Search Results (76)

This study systematically explores the synergistic effects of direct aging treatment (480 °C for 6 h) combined with cryogenic treatment (−196 °C for 8 h) on the mechanical properties and microstructural evolution of 18Ni300 maraging steel fabricated via selective laser melting (SLM). Three conditions were investigated: as-built, direct aging (AT6), and direct aging plus cryogenic treatment (AT6C8). Microstructural characterization was performed using optical microscopy (OM), scanning electron microscopy (SEM), transmission electron microscopy (TEM), and X-ray diffraction (XRD), while the mechanical properties were evaluated via microhardness and tensile testing. The results show that the AT6C8 sample achieved the highest microhardness (635 HV_0.5) and tensile strength (2180 MPa), significantly exceeding the as-built (311 HV_0.5, 1182 MPa) and AT6 (580 HV_0.5, 2012 MPa) samples. Cryogenic treatment induced a notable phase transformation from retained austenite (γ phase) to martensite (α phase), with the peak relative intensity ratio ranging from 1.42 (AT6) to 1.58 (AT6C8) in the XRD results. TEM observations revealed that cryogenic treatment refined lath martensite from 0.75 μm (AT6) to 0.24 μm (AT6C8) and transformed reversed austenite into thin linear structures at the martensite boundaries. The combination of direct aging and cryogenic treatment effectively enhances the mechanical properties of SLM-fabricated 18Ni300 maraging steel through martensite transformation, microstructural refinement, and increased dislocation density. This approach addresses the challenge of balancing strength improvement and residual stress relaxation. Full article

This investigation implemented an integrated aging–cryogenic thermal processing method for extruded Mg-8Gd-3Y-0.4Zr alloy to further improve its performance and broaden its scope of application, employing a characterization approach combining optical microscopy (OM), electron backscatter diffraction (EBSD), X-ray diffraction (XRD), and transmission electron microscopy (TEM). The comprehensive microstructure characterization was systematically correlated with mechanical property evolution to establish structure–property relationships. The results show that aging combined with cryogenic treatment significantly enhances the hardness and improves the microstructure of magnesium alloys. Specimens aged at 210 °C for 20 h followed by one-hour cryogenic treatment exhibited the highest average hardness (113.5 HV), representing a 11.2–25% improvement compared to those aged at lower temperatures. This enhancement can be attributed to the elevated aging temperature promoting substantial precipitation and subsequent growth of second phases such as Mg₃(Gd,Y), which benefit from sufficient thermal activation energy. The increased density and larger dimensions of these second phases contribute to enhanced hardness through elevated internal stress generation. However, their non-uniform distribution may induce localized stress concentration, consequently reducing hardness uniformity. Notably, specimens subjected solely to 210 °C aging for 20 h showed marginally lower hardness compared to their cryogenically treated counterparts, suggesting that although cryogenic treatment may refine grain structures and introduce dislocation defects to enhance hardness, its concurrent reduction in residual stresses might limit the overall improvement magnitude. Full article

TiO₂ nanoparticles are found as pigments in coatings and paints and are, therefore, released into the environment through runoff. To assess their environmental impact, comprehensive fate and ecotoxicity studies necessitate particles closely resembling those released into the environment. In response, we developed a method designed to isolate TiO₂ particles from commercial paints. Using six contrasting paints alongside a pure TiO₂ pigment, we evaluated two extraction methods in terms of recovery, purification rate, and preservation of both inorganic and organic particle coatings. The paints and extracts were characterized using cryogenic-TEM, ICP-OES, thermogravimetry, and infrared spectroscopy. In contrast to the alkaline-based extraction method, the extraction with acetic acid facilitated the retention of both inorganic and organic coatings and ensured good removal of organic polymers. Recovery rates exceeded 70% for all paints and extraction methods, yet the complete removal of SiO₂, when present, was not achieved. CaCO₃ removal was effective with both extraction methods. Our developed extraction method enables the isolation of TiO₂-particles similar to those aged within paints. However, we recommend using silicate-free paints when SiO₂ interference is of concern for the study design. Furthermore, this method could be interesting for pigment recycling, offering a gentler alternative to existing techniques which compromise particle coatings. Full article

A novel coupled processing method (PDCT) that associated deep cryogenic treatment (DCT) with a high pulsed magnetic field (PMT) was investigated to improve the performance of an as-cast TC4 aero-titanium alloy. Through XRD, SEM, TEM, EBSD, and a properties test, its microstructure and tensile properties and their relationship were investigated. The results show that in comparison with the untreated samples, in the PDCT alloys, the amount of nano-sized precipitates and dislocation density are increased, and this phenomenon is characterized by their combed dislocation morphology. The grain sizes are refined and rounded, and the deformed grains are enhanced, together with the enhancement of low-angle grain boundaries in grains and the transformation from the β phase to the α phase. The (112) crystal orientation is apparently strengthened. The tensile strength, elongation, and fracture energy of the optimized PDCT sample are 921.4 MPa, 7.6% and 5.47 × 10⁷ J/m³, which increased by 4.9%, 28.8% and 80.5% compared with the untreated sample, respectively. The tensile fracture exhibits rheological deformation along the phase boundaries. The strength–toughness mechanisms are mainly attributed to the texture, precipitation, dislocation and fine grain strengthening, which stem from the cold contraction and lattice distortion of DCT and the main magneto-plasticity effect of PMT, together with their coupling effects. Full article

The relationship between the stability of tool materials and their cutting performance is a critical technical challenge for the manufacturing industry, which is essential for selecting appropriate treatment processes to achieve superior treatment tool performance. In this paper, a standard cutting tool experiment was used to study the sharpness of the knife with different residual austenite content. The cutting edges of the knife were characterized by an optical microscope (OM), scanning electron microscope (SEM), electron back scattering diffraction (EBSD), and transmission electron microscope (TEM), to analyze the relationship between tool edge hardness and microstructure. The microstructure stability of the material was analyzed by a separated Hopkinson pressure bar (SHPB) experiment. The results show that the hardness and cutting performance of the knives are affected by the joint action of carbide and residual austenite, with an initial increase followed by decreases as the heat treatment quenching temperature increases. After the knife material is treated by cryogenic process, the hardness of the knife is increased by 3.89 HRC, the initial sharpness by 15.3%, and the sharpness and durability by 18.8%. The residual austenite in the knives was found to be unstable and easy to transformation during high-rate deformation processes. This study elucidates the effect of residual austenite content on the sharpness of the knives, providing a foundation for the reasonable control of residual austenite content in the actual production settings. Full article

Wormlike micelles (WLMs) with tunable viscoelastic characteristics have emerged as indispensable smart materials with a wide range of applications, which have garnered intense interest over the past few decades. However, quantitatively predicting the effect of various hydrotropes on the rheological behaviors of WLMs remains a challenge. In this article, micelles were formed in a mixture of 3-hexadecyloxy-2-hydroxypropyltrimethylammonium bromide (R₁₆HTAB) and aromatic hydrotropes (e.g., sodium benzoate, sodium cinnamate and their derivatives, respectively) in an aqueous solution. The phase behavior, viscoelasticity and thickening mechanism were systematically studied by macroscopic observation, rheological measurements, electrostatic potential analysis and cryogenic transmission electron microscopy (Cryo-TEM). Rheological measurements were used to probe the remarkable viscoelastic properties of micelles stemming from their lengthening and entanglement under the interaction between R₁₆HTAB and hydrotropes with structural variations. For an equimolar system of R₁₆HTAB and cosolute (40 mM), the relaxation time decreases in the following order: SpMB > SoHB > S4MS > SmMB > S5MS > SB > SmHB > SoMB > SpHB. These results allow us to predict the possible rules for the self-assembly of R₁₆HTAB and aromatic hydrotropes, which is conductive to directionally designing and synthesizing smart wormlike micelles. Full article

Residual stress induced by solution treatment in 6061 aluminum alloy can lead to workpiece deformation, or even premature failure. The efficiency of traditional heat treatment for relieving residual stress is relatively low. Therefore, this study introduces a novel cryogenic treatment technique to reduce residual stress. The optimal cryogenic process parameters were achieved by orthogonal experiments: cryogenic temperature of 113 K, holding time of 24 h, 1 cryogenic cycle, and a cooling rate of 3 K·min⁻¹, and the residual stress of aluminum alloy was measured by the blind hole method. The microstructural evolutions in 6061 aluminum alloy were tested by OM, SEM, and TEM. The results show that the introduction of cryogenic treatment can reduce residual stress in 6061 aluminum alloy by 64%, mainly due to the reduction of dislocations and the uniform distribution of β’’ phase. Full article

The field of energy storage and conversion materials has witnessed transformative advancements owing to the integration of advanced in situ characterization techniques. Among them, numerous real-time characterization techniques, especially in situ transmission electron microscopy (TEM)/scanning TEM (STEM) have tremendously increased the atomic-level understanding of the minute transition states in energy materials during electrochemical processes. Advanced forms of in situ/operando TEM and STEM microscopic techniques also provide incredible insights into material phenomena at the finest scale and aid to monitor phase transformations and degradation mechanisms in lithium-ion batteries. Notably, the solid–electrolyte interface (SEI) is one the most significant factors that associated with the performance of rechargeable batteries. The SEI critically controls the electrochemical reactions occur at the electrode–electrolyte interface. Intricate chemical reactions in energy materials interfaces can be effectively monitored using temperature-sensitive in situ STEM techniques, deciphering the reaction mechanisms prevailing in the degradation pathways of energy materials with nano- to micrometer-scale spatial resolution. Further, the advent of cryogenic (Cryo)-TEM has enhanced these studies by preserving the native state of sensitive materials. Cryo-TEM also allows the observation of metastable phases and reaction intermediates that are otherwise challenging to capture. Along with these sophisticated techniques, Focused ion beam (FIB) induction has also been instrumental in preparing site-specific cross-sectional samples, facilitating the high-resolution analysis of interfaces and layers within energy devices. The holistic integration of these advanced characterization techniques provides a comprehensive understanding of the dynamic changes in energy materials. This review highlights the recent progress in employing state-of-the-art characterization techniques such as in situ TEM, STEM, Cryo-TEM, and FIB for detailed investigation into the structural and chemical dynamics of energy storage and conversion materials. Full article

The purpose of this study was to evaluate the properties and pharmacokinetics of liposomal vitamin C in powder form obtained by a method devoid of organic solvents. The powder and liposome morphology were analyzed using scanning electron microscopy (SEM) and cryogenic transmission electron microscopy (cryo-TEM), respectively. Additionally, the carrier particle size, size distribution (STEP-Technology^®; L.U.M. GmbH, Berlin, Germany), and zeta potential value were determined. The pharmacokinetic parameters of liposomal and non-liposomal vitamin C (AUC, C_max, C_10h, and C_24h) were compared in a randomized, single-dose, double-blind, cross-over trial (ClinicalTrials.gov ID: NCT05843617) involving healthy adult volunteers (n = 10, 1000 mg dose). The process of spray drying used to transform liquid suspensions of the liposomes into powder form did not adversely affect the quality of the carrier particles obtained. Compared to non-encapsulated vitamin C, oral administration of the liposomal formulation resulted in significantly better absorption of ascorbic acid into the bloodstream, which equated to a higher bioavailability of the liposomal product (30% increase in AUC, p < 0.05). The duration of elevated vitamin C blood levels was also longer (C_24h increase of 30%, p < 0.05). Although the results obtained are promising and suggest higher bioavailability for the liposomal form of vitamin C, the limited sample size necessitates further research with a larger cohort to confirm these findings. Full article

This study investigates the impact of cryogenic treatment duration on the mechanical properties and microstructural evolution of 6082 aluminum alloy subjected to subsequent artificial aging. Tensile tests were conducted using an electronic universal testing machine, and the microstructure was characterized by employing optical microscopy (OM), scanning electron microscopy (SEM), and transmission electron microscopy (TEM). The results indicate that both the tensile strength and elongation of the alloy first increase and then decrease with the extension of cryogenic treatment duration. The alloy treated with 12 h of cryogenic treatment followed by artificial aging at 180 °C for 8 h achieved a peak strength of 390 MPa. Meanwhile, the alloy treated with 8 h of cryogenic treatment and the same artificial aging process reached a maximum elongation of 13%. All specimens of 6082 aluminum alloy subjected to cryogenic and aging treatments exhibited ductile fracture under room temperature tensile conditions. The size of dimples at the fracture surface first increased and then decreased with increasing cryogenic treatment duration, indicating a transition from deeper to shallower dimples. The cryogenic treatment did not significantly affect the grain size of the alloy, which remained approximately 230 µm on average. Cryogenic treatment facilitated the precipitation of fine, densely distributed precipitates, enhancing the pinning effect of dislocations and thus improving the tensile strength. Additionally, cryogenic treatment increased the dislocation density and promoted the formation of subgrains, while the grain boundary precipitates transitioned from a continuous to a discontinuous distribution, all of which contribute to the enhancement of the plasticity. Full article

Sputtering of silicon in a He magnetron discharge (MS) has been reported as a bottom-up procedure to obtain He-charged silicon films (i.e., He nanobubbles encapsulated in a silicon matrix). The incorporation of heavier noble gases is demonstrated in this work with a synergistic effect, producing increased Ne and Ar incorporations when using He–Ne and He–Ar gas mixtures in the MS process. Microstructural and chemical characterizations are reported using ion beam analysis (IBA) and scanning and transmission electron microscopies (SEM and TEM). In addition to gas incorporation, He promotes the formation of larger nanobubbles. In the case of Ne, high-resolution X-ray photoelectron and absorption spectroscopies (XPS and XAS) are reported, with remarkable dependence of the Ne 1s photoemission and the Ne K-edge absorption on the nanobubble’s size and composition. The gas (He, Ne and Ar)-charged thin films are proposed as “solid” targets for the characterization of spectroscopic properties of noble gases in a confined state without the need for cryogenics or high-pressure anvils devices. Also, their use as targets for nuclear reaction studies is foreseen. Full article

In this work, the effects of cold rolling (CR) and cold rolling–cryogenic treatment (CR–CT) on the microstructure and mechanical properties of Fe–32Ni alloy were studied via optical microscopy methods, OM, SEM, XRD, TEM, tensile strength and hardness tester, and tensile testing. The results reveal the grain refinement in the alloy after rolling deformation. When the deformation is higher than 85%, the polygonal austenite grains become layered, and a small amount of martensite forms. Because of the inhibitory effect of cold-rolling deformation before cryogenic treatment on martensitic transformation, the amount of martensite form phase after cryogenic treatment decreases with the increase of deformation. The hardness and strength of the sample, independent of whether the cryogenic treatment is performed, increase with the increase of deformation degree. Under the same deformation rate, the hardness of the CR–CT sample is higher than that of the CR sample, which is related to the hard martensite phase with high dislocation density obtained during cryogenic treatment. The strain hardening behavior of the sample is greatly affected by the deformation degree. With the increase of true strain, the work hardening exponent of CR and CR–CT samples undergoing severe plastic deformation is lower than that at small deformation degree and low dislocation density, which is attributed to the earlier entanglement of high dislocations in CR and CR–CT samples with large deformation degrees. Full article

The CoCrNi-based medium-entropy alloys (MEA) have been extensively investigated due to their exceptional mechanical properties at both room and cryogenic temperatures. To investigate the hot deformation behavior and the recrystallization mechanism of the CoCr_0.4NiSi_0.3 medium-entropy alloy, a series of deformation tests was conducted using the MMS-100 thermal simulation tester, with deformation conditions of 0.001–1 s⁻¹/850–1150 °C. During the hot deformation process, the flow stress initially increases up to its peak value before gradually decreasing towards a steady state level. Higher flow stress levels are observed with increasing strain rate and decreasing deformation temperature. The estimated activation energy for hot deformation of this alloy is approximately 423.6602 kJ/mol. The Arrhenius-type constitutive equation is utilized to establish a modified model while incorporating power dissipation theory and the instability criterion of a dynamic material model to construct power dissipation maps and instability maps. By superimposing these maps, hot processing maps with strains of 0.4, 0.5, and 0.7 are derived. In this investigation, it is observed that regions of instability exclusively occur when the true strain exceeds 0.4. These regions of instability on the hot processing map align well with experimental findings. The suitable range of parameters for hot-working decreases as the true strain increases. The microstructure was analyzed using electron backscatter diffraction and transmission electron microscopy (TEM) techniques. The volume fraction of dynamic recrystallization (DRX) decreases with increasing strain rate but diminishes with rising temperature. The TEM characterization elucidated the mechanism of DRX in this MEA. The presence of the long-period stacking ordered (LPSO) phase was observed in both the face-centered cubic matrix and hexagonal close-packed recrystallized grains under different deformation conditions. The LPSO phase originates from the matrix at a low strain rate, whereas it is generated during recrystallization at a high strain rate. The observed increase in flow stress of the as-cast MEA is primarily attributed to the synergistic effects arising from the interaction of the dislocation with twins and the second phase. The onset of instability is effectively suppressed within a limited range through the formation of coherent second phases such as L1₂, LPSO, and superlattice structures resulting from phase transitions. These second phases serve as nucleation sites for recrystallization and contribute to the strengthening of dispersion. Furthermore, their interaction with dislocations and twins significantly influences both flow stress behavior and recrystallization kinetics under hot deformation. These findings not only deepen our understanding of the underlying deformation mechanisms governing MEA but also offer valuable insights for designing CoCrNi-based alloys with improved mechanical properties at elevated temperatures. Full article

In this study, the effect of finish rolling temperature on the critical crack tip opening displacement (CTOD) of typical 500 MPa grade weathering steel was elucidated. The microstructures were observed via optical microscope (OM), scanning electron microscope (SEM), transmission electron microscope (TEM), and electron back-scattered diffraction (EBSD). The cryogenic fracture toughness and microstructures of steels were analyzed at different finish rolling temperatures (780–840 °C). The results show that a mixed microstructure, i.e., granular bainitic ferrite (GBF), polygonal ferrite (PF), and martensite/austenite (M/A), constituent was formed in each sample. With the decrease of the finish rolling temperature, the GBF content decreased, PF content increased, and the high angle grain boundary (HAGB) number fraction of the matrix increased. Furthermore, the fraction of M/A constituents was increased with reduced average size. The value of CTOD increased significantly from 0.28 to 1.12 mm as the finish rolling temperature decreased from 840 to 780 °C. Both the decrease of M/A constituents and the increase of HAGB increased the cryogenic (−40 °C) fracture toughness of the typical 500 MPa grade weathering steel. Full article

Photodetectors that can operate over a wide range of temperatures, from cryogenic to elevated temperatures, are crucial for a variety of modern scientific fields, including aerospace, high-energy science, and astro-particle science. In this study, we investigate the temperature-dependent photodetection properties of titanium trisulfide (TiS₃)- in order to develop high-performance photodetectors that can operate across a wide range of temperatures (77 K–543 K). We fabricate a solid-state photodetector using the dielectrophoresis technique, which demonstrates a quick response (response/recovery time ~0.093 s) and high performance over a wide range of temperatures. Specifically, the photodetector exhibits a very high photocurrent (6.95 × 10⁻⁵ A), photoresponsivity (1.624 × 10⁸ A/W), quantum efficiency (3.3 × 10⁸ A/W·nm), and detectivity (4.328 × 10¹⁵ Jones) for a 617 nm wavelength of light with a very weak intensity (~1.0 × 10⁻⁵ W/cm²). The developed photodetector also shows a very high device ON/OFF ratio (~32). Prior to fabrication, the TiS₃ nanoribbons were synthesized using the chemical vapor technique and characterized according to their morphology, structure, stability, and electronic and optoelectronic properties; this was performed using scanning electron microscopy (SEM), transmission electron microscopy (TEM), Raman spectroscopy, X-ray diffraction (XRD), thermogravimetric analysis (TGA), and a UV–Visible–NIR spectrophotometer. We anticipate that this novel solid-state photodetector will have broad applications in modern optoelectronic devices. Full article
