Search Results (62)

Focusing on the dielectric elastomer actuator (DEA), this paper proposes a backstepping implicit inverse adaptive control scheme with creep direct inverse compensation. Firstly, a novel fractional-order creep Krasnoselskii–Pokrovskii (FCKP) model is established, which effectively captures hysteresis behavior and creep dynamic characteristics. Significantly, this study pioneers the incorporation of the fractional-order method into a hysteresis-coupled creep model. Secondly, based on the FCKP model, the creep direct inverse compensation is developed to combine with the backstepping implicit inverse adaptive control scheme, where the implicit inverse algorithm avoids the construction of the direct inverse model to mitigate hysteresis. Finally, the proposed control scheme was validated on the DEA system control experimental platform. Under both single-frequency and composite-frequency conditions, it achieved mean absolute errors of 0.0035 and 0.0111, and root mean square errors of 0.0044 and 0.0133, respectively, demonstrating superior tracking performance compared to other control schemes. Full article

As a soft actuator for fish robots, an oblique cone dielectric elastomer actuator (DEA) module inspired by the structure of white muscles in fish was proposed in the authors’ previous study. However, a mathematical model of an oblique cone DEA was not established, and designing a drive module that took into account its driving characteristics and passivity for integration into a fish robot remained a challenge. The purpose of this paper is to develop a vertebrate fish robot using multiple oblique cone DEA modules to achieve fish-like bending capability. First, an oblique cone DEA module was modeled for the design of a fish robot. The relationships among bending angle, blocking torque, driving voltage, and design parameters were established and confirmed by comparing the calculated and experimental results. Based on the modeling results, we designed an oblique cone DEA module-connected vertebrate fish robot. Finally, the experimental results of the fabricated fish robot demonstrated that the model-based design enabled flexible body swinging and swimming through a multiple-module-connected vertebrate structure. Full article

With the ongoing journey of automation advancements and a trend towards miniaturization, the choice of actuator plays a crucial role. Over recent years, soft actuators have demonstrated their usefulness in various applications, especially where light weight and high strain are required. Dielectric elastomer actuators (DEAs) are a class of soft actuators that provide high-strain actuation possibilities in applications like biomedicine, logistics, or consumer electronics. A variety of work featuring DEAs for actuation has been carried out in recent years, but a single work detailing the design conception, fabrication, modeling and experimental validation is lacking, especially in the context of achieving high strains with the integration of multiple electrodes and their interaction. This work discusses these issues with an equibiaxial DEA, enabling optimized equibiaxial strain patterns due to full use of the available actuation area. The developed DEA can achieve an equibiaxial strain of 12.75% for actuation at 60 V μm⁻¹ over an active area of 7 cm² which is an improvement of 1.3 times compared to traditional dot actuators. These properties position the device as a promising alternative for various applications like cell cultures or microassembly and provide an advantage of optimized use of passive regions within the actuator. Full article

Optical imaging systems using varifocal lenses have been widely used in many applications over the past several decades, such as machine vision devices, consumer electronic products, and medical instruments. Traditional varifocal lenses often consist of multiple solid focal length refractive optical elements. The varifocal ability is obtained by dislocating these optical elements along the optical axis over specific distances using mechanical driving mechanisms. It makes the traditional optical varifocal imaging systems suffer from bulky dimensions, slow response speed, complicated configuration, and discrete magnifications. Adaptive varifocal lenses have been a better choice to address the aforementioned limitations of traditional varifocal lenses. Dielectric elastomer actuators (DEA), which can effectively respond to an electric field and result in shape deformation, have been used to develop various adaptive lenses. This paper aims to give a brief review of adaptive varifocal lenses based on DEA. First, this paper describes the basic physical mechanism of DEA. Second, this paper reviews adaptive varifocal liquid lenses based on DEA and introduces their material, structure, and fabrication process, focusing on their unique advantages, such as fast response speed and compactness. However, despite these merits, the adaptive varifocal liquid lens still has challenges in environment stability and liquid leakage. To address these challenges, adaptive varifocal soft solid lenses based on DEA have been proposed, which are also reviewed. In addition, other adaptive varifocal lenses, including metalens, Fresnel lens, microlens array, and Alvarez lens, are also presented. Finally, the prospects and challenges for the development of adaptive varifocal lenses based on DEA are discussed. Full article

In this study, we investigated the influence of an epoxy end-capped polypropylene oxide crosslinker (epoxy-PPO) on the formation of the crosslinked network structure, the stress–strain response, and the electro-mechanical actuation performance of a maleic anhydride functionalized liquid isoprene rubber (LIR). The crosslinker amount varied from 10 (C-LIR-10) to 50 (C-LIR-50) weight parts per hundred parts (phr) of LIR. The swelling test of the cured rubbers revealed that C-LIR-20 formed the densest crosslinked network with the lowest chloroform uptake value within this series. The crosslinked rubber became stiffer in tensile response upon increasing the epoxy-PPO amount from C-LIR-10 to C-LIR-20 and then softened at higher amounts. The SEM measurements were used to relate this composition-induced softening of the rubbers to the phase morphology evolution from nanoscale homogeneity in C-LIR-10 to microscale segregations of excess crosslinkers in C-LIR-50. The use of epoxy-PPO improved the dielectric constant value of LIR; however, the leakage current through the films also increased from 25 µA DC to 320 µA DC for LIR-30 and LIR-50, respectively, during DEA operation. The electro-mechanical actuation tests with circular actuators showed that the C-LIR-10 elastomer film demonstrated a radial strain of 1.7% on activation at an electric field strength of 17.5 V/µm. At higher crosslinker amounts, the close proximity of excess epoxy-PPO molecules caused leakage current across elastomer films thus diminishing the actuation strain of otherwise relatively softer elastomers with higher dielectric constant values. Full article

As an electrically driven artificial muscle, dielectric elastomer actuators (DEAs) are notable for their large deformation, fast response speed, and high energy density, showing significant potential in soft robots. The paper discusses the working principles of DEAs, focusing on their reversible deformation under electric fields and performance optimization through material and structural innovations. Key applications include soft grippers, locomotion robots (e.g., multilegged, crawling, swimming, and jumping/flying), humanoid robots, and wearable devices. The challenges associated with DEAs are also examined, including the actuation properties of DE material, material fatigue, viscoelastic effects, and environmental adaptability. Finally, modeling and control strategies to enhance DEA performance are introduced, with a perspective on future technological advancements in the field. Full article

Dielectric elastomer actuators (DEAs) are difficult to apply to flexible grippers due to their small deformation range and low output force. Hence, a DEA with a large bending deformation range and output force was designed, and a corresponding flexible gripper was developed to realize the function of grasping objects of different shapes. The relationship between the pre-stretch ratio and DEA deformation degree was tested by experiments. Based on the performance test results of the dielectric elastomer (DE), the bending deformation process of DEAs with different shapes was simulated by Finite Element Method (FEM) simulation. DEAs with different shapes were prepared through laser cutting and the relationship between the voltage and the bending angle, and the output force of the DEAs was measured. The result shows that under uniaxial stretching, the deformation of the DEA in the stretching direction gradually increases and decreases in the unstretched direction with the increase in the pre-stretch ratio. Under biaxial stretching, DEA deformation increases with the increase in the pre-stretch ratio. The shape of the DEA has a certain influence on the bending deformation range under the same conditions, and the elliptical DEA has a larger bending deformation range and higher output force compared with the rectangular DEA and the trapezium DEA. The elliptical DEA can produce a bending deformation of 40° and an output force of 37.2 mN at a voltage of 24 kV. The three-finger flexible gripper composed of an elliptical DEA can realize the grasping of a paper cup. Full article

Dielectric elastomer actuators (DEAs) are increasingly recognized for their potential in robotic applications due to their ability to undergo significant deformation when subjected to an electric field. However, they are often limited by their low output power, which can make their integration into dynamic systems like hopping robots particularly challenging. This research optimizes the performance by introducing a cone DEA with a novel type of semi-diamond preload mechanism. This type of preload mechanism can meet the requirements of a negative-stiffness preload and a light weight. According to the experiments, the DEA can provide 3.62 mW power and its mass is only about 17.5 g. In order to drive hopping robots based on a cone DEA, this research introduces an energy accumulation mechanism coupled with a constant-torque cam for a hopping robot. The hopping robot weighs approximately 30.3 g and stands 10 cm tall in its upright position. Its energy accumulation mechanism involves a gear and cam transmission system, which is the key to store and release energy efficiently. The primary components of this mechanism include a torsion spring that stores mechanical energy when twisted, a constant-torque actuation cam that ensures the consistent application of torque during the energy storage phase, and a conical DEA that acts as an actuator. When the conical DEA is activated, it pushes a one-way clutch to the rocker, rotating the gear and cam mechanism and subsequently twisting the torsion spring to store energy. Upon release, the stored energy in the torsion spring is rapidly converted into kinetic energy, propelling the robot into the air. The experiments reveal that the designed DEA can drive the hopping robot by using the energy storage mechanism. Its hopping height is related to the pre-compression angle of the torsion spring. The DEA can drive the rigid hopping mechanism, and the maximum hopping height of the robot is up to 2.5 times its height. DEA hopping robots have obvious advantages, such as easy control, quietness and safety. Full article

This review will examine the rapidly growing field of soft robotics, with a special emphasis on soft robotic actuators and their applications in bioengineering. Bioengineering has increasingly utilized soft robotics due to their mechanical adaptability and flexibility, with applications including drug delivery, assistive and wearable devices, artificial organs, and prosthetics. Soft robotic applications, as well as the responsive mechanisms employed in soft robotics, include electrical, magnetic, thermal, photo-responsive, and pressure-driven actuators. Special attention is given to hydraulically amplified self-healing electrostatic (HASEL) actuators due to their biomimetic properties and innovative combination of dielectric elastomer actuators (DEAs) and hydraulic actuators, which eliminates the limitations of each actuator while introducing capabilities such as self-healing. HASEL actuators combine the fast response and self-sensing features of DEAs, as well as the force generation and adaptability of hydraulic systems. Their self-healing ability from electrical damage not only makes HASELs a unique technology among others but also makes them promising for long-term bioengineering applications. A key contribution of this study is the comparative analysis of the soft actuators, presented in detailed tables. The performance of soft actuators is assessed against a common set of critical parameters, including specific power, strain, maximum actuation stress, energy efficiency, cycle life, and self-healing capabilities. This study has also identified some important research gaps and potential areas where soft robotics may still be developed in the future. Future research should focus on improvements in power supply design, long-term material durability, and enhanced energy efficiency. This review will serve as an intermediate reference for researchers and system designers, guiding the next generation of advancements in soft robotics within bioengineering. Full article

Dielectric elastomer actuators (DEAs) are emerging as promising candidates for various applications in robotics and optical devices due to their lightweight, miniaturization potential, high energy density, simple structure, and low power consumption. However, their effective actuation always demands sophisticated high-voltage driving circuits that are compact and responsive. DEAs need to be capable of generating intricate high-voltage waveforms or simultaneously controlling multiple quadrants with distinct high-voltage levels. This paper proposes a high-voltage power supply for DEAs, featuring a four-quadrant high-voltage driving circuit. The circuit is capable of independently generating high-voltage signals ranging from 100 V to 6000 V and producing arbitrary waveforms with adjustable frequencies. The independent operation of the quadrants without crosstalk showcases the system’s integration and potential for cross-disciplinary applications. Full article

Soft grippers, a rapidly growing subfield of soft robotics, utilize compliant and flexible materials capable of conforming to various shapes. This feature enables them to exert gentle yet, if required, strong gripping forces. In this study, we elaborate on the material selection and fabrication process of gripping fingers based on the dielectric elastomer actuation technique. We study the effects of mixing the silicone elastomer with a silicone thinner on the performance of the actuators. Inspired by nature, where the motion of end-effectors such as soft limbs or fingers is, in many cases, directed by a stiff skeleton, we utilize backbones for translating the planar actuation into a bending motion. Thus, the finger does not need any rigid frame or pre-stretch, as in many other DEA approaches. The idea and function of the backbone strategy are demonstrated by finite element method simulations with COMSOL Multiphysics^® 6.5. The paper describes the full methodology from material choice and characterization, design, and simulation to characterization to enable future developments based on our approach. Finally, we present the performance of these actuators in a gripper demonstrator setup. The developed actuators bend up to 68.3° against gravity, and the gripper fingers hold up to 10.3 g against gravity under an actuation voltage of 8 kV. Full article

Inspired by the fact that flying insects improve their power conversion efficiency through resonance, many soft robots driven by dielectric elastomer actuators (DEAs) have achieved optimal performance via first-order modal resonance. Besides first-order resonance, DEAs contribute to multiple innovative functions such as pumps that can make sounds when using multimodal resonances. This study presents the multimodal resonance of a rectangular planar DEA (RPDEA) with a central mass bias. Using a combination of experiments and finite element modeling (FEM), it was discerned that under a prestretch of 1.0 × 1.1, the first-, second-, and third-order resonances corresponded to vertical vibration, rotation along the long axis, and rotation along the short axis, respectively. In first-order resonance, superharmonic, harmonic, and subharmonic responses were activated, while only harmonic and subharmonic responses were observed in the second- and third-order resonances. Further investigations revealed that prestretching tended to inhibit third-order resonance but could elevate the resonance frequencies of the first and second orders. Conveniently, both the experimental and FEM results showed that the frequencies and amplitudes of the multimodal resonances could be tuned by adjusting the amplitudes of the excitation signals, referring to the direct current (DC) amplitude and alternating current (AC) amplitude, respectively. Moreover, instead of linear vibration, we found another novel approach that used rotation vibration to drive a robot with soft bristles via hopping locomotion, showcasing a higher speed compared to the first-order resonance in our robot. Full article

Dielectric elastomer actuators (DEAs) have gained significant attention due to their potential in soft robotics and adaptive structures. However, their performance is often limited by their in-plane strain distribution and limited mechanical stability. We introduce a novel design utilizing fiber reinforcement to address these challenges. The fiber reinforcement provides enhanced mechanical integrity and improved strain distribution, enabling efficient energy conversion and out-of-plane displacement. We discuss an analytical model and the fabrication process, including material selection, to realize fiber-reinforced DEAs. Numerical simulations and experimental results demonstrate the performance of the fiber-reinforced equibiaxial DEAs and characterize their displacement and force capabilities. Actuators with four and eight fibers are fabricated with 100 $\mathsf{\mu }$m and 200 $\mathsf{\mu }$m dielectric thicknesses. A maximal out-of-plane displacement of 500 $\mathsf{\mu }$m is reached, with a force of 0.18 N, showing promise for the development of haptic devices. Full article

A Dielectric Elastomer Actuator (DEA) consists of electrodes with a dielectric layer between them. By controlling the design of the electrodes, voltage, and frequency, the operating range and speed of the DEA can be adjusted. These DEAs find applications in biomimetic robots, artificial muscles, and similar fields. When voltage is applied to the DEA, the dielectric layer undergoes compression and expansion due to electrostatic forces, which can lead to electrical breakdown. This phenomenon is closely related to the performance and lifespan of the DEA. To enhance stability and improve dielectric properties, a DEA Reservoir layer is introduced. Here, stability refers to the ability of the DEA to perform its functions even as the applied voltage increases. The Reservoir layer delays electrical breakdown and enhances stability due to its enhanced thickness. The proposed DEA in this paper is composed of a Reservoir layer and electrode layer. The Reservoir layer is placed between the electrode layers and is independently configured, not subjected to applied voltage like the electrode layers. The performance of the DEA was evaluated by varying the number of polymer layers in the Reservoir and electrode designs. Introducing the Reservoir layer improved the dielectric properties of the DEA and delayed electrical breakdown. Increasing the dielectric constant through the DEA Reservoir can enhance output characteristics in response to electrical signals. This approach can be utilized in various applications in wearable devices, artificial muscles, and other fields. Full article

Loss of an upper limb exerts a negative influence on an individual’s ability to perform their activities of daily living (ADLs), reducing quality of life and self-esteem. A prosthesis capable of performing basic ADLs functions has the capability of restoring independence and autonomy to amputees. However, current technologies present in robotic prostheses are based on rigid actuators with several drawbacks, such as high weight and low compliance. Recent advances in robotics have allowed for the development of flexible actuators and artificial muscles to overcome the limitations of rigid actuators. Dielectric elastomer actuators (DEAs) consist of a thin elastomer membrane arranged between two compliant electrodes capable of changing dimensions when stimulated with an electrical potential difference. In this work, we present the design and testing of a finger prosthesis driven by two DEAs arranged as agonist–antagonist pairs as artificial muscles. The soft actuators are designed as fiber-constrained dielectric elastomers (FCDE), enabling displacement in just one direction as natural muscles. The finger prosthesis was designed and modeled to show bend movement using just one pair of DEAs and was made of PLA in an FDM 3D printer to be lightweight. The experimental results show great agreement with the proposed model and indicate that the proposed finger prosthesis is promising in overcoming the limitations of the current rigid based actuators. Full article
