulated-gate bipolar transistors (IGBTs). A comprehensive summary of recent developments in infrared camera (IRC), thermal sensitive optical parameter (TSOP), and fiber Bragg grating (FBG) temperature sensing techniques is provided, shedding light on their merits and challenges while providing a few possible future solutions. In addition, calibration methods and remedies for obtaining accurate measurements are discussed, thus providing better insight and directions for future research. Full article

Borophene, an emerging two-dimensional (2D) material platform, is capable of supporting highly confined plasmonic modes in the visible and near-infrared wavebands. This provides a novel building block for light manipulation at the deep subwavelength scale, thus making it well-suited for designing ultracompact optical devices. Here, we theoretically explore a borophene-based plasmonic hybrid system comprising a continuous borophene monolayer (CBM) and sodium nanostrip gratings (SNGs), separated by a polymer spacer layer. In such a structure, a dynamically tunable plasmon-induced transparency (PIT) effect can be achieved by strongly coupling dark and bright plasmonic modes, while actively controlling borophene. Here, the bright mode is generated through the localized plasmon resonance of SNGs when directly excited by TM-polarized incident light. Meanwhile, the dark mode corresponds to a propagating borophene surface plasmon (BSP) mode in the CBM waveguide, which cannot be directly excited, but requires phase matching with the assistance of SNGs. The thickness of the polymer layer has a significant impact on the coupling strength of the two modes. Owing to the BSP mode, highly sensitive to variations in the ambient refractive index (RI), this borophene-based hybrid system exhibits a good RI-sensing performance (643.8 nm/RIU) associated with a wide range of dynamically adjustable wavebands (1420–2150 nm) by tuning the electron density of borophene. This work offers a novel concept for designing active plasmonic sensors dependent on electrically gating borophene, which has promising applications in next-generation point-of-care (PoC) biomedical diagnostic techniques. Full article

Nanocrystals’ (NCs) band gap can be easily tuned over the infrared range, making them appealing for the design of cost-effective sensors. Though their growth has reached a high level of maturity, their doping remains a poorly controlled parameter, raising the need for post-synthesis tuning strategies. As a result, phototransistor device geometry offers an interesting alternative to photoconductors, allowing carrier density control. Phototransistors based on NCs that target integrated infrared sensing have to (i) be compatible with low-temperature operation, (ii) avoid liquid handling, and (iii) enable large carrier density tuning. These constraints drive the search for innovative gate technologies beyond traditional dielectric or conventional liquid and ion gel electrolytes. Here, we explore lithium-ion glass gating and apply it to channels made of HgTe narrow band gap NCs. We demonstrate that this all-solid gate strategy is compatible with large capacitance up to 2 µF·cm⁻² and can be operated over a broad range of temperatures (130–300 K). Finally, we tackle an issue often faced by NC-based phototransistors:their low absorption; from a metallic grating structure, we combined two resonances and achieved high responsivity (10 A·W⁻¹ or an external quantum efficiency of 500%) over a broadband spectral range. Full article

In this study, the performance of a current sensor based on giant magnetostrictive materials (GMM) and fiber Bragg grating (FBG) has been improved by optimizing the spectral characteristics of gratings. By analyzing the influence of FBG on the current sensor characteristics, three key parameters (gate region length, refractive index modulation depth, and toe cutting system) are selected for optimization. The optimal grating parameters are determined to improve the linearity and sensitivity of sensor output. Experimental tests reveal that after grating optimization, the current sensor shows excellent performance parameters, including a linearity of 0.9942, sensitivity of 249.75 mV/A, and good stability in the temperature range of 0–60 °C. This research can provide a reference for improving the grating design and performance of existing GMM-FBG current sensors. Full article
