In many construction applications, including bridge pedestals, concrete corbels, and concrete anchors, the concrete’s local compressive strength attribute (bearing) is crucial. One of the benefits from concrete’s bearing is its role in mitigation construction failure risk and increase the safety of the buildings. The local compression characteristics of fully hardened concrete were the primary focus of earlier study, with less attention paid to early age concrete (less than 28 days). In order to evaluate the bearing qualities of early age concrete—here defined as the first month—the current experimental program is being carried out. While the bearing plate’s area (Ab), which was placed in the middle of each block’s top surface, differed in dimension (100 × 100 mm, 80 × 80 mm, 60 × 60 mm, and 40 × 40 mm), the concrete pedestals’ size remained constant at 250 × 250 × 200 mm. Tests were conducted on sixteen concrete supports. Four equal groups of samples were created, and each group underwent testing at a different age (T = 3, 7, 15, and 28 days). In each group, unloaded-to-loaded area is varied (A₁/A_b = 6.25, 9.76, 17.36, and 39). The failure, bearing stress–slip curve, ultimate bearing strength and ultimate associated deformation of the tested concrete supports were studied. The results showed that the compressive and tension strengths increased by 178% and 244% when the concrete age reached 28 days compared to 3 days-concrete. As A₁/A_b or/and concrete age increased, the bearing characteristics improved more. The ultimate bearing strength increased by 51%, 56.5%, and 69.5% at $\sqrt{{\displaystyle \frac{A_1}{A_b}}}$ = 6.25 when the samples’ concrete age increased from 3 to 7, 15, and 28 days. The main contribution of this study is a novel formula to forecast the concrete’s bearing strength while accounting for the impact of the concrete’s age and the ratio $\sqrt{{\displaystyle \frac{A_1}{A_b}}}$. Full article

This study aimed to investigate the shear performance of reinforced concrete corbels and to evaluate the accuracy and safety of the Chinese code GB 50010-2010’s triangular truss model and the American code ACI 318-19’s strut-and-tie model under various design parameters with a specified design load. A total of 22 corbel specimens with different dimensions and reinforcement configurations were designed and simulated using the finite element software ABAQUS 2020, incorporating the microplane M7 material model, which was validated against experimental data. The findings reveal that for corbels with high-strength concrete or larger shear spans, the Chinese code offers a higher safety margin. Conversely, the safety margin according to the American code initially increases and then decreases with the enhancement of concrete strength, while changes in the shear span have an insignificant impact on the safety margin, which tends to decrease as the shear span increases. Additionally, the inclusion of stirrup reinforcement significantly improves the load-bearing capacity of corbels, with an increase ranging from 15% to 46% compared to those without stirrups. Full article

The advantage of 3DCP technologies is the ability to fabricate free-form structures. However, printing openings in concrete structures are limited by the presence of overhanging sections. While various 3D printing and additive manufacturing technologies have established methods for handling overhangs with temporary supports, many existing techniques for 3D concrete printing still rely on wooden planks and corbelling, which restrict the design flexibility and slope angles. The objective of this study is to develop a removable and sustainable support material with high printability performance. This support material serves as temporary support for overhang sections in 3D-printed structures and can be removed once the primary concrete has hardened sufficiently. This study observed that increasing the recycled glass content in the mixture raises both the dynamic and static yield stresses, with only mixtures containing up to 60% recycled glass remaining pumpable. Optimization of the mixture design aimed to balance high flowability and buildability, and the results indicated that a mixture with 60% recycled glass content is optimal. The effectiveness of the optimized support material was validated through the successful printing of a structure featuring a free-form opening and overhang section. Full article

To investigate the impact of various compartment partition plate connection methods within a shield utility tunnel on the mechanics behavior of the connecting nodes and the overall structural integrity, this study examines and simulates three distinct connection approaches in a laboratory. These approaches include a steel corbel and rear expansion anchor bolt connection, an embedded part and steel corbel welding connection, and a reinforced concrete corbel connection. The objective in selecting the above three connection methods was to gain insights into how they influence the mechanical properties of the connections and the tunnel structure itself. The failure criteria of the structure dictate that neither the steel bar nor the steel plate should exceed their respective yield strength. Furthermore, the concrete damage zone surrounding the anchor should not exhibit any connectivity. The findings of our study indicate that: (1) The weak link in the steel truss-rear expansion anchor bolt connection scheme is centered within the connection section. With six rear expansion anchor bolts, the load capacity reached 180 kN. Conversely, when employing nine rear expansion anchor bolts, the reduced spacing between the bolts led to premature concrete breakage, decreasing the bearing capacity to 170 kN. (2) Arranging the six anchor bolts into two rows and three columns enhanced the load-bearing capacity, yet one must be cautious to prevent damage from incorrect bolt spacing. According to the conditions outlined in this study, the ideal bolt spacing fell within the range from 66.7 mm to 100 mm. Additionally, it is worth noting that the bolt deformation was concentrated within 5 cm and 6 cm around the bolt. (3) The connection scheme of the embedded part and steel corbel demonstrated impressive load-bearing capabilities, showing the ability to withstand a load of 220 kN within the elastic stage. Notably, the deformation of the anchor bar was concentrated primarily within a 5 cm radius around the corbel. (4) In the reinforced concrete corbel connection scheme, the load-bearing capacity reached 240 kN. The key factor influencing this capacity was the presence of cracks. Initially, these cracks appeared symmetrically on both sides of the corbel, and gradually extended to the width and height of the corbel structure. Full article

In order to analyze the shear mechanism of the steel-fiber high-strength concrete corbels, a calculation model for the shear bearing capacity of steel-fiber-reinforced high-strength concrete corbels was proposed based on the modified compression field theory. Considering the existence of residual tensile stress in steel-fiber-reinforced concrete at crack locations, the cracked steel-fiber-reinforced concrete was treated as a continuous material. The constitutive relation of cracked steel-fiber-reinforced concrete and the local stress equilibrium equation were modified. It was compared with the results of 34 steel-fiber high-strength concrete corbels, including those in this paper. The predicted results were compared with the experimental values and the predictions of the Fattuhi model, Campione model, and Russo model to validate the rationality of the proposed model. The results revealed that the mean value between the experimental values and the predicted results of the proposed model is 1.104, with a variance of 0.003, showing good agreement. The proposed model can accurately predict the shear bearing capacity of steel-fiber-reinforced high-strength concrete corbels. Full article

This paper presents the results of experimental and numerical investigations aimed at enhancing the flexural capacity of Precast Concrete Corbel Beam–Column Connections (PC-CBCCs) using Fiber-Reinforced Plastic (FRP) sheets. The experimental study primarily focused on assessing the flexural capacity of pinned PC-CBCCs reinforced with FRP layers, comparing them to a moment-resisting connection. A series of half-scale specimens, including three PC-CBCCs with varying FRP configurations, were tested alongside one in situ concrete fixed connection. The first specimen (PC-1) utilized L-shaped and full-wrap FRPs, whereas PC-2 and PC-3 employed both U-shaped and full-wrap layers. The objective is to quantify the ultimate flexural capacity of PC-CBCCs reinforced by FRP sheets. In PC-3, the external anchorage is introduced to assess its influence on delaying the FRP layer debonding under lateral loading. The effects of the FRP layer thickness, locations, and potential debonding are examined under unidirectional static tests while applying a constant axial compressive load to the columns and subjecting the beams to lateral loads until fracture. The test results illustrate that strengthening the corbel connection with L-shaped FRP or spiral U-shaped FRP sheets without mechanical anchorage cannot result in a significant bending capacity due to debonding. However, with the incorporation of mechanical anchors, the connection manages to enhance the moment capacity to 81% of a fixed connection’s flexural capacity. Additionally, a finite element model of the PC-CBCCs and a fixed joint is developed to simulate nonlinear static analyses of the connections using ANSYS 19.2 software. The simulation model is precise in predicting the initial stiffness and ultimate capacity of the beam–column joints, as verified by the experimental results. A comprehensive comparison is conducted to determine their responses by employing various FRP configurations and properties. Moreover, design parameters such as bond length and thickness of the FRP sheets, along with appropriate mechanical anchorage, are identified as effective in preventing debonding, and delamination. However, wrapping the beam far away from the joint interface has a minimal impact on the failure mode, stress reduction, and load-bearing capacity. Full article

The Concrete Damage Plasticity (CDP) model is a widely used constitutive model to represent the non-linear behavior of concrete in numerical analysis. However, a limited number of studies compared the level of accuracy of numerical models with the main code provisions from the literature. In addition, the influence of CDP material parameters on the structural behavior of corbels was scarcely studied. This study proposes to evaluate the ability of numerical models using CDP to represent the structural behavior of corbels regarding the ultimate load, reinforcement deformation and failure mechanism. In addition, we compared the predictions of the numerical models with the ones from design code expressions regarding the ultimate capacity. For this, three test results of corbels from the literature were evaluated with numerical models using the CDP, as well as with analytical models from different code provisions. A sensitivity analysis—by changing the dilation angle (ψ) and shape factor (K_c)—was performed. The comparison between tested and predicted resistances with the proposed numerical modeling choices was equal to 1.04 with a coefficient of variation of 11%. On the other hand, the analytical models evaluated overestimated the corbel capacity by more than 62%, on average. Therefore, the proposed modeling choices provide better predictions of ultimate capacity than the evaluated analytical models and can be used to assess the corbel design under more complex boundary conditions. Full article

With the continuous utilization of renewable energy, the number of onshore wind turbines is increasing. Small design improvements can save costs and facilitate the maintenance and repair of the wind turbine foundation. In this paper, an existing gravity expansion foundation with an anchor cage is improved. Our improvements further expand the space inside the foundation and reduce the length of the anchor bolt, which could reduce the costs and facilitate construction. To study the performance of the new foundation, a three-dimensional finite element model of the foundation–soil–anchor bolt was established via a finite element simulation. The damage evolution of the foundation was simulated with the concrete damage plasticity model (CDP). The separation ratio, foundation settlement, inclination ratio, reinforcement stress, foundation stress, and foundation damage of the new foundation under ultimate load conditions were analyzed. The influence of parameters h1 and b3 on the performance of the foundation was further studied. The finite element analysis results show that the tensile stress of concrete can be effectively reduced by appropriately increasing the corbel height and ring beam width of the foundation. The results also show that the improved wind turbine foundation force is reasonable and can meet the use of the actual project requirements on the level of finite element analysis. Full article

Reinforced concrete corbels were examined in this study for the cracking behavior and strength evaluation, focusing on defects typically found in these structures. A total of 11 corbel specimens were tested, including healthy specimens (HS), specimens with lower concrete strength (LC), specimens with less reinforcement ratio (LR), and specimens with more concrete cover than specifications (MC). The HS specimens were designed using the ACI conventional method. The specimens were tested under static loading conditions, and the actual strengths along with the crack patterns were determined. In the experimental tests, the shear capacity of the HS specimens was 28.18% and 57.95% higher than the LR and LC specimens, respectively. Similarly, the moment capacity of the HS specimens was 25% and 57.52% greater than the LR and LC specimens, respectively. However, in the case of the built-up sections, the shear capacity of the HS specimens was 9.91% and 37.51% higher than the LR and LC specimens, respectively. Likewise, the moment capacity of the HS specimens was 39.91% and 14.30% higher than the LR and LC specimens, respectively. Moreover, a detailed nonlinear finite element model (FEM) was developed using ABAQUS, and a more user-friendly strut and tie model (STM) was investigated toward its suitability to assess the strengths of the corbels with construction defects. The results from FEM and STM were compared. It was found that the FEM results were in close agreement with their experimental counterparts. Full article

Non-linear finite element analysis (NLFEA) has been frequently used to assess the ultimate capacity of reinforced concrete (RC) structures under the most complex conditions. Nevertheless, the guidelines using such methods to evaluate RC corbels are limited. In addition, the influence of material modeling options regarding the behavior of such members was not investigated until now. This paper proposes to present a framework for the NLFEAs of RC corbels using the Concrete Damaged Plasticity (CDP) model. the influence of several modeling choices related to this constitutive model also is discussed in detail, including the assumed stress–strain behavior in compression and tension and the parameters related to the yield criterion and flow rule. For this, a first set of test results was used to validate the proposed approach to the NLFEA. Afterwards, the sensibility of the numerical results for several modeling choices was investigated. In the end, the proposed framework for the NLFEA was checked against a database of 36 test results from the literature. The mean ratio between the predicted and experimental test results was 1.015 with a coefficient of variation of only 8.57%. The governing failure mechanism of the tests was predicted correctly in approximately 88% of the simulations. In summary, the proposed approach allows for predicting the ultimate capacity and failure mechanism of RC corbels accurately. Full article

According to the shear capacity test results of six steel-fiber-reinforced high-strength concrete (SFHSC) corbels with welded-anchorage longitudinal reinforcement under concentrated load, the effects of shear span ratio and steel fiber volume fraction on the failure mode, cracking load and ultimate load of corbel specimens were analyzed. On the basis of experimental research, the shear transfer mechanism of corbel structure was discussed. Then, a modified softened strut-and-tie model (MSSTM), composed of the diagonal and horizontal mechanisms, was proposed, for steel-fiber-reinforced high-strength concrete corbels. The contributions of concrete, steel fiber and horizontal stirrups to the shear bearing capacity of the corbels were clarified. A calculation method for the shear bearing capacity of steel-fiber-reinforced high-strength concrete corbels was established and was simplified on this basis. The calculation results of the model were compared with the test values and calculation results of the GB50010-2010 code, the ACI318-19 code, the EN 1992-1-1 code and the CSA A23.3-19 code. The results showed that the concrete corbel with small shear span ratio mainly has two typical failure modes: shear failure and diagonal compression failure. With the increase in shear span ratio, the shear capacity of corbels decreases. Steel fiber can improve the ductility of a reinforced concrete corbel, but has little effect on the failure mode of the diagonal section. The calculated values of the national codes were lower than the experimental values, and the results were conservative. The theoretical calculation values of the shear capacity calculation model of the corbels were close to the experimental results. In addition, the model has a clear mechanical concept considering the tensile properties of steel-fiber-reinforced high-strength concrete and the influence of horizontal stirrups, which can reasonably reflect the shear transfer mechanism of corbels. Full article

The radial gate corbel beam is a kind of gate support structure more often used in large and medium-sized reservoirs, but the current corresponding structural design code does not give a review calculation method for it. Because there are obvious differences between a corbel and a corbel beam in structural form and force, if the corbel beam is just simplified in the calculation as a corbel structure, it can easily lead to misjudgment of insufficient bearing capacity. This misjudgment has a significant impact on later safety assessment, danger removal, and reinforcement. Currently, there are limited studies available on the internal stress distribution of the corbel beam. In this study, taking the danger removal and reinforcement of the radial gate beam of a medium reservoir in Beijing as an example, the concrete quality of the dam was tested by the core drilling method, and two safety review methods of the corbel beam for different types of reservoirs were proposed in combination with the Code for Design of Hydraulic Concrete Structures (SL191-2008). Then, three different types of calculation model were established by the method of theoretical mechanics calculation and finite element simulation. Combined with the safety test data, the stress state of the combined stress structure of the corbel beam and gate pier under the real state was analyzed and the safety evaluation was carried out. The calculation results of these two corbel beam safety review methods were respectively reduced by 32% and 47% compared with the current calculation method. Engineering practice has proved the rationality of the two safety evaluation methods proposed in this paper, which can provide a certain reference for similar engineering reinforcement. Full article

On the basis of the test results of nine steel-fiber high-strength concrete corbel specimens subjected to a vertical load, the influence of the steel fiber content on the shear performance of corbels was analyzed. The softened strut-and-tie model (SSTM) was used to analyze the shear strength of steel-fiber high-strength concrete corbels, taking into consideration the shear contribution of steel fibers. A calculation model for the shear strength of steel-fiber high-strength concrete corbels is proposed, and a database for 26 steel-fiber high-strength concrete corbels was created by using the model. The results obtained according to the codes ACI318-19, EC2, CSA A23.3-19 and the softened strut-and-tie model were compared with the experimental values to verify the rationality of the model. The findings showed that steel fiber can effectively limit the crack width and improve the crack morphology. The overall average value of the ratio between the experimental and the predicted strengths of the model was 1.082, and the variance was 0.004. The values predicted with the proposed calculation model were closer to the experimental values than those calculated according to the codes. This study provides a definite mechanical model that can reveal the shear mechanism of steel-fiber high-strength concrete. It can reasonably predict the shear strength of steel-fiber high-strength concrete corbels. Full article

As short cantilever members, corbels are mainly used to transfer eccentric loads to columns. Because of the discontinuity of load and geometric structure, corbels cannot be analyzed and designed using the method based on beam theory. Nine steel-fiber-reinforced high-strength concrete (SFRHSC) corbels were tested. The width of the corbels was 200 mm, the cross-section height of the corbel column was 450 mm, and the cantilever end height was 200 mm. The shear span/depth ratios considered were 0.2, 0.3, and 0.4; the longitudinal reinforcement ratios were 0.55%, 0.75%, and 0.98%; the stirrup reinforcement ratios were 0.39%, 0.52%, and 0.785%; and the steel fiber volume ratios were 0, 0.75%, and 1.5%. According to the test results, this paper discusses the failure process and failure mode of corbel specimens with a small shear span/depth ratio and analyzes the effects of variables such as shear span/depth ratio, longitudinal reinforcement ratio, stirrup reinforcement ratio, and steel fiber volume content on the shear capacity of corbels. The shear capacity of corbels is significantly affected by the shear span/depth ratio, followed by the longitudinal reinforcement ratio and the stirrup reinforcement ratio. Moreover, it is shown that steel fibers have little impact on the failure mode and ultimate load of corbels, but can enhance the crack resistance of corbels. In addition, the bearing capacities of these corbels were calculated by Chinese code GB 50010-2010 and further compared with ACI 318-19 code, EN 1992-1-1:2004 code, and CSA A23.3-19 code, which adopt the strut-and-tie model. The results indicate that the calculation results by the empirical formula in the Chinese code are close to the corresponding test results, while the calculation method based on the strut-and-tie model of a clear mechanical concept yields conservative results, and hence the related parameter values must be further modified. Full article

In this paper, five reinforced concrete double-corbel specimens with the same designed bearing capacity are produced according to the triangular-truss method (TTM) in GB 50010-2010. Corbels with different dimensions and reinforcement configurations are obtained by separately varying the concrete compressive strength and shear span. The differences in the mechanical performance and load-bearing capacity of the corbels are compared to evaluate the accuracy and rationality of the TTM under specific variables. Then, the accuracy in predicting the load-bearing capacity of GB 50010-2010, ACI 318-19, EC 2, CSA A23.3-04, the softened strut-and-tie method, and the Russo strut-and-tie method is compared. The results show that the safety factor (ratio of the actual bearing capacity to the designed bearing capacity) of the TTM is increased from 1.419 to 1.718 when the concrete strength is improved from 20.8 MPa to 65.3 MPa; the safety factor of the TTM is increased from 1.414 to 1.859 when the shear span–depth ratio is increased from 0.25 to 0.67. Compared to GB 50010-2010, ACI 318-19, and EC 2, the predictions of CSA A23.3-04 for corbels are closer to the test values. The safety level of codes GB 50010-2010, ACI 318-19, and EC 2 is essentially the same; both the SSTM and the Russo STM are accurate in the predictions. Full article
