Search Results (40)

This study investigates the dimensional synthesis of steering mechanisms for front-wheel-drive, two-axle, four-wheeled vehicles using two metaheuristic optimization algorithms: Differential Evolution with golden ratio (DE-gr) and Improved Particle Swarm Optimization (IPSO). The vehicle under consideration has a track-to-wheelbase ratio of 0.5 and an inner wheel steering angle of 70 degrees. The mechanisms synthesized include the Ackermann steering mechanism and two variants (Type I and Type II) of the Watt-I six-bar steering mechanisms, also known as central-lever steering mechanisms. To ensure accurate steering and minimize tire wear during cornering, adherence to the Ackermann steering condition is enforced. The objective function combines the mean squared structural error at selected steering positions with a penalty term for violations of the Grashoff inequality constraint. Each optimization run involved 100 or 200 iterations, with numerical experiments repeated 100 times to ensure robustness. Kinematic simulations were conducted in ADAMS v2015 to visualize and validate the synthesized mechanisms. Performance was evaluated based on maximum structural error (steering accuracy) and mechanical advantage (transmission efficiency). The results indicate that the optimized Watt-I six-bar steering mechanisms outperform the Ackermann mechanism in terms of steering accuracy. Among the Watt-I variants, the Type II designs demonstrated superior performance and convergence precision compared to the Type I designs, as well as improved results compared to prior studies. Additionally, the optimal Type I-2 and Type II-2 mechanisms consist of two symmetric Grashof mechanisms, can be classified as non-Ackermann-like steering mechanisms. Both optimization methods proved easy to implement and showed reliable, efficient convergence. The DE-gr algorithm exhibited slightly superior overall performance, achieving optimal solutions in seven cases compared to four for the IPSO method. Full article

Aiming at the problems of energy utilization efficiency and braking stability in electric vehicles, a high-efficiency and energy-saving control strategy that takes both driving and braking into account is proposed with the distributed hub motor-driven vehicle as the research object. Under regular driving and braking conditions, the front and rear axle torque distribution coefficients are optimized by an adaptive particle swarm algorithm based on simulated annealing and a multi-objective co-optimization strategy based on variable weight coefficients, respectively. During emergency braking, the anti-lock braking strategy (ABS) based on sliding mode control realizes the independent distribution of torque among four wheels. The joint simulation verification based on MATLAB R2023a/Simulink-Carsim 2020.0 shows that under World Light Vehicle Test Cycle (WLTC) conditions, the optimization strategy reduces the driving energy consumption by 3.20% and 2.00%, respectively, compared with the average allocation and the traditional strategy. The braking recovery energy increases by 4.07% compared with the fixed proportion allocation, improving the energy utilization rate of the entire vehicle. The wheel slip rate can be quickly stabilized near the optimal value during emergency braking under different adhesion coefficients, which ensures the braking stability of the vehicle. The effectiveness of the strategy is verified. Full article

A friction loss model for a loading brake tester with adjusted shaft distance was constructed to correct the test results of the braking rate of the loading shaft, which could largely improve the accuracy of automobile braking performance tests. Specifically, the influence of tire pressure, vehicle axle load, placement angle, and vehicle speed on the friction loss was tested and analyzed on the tester. The friction loss model for the tester was constructed based on the first defined relative slip and placement angle, which was validated through actual tests on four types of vehicles. The results showed that the maximum relative error between the simulation and the measured values is 2.2%, indicating the friction loss model is valid and can provide a basis for correcting the braking force of automobile brakes. Meanwhile, the maximum braking force increased from 3982 N to 4772 N, increased by 19.8%, when the placement angle was raised from 36.9° to 47.0°, demonstrating the effectiveness of constructing a friction loss model and enhancing the accuracy of the loading brake tester with adjusted shaft distance test results. Accordingly, in order to improve the detection accuracy of the self-developed tester, the friction loss model is essential for correcting the friction loss caused by the change in the placement angle, and then the braking rate of the vehicle should be determined according to the relevant regulations stipulated in China, EU, USA, Japan, and other countries or regions, which can accurately reflect the performance of the vehicle’s braking system. Full article

This study employs four metaheuristic optimization methods to optimize the dimensional synthesis of Ackermann steering mechanisms for three-axle, six-wheeled vehicles with front-axle steering mode and reverse-phase steering mode. The employed optimization methods include Particle Swarm Optimization (PSO), Hybrid Particle Swarm Optimization (HPSO), Differential Evolution with golden ratio (DE-gr), and Linearly Ensemble of Parameters and Mutation Strategies in Differential Evolution (L-EPSDE). With a front-wheel steering angle range of 70 degrees, two hundred optimization experiments were conducted for each method, and statistical analyses revealed that DE-gr and L-EPSDE methods outperformed PSO and HPSO methods in terms of standard deviation, mean value, and minimum error. These two methods exhibited superior convergence stability, faster convergence, and higher accuracy compared to PSO and HPSO. Reverse-phase (K = 1) steering mode outperformed front-axle steering mode, delivering reduced steering errors and turning radii. Considering the transmission ratio of front to rear axle (K) as a design variable in reverse-phase steering mode increased design flexibility and significantly lowered steering errors for the front and rear axle steering mechanisms. However, this comes with a slight increase in the turning radius of the vehicle’s front part compared to when K = 1. The optimized mechanism, designed using the DE-gr method, was validated through kinematic simulations and steering analyses using MSC-ADAMS v2015 software, further confirming the effectiveness and reliability of the proposed design. Full article

This paper focuses on a comprehensive study of a four-axle vehicle, including dynamics analysis, equivalent modeling methods, and their comparison. Firstly, a linear two-degree lateral dynamic model is established, which has four drive axles and two steer axles. Secondly, the mathematical transfer function expressions for the yaw rate and the centroid sideslip angle were derived on the basis of the model. The steady-state parameters, such as yaw rate gain G_γss, centroid sideslip angle gain G_βss, stability factor K_n, equivalent axial distance l_n, and equivalent centroid sideslip angle coefficient K_n’ were obtained by using the transfer functions. Then, the steady-state and transient characteristics are roundly discussed, including steady-state parameters, system root trajectory, frequency domain, and time domain. Some recommendations for the four-axle vehicle’s parameter design are also given. Finally, for a more simple and efficient analysis of response characteristics of four-axle vehicles and even n (n > 4) axle vehicles, the equivalent model is developed for the four-axle vehicle, and comprehensive analyses are presented with four equalization methods, which are based on the inner heart of the approximation triangle, the outer heart of the approximation triangle, the center of gravity of the approximation triangle and the compensation point. Following a thorough analysis of the four, it is determined that the inner approximation triangle solution approach is most suited for four-axle vehicles. Full article

Highways, urban roads, and bridges are the important transportation infrastructures for the economic development of modern society. The evaluation of bridge and road quality is crucial to the maintenance and management of the bridge and road industry. Road roughness is a widely accepted indicator in the evaluation of road quality and safety, which is a major input source for vehicles. The vehicle responses-based method of identifying road roughness is efficient and convenient. However, the dynamic characteristics of the vehicle have an important impact on the interaction between the vehicle and the road. When the vehicle parameters are not yet clear, the coupling of unknown parameters and unknown road roughness results in the need for mutual iteration when the existing methods simultaneously identify vehicle parameters and road roughness. To address this issue, this study proposes an effective method for the combined identification of vehicle parameters and road roughness using vehicle responses. The test vehicle is modeled as a four-degree-of-freedom half-vehicle model. In view of the coupling effect between tire stiffness and road roughness, the unknown vehicle physical parameters, except for tire stiffness, are first included in the extended state vector. Based on the extended Kalman filter for unknown excitation (EKF-UI), unknown vehicle physical parameters and unknown forces on the axle are identified. Subsequently, based on the property that the front and rear axles of the vehicle pass through the same road roughness area at a fixed time lag, the tire stiffness is identified by combining the identified unknown forces on the axle. Finally, the road roughness is obtained using the identified vehicle parameters and unknown forces. Numerical studies with different levels of roughness, different noise levels, and different vehicle speeds have verified the accuracy of this method in identifying vehicle parameters and road roughness. Full article

As interest in eco-friendly work vehicles grows, research on the powertrains of eco-friendly tractors has increased, including research on the development of eco-friendly vehicles (tractors) using hydrogen fuel cell power packs and batteries. However, batteries require a long time to charge and have a short operating time due to their low energy efficiency compared with hydrogen fuel cell power packs. Therefore, recent studies have focused on the development of tractors using hydrogen fuel cell power packs; however, there is a lack of research on powertrain performance analysis considering actual working conditions. To evaluate vehicle performance, an actual load measurement during agricultural operation must be conducted. The objective of this study was to conduct an efficiency analysis of powertrains according to their power source using data measured during agricultural operations. A performance evaluation with respect to efficiency was performed through comparison and an analysis with internal combustion engine tractors of the same level. The specifications of the transmission for hydrogen fuel cell and engine tractors were used in this study. The power loss and efficiency of the transmission were calculated using ISO 14179-1 equations, as shown below. Plow tillage and rotary tillage operations were conducted for data measurement. The measurement system consists of four components. The engine data load measurement was calculated using the vehicle’s controller area network (CAN) data, the axle load was measured using an axle torque meter and proximity sensors, and fuel consumption was measured using the sensor installed on the fuel line. The calculated capacities, considering the engine’s fuel efficiency for plow and rotary tillage operations, were 131.2 and 175.1 kWh, respectively. The capacity of the required power, considering the powertrain’s efficiency for hydrogen fuel cell tractors with respect to plow and rotary tillage operations, was calculated using the efficiency of the motor, inverter, and power pack, and 51.3 and 62.9 kWh were the values obtained, respectively. Considering these factors, the engine exhibited an efficiency of about 47.9% compared with the power pack in the case of plow tillage operations, and the engine exhibited an efficiency of about 29.3% in the case of rotary tillage operations. A hydrogen fuel cell tractor is considered suitable for high-efficiency and eco-friendly vehicles because it can operate on eco-friendly power sources while providing the advantages of a motor. Full article

In asphalt pavement structure design, traffic axle loads and pavement layer temperatures are crucial factors affecting fatigue damage calculations. To investigate the differences in fatigue damage calculations caused by different characterizations of traffic axle loads and temperature, fatigue damage calculations were conducted under equivalent standard axle loads (ESALs), axle load spectra (ALS), constant temperatures, and seasonal temperature variations using the field data from an expressway in Shandong Province, China under seven calculation plans. The results indicated: (1) the annual traffic composition is dominated by vehicle Type 9, with a proportion of about 43% in all the vehicle types, and its load level is also high, with a proportion about of 80% in the heavy load interval at all axle types; (2) The ESALs method underestimates the actual fatigue damage incurred in asphalt pavement by 6.04 times, with an accumulated damage of 2.34 × 10⁻⁹ (ESALs), 1.69 × 10⁻⁸ (ALS), respectively; (3) The fatigue damage results from a single month with consistent temperature showed similar trends, with an accumulated damage of 1.50 × 10⁻⁵, 9.07 × 10⁻⁵, respectively; (4) The cumulative fatigue damage calculated using the ALS method across the four seasons, respectively, is 6.51, 5.88, 6.42, and 4.60 times that of the fatigue damage calculated using the ESALs method. Although the ratio of fatigue damage between the two characterizations of traffic axle loads remains consistent, which is 6.04, the fatigue damage calculation that accounts for temperature variations can reveal seasonal trends in fatigue damage development. Based on the axle load spectra and considering temperature variations, fatigue damage calculation will be more closely related to the actual service state of asphalt pavement. These research findings provide insights for estimating asphalt pavement fatigue damage to some extent. Full article

This paper deals with the phenomenon of torsion oscillations in railway vehicle drive systems. The main goal is to reduce the risk of presence of torsional oscillations in wheelset drive, eventually to propose systems to effectively identify and eliminate torsional oscillations of wheelsets. Therefore, a simulation wheelset drive model including a detailed model of the asynchronous traction motor control was built. The results of computer simulations show that the torsional oscillations can be effectively eliminated by avoiding the resonance states between the excitation frequencies given by pulse width modulation of the inverter and the eigenfrequencies of the mechanical part of the drive. Furthermore, it was found that the presence of torsional oscillations of the wheels can be detected based on the traction motor current ripple. The wheelset drive model was subsequently implemented in a simulation model of a four-axle locomotive. A new algorithm of an anti-slip protection system that utilizes motor currents was implemented in the model. Simulations show that such an anti-slip protection system can prevent the occurrence of undesired large amplitude of wheelset torsional oscillations. The models and simulation results are presented in detail in the paper. Full article

In recent years, the increased use of heavy commercial vehicles with higher axle weights has required the development of innovative technologies to improve the mechanical properties of asphalt concrete conglomerates, such as fatigue resistance and rutting. This study offers a comprehensive comparative analysis of different types of asphalt concrete tested in four trial sections (S1, S2, S3, S4) of the SP3 Ardeatina rural road in Rome, under actual traffic and operational conditions. More precisely, the pavement technologies applied include modified asphalt concrete with graphene and recycled hard plastics for S1, asphalt concrete modified with styrene–butadiene–styrene (SBS) for S2, asphalt concrete with a standard polymeric compound for S3, and traditional asphalt concrete for S4. The evaluation approach involved visual inspections in order to calculate the pavement condition index (PCI) and falling weight deflectometer (FWD) tests. In addition, back-calculation analyses were performed using ELMOD software to assess the mechanical properties. The laboratory tests revealed superior properties of M1 in terms of its resistance to permanent deformations (+13%, +15%, and +19.5% compared to M2, M3, and M4, respectively) and stiffness (10,758 MPa for M1 vs. 9259 MPa, 7643 MPa, and 7289 MPa for M2, M3, and M4, respectively). These findings were further corroborated by the PCI values (PCI_S1 = 65; PCI_S2 = 17; PCI_S3 = 28; PCI_S4 = 29) as well as the FWD test results after 5 years of investigation, which suggests greater durability and resistance than the other sections. Full article

The study aims to improve the technique of motion planning for all-wheel drive (AWD) autonomous vehicles (AVs) by including torque vectoring (TV) models and extended physical constraints. Four schemes for realizing the TV drive were considered: with braking internal wheels, using a rear-axle sport differential (SD), with braking front internal wheel and rear-axle SD, and with SDs on both axles. The mathematical model combines 2.5D vehicle dynamics model and a simplified drivetrain model with the self-locking central differential. The inverse approach implies optimizing the distribution of kinematic parameters by imposing a set of constraints. The optimization procedure uses the sequential quadratic programming (SQP) technique for the nonlinear constrained minimization. The Gaussian N-point quadrature scheme provides numerical integration. The distribution of control parameters (torque, braking moments, SDs’ friction moment) is performed by evaluating linear and nonlinear algebraic equations inside of optimization. The technique proposed demonstrates an essential difference between forecasts built with a pure kinematic model and those considering the vehicle’s drive/control features. Therefore, this approach contributes to the predictive accuracy and widening model properties by increasing the number of references, including for actuators and mechanisms. Full article

An accurate power loss prediction in the gearbox is desirable for improving vehicle efficiency. To achieve this objective, evaluating the power loss is necessary. However, power loss is influenced by factors such as the gearbox structure, operating conditions, and gear oil formulation, making power loss evaluation a bottleneck in practice. Therefore, a systematic modeling methodology was developed to evaluate the gearbox power loss in an E-Axle that focuses on the influence of the gear oil factors in the load and no-load cases. The gearbox used in a light-duty truck E-Axle was tested to verify the proposed model. The test was performed under various operating speeds, input loads, and oil temperatures, and four types of gear oil with different formulations were also included to quantify their influence on the power loss. The results showed that the gearbox power loss was significantly influenced by the E-Axle operating conditions, oil temperatures, and different gear oil formulations, promoting different power losses. The comparison results showed good consistency between the predicted power loss and the measured data. The proposed methodology can be utilized to effectively predict the power loss of the E-Axle gearbox and further improve the E-Axle efficiency by selecting suitable oil formulations and adjusting oil temperatures. Full article

In today’s automotive industry, electrification is a major trend. In-wheel electric motors are among the most promising technologies yet to be fully developed. Indeed, the presence of multiple in-wheel motors acting as independent actuators allows for the implementation of innovative active systems and control strategies. This paper analyzes different design possibilities for a torque vectoring system applied to an originally compact front-wheel drive hybrid electric vehicle with one internal combustion engine for the front axle and two added electric motors integrated in the wheels of the rear axle. A 14 degrees of freedom vehicle model is present o accurately reproduce the nonlinearities of vehicle dynamic phenomena and exploited to obtain high-fidelity numerical simulation results. Different control methods are compared, a PID, an LQR, and four different sliding mode control strategies. All controllers achieve sufficiently good results in terms of lateral dynamics compared with the basic hybrid version. The various aspects and features of the different strategies are analyzed and discussed. Chattering reduction strategies are developed to improve the performance of sliding mode controllers. For a complete overview, control systems are compared using a performance factor that weighs control accuracy and effort in different driving maneuvers, i.e., ramp and step steering maneuvers performed under quite different conditions ranging up to the limits. Full article

To address the issues that arise when auto-leveling the vehicle body of a hillside tractor under complex working conditions, an auto-leveling control system was developed based on a newly developed hillside tractor and four-point body leveling mechanism. In this approach, leveling accuracy and stability were improved by adopting a sliding mode variable structure control algorithm based on fuzzy switching gain adjustment to achieve real-time dynamic auto-leveling control. To obtain curves of front and rear axle leveling displacement, speed, flow, pressure and body tilting angle during the leveling process, AMEsim/Simulink co-simulation was used to simulate and analyze the control system. The simulation results revealed that the tractor achieves a good leveling effect under complex working conditions in hilly and mountainous areas; the tractor can remain within a ±2° tilting angle range during the leveling process and can return to 0° after leveling, demonstrating good dynamic stability. To further assess the algorithm, a model of the system was submitted to live-testing on a custom-built auto-leveling test bench. Comparison of the test and simulation results revealed a close agreement between the two, indicating that the self-leveling control system and control algorithm developed in this study have high leveling accuracies. The results reported in this paper could provide assistance with or in reference to obtaining solutions to the problems of tractor body leveling in hilly and mountainous areas. Full article

For multi-axle distributed drive (MADD) vehicles, the complexity of the longitudinal dynamics control system increases with the number of driven wheels, which presents a huge challenge to control the multi-motor drive vehicle with more than four wheels. To reduce the control system complexity, this paper proposes a coordinated slip control algorithm using the hierarchical linear quadratic regulator (HLQR) scheme for a 12 × 12 MADD vehicle. The 12-wheel driving system is decoupled based on the wheel load and simplified to a double local subsystem. First, the 12 × 12 MADD vehicle dynamics model is established. Then, the optimal slip ratio is obtained on the basis of the road friction coefficient estimation through a fuzzy control algorithm when the wheel slips. Afterwards, the wheel slip ratio is controlled based on the HLQR program for anti-slip regulation. Furthermore, the driving torque control allocation based on quadratic programming (QR) is coordinated with the anti-slip control. Simulink results show that the proposed coordinated slip control based on HLQR can improve slip control accuracy by more than 30% and greatly reduce the calculation load. The torque control allocation is also limited by the slip control results to ensure wheel dynamic stability and smoothly satisfy the driver’s demand. Full article
