Flow-induced vibration (FIV) characteristics are key factors in enhancing heat transfer. However, challenges such as insufficient heat transfer enhancement and the fatigue strength of the tube bundle persist in the context of improving the heat transfer in elastic tube bundle heat exchangers. This study proposes a novel passive heat transfer enhancement paradigm for elastic tube bundles based on externally induced self-excited oscillations of fluid. By constructing a non-contact energy transfer system, the external oscillation energy is directed into the elastic tube bundle heat exchanger, achieving dynamic stress buffering and breaking through the steady-state flow heat transfer boundary layer. A three-dimensional fluid–structure interaction numerical model is established using Star CCM+2021.3 (16.06.008) to conduct a comparative analysis of the flow characteristics and heat transfer performance between the original structure without an oscillator and the improved structure equipped with a fluid oscillator. The results indicate that the improved structure, through the periodic unsteady jet induced by the fluid oscillator, significantly enhances the turbulence intensity of the shell-side fluid, with the turbulent kinetic energy increasing by over 50%. The radial flow area is notably expanded, thereby reducing the thermal resistance of the boundary layer. At cooling fluid velocities of 6 to 9 m/s, the heat transfer capability of the improved structure is enhanced by more than 50%. Compared with the original structure, the new structure, due to the loading of an external oscillation structure, causes the cold air to present a periodic up and down jet phenomenon. This jet phenomenon, on the one hand, increases the heat exchange area between the cold air and the outer surface of the tube bundle, thereby enhancing the heat exchange capacity. On the other hand, the large-area impact of the fluid reduces the thickness of the boundary layer, lowers the thermal resistance and thereby enhances the heat exchange capacity. Furthermore, this improved structure buffers the mechanical vibrations through self-excited oscillations of the fluid medium, ensuring that the stress levels in the tube bundle remain below the fatigue threshold, effectively mitigating the failure risks associated with traditional active vibration strategies. Full article

Numerical simulations of an 80-degree delta wing in free-to-roll motion are performed by applying the dynamic fluid–body interaction (DFBI) model and the overlap/chimera method using the URANS equations. The capabilities of modern computational fluid dynamics methods for predicting wing-rock phenomena over a wide range of angles of attack at low Mach numbers and strong wing–vortex interaction, including the vortex breakdown phenomenon, were investigated by comparing simulation results with wind tunnel test data. At low angles of attack, delays in the strength and position of the leading-edge vortices above the wing have a destabilizing effect on it, leading to the emergence of self-sustained limit-cycle oscillations. At high angles of attack, where vortex breakdown occurs, the available wind tunnel data show that there are two modes of wing self-oscillations in free-to-roll motion, namely, regular large-amplitude oscillations and irregular small-amplitude oscillations, where the excitation of the latter mode depends on the angle of attack and the initial roll angle of the wing motion. The performed numerical simulation also shows the existence of these two self-oscillatory modes in roll, qualitatively and quantitatively matching the experimental data. Full article

To enhance the erosion efficiency in traditional abrasive water jet processing, an abrasive water jet processing method based on self-excited fluid oscillation is proposed. Traditional abrasive water jet methods suffer from reduced jet kinetic energy due to the presence of a stagnation layer, which hinders efficient material removal. By integrating a self-oscillation chamber into the conventional abrasive water jet nozzle, the continuous jet is transformed into a pulsed jet, thereby increasing the jet velocity and enhancing the kinetic energy of the process. This modification aims to improve material removal efficiency. Using Ansys Fluent, we simulated the material removal efficiency on workpiece surfaces with varying lengths of self-oscillation chambers. The simulation results reveal that the optimal length of the self-oscillation chamber for maximum erosion is 4 mm. SiC materials were used to evaluate the impact of self-oscillation chamber length (L), jet pressure (P), abrasive flow rate (M), and abrasive grain size (D) on erosion. Experimental results show that the self-oscillation chamber increases erosion depth by 33 μm. The maximum erosion depths recorded were 167 μm when L = 4 mm, 223 μm when P = 16 MPa, 193 μm when M = 80 g/min, and 268 μm when D = 2000 μm. Overall, the self-excited oscillation effect enhances the erosion efficiency of the waterjet by 14%. This study further elucidates the factors influencing erosion behaviors in oscillating abrasive water jet processing. Full article

Transonic buffet is a phenomenon of large self-excited shock oscillations caused by shock wave-boundary layer interaction, which is one of the common flow instability problems in aeronautical engineering. This phenomenon involves unsteady flow, which makes optimal design more difficult. In this paper, aerodynamic shape optimization design is combined with reinforcement learning to address the problem of transonic buffet. Using the deep deterministic policy gradient (DDPG) algorithm, a reinforcement learning-based design framework for airfoil shape optimization was constructed to achieve effective suppression of transonic buffet. The aerodynamic characteristics of the airfoil were calculated by the computational fluid dynamics (CFD) method. After optimization, the buffet onset angles of attack of the airfoils NACA0012 and RAE2822 were improved by 2° and 1.2° respectively, and the lift-drag ratios improved by 83.5% and 30% respectively. Summarizing and verifying the optimization results, three general conclusions can be drawn to improve the buffet performance: (1) narrowing of the leading edge of the airfoil; (2) situating the maximum thickness position at approximately 0.4 times the chord length; (3) increasing the thickness of the trailing edge within a certain range. This paper established a reinforcement learning-based unsteady optimal design method that enables the optimization of unsteady problems, including buffet. Full article

A self-excited oscillating pulsed abrasive water jet polishing method is proposed to solve the problems of low removal efficiency in traditional abrasive water jet polishing and the influence of an external flow field on the material surface removal rate. The self-excited oscillating chamber of the nozzle was used to generate pulsed water jets to reduce the impact of the jet stagnation zone on material surface removal and increase the jet speed to improve processing efficiency. ANSYS Fluent was employed to simulate the processing flow field characteristics for different lengths of oscillation cavities. The simulation results indicate that the velocity of the jet shaft reached a maximum of 178.26 m/s when the length of the oscillation cavity was 4 mm. The erosion rate of the material is linear with the processing angle. A nozzle with a length of 4 mm of the self-excited oscillating cavity was fabricated for SiC surface polishing experiments. The results were compared with those of ordinary abrasive water jet polishing. The experimental results showed that the self-excited oscillation pulse fluid enhanced the erosion ability of the abrasive water jet on the SiC surface and significantly improved the material-removal depth of the abrasive water jet polishing SiC. The maximum surface erosion depth can be increased by 26 μm. Full article

The challenges posed by elevated rock hardness, deficient drillability, excessive friction torque, and significant underpressure in extended−reach horizontal wells are the primary factors that contribute to low ROP (Rate of Penetration) and limited horizontal reach during the drilling operation. Reducing drag and friction is one of the primary methods of addressing the aforementioned challenges. To augment the pulse output characteristics of the oscillating jet and bolster the energy of the hydrodynamic impact load, we developed and designed a multi−source impact oscillation speed−increasing tool coupled with blade rotation disturbance and multi−order oscillation cavity self−excitation. We utilized fluid dynamics software to model and conduct numerical analysis on the multi−source pulsed jet generator. Furthermore, we constructed a prototype and subjected it to testing. This paper examines the impact of dimensionless structural parameters on the pressure output characteristics of the multi−source pulse−jet generator. Specifically, we used three dimensionless quantities (cavity length ratios, cavity diameter ratios, and inner wall collision angle ratios) to study this effect. The findings indicate that the multi−source impact oscillation speed−increasing tool is capable of augmenting the pulse oscillation amplitude, and the frequency of pulse oscillation can be adjusted within the range of 5 Hz to 15 Hz. During the study, we determined that the optimal oscillation output characteristics can be achieved when the cavity diameter ratio is 0.8, the cavity length ratio is 1.0, and the inner wall collision angle ratio is 1.5. These findings present a novel approach for the development of downhole hydraulic impact oscillation speed−increasing tools. Full article

Guide vanes (GVs) are installed between the runner and the stay vanes for flow guidance and discharge regulation in reversible pump-turbines. The unstable torsional self-excited vibration of the guide vane (GV) may occur when running at small guide vane opening angles during the transient operations involving pump flow. In addition, the double-stage radial vanes may induce complex flow in the vanes and influence the stability of torsional self-excited vibration of the guide vane. In this study, numerical simulations were conducted at small guide vane opening angles in pump mode for two different guide vanes based on the three-dimensional computational fluid dynamics (CFD) method. The flow regime with a deflection was formed on the trailing edge with a circle in the vaneless region that rotated reversely against the runner rotation when operating at smaller guide vane opening angles for both of the two guide vanes. Based on this, the coupling simulations based on the CFD method with a single-degree-of-freedom (1DOF) oscillator were carried out under these operating conditions. Two flow types were formed at small opening angles when adopting different inlet boundary conditions. The results showed the flow regime with a deflection on the trailing edge may aggravate the instability of torsional vibration when applied as an initial flow field. Moreover, the vibration instability of the torsional self-excitation for two guide vanes was analyzed, showing that modifying the profile of guide vane airfoil is an efficient and reliable approach for weakening the torsional vibration instability. Full article

This paper explores the nonlinear characteristics of the self-excited aerodynamic forces of a semi-closed box deck section to perfect the theory of aeroelastic response analysis. A numerical wind tunnel model was established based on the computational fluid dynamics (CFD) method. The heaving-pitching coupled motion is realized by loading user-defined function (UDF) and dynamic grid technology. The self-excited aerodynamic forces varying with amplitude are identified and analyzed, and the reliability of the aerodynamic results obtained by numerical simulation is verified in the wind tunnel test. In the heaving-pitching coupled motion, the results show that the nonlinear characteristics of aerodynamic forces, especially the aerodynamic moment, are mainly affected by the pitching motion. The phenomenon of high-order harmonic energy transfer is observed with the increase in pitching amplitude, and the main component of high-order harmonic can be determined by the pitching amplitude. The contribution of heaving motion to aerodynamic forces nonlinear components is small, but its influence on nonlinear characteristics is complex. Small amplitude heaving motion plays a positive damping role in heaving-pitching coupled motion, and its scope and effect of positive damping action are affected by pitching motion. The extreme value heaving amplitude of positive damping action is observed in the aerodynamic lift. Full article

The flow field structure in the pilot stage of the electro-hydraulic servo valve is small and complex, and the extreme temperature environment will aggravate the self-excited oscillation, resulting in a decrease in the control accuracy of the servo valve. With the increase in temperature, the size of the orifice, the temperature characteristics of the fluid and the pressure loss in the flow pipe will influence the characteristics of the pilot stage. Considering the influence of temperature and pressure loss, a theoretical mathematical model is established to describe the flow force in the pilot stage. To verify the accuracy of the theoretical model, CFD simulations of the flow force at different inlet pressures and deflection positions and temperatures are analyzed in this paper. As the temperature rises, the oil viscosity rapidly decreases, which results in the flow force acting on the flapper increasing with the temperature. When the temperature exceeds 50 °C, the effect of oil viscosity is small, and the flow force tends to decrease slightly with the combined effect. As the supply oil pressure increases and the flapper moves toward the nozzle, the flow force acting on the flapper increases, and the trend is consistent with the CFD simulation results. An experimental device is designed, including establishing the experimental conditions and measuring the flow force to validate the theoretical model and to observe the cavitation phenomenon of the pilot stage. Full article

Unstable guide vane torsional mode self-excited vibrations that occur at small guide vane openings during the transient operations with pump flow, such as the starting and closing of the pump mode, are considered to have potentially severe consequences, such as guide vane slippage or damage to the link and lever mechanism. Related site tests have indicated that the end wall clearance of a guide vane may have important influences on torsional mode self-excited vibrations. In this paper, numerical investigations, which were based on computational fluid dynamics (CFD) with a single degree of freedom (1DOF) mass-spring oscillator, were carried out on a prototype high-head reversible pump turbine. The results showed that the guide vane self-excited vibrations are unstable under steady-state conditions and during the pump mode’s starting up process for cases with small end wall clearances. In addition, the critical conditions of self-excitation instability under steady-state conditions have larger safety margins than those during the pump mode’s starting up process. After further discussion, it was concluded that increasing the end wall clearance to suppress unstable guide vane self-excited vibration is unreliable due to the complexity and randomness of the initial vibration excitations. Full article

A self-oscillating microcantilever in a feedback loop comprised of a gain, a saturator, and an adjustable phase-shifter is used to measure the viscosity of Newtonian fluids. Shifting the signal of the loop with the adjustable phase-shifter causes sudden jumps in the oscillation frequency of the cantilever. The exact position of these jumps depends on whether the shift imposed by the phase-shifter is increasing or decreasing and, therefore, the self-excited cantilever exhibits a hysteretic non-linear response. This response was studied and the system modeled by a delay differential equation of motion where frequency-dependent added mass and damping terms accounted for the density and the viscosity of the medium. Experimental data were obtained for solutions with different concentrations of glycerol in water and used to validate the model. Two distinct sensing modalities were proposed for this system: the sweeping mode, where the width of the observed hysteresis depends on the viscosity of the medium, and the threshold mode, where a sudden jump of the oscillation frequency is triggered by an arbitrarily small change in the viscosity of the medium. Full article

Self-excited oscillation pulse jet technology is widely used to clean sediment from oil storage tanks. Its successful application is dependent on jet performance. As the cleaning requirements of the oil industry increase, it is necessary to optimise the structure of self-excited oscillation pulsed jet nozzles (SOPJNs) to optimise cleaning and energy efficiencies. In this study, the jet performance of a SOPJN is modelled and analysed based on computational fluid dynamics with consideration of a large eddy simulation and homogeneous cavitation. The modelling results are highly consistent with experimental results. The effects of the SOPJN’s inlet diameter, cavity diameter, cavity length, wall reflection angle, and inlet pressure on the jet’s peak velocity, oscillation frequency, and cavitation number were analysed. The results show that the oscillation frequency decreases with the increase of the inlet diameter d₁, cavity diameter D, cavity length L and reflection angle of wall α. Optimisation of the SOPJN inlet diameter, cavity length, and wall reflection angle produced a jet with a high peak velocity and strong cavitation. The optimal nozzle cavity diameter strengthens cavitation, while the peak velocity fluctuates as the cavity diameter increases. The peak velocity increases with the inlet pressure, while the increasing rate of the peak velocity decreases. The results of this study can be used in the design and optimisation of similar nozzle structures for improved pulse jet cleaning. Full article

The mechanical deformation of the ear canal induced by the temporomandibular joint movement constitutes a promising source of energy to power in-ear devices (hearing aids, communication earpieces, etc.). The large morphological variability of the human ear canal and its intrinsic dynamic characteristics—with displacement frequencies below 1.5 Hz with an average volume variation of 60 mm³—motivate the development of non-conventional dedicated energy harvesting methods. This paper demonstrates the concept and design of a modular hydraulic–piezoelectric self-actuated frequency up-conversion micromachine for energy harvesting. The mechanical energy is conveyed using a liquid-filled custom fitted earplug, which can be considered as a hydraulic pump. A hydraulic circuit composed of a pressure amplifier, two driven valves and two check valves allows to drive two micro-pistons. These micro-pistons actuate a bistable oscillator associated to a piezoelectric transducer allowing the low frequency mechanical excitation to be efficiently converted into electric energy through frequency-up conversion. The two integrated passively driven valves are based on tube buckling and allow the pistons to act alternatively on the oscillator to generate a backward and forward run for two jaw movements. A complete theoretical multiphysics model of the machine has been established for the design and evaluation of the potential of the proposed approach. Global analytical and refined FEM approaches have been combined to integrate the fluid and mechanical behaviors. Based on simulation and preliminary experimental data, the harvested energy is expected to be 8 µJ for one jaw closing, with a theoretical 40% end-to-end conversion efficiency. Full article

Vibration energy harvesting (VeH) techniques by means of intentionally designed mechanisms have been used in the last decade for frequency bandwidth improvement under excitation for adequately high-vibration amplitudes. Oil, gas, and water are vital resources that are usually transported by extensive pipe networks. Therefore, wireless self-powered sensors are a sustainable choice to monitor in-pipe system applications. The mechanism, which is intended for water pipes with diameters of 2–5 inches, contains a piezoelectric beam assembled to the oscillating body. A novel U-shaped geometry of an underwater energy harvester has been designed and implemented. Then, the results have been compared with the traditional circular cylinder shape. At first, a numerical study has been carried at Reynolds numbers Re = 3000, 6000, 9000, and 12,000 in order to capture as much as kinetic energy from the water flow. Consequently, unsteady Reynolds Averaged Navier–Stokes (URANS)-based simulations are carried out to investigate the dynamic forces under different conditions. In addition, an Adaptive Differential Evolution (JADE) multivariable optimization algorithm has been implemented for the optimal design of the harvester and the maximization of the power extracted from it. The results show that the U-shaped geometry can extract more power from the kinetic energy of the fluid than the traditional circular cylinder harvester under the same conditions. Full article

Over the past few years, it has been established that vibration energy harvesters with intentionally designed components can be used for frequency bandwidth enhancement under excitation for sufficiently high vibration amplitudes. Pipelines are often necessary means of transporting important resources such as water, gas, and oil. A self-powered wireless sensor network could be a sustainable alternative for in-pipe monitoring applications. A new control algorithm has been developed and implemented into an underwater energy harvester. Firstly, a computational study of a piezoelectric energy harvester for underwater applications has been studied for using the kinetic energy of water flow at four different Reynolds numbers Re = 3000, 6000, 9000, and 12,000. The device consists of a piezoelectric beam assembled to an oscillating cylinder inside the water of pipes from 2 to 5 inches in diameter. Therefore, unsteady simulations have been performed to study the dynamic forces under different water speeds. Secondly, a new control law strategy based on the computational results has been developed to extract as much energy as possible from the energy harvester. The results show that the harvester can efficiently extract the power from the kinetic energy of the fluid. The maximum power output is 996.25 µW and corresponds to the case with Re = 12,000. Full article
