Search Results (41)

Search Parameters:
Keywords = earth filling pressure

Order results
Result details
Results per page
Select all
Export citation of selected articles as:
15 pages, 3197 KiB
Article
Experimental and Numerical Investigation of Seepage and Seismic Dynamics Behavior of Zoned Earth Dams with Subsurface Cavities
by Iman Hani Hameed, Abdul Hassan K. Al-Shukur and Hassnen Mosa Jafer
GeoHazards 2025, 6(3), 37; https://doi.org/10.3390/geohazards6030037 - 17 Jul 2025
Viewed by 320
Abstract
Earth fill dams are susceptible to internal erosion and instability when founded over cavity-prone formations such as gypsum or karstic limestone. Subsurface voids can significantly compromise dam performance, particularly under seismic loading, by altering seepage paths, raising pore pressures, and inducing structural deformation. [...] Read more.
Earth fill dams are susceptible to internal erosion and instability when founded over cavity-prone formations such as gypsum or karstic limestone. Subsurface voids can significantly compromise dam performance, particularly under seismic loading, by altering seepage paths, raising pore pressures, and inducing structural deformation. This study examines the influence of cavity presence, location, shape, and size on the behavior of zoned earth dams. A 1:25 scale physical model was tested on a uniaxial shake table under varying seismic intensities, and seepage behavior was observed under steady-state conditions. Numerical simulations using SEEP/W and QUAKE/W in GeoStudio complemented the experimental work. Results revealed that upstream and double-cavity configurations caused the greatest deformation, including crest displacements of up to 0.030 m and upstream subsidence of ~7 cm under 0.47 g shaking. Pore pressures increased markedly near cavities, with peaks exceeding 2.7 kPa. Irregularly shaped and larger cavities further amplified these effects and led to dynamic factors of safety falling below 0.6. In contrast, downstream cavities produced minimal impact. The excellent agreement between experimental and numerical results validates the modeling approach. Overall, the findings highlight that cavity geometry and location are critical determinants of dam safety under both static and seismic conditions. Full article
Show Figures

Figure 1

21 pages, 7576 KiB
Article
Interpreting Global Terrestrial Water Storage Dynamics and Drivers with Explainable Deep Learning
by Haijun Huang, Xitian Cai, Lu Li, Xiaolu Wu, Zichun Zhao and Xuezhi Tan
Remote Sens. 2025, 17(13), 2118; https://doi.org/10.3390/rs17132118 - 20 Jun 2025
Viewed by 461
Abstract
Sustained reductions in terrestrial water storage (TWS) have been observed globally using Gravity Recovery and Climate Experiment (GRACE) satellite data since 2002. However, the underlying mechanisms remain incompletely understood due to limited record lengths and data discontinuity. Recently, explainable artificial intelligence (XAI) has [...] Read more.
Sustained reductions in terrestrial water storage (TWS) have been observed globally using Gravity Recovery and Climate Experiment (GRACE) satellite data since 2002. However, the underlying mechanisms remain incompletely understood due to limited record lengths and data discontinuity. Recently, explainable artificial intelligence (XAI) has provided robust tools for unveiling dynamics in complex Earth systems. In this study, we employed a deep learning technique (Long Short-Term Memory network, LSTM) to reconstruct global TWS dynamics, filling gaps in the GRACE record. We then utilized the Local Interpretable Model-agnostic Explanations (LIME) method to uncover the underlying mechanisms driving observed TWS reductions. Our results reveal a consistent decline in the global mean TWS over the past 22 years (2002–2024), primarily influenced by precipitation (17.7%), temperature (16.0%), and evapotranspiration (10.8%). Seasonally, the global average of TWS peaks in April and reaches a minimum in October, mirroring the pattern of snow water equivalent with approximately a one-month lag. Furthermore, TWS variations exhibit significant differences across latitudes and are driven by distinct factors. The largest declines in TWS occur predominantly in high latitudes, driven by rising temperatures and significant snow/ice variability. Mid-latitude regions have experienced considerable TWS losses, influenced by a combination of precipitation, temperature, air pressure, and runoff. In contrast, most low-latitude regions show an increase in TWS, which the model attributes mainly to increased precipitation. Notably, TWS losses are concentrated in coastal areas, snow- and ice-covered regions, and areas experiencing rapid temperature increases, highlighting climate change impacts. This study offers a comprehensive framework for exploring TWS variations using XAI and provides valuable insights into the mechanisms driving TWS changes on a global scale. Full article
Show Figures

Figure 1

18 pages, 1912 KiB
Article
Long-Term Stress Characteristics and Earth Pressure Calculation Method for High-Fill Box Culverts
by Zengpan Jia, Baoguo Chen, Guoqing Ren, Ruiping Luo and Lan Ding
Buildings 2025, 15(11), 1954; https://doi.org/10.3390/buildings15111954 - 4 Jun 2025
Viewed by 269
Abstract
Setting an expandable polystyrene (EPS) board on box culverts can reduce the vertical earth pressure (VEP) acting on the culvert roof. However, long-term backfill load will induce creep in both the EPS board and the surrounding soil, resulting in a change in the [...] Read more.
Setting an expandable polystyrene (EPS) board on box culverts can reduce the vertical earth pressure (VEP) acting on the culvert roof. However, long-term backfill load will induce creep in both the EPS board and the surrounding soil, resulting in a change in the stress state of the culvert–soil system. A mechanical model for the long-term interaction of “backfill–EPS board–box culvert” was established, and theoretical formulas were derived for calculating the earth pressure around the culvert. Numerical simulation was employed to validate the accuracy of the proposed theoretical approach. Research indicates that, with EPS board, the VEP decreases rapidly then slightly increases with time and eventually approaches an asymptotic value, ultimately decreasing by 33%. However, the horizontal earth pressure (HEP) shows the opposite pattern and ultimately increases by 15%. The foundation contact pressure (FCP) increases nonlinearly and reaches a stable value, ultimately increasing by 10.2%. Without the EPS board, the VEP and HEP are significantly different from those with the EPS board. Although EPS boards can reduce the VEP on the culvert, attention should be paid to the variation of HEP caused by the creep of the EPS board and backfill. Full article
(This article belongs to the Section Building Structures)
Show Figures

Figure 1

23 pages, 16870 KiB
Article
Analysis of the Dynamic Active Earth Pressure from c-φ Backfill Considering the Amplification Effect of Seismic Acceleration
by Zhiliang Sun, Wei Wang and Hanghang Liu
Appl. Sci. 2025, 15(11), 5966; https://doi.org/10.3390/app15115966 - 26 May 2025
Viewed by 365
Abstract
This study extends the method of pseudo-dynamic analysis based on the Mononobe-Okabe (M-O) method by comprehensively incorporating the seismic acceleration response characteristics of backfill soil and the cohesive properties of the fill. The proposed method is adapted for backfill soils by incorporating the [...] Read more.
This study extends the method of pseudo-dynamic analysis based on the Mononobe-Okabe (M-O) method by comprehensively incorporating the seismic acceleration response characteristics of backfill soil and the cohesive properties of the fill. The proposed method is adapted for backfill soils by incorporating the cohesion c and internal friction angle φ (including scenarios with non-horizontal backfill surfaces). Theoretical formulas for the active earth pressure coefficient and its distribution on rigid retaining walls under the most unfavorable conditions are derived. The rationality of the proposed formulas is preliminarily verified using model test data from the relevant literature. A detailed parametric sensitivity analysis reveals the following trends: The active earth pressure coefficient Ka increases with increases in the amplification factor fa, wall backface inclination angle θ, backfill slope inclination i, lateral vibration period T, and horizontal seismic acceleration coefficient kh; Ka decreases with an increasing internal friction angle φ and cohesion/unit weight ratio c/γH. The failure wedge angle αa increases with increases in φ, θ, and c/γH, decreases with increases in fa, the soil–wall friction angle δ, i, T, kh, and the vertical seismic acceleration coefficient kv. Calculations are carried out to further identify the critical tensile stress depth in cohesive backfill soils using c and φ. The proposed analysis highlights the necessity of considering the seismic acceleration amplification factor fa, backfill cohesion c, and soil–wall adhesion cw in active earth pressure calculations. This study recommends that the seismic design of retaining walls should involve appropriate evaluation of the the actual cohesion of backfill materials and fully account for the acceleration amplification effects under seismic loading. Full article
Show Figures

Figure 1

17 pages, 5223 KiB
Article
A Study on the Response of Coral Sand Foundations with Different Particle Gradations Reinforced Using a Vibroflotation Method
by Yiwen Xin, Xuanming Ding, Jinqiao Zhao, Hong Wang and Chunyong Jiang
J. Mar. Sci. Eng. 2025, 13(4), 666; https://doi.org/10.3390/jmse13040666 - 26 Mar 2025
Viewed by 425
Abstract
Vibroflotation has proven to be an effective method for treating loose and unevenly graded coral sand foundations formed through hydraulic filling. In this study, a series of model tests were conducted to investigate the effects of particle gradations on the response of coral [...] Read more.
Vibroflotation has proven to be an effective method for treating loose and unevenly graded coral sand foundations formed through hydraulic filling. In this study, a series of model tests were conducted to investigate the effects of particle gradations on the response of coral sand foundation reinforced by vibroflotation. The main focus was on analyzing the changes in excess pore water pressure (EPWP) and horizontal earth pressure. Cone penetration tests (CPTs) were then used to evaluate the effectiveness of vibroflotation. The results indicate that the maximum settlement occurs after the first vibroflotation, with surface settlement significantly increasing as the distance to the vibro-point decreases. The reinforcement range expands radially, and the foundation can achieve a medium or dense state after vibroflotation. During the penetration stage, the EPWP rapidly peaks and increases with depth. Shallow foundations exhibit a higher excess pore pressure ratio compared to deep foundations. Foundations with lower coarse particle content show higher EPWPs compared to those with higher coarse particle content. Lower vibration frequency results in diminished reinforcement effects in foundations with high coarse particle content and increases the difficulty of penetration. Additionally, the residual soil pressure in foundations with high coarse particle content significantly rises after three vibroflotation reinforcements. The increase in strength after reinforcement is more pronounced because the foundation has a greater coarse particle content. The reinforcement effect diminishes with increasing distance from the vibrator. Full article
(This article belongs to the Section Ocean Engineering)
Show Figures

Figure 1

16 pages, 6409 KiB
Article
Experimental and Mechanical Characteristics of Xanthan Gum and Calcium Lignosulfonate-Cured Gravel Soil
by Cheng Peng, Jierong Zhu, Dongxing Wang, Haiyan Zhou and Junjie Bi
Appl. Sci. 2025, 15(6), 3339; https://doi.org/10.3390/app15063339 - 19 Mar 2025
Viewed by 586
Abstract
The objective of this study was to enhance the mechanical properties of gravelly soil and to consider the binding and filling effects of xanthan gum and calcium lignosulfonate. To this end, gravelly soil samples were prepared with various dosages of xanthan gum and [...] Read more.
The objective of this study was to enhance the mechanical properties of gravelly soil and to consider the binding and filling effects of xanthan gum and calcium lignosulfonate. To this end, gravelly soil samples were prepared with various dosages of xanthan gum and calcium lignosulfonate, and their curing effects were investigated. The mechanical properties and strength parameters of the cured gravelly soil were investigated using unconfined compressive strength (UCS) tests and conventional triaxial compression tests. Furthermore, scanning electron microscopy (SEM) was employed to examine the microstructure and curing mechanisms of the gravelly soil treated with these additives. The findings demonstrate that as the dosage increases, both xanthan gum and calcium lignosulfonate markedly enhance the compressive strength and shear strength of the gravelly soil. The curing effect of xanthan gum was found to be more pronounced with higher dosages, while the optimal curing effect for calcium lignosulfonate was achieved at a dosage of 4%. The gravelly soil treated with xanthan gum exhibited superior performance compared to that treated with calcium lignosulfonate when the same dosage was used. Moreover, at elevated confining pressures, the binding effect of xanthan gum and calcium lignosulfonate on the gravelly soil was less pronounced than the strength effect imparted by the confining pressure. This suggests that the impact of dosage on the shear strength of the gravelly soil is diminished at higher confining pressures. The stabilization of crushed stone soil by xanthan gum is a complex process that involves two main mechanisms: bonding and cementation, and filling and film-forming. The curing mechanism of calcium lignosulfonate-cured gravelly soil can be summarized as follows: ion exchange, adsorption and encapsulation, and pore filling and binding effects. The findings of this research offer significant insights that are pertinent to the construction of high earth–rock dams and related engineering applications. Full article
Show Figures

Figure 1

20 pages, 7041 KiB
Article
Study on Calibration Tests for Interface-Type Earth Pressure Cell Based on Matching Error Analysis
by Mingyu Li, Longwei Zhu, Jicheng Shu, Zhenzhen Lu and Yunlong Liu
Sensors 2024, 24(23), 7778; https://doi.org/10.3390/s24237778 - 5 Dec 2024
Viewed by 984
Abstract
The stress status of a soil pressure cell placed in soil is very different from its stress state in a uniform fluid medium. The use of the calibration coefficient provided by the soil pressure cell manufacturer will produce a large error. In order [...] Read more.
The stress status of a soil pressure cell placed in soil is very different from its stress state in a uniform fluid medium. The use of the calibration coefficient provided by the soil pressure cell manufacturer will produce a large error. In order to improve the measurement accuracy of the interface-type earth pressure cell placed in soil, this paper focuses on a single-membrane resistive earth pressure cell installed on the surface of a structure, analyzing the influence of loading and unloading cycles, the thickness and particle size of the sand filling, and the depth of the earth pressure cell inserted in the structure on the calibration curve and matching error, which were analyzed through calibration tests. The results show that when the sand filling thickness is less than D (D is the diameter of the earth pressure cell), the calibration curve is unstable in relation to the increase in the number of loading and unloading cycles, which will cause the sand calibration coefficient used for stress conversion to not be used normally. When the sand filling thickness in the calibration bucket increases from 0.285D to 5D, the absolute value of the matching error first decreases and then increases, such that the optimal sand filling thickness is 3D. The output of the earth pressure cell increases with the decrease in sand particle size under the same load, and there is a significant difference between the theoretical calculation value and the experimental value of the matching error; aiming at this difference, an empirical formula is derived to reflect the ratio of the diameter of the induction diaphragm of the earth pressure cell to the maximum particle size of the sand filling. When the depth of the earth pressure cell inserted in the structure is “0”, the sensing surface is flush with the structure and the absolute value of the matching error is the smallest. Changes in the horizontal placement of the soil pressure cell in the calibration bucket result in significant differences in both the output and hysteresis of the calibration curve. To improve the measurement accuracy of soil pressure cells in scaled tests for applications such as in the retaining walls of excavation pits, tunnel outer surfaces, pile tops, pile ends, and soil pressure measurements in soil, calibration of the soil pressure cells is required before testing. Due to the considerable difference in the stress states of the soil pressure cell between granular media and uniform fluid media, calibration in soil is essential. During in-soil calibration, factors such as cyclic loading and unloading, soil compression, sand thickness and particle size, and the placement of the soil pressure cell all affect the calibration results. This paper primarily investigates the influence of these factors on the calibration curve and matching error. This study found that, as the sand thickness increases, the matching error decreases initially and then increases. Full article
(This article belongs to the Section Physical Sensors)
Show Figures

Figure 1

19 pages, 8323 KiB
Article
Pore Types and Dolomite Reservoir Genesis of the Fifth Member of the Ordovician Majiagou Formation in the Central and Eastern Ordos Basin
by Shilei Chen, Rong Dai and Shunshe Luo
Appl. Sci. 2024, 14(23), 10976; https://doi.org/10.3390/app142310976 - 26 Nov 2024
Viewed by 872
Abstract
The Ordovician dolomite in the Ordos Basin is an important natural gas reservoir. Exploring dolomite genesis and the factors influencing reservoir characteristics is essential for deep carbonate rock exploration. This study offers a comprehensive analysis of dolomite evolution using methods such as thin-section [...] Read more.
The Ordovician dolomite in the Ordos Basin is an important natural gas reservoir. Exploring dolomite genesis and the factors influencing reservoir characteristics is essential for deep carbonate rock exploration. This study offers a comprehensive analysis of dolomite evolution using methods such as thin-section petrography, isotope analysis, and trace and rare earth elements. The analysis shows that: Based on petrographic observations of the Majiagou Formation in the study area, the dolomite in the study area can be divided into residual oolitic dolomite of synsedimentary or metasomatic origin, micritic dolomite of secondary metasomatism or recrystallization origin, powder crystal dolomite, and fine crystal dolomite. Reservoir pores mainly develop intergranular pores, mold pores, dissolved pores, and fractures. Combined with the characteristics of major elements, trace elements, carbon and oxygen isotopes, rare earth elements, and inclusions in the study area, it can be concluded that the fifth member dolomite of the Majiagou Formation is of shallow–medium burial origin. The diagenetic evolution sequence from the penecontemporaneous period to the middle–deep burial period in the study area is penecontemporaneous dolomite, anhydrite dissolution → seepage silt filling, freshwater dolomite, calcite, and gypsum filling, pressure solution compaction, calcite partial dissolution → gypsum filling, karst cave, buried hydrothermal dolomite, dolomite partial dissolution → calcite complete dissolution, pore dissolution expansion, and quartz pyrite filling. In the early stage of compaction and pressure solution, the primary pores are rapidly reduced, and in the later stage, sutures are generated to provide channels for reservoir fluid migration. The recrystallization reduces the porosity during the middle–deep burial period. Full article
(This article belongs to the Section Earth Sciences)
Show Figures

Figure 1

16 pages, 6193 KiB
Article
Autonomous Planetary Liquid Sampler (APLS) for In Situ Sample Acquisition and Handling from Liquid Environments
by Miracle Israel Nazarious, Leonie Becker, Maria-Paz Zorzano and Javier Martin-Torres
Sensors 2024, 24(18), 6107; https://doi.org/10.3390/s24186107 - 21 Sep 2024
Viewed by 1491
Abstract
Many natural and artificial liquid environments, such as rivers, oceans, lakes, water storage tanks, aquariums, and urban water distribution systems, are difficult to access. As a result, technology is needed to enable autonomous liquid sampling to monitor water quality and ecosystems. Existing in [...] Read more.
Many natural and artificial liquid environments, such as rivers, oceans, lakes, water storage tanks, aquariums, and urban water distribution systems, are difficult to access. As a result, technology is needed to enable autonomous liquid sampling to monitor water quality and ecosystems. Existing in situ sample acquisition and handling systems for liquid environments are currently limited to a single use and are semi-autonomous, relying on an operator. Liquid sampling systems should be robust and light and withstand long-term operation in remote locations. The system components involved in liquid sampling should be sterilisable to ensure reusability. Here, we introduce a prototype of a liquid sampler that can be used in various liquid environments and may be valuable for the scientific characterisation of different natural, remote, and planetary settings. The Autonomous Planetary Liquid Sampler (APLS) is equipped with pre-programmed, fully autonomous extraction, cleaning, and sterilisation functionalities. It can operate in temperatures between −10 °C and 60 °C and pressure of up to 0.24 MPa (~24 m depth below mean sea level on Earth). As part of the control experiment, we demonstrate its safe and robust autonomous operation in a laboratory environment using a liquid media with Bacillus subtilis. A typical sampling procedure required 28 s to extract 250 mL of liquid, 5 s to fill the MilliQ water, 25 s for circulation within the system for cleaning and disposal, and 200 s to raise the system temperature from ~30 °C ambient laboratory temperature to 150 °C. The temperature is then maintained for another 3.2 h to sterilise the critical parts, allowing a setup reset for a new experiment. In the future, the liquid sampler will be combined with various existing analytical instruments to characterise the liquid solution and enable the autonomous, systematic monitoring of liquid environments on Earth. Full article
(This article belongs to the Section Environmental Sensing)
Show Figures

Figure 1

41 pages, 10492 KiB
Review
Water Dams: From Ancient to Present Times and into the Future
by Andreas N. Angelakis, Alper Baba, Mohammad Valipour, Jörg Dietrich, Elahe Fallah-Mehdipour, Jens Krasilnikoff, Esra Bilgic, Cees Passchier, Vasileios A. Tzanakakis, Rohitashw Kumar, Zhang Min, Nicholas Dercas and Abdelkader T. Ahmed
Water 2024, 16(13), 1889; https://doi.org/10.3390/w16131889 - 1 Jul 2024
Cited by 8 | Viewed by 7087
Abstract
Since ancient times, dams have been built to store water, control rivers, and irrigate agricultural land to meet human needs. By the end of the 19th century, hydroelectric power stations arose and extended the purposes of dams. Today, dams can be seen as [...] Read more.
Since ancient times, dams have been built to store water, control rivers, and irrigate agricultural land to meet human needs. By the end of the 19th century, hydroelectric power stations arose and extended the purposes of dams. Today, dams can be seen as part of the renewable energy supply infrastructure. The word dam comes from French and is defined in dictionaries using words like strange, dike, and obstacle. In other words, a dam is a structure that stores water and directs it to the desired location, with a dam being built in front of river valleys. Dams built on rivers serve various purposes such as the supply of drinking water, agricultural irrigation, flood control, the supply of industrial water, power generation, recreation, the movement control of solids, and fisheries. Dams can also be built in a catchment area to capture and store the rainwater in arid and semi-arid areas. Dams can be built from concrete or natural materials such as earth and rock. There are various types of dams: embankment dams (earth-fill dams, rock-fill dams, and rock-fill dams with concrete faces) and rigid dams (gravity dams, rolled compacted concrete dams, arch dams, and buttress dams). A gravity dam is a straight wall of stone masonry or earthen material that can withstand the full force of the water pressure. In other words, the pressure of the water transfers the vertical compressive forces and horizontal shear forces to the foundations beneath the dam. The strength of a gravity dam ultimately depends on its weight and the strength of its foundations. Most dams built in ancient times were constructed as gravity dams. An arch dam, on the other hand, has a convex curved surface that faces the water. The forces generated by the water pressure are transferred to the sides of the structure by horizontal lines. The horizontal, normal, and shear forces resist the weight at the edges. When viewed in a horizontal section, an arch dam has a curved shape. This type of dam can also resist water pressure due to its particular shape that allows the transfer of the forces generated by the stored water to the rock foundations. This article takes a detailed look at hydraulic engineering in dams over the millennia. Lessons should be learned from the successful and unsuccessful applications and operations of dams. Water resource managers, policymakers, and stakeholders can use these lessons to achieve sustainable development goals in times of climate change and water crisis. Full article
(This article belongs to the Section Soil and Water)
Show Figures

Figure 1

16 pages, 8876 KiB
Article
Experimental Study on Mechanical Properties of Reinforced Soil and Frame Beam Anchor Combination System
by Jiangfei He and Leihua Yao
Buildings 2024, 14(5), 1372; https://doi.org/10.3390/buildings14051372 - 10 May 2024
Cited by 1 | Viewed by 1512
Abstract
To address issues with excessive displacement, deformation, and insufficient load bearing capacity in high-fill-reinforced soil-retaining walls, a novel reinforced soil–frame anchor combination system was developed. Despite the limited existing research on its mechanical properties and synergy, a physical model test was conducted to [...] Read more.
To address issues with excessive displacement, deformation, and insufficient load bearing capacity in high-fill-reinforced soil-retaining walls, a novel reinforced soil–frame anchor combination system was developed. Despite the limited existing research on its mechanical properties and synergy, a physical model test was conducted to investigate the system’s behavior. The test focused on the horizontal displacement of the frame beam wall, grid strain, wall back earth pressure, and anchor strain. Results indicated that anchor prestress effectively controlled horizontal deformation, limiting it to 65% of the original displacement value. Additionally, as the top load increased, strain in the bottom bars showed minor changes, while strain in the middle and upper bars exhibited significant sensitivity to load variations. The application of anchor prestress reduced strain in each reinforcement layer, enhancing the geogrid’s load bearing capacity. Furthermore, anchor prestress altered the distribution of earth pressure within the system, establishing a synergistic relationship between reinforced soil and frame beam anchors. This stress transfer mechanism improved overall system performance, as demonstrated in the test. Overall, the study confirmed the benefits and superior performance of the combined system. Full article
(This article belongs to the Special Issue Advances and Applications in Geotechnical and Structural Engineering)
Show Figures

Figure 1

19 pages, 11017 KiB
Article
Ground Deformation of Shield Tunneling through Composite Strata in Coastal Areas
by Xiong Wu, Jiangbo Xu, Shaowei Wang, Peng Sha, Zemin Han, Xinyu Chen, Sheng Shu, Wei Qiao and Xianglong Zeng
Buildings 2024, 14(5), 1236; https://doi.org/10.3390/buildings14051236 - 26 Apr 2024
Cited by 4 | Viewed by 1285
Abstract
In order to mitigate ground deformation during shield construction in both upper soft and lower hard strata of coastal areas, a numerical simulation was executed. This simulation assessed surface deformation under varying stratum ratios, grouting pressures, and earth bin pressures. The evaluation was [...] Read more.
In order to mitigate ground deformation during shield construction in both upper soft and lower hard strata of coastal areas, a numerical simulation was executed. This simulation assessed surface deformation under varying stratum ratios, grouting pressures, and earth bin pressures. The evaluation was primarily based on the amount of ground deformation, which revealed that hard rock strata offer superior settlement control compared to soft rock strata. The excavation of the right tunnel line increased disturbance to the left line at higher stratum ratios. Surface deformation demonstrated a linear correlation with earth pressure, with 130 kPa identified as the optimal point. Higher pressures resulted in extrusion deformation and ground uplift. Grouting pressure had a minimal impact on stratum deformation over time. The stratum ratio exerted the most significant influence on settlement, followed by earth pressure, with grouting pressure having the least impact. In the context of coastal tunnel construction, hard rock excavation is favored. Earth pressure must be balanced to prevent subsidence or uplift, while excessive grouting pressure does not significantly reduce subsidence. Grouting pressure should ensure the complete filling of voids. Full article
(This article belongs to the Special Issue Foundation Treatment and Building Structural Performance Enhancement)
Show Figures

Figure 1

17 pages, 5377 KiB
Article
Study on Impoundment Deformation Characteristics and Crack of High Core Rockfill Dam Based on Inversion Parameters
by Litan Pan, Bo Wu, Daquan Wang, Xiongxiong Zhou, Lijie Wang and Yi Zhang
Water 2024, 16(1), 188; https://doi.org/10.3390/w16010188 - 4 Jan 2024
Cited by 4 | Viewed by 2180
Abstract
In the numerical simulation of earth-rock dam, accurate and reliable mechanical parameters of the dam material are the important basis for dam deformation predictions and dam safety evaluations. Based on the deformation monitoring data of Luding core wall rockfill dam, the rheological parameters [...] Read more.
In the numerical simulation of earth-rock dam, accurate and reliable mechanical parameters of the dam material are the important basis for dam deformation predictions and dam safety evaluations. Based on the deformation monitoring data of Luding core wall rockfill dam, the rheological parameters of rockfill and core wall materials are inverted in this paper. Combined with the actual filling and impoundment process of the dam, the numerical simulation is carried out, and the stress deformation and differential settlement of the dam after completion and impoundment are analyzed. The results showed that the stress deformation results of the dam based on the inversion parameters were in good agreement with the actual deformation. The horizontal displacement, settlement, and principal stress of the dam during the completion period were symmetrically distributed along the core wall. The maximum horizontal displacement occurred at the main dam on both sides of the core wall and the upstream and downstream dam slopes, and the maximum settlement occurred in the middle of the core wall. During the impoundment period, under the action of reservoir water pressure and upstream rockfill wetting deformation, the deformation and stress of the dam body no longer met the symmetrical distribution law, and the maximum horizontal displacement of the dam body during the impoundment period was located at 2/3 of the upstream dam slope. The maximum settlement of the dam body was located at 1/2 of the dam height. The maximum principal stress on the upstream side of the core wall was located on the left side of the bottom of the core wall, and the minimum principal stress was also located on the left side of the bottom of the core wall. The simulation results of the deformation and stress met the general law of earth-rock dam engineering. During the completion period, the deformation inclination of the dam crest was less than 1%. During the impoundment period, the deformation inclination of the dam crest area increased due to the wetting deformation of the upstream rockfill material. At the same time, the deformation inclination of the dam crest axis was larger than that of the upstream and downstream sides, and the deformation inclination of the dam crest at the middle of the valley was the largest, but it did not exceed 3%, that is, there would be no longitudinal cracks, which is consistent with the actual situation. The research results can better predict the stress deformation and crack of the dam body, and provide important support for dam safety evaluations. Full article
(This article belongs to the Special Issue Research Advances in Hydraulic Structure and Geotechnical Engineering)
Show Figures

Figure 1

12 pages, 20688 KiB
Article
Data Downloaded via Parachute from a NASA Super-Pressure Balloon
by Ellen L. Sirks, Richard Massey, Ajay S. Gill, Jason Anderson, Steven J. Benton, Anthony M. Brown, Paul Clark, Joshua English, Spencer W. Everett, Aurelien A. Fraisse, Hugo Franco, John W. Hartley, David Harvey, Bradley Holder, Andrew Hunter, Eric M. Huff, Andrew Hynous, Mathilde Jauzac, William C. Jones, Nikky Joyce, Duncan Kennedy, David Lagattuta, Jason S.-Y. Leung, Lun Li, Stephen Lishman, Thuy Vy T. Luu, Jacqueline E. McCleary, Johanna M. Nagy, C. Barth Netterfield, Emaad Paracha, Robert Purcaru, Susan F. Redmond, Jason D. Rhodes, Andrew Robertson, L. Javier Romualdez, Sarah Roth, Robert Salter, Jürgen Schmoll, Mohamed M. Shaaban, Roger Smith, Russell Smith, Sut Ieng Tam and Georgios N. Vassilakisadd Show full author list remove Hide full author list
Aerospace 2023, 10(11), 960; https://doi.org/10.3390/aerospace10110960 - 14 Nov 2023
Cited by 7 | Viewed by 32719
Abstract
In April 2023, the superBIT telescope was lifted to the Earth’s stratosphere by a helium-filled super-pressure balloon to acquire astronomical imaging from above (99.5% of) the Earth’s atmosphere. It was launched from New Zealand and then, for 40 days, circumnavigated the globe five [...] Read more.
In April 2023, the superBIT telescope was lifted to the Earth’s stratosphere by a helium-filled super-pressure balloon to acquire astronomical imaging from above (99.5% of) the Earth’s atmosphere. It was launched from New Zealand and then, for 40 days, circumnavigated the globe five times at a latitude 40 to 50 degrees south. Attached to the telescope were four “drs” (Data Recovery System) capsules containing 5 TB solid state data storage, plus a gnss receiver, Iridium transmitter, and parachute. Data from the telescope were copied to these, and two were dropped over Argentina. They drifted 61 km horizontally while they descended 32 km, but we predicted their descent vectors within 2.4 km: in this location, the discrepancy appears irreducible below ∼2 km because of high speed, gusty winds and local topography. The capsules then reported their own locations within a few metres. We recovered the capsules and successfully retrieved all of superBIT’s data despite the telescope itself being later destroyed on landing. Full article
(This article belongs to the Special Issue Space Telescopes & Payloads)
Show Figures

Figure 1

18 pages, 5493 KiB
Article
An Experimental Study on Estimation of the Lateral Earth Pressure Coefficient (K) from Shaft Friction Resistance of Model Piles under Axial Load
by Huseyin Suha Aksoy, Nichirvan Ramadhan Taher, Aykut Ozpolat, Mesut Gör and Omer Muhammad Edan
Appl. Sci. 2023, 13(16), 9355; https://doi.org/10.3390/app13169355 - 17 Aug 2023
Cited by 2 | Viewed by 2239
Abstract
Estimating a pile shaft’s frictional capacity is challenging and has been a controversial subject among researchers. In this study, the shaft friction resistance of non-displacement (pre-installed) model piles under axial load was investigated. Four different model piles were used, including steel, timber, and [...] Read more.
Estimating a pile shaft’s frictional capacity is challenging and has been a controversial subject among researchers. In this study, the shaft friction resistance of non-displacement (pre-installed) model piles under axial load was investigated. Four different model piles were used, including steel, timber, and two composite piles (FRP and PVC filled with concrete). The angle of interface friction (δ) between test sand, and pile materials was determined using an interface shear test (IST) at four relative densities. Axial pile load experiments were implemented in a soil tank and piles were embedded into loose to very dense sand. Model pile load tests were performed in such a way that there was no end (point) bearing capacity (only friction was generated), and lateral friction resistance between the pile material and the soil along the pile shaft formed the complete bearing capacity of the model pile. According to experimental results, it was observed that, with increasing sand relative density and surface roughness of the pile material, the shaft friction resistance of the model pile increases. A back-calculation analysis was also performed to find the values of lateral earth pressure coefficient (K) using Burland’s (1973) equation with the help of measured shaft friction capacity of the model pile load test. By performing multivariate regression analysis, an equation was obtained between the back-calculated lateral earth pressure coefficient (K) and other parameters. The obtained equation was used to calculate the K values given in other studies in the literature. It was determined that the obtained equation was in good agreement with the data in other studies. This equation can be beneficial in practice and can be advantageous for further study in the future. Full article
Show Figures

Figure 1
