Search Results (68)

The artificial ground freezing method (AGF) is widely used in underground construction to reinforce the ground and ensure construction safety. This study systematically evaluates the implementation of the artificial ground freezing method in the construction of a metro tunnel cross-passage, with a focus on analyzing the soil’s thermo-mechanical behavior and assessing safety performance throughout the construction process. A combined approach integrating field monitoring and refined three-dimensional numerical simulation using FLAC3D is adopted, considering critical factors, such as freezing pipe inclination, thermo-mechanical coupling, and ice–water phase transitions. Both field data and simulation results demonstrate that increasing the density of freezing pipes accelerates temperature reduction and intensifies frost heave-induced displacements near the pipes. After 45 days of active freezing, the freezing curtain reaches a thickness of 3.7 m with an average temperature below −10 °C. Extending the freezing duration beyond this period yields negligible improvement in curtain performance. Frost heave deformation develops rapidly during the initial phase and stabilizes after approximately 25 days, with maximum vertical displacements reaching 12 cm. Significant stress concentrations occur in the soil adjacent to the freezing pipes, with shield tunnel segments experiencing up to 5 MPa of stress. Thaw settlement is primarily concentrated in areas previously affected by frost heave, with a maximum settlement of 3 cm. Even after 45 days of natural thawing, a frozen curtain approximately 3.3 m thick remains intact, maintaining sufficient structural strength. The refined numerical model accurately captures the mechanical response of soil during the freezing and thawing processes under realistic engineering conditions, with field monitoring data validating its effectiveness. This research provides valuable guidance for managing construction risks and ensuring safety in similar cross-passage and cross-river tunnel projects, with broader implications for underground engineering requiring precise control of frost heave and thaw settlement. Full article

Integrating ejectors into CO₂ transcritical refrigeration systems to reduce energy consumption has been performed successfully throughout the industry in recent years. The objective of the present work is to investigate the effect of indoor and outdoor operating conditions on the energy efficiency of ejector expansion supermarket refrigeration plants. The analysis uses the measured energy consumptions and loads for two supermarket refrigeration plants operating in two cities in the Republic of Moldova (Chisinau and Balti). A model for the prediction of the plant’s annual energy consumption and the loads of the refrigeration and freezing compressors is developed using experimental results. Although there are theoretical and experimental analyses of the investigated systems in the specialized literature, no studies were found in the specialized literature regarding energy consumption increase due to pressure losses through the pipe route in transcritical CO₂ refrigeration installations with an ejector for supermarkets. The results indicate that refrigeration compressors have a greater increase in energy consumption than freezing compressors with increases in the outdoor temperature. The study shows that the additional drop in evaporating pressure at the compressor rack due to incorrect sizing of the pipe route leads to higher energy consumption compared to what the same plant would consume if the pipe route were correctly sized and executed. For every one-degree increase in temperature loss due to additional pressure drop through the pipeline, the entire plant consumes around 1.5% more energy. Knowledge of these performance data of real systems provides designers and manufacturers with clues to understand the importance of the correct design of the pipe route to obtain maximum energy efficiency. Full article

Frost heave in seasonally frozen soil surrounding natural gas pipelines (NGPs) can cause severe damage to adjacent infrastructure, including road surfaces and buildings. Based on the stratigraphic characteristics of seasonal frozen soil in Beijing, a soil–natural gas pipeline–heat pipe heat transfer model was developed to investigate the mitigation effect of the soil-freezing phenomenon by transferring shallow geothermal energy utilizing heat pipes. Results reveal that heat pipe configurations (distance, inclination angle, etc.) significantly affect soil temperature distribution and the soil frost heave mitigation effect. When the distance between the heat pipe wall and the NGP wall reaches 200 mm, or when the inclined angle between the heat pipe axis and the model centerline is 15°, the soil temperature above the NGP increases by 9.7 K and 17.7 K, respectively, demonstrating effective mitigation of the soil frost heave problem. In the range of 2500–40,000 W/(m·K), the thermal conductivity of heat pipes substantially impacts heat transfer efficiency, but the efficiency improvement plateaus beyond 20,000 W/(m·K). Furthermore, adding fins to the heat pipe condensation sections elevates local soil temperature peaks above the NGP to 274.2 K, which is 5.5 K higher than that without fins, indicating enhanced heat transfer performance. These findings show that utilizing heat pipes to transfer shallow geothermal energy can significantly raise soil temperatures above the NGP and effectively mitigate the soil frost heave problem, providing theoretical support for the practical applications of heat pipes in soil frost heave management. Full article

This article describes a robust Gaussian Prior process state space modeling (GPSSM) approach to assess the impact of an intervention in a time series. Numerous applications can benefit from this approach. Examples include: (1) time series could be the stock price of a company and the intervention could be the acquisition of another company; (2) the time series under concern could be the noise coming out of an engine, and the intervention could be a corrective step taken to reduce the noise; (3) the time series could be the number of visits to a web service, and the intervention is changes done to the user interface; and so on. The approach we describe in this article applies to any times series and intervention combination. It is well known that Gaussian process (GP) prior models provide flexibility by placing a non-parametric prior on the functional form of the model. While GPSSMs enable us to model a time series in a state space framework by placing a Gaussian Process (GP) prior over the state transition function, probabilistic recurrent state space models (PRSSM) employ variational approximations for handling complicated posterior distributions in GPSSMs. The robust PRSSMs (R-PRSSMs) discussed in this article assume a scale mixture of normal distributions instead of the usually proposed normal distribution. This assumption will accommodate heavy-tailed behavior or anomalous observations in the time series. On any exogenous intervention, we use R-PRSSM for Bayesian fitting and forecasting of the IoT time series. By comparing forecasts with the future internal temperature observations, we can assess with a high level of confidence the impact of an intervention. The techniques presented in this paper are very generic and apply to any time series and intervention combination. To illustrate our techniques clearly, we employ a concrete example. The time series of interest will be an Internet of Things (IoT) stream of internal temperatures measured by an insurance firm to address the risk of pipe-freeze hazard in a building. We treat the pipe-freeze hazard alert as an exogenous intervention. A comparison of forecasts and the future observed temperatures will be utilized to assess whether an alerted customer took preventive action to prevent pipe-freeze loss. Full article

This paper investigates the frost heave and thaw settlement characteristics of the pipe–soil system during the freeze–thaw cycle, along with the underlying mechanisms. A numerical simulation platform for the complex pipe–soil system was developed using the heat conduction equation, moisture migration equation, and stress–strain equation, all of which account for the ice–water phase change process. The simulations were performed with the coefficient-type partial differential equation (PDE) module in COMSOL Multiphysics. By employing coupled thermal–hydraulic–mechanical (THM) simulation methods, the study analyzed the changes in volumetric water content, volumetric ice content, moisture migration patterns, and temperature field distribution of a water pipeline after three years of service under real engineering conditions in the cold region of northern Xinjiang, China. The study also examined the effects of parameters such as pipeline burial depth, specific heat capacity, thermal conductivity, permeability of saturated soil, and initial saturation on the displacement field. The results show that selecting soil layers with high specific heat capacity (e.g., 1.68 kJ/kg·°C) and materials with high thermal conductivity (e.g., 2.25 W/m·°C) can reduce surface frost heave displacement by up to 40.8% compared to low-conductivity conditions. The maximum freezing depth near the pipeline is limited to 0.87 m due to the thermal buffering effect of water flow. This research provides a scientific reference and theoretical foundation for the design of frost heave resistance in water pipelines in seasonally frozen regions. Full article

The rapid development of urban transportation renovation and transportation networks in China has driven the construction of an increasing number of large-span, large cross-section tunnels under sensitive environments, such as airport runways, critical infrastructure, and high-speed railways. These projects often require strict settlement control within a millimeter-level tolerance range, thus theoretical methods and key technologies for micro-settlement control have been developed. This study first derives a calculation formula for surface settlement associated with large cross-section tunnels and elucidates its correlations with factors such as pipe-roof stiffness, support system stiffness, pipe-roof construction procedures, and groundwater level changes. Theoretical approaches for controlling micro-settlement are introduced, including increasing pipe-roof stiffness, reinforcing the support system, mitigating group pipe effects, maintaining pressure and reducing resistance around the pipe, and controlling groundwater levels. A method is proposed for determining the appropriate stiffness of the pipe roof and support system. The stiffness should be selected from the transition segment between the steep decline and the gentle slope on the stiffness-settlement curves of the pipe roof and the support system. If the stiffness of the pipe roof and primary support combined with temporary support fails to meet the micro-settlement control requirements, an integrated support system with greater stiffness can be adopted. A reasonable pressure-regulating grouting technique for maintaining pressure and reducing resistance around the pipe is proposed. It is recommended that the spacing for simultaneous jacking of pipes be greater than half the width of the settlement trough. For over-consolidation-sensitive strata such as medium or coarse sands, water-blocking measures, including freezing, grouting, or a combination of both, are recommended. For over-consolidation-insensitive strata like gravels and cobbles with strong permeability, water-blocking treatments are generally unnecessary. The proposed theoretical approaches have been successfully implemented in projects such as the tunnel beneath Beijing Capital Airport runways and Taiyuan Railway Station, demonstrating their reliability. The research findings provide valuable insights into surface micro-settlement control for similar projects. Full article

In cold regions, fire pipes are highly susceptible to freezing, which can obstruct water flow and lead to pipe ruptures. Accurately predicting the freeze thickness is crucial to maintaining the functionality of fire protection systems. Traditional methods for predicting fire pipe freezing often rely on simplified models or time-consuming simulations, which limits their accuracy in complex environments. A model for predicting the freeze thickness of fire pipes under low-temperature conditions was developed by integrating Computational Fluid Dynamics with an Artificial Neural Network (ANN). The CFD model was validated to generate data for training and optimizing an ANN based on collected experimental data. The CFD results demonstrate a nonlinear relationship between the freeze thickness of the fire pipe, ambient temperature, and time. Afterwards, the optimal ANN topology, determined through hyperparameter tuning, was found to consist of 12 neurons, the trainlm training function, and tansig–purelin activation functions. Eventually, the ANN model achieved high prediction accuracy with a mean squared error (MSE) of 6.62 × 10⁻⁴ on the test set and a regression coefficient R greater than 0.98 across all datasets. Furthermore, the ANN model agrees closely with the simulated data, not only for trained temperature conditions (−5 °C to −50 °C) but also for unseen temperature conditions (−55 °C and −60 °C), indicating excellent generalization performance. Full article

Taking the Sanya River Mouth Channel project as a case study, this research explores the minimum brine temperature required for the pipe-jacking freezing method during staged freezing. Based on the heat transfer theory of porous media, a three-dimensional model of the actual working conditions was established using COMSOL 6.1 finite element software. By adjusting the brine cooling scheme, the development and distribution patterns of the freezing curtain under different brine temperatures were analyzed. The results indicate that as the staged freezing brine temperature increases, the thickness of the freezing curtain decreases linearly, and the closure of isotherms is inhibited. When the brine temperature is −8 °C, the thickness of the freezing curtain meets the minimum requirement and effectively achieves the freezing effect under both low and high seepage flow conditions. Additionally, seepage significantly affects the formation of the freezing curtain, causing it to shift towards the direction of seepage, with the degree of shift becoming more pronounced as the seepage velocity increases. When the seepage velocity is so high that the thickness of the freezing curtain on one side is less than 2 m, the impact of seepage on the freezing curtain can be reduced by decreasing the hydraulic head difference in the freezing area or by increasing the arrangement of freezing pipes, thereby enhancing the freezing effect. Full article

This study investigates the application of pipe freeze crystallization (PFC) as a sustainable, zero-waste technology for treating high-salinity industrial wastewater, enabling the simultaneous recovery of salts and clean water. PFC addresses the limitations of traditional brine treatment methods such as evaporation ponds and distillation, which are energy-intensive, produce concentrated brine requiring disposal, and emit significant CO₂. A pilot demonstration plant in Olifantsfontein, South Africa, served as the basis for this research. The plant operates at an energy consumption rate of 330 kJ/kg, significantly lower than distillation’s 2200 kJ/kg. It efficiently recovers high-purity Na₂SO₄ and clean ice, which can be reused as water, with plans underway to incorporate NaCl recovery. Comparative analyses highlight PFC’s energy efficiency and reduced CO₂ emissions, achieving an 82% reduction in greenhouse gas emissions compared to evaporation-based methods. This study evaluates the operational parameters and scalability of PFC for broader industrial applications. X-ray Diffraction analysis confirmed that the Na₂SO₄ recovered from the pilot plant achieved a purity level of 84.9%, demonstrating the process’s capability to produce valuable, market-ready by-products. These findings reinforce PFC’s potential as a cost-effective and environmentally sustainable alternative to conventional methods. PFC offers a transformative solution for managing saline effluents, aligning with zero-waste objectives and contributing to reduced environmental impact. This technology provides industries with an economically viable solution for resource recovery while supporting compliance with stringent environmental regulations. Full article

Managing high-salinity industrial wastewater poses environmental and operational challenges, particularly in recovering valuable salts like Na₂SO₄. Traditional methods such as evaporation and distillation are energy-intensive (2200 kJ/kg) and environmentally unsustainable. Addressing these limitations, this study investigates the application and optimisation of pipe freeze-crystallization (PFC), an innovative, energy efficient technology operating at 330 kJ/kg, to achieve zero-waste treatment objectives. This research used OLI ESP software to model the crystallization dynamics, accurately predicting Na₂SO₄ recovery and reductions in sulphate concentrations from 74.3 g/L to 6.9 g/L at temperatures below −2 °C. The recovered Na₂SO₄ was analysed using X-ray diffraction with its purity increasing over the years from 50% to 84.9%. Over a four-year operational period at a demonstration plant in Olifantsfontein, South Africa, modifications including extending pipe length from 90 m to 120 m and increasing pipe diameter from 20 mm to 25 mm improved salt recovery rates from 3.5 t/month to 9.1 t/month. Enhanced chiller performance sustained sub-zero temperatures, achieving a cooling capacity of 7 kW while enabling consistent salt and ice recovery. Results showed that feedwater composition substantially influenced crystallization dynamics, with high NaCl concentrations delaying Na₂SO₄ crystallization. The plant’s adaptability to diverse feedwaters and scalability for broader industrial applications highlights its potential as a cost-effective solution. These findings establish PFC as a transformative technology for sustainable saline wastewater treatment, offering industry compliance with environmental regulations, and economic benefits through resource recovery. Full article

The artificial freezing construction technology, compared to other methods, offers several advantages, including superior waterproofing capabilities and the absence of environmental pollution. This technique is particularly prevalent in the construction of tunnels in challenging environments, where the dynamics of the freezing temperature field during the freezing process have consistently been a key area of interest during actual construction activities. In the Sanya Estuary Channel Submarine Tunnel Project, a three-dimensional transient model was developed using COMSOL finite element software to deeply analyze the formation and temperature distribution of the permafrost curtain. Two alternative schemes were designed to improve the original design by optimizing the layout of the permafrost pipeline. Comparative analysis shows that the isotherm −10 °C intersected at 14 days in the original scheme, 23 days in Optimized Scheme 1, and 24 days in Optimized Scheme 2, indicating a 10-day delay in Scheme 2 versus the original, yet still meeting the 25-day deadline. After 40 days of active freezing, the greatest difference in permafrost curtain thickness was observed at the east wall (downstream), with Scheme 2 differing by 1.05 m from the original and by 0.23 m from Scheme 1. Scheme 2 achieved an average permafrost curtain thickness of 4.18 m around the tunnel, exceeding the 3.5-m design requirement. The mean temperatures in the strong and weak freezing zones of Scheme 2 were below −10 °C and −8 °C, respectively, aligning with design standards. Given the conservative nature of the initial plan, Optimized Scheme 2 is highly practical for implementation and offers significant cost savings. Full article

Recent advancements in underground construction have led to the widespread utilization of pipe jacking. However, the engineering challenges posed by frozen ground in pipe jacking projects have not been extensively studied. This research aims to address the critical challenges linked to employing pipe jacking in frozen ground for underground construction. It is widely recognized that the accurate calculation of jacking thrust and mitigation of pipe–soil interaction plays a crucial role in determining the success or failure of pipe jacking operations. To explore these issues, this study conducted numerical simulations and comparative analyses, considering various factors such as soil properties, geometric dimensions, and burial depth, to assess their influence on jacking thrust. Additionally, the study also examines the freeze–thaw effect on concrete pipes and the injected lubricant. The results indicate that the numerical model, which considers the temperature effects and static friction instead of sliding friction, provides a more reliable estimation of jacking thrust in frozen ground compared to traditional theoretical models. Furthermore, the freezing point depression method was successfully employed in the development of an anti-freezing lubricant, which can effectively reduce pipe–soil interaction even at extremely low temperatures of up to −10 °C. Full article

In order to study the development law of the irregular hole freezing temperature field, combined with the shield solution project of the Nanjing Water Supply Corridor, the distribution characteristics and influencing factors of the irregular freezing temperature field of the river bottom shield machine are studied by numerical simulation. The following conclusions are obtained: (1) The extension length of the outer ring pipe is correlated approximately positively with the thickness and average temperature of the freezing wall at the bottom of the cup. The thickness increases by 0.25 m, and the average temperature decreases by 1.25 °C for every 1 m increase in the extension length. (2) The intersection time decreases logarithmically with the increase in the extension length of the outer ring tube. (3) As the ratio of the axial angle between the two adjacent tubes in the weak area of the outer ring tube becomes larger, the temperature of the weak point in the center of the two tubes increases approximately linearly. The midpoint temperature of the two tubes increases by 3.3 °C for every 1 increase in the angle coefficient. (4) With the increase in the opening angle of the inner ring hole, the thickness and average temperature change, respectively, at 150 d are not more than 0.15 m and 0.6 °C. The results show that under the irregular freezing form, the angle and length of the outer ring pipe have a great influence on the temperature field, and the angle of the inner ring pipe has little influence on the final distribution of the temperature field. The average temperature and the temperature distribution of the weak points show a trend of decreasing first and then increasing along the shield advancing direction, reaching a minimum near the cutterhead. Full article

Nuclear energy, as an important component of the power system, has become a key focus of future energy development research. Various equipment and pipelines in nuclear power plants require regular inspection, maintenance, and repair. The pipelines in nuclear power plants are typically large, necessitating a device that can locally isolate sections of the pipeline during maintenance operations. Ice plug freezing technology, an economical and efficient method for maintaining and replacing equipment without shutdown, has been widely applied in nuclear power plants. The structure of the ice plug jacket, a type of low-temperature jacket heat exchanger, affects the flow path of the working fluid within the jacket and consequently impacts heat transfer. This study utilizes Computational Fluid Dynamics (CFD) to establish five types of jacket structures: standard, center-offset (center-in, side-out), helical, helical fin, and labyrinth. The effects of different structures on the freezing characteristics of ice plugs are analyzed and compared. The research indicates that the labyrinth jacket enhances the heat transfer performance between liquid nitrogen and the liquid inside the pipe, forming a larger ice layer at the same liquid nitrogen flow rate. Additionally, the standard jacket has the shortest sealing time at high liquid nitrogen flow rates. Full article

In this paper, the freezing and strengthening project of the Sanya estuary tunnel is analyzed, which is facilitated by the use of the partial differential equation (PDE) module in COMSOL Multiphysics software. The solid–liquid ratio is utilized as the water–heat coupling term, and the solid mechanics module is introduced to achieve three-field coupling. Numerical simulations are conducted to study changes in the temperature field, moisture field, and vertical displacement due to freezing and expansion in the most unfavorable soil layer during the freezing process. The results indicate that a complete freezing curtain forms around the 30th day. The distribution of freezing pipes significantly influences the freezing effect. The strong freezing zone is characterized by a high cooling rate and rapid water content reduction with the opposite trends being observed in the weak freezing zone. Upon completion of the freezing process, a large uplift of the ground surface is observed with more pronounced vertical displacement changes in areas affected by temperature and phase changes. The maximum vertical displacement of the ground surface deviates from the center position. While the frozen soil curtain meets the design requirements for freezing, the effects of freezing and expansion should be taken into account. These findings could be instrumental in elaborating the most effective freezing and expansion control measures for areas with powdery clay-based layers in AGF-based projects. Full article
