Search Results (11)

Persistently and reliably harvesting wind energy to power intelligent online monitoring devices for transmission lines promotes the intelligent and sustainable development of the Internet of Things. Current small-scale wind-energy-harvesting devices, relying on a single energy conversion principle, face challenges such as low efficiency and poor performance at low wind speeds. This paper presents a coaxial rotating non-contact coupling transducer structure, and its optimization methods have been studied, which are based on electret electrostatic induction and magnetically actuated piezoelectric conversion. By analyzing the principles of alternating positive–negative unipolar electret components and constructing a finite element model, improved output capacity is demonstrated. The electric signals from electret components are more suitable for inferring the shaft and wind speeds compared to piezoelectric components. The piezoelectric components utilize frequency up-conversion theory to enhance output while addressing the low power density of the electrostatic components. Experimental results indicate that the proposed structure operates reliably at rotational speeds of 100–700 rpm, achieving a maximum output power of 6.742 mW. The output power of the electret electrostatic component’s electrodes nearly doubled, with the signal positively correlated to rotation speed. The optimized structure of the magnetically actuated piezoelectric component achieved a power increase of 11.51% at four excitations and 250 rpm. This study provides a new design approach for more durable and efficient small-scale wind-energy-harvesting devices, as well as for achieving integrated measurement and supply. Full article

An all-integrated on-chip electrochemical microcell (10 × 11 mm²) is developed using silicon technology. The potentiometric nitrate ion detection is based on the functionalization of the working microelectrode array with a polymer membrane in fluoropolysiloxane (FPSX) containing ionophore tetradodecylammoniumnitrate (TDDAN) and ionic additive potassium tetrakis[3,5-bis(trifuoromethyl)phenyl]borate (KTFPB) to form an all-solid-state ion selective electrode (ISE). The addition of an ion-to-electron transducing layer between the platinum working electrode and the polymer membrane helped to improve the sensor performances, especially the response time, the sensitivity, and the stability. Composites formed with two conductive polymers were compared: Polyethylenedioxythiophène (PEDOT) and Polypyrrole (PPy), doped with Poly(styrene sulfonate) or double-walled carbon nanotubes (DWCNTs). Full article

Low temperature measurement is crucial in deep space exploration. Surface acoustic wave (SAW) sensors can measure temperature wirelessly, making them ideal in extreme situations when wired sensors are not applicable. In this study, 128° YX LiNbO₃ was first introduced into low temperature measurements for its little creep or hysteresis in cryogenic environments and affordable price. The finite element method was utilized to raise the design efficiency and optimize the performance of SAW sensors by comparing the performance with different interdigital transducer (IDT) structure parameters, including the height of electrodes, pairs of IDTs, reflecting grid logarithm and acoustic aperture. Once the parameters were changed, a novel design of high-performance SAW temperature sensors based on 128° YX LiNbO₃ with double electrode transducers was obtained, of which the Q value could reach up to 5757.18, 4.2-times higher than originally reported. Low temperature tests were conducted, and the frequency responsiveness of SAW sensors was almost linear from −100 °C to 150 °C, which is in good agreement with the simulation results. All results demonstrate that double electrode transducers are considerably efficient for performance enhancement, especially for high-Q SAW sensors, and indicate that LiNbO₃ substrate can be a potential high-performance substitute for cryogenic temperature measurements. Full article

Solid-contact ion-selective electrodes (SC-ISEs) exhibit great potential in the detection of routine and portable ions which rely on solid-contact (SC) materials for the transduction of ions to electron signals. Carbon-based materials are state-of-the-art SC transducers due to their high electrical double-layer (EDL) capacitance and hydrophobicity. However, researchers have long searched for ways to enhance the interfacial capacitance in order to improve the potential stability. Herein, three representative carbon-based SC materials including nitrogen-doped mesoporous carbon (NMC), reduced graphene oxide (RGO), and carbon nanotubes (CNT) were compared. The results disclose that the NMC has the highest EDL capacitance owing to its mesopore structure and N-doping while maintaining high hydrophobicity so that no obvious water-layer effect was observed. The Ca²⁺-SC-ISEs based on the SC of NMC exhibited high potential stability compared with RGO and CNT. This work offers a guideline for the development of carbon-material-based SC-ISEs through mesoporous and N-doping engineering to improve the interfacial capacitance. The developed NMC-based solid-contact Ca²⁺-SC-ISE exhibited a Nernstian slope of 26.3 ± 3.1 mV dec⁻¹ ranging from 10 μM to 0.1 M with a detection limit of 3.2 μM. Finally, a practical application using NMC-based SC-ISEs was demonstrated through Ca²⁺ ion analysis in mineral water and soil leaching solutions. Full article

In this study, we propose tunable pH sensors based on the electric-double-layer transistor (EDLT) with time-dependent sensitivity characteristics. The EDLT is able to modulate the drain current by using the mobile ions inside the electrolytic gate dielectric. This property allows the implementation of a device with sensitivity characteristics that are simply adjusted according to the measurement time. An extended gate-type, ion-sensitive, field-effect transistor consisting of a chitosan/Ta₂O₅ hybrid dielectric EDLT transducer, and an SnO₂ sensing membrane, were fabricated to evaluate the sensing behavior at different buffer pH levels. As a result, we were able to achieve tunable sensitivity by only adjusting the measurement time by using a single EDLT and without additional gate electrodes. In addition, to demonstrate the unique sensing behavior of the time-dependent tunable pH sensors based on organic–inorganic hybrid EDLT, comparative sensors consisting of a normal FET with a SiO₂ gate dielectric were prepared. It was found that the proposed pH sensors exhibit repeatable and stable sensing operations with drain current deviations <1%. Therefore, pH sensors using a chitosan electrolytic EDLT are suitable for biosensor platforms, possessing tunable sensitivity and high-reliability characteristics. Full article

This paper presents the principle, design, fabrication, and characterization of Molecular Electronic Transducer (MET) dual-axis tilt sensors. The proposed sensor has a 3D-printed cylindrical channel inserted with four double-band electrodes and partially filled with a liquid electrolyte. The double-band electrodes were fabricated by wire winding with a ~0.1 mm anode-cathode distance under controlled tension. It allows the electrode to become any 3D coil rather than a 2D structure by microfabrication and exhibits good repeatability ($\pm 10\%$). The tilting changes the electrolyte level and electrode-electrolyte contact area, resulting in Faradaic current changes. The x-axis and the y-axis sensitivity reach 0.121 V/° and 0.154 V/°, respectively. Full article

Wearable sensors based on solid-contact ion-selective electrodes (SC-ISEs) are currently attracting intensive attention in monitoring human health conditions through real-time and non-invasive analysis of ions in biological fluids. SC-ISEs have gone through a revolution with improvements in potential stability and reproducibility. The introduction of new transducing materials, the understanding of theoretical potentiometric responses, and wearable applications greatly facilitate SC-ISEs. We review recent advances in SC-ISEs including the response mechanism (redox capacitance and electric-double-layer capacitance mechanisms) and crucial solid transducer materials (conducting polymers, carbon and other nanomaterials) and applications in wearable sensors. At the end of the review we illustrate the existing challenges and prospects for future SC-ISEs. We expect this review to provide readers with a general picture of SC-ISEs and appeal to further establishing protocols for evaluating SC-ISEs and accelerating commercial wearable sensors for clinical diagnosis and family practice. Full article

This work demonstrates a novel electrochemical biosensor for the detection of chloride ion levels in ultra-low volumes (1–3 microliters) of passively expressed human sweat. We present here a hydration monitor that the pediatric, geriatric, and other immune-compromised or physically inactive/sedentary population cohort can utilize, for whom the current methods of chloride quantification of active stimulation of sweat glands through iontophoresis or treadmill runs are unsuitable. In this work, non-faradaic electroanalysis using gold microelectrodes deposited on a flexible nanoporous substrate, for high nanoscale surface area to volume enhancement, was leveraged to operate in ultra-low sweat volumes of <3 µL eluted at natural rates. The specific chloride ionophore-based affinity of chloride ions resulted in the modulation of charge transfer within the electrical double layer at the electrode–sweat buffer interface, which was transduced using electrochemical impedance spectroscopy (EIS) and chronoamperometry (CA). Linear calibration dose responses with R-squared values of 0.9746 and 0.9403 for EIS and CA respectively were obtained for a dynamic range of 10–100 mM. The surface charge and the binding chemistry of the capture probe were studied using zeta potential studies and UV-Vis. The dynamic sweat chloride-tracking capability of the sensor was evaluated for a duration of 180 min. Studies were conducted to probe the efficacy of the developed sensor for passive ultra-low sweat chloride assessment on human subjects (n = 3). Full article

Solid-contact potentiometric ion-selective electrodes (SC-ISEs) for thallium determination have been designed using multiwall carbon nanotubes (MWCNTs) as the ion-to-electron transducer. Dispersed MWCNTs were drop-casted over a gold plate electrode. Two different crown ethers were used in the sensing membrane for the recognition of thallium (I). Sensorsbased on dibenzo-18-crown-6 (DB18C6) as a neutral carrier and NaTPB as an anionic additive exhibited a near Nernstian response of 57.3 mV/decade towards Tl⁺ ions over the activity range 4.5 × 10⁻⁶–7.0 × 10⁻⁴ M, with a limit of detection of 3.2 × 10⁻⁷ M. The time required to achieve 95% of the steadyequilibrium potential was <10 s. The complex formation constant (log β_ML) between dibenzo-18-crown-6 and thallium (I) (i.e., 5.99) was measured using the sandwich membrane technique. The potential response was pH independent over the range 3.0–9.5. The introduction of MWCNTs as an electron-ion-transducer layer between gold plate and the sensing membrane lead to a smaller membrane resistance and a large double layer capacitance, which was proven using impedance spectra and chronopotentiometry (i.e., 114.9 ± 12 kΩ, 52.1 ± 3.3 pF, 200 ± 13.2 kΩ, and 50 ± 4.2 µF). Additionally, reduction ofthe water layer between the sensing membrane and the underlying conductor wastested. Thus, it is clear that MWCNTs can be used as a transducing layer in SC-ISEs. The proposed sensor was introduced as an indicator electrode for potentiometric titration of single and ternary mixtures of I⁻, Br⁻, and S²⁻ anions. Full article

Capacitors made of interdigitated electrodes (IDEs) as a transducer platform for the sensing of volatile organic compounds (VOCs) have advantages due to their lower power operation and fabrication using standard micro-fabrication techniques. Integrating a micro-electromechanical system (MEMS), such as a microhotplate with IDE capacitor, further allows study of the temperature-dependent sensing response of VOCs. In this paper, the design, fabrication, and characterization of a low-power MEMS microhotplate with IDE capacitor to study the temperature-dependent sensing response to methanol using Zeolitic imidazolate framework (ZIF-8), a class of metal-organic framework (MOF), is presented. A Titanium nitride (TiN) microhotplate with aluminum IDEs suspended on a silicon nitride membrane is fabricated and characterized. The power consumption of the ZIF-8 MOF-coated device at an operating temperature of 50 ${}^{\circ }$ C is 4.5 mW and at 200 ${}^{\circ }$ C it is 26 mW. A calibration methodology for the effects of temperature of the isolation layer between the microhotplate electrodes and the capacitor IDEs is developed. The device coated with ZIF-8 MOF shows a response to methanol in the concentration range of 500 ppm to 7000 ppm. The detection limit of the sensor for methanol vapor at 20 ${}^{\circ }$ C is 100 ppm. In situ study of sensing properties of ZIF-8 MOF to methanol in the temperature range from 20 ${}^{\circ }$ C to 50 ${}^{\circ }$ C using the integrated microhotplate and IDE capacitor is presented. The kinetics of temperature-dependent adsorption and desorption of methanol by ZIF-8 MOF are fitted with double-exponential models. With the increase in temperature from 20 ${}^{\circ }$ C to 50 ${}^{\circ }$ C, the response time for sensing of methanol vapor concentration of 5000 ppm decreases by 28%, whereas the recovery time decreases by 70%. Full article

The damage caused by localized heavy rains has been increasing in recent years, but it is difficult to find ways to protect people and property through existing rainfall measuring devices. This study applied energy harvesting technology through water movement as a sensor technology to monitor instantaneous water bombing phenomenon such as guerrilla storm concentrated in a small area. Water motion active transducer (WMAT) is an energy harvesting device that uses an electric double layer formed when water and a specific polymer are in contact with each other. Transient electron transfer between electrodes formed under the polymer is a main cause of AC peak formation. Measuring the AC peak formed when a raindrop drops onto the surface of the sensor can be used to measure the number of raindrop drops per second. Full article
