The DIGIT experiment was launched at the Tournemire Underground Research Laboratory (URL) with the aim of determining the effects of temperature on the transfer of tracers mimicking the most mobile radionuclides in the Toarcian clay rock. The properties of this rock are similar to those of the host rocks being considered for a future deep geological repository for high-level radioactive waste (HLW). The experiment involves the monitoring of the interaction between a test water doped with stable halides and deuterium at constant concentration, and the porewater of the Toarcian clay rock under constant ambient conditions, as well as at higher temperature induced by artificial heating. This experiment seeks to partially address questions regarding the potential spread of contaminants during the thermal phase of HL waste packages. Specifically, the in situ experiment aims to evaluate the role of scale effects, thermodiffusion, a process that combines Fick’s law, the Soret effect, and convection in the transfer of radionuclides. This paper is the second part of a companion paper dedicated to predictive calculations and the installation of the experimental device. It presents the main experimental and modeling results obtained since the beginning of the installation and after 20 months of heat at 70 °C. The test was carried out in five phases, finishing with a sampling campaign: a phase 0 called “initial conditions”, followed by a pure diffusion phase (5 months), then three phases in a heated period lasting 1 year and 8 months. In total, 47 rock cores were analyzed, with approximately 170 samples tested by four diffusion methods (radial, outgoing, through and in vapor-phase) to determine the tracer concentrations in the porewater, their water content and their diffusive transport parameters. The results show a decrease in tracer concentrations with distance from the test zone, in the directions parallel and perpendicular to the stratification. The anisotropy of the medium results in greater migration in the direction parallel to the stratification. Thermal properties also confirm anisotropy with a higher thermal conductivity in the direction parallel to the stratification. Finally, an activation energy of 22.9 ± 1.7 kJ·mol
−1 could be proposed by NMR for deuterium, indicating diffusion behavior following an Arrhenius law between 30 and 70 °C. The experimental data allowed for the calibration of a 2D axisymmetric numerical model using the commercial finite element software COMSOL Multiphysics
®. The Fick’s law corrected by an Arrhenius law best reproduces the penetration of deuterium and anions. The Soret effect, integrated into certain scenarios, is only significant for anions’ migration, using a fitted Soret coefficient of 0.1 K
−1, as proposed in the literature for the Callovo-Oxfordian, the host rock of the Cigéo project in the east of France. The calibration of the simulated data with the experimental data allowed for the characterization of damaged and/or disturbed zones evolving over time. Simulations over 150 years, the duration of the thermal maximum for HLW packages, show that advection—modeled by Darcy’s law—would have a negligible role in this context due to the low permeability of the upper Toarcian. In conclusion, the DIGIT test showed that, for the Upper Toarcian clay rocks at the Tournemire URL in France, diffusion, corrected for the effect of temperature, is the mechanism that characterizes the transport of radionuclide analogues. The study showed that thermodiffusion has a limited influence on deuterium migration but remains significant for anions in the case of a coupling between temperature correction and thermodiffusion. The test also highlighted the impact of temperature on the spatiotemporal development of a damaged and/or disturbed zone. These new and relevant results in the field will need to be confirmed later through additional experiments.
