In recent years, the exploration and utilization of geothermal energy have received growing attention as a sustainable alternative to conventional energy sources. Reliable, data-driven identification of geothermal reservoirs, particularly in crystalline basement terrains, is crucial for reducing exploration uncertainties and costs. In such geological settings, magnetic susceptibility, radioactive heat production, and seismic wave characteristics play a vital role in evaluating geothermal energy potential. Building on this foundation, our study integrates in situ and laboratory measurements, collected using advanced sensors from spatially diverse locations, with statistical and unsupervised artificial intelligence (AI) clustering models. This integrated framework improves the effectiveness and reliability of identifying clusters of potential geothermal sites. We applied this methodology to the migmatitic gneisses within the Simav Basin in western Türkiye. Among the statistical and AI-based models evaluated, Density-Based Spatial Clustering of Applications with Noise and Autoencoder-Based Deep Clustering identified the most promising and spatially confined subregions with high geothermal production potential. The potential geothermal sites identified by the AI models align closely with those identified by statistical models and show strong agreement with independent datasets, including existing drilling locations, thermal springs, and the distribution of major earthquake epicenters in the region. Full article

This study evaluates the potential of enhanced geothermal systems (EGSs) in Poland, focusing on formations composed by igneous rocks, such as crystalline rocks of the Karkonosze pluton and volcanic rocks of the Gorzów Block. A total of 57 rock samples, including granites and rhyolites from these formations, were analyzed for their thermal and geochemical properties to assess their suitability for EGS development. The results highlight the importance of thermal parameters, such as conductivity and diffusivity, in optimizing geothermal exploitation. The measurements reveal that Karkonosze granite exhibits high thermal diffusivity and conductivity, making it a prime candidate for heat extraction. Although the Gorzów Block rhyolites show slightly lower values, their high initial temperatures still promise long-term geothermal viability. Geochemical modelling indicates that mineral precipitation that causes permeability damage is unlikely in these reservoirs. Instead, minor increases in porosity due to mineral dissolution can reduce hydraulic resistance, potentially affecting the performance of the system. Full article

The thermal water deposit in Lądek-Zdrój (SW Poland) occurs in fractured reservoir rocks, and its hydrogeological regime is controlled by the features of the local geology and lithology of the hosting crystalline complexes, mainly impermeable high-grade metamorphosed mica schists and gneisses. The fractured thermal water aquifer is confined by a thrust fault-type aquitard that creates artesian pressure and, therefore, the water intakes and natural springs in Lądek Zdrój provide spontaneous outflow. Classical geothermometers yield an estimation of reservoir temperatures that ranges from 50 to 70 °C, with a maximum of 88 °C. The heat flux (HF) value of the Lądek-Zdrój region is 64 mW/m². The new borehole, LZT-1, is in the border zone of a local thermal anomaly with a geothermal degree of 25–27 m/°C. The estimated temperature at the bottom of the LZT-1 borehole, under thermal equilibrium conditions, ranges between 70 °C and 80 °C. A stream of heated waters from the deep system flows from the recharge areas, shaping the local geothermal anomaly and thus influencing the thermal conditions in the Lądek-Zdrój area. The activation of this water circulation system occurred in the Pleistocene. Full article

Over the past decades, considerable research has been conducted on extracting energy from superhot geothermal reservoirs, where temperatures are higher than at the critical point of water. A major challenge when operating wells under such conditions is managing scaling in an effective manner. In this study, the thermodynamics of the precipitation and scaling of crystalline NaCl (halite) under superhot conditions is explored using the ${\mathrm{H}}_2\mathrm{O}$–$\mathrm{NaCl}$ system as a proxy. Phase diagrams in pressure–enthalpy and pressure–entropy coordinates are used to illustrate how scaling occurs in idealized processes, such as the isenthalpic expansion of geothermal fluid to the wellhead or the isentropic power generation of a steam turbine. Particular emphasis is placed on explaining the non-trivial graphical composition of these phase diagrams in an accessible manner. A wellhead sample and an estimate of the downhole conditions are used as points of reference in the discussion of scaling. All thermodynamic properties, including the solubility of $\mathrm{NaCl}$ in water vapor, are calculated using a newly developed equation of state by the same authors as in this article. Full article

Whether from the near-surface or at great depths, geothermal energy aims to harness the heat of the Earth to produce energy. Herein, emphasis is put on geothermal reservoirs and their cap rock in crystalline rocks, in particular, the basements of sedimentary basins and volcanic islands in the context of subduction. This study is based on a case study of three examples from around the world. The aim of this paper is to show how the study of newly formed minerals can help the exploration of geothermal reservoirs. The key parameters to define are the temperature (maximum temperature reached formerly), fluid pathways, and the duration of geothermal events. To define these parameters, numerous methods are used, including optical and electronic microscopy, X-ray diffraction, microthermometry on fluid inclusions, chlorite geothermometry, and geochemistry analysis, including that of isotopes. The key minerals that are studied herein are phyllosilicates and, in particular, clay minerals, quartz, and carbonates. They are formed because of hydrothermal alterations in fracture networks. These minerals can have temperatures of up to 300 °C (and they can cool down to 50 °C), and sometimes, they allow for one to estimate the cooling rate (e.g., 150 °C/200 ka). The duration of a hydrothermal event (e.g., at least 63 Ma or 650 ka, depending on the site) can also be established based on phyllosilicates. Full article

Morocco has an important geothermal potential materialized by its several thermal springs which constitute an essential surface geothermal indicator. These springs are dispersed throughout the country and present in every major structural domain. However, a significant amount is concentrated in the northern and northeastern areas. Associated with the great hydrothermal system of eastern Morocco, the thermal spring of Goutitir emerges in the Meso-Cenozoic sedimentary formations located east of the Guercif Basin, composed of a mixture of clays, carbonates, and marls, covered in unconformity by Quaternary tabular molasses. The upflow of the thermal water is dependent of Alpine faults systems with N30 and N100 directions, which are probable reactivated Hercynian structures that facilitate its circulation to the surface. The Goutitir spring has been studied by an interdisciplinary approach to identify the origin of the thermal water, the rock–water interactions, and the reservoir temperatures, contributing to the establishment of the conceptual model of the associated hydrothermal system. This thermal water is of chloride-sodium type with a hyperthermal character (43–47 °C). The isotopic composition (δ¹⁸O = −8.7 to −8.35‰; δ²H = −58.6 to −54.3‰) indicates a meteoric origin and a recharging zone located at around 2000 m of altitude. The chemical composition allows to classify the water as chloride-sodium hydrochemical facies, stabilized at ~100 °C in crystalline basement rocks, which, according to seismic data, are located at ~3 km depth. The concentrations, patterns, and correlations of trace elements point out water–rock interaction processes between the deep water and basic magmatic rocks. The integration of the chemical and isotopic data and the surface geological context shows that the Goutitir water flows within a hydrothermal zone were basic to ultrabasic lamprophyres rich in gabbroic xenoliths outcrop, witnessing the existence, at depth, of basic plutons. Moreover, near the source, these veins are strongly altered and hydrothermalized, showing late recrystallization of centimetric-sized biotites. The chloride-sodium composition of this water may also be a testimony to the presence and reaction with the overlying Triassic saline and gypsiferous and Meso-Cenozoic mainly carbonated formations. Full article

As a result of negligible connected porosity—and thus, minimal matrix permeability—the fluid-transport characteristics of crystalline rocks are strongly influenced by the fractures at all scales. Understanding the flow behaviour of fractured rock under extreme stress and temperature conditions is essential for safe and effective deep geo-engineering applications, such as deep geothermal recovery, geological nuclear waste disposal, oil and gas extraction, geological storage and deep mining operations. Therefore, this study aims to investigate the flow characteristics of mechanically fractured Australian Strathbogie granite under a wide range of stress (confining pressures 1–80 MPa) and temperature conditions (20 °C to 350 °C). The study utilised a sophisticated high-temperature, high-pressure tri-axial setup capable of simulating extreme geological conditions, followed by a numerical simulation. According to the experimental results, a linear increment in the steady-state flow rate was observed, with increased injection pressure for the experimental conditions considered. Therefore, linear laminar Darcy flow was considered, and the fracture permeability was calculated using the cubic law. It was found that stress and temperature strongly depend on the flow of fluid through fractures. The steady-state flow rate decreased exponentially with the increase in normal stress, showcasing fracture shrinkage with an increment in effective stress. With regard to permeability through the fractures, increasing temperature was found to cause an initial reduction in fracture permeability due to an increased interlock effect (induced by thermal overclosure), followed by increments because of the thermally induced damage. Furthermore, the increasing temperature caused significant non-linear increments in the fluid flow rates due to the associated viscosity and density reduction in water. Considering the laboratory-scale flow-through exercises, a fully coupled numerical model that can predict hydro–thermo–mechanical variations in the reservoir rocks was developed using the COMSOL Multiphysics simulator. The developed model was calibrated, utilising the temperature- and pressure-dependent properties of granite rocks and fluid (water); was validated against the experimental results; and was used to predict the permeability, pressure development and strain of rock samples under extreme conditions, which were difficult to achieve in the laboratory. Full article

Fracture network is a crucial element to address in any model of the thermo-hydro-mechanical behaviour of a reservoir rock. This study aims to provide quantified datasets and a further understanding of the critical parameters of the fracture network pattern in crystalline rocks. In the Northern Upper Rhine Graben, such rock units are targeted for multiple energy applications, from deep geothermal heat extraction to heat storage. Eleven outcrops were investigated with a combined LiDAR and 2D profiles analysis to extract faults and fracture network geometrical parameters, including length distribution, orientation, connectivity, and topology. These properties are used to decipher the structural architecture and estimate the flow properties of crystalline units. Fracture networks show a multi-scale power-law behaviour for length distribution. Fracture topology and orientation are mainly driven by both fault networks and lithology. Fracture apertures and permeability tensors were then calculated for two application case studies, including the stress field effect on aperture. Obtained permeabilities are in the range of those observed in the sub-surface in currently exploited reservoirs. The dataset provided in this study is thus suitable to be implemented in the modelling during the exploration stage of industrial applications involving fractured crystalline reservoirs. Full article

Dolomite plays an important role in carbonate reservoirs. The topography in the study area creates conditions for reflux dolomitization. The northeastward paleogeomorphy during the deposition of the Yingshan Formation was favorable for reflux dolomitization. Furthermore, the petrological and geochemical evidence indicated that the formation of finely crystalline dolomites was penecontemporaneous to sedimentation. The content of powder crystal dolomites increases from grainstone, to packstone, to mudstone. Previous studies only analyzed the origin of dolomites based on traditional geological methods, but did not analyze the spatial influence of reflux dolomitization on the reservoir quality. In this study, the reflux dolomitization of platform carbonate sediments was evaluated using three-dimensional reactive transport models. The sensitivity of dolomitization to a range of intrinsic and extrinsic controls was also explored. The reflux dolomitization involves replacement dolomitization and over-dolomitization. The porosity change is the result of the abundance change of dolomite and anhydrite. The fluid flow pattern in the model is related to the injection rate and geothermal gradient. According to the spatial and temporal change of mineral, ionic concentration, and physical property, the reflux dolomitization could be divided into five stages. From the sensitivity analysis, high permeability promotes dolomitization only in the initial stage, while low permeability and high porosity means stronger dolomitization. Besides, the injection rate, reactive surface area (RSA), geothermal gradient, and brine salinity are all proportional to the dolomitization. Differently from porosity change, the permeability change is concentrated in the upper part of the numerical model. The location of “sweet spot” varies with the locations of change centers of porosity and permeability. In the stage-1 and 4 of dolomitzation, it overlaps with porosity and permeability growth centers. While in the stage-2, 3 and 5, it lies between the porosity and permeability growth/reduction centers. Full article

We have performed several sensitivity studies to assess the ability of the Full Wave Inversion method to detect, delineate and characterize faults in a crystalline geothermal reservoir from OVSP data. The distant goal is to apply the method to the Soultz-sous-Forêts site (France). Our approach consists of performing synthetic Full Wave 2D Inversion experiments using offset vertical seismic and comparing the estimated fields provided by the inversion, i.e., the estimated underground images, to the initial reference model including the fault target. We first tuned the inversion algorithmic parameters in order to adapt the FWI software, originally dedicated to a sedimentary context, to a crystalline context. In a second step, we studied the sensitivity of the FWI fault imaging results as a function of the acquisition geometry parameters, namely, the number of shots, the intershot distance, the maximum offset and also the antenna length and well deviation. From this study, we suggest rules to design the acquisition geometry in order to improve the fault detection, delineation and characterization. In a third step, we studied the sensitivity of the FWI fault imaging results as a function of the fault or the fault zone characteristics, namely, the fault dip, thickness and the contrast of physical parameters between the fault materials and the surrounding fresh rocks. We have shown that a fault with high dip, between 60 and 90° as thin as 10 m (i.e. lower than a tenth of the seismic wavelength of 120 m for Vp and 70 m for Vs) can be imaged by FWI, even in the presence of additive gaussian noise. In summary, for a crystalline geological context, and dealing with acceptable S/N ratio data, the FWI show a high potential for accurately detecting, delineating and characterizing the fault zones. Full article

For an accurate multiscale property modelling of fractured crystalline geothermal reservoirs, an enhanced characterisation of the geometrical features and variability of the fracture network properties is an essential prerequisite. Combining regional digital elevation model analysis and local outcrop investigation, the study comprises the characterisation of the fracture pattern of a crystalline reservoir analogue in the Northern Odenwald, with LiDAR and GIS structural interpretation. This approach provides insights into the 3D architecture of the fault and fracture network, its clustering, and its connectivity. Mapped discontinuities show a homogeneous length distribution, which follows a power law with a −2.03 scaling factor. The connectivity of the fracture network is heterogenous, due to a fault control at the hectometric scale. Clustering is marked by long sub-vertical fractures at the outcrop scale, and strongly enhance heterogeneity around weathered fracture and fault corridors. The multi-variable dataset created within this study can be used as input data for accurate discrete fracture networks and fluid-flow modelling of reservoirs of similar type. Full article

Clay minerals are the signature of hydrothermal alterations related to fluid circulation in volcanic and crystalline rocks. In the French part of the Upper Rhine Graben, in the deep-seated granites, illitic minerals (illite and I/S mixed layers (ml)) are typical products of the structurally-controlled argillic alteration in the Paleozoic granitic basement. In the new Illkirch geothermal well, GIL-1, drill-cuttings were studied with various petrographic methods to determine the characteristics of illite in paleo- and present-permeable zones, and to compare the alteration mineralogy with that of geothermal Soultz-sous-Forêts and Rittershoffen sites. Alteration petrography, crystal structure as well as the chemical composition of the illitic minerals and the altered bulk rocks were performed all along the well. This complete characterization, combined with geophysical logs and structural results, highlighted that the illitic minerals at Illkirch, Soultz-sous-Forêts, and Rittershoffen are composed of illite and illite-rich illite-smectite mixed layers (I/S ml) (<10% smectite). Two mineralogical assemblages were distinguished: chlorite + illite resulting from the propylitic alteration after the emplacement of the granitic basement under temperatures higher than 350 °C, and illite + I/S ml + carbonates + quartz resulting from the argillic alteration due to fluid circulation in the fractures at temperatures between 130 and 160 °C. Fracture zones are characterized by the occurrence of illitic minerals (illite and I/S ml), and specifically, by higher quantities of I/S ml in present-day permeable zones than in paleo-permeable zones. A conceptual model of the fracture zones at the interface between the overlying sedimentary rocks and the granitic basement is proposed. The present-day permeability distribution is controlled by the fault and fracture network, which consists of sealed zones and unsealed zones. Fluid convection in the URG implies paleo and present fluids circulating in both fractured sedimentary and crystalline reservoirs. Such circulations develop illitic minerals that could be considered as exploration guides for future geothermal sites in the URG. At Illkirch, the repartition of the present-permeable fracture zones (KFZs) in the GIL-1 well indicates that the moderately argillically altered granite distally situated from the Eschau fault is more permeable than the intensely argillically altered granite close to the Eschau fault. Full article

The Huailai area is rich in geothermal resources, but the formation mechanism of its deep heat source is still unclear. In this paper, based on 16 broadband magnetotelluric sounding points, the two-dimensional electrical structure of the crust and mantle in the Huailai area was obtained. Combined with deep seismic reflection and P-wave seismic tomography, the geophysical characteristics of deep heat sources and reservoirs in the Huailai area are described. The Huailai area is characterized by low resistivity and layered reflection above 2 km in depth, which shows the distribution of the Cenozoic sedimentary cover layer. The upper crust is characterized by high resistivity without an obvious reflector, corresponding to the crystalline basement of the basin, whose main lithology is Archean gneiss. There is a highly conductive and bright-spot-reflective structure under the basement, which extends to 100 km, indicating the upwelling of mantle-derived material. Combined with the results of helium isotope tracing, a magma-type geothermal model in the Huailai area is proposed. The upwelling mantle-derived magma material is enriched under the basement to form a heat source. The heat is transferred to the upper crust through heat conduction along the crystalline basement. Then, groundwater circulation brings deep heat to the surface, forming hydrothermal resources. Full article

Currently, water fracturing under deep geothermal conditions remains poorly understood because the reservoir rocks are usually high-strength crystalline rocks characterized by high temperatures. The aim of this study is to investigate the effects of rock properties, injection rates, and temperatures on hydraulic fracturing behavior and the induced crack characteristics through experimental investigations. A series of hydraulic fracturing experiments was conducted on two Indosinian granite types to investigate the differences in hydraulic fracturing behavior caused by rock properties. Among others, six samples were tested under a room-temperature condition at different injection rates from 1 to 30 mL/min to clarify the effect of the injection rate and three samples were tested under a high-temperature condition (150 °C) to simulate specific geothermal environments. The results indicated that granites with different rock properties have different injection rate thresholds. When the injection rate is below the threshold, the injection pressure finally reached a constant value without fracturing. For rocks with the same properties, the temperature effect can lead to a high injection rate threshold due to the occurrence of thermally-induced cracks. The number of acoustic emission events recorded during the room-temperature experiments increased linearly with increasing injection rate, while high-temperature tests increased sharply. The investigation results imply that a complex hydraulically-induced crack network is expected to be achieved in geothermal reservoirs by a high injection rate or high temperature differences (between injected fluid and rock). Additionally, the characteristics of the hydraulically-induced cracks were investigated by cutting through the sample blocks and measuring the residual pressure. The results indicated that the induced crack aperture can maintain a fluid conductivity of 0.1–0.8 mm/s at a closure pressure of 12 MPa. Full article
