Search Results (23)

To enhance the operational stability of distribution networks during peak periods, this paper proposes a multi-timescale operational method considering load forecasting impacts. Firstly, the Crested Porcupine Optimizer (CPO) is employed to optimize the hyperparameters of long short-term memory (LSTM) networks for an accurate prediction of the next-day load curves. Building on this foundation, a multi-timescale optimization strategy is developed: During the day-ahead operation phase, a conservation voltage reduction (CVR)-based regulation plan is formulated to coordinate the control of on-load tap changers (OLTCs) and distributed resources, alleviating peak-shaving pressure on the upstream grid. In the intraday optimization phase, real-time adjustments of OLTC tap positions are implemented to address potential voltage violations, accompanied by an electrical distance-based control strategy for flexible adjustable resources, enabling rapid voltage recovery and enhancing system stability and robustness. Finally, a modified IEEE-33 node system is adopted to verify the effectiveness of the proposed multi-timescale operational method. The method demonstrates a load forecasting accuracy of 93.22%, achieves a reduction of 1.906% in load power demand, and enables timely voltage regulation during intraday limit violations, effectively maintaining grid operational stability. Full article

The increasing penetration of distributed energy resources (DERs) and power electronic loads challenges the modeling and control of modern distribution networks (DNs). The traditional models often fail to capture the complex aggregate dynamics required for advanced control strategies. This paper proposes a novel framework for DN power regulation based on Neural Ordinary Differential Equations (NODEs) and Model Predictive Control (MPC). NODEs are employed to develop a data-driven, continuous-time dynamic model capturing the aggregate relationship between the voltage at the point of common coupling (PCC) and the network’s power consumption, using only PCC measurements. Building upon this NODE model, an MPC strategy is designed to regulate the DN’s active power by manipulating the PCC voltage. To ensure computational tractability for real-time applications, a local linearization technique is applied to the NODE dynamics within the MPC, transforming the optimization problem into a standard Quadratic Programming (QP) problem that can be solved efficiently. The framework’s efficacy is comprehensively validated through simulations. The NODE model demonstrates high accuracy in predicting the dynamic behavior in a DN against a detailed simulator, with maximum relative errors below 0.35% for active power. The linearized NODE-MPC controller shows effective tracking performance, constraint handling, and computational efficiency, with typical QP solve times below 0.1 s within a 0.1 s control interval. The validation includes offline tests using the NODE model and online co-simulation studies using CloudPSS and Python via Redis. Application scenarios, including Conservation Voltage Reduction (CVR) and supply–demand balancing, further illustrate the practical potential of the proposed approach for enhancing the operation and efficiency of modern distribution networks. Full article

This research aimed to ascertain the ZIP (constant impedance, constant current, and constant power) coefficients and Conservation of Voltage Reduction factor (CVR_f) for residential appliances as well as for the residential network feeders in Malaysia through measurement and simulation analysis. The required power data were obtained through varying the supply voltage from 250 V to 215 V with a 5 V reduction. The appliances’ components were identified using the ZIP coefficients solved with the Sequential Least Squares Programming optimizer in Python (Spyder 5.5.4). The CVR_f for residential appliances was determined using the well-established voltage and power correlation analysis. The study’s findings demonstrate a strong association between the appliance load composition determined by the ZIP load model and CVR_f. This paper’s primary contribution is a comprehensive analysis conducted using the ZIP and CVR techniques to ascertain each appliance’s load composition. Based on the findings of this study, a classification is developed and extended to include a range of findings from other published studies in which the conclusion is consistent. Moreover, the CVR_f value for one residence corresponds to a residential substation CVR_f which is further validated via bottom-up load model analysis. The main contribution of this paper is to categorize residential appliances based on constant impedance, constant current, and constant power through the ZIP load model and the CVR_f. Additionally, this CVR analysis is the pioneer study in Malaysia; thus, it is crucial to develop a systematic approach for identifying and classifying household devices according to their electrical characteristics. Load categorization provides the fundamental understanding about an appliance to determine its behavior towards a change in voltage, thus establishing cost savings and energy management in a home. Full article

The operation of the utility grid is being reshaped by the continuous addition of distributed energy resources and advanced metering infrastructure, which challenge existing grid control strategies. Some utilities deploy advanced distribution management systems (ADMS) to assist with the consolidation of various applications and to augment situational awareness in response to the new power delivery dynamics. An ADMS is an integrated software platform that provides utilities with a way to enhance their reliability, control, and optimization with advanced applications, such as volt/VAR optimization (VVO). A VVO application could serve as a vehicle to deliver cost savings by providing the utility with a method to reduce rates by controlling the voltage and decreasing the energy usage in their service territory. Some utilities are reluctant to integrate an ADMS, because it is a significant investment that requires approval from the public regulatory commission and/or their customers. This paper evaluates the impact on VVO performance when using a lower-quality network model supplemented with additional measurements, which could provide an implementation for cost savings. The results show that a better model quality would provide the highest energy savings; however, some level of telemetry is necessary in all scenarios to prevent voltage exceedances. Full article

Conservation Voltage Reduction (CVR) is a potential energy management approach for increasing computer system energy efficiency. This study uniquely contributes to the field by thoroughly investigating the impact of CVR on computing devices, filling a significant gap in the existing literature. The research employs a novel experimental approach, considering the temporal variations in energy use behavior, and presents a comprehensive benchmark analysis of desktop PCs and laptops. Notable gains in processing efficiency are observed, with specific instances such as Desktop 1’s 1.53% Single-Core performance improvement and Desktop 3’s 3.19% total performance boost. Despite variations, the thermal performance of CVR-equipped devices, particularly Desktop 3 and Laptop 3, consistently demonstrates lower temperatures, indicating thermal management enhanced by 3.19% and 1.35%, respectively. Additionally, the study introduces the CVR Performance Enhancement Ratio (%), providing a unique metric for evaluating the trade-offs between energy efficiency and system performance. This research highlights the dual impact of CVR on thermal and computational elements, emphasizing its broad advantages. Integrating CVR emerges as a viable strategy for developing more durable, efficient, and sustainable computing devices, setting the stage for advancements in voltage regulation. Full article

This paper presents a detailed study of the energy savings that can be achieved through residential appliances by implementing conservation voltage reduction (CVR). The computed energy savings are derived from the ZIP coefficients of a load model (static) under varying voltage conditions that represent the power consumed by each appliance tested. Multiple studies have shown energy savings at the substation level but not at the level of a specific residence and appliance; hence, the latter is the focus of this analysis. The appliances are determined based on the type of heating and cooling loads, and the daily duration of use for each appliance, which contributes to the total monthly consumption that is billed for a household are included in this study. Energy savings in Malaysia has been a focus of many current studies, and this study is the first attempt to achieve energy savings through the implementation of CVR. No published work has compared individual appliances that truly benefits from CVR, and this is addressed in this study. The main contribution of this study is that it provides very detailed and measured data that are used to analyze and generate energy savings for very specific residential appliances intended to meet every 1% voltage drop. The load model is developed for the common household appliances in Malaysia, and then a voltage reduction study is applied to the appliances as well as the Malaysian distribution networks. Here, we also provide insight for performing voltage reduction at an electric vehicle (EV) charging station in Malaysia. The results of this study should serve as a foundation for all practicing utilities engineers to address the issue of CVR in Malaysia. The CVR factors for residential, commercial, and industrial networks in Malaysia are also published in this paper. Full article

This paper presents a novel modular voltage control algorithm for optimal scheduling of a distribution system’s load tap changers to minimize the number of tap changes while maintaining a voltage deviation (VD) around a desired target. To this end, a bi-objective optimal voltage regulation (OVR) problem is addressed in two distinct stages. First, the operational constraint on the load tap changer is removed to form a single-objective OVR problem relating to the voltage. The solution obtained in this stage is ultimately utilized to determine the penalty value assigned to the distance from the optimal (solely in terms of voltage) control value. In the second stage, the optimal scheduling problem is formulated as a minimum-cost-path problem, which can be efficiently solved via dynamic programming. This approach allows the identification of optimal scheduling that considers both the voltage-related objective as well as the number of load tap changer switching operations with no added computational burden beyond that of a simple voltage optimization problem. The method imposes no restriction on the load tap changer’s operation and is tested under two different target functions on the standard IEEE-123 test case. The first attains a nominal voltage with a 0.056 p.u. voltage deviation and the second is the well-known conservation voltage reduction (CVR) case with a 0.17 p.u. voltage deviation. The method is compared to an evolutionary-based algorithm and shows significant improvement in the voltage deviation by a factor of 3.5 as well as a computation time acceleration of two orders of magnitude. The paper demonstrates the effectiveness and potential of the proposed method as a key feature in future cutting-edge OVR methods. Full article

As the smart grid involves more new technologies such as electric vehicles (EVs) and distributed energy resources (DERs), more attention is needed in research to general energy storage (GES) based energy management systems (EMS) that account for all possible load shifting and control strategies, specifically with major appliances that are projected to continue electrification such as the electric water heater (EWH). In this work, a methodology for a modified single-node model of a resistive EWH is proposed with improved internal tank temperature for user comfort modeling and capabilities for conservation voltage reduction (CVR) simulations as well as Energy Star and Consumer Technology Association communications protocol (CTA-2045) compliant controls, including energy storage calculations for “energy take”. Daily and weekly simulations are performed on a representative IEEE test feeder distribution system with experimental load and hot water draw (HWD) profiles to consider user comfort. Sequential controls are developed to reduce power spikes from controls and lead to peak shavings. It is found that EWHs are suitable for virtual power plant (VPP) operation with sustainable tank temperatures, i.e., average water temperature is maintained at set-point or above at the end of the control period while shifting up to 78% of EWH energy out of shed windows per day and 75% over a week, which amounts to up to 23% of the total load shifted on the example power system. While CVR simulations reduced the peak power of individual EWHs, the aggregation effect at the distribution level negates this reduction in power for the community. The EWH is shown as an energy constant load without consistent benefit from CVR across the example community with low energy reductions of less than 0.1% and, in some cases, increased daily energy by 0.18%. Full article

It has been suggested in the literature that by reducing the incoming voltage at a distribution feeder head or at the supply side of buildings, significant electricity savings can be achieved. This technique is called Conservation Voltage Reduction (CVR). Data-based analysis with and without CVR is primarily used to support such assertions, which does not explain the physics behind reduction in energy consumption with CVR. This paper presents a new approach for evaluating the impact of CVR on cooling equipment. In this approach, a thermal-electric model of the cooling process is developed in MATLAB’s SIMSCAPE toolbox that can be used to explain the physics behind energy reduction with CVR. This model includes an accurate model of a compressor coupled to an induction motor whose supply voltage can be varied to simulate CVR. Simulations performed using this model show that the Coefficient of Performance (COP) of cooling equipment improves with a reduction in supply voltage. However, the energy lost in the motor windings may nullify the impact of the improvement in the COP and render the CVR programs ineffective if the range of speed change is small over the allowable voltage change. The simulation results show an increase in energy consumption of 4% at 90% rated voltage compared to the energy consumed at the rated voltage. However, if variable frequency drives-based cooling equipment is appropriately controlled, it is possible to reduce their net energy consumption using CVR. Simulations performed keeping the ratio of the supply voltage and the frequency constant showed a reduction in energy consumption of 2.5% at 90% rated voltage compared to the energy consumed at the rated voltage. Thermal-electric modeling of building cooling equipment is, therefore, vital to accurately evaluating the benefits of CVR as smart, power electronics-based end-use equipment is globally adopted. Full article

The application of voltage reduction in medium and low voltage grids to reduce peak power demand or energy consumption has been implemented since the 1980s using several approaches. Conservation Voltage Reduction (CVR), as one such approach, uses a voltage control device to reduce or increase the voltage setpoint on a busbar, thereby reducing or increasing the amount of active and reactive power supply in the network. Voltage regulation for CVR is always implemented according to established network planning standards in each country. Research in this field has proven that a CVR factor (${CVR}_f$) of 0.7–1.5 for peak demand reduction can be achieved. This is an evaluation metric of CVR. The aim of this research is to determine and validate ${CVR}_f$ for peak demand reduction by comparing actual results obtained during regular tap changes with other randomly distributed periods outside tap change operations, using a set of measurement data. It is important to understand CVR deployment capability by evaluating CVR potentials from historical random tap operations before a robust network-wide deployment is introduced. This research provides such guidance. It also provides a novel approach to determining tap changes from voltage measurements using a time-based algorithm. A ${CVR}_f$ ranging from 0.95 to 1.61 was estimated using a measurement dataset from a test field. The result of the entire evaluation shows that the ${CVR}_f$ are smaller during peak PV production and greater during peak demand periods. Further evaluation using statistical hypotheses testing and a control chart was used to validate the evaluation. Full article

Conservation voltage reduction (CVR) is a potentially effective and efficient technique for inertia synthesis and frequency support in modern grids comprising power electronics (PE)-based components, aiming to improve dynamic stability. However, due to the complexities of PE-based grids, implementing the CVR methods cannot be performed using traditional techniques as in conventional power systems. Further, quantifying the CVR impacts in modern grids, while focusing on dynamic time scales, is critical, consequently making the traditional methods deficient. This is an important issue as CVR utilization/quantification depends on grid conditions and CVR applications. Considering these concerns, this work offers a thorough analysis of CVR applications, implementation, and quantification strategies, including data-driven AI-based methods in PE-based modern grids. To assess the CVR applications from a new perspective, aiming to choose the proper implementation and quantification techniques, they are divided into categories depending on various time scales. CVR implementation methods are categorized into techniques applied to PE-based grids and islanded microgrids (MGs) where different control systems are adopted. Additionally, to address the evaluation issues in modern grids, CVR quantification techniques, including machine learning- and deep learning-based techniques and online perturbation-based methods are evaluated and divided based on the CVR application. Concerns with the further utilizing and measuring of CVR impacts in modern power systems are discussed in the future trends section, where new research areas are suggested. Full article

The objective of this study is to perform peak load shaving at a virtual power plant (VPP) to maximize the electricity cost-saving for local distribution companies (LDCs) while satisfying the necessary operational constraints. It can be achieved by implementing an efficient algorithm to control the conservation voltage reduction technique (CVR) with embedded energy resources (EERs) to optimize electricity costs during peak hours. EERs consist of distributed energy resources (DERs) such as solar and diesel generators and energy storage systems (ESSs) such as utility-scale and residential batteries. An objective function of mixed integer linear programming is formulated as the electricity cost function. Different operational constraints of EERs are formulated to solve the peak shaving optimization problem. The proposed algorithm is tested using data from a real Australian power distribution network. This paper discusses four cases to demonstrate the performance and economic benefits of the control algorithm. Each of these cases illustrates how EERs contribute differently each year, month, and day. Results showed that the proposed algorithm offers significant cost savings and can shave up to three daily peaks. Full article

The peak-load management of a distribution network (DN) has gained attention by increasing the electric power consumption on the demand side. By developing smart-grid infrastructures, effective utilization of the DN’s components and proper management of the DN would create a valuable solution for DN operators. Hence, in this paper, a peak-load management framework is proposed in which the real-time rating of the components and voltage-dependent features of the electric loads help the DN operator handle the peak times successfully. In addition to the individual advantages of efficient operation of the DN, more practical results are obtained by combining the conservation voltage reduction (CVR) and dynamic thermal rating (DTR) of the DN’s lines and transformers. Based on the obtained results, compared to the individual implementation of CVR, the cost-saving level is increased significantly during the peak events using the simultaneous utilization of DTR and CVR. Furthermore, a discussion is presented about the current problems of the feeders supplying the voltage-dependent constant-power loads during CVR utilization, which is resolved by the dynamic rating of the DN’s components. Full article

Conservation through voltage reduction (CVR) aims to reduce the peak load and energy savings in electric power systems and is being deployed at various utilities. The effectiveness of the CVR program depends on the load characteristics, i.e., the sensitivity of the load to voltage variation, and voltage regulation device settings. In the current literature, there is a lack of discussion on the CVR factor calculation using different measurements, and there is a lack of method for active power loss estimation using substation measurements. This paper provides insights into CVR factor calculation based on the measurements captured at the substation and those at the load location. This paper also proposes a new method based on curve fitting and artificial neural network to estimate the active power loss using input active power, input reactive power and input voltage at the substation. The CVR comparison study conducted in this paper helps in understanding the factors affecting CVR factor and may provide guidance in CVR implementation and impact assessment. The proposed loss estimation method sheds light on the impacts of CVR in terms of load and loss reduction. The results based on simulation studies using the IEEE 13-bus and 34-bus systems are reported in this paper, noting that the proposed methods are applicable to larger systems, as long as the required measurements at the substation are available. Future research includes testing and refining the methods using large IEEE and utility distribution systems and considering the stochastic nature of the CVR factor with changing load and voltage regulator control schemes. Full article

Recent research has enabled the integration of traditional Volt-VAr Control (VVC) resources, such as capacitor banks and transformer tap changers, with Distributed Energy Resources (DERs), such as photo-voltaic sources and energy storage, in order to achieve various Volt-VAr Optimization (VVO) targets, such as Conservation Voltage Reduction (CVR), minimizing VAr flow at the transformer, minimizing grid losses, minimizing asset operations and more. When more than one target function can be optimized, the question of multi-objective optimization is raised. In this work, a general formulation of the multi-objective Volt-VAr Optimization problem is proposed. The applicability of various multi-optimization techniques is considered and the operational interpretation of these solutions is discussed. The methods are demonstrated using a simulation on a test feeder. Full article
