Search Results (332)

Parkinson’s disease (PD) is a neurodegenerative disorder with an increasing incidence rate that significantly affects patients’ motor functions and quality of life. Involuntary upper limb tremors (ULTs) commonly manifest unilaterally, affecting either the left or right upper limb. Clinically, ULT frequencies can be categorized into three distinct classes: low-frequency (<4.0 Hz), mid-frequency (4.0–7.0 Hz), and high-frequency (>7.0 Hz) tremors. These tremor motions are characterized by oscillatory or rotational (angular displacement) movements, commonly referred to as the micro-Doppler effect (mDE). This study aims to develop a short-range (<1.0 m) and contactless sensing method for ULT detection based on Doppler millimeter-wave (mm-Wave) radar. The reflected electromagnetic waves indicate time-varying frequency characteristics, which can be analyzed by using time–frequency transform (TFT) methods, such as the Wigner–Ville distribution (WVD) and smoothed pseudo WVD (SPWVD). These TFT methods are employed to extract mDE features, which are subsequently visualized as color-coded spectrograms for ULT classification. Then, a two-dimensional (2D) convolutional neural network (CNN) is employed to automatically recognize the visual feature patterns for ULTs classification based on frequency and amplitude information. In the experimental setup, the W-band (76–81 GHz) Doppler mm-Wave biosensor is implemented for sensing and extracting feature patterns. The proposed classifiers based on “WVD + 2D CNN” and “SPWVD + 2D CNN” are trained and validated by using the collected datasets, with 60% randomly selected for training datasets and 40% for testing datasets in each fold validation. A 10-fold cross-validation method is applied to evaluate the classifier’s performances, achieving an average precision of 95.92 ± 0.60%, average recall of 95.89 ± 0.62%, average F1-score of 0.9588 ± 0.0060, and average accuracy of 95.89 ± 0.62%, respectively. The experimental results demonstrate the feasibility of the proposed classifier for real-time ULTs classification in PD patients using short-range (<1.0 m) and contactless sensing. Full article

Nowadays, numerical simulation methods are advanced and widely used in industry, enabling the modeling of complex systems from printed circuit boards (PCBs) to full power converters. Among many isolated topologies, the phase-shift full-bridge (PSFB) topology is a well-established solution for isolated DC–DC conversion in electric vehicles. Therefore, this paper proposes a broadband electromagnetic compatibility (EMC) modeling methodology for a custom-designed 1 kW gallium nitride (GaN)-based PSFB converter intended for an electric vehicle (EV) DC powertrain. Moreover, the approach combines full-wave electromagnetic simulation with circuit-level simulation, including parasitic effects from PCB layout, power harnesses, and discrete components. Thus, the virtual prototype is assessed within a complete virtual test bench compliant with the standard Comité International Spécial des Perturbations Radioélectriques (CISPR) 25 over the 150 kHz–108 MHz range to capture common-mode (CM) and differential-mode (DM) conducted electromagnetic interference (EMI). Results show that the converter achieves efficiencies of 97.26% in standalone mode and 97.03% when integrated into the full DC powertrain. However, the conducted EMI assessment reveals that both CM and DM emissions exceed CISPR 25 Class 2 limits across the entire spectrum, with excess levels reaching up to 72 dBµV. Therefore, power harnesses significantly increase EMI levels at low frequencies due to the distributed inductance and stray capacitance. Finally, this study demonstrates the value of virtual prototyping for simulation-based EMI prediction in early-stage power converter design. Full article

We review the structure of pseudoscalar mesons within an algebraic model formulated in the light-front framework. The approach provides a unified description of leading-twist parton distribution amplitudes, light-front wave functions, generalized parton distributions, parton distribution functions, elastic electromagnetic form factors, charge radii, and impact-parameter space distributions, all obtained from the same underlying Bethe–Salpeter wave-function representation. The analysis covers light mesons $(\pi ,K)$, the mixed $\eta$–${\eta }^{\prime }$ system, heavy–light states $(D,D_s,B,B_s,B_c)$, and heavy quarkonia $({\eta }_c,{\eta }_b)$, thereby enabling a systematic study of quark-mass effects, flavor-symmetry breaking, and the transition from emergent hadronic mass to heavy-quark dynamics. Where available, results are compared with experimental measurements, functional methods such as lattice-QCD calculations and Dyson–Schwinger Equation formalism, and other phenomenological approaches. The algebraic model thus offers a transparent, symmetry-preserving, and analytically tractable framework for connecting the longitudinal, transverse-momentum, and spatial structure of pseudoscalar mesons across all quark-mass regimes. Full article

Existing ground-slotted coplanar waveguide (CPW) spoof surface plasmon polariton (SSPP) low-pass filters (LPFs) remain constrained by the difficulty of achieving a wide stopband while maintaining a compact size, as well as by undesired radiation leakage arising from their open-aperture slot configuration. To address these issues, a grounded coplanar waveguide spoof surface plasmon polariton (GCPW-SSPP) low-pass filter based on a multi-arm star-shaped slot (MASS) loading topology is proposed. An equivalent-circuit interpretation and full-wave dispersion analysis show that the multi-arm slots introduce enhanced distributed reactive loading, thereby lowering the asymptotic frequency and enabling compact SSPP implementations. The near-field characteristics further demonstrate tighter electromagnetic confinement, as reflected by an approximately 48% reduction in the electric-field confinement width along the z-direction. To alleviate the trade-off between miniaturization and wide-stopband performance in cascaded SSPP LPFs, the single-cell S-parameters of the proposed topology are investigated. A single MASS unit exhibits a sharp cutoff and a deep transmission notch, allowing a wide stopband to be obtained with fewer cascaded cells. Radiation characteristics are subsequently quantified by a loss-decomposition method, and the MASS topology is found to suppress the radiation leakage of open-aperture ground-slotted structures, yielding a maximum radiation-loss reduction of approximately 75%. To validate the design methodology, a MASS-loaded GCPW-SSPP LPF is designed, fabricated, and measured. The measured results are in good agreement with the simulated ones, confirming the effectiveness of the proposed scheme. By simultaneously achieving a wide stopband, compact size, and suppressed radiation leakage, the proposed filter offers a promising low-interference filtering solution for highly integrated microwave and RF front-end systems. Full article

A structurally simple three-layer optical absorber is proposed and systematically investigated, consisting of a continuous Ti ground plane, a SiO₂ dielectric spacer, and a Ti tetrahedral nanostructure. The absorber is constructed on a periodic square unit cell, where the lateral dimension directly determines the base width and sidewall inclination angle of the tetrahedral structure, thereby enabling effective modulation of the optical response. Full-wave electromagnetic simulations performed using COMSOL Multiphysics (version 6.0) are employed to evaluate the influence of geometric parameters on broadband absorption behavior. The optimized structure achieves a near-unity absorptivity of 0.9999 at 200 nm and maintains an effective absorption bandwidth (absorptivity > 0.9) spanning 200–3000 nm, covering the ultraviolet, visible, and near-infrared spectral regions. Parametric analysis reveals that the tetrahedral height primarily governs long-wavelength extension through enhanced optical path length, graded-index transition, and improved electromagnetic field confinement, while the unit cell width strongly influences impedance matching and localized field localization. In contrast, the Ti ground layer thickness exhibits minimal influence once it exceeds the optical skin depth, confirming its primary role as a transmission-blocking reflective substrate. Impedance retrieval analysis shows that the real part of the normalized impedance remains close to unity and the imaginary part approaches zero over most of the operating range, demonstrating that the ultrabroadband absorption behavior is dominated by effective impedance matching rather than isolated narrowband resonances. Furthermore, electric and magnetic field distribution analyses reveal that electromagnetic energy dissipation is concentrated near the tetrahedral apex and metal–dielectric interfaces, indicating the coexistence of localized plasmonic modes, cavity-assisted absorption, and multi-scale optical confinement. Full article

As wireless networks evolve from 5G toward 6G, the complexity of the electromagnetic environment increases sharply. Spectrum usage expands significantly into millimetre-wave (mmWave) and terahertz (THz) high-frequency bands. Network node density and mobility increase markedly. Moreover, communication-sensing-computation functions are deeply integrated. Accurate, real-time, full-band Electromagnetic Spectrum Maps (ESMs) have become a core infrastructure for 6G spectrum situational awareness, Dynamic Spectrum Access (DSA), interference coordination, and Integrated Sensing and Communication (ISAC). However, while a growing body of recent work extends radio mapping to multi-band and temporal domains, the predominant focus of existing Radio Map research remains the two-dimensional spatial power distribution at a single fixed frequency—essentially a degenerate special case of ESM after the frequency and time dimensions are collapsed—and no existing survey unifies 3D spatial construction, time-varying prediction, and full 6G system integration under a shared 4D formalism. This paper focuses on the three core research dimensions of ESMs, i.e., 3D spatial ESM construction, dynamic time-varying ESM modelling and prediction, and ESM integration with 6G systems. Under a unified four-dimensional ESM framework (space × frequency × time × power), we clarify the hierarchical relationships among ESM/SEM/REM/Radio Map/Channel Knowledge Maps (CKMs). Then, we systematically review 3D ESM construction, dynamic ESM modelling and prediction, and the integration of ESM with CKM/Digital Twin Networks (DTNs)/ISAC. Finally, we identify five, core open problems that constrain the development of the field to provide a systematic reference for 6G intelligent spectrum management research. Full article

A pressing challenge of modern wireless networks is ensuring stable radio coverage inside buildings, where radio signal propagation is significantly complicated by the influence of building structures. Reinforced concrete walls, floor slabs, internal partitions, and energy-efficient windows with metallized coatings create substantial obstacles to the propagation of electromagnetic waves, causing reflection, absorption, and scattering. As a result, areas with weakened coverage are formed inside buildings, leading to deterioration in mobile communication quality and reduced data transmission rates. This study presents an experimental investigation of the received signal strength of mobile operators inside a multi-storey residential complex. An analysis was conducted to evaluate the impact of building height, architectural features, and construction materials on radio signal propagation. In addition, the frequency bands used in 4G LTE and 5G networks by mobile operators were examined. It was found that LTE networks mainly operate in the 1.8–2.1 GHz frequency range, whereas 5G networks operate in the n77 band (3.6–3.7 GHz), which provides higher data throughput but is characterized by greater signal attenuation when propagating inside buildings. To address this issue, a Distributed Antenna System (DAS) based on GPON technology was implemented in the studied building. The placement of antenna equipment on the roof enabled the efficient reception of the signal from the base station and its subsequent distribution inside the building through an internal antenna network. The measurement results demonstrated that the deployment of a GPON-based DAS significantly improves the received signal level and ensures more uniform radio coverage inside indoor environments. The obtained results confirm that the use of distributed antenna systems is an effective solution for compensating signal losses caused by the shielding effect of building structures and can significantly improve the quality of mobile communications in dense urban environments. The results show that the RSRP level in indoor environments without DAS decreases to approximately −100 to −110 dBm, while after deployment of the GPON-based DAS, it improves to −45 to −75 dBm. This corresponds to a signal gain of up to 40–50 dB, ensuring stable connectivity and significantly improved data transmission performance. Full article

This work introduces a compact multi-resonant metamaterial absorber designed to achieve efficient electromagnetic absorption over several microwave frequency bands. The proposed configuration is based on a hybrid resonator arrangement that promotes strong electromagnetic interaction and enables multiple resonant modes within a single unit cell. Consequently, six distinct absorption peaks are obtained at 2.4, 5.21, 6.88, 9.77, 12.61, and 14.99 GHz, covering S-, C-, X-, and Ku-band applications. The absorber exhibits high absorption performance, exceeding 97% across most operating frequencies and slightly lower value is observed of 91.13% at 12.61 GHz, which indicates effective impedance matching with free space and efficient energy dissipation mechanisms. The absorption characteristics are further examined through surface current distributions, electric field confinement, and effective medium analysis, demonstrating that the multi-band response originates from the interaction of multiple resonant elements and intrinsic material losses. Moreover, the proposed structure maintains stable performance for different polarization angles and oblique wave incidence, confirming its polarization-insensitive and angularly stable behavior. To validate the design, a prototype is fabricated and experimentally characterized using a free-space measurement setup, showing close agreement with the simulated results. The compact geometry, low fabrication cost, and scalability of the proposed absorber make it a promising candidate for applications such as electromagnetic interference mitigation, radar cross-section reduction, and modern wireless communication systems. Full article

In practical applications, high-temperature superconducting (HTS) cables or magnets may carry AC with DC bias, such as in superferric magnets, which can increase the AC loss of the cables or magnets. When the DC bias current is high, the resulting high loss can lead to a significant temperature rise in the cable or magnet and may even cause quench. Furthermore, different waveforms of the alternating current also result in different losses and temperature rises. Therefore, it is essential to investigate the AC loss of the cable under different current waveforms and DC bias levels using an electromagnetic–thermal coupling method. In this paper, an electromagnetic–thermal coupling model is used to investigate the AC loss and temperature rise characteristics of four stacked REBCO tapes under four typical current waveforms and various DC bias levels. The actual multilayer structure of REBCO tapes is considered in the numerical simulation, which facilitates the analysis of current distribution among different layers and its contribution to the total loss of the stacked cable. The results show that under zero DC bias or a small DC bias (0.1I_dc), the square-wave current yields the largest AC loss, while the triangular-wave current results in the smallest AC loss. The losses generated by the sawtooth and sinusoidal currents are comparable and intermediate between those of the two aforementioned waveforms. When the DC bias current is moderate (0.5I_dc) and the amplitude of the alternating current is greater than 0.5I_cable, the loss of the cable increases rapidly. The loss generated by the square-wave current is the largest, followed by the sinusoidal current, while the sawtooth and triangular currents produce the smallest losses. When the DC bias current is high (0.9I_dc), even a small amplitude alternating current results in high AC loss in the cable. Full article

Thermoacoustic power generation holds significant promise for applications such as solar thermal utilization, industrial waste heat recovery, and distributed energy systems, owing to its high efficiency and reliability. Conventional standing-wave and traveling-wave thermoacoustic generators, however, are often limited by bulky resonators and substantial acoustic power dissipation. Replacing the resonator with a linear alternator (LA) offers an effective means to improve system compactness and output performance. Nonetheless, under standing-wave acoustic conditions, the LA’s large piston swept volume increases the device size, thereby constraining overall compactness. To address this limitation, a novel moving-magnet LA with electromagnetic components integrated into the moving piston is proposed. Compared to conventional configurations, this design significantly reduces the size and weight of the alternator. Furthermore, the influence of different magnetic circuit configurations on output performance is systematically investigated, enabling optimization of the alternator design. Results demonstrate that the proposed alternator achieves a more compact structure while delivering output performance comparable to that of conventional external magnetic-circuit designs, thereby validating the feasibility of the proposed approach. Full article

Electron density is a fundamental parameter characterizing the ionosphere. Multiple ground-based and space-based detection technologies are applied to detect ionospheric electron density using artificial electromagnetic waves, based on the ionospheric effects of reflection, refraction, incoherent scattering, and doppler shift on radio waves. Lightning-generated whistlers (LGWs) constitute a natural signal with a wide spatiotemporal distribution that can substitute for these artificial transmissions, achieving global ionospheric detection. This paper proposes a method for reconstructing ionospheric electron density profiles by comparing simulated and observed dispersion of LGWs. We develop an LGW propagation model based on the finite-difference time-domain (FDTD) algorithm, where the background electron density is derived from the International Reference Ionosphere (IRI) model. The dispersion of simulated whistlers is compared with satellite observations, and a modification factor is introduced to modify the background electron density based on the relationship between dispersion and electron density. The approach is applied to two events, and the electron density modification effect is assessed with independent data sources. The results show that the errors between the modified electron density and the true value in two events are reduced by 62.81% and 69.29%, respectively, confirming the efficacy of the proposed method. Full article

This work presents the application of a Time-Domain Reflectometry (TDR) inversion algorithm for localizing water along a bi-wire cable acting as a distributed sensing element (SE), and for evaluating the uncertainty of the water position measurement. The TDR inversion relies on a simplified yet effective gray-box circuital model of the measurement system that, without attempting a full-wave electromagnetic (EM) simulation, reproduces with good accuracy any actually observed reflectograms. The model parameters are estimated from a single acquired reflectogram so as to reproduce the measured signal, without a prior EM characterization of the system components. The model provides the water localization and enables extensive simulation campaigns under realistic variations in water position, stimulus pulse duration, and disturbance effects. A specific measurement setup, designed to perform repeated measurements in controlled laboratory conditions, is analyzed in detail as a case study. The water localization error of the measurement system is statistically evaluated in terms of confidence intervals, bias, and standard deviation, by means of simulated measurements of the model, with different water positions and TDR pulse durations. Then, the uncertainty evaluation is validated through 45 actual measurements, using multiple SEs, and the same water positions and pulse durations. The work proves the viability and the performance of the presented TDR inversion method for both localization measurements and for their uncertainty evaluation under different experimental conditions. More generally, it establishes a general framework for TDR measurements and uncertainty evaluation combining physical modeling, simulation-based uncertainty evaluation, and experimental verification. Full article

In response to the need to monitor groundwater migration and structural damage to rock strata during tunnel excavation and coal mining, this paper presents a novel electromagnetic detection system that features continuous ground-based transmission and full-waveform underground observation. As the transmitted waveform is crucial for determining the distribution of induced eddy currents and the characteristics of the secondary field response, studying these response characteristics is essential for the system’s practical application. This study selects four typical transmission waveforms—step, triangular, half-sine and trapezoidal—and uses a tetrahedral, three-dimensional grid discretization method to analyze the transient electromagnetic full-wave response patterns of electrical and magnetic sources under different waveform excitations. This elucidates the propagation characteristics of electromagnetic fields in the medium. The research reveals that the waveform type during energization significantly influences the electromagnetic response, with the full-wave response characteristics of electrical and magnetic sources differing significantly in the near-source region and response trends converging in the far-source region. In practical detection, combining the advantages of the three-component responses of the electrical and magnetic sources can effectively improve detection accuracy. The findings of this study provide important theoretical support for optimizing the design of transient electromagnetic detection systems and precisely interpreting detection data. They also lay a theoretical foundation for electromagnetic detection applications in fields such as mineral resource exploration and engineering geological surveys. Full article

This paper presents the design and experimental validation of a compact low-pass filter based on a quasi-eight-shaped defected ground structure (DGS). The study begins with a single DGS resonator that perturbs the ground-plane current distribution, introducing additional effective inductance and capacitance. An equivalent circuit model is developed to provide physical insight into the resonant mechanism and to establish the relationship between the DGS geometry and the electromagnetic response. By incorporating microstrip stubs on the top layer, the resonant structure is transformed into a low-pass filtering configuration with improved passband characteristics. Subsequently, a higher-order topology composed of two identical quasi-eight DGS units and three microstrip stubs is implemented to significantly enhance the rejection performance and extend the stopband bandwidth. The fabricated prototype exhibits a measured cutoff frequency of approximately 2.1 GHz, with an insertion loss lower than 1 dB in the passband. A wide stopband extending from 2.8 GHz to 8 GHz is achieved, with attenuation exceeding 26 dB. The close agreement between the equivalent circuit model, full-wave electromagnetic simulations, and measured results confirms the effectiveness and physical consistency of the proposed design. Owing to its compact planar implementation and strong harmonic suppression capability, the proposed filter is suitable for microwave front-end and antenna applications. Full article

This paper proposes a millimeter-wave miniature on-chip bandpass filter (BPF) implemented using a 0.18 μm CMOS process. To address the issues of insufficient coupling capability, limited control of transmission zeros, and excessive chip area in traditional on-chip filters, a folded cross-interdigital coupling structure is proposed to enhance coupling efficiency and reduce size. The design incorporates metal–insulator–metal (MIM) capacitors to increase the coupling capacitance between resonators without increasing the area, and utilizes a defected ground structure (DGS) to modify the current distribution at the ground plane, generating additional transmission zeros to improve selectivity. An LC equivalent circuit model was established and verified through full-wave electromagnetic simulation, and the design was validated through chip fabrication and on-wafer measurements. The measurement results show an insertion loss of 3.36 dB and a fractional bandwidth of 49.1% at 32 GHz, with two transmission zeros. The core dimensions are 0.25 mm × 0.18 mm. This design achieves a good balance between miniaturization, selectivity, and insertion loss, making it suitable for millimeter-wave SoC applications. Full article
