Space particle radiation induces charging and discharging phenomena in spacecraft dielectric materials, leading to electrostatic discharge (ESD) and electromagnetic pulses (EMP), which pose significant risks to spacecraft electronic systems by causing interference and potential damage. Accurate and timely monitoring of these phenomena, combined with a comprehensive understanding of their underlying mechanisms, is critical for developing effective protection strategies against satellite charging effects. Addressing in-orbit monitoring requirements, this study proposes the design of a compact sleeve monopole antenna. Through simulations, the relationships between the antenna’s design parameters and its voltage standing wave ratio (VSWR) are analyzed alongside its critical performance characteristics, including frequency band, gain, radiation pattern, and matching circuit. The proposed antenna demonstrates operation within a frequency range of (28.73–31.25) MHz (VSWR < 2), with a center frequency of 30 MHz and a relative bandwidth of 8.4%. Performance evaluations and simulation-based experiments reveal that the antenna can measure pulse signals with electric field strengths ranging from (−1000 to −80) V/m and (80 to 1000) V/m, centered at 25.47 MHz. It reliably monitors discharge pulses generated by electron irradiation on spacecraft-grade FR4 (Flame-Retardant 4) dielectric materials, providing technical support for the engineering application of discharge research in space environments. Full article

The control of powder aging during Selective Laser Sintering (SLS) processing is one of the challenges to be overcome for the implementation of this technique in serial production. Aging phenomena, because of the elevated temperatures and long processing times, need to be considered when a fraction of the polymer powders present in the build chamber and not used to manufacture the parts are reused at various times. The aim of this study was to investigate the influence of successive reuse of blends of pure Polyamide 12 and its blends with two types of flame retardants (FR): ammonium polyphosphate (APP) and zinc borate (ZB). The composition of the blends was 70/30 (wt/wt) PA 12/FR. Four successive processing stages have been carried out by collecting the remaining powder blend each time. The powders were re-used using the same processing parameters after sieving. DSC measurements showed that the incorporation of FRs entailed a reduction in the processing window up to 4 °C; nevertheless, no further reduction was noted after aging. The TGA curves of aged blends of powders were also similar for pure PA 12 and PA 12 with FR. In addition, initial and reused powders presented a higher degree of crystallinity than the specimens processed from the powders. The heterogeneous character of the PA 12 after LS processing or reprocessing was shown through Pyrolysis Combustion Flow Calorimetry (PCFC) and cone calorimeter (CC) tests. FTIR analysis also showed that post-condensation reactions have occurred. The mode of action of the flame retardants was clearly seen on HRR curves at both tests. The first reuses of PA 12 powders entailed a significant reduction in time to ignition at the cone calorimeter (150 for the initial material to around 90 s for the reused material), indicating the formation of short polymer chains. Only in the case of zinc borate was it noticed that re-used powder was detrimental to the fire performance because of a strong increase in the value of pHRR (between 163 and 220 kW/m² for reused material instead of 125 kW/m² for the initial one). Full article

This paper describes the fabrication opportunities that Printed Circuit Boards (PCBs) offer for electronic and biomedical engineering. Historically, PCB substrates have been used to support the components of the electronic devices, linking them using copper lines, and providing input and output pads to connect the rest of the system. In addition, this kind of substrate is an emerging material for biomedical engineering thanks to its many interesting characteristics, such as its commercial availability at a low cost with very good tolerance and versatility, due to its multilayer characteristics; that is, the possibility of using several metals and substrate layers. The alternative uses of copper, gold, Flame Retardant 4 (FR4) and silver layers, together with the use of vias, solder masks and a rigid and flexible substrate, are noted. Among other uses, these characteristics have been using to develop many sensors, biosensors and actuators, and PCB-based lab-on chips; for example, deoxyribonucleic acid (DNA) amplification devices for Polymerase Chain Reaction (PCR). In addition, several applications of these devices are going to be noted in this paper, and two tables summarizing the layers’ functions are included in the discussion: the first one for metallic layers, and the second one for the vias, solder mask, flexible and rigid substrate functions. Full article

A low-profile frequency reconfigurable monopole antenna operating in the microwave frequency band is presented in this paper. The proposed structure is printed on Flame Retardant-4 (FR-4) substrate having relative permittivity of 4.3 and tangent loss of 0.025. Four pin diode switches are inserted between radiating patches for switching the various operating modes of an antenna. The proposed antenna operates in five modes, covering nine different bands by operating at single bands of 5 and 3.5 GHz in Mode 1 and Mode 2, dual bands (i.e., 2.6 and 6.5 GHz, 2.1 and 5.6 GHz) in Mode 3 and 4 and triple bands in Mode 5 (i.e., 1.8, 4.8, and 6.4 GHz). The Voltage Standing Waves Ratio (VSWR) of the presented antenna is less than 1.5 for all the operating bands. The efficiency of the designed antenna is 84 % and gain ranges from 1.2 to 3.6 dBi, respectively, at corresponding resonant frequencies. The achieve bandwidths at respective frequencies ranges from 10.5 to 28%. The proposed structure is modeled in Computer Simulation Technology microwave studio (CST MWS) and the simulated results are experimentally validated. Due to its reasonably small size and support for multiple wireless standards, the proposed antenna can be used in modern handheld fifth generation (5G) devices as well as Internet of Things (IoT) enabled systems in smart cities. Full article

This paper presents a miniaturized, broadband near-infrared (NIR) spectrometer with a flame-retardant 4 (FR4)-based scanning micrograte. A 90° off-axis parabolic mirror and a crossed Czerny–Turner structure were used for creating an astigmatism-free optical system design. The optical system of the spectrometer consists of a 90° off-axis parabolic mirror, an FR4-based scanning micrograte, and a two-color indium gallium arsenide (InGaAs) diode with a crossed Czerny–Turner structure optical design. We used a wide exit slit and an off-axis parabolic mirror with a short focal length to improve the signal-to-noise ratio (SNR) of the full spectrum. We enabled a miniaturized design for the spectrometer by utilizing a novel FR4 micrograte for spectral dispersion and spatial scanning. The spectrometer can detect the full near-infrared spectrum while only using a two-color InGaAs diode, and thus, the grating scanning angle of this spectrometer is small when compared to a dual-detector-based spectrometer. In addition, the angle signal can be obtained through an angle sensor, which is integrated into the scanning micrograte. The real-time angle signal is used to form a closed-loop control over the scanning micrograte and calibrate the spectral signal. Finally, a series of tests was performed. The experimental results showed that the spectrometer has a working wavelength range of 800–2500 nm. The resolution is 10 nm at a wavelength range of 800–1650 nm and 15 nm at a wavelength range of 1650–2500 nm. Similarly, the stability of these two wavelength ranges is better than ±1 nm and ±2 nm, respectively. The spectrometer’s volume is 80 × 75 × 65 mm³ and its weight is 0.5 kg. The maximum spectral fluctuation does not exceed 1.5% and the signal-to-noise ratio is 284 after only one instance of averaging. Full article

This paper presents a multiband metamaterial (MM) absorber based on a novel spiral resonator with continuous, dual, and opposite P-shape. The full wave analysis shows 80.06% to 99.95% absorption at frequencies range for Ku and K bands for several substrate materials of 100 mm² area. The results indicate that the absorption rate remains similar for different polarizing angles in TEM mode with different substrates. With FR4 (Flame Retardant 4) substrate and 64 mm² ground plane, the design acts as single negative (SNG) MM absorber in K band resonance frequencies (19.75–21.37 GHz) and acts as double negative (DNG) absorber in Ku band resonance frequencies (15.28–17.07 GHz). However, for Rogers 3035 substrate and 36 mm² ground plane, it acts as an SNG absorber for Ku band resonance frequency 14.64 GHz with 83.25% absorption and as a DNG absorber for K band frequencies (18.24–16.15 GHz) with 83.69% to 94.43% absorption. With Rogers 4300 substrate and 36 mm² ground plane, it acts as an SNG absorber for Ku band at 15.04 GHz with 89.77% absorption and as DNG absorber for K band frequencies (22.17–26.88 GHz) with 92.87% to 93.72% absorption. The design was fabricated with all three substrates and showed quite similar results as simulation. In comparison with other broadband absorbers, this proposed MM absorber illustrated broad incidence angles in TEM mode. Full article

This paper presents a compound control system for precise control of the flame-retardant 4 (FR4)-based electromagnetic scanning micrograting. It mainly consists of a frequency controller and an angle controller. A dual closed-loop structure consisting of a current loop and an angle loop was designed in the angle controller. In addition, the incremental proportional–integral–derivative (PID) control algorithm was designed in the current loop, and the fuzzy-PID control algorithm was employed in the angle loop. From the experimental results, the frequency controller can effectively track the real-time resonant frequency of the scanning micrograting with a tracking accuracy of 0.1 Hz. The overshoot of the scanning micrograting is eliminated. Compared to an open-loop control system, the control system presented in this work reduces the steady-state error of the scanning micrograting from 1.122% to 0.243%. The control accuracy of the compound control system is 0.02°. The anti-interference recovery time of the scanning micrograting was reduced from 550 ms to 181 ms, and the long-term stability was increased from 2.94% to 0.12%. In the compound control system presented in this paper, the crucial parameters of the FR4-based electromagnetic scanning micrograting, including motion accuracy, anti-interference ability, and long-term stability, were effectively improved. Full article

Recycled polyethylene-terephthalate (rPET) nanocomposites of reduced flammability were prepared by combining aluminum-alkylphosphinate (AlPi) flame retardant (FR) and natural montmorillonite (MMT), in order to demonstrate that durable, technical products can be produced from recycled materials. During the development of the material, by varying the FR content, the ratio and the type of MMTs, rheological, morphological, mechanical and flammability properties of the nanocomposites were comprehensively investigated. Related to the differences between the dispersion and nucleation effect of MMT and organo-modified MMT (oMMT) in rPET matrix, analyzed by Scanning Electron Microscopy (SEM), Energy Dispersive X-Ray Spectroscopy (EDS) and Differential Scanning Calorimetry (DSC), mechanical properties of the nanocomposites changed differently. The flexural strength and modulus were increased more significantly by adding untreated MMT than by the oMMT, however the impact strength was decreased by both types of nanofillers. The use of different type of MMTs resulted in contradictory flammability test result; time-to-ignition (TTI) during cone calorimeter tests decreased when oMMT was added to the rPET, however MMT addition resulted in an increase of the TTI also when combined with 4% FR. The limiting oxygen index (LOI) of the oMMT containing composites decreased independently from the FR content, however, the MMT increased it noticeably. V0 classification according to the UL-94 standard was achieved with as low as 4% FR and 1% MMT content. The applicability of the upgraded recycled material was proved by a pilot experiment, where large-scale electronic parts were produced by injection molding and characterized with respect to the commercially available counterparts. Full article

This paper performs a detailed investigation on the electromagnetic angle sensor integrated in the flame retardant 4 (FR4)-based scanning micromirror. An accurate theoretical model is presented, especially considering the coupling effect between the driving and sensing coils. Experimental results agree well with the theoretical results, and show a sensitivity of 55.0 mV_p/° and a high signal-to-noise ratio (SNR) of 71.9 dB. Moreover, the linearity of the angle sensor can still reach 0.9995, though it is affected slightly by the coupling effect. Finally, the sensor’s good feasibility for feedback control has been further verified through a simple closed-loop control circuit. The micromirror operated with closed-loop control possesses better long-term stability and temperature stability than that operated without closed-loop control. Full article

Low viscosity, potentially renewable aliphatic epoxy resins, appropriate for processing with injection techniques were flame retarded with the use of resorcinol bis(diphenyl phosphate) (RDP), acting predominantly in the gas phase, ammonium polyphosphate (APP), acting in the solid phase, and their combination. Samples of gradually increasing phosphorus (P) content (1%, 2%, 3%, 4%, and 5%) and mixed formulations with 2% P from APP and 2% P from RDP were prepared. The fire retardancy of matrix and carbon fibre reinforced samples was examined by limiting oxygen index (LOI), UL-94 tests, and mass loss calorimetry. The thermal stability of the matrices was investigated by thermogravimetric analysis, whereas the effect of flame retardants (FRs) on the crosslinking process and glass transition temperature was evaluated by differential scanning calorimetry in matrices and by dynamic mechanical analysis in composites. According to the results, although the trifunctional glycerol -based (GER) and the tetrafunctional pentaerythritol-based (PER) epoxy resins have a similar initial LOI and horizontal burning rate, GER has an approximately 1.5 times higher peak of heat release rate (pHRR) than PER. At least 4% P content is necessary to reach a reasonable improvement in fire performance in these resin transfer molding (RTM)-compatible systems and with the same FR-content PER reaches better fire performance. RDP has an early gas phase effect at the beginning of degradation, while later on the solid phase action of APP prevails, although in composites hindered by the reinforcing carbon fibres. In PER composites, the combination of APP and RDP had a synergistic effect, leading to a pHRR of 218 kW/m² and total heat release of 18.2 MJ/m². Full article

A technology platform based on commercial printed circuit boards (PCB) technology is developed and presented. It integrates rigid flame retardant (FR)-4 boards, flexible polyimide (PI) structures, and embedded cavities for micro- and meso-scale applications. The cavities or channels can be filled with fluids for microfluidic and lab-on-chip systems. In this study, an electromagnetic energy harvester with enhanced output was designed and implemented in the platform. To enhance harvester output, the embedded cavities were filled with ferrofluid (FF) to improve the overall magnetic circuit design and electromechanical coupling of the device. The fabricated PCB-based harvester had a dimension of 20 mm × 20 mm × 4 mm. Vibration tests of the harvesters were conducted with different magnet sizes and different FF. Test results showed up to a 70% enhancement of output voltage and a 195% enhancement of output power when the cavities were filled with oil-based FF as compared with harvesters without FF. When the cavities were filled with water-based FF, the enhancement of voltage and power increased to 25% and 50%, respectively. The maximum output power delivered to a matched load at a 196-Hz resonance frequency and 1 g_rms vibration was estimated to be 2.3 µW, corresponding to an area power density of 0.58 µW/cm² and a volume power density of 1.4 µW/cm³, respectively. Full article

This paper presents a flame retardant 4 (FR4)-based electromagnetic scanning micromirror, which aims to overcome the limitations of conventional microelectromechanical systems (MEMS) micromirrors for the large-aperture and low-frequency scanning applications. This micromirror is fabricated through a commercial printed circuit board (PCB) technology at a low cost and with a short process cycle, before an aluminum-coated silicon mirror plate with a large aperture is bonded on the FR4 platform to provide a high surface quality. In particular, an electromagnetic angle sensor is integrated to monitor the motion of the micromirror in real time. A prototype has been assembled and tested. The results show that the micromirror can reach the optical scan angle of 11.2 ${}^{\circ }$ with a low driving voltage of only 425 mV at resonance (361.8 Hz). At the same time, the signal of the integrated angle sensor also shows good signal-to-noise ratio, linearity and sensitivity. Finally, the reliability of the FR4 based micro-mirror has been tested. The prototype successfully passes both shock and vibration tests. Furthermore, the results of the long-term mechanical cycling test (50 million cycles) suggest that the maximum variations of resonant frequency and scan angle are less than 0.3% and 6%, respectively. Therefore, this simple and robust micromirror has great potential in being useful in a number of optical microsystems, especially when large-aperture or low-frequency is required. Full article
