To address the impact of environmental and equipment factors on signal identification in highway tunnel drainage pipeline blockage monitoring, this study aims to elucidate the influence patterns of pipeline flow rate, optical fiber deployment scheme, and fiber performance on blockage-induced acoustic signals. A full-scale concrete pipeline experimental platform was established. Data were acquired using a HIFI-DAS V2 sensing system. The time–frequency domain characteristics of acoustic signals under different flow rates (50 m³/h and 100 m³/h), fiber deployment schemes (inside the pipe, outside the pipe, and outside a soundproofing layer), and fiber materials (six typical types) were analyzed and compared. The degree of influence of each factor on signal amplitude and dominant frequency components was quantified. The experimental results indicate that: Compared to a flow rate of 50 m³/h, the amplitude characteristic value at the blockage channel exhibited a marked increase at 100 m³/h, accompanied by an increase in the number and amplitude of dominant frequency components. While the dominant frequency components of the acoustic signals were less stable across the three deployment schemes, the overall amplitude at the blockage channel was consistently higher than that at non-blockage channels. When the fiber was deployed farther from the fluid core (outside the soundproofing layer), the dominant frequencies essentially disappeared, with energy distributed in a broadband form. The peak amplitude and array energy of the sensitive vibration sensing fiber were 2 times and 3.6 times those of the worst-performing type, respectively. Furthermore, its physical properties are better suited to the tunnel environment, effectively enhancing signal acquisition stability and the signal-to-noise ratio. Comprehensive analysis demonstrates that deploying sensitive fibers inside the pipe is more conducive to the accurate identification of blockage events. Moreover, uniform dominant frequency components and threshold criteria are not recommended along the entire length of the drainage pipe. This research provides theoretical and experimental support for parameter optimization of DAS systems to achieve high-precision pipeline blockage monitoring in complex tunnel environments. Full article

With the rapid development of high-voltage DC (HVDC) power systems, accurate measurement of surface electrostatic potential on insulating components has become critical for electric field assessment and insulation reliability. This paper proposes an electrostatic potential sensor based on cantilever micro-vibration modulation, which employs piezoelectric actuators to drive high-frequency micro-vibration of cantilever-type shielding electrodes, converting the static electrostatic potential into an alternating induced charge signal. An electrostatic induction model is established to describe the sensing principle, and the influence of structural and operating parameters on sensitivity is analyzed. Multi-physics coupled simulations are conducted to optimize the cantilever geometry and modulation frequency, aiming to enhance modulation efficiency while maintaining a compact sensor structure. To validate the effectiveness of the proposed sensor, an electrostatic potential measurement platform for insulating components is constructed, obtaining response curves of the sensor at different potentials and establishing a compensation model for the working distance correction coefficient. The experimental results demonstrate that the sensor achieves a maximum measurement error of 0.92% and a linearity of 0.47% within the 1–10 kV range. Surface potential distribution measurements of a post insulator under DC voltage agreed well with simulation results, demonstrating the effectiveness and applicability of the proposed sensor for HVDC insulation monitoring. Full article

This work demonstrates the synthesis of ferromagnetic metallic cobalt nanoparticles embedded in a graphene framework through a graphene-assisted carbothermal reduction process. Cobalt oxide (Co₃O₄) was employed as the starting material, with graphene nanopowder functioning simultaneously as the reducing medium and structural scaffold. Thermal treatment at 850 °C under an argon atmosphere triggered the phase transformation. X-ray diffraction (XRD) confirmed the successful conversion of cobalt oxide into face-centered cubic (FCC) metallic cobalt. The graphene network not only accelerated the reduction reaction but also ensured the homogeneous distribution of cobalt nanoparticles within the matrix. Magnetic measurements using vibrating sample magnetometry (VSM) revealed a substantial improvement in ferromagnetic behavior: the graphene-mediated samples reached a saturation magnetization (M_s) of approximately 130 emu/g, compared to the nearly non-magnetic response of cobalt oxide annealed under the same conditions without graphene. Collectively, the structural, compositional, and magnetic results highlight graphene’s critical role in driving the formation of metallic cobalt nanoparticles with enhanced ferromagnetism, emphasizing their promise for use in magnetic storage, sensing, and spintronic applications. We anticipate that this study will inspire further research into the dual functionality of graphene, serving as both a reductive agent for metal oxides and a supportive matrix for nanoparticles, toward enhancing the structural integrity and functional properties of graphene-based metal nanocomposite materials. Full article

Distributed fiber-optic sensing (DFOS) with intentionally spaced mechanical fixity points was experimentally evaluated for the structural health monitoring (SHM) of reinforced concrete (RC) members. A full-scale four-point bending test was conducted on a 12 m RC beam (400 × 400 mm) instrumented with a single-mode DFOS cable incorporating internal anchors at 2 m intervals and bonded externally with structural epoxy. Brillouin time-domain analysis (BOTDA) provided distributed strain measurements at approximately 0.5 m spatial resolution, with all cables calibrated to ±15,000 µε. Under stepwise monotonic loading, the system captured smooth, repeatable strain baselines and clearly resolved localized tensile peaks associated with crack initiation and propagation. Long-gauge averages exhibited a near-linear load–strain response (R² ≈ 0.99) consistent with discrete foil and vibrating-wire strain gauges. Even after cracking, the DFOS signal remained continuous, while some discrete sensors showed saturation or scatter. Temperature compensation via a parallel fiber ensured thermally stable interpretation during load holds. The fixed-point configuration mitigated local debonding effects and yielded unbiased long-gauge strain data suitable for assessing serviceability and differential settlement. Overall, the results confirm the suitability of fixed-point DFOS as a durable, SHM-ready sensing approach for RC foundation elements and as a dense data source for emerging digital-twin frameworks. Full article

This study presents a methodology for determining the optimal placement of sensors along the height of buildings to minimize uncertainty in reconstructing structural response at non-instrumented floors. Recent advancements in sensing technology have expanded the application of sensor data in earthquake and structural engineering, including model validation, post-event damage assessment, and structural health monitoring. However, to lower the costs of sensor installation and maintenance—particularly at the regional scale—it is essential to strategically place sensors to maximize the value of the collected data. Because the optimal sensor configuration depends on the specific objectives of an instrumentation project, there is no universal solution to the sensor placement problem. In this study, we focus on identifying sensor locations that allow for accurate interpolation of structural responses at non-instrumented floors with minimal prediction uncertainty. This objective supports the primary goal of the California Strong Motion Instrumentation Program (CSMIP), which is to collect structural response data with the highest possible accuracy and the lowest uncertainty. The proposed method is limited to stationary excitations (e.g., ambient vibrations or distant earthquakes) and to buildings with uniform mass and stiffness distributions along their height. Under these assumptions, a Gaussian Process Regression (GPR) model is used to quantify response prediction uncertainty and minimize the total uncertainty across the building height by placing sensors at the most informative locations. The GPR model is based on a simple shear-flexural beam representation, which effectively approximates the building using very few parameters—parameters that can be estimated from limited building information. The proposed method is verified and validated using both simulated and real data. Finally, a table is proposed that can be used by strong motion networks to facilitate more quantitative decision-making regarding sensor placement. While assumptions used in this study may seem restrictive, they strike a practical balance between accuracy and simplicity for large-scale applications such as CSMIP. The extension of this work to non-stationary excitations and general building types by training the GPR model on recorded seismic data rather than random vibration theory is under development. Full article

In this paper, we investigate the physical mechanics of vibration wave detection in distributed acoustic sensing (DAS) systems with the aim of enhancing the interpretation of the quantitative wavefield. We investigate the nonlinear relationship of DAS gauge length and pulse width on the seismic wave response, and the result is explained by the trigonometric relationship of backscattered Rayleigh wave phases. We further demonstrate the influence of spiral winding on DAS performance and also build phase response models for P-waves and S-waves in helically wound cables. These models suggest that the winding angle controls the measurement interval spacing and the angle of wave incidence. Additionally, integration of structural reinforcement improves the amplitude response characteristics and SNR. The experimentally inspired results show, using simulations and field tests, that the same vibration sources can give helically wound cables with larger winding angles the largest phase amplitudes, which would substantially exceed that of straight cables. SNR increased significantly (approximately 10% to 30%). The efficacy of the method was also checked using experiments for different vibration amplitudes and frequencies. Such results provide evidence for the design and installation of fiber-optic cables for use in practical engineering applications involving safety monitoring. Full article

The transportation phase in off-site construction subjects prefabricated modules to road-induced vibrations, shocks, and handling loads that can degrade structural integrity. Existing monitoring approaches often rely on local data loggers, which not only lack real-time visibility but also fail to link structural responses to their precise spatial and temporal context. To address this gap, this study proposes a GPS-integrated Internet of Things (IoT) framework for real-time monitoring of prefabricated modules during transit. The system comprises distributed inertial sensing nodes wirelessly connected to a central gateway, which aggregates and transmits synchronized sensor and GPS data to a cloud platform for analysis and visualization. Field validation demonstrated stable multi-node data acquisition with sufficient battery life to support extended monitoring under LTE connectivity. The framework supports dual-stream analytics: (i) time- and frequency-domain assessment of structural exposure using peak acceleration, RMS, and FFT metrics, and (ii) causal inference of road events (e.g., potholes, bumps, sharp turns). Vertical acceleration emerged as the most responsive diagnostic channel for capturing road-induced excitations, while gyroscope-derived motion profiles distinguish between driver maneuvers and road irregularities. Through seamless integration of structural and geospatial data in a scalable, low-cost system, this framework enables actionable insights for route planning, condition-based inspection, and improved logistics management in modular construction. Full article

The phase-sensitive optical time-domain reflectometer (Φ-OTDR) system is a distributed optical fiber sensing technology capable of measuring weak vibration signals in real time. However, while the use of a narrow-linewidth laser source enhances the system’s sensitivity, the accompanying high coherence introduces an inherent drawback: fading noise. This phenomenon can lead to significant phase demodulation distortion, severely compromising the system’s reliability. Consequently, interference fading represents a fundamental challenge in Φ-OTDR systems. We propose an optimized density clustering algorithm, termed adaptive principal component analysis DBSCAN++ (AP-DBSCAN). The procedure begins by identifying fading regions based on the fading principle. Subsequently, AP-DBSCAN integrates the K-distance to adaptively determine parameters, and incorporates PCA technology and the DBSCAN++ algorithm to efficiently and accurately distinguish fading points within these regions. Finally, the compromised data points are reconstructed using a nearest-neighbor interpolation method. Experimental results demonstrate the superior performance of the proposed method over DBSCAN, FDBSCAN, and DBSCAN++. Our approach achieves adaptive determination of the eps and Minpts parameters, maintaining a high fading-point detection accuracy of 99.92% while significantly improving computational efficiency by 67.33% to 76.29%. Full article

Distributed acoustic sensing (DAS) systems enable real-time monitoring of physical events across extended areas using optical fiber that detects vibrations through changes in backscattered light patterns. In perimeter security applications, these systems must accurately distinguish between legitimate activities and potential security threats by analyzing complex spatio-temporal data patterns. However, the high dimensionality and noise content of raw DAS data presents significant challenges for effective feature extraction and event classification, particularly when computational efficiency is required for real-time deployment. Traditional approaches or current machine learning methods often struggle with the balance between information preservation and computational complexity. This study addresses the critical need for efficient and accurate feature extraction methods that can identify informative signal components while maintaining real-time processing capabilities in DAS-based security systems. Here we show that wavelet packet decomposition (WPD) combined with a cascaded machine learning approach achieves 98% classification accuracy while reducing computational load through intelligent channel selection and preliminary filtering. Our modified peak signal-to-noise ratio metric successfully identifies the most informative frequency bands, which we validate through comprehensive neural network experiments across all possible WPD channels. The integration of principal component analysis with logistic regression as a preprocessing filter eliminates a substantial portion of non-target events while maintaining high recall level, significantly improving upon methods that processed all available data. These findings establish WPD as a powerful preprocessing technique for distributed sensing applications, with immediate applications in critical infrastructure protection. The demonstrated gains in computational efficiency and accuracy improvements suggest broad applicability to other pattern recognition challenges in large-scale sensor networks, seismic monitoring, and structural health monitoring systems, where real-time processing of high-dimensional acoustic data is essential. Full article

With the increasing demand for safety monitoring of offshore engineering structures, traditional single-modality sensing and centralized data processing models face challenges such as insufficient real-time performance and weak anti-interference abilities in complex marine environments. This research proposes an intelligent monitoring system based on multimodal sensor fusion and edge computing, aiming to achieve high-precision real-time diagnosis of offshore structure damage. The research plans to construct multimodal sensors through sensors such as stress change sensors, vibration sensors, ultrasonic sensors, and fiber Bragg grating sensors. A distributed wireless sensor network will be adopted to realize the transmission of sensor data, reduce the complexity of wiring, and meet the requirements of high humidity and strong corrosion in the marine environment. At the edge computing layer, lightweight deep learning models (such as multi-branch Transformer) and D-S evidence theory fusion algorithms will be deployed to achieve real-time feature extraction of multi-source data and damage feature fusion, supporting the intelligent identification of typical damages such as cracks, corrosion, and deformation. Experiments will simulate the coupled working conditions of wave impact, seismic load, and corrosion to verify the real-time performance and accuracy of the system. The expected results can provide a low-latency and highly robust edge-intelligent solution for the health monitoring of offshore engineering structures and promote the deep integration of sensor networks and artificial intelligence in Industry 4.0 scenarios. Full article

The dual-pulse heterodyne demodulation distributed acoustic sensing (HD-DAS) system has superior performance but is fundamentally limited by the short sensing range, which poses a significant obstacle to its application in long-distance monitoring. This paper proposes and experimentally demonstrates a novel binary-tree structure DAS (BTS-DAS) aimed at overcoming this critical limitation. By physically decoupling the long-distance transmission fiber from the final sensing part, this structure effectively expands the system’s remote sensing capability without compromising the high pulse repetition rate for high-performance measurement. We identified modulation instability (MI), rather than stimulated Brillouin scattering (SBS), as the dominant nonlinear noise source in the extended fiber chain. Through careful power management, we established an optimal launch power window. The practical feasibility of the system was verified during on-site testing, where vibrations were successfully detected over a 10 km transmission link with sensing occurring in the 250 m sensing fiber segment, achieving a low background noise of −59.79 dB ref rad/$\sqrt{\mathrm{Hz}}$. This work presents a robust and scalable solution for long-range, high-performance acoustic sensing. Full article

Geohazards pose significant dangers to human safety, infrastructures, and the environment, highlighting the need for advanced monitoring techniques for early damage detection and structure management. The distributed optical fiber sensors (DFOS) are strain, temperature, and vibration monitoring tools characterized by minimal intrusiveness, accuracy, ease of deployment, and the ability to perform measurements with high spatial resolution. Although these sensors rely on well-established measurement techniques, available for over 40 years, their diffusion within monitoring and early warning systems is still limited, and there is a certain mistrust towards them. In this regard, based on several case studies, the implementation of DFOS for early warning of various geotechnical hazards, such as landslides, earthquakes and subsidence, is discussed, providing a comparative analysis of the typical advantages and limitations of the different systems. The results show that real-time monitoring systems based on well-established distributed fiber-optic sensing techniques are now mature enough to enable reliable and long-term geotechnical applications, identifying a market segment that is only minimally saturated by using other monitoring techniques. More challenging remains the application of the technique for vibration detection that still requires improved interrogation technologies and standardized practices before it can be used in large-scale, real-time early warning systems. Full article

Timely detection of leaks is essential for the safe and reliable operation of pressure vessels used in superconducting systems, aerospace, and medical equipment. To address the lack of efficient online leak detection methods for such vessels, this paper proposes a quasi-distributed fiber Bragg grating (FBG) sensing network combined with theoretical stress analysis to diagnose vessel conditions. We analyze the stress–strain distributions of vacuum vessels under varying pressures and examine stress concentration effects induced by small holes; these analyses guided the design and placement of quasi-distributed FBG sensors around the vacuum valve for online leakage monitoring. To improve measurement accuracy, we introduce a vibration correction algorithm that mitigates pump-induced vibration interference. Comparative tests under three leakage scenarios demonstrate that when leakage occurs during vacuum extraction, the proposed system can reliably detect the approximate leak location. The results indicate that combining an FBG sensing network with stress concentration analysis enables initial localization and assessment of leak severity, providing valuable support for the safe operation and rapid maintenance of vacuum pressure vessels. Full article

The failure to accurately identify abnormal vibrations in protected metro areas is a serious threat to the operational safety of metro tunnels and trains, and there is currently no suitable method for effectively improving the accuracy of abnormal vibration identification. To address this issue, an accurate method for identifying abnormal vibrations in a metro reserve based on spatially correlated dense measurement points is proposed. First, by arranging distributed optical fibers along the longitudinal length of a tunnel, dynamic strain vibration signals are extracted via phase-sensitive optical time-domain reflectometry analysis, and analysis of variance (ANOVA) and Pearson correlation analysis are used to jointly downscale the dynamic strain features. On this basis, a spatial correlation between the calculated values of the features of the target measurement points to be updated and its adjacent measurement points is constructed, and the spatial correlation credibility of the dynamic strain features between the dense measurement points and the target measurement points to be updated is calculated via quadratic function weighting and kernel density estimation methods. The weights are calculated, and the eigenvalues of the target measurement points are updated on the basis of the correlation credibility weights between the adjacent measurement points. Finally, a support vector machine (SVM) and back propagation (BP) identification model for the eigenvalues of the target measurement points are constructed to identify the dynamic strain eigenvalues of the abnormal vibrations in the underground tunnel. Numerical simulations and an experiment in an actual tunnel verify the effectiveness of the proposed method. Full article

Fiber-optic sensing systems based on a forward transmission interferometric structure can achieve high sensitivity and a wide frequency response over long distances. However, there are still shortcomings in its ability to position multi-point vibrations and detect low-frequency vibrations, which limits its usefulness. To address these challenges, we study the viability of merging long-range forward-transmission distributed vibration sensing (FTDVS) with high spatial resolution optical frequency-domain reflectometry (OFDR), forming the first reported hybrid distributed sensing method between these two methods. The probe light source is shared between the two sub-systems, which utilizes stable linear optical frequency sweeping facilitated by high-order sideband injection locking. As a result, this is a new approach for the FTDVS method, which conventionally uses fixed-frequency continuous light. The method of nearest neighbor signal replacement (NSR) is proposed to address the issue of discontinuity in phase demodulation under periodic external modulation. The experimental results demonstrate that the hybrid system can determine the position of vibration signals between 0 and 900 Hz within a sensing distance of 21 km. When the sensing distance is extended to 71 km, the FTDVS module can still function adequately for high-frequency vibration signals. This hybrid architecture offers a fresh approach to simultaneously achieving long-distance sensing and wide frequency response, making it suitable for the combined measurement of dynamic (e.g., gas leakage, pipeline excavation warning) and quasi-static (e.g., pipeline displacement) events in long-distance applications. Full article
