Optical sensing technologies, particularly refractive index and temperature sensing, are pivotal in biomedical, environmental, and industrial applications. This study introduces a dual-parameter all-dielectric transmissive grating sensor leveraging symmetry-protected bound states in the continuum (BICs). A one-dimensional silicon grating on a silica substrate was designed and analyzed using finite element analysis software. The proposed grating structure enables the excitation of two distinct BICs, both exhibiting high quality factors (Q-factors) of $Q_{\mathrm{I}}=8.03\times {10}^4$ for Mode I and $Q_{\mathrm{I}\mathrm{I}}=4.48\times {10}^4$ for Mode II. These modes demonstrate significantly different sensing characteristics due to their unique field distributions: Mode I predominantly confines its electromagnetic field within the grating slits, achieving an outstanding refractive index (RI) sensitivity of ${S_{\mathrm{R}\mathrm{I}}}^{\mathrm{I}}=406 \mathrm{n}\mathrm{m}/\mathrm{R}\mathrm{I}\mathrm{U}$ with a minor thermal sensitivity of ${S_{\mathrm{T}}}^{\mathrm{I}}=0.052 \mathrm{n}\mathrm{m}/°\mathrm{C}$. In contrast, Mode II concentrates its field energy in the silicon substrate, resulting in enhanced thermal sensitivity of ${S_{\mathrm{T}}}^{\mathrm{I}\mathrm{I}}=0.078 \mathrm{n}\mathrm{m}/°\mathrm{C}$ while maintaining a refractive index sensitivity of ${S_{\mathrm{R}\mathrm{I}}}^{\mathrm{I}\mathrm{I}}=220 \mathrm{n}\mathrm{m}/\mathrm{R}\mathrm{I}\mathrm{U}$. This complementary sensitivity profile between the two modes establishes an ideal platform for developing a dual-parameter sensing system capable of simultaneously monitoring both refractive index variations and temperature changes. These results highlight the correlation between mode field distribution characteristics and sensing sensitivity performance, and enabling high Q-factor dual-parameter sensing with potential applications in lab-on-a-chip systems and real-time biomolecular monitoring. Full article

This study presents a novel method for dynamically tuning singular states in one-dimensional (1D) photonic lattices (PLs) using air-slit-based structural modifications. Singular states, arising from symmetry-breaking-induced resonance radiation, generate diverse spectral features through interactions between resonance modes and background radiation. By strategically incorporating air slits to break symmetry in 1D PLs, we demonstrated effective control of resonance positions, enabling dual functionalities including narrowband band pass and notch filtering. These singular states originate from asymmetric guided-mode resonances (aGMRs), which can be interpreted by analytical modeling of the equivalent slab waveguide. Moreover, the introduction of multiple air slits significantly enhances spectral tunability by inducing multiple folding behaviors in the resonance bands. This approach allows for effective manipulation of optical properties through simple adjustments of air-slit displacements. This work provides great potential for designing multifunctional photonic devices with advanced metamaterial technologies. Full article

In order to reveal the heat transfer mechanism of CO₂ injection and extraction in the fracture network of geothermal reservoir rock, based on the assumption of a dual-media model and considering the characteristics of the rock matrix and the fracture network, the changes in the physical properties of the heat transfer fluid, and the effects of multi-field coupling, a coupled thermo–hydro–mechanical (THM) model of CO₂ injection and extraction heat transfer was established. A numerical simulation study was carried out to investigate the evolution of injection and extraction temperature and heat extraction performance under the influence of different factors in the randomly distributed fracture network of the reservoir rock, which has a horizontal slit and a high-angle slit, with CO₂ as the heat transfer fluid. The results show that the heat exchange efficiency of reservoir fracture is higher than that of rock matrix; compared with water, the CO₂ heat extraction rate is low, and the temperature drop in production wells is small, which is favorable to the long-term exploitation of geothermal reservoirs. if the horizontal distance between the production wells and the injection wells is far and the fracture connectivity is good, the heat exchange is strong and the heat extraction rate is higher; increasing the CO₂ injection rate will increase the range of the low-temperature area, reduce the temperature of the production wells, and increase the heat extraction rate in a short period of time; and the heat extraction rate will increase in the later stages. The increase in CO₂ injection rate will rapidly increase the range of the low-temperature area in a short time, decrease the temperature of the production well and increase the heat extraction rate, and then the growth of the heat extraction rate tends to stabilize in the later stages; the width ratio of horizontal fracture and high-angle fracture affects the direction of heat exchange, the temperature of production well and the heat extraction rate, and the influence is more significant when the width ratio is greater than 1; the temperature of the production well decreases fastest, the increase in the heat extraction rate is largest, and the effects on the temperature of the production well and the heat extraction rate are insignificant when it is close to the production well. The increase in the heat extraction rate is slower when close to the injection well. Full article

In this paper, the performance of a Dual-Stator Winding Synchronous Reluctance Generator (SynRG) suitability for off-grid wind power generation is analyzed. The rotor of the SynRG has a slitted-rotor core to improve selected vital performance parameters. The SynRG with a slitted-rotor core was modeled using a two-dimensional (2D) Finite Element Method (FEM) to study the electromagnetic performance of key parameters of interest. To validate the FEA results, a prototype of the SynRG with a slitted rotor was tested in the laboratory for no-load operation and load operation for unity, lagging, and leading power factors. To evaluate the capability of the SynRG with a slitted-rotor core to operate in a wind turbine environment, the machine was modeled and simulated in Matlab/Simulink (R2023a) for dynamic responses. The FEA results reveal that the SynRG with a slitted-rotor core, compared with the conventional SynRG with the same ratings and specifications, reduces the torque ripple by 24.51%, 29.72%, and 13.13% when feeding 8 A to a load with unity, lagging, and leading power factors, respectively. The FEA results also show that the induced voltage on no-load of the SynRG with a slitted-rotor core, compared with the conventional SynRG of the same ratings and specifications, increases by 10.77% when the auxiliary winding is fed by a capacitive excitation current of 6 A. Furthermore, the same results show that with a fixed excitation capacitive current of 6 A, the effect of armature reaction of the SynRG with a slitted-rotor core is demagnetizing when operating with load currents having a lagging power factor, and magnetizing when operating with load currents having unity and leading power factors. The same patterns have been observed in the experimental results for different excitation capacitance values. The Matlab/Simulink results show that the SynRG with a slitted-rotor core has a quicker dynamic response than the conventional SynRG. However, a well-designed pitch-control mechanism for the wind turbine is necessary to account for changes in wind speeds. Full article

This paper presents a circularly polarized (CP) microstrip antenna with dual circular polarization that is fed using a 3 dB 90° hybrid coupler to ensure dual-CP radiation. The proximity-coupled structure is used as a feeding technique to obtain a larger operational bandwidth that covers the standard LTE 43 of the 5G mid-band applications (3.6–3.8 GHz). The antenna was fabricated on an FR4 dielectric substrate with overall dimensions of 66.1 × 35 × 1.6 ${\mathrm{m}\mathrm{m}}^3$. A circular patch was formed as a radiating element, with four identical slits that were etched on the patch to guarantee the presence of CP radiation at the required mid-band of the 5G frequency range. The measured impedance bandwidth (BW) of this antenna was 10.6% (3.46–3.85 GHz), while the 3 dB axial ratio bandwidth (ARBW) was 8.2% along the range (3.50–3.80 GHz). The measured average gain was about 1.3 dBi along the antenna impedance bandwidth. Full article

This paper presents an innovative, compact, dual-element, implantable, ultra-wideband, circularly polarized multiple-input multiple-output (MIMO) antenna designed to operate within the 2.45 GHz industrial, scientific, and medical band, and both of its radiating units are circularly polarized antennas with polarization diversity. Specifically, antenna-1 exhibits left-handed circular polarization properties, while antenna-2 demonstrates right-handed circular polarization properties. The slots in the radiating patch and ground plane help the antenna achieve 690 MHz (2.14–2.83 GHz) ultra-wide bandwidth characteristics and circularly polarized characteristics. Additionally, a slit connecting two U-slots on the ground plane allows the antenna to achieve a wide effective circularly polarized axial ratio bandwidth of 400 MHz (2.23–2.63 GHz). The antenna is compact, with dimensions of 0.065 × 0.057 × 0.0042 λ₀³ (λ₀ represents the free-space wavelength corresponding to the lowest operating frequency). The proposed antenna system’s performance was evaluated with a seven-layer homogeneous human head model, a real human head model, and minced pork. This evaluation revealed that the antenna attained a peak gain of −24.1 dBi and an isolation level of 27.5 dB. Furthermore, the assessment included the antenna’s link margin (LM), key MIMO channel characteristics, and Specific Absorption Rate (SAR) metrics. The results indicate that the antenna performs exceptionally well. Full article

As mature oilfields enter the high-water-cut development stage, significant amounts of residual oil remain trapped underground. To enhance the effectiveness of tertiary oil recovery, it is crucial to understand the distribution and mobilization patterns of this residual oil. In this study, polydimethylsiloxane (PDMS) was used to create a microscopic oil displacement model, which was observed and recorded using a stereomicroscope. The experimental images were extracted, analyzed, and quantitatively evaluated, categorizing the microscopic residual oil in the high-water-cut sandstone reservoirs of Dagang Oilfield into cluster-like, pore surface film-like, corner-like, and slit-like types. Polymer–surfactant composite flooding (abbreviated as SP flooding) effectively mobilized 47.16% of cluster-like residual oil and 43.74% of pore surface film-like residual oil, with some mobilization of corner-like and slit-like residual oil as well. Building on SP flooding, dual-mobility flooding further increased the mobilization of cluster-like residual oil by 12.37% and pore surface film-like residual oil by 3.52%. With the same slug size, dual-mobility flooding can reduce development costs by 16.43%. Overall, dual-mobility flooding offers better development prospects. Full article

To meet the recent requirements of low-damage design, there is a growing need to retrofit building structures with a self-centering dissipation system. This system serves a dual purpose: reducing lateral drift and providing supplemental damping to enhance the seismic performance of buildings. This research focuses on assessing the efficiency in seismic response of structures retrofitted with an innovative self-centering hysteretic damper called a Self-Centering Disc Slit Damper (SC-DSD). The SC-DSD consists of four slit dampers and pre-compressed Belleville disc springs that provide self-centering and energy dissipation capabilities. This study investigates the SC-DSD’s working mechanism, theoretical formulation, and design method of SC-DSD dampers for their application in multistory building structures. A reinforced concrete (RC) structure is selected as a case study building that is retrofitted with SC-DSDs and conventional slit dampers. Subsequent seismic performance assessments are conducted using detailed pushover to evaluate the global behavior and capacity of the structure used for the design of the damping system. Nonlinear time history analysis is performed to simulate the dynamic behavior of the retrofitted structure under a variety of seismic excitations. This analysis considers a range of ground motion records to capture different intensity levels and frequency content. Comparing these analyses reveals that the designed SC-DSDs effectively reduce seismic responses while minimizing residual displacement up to 95% when contrasted with both the bare structure and the structure retrofitted with conventional steel slit dampers. Full article

In this paper, we demonstrate the first ever dual-period diffraction gratings that do not require electrical tuning to obtain the effect of period change. Our method allows for multiplication of the base period by proper modification of the subsequent slits of the grating. The proposed elements are fabricated by selective photopolymerization of a composite based on a nematic liquid crystal. The gratings are formed by polymer stabilization of a liquid crystal in different orientations of the molecules in selected grating slits to allow for period manipulation. The operating principle is based on changing the phase delay introduced by the slits depending on polarization direction of incident light with respect to the director in each type of slit, which allows to change the grating’s period. The proposed technique was successfully utilized to obtain diffraction gratings with either doubling or tripling of the period. Full article

This work proposes a multi-objective polydimethylsiloxane (PDMS) micro-optofluidic (MoF) device suitably designed and manufactured through a 3D-printed-based master–slave approach. It exploits optical detection techniques to characterize immiscible fluids or microparticles in suspension inside a compartment specifically designed at the core of the device referred to as the MoF chamber. In addition, we show our novel, fast, and cost-effective methodology, dual-slit particle signal velocimetry (DPSV), for fluids and microparticle velocity detection. Different from the standard state-of-the-art approaches, the methodology focuses on signal processing rather than image processing. This alternative has several advantages, including the ability to circumvent the requirement of complex and extensive setups and cost reduction. Additionally, its rapid processing speed allows for real-time sample manipulations in ongoing image-based analyses. For our specific design, optical signals have been detected from the micro-optics components placed in two slots designed ad hoc in the device. To show the devices’ multipurpose capabilities, the device has been tested with fluids of various colors and densities and the inclusion of synthetic microparticles. Additionally, several experiments have been conducted to prove the effectiveness of the DPSV approach in estimating microparticle velocities. A digital particle image velocimetry (DPIV)-based approach has been used as a baseline against which the outcomes of our methods have been evaluated. The combination of the suitability of the micro-optical components for integration, along with the MoF chamber device and the DPSV approach, demonstrates a proof of concept towards the challenge of real-time total-on-chip analysis. Full article

A dual-band UWB coplanar waveguide monopole antenna is presented in this paper. The antenna proposed in this paper consists of an FR4 substrate, two ground planes, and a rectangular patch. The size of the antenna proposed is 24 × 25 × 1 mm³ with a slit of length and width of 5.7 and 0.5 mm, respectively. We received two operating bands, a C- and Ku-band, with both Bi and Omni-directional radiation patterns. The bandwidth values of the first (3.65–7.49) GHz and second (11.5–13.4) GHz band of the proposed antenna are 3.9 GHz and 1.7 GHz, respectively. The proposed antenna operating at a frequency 5.8 GHz has a maximum bandwidth of 4.5 GHz and minimum bandwidth of 1.6 GHz. The characteristics of this antenna show that the antenna proposed in this paper is suitable for dual-band and UWB communication systems. We achieved a wide bandwidth by improving the ground plane. Full article

We have theoretically investigated the spatial-temporal dynamics of extraordinary optical transmission (EOT) through a two-slit plasmonic antenna under femtosecond laser dual-beam irradiation. The dynamic interference of the crossed femtosecond laser dual-beam with the transiently excited surface plasmon polariton waves are proposed to characterize the particular spatial-temporal evolutions of EOT. It is revealed that the dynamic EOT can be flexibly switched with tunable symmetry through the respective slit of a two-slit plasmonic antenna by manipulating the phase correlation of the crossed femtosecond laser dual-beam. This is explained as tunable interference dynamics by phase control of surface plasmon polariton waves, allowing the dynamic modulation of EOT at optimized oblique incidences of dual-beams. Furthermore, we have obtained the unobserved traits of symmetry-broken transient spectra of EOT from the respective up- and down-slit of the antenna under crossed femtosecond laser dual-beam irradiation. This study can provide fundamental insights into the ultrafast dynamics of EOT in two-slit plasmonic antennas, which can be helpful to advance a wide range of applications, such as ultrafast plasmonic switch, ultrahigh resolution imaging, the transient amplification of non-linear effects, etc. Full article

In this paper, new single/double-layer N-way Wilkinson power dividers (WPDs) were designed by using slow-wave structures such as narrow-slit-loaded and meandered transmission lines. For size reduction, the slit-loaded and meandered lines were used instead of the quarter-wavelength transmission lines of a conventional WPD. Based on the proposed approaches, two-, four-, and eight-way power dividers were designed, simulated, and fabricated. The fabricated 2-, 4-, and 8-way circuits were measured at the center frequencies of 2.03, 1.77, and 1.73 GHz, which are in excellent agreement with the predicted ones. The meandered transmission lines were also used to design WPD types with novel input/output port arrangements. For this purpose, two three-way WPDs were located on both sides of the same board to have different power-splitting ratios at different inputs and outputs in order to provide alternative solutions for antenna arrays. Furthermore, a five-way dual-layer WPD was introduced by locating the meandered transmission lines into two layers. The most important advantage of the proposed 3- and 5-way WPDs is that they allowed the input power at the next output port to be halved, in the order of P/2, P/4, P/8, P/16, and P/16. All the designed power-halving WPDs were simulated, fabricated, and successfully tested. Full article

This paper investigates the directional beaming of metallic subwavelength slits surrounded by dielectric gratings. The design of the structure for light beaming was formulated as an optimization problem for the far-field angular transmission. A vertical mode expansion method was developed to solve the diffraction problem, which was then integrated into a genetic algorithm and an active set method to obtain the optimal result. By using the proposed method for a two-slit structure, we demonstrate that both the single- and dual-beaming effects can be efficiently achieved. Moreover, the beaming directions can be flexibly adjusted and precisely controlled. Full article

This paper presents a novel design for and an experimental study of a dual-polarized quad-port MIMO antenna. The design achieves resonance at five distinct frequency bands with reduced mutual coupling. The design includes a single annular ring slot, four truncated rectangular corners, and a truncated aperture to improve resonance behavior. The design is then extended to a four-port MIMO antenna by including a ground-plane slit to enhance isolation between antenna elements at the center resonance band. The antenna achieves resonances at 5 distinct bands, ranging from 1.5 to 8.4 GHz, with significant mutual coupling reductions. The resonances of the quad-port pentaband MIMO antenna are achieved at 1.55 GHz (1.5–1.65 GHz), 2.5 GHz (2.4–2.7 GHz), 5.2 GHz (5–5.85), 7.3 GHz (7.1–7.4), and 8.15 GHz (7.9–8.4), with respective mutual coupling reductions of 27 dB, 37 dB, 21 dB, 29 dB, and 21 dB. Additionally, the 3 dB axial ratio bandwidth (ARBW) is observed at 6.5% (1.5–1.6 GHz) and 15% (2.4–2.7 GHz) in 2 distinct bands, and the envelope correlation coefficient and diversity gain are calculated within the specified band range. Experimental measurements of the prototype for the quad-port antenna are conducted, with excellent agreement found between the results and the simulations. Full article
