To enhance the performance of resonant DC–DC converters, particularly under low-load conditions, a semi-series-resonant dual-active-bridge (Semi-SRDAB) converter with a hybrid optimization strategy is proposed. This strategy aims to reduce conduction-related losses and is designed for applications requiring a wide voltage range. The proposed Semi-SRDAB converter comprises a full-bridge inverter on the primary side and a hybrid-output bridge rectifier on the secondary side. It adopts phase-shift modulation combined with frequency modulation for power control. The hybrid optimization strategy for the Semi-SRDAB converter is investigated, beginning with the deduction of resonant current minimization using phasor analysis. Based on these analysis results, zero reactive power operation and soft-switching operation are achieved for both buck and boost modes. Successful validation has been demonstrated through experimental testing on a 300 W laboratory prototype. Enhanced conversion performance is confirmed by comparing the results with those from previous works. Full article

In this paper, to achieve versatile, cost-effective charging for dual-motor EVs, a multi-functional integrated onboard charger is constructed using a dual-motor driving system. In the driving mode, a five-phase flux-switching permanent-magnet (FSPM) motor powers the front, while a three-phase FSPM motor drives the rear. While in the charging mode, different topologies are adopted for different application scenarios, such as the single-phase AC charging mode, the three-phase AC charging mode, and the DC charging mode. The five-phase FSPM motor and its inverters serve as a boost-based AC/DC converter in both single-phase and three-phase AC charging modes, transforming grid power to DC. In the DC charging mode, they are reconfigured to function as a buck converter. During the three-phase AC charging mode, the three-phase FSPM motor and its inverters take on the role of a rear-stage buck converter. They function to regulate the rectified DC voltage, ensuring it meets battery charging needs. The performance of the integrated charger is validated through simulation and experiment results. Full article

This paper is about the development and demonstration of a motor drive for e-transport applications based on an innovative hybrid Si-SiC dual switching frequency interleaved buck–boost Y-inverter and a single-rotor Halbach machine. In particular, the focus is the implementation of the required discontinuous inverter modulation scheme, input voltage feed-forward and motor currents feedback control loops, as well as over-voltage, over-current, and over-temperature protections, using an off-the-shelf commercial hardware platform enabling straightforward Simulink-environment programming of all parts, while ensuring the high switching frequency capability required by wide-band-gap semiconductors. Experimental results showed good inverter efficiency, transient dynamic response to load changes, input voltage regulation, and fully functional protection capability, validating the proposed approach as a powerful option for reducing system development time and cost. Full article

Bi-directional DC-AC converters are widely used in the field of electric vehicle-to-grid. However, the inductance of the grid-side interface filter is affected by the length of the grid connection and the power level, which presents nonlinear characteristics. This poses challenges for high-performance grid waveform control. In this paper, a modeling method for bi-directional DC-AC grid-connected converters based on type-II T-S fuzzy models is proposed, and the corresponding type-II T-S fuzzy control strategy is designed to address the parameter uncertainty and non-linearity issues. Simulation results show that type-II T-S fuzzy control offers superior control performance and better current waveform quality compared to type-I T-S fuzzy control under uncertainty parameter conditions. The effectiveness of the proposed strategy is further validated through a 1 kW prototype of a bi-directional DC-AC converter. Full article

Circulation of salty and fresh water through the electrodes of a deionization cell produces a voltage between the electrodes caused by the Capacitive Donnan Potential (CDP). The voltage so generated is very low (100 mV), but this work demonstrates that it is possible to develop a power converter suitable to inject this energy into the grid or into energy storage systems; this is a relevant aspect of this paper, for most works in the literature simply dissipate this energy over a resistor. To increase the input voltage, a stack of electrodes is connected in series. A bridgeless rectifier that uses a dual buck–boost converter to operate with both the positive and negative cycles is used to extract the energy from the cell. The topology chosen, which is operated as a current source, can work at extremely low voltage levels and provide power factor correction. After this stage, an H-bridge inverter can be included to inject the energy into the AC grid. The whole system implements a hysteresis control system using the current through the inductor of the power converter as control variable. This paper investigates the influence of such current on the efficiency of the total system. Full article

In this paper, we propose a design of a two-channel high-performance DC-DC converter that provides a positive voltage V_POS with a low ripple, and a negative voltage V_NEG with high power efficiency, for the purpose of enhancing power efficiency and output ripple under light loads of 100 mA or less for mobile active-matrix organic light-emitting diode (AMOLED) displays. The V_POS was designed as a boost converter using a novel input voltage variation reduction circuit (IVVRC), which rapidly changes the pulse width for input voltage fluctuations, using a feed-forward path. The V_NEG was designed as an inverting buck–boost converter based on the pulse width modulation–set time variable pulse width modulation (PWM–SPWM) dual-mode switching method to enhance power efficiency, especially under light loads, and to reduce the overhead of the circuit configuration using a voltage-controlled oscillator. In addition, an adaptive dead-time using voltage detection of switching node (ADTVS) circuit was proposed to enhance power efficiency, which detects the voltage of the switching node at every cycle, and keeps the dead-time constant irrespective of changes in driving conditions. The proposed converter was fabricated with a chip size of 1.67 mm × 2.44 mm, using a 0.35 μm BCD process. Measurement results showed that the power efficiency of our converter was 72.9%~90.4% at 5 mA–100 mA light load output current, which is 2.7%~5.8% higher than the output of the previous converter. Furthermore, the output voltage ripple of V_POS and V_NEG at 5 mA light load output current was 3.0 mV and 5.3 mV, respectively, which improved by 19% and 25% as compared to those of the previous converter, respectively. Full article

This paper presents the design and implementation of an on-grid microinverter control technique for managing active and reactive power based on a dq transformation. The system was implemented in a solar microinverter development kit (Texas Instruments—TMDSSOLARUINVKIT). This microinverter has two stages: DC-DC and DC-AC. The DC-DC stage contains an active clamp flyback converter, where the maximum power point tracking (MPPT) of the solar panel is obtained with a current-based incremental conductance algorithm. The DC-AC stage comprises a dual-buck inverter in which voltage-, current-, and phase-tracking control loops are implemented to control the active and reactive power. These techniques were simulated in MATLAB using the proposed mathematical model and experimentally validated in the solar development kit. The results show that the simulated model behaved similarly to the real system, and the control techniques presented good performance. The maximum power point (MPP) of the solar panel was monitored in the DC-DC stage using a current reference provided by the incremental conductance MPPT algorithm and was regulated by a 2P2Z control. The algorithm is robust against continuous changes in irradiance, as it quickly follows the ideal power and continually operates at a point close to the MPP. In addition, the active and reactive power control in the DC-AC stage enables the microinverter to supply the maximum active power. Moreover, the microinverter supplies reactive power according to a defined reference and within the established limits. The proposed mathematical model of the microinverter can be used to design new control techniques and other microinverter topologies. In addition, this active and reactive power-control technique can be implemented in low-power and low-cost microinverters to successfully maintain power quality in small microgrids. Full article

This paper aims to present a new structure of the parallel Z-source inverters (ZSIs) for dual-input single-phase grid-connected photovoltaic (PV) systems. The ZSI is a single-stage buck-boost converter that uses an inductor-capacitor network between the inverter bridge and the PV string and follows the maximum power point by applying the shoot-through vector. Therefore, a DC/DC converter is no longer needed to track the maximum power point, and the cost and complexity of the power conditioning system (PCS) are reduced. For controlling the proposed PCS, a cascade control structure is employed in this paper. The inner current loop injects the maximum active power with unity power factor sinusoidal current to the grid. The outer capacitor voltage loop is applied to control capacitors voltages in the Z-source networks. Additionally, an enhanced dual-string maximum power point tracking (eDS-MPPT) method is proposed to find MPPs with minimum burden competitional. The eDS-MPPT does not need the PVs voltages measurements compared to other MPPT methods. The simulation results confirm the accuracy of the performance of the system. Full article

A new circuit structure and control method for a high power interleaved dual-buck inverter are proposed. The proposed inverter consists of six switches, four diodes and two inductors, uses a dual-buck structure to eliminate zero-cross distortion, and operates in an interleaved mode to reduce the current stress of switch. To reduce the total harmonic distortion at low output power, the inverter is controlled using discontinuous-current-mode control combined with continuous-current-mode control. The experimental inverter had a power-conversion efficiency of 98.5% at output power = 1300 W and 98.3% at output power = 2 kW, when the inverter was operated at an input voltage of 400 V_DC, output voltage of 220 V_AC/60 Hz, and switching frequency of 20 kHz. The total harmonic distortion was < 0.66%, which demonstrates that the inverter is suitable for high-power dc-ac power conversion. Full article

In this paper, a high frequency, interleaved, dual-buck, bidirectional, grid-connected converter topology is proposed. Free from the straight-through and dead-time distortion issues, both higher switching frequency and power density can be achieved. Due to the interleaved technique, the current ripple and stress for inductors and other power devices can be effectively reduced. Moreover, a novel filter parameter design method is proposed. The method is optimized with smaller inductance, higher filtering performance, and better steady-state performance. For one thing, the performance requirements under the two states of inverter and rectifier are comprehensively considered. For another, the relationship between the performance indexes and the filter parameters is analyzed. However, the results show that the relationship between the performance indexes is contradictory. A set of optimization parameters were obtained by setting the priority of the filter performance index. The specific design process of the filter parameters is given in detail. In order to verify the rationality of the parameter design, a 5 kW prototype was built and tested. The total harmonic distortions (THDs) of the grid currents in the among grid-connected inverter, off-connected inverter, and rectifier states under full load were 2.7%, 1.2%, and 4.5%, respectively, and the power density reached 36 W/in³. Full article

This paper proposes a new three-switch single-phase Z-source inverter (ZSI) based on a CUK converter, which is named a CUK-based ZSI. This topology has characteristics of buck‒boost capability and dual grounding. In addition, the voltage gain of proposed inverter is higher than those of the single-phase quasi-Z-source and semi-Z-source inverters. Aside from that, a simple control method is presented to achieve the linear voltage gain. The operational principle of the proposed topology is described. Finally, a performance evaluation is carried out and the test results verify the effectiveness of the proposed solution. Full article

This paper proposes a synchronous reference frame (SRF) control strategy for a single-phase, three-level, dual-buck photovoltaic (PV) inverter. The concept of virtual d-q transformation is adapted to the current control of the inverter, and the repetitive controller is implemented in the SRF. With the proposed control strategy, the memory allocation quantity for the repetitive controller is decreased and the capability of the current reference tracking is maximized. Thus, the proposed method significantly reduces the total harmonic distortion (THD) of the output current in both the continuous conduction mode (CCM) and the discontinuous conduction mode (DCM). In addition, the distortion of the output current is mostly composed of odd harmonics. Odd harmonic expressed to the even harmonic in SRF can be calculated using Park’s transformation. Therefore, a repetitive controller can improve dynamics by considering only even harmonic components in SRF rather than including all harmonics. The simulation and the experimental results verify the effectiveness of the proposed control strategy. The proposed method not only reduces the THD of the output current in both the CCM operation and the DCM operation, but also improves the dynamics of the current controller. Full article

When medium- or high-voltage power conversion is preferred for renewable energy sources, multilevel power converters have received much of the interest in this area as methods for enhancing the conversion efficiency and cost effectiveness. In such cases, multilevel, multi-input multi-output (MIMO) configurations of DC-DC converters come to the scenario for integrating several sources together, especially considering the stringent regulatory needs and the requirement of multistage power conversion systems. Considering the above facts, a three-level dual input dual output (DIDO) buck-boost converter, as the simplest form of MIMO converter, is proposed in this paper for DC-link voltage regulation. The capability of this converter for cross regulating the DC-link voltage is analyzed in detail to support a three-level neutral point clamped inverter-based grid connection in the future. The cross-regulation capability is examined under a new type of pulse delay control (PDC) strategy and later compared with a three-level boost converter (TLBC). Compared to conventional boost converters, the high-voltage three-level buck boost converter (TLBBC) with PDC exhibits a wide controllability range and cross regulation capability. These enhanced features are extremely important for better regulating variable output renewable energy sources such as solar, wind, wave, marine current, etc. The simulation and experimental results are provided to validate the claim. Full article

A high frequency dual-buck full-bridge inverter for small power renewable energy applications is proposed in this paper. The implementation of the wide band gap SiC (Silicon Carbide) power device contributes to the high switching frequency of 400 kHz. This high frequency contributes to reduced converter volume as well as improved power density, which greatly strengthens its portability and application range. For the control strategy, a voltage-current dual loop controller is employed. A three-pole-three-zero (3P3Z) compensator is applied in the current loop in order to track the current reference without static error. A voltage loop two-pole two-zero (2P2Z) compensator is used to generate the current reference for stabilizing the DC bus voltage. Not only is the inner current loop analyzed in detail, which includes the modeling of the equivalent inductor-capacitor-inductor (LCL)-type inverter and the design of the 3P3Z compensator, but also the outer voltage loop is discussed, the model of which is established based on the energy balance. Furthermore, a feedback linearization method is adopted to simplify the duty cycle calculation and helps to accelerate the control speed. A second-order generalized integrator software phase lock loop (SOGI-SPLL) is employed to obtain the phase angle and to synchronize the inverter output current with the grid voltage. A parallel structure algorithm is conducted based on a dual-core microcontroller unit (MCU) for the first time to control the high frequency inverter. This approach avoids the contradiction between the high frequency operation and the limited computing capacity of the conventional single-core MCUs. The software structure, time-consuming distribution, and interactive communication method are analyzed in detailed. Finally, this paper verifies the feasibility of the theoretical analyses through simulation and experiments based on a 1 kW prototype. Full article

A high frequency dual-buck full-bridge inverter for small power renewable energy application is proposed in this paper. A switching frequency of 400 kHz is achieved with the adoption of the SiC power device. A two-pole two-zero (2P2Z) compensator is employed in the outer voltage loop to generate the current reference for inner current loop. A 3P3Z compensator is adopted in the inner current loop to track the current reference. A systematic way for calculating the losses of high frequency inverter is presented, and the losses of the components are thoroughly analyzed. The turn-on and turn-off procedures of the inverter are discussed in detail. The losses caused by high frequency are calculated accurately, and the loss distribution is established as well. The procedure of the loss analysis gives a practical example for calculating the loss of similar type inverters. Moreover, deviation between pulse width modulation (PWM) control signal and switching response in high frequency switching is thoroughly analyzed. The influence of deviation is verified by designed experiment. Hence, a compensation method is proposed in order to minimize the influence. The compensation effect is validated by experiment and simulation. Finally, a 1-kW prototype is built to verify the feasibility of the theoretical analyses. The grid-connected maximum output power experiment is completed at 1 kW with the efficiency of 96.1% and the total harmonic distortion (THD) of 1.8%. The comparison experiments of power loss between Si and SiC power devices are carried out. The experiment results confirm the loss calculation method to be valid. Full article
