Search Results (5,507)

Compared with mass spectrometry or high-performance liquid chromatography (HPLC), surface-enhanced Raman scattering (SERS) is a promising alternative technique for inspection of preservatives in food safety. However, conventional SERS substrates based on metallic nanoparticles commonly suffer from complicated fabrication processes, long processing times, and high costs. Therefore, we propose a high-density porous anodic aluminum oxide (AAO) substrate prepared by one-step anodization process combined with pore widening to increase number of SERS hotspots on template. Through a rapid one-step anodization process conducted at 25 °C, the processing time and efficiency are greatly improved compared to conventional low temperature of 0–10 °C and two-step anodization method. By lowering the anodization voltage to 20 V, a high-density porous substrate is achieved, effectively enhancing the SERS signal intensity. Furthermore, we demonstrated that SERS signal intensities are affected by multiple correlated structural factors and significantly improved by lower anodization voltage with pore widening. The analytical enhancement factor is calculated as 1.18 × 10⁵ to 1.44 × 10⁷ on an AAO substrate prepared at 20 V with pore-widening process for 1000 and 0.1 ppm p-hydroxybenzoic acid, respectively. For the preservative detection of p-hydroxybenzoic acid, a detection limit of 100 ppb is achieved by a high-density AAO substrate prepared at 20 V, which is far below the regulatory limit of 600 ppm. Full article

High-temperature metallic surfaces in aero-engine hot sections and related thermal systems are subjected to MW/m²-level heat-flux loads and transient thermal conditions, creating a need for sensors capable of quantifying heat flux under high-temperature conditions. This study aims to develop a screen-printed Ag–AgPd thick-film thermopile heat-flux sensor (HFS) for MW/m²-level heat-flux measurement on high-temperature metallic surfaces. Its main feature is the integration of an Ag–AgPd thermopile sensing layer, an insulating layer, and a thermal-resistance layer on a SUS430 stainless-steel substrate through a screen-printing-based multilayer fabrication route. Microstructural characterization, annealing condition comparison, laser comparison calibration, repeated loading, dynamic-response testing, and flame-heating testing were conducted to evaluate the sensor structure and performance. Under laser comparison calibration, the sensor achieved a MW/m²-level calibrated heat-flux response over 0.32–1.37 MW/m², with a near-linear output relationship of $R^2>0.998$, a sensitivity of 2.67 μV/(kW/m²), a nonlinearity of 1.83%, a hysteresis error below 0.29%, a repeatability error below 0.43%, a sample-to-sample consistency error of 1.06%, a maximum accuracy-test deviation of 1.84%, and a maximum repeated-loading stability error of 1.33%. The sensor also exhibited a time constant of 0.806 s under laser step excitation, and the baseline-corrected equivalent heat-flux response remained stable during approximately 120 s of flame heating at about 800 °C. These results indicate that the proposed HFS provides a feasible thick-film thermopile sensing approach for MW/m²-level heat-flux measurement on high-temperature metallic surfaces. Full article

The detection of bolt preload force is of vital importance for ensuring the structural reliability of equipment under extreme operating conditions. Traditional ultrasonic transducers based on bulk piezoelectric materials suffer from poor long-term coupling stability and high brittleness of the material, which limits their practical applications. In this work, AlN piezoelectric thin films were fabricated by RF magnetron sputtering, and the effects of RF power and target-to-substrate distance on film morphology, crystal structure, and ultrasonic response were investigated. The results show that increasing RF power increased the film thickness and deposition rate, reduced the detected O content on the film surface, and changed the XRD response. The film deposited at 900 W generated ultrasonic longitudinal wave echoes with a relatively high signal amplitude among the tested RF powers. Among the tested target-to-substrate distances, the film deposited at 60 mm showed a relatively higher deposition rate and generated an ultrasonic longitudinal wave echo with a relatively higher amplitude. The measured d₃₃ value of this film was approximately 4.8 pC/N. The AlN thin-film ultrasonic transducers prepared under the selected deposition conditions were directly deposited on bolts, and the effects of temperature and axial load were calibrated using the ultrasonic TOF measurement method. There was a linear correlation between the TOF and the temperature (R² > 99.99%), as well as between the TOF and the axial load. These results indicate that the deposited AlN thin-film transducer has potential for bolt preload measurement in wind turbine bolts. Full article

The study objectives were to evaluate the in vitro and in vivo performance of additive manufacturing (AM) Ti6Al4V ELI alloy compared to that of a commercially available dental implant. Two AM shapes with the solid or lattice structures on the solid substrate were used: in vitro test: disk shapes (10.0 mm/dia. 2.0 mm/thick) and in vivo test: AM shapes matching the overall geometry of a commercial implant (3.0 mm/dia. 8.0 mm/length). Six disk specimens were placed in direct contact with Balb/c 3T3 fibroblasts for 72 h. Cytotoxicity was assessed with adenosine triphosphate activity. Four implant-shaped specimens were placed in the femurs of three rabbits and retrieved after 6 weeks. Osseointegration was evaluated by push-out testing and histological analysis. Data were analyzed using one-way ANOVA (α = 0.05). Surface roughness (µm) of AM-solid, AM-lattice, and a commercial implant were 8.02, 9.00, and 1.46, respectively. Cytotoxicity was not statistically different compared to surface configuration and Teflon^® controls (p > 0.05). Push-out test results were not significant between implants: the shear stiffness of commercial > AM-lattice > AM-solid (p > 0.05). Histological analysis demonstrated osseointegration without inflammatory responses in the surrounding bone tissue for all implants. While some processes and improvements are still required, AM remains a promising method for fabricating customized porous implants in the future. Full article

To satisfy the demands of 5G communication and reliable data connectivity for unmanned aerial vehicles (UAVs), a novel two-element dual-band MIMO antenna with an inherent self-decoupling property based on orthogonal linear polarization diversity is proposed. Distinct from conventional designs relying on extra decoupling components, the antenna realizes isolation enhancement via coupled currents between annular strips and S-shaped strips without additional decoupling structures, representing the core design novelty. Fabricated on a low-cost 1.6 mm thick FR4 substrate, the antenna features compact overall dimensions of 60 mm × 30 mm × 1.6 mm, covering the 2.40–2.73 GHz ISM band and 3.38–3.63 GHz 5G Sub-6 GHz band. Measured results demonstrate that the reflection coefficient remains below −10 dB across the entire operating bands, with port isolation exceeding 27 dB for the 2.4 GHz band and 20 dB for the 3.5 GHz 5G band. The measured realized gain is 0.7–1.5 dB in the lower band and 2.3–2.9 dB in the upper band. The radiation efficiency, which is obtained exclusively from ANSYS HFSS 2025 R1 simulation, is higher than 90% for the lower band and over 80% for the upper band. The calculated envelope correlation coefficient (ECC) is less than 0.15 throughout the working bandwidth, which effectively suppresses inter-channel electromagnetic interference and mitigates channel fading caused by varying UAV attitudes to improve system channel capacity. Further verifications via epoxy encapsulation and co-simulation on an eight-rotor UAV platform prove slight frequency drift after packaging and installation, whereas its bandwidth and isolation still meet practical engineering requirements. Benefiting from a compact layout and omnidirectional radiation performance, the proposed low-cost MIMO antenna is convenient for conformal integration into a UAV fuselage, improving the practicability of UAV-aided emergency communication, equipment inspection and 5G network coverage. Full article

Single-crystal diamond (SCD) is an ideal substrate material for semiconductor devices due to its extremely wide bandgap and exceptionally high thermal conductivity. However, diamond’s extreme hardness and chemical inertness pose challenges for the fabrication of ultra-smooth surfaces. Traditional polishing processes are not only inefficient but also prone to introducing subsurface defects, which severely degrade device performance. To address the above issues, this study proposes a hybrid polishing process combining reactive ion etching (RIE) surface modification with chemical mechanical polishing (CMP), which enables low-loss atomic-level processing of SCD. The study found that RIE treatment induces lattice disorder on the diamond surface, forming a sp²-hybridized amorphous carbon-modified layer. Compared to the sp³ structure of native diamond, this modified layer has lower hardness and is easier to remove. We conducted the verification of the optimized process using high-quality single-crystalline diamond (SCD) samples with an initial surface roughness Ra of 0.68 nm. Under the optimized RIE parameters (substrate bias power: 200 W, etching time: 600 s, gas flow ratio of Ar:O₂:CF₄ = 40:50:10), the surface roughness Ra was reduced to as low as 0.35 nm after 2 h of CMP treatment. Furthermore, systematic characterization of the SCD’s as-received surface, RIE-modified surface, and CMP-treated surface was performed using Raman spectroscopy and X-ray photoelectron spectroscopy (XPS), elucidating the “etching modification–mechanical removal” polishing mechanism. Full article

Dual-beam circularly polarized antenna arrays are widely demanded in high-capacity wireless and satellite communication systems. However, conventional designs typically suffer from complex feeding networks, large profile, and high insertion loss, which limit their integration level and efficiency. To address these issues, this paper proposes a low-loss, highly integrated dual-beam circularly polarized antenna array based on a substrate-integrated waveguide equivalent ENZ feeding network. A new physical phenomenon is revealed that the tangential electric field in the slots exhibits an equal-amplitude and anti-phase distribution due to the combined effect of the uniform field distribution in the ENZ medium and the boundary conditions of the slotted perfect electric conductor. Using this inherent mechanism, the antenna achieves symmetric dual-beam radiation at approximately ±27° in the E-plane. A polarization conversion meta surface layer is loaded to convert linear polarization into circular polarization. A prototype is fabricated and measured. At 8.3 GHz, the measured peak gain is 9.1 dBi, the minimum axial ratio is better than 1.5 dB, and the radiation efficiency is higher than 85%. The proposed array features simple structure, low loss, and high integration. Compared with conventional feeding structures, it eliminates the need for additional phase shifters or power dividers, effectively reducing insertion loss and structural complexity. It exhibits good application potential in compact base stations and satellite communication terminals. Full article

Mg-based thin films are promising candidates for hydrogen-responsive optical devices. However, their performance is strongly influenced by microstructural evolution during deposition. In this work, Mg thin films were deposited onto glass substrates placed on different substrate-holder materials (Si and 304 stainless steel) to investigate the influence of substrate-holder configuration on microstructure formation. Fluorocarbon (FC)/Pd/Mg multilayer films were subsequently fabricated to evaluate hydrogenation and dehydrogenation behaviors. The results show that the substrate-holder material significantly affects film morphology and hydrogenation performance. Mg films prepared using the Si holder exhibit relatively uniform hexagonal-like surface morphologies, whereas those prepared using the stainless-steel holder show a transition from granular to hexagonal-like morphologies with increasing sputtering power. Hydrogenation measurements reveal that FC/Pd/Mg films prepared using the stainless-steel holder exhibit superior performance, including a reflectance modulation of approximately 70%, a transmittance modulation exceeding 40%, and a hydrogenation time of about 30 s. In contrast, films prepared using the Si holder show reduced optical modulation and slower hydrogenation kinetics. The observed differences in hydrogenation behavior are closely correlated with variations in film microstructure induced by different substrate-holder configurations. The results suggest that substrate-holder-dependent growth conditions may influence defect formation and hydrogen diffusion pathways in Mg-based thin films. This study highlights the importance of substrate-holder configuration as a processing parameter affecting microstructure evolution and hydrogen-responsive performance in FC/Pd/Mg multilayer films. Full article

As the prevalence of myopia among adolescents continues to increase, the design and fabrication of myopia control lenses have become an important research direction in modern optics. Existing myopia control lenses mostly adopt purely refractive structures, which suffer from limited design freedom, insufficient chromatic aberration suppression, and relatively large lens thickness, thereby restricting further improvement of optical performance. This paper proposes a refractive–diffractive hybrid design and fabrication method for myopia control lenses. Centered on a harmonic diffractive optical element (HDOE), an optimization model is established to balance achromatization performance and fabrication feasibility. To address the challenges of small period width, tool shadow effect, and sensitivity to machining tolerances in diffractive lenses with large-aperture and high-additional-power, harmonic design is employed to increase the period width, thereby reducing fabrication difficulty and mitigating the influence of shadowing errors on diffraction efficiency. On this basis, two lenses with different phase structures are designed: one adopts a conventional diffractive correction phase to verify the role of HDOE in achromatization and edge-thickness reduction, while the other adopts a high-degree-of-freedom smooth phase to achieve a continuous multifocal visual effect. Both lenses are fabricated by single-point diamond turning (SPDT), and the effects of surface profile and machining parameters on performance are analyzed. Simulations and measurements show that the proposed method provides stable diffraction efficiency and effective chromatic aberration correction across the design band, while reducing the edge thickness by approximately 37.85% without additional thinning of the aspheric substrate. The results indicate that the refractive–diffractive hybrid design provides a feasible design and fabrication approach for functionally more complex myopia control lenses. Full article

Herein, p-NbSe₂ thin films were deposited onto n-Si substrates to fabricate an n-Si/p-NbSe₂ (SNS) heterojunction for visible light communication (VLC) applications. Structural analysis revealed that the NbSe₂ films possess a trigonal phase and are composed of slightly elongated and irregularly shaped grains with an average size of 0.131 μm. Electrical characterization showed that the SNS heterojunction exhibits pronounced rectifying behavior, with a bias-dependent asymmetry factor reaching 6.6 × ${10}^3$. The photodetection performance of the device was evaluated under illumination from white, blue, red, tungsten, and infrared LEDs. The device exhibited excellent photodetection characteristics across the visible region, achieving a maximum responsivity of 3.79/3.68 AW⁻¹, external quantum efficiency of 1160/809%, noise equivalent power of 4.43 × 10⁻¹⁴ /4.57 × 10⁻¹⁴ WHz^−1/2, and specific detectivity of 3.91 × 10¹²/3.79 × 10¹² Jones under blue/white light illumination, confirming its practical relevance for VLC systems. In addition, frequency-dependent photocurrent measurements under modulated blue and white LED illumination revealed −3 dB bandwidths of approximately 775 Hz and 716 Hz, respectively, supporting the potential of the n-Si/p-NbSe₂ photodiode for low-frequency VLC-related visible-light detection. Compared with previously reported photodiodes used in VLC and IR technologies, the present device demonstrated superior responsivity and EQE%, together with competitive NEP and detectivity. The enhanced performance is attributed to efficient photocarrier generation and collection across the Si/NbSe2 heterojunction. These results confirm that the fabricated SNS photodiode is a promising candidate for high-sensitivity and efficient visible light communication applications. Full article

Triboelectric nanogenerators (TENG) show significant potential in pressure sensing by converting mechanical disturbances into electrical signals positively correlated with the magnitude of the applied force, yet their development as practical pressure sensors is severely hindered by the major drawback of only detecting transient mechanical inputs. Additionally, traditional dual-mode pressure sensors have typically required complex multilayer structures and time-consuming fabrication processes. Here, a simple dual-mode pressure sensor of novel structure integrated with TENG and anodic aluminum oxide (AAO) for both dynamic and static pressure detection is proposed. Nanoporous AAO is directly grown on an aluminum substrate to simplify the traditionally complex multi-layer structure of dual-mode pressure sensors. The AAO layer serves a dual functionality by acting as an active triboelectric layer that significantly enhances the triboelectric output performance while concurrently functioning as the capacitive dielectric layer. A polydimethylsiloxane (PDMS) film is employed as the elastic counterpart to pair with the AAO substrate. The influence of PDMS thickness on the charge accumulation and extraction of the TENG mode is investigated to optimize the device output. Under optimal configurations, the streamlined Al-AAO/PDMS sensor demonstrates good sensitivity and linearity (R² > 0.99) for both dynamic triboelectric voltage (1.05 V/kPa) and static capacitance (5.56 pF/kPa) over a wide sensing range of 1–73 kPa. This dual-mode sensor effectively overcomes the transient limitation of conventional single-mode TENGs and shows significant potential for future smart tactile applications. Full article

Reliable temperature monitoring is essential for the thermal management and safe operation of modern telecommunication equipment. However, conventional temperature sensors are often relatively large and rigid, which limits their applicability for localized temperature measurement on compact electronic components. In this study, a flexible thin-film thermocouple based on NiCr–NiSi thermoelectric materials was developed for temperature monitoring of telecommunication equipment. The sensor adopts a multilayer structure consisting of a polyimide (PI) flexible substrate, an Al₂O₃ insulating layer, NiCr and NiSi thermoelectric films, and a SiO protective layer and was fabricated using magnetron sputtering. Static calibration experiments show that the fabricated sensor exhibits a thermoelectric sensitivity of approximately 40.45 µV/°C, which is close to the reference value of conventional K-type thermocouples, with a relative error of about 1.34%. Repeated heating–cooling cycles demonstrate good repeatability and stable thermoelectric characteristics. Dynamic tests under representative transient thermal conditions showed that the sensor could continuously capture temperature variations without signal interruption or abnormal fluctuations. To further quantify its dynamic behavior, a numerical step-response simulation was performed for the PI/Al₂O₃/NiCr–NiSi/SiO multilayer structure. The simulated thermal time constant and curve-extracted 90% response time were 0.0343 s and 0.0803 s, respectively, under the specified boundary conditions. Owing to its small thickness, low thermal mass, and good mechanical flexibility, the proposed thin-film thermocouple can be conformally attached to compact and curved electronic surfaces, indicating promising potential for real-time localized temperature monitoring of telecommunication equipment and other compact electronic systems. Full article

Gas Electron Multiplier (GEM) detectors have become an indispensable component of modern tracking systems. The heart of a GEM detector is a thin polyimide foil (∼50 µm) clad with copper (∼5 µm) on both sides and containing an array of regularly spaced holes (typically diameter of ∼70 µm and pitch of ∼140 µm) fabricated using photolithographic techniques. The presence of the dielectric substrate (polyimide) within the amplification region introduces a time dependent response when the detector is exposed to external irradiation, a phenomenon commonly referred to as the charging-up effect. This effect arises from the accumulation of charge on the insulating polyimide surfaces, leading to a gradual modification of the local electric field configuration inside the GEM holes and, consequently, a variation in the detector gain over time. The charging-up behaviour has been systematically investigated for triple GEM chamber prototypes using an Fe-55 radioactive source (5.9 keV X-rays) with an activity of ∼20 mCi. The characteristic charging-up time constant has been extracted, and its dependence on detector gain and irradiation rate has been examined. In addition, the uniformity of detector performance in terms of count rate, gain, and energy resolution has been studied both before and after the charging-up process. In this review article, the experimental setup, data acquisition methodology, and analysis procedures developed and carried out by our group are summarised. The key findings reported by other groups, relevant Monte Carlo simulation efforts, and future outlook for the charging-up investigation on GEM based detectors are also discussed in this article. The investigations and their outcomes reviewed here provide valuable insight into the charging-up dynamics of GEM detectors and their dependence on operational parameters. Full article

Copper (Cu) thin films and meshes on polyethylene terephthalate (PET) substrates are promising flexible transparent conductive electrodes (TCEs), yet their practical use is limited by insufficient interfacial adhesion and poor oxidative stability on inert polymer substrates. This work addresses these issues via a synergistic strategy of interfacial layer engineering and maskless laser lithography-based aperiodic mesh patterning, systematically comparing ceramic (Al₂O₃) and metallic (NiCr) interfacial layers for PET-supported Cu films and fabricating Linear/Sinusoidal aperiodic Cu meshes with tailored performance. Magnetron sputtering shows that Ar plasma-activated NiCr interfacial layers form a gradient-alloyed interface with Cu via interdiffusion, achieving 5B-level adhesion, mitigating bending-induced stress concentration, and enhancing damp-heat resistance (85 °C/85% RH) by suppressing oxidation—outperforming brittle Al₂O₃ layers. Patterning the optimized Cu/NiCr/PET structure into micrometer-scale meshes yields a Linear design with superior optoelectronic performance (~10.8 Ω/sq sheet resistance, >87% transmittance at 550 nm) and a Sinusoidal design with enhanced bending robustness via stress delocalization. Microstructural and elemental analyses clarify the NiCr layer’s interfacial toughening and anti-oxidation mechanisms. Practical validation in flexible transparent heaters demonstrates rapid thermal response and >20 h continuous operational stability. This study provides a scalable design strategy for high-performance PET-supported Cu meshes, offering insights for interface and structural optimization of flexible metallic TCEs for next-generation optoelectronics. Full article

Smart contact lens sensors integrate biochemical sensing elements, flexible electronics, power modules, and wireless readout components onto optically transparent contact lens platforms, enabling non-invasive and potentially continuous analysis of tear-derived biomarkers and ocular physiological signals. This review focuses on the translation pathway from contact lens materials and fabrication methods to sensing mechanisms, tear biomarker interpretation, and clinical deployment. We synthesize recent progress in substrate engineering, manufacturing processes, power delivery, and representative sensing strategies for intraocular pressure, glucose, electrolytes, pH, cortisol, cholesterol, and inflammatory cytokines. Instead of treating these systems as isolated examples, we compare optical/colorimetric, electrochemical, field-effect transistor, microfluidic, and wireless resonant approaches in terms of sensitivity, response time, power/readout requirements, and clinical relevance. Finally, we discuss persistent barriers, including biocompatibility, interface stability, tear-sample variability, calibration, sterilization, regulatory validation, data privacy, and compatibility with commercial contact lens manufacturing. Full article
