Search Results (60)

This study presents a strut-and-tie modeling (STM) framework for reinforced concrete (RC) deep beams strengthened with intraply hybrid composites (IRCs), integrating comprehensive experimental data from beams with three different span lengths (1.0 m, 1.5 m, and 2.0 m). Although the use of fiber-reinforced polymers (FRPs) for shear strengthening of RC members is well established, limited attention has been given to the development of STM formulations specifically adapted for hybrid composite systems. In this research, three distinct IRC configurations—Aramid–Carbon (AC), Glass–Aramid (GA), and Carbon–Glass (CG)—were applied as U-shaped jackets to RC beams without internal transverse reinforcement and tested under four-point bending. All experimental data were derived from the authors’ previous studies, ensuring methodological consistency and providing a robust empirical basis for model calibration. The proposed modified STM incorporates both the axial stiffness and effective strain capacity of IRCs into the tension tie formulation, while also accounting for the enhanced diagonal strut performance arising from composite confinement effects. Parametric evaluations were conducted to investigate the influence of the span-to-depth ratio (a/d), composite configuration, and failure mode on the internal force distribution and STM topology. Comparisons between the STM-predicted shear capacities and experimental results revealed excellent correlation, particularly for deep beams (a/d = 1.0), where IRCs substantially contributed to the shear transfer mechanism through active tensile engagement and confinement. To the best of the authors’ knowledge, this is the first study to formulate and validate a comprehensive STM specifically designed for RC deep beams strengthened with IRCs. The proposed approach provides a unified analytical framework for predicting shear strength and optimizing the design of composite-strengthened RC structures. Full article

Steel fiber-reinforced concrete (SFRC) exhibits superior tensile and flexural strengths, crack resistance, compressive toughness, and ductility. These characteristics make SFRC attractive for precast beam joints, shear-critical regions without stirrups, and retrofitted overlays, thereby enabling composite members. However, the shear and flexural responses of such members often differ from monolithically cast elements. To clarify these effects, nine composite specimens and one cast-in-place control were tested under four-point bending. Key parameters, including load-bearing capacity, failure evolution, and failure modes, were documented, together with load–deformation behavior, reinforcement strains, and concrete deformations. Results showed that horizontal joints reduced shear resistance and altered crack propagation compared to monolithic beams. Incorporating 1.0% hooked-end steel fibers improved both shear and flexural performance. SFRC above the joint was more effective for shear, while SFRC in both zones improved flexure. The fully SFRC specimen without stirrups achieved 63% higher shear capacity than its NC counterpart, with ductility rising from 2.2 to 3.1. A 1.0% fiber dosage provided shear resistance equivalent to D8@200 stirrups, confirming the potential of SFRC to reduce transverse reinforcement. Analytical models, including a fiber beam–column element and strut-and-tie approach, showed reasonable agreement with experiments. Full article

Reinforced concrete (RC) deep beams constructed with low-strength concrete are susceptible to sudden splitting failures in the strut region due to shear–compression stresses. To mitigate this vulnerability, various strengthening techniques, including steel plates, fiber-reinforced polymer sheets, and cementitious composites, have been explored to confine the strut area. This study investigates the structural performance of RC deep beams with low-strength concrete, strengthened externally using an Engineered Cementitious Composite (ECC) layer. To ensure effective confinement and uniform shear distribution, shear reinforcement was provided at equal intervals with configurations of zero, one, and two vertical shear reinforcements. Four-point bending tests revealed that the ECC layer significantly enhanced the shear capacity, increasing load-carrying capacity by 51.6%, 54.7%, and 46.7% for beams with zero, one, and two shear reinforcements, respectively. Failure analysis through non-linear finite element modeling corroborated experimental observations, confirming shear–compression failure characterized by damage in the concrete struts. The strut-and-tie method, modified to incorporate the tensile strength of ECC and shear reinforcement actual stress values taken from the FE analysis, was used to predict the shear capacity. The predicted values were within 10% of the experimental results, underscoring the reliability of the analytical approach. Overall, this study demonstrates the effectiveness of ECC in improving shear performance and mitigating strut failure in RC deep beams made with low-strength concrete. Full article

Bioabsorbable polymer stents (BPSs) were developed to address the long-term clinical drawbacks associated with permanent metallic stents by gradually dissolving over time before these drawbacks have time to develop. However, the polymers used in BPSs, such as polylactic acid (PLA), have lower mechanical properties than metals, often requiring larger struts to provide the necessary structural support. These larger struts have been linked to delayed endothelialisation and an increased risk of stent thrombosis. To address this limitation, this study investigated the incorporation of high-strength basalt fibres into PLA to enhance its mechanical performance, with an emphasis on optimising the processing conditions to achieve notable improvements at minimal fibre loadings. In this regard, PLA/basalt fibre composites were prepared via twin-screw extrusion at screw speeds of 50, 200, and 350 RPM. The effects were assessed through ash content testing, tensile testing, SEM, and rheometry. The results showed that lower screw speeds achieved adequate fibre dispersion while minimising the molecular weight reduction, leading to the most substantial improvement in the mechanical properties. To examine whether a second extrusion run could enhance the fibre dispersion, improving the composite’s uniformity and, therefore, mechanical enhancement, all the batches underwent a second extrusion run. This run improved the dispersion, leading to increased strength and an increased modulus; however, it also reduced the fibre–matrix adhesion and resulted in a notable reduction in the molecular weight. The highest mechanical performance was observed at 10% fibre loading and 50 RPM following a second extrusion run, with the tensile strength increasing by 20.23% and the modulus by 27.52%. This study demonstrates that the processing conditions can influence the fibres’ effectiveness, impacting dispersion, adhesion, and molecular weight retention, all of which affect this composite’s mechanical performance. Full article

Porous bone implants have been extensively studied, with gradient structures receiving increasing attention due to their superior compatibility with bone tissue. However, comparative studies between gradient and uniform structures remain relatively scarce. In this study, selective laser melting (SLM) technology was employed to fabricate a gradient composite Ti6Al4V humeral bone plate, utilizing rhombic dodecahedron and its derived structures as unit cells. By adjusting the porosity parameter range to 22.02–94.37% using the Ashby Gibson formula, the mechanical properties of the porous bone plate were analyzed by varying the porosity parameters and conducting compression tests. The experimental results show that after preparing and compressing the structure, the elastic modulus of the model is controlled between 0.09–5.43 GPa, and the maximum yield strength is 216.1 Mpa. The experimental results demonstrate that, under shear loading, the gradient structure generates stress from the center of mass, with the phenomenon becoming more pronounced as the number of struts aligned with the direction of the applied load increases. This results in the model exhibiting characteristics of good resilience on the outside and a certain degree of rigidity on the inside. Compared to non-gradient models, gradient structures are more effective in controlling the direction of force transmission. Moreover, the elastic modulus of the bone plate is closer to that of natural bone tissue. These findings provide valuable insights for further research into gradient structure models of other rod-shaped unit cells, highlighting the mechanical advantages of gradient structures over uniform ones. Full article

The field of tissue engineering increasingly demands accurate predictive models to optimize the 3D printing process of bio-scaffolds. This study presents a unified numerical model that predicts extrusion velocity and strut diameter based on printing conditions and the material properties of polycaprolactone (PCL) and dimethyl sulfone (DMSO₂) composites. The extrusion velocity was simulated using Navier–Stokes equations, while the strut diameter was calculated via a surface energy model. For PCL, the extrusion velocity showed a temperature coefficient of 23.3%/°C and a pressure coefficient of 19.1% per 100 kPa; the strut diameter exhibited a temperature coefficient of 21.6%/°C and a pressure coefficient of 16.6% per 100 kPa. When blended with DMSO₂, the lower viscosity and higher surface energy resulted in increased extrusion velocity and strut diameter. The proposed model achieved a high predictive accuracy, with determination coefficient (R²) values exceeding 0.95. These results demonstrate the model’s potential to optimize 3D printing parameters, guide biomaterial selection, and predict pore characteristics, ultimately supporting the rational design of tissue engineering scaffolds. Full article

The current commitment towards aviation climate neutrality and decarbonisation is boosting research programmes on disruptive aircraft configurations featuring sustainable powertrains and fuel-efficient airframes. This trend is pushing the design towards high-aspect-ratio wings made of lightweight structures housing distributed propulsion systems. Airframe preliminary sizing and mass estimation of non-conventional configurations, if performed using legacy methodologies based on experience, gathered with traditional configurations may result in non-optimised and non-viable designs. Therefore, a physics-based optimisation approach may allow more accurate sizing and airframe mass estimation. The methodology suggested in this paper is based on the automatic generation of a global finite element model to estimate the weight and determine a feasible material distribution for the wing box structure of a strut-braced wing configuration by means of size optimisation. Composite materials with defined stacking sequences were assigned to the wing components and structural weight minimised with the aim of offsetting the weight penalties associated with this non-conventional aircraft configuration. Preliminary results suggest that the composite strut-braced wing could achieve a weight reduction of up to 44% compared to a composite cantilever wing with equal aspect ratio of 20. The actual weight reduction is thought to be lower due to potential overestimation of the cantilever configuration. Full article

In this study, an experimental program was conducted to investigate the shear behavior of beams made of high-strength and lightweight cementitious composites (HS-LWCCs) containing hollow glass microspheres and carbon nanotubes. The compressive strength and dry density of the HS-LWCCs were 87.8 MPa and1.52 t/m³, respectively. To investigate their shear behavior, HS-LWCC beams with longitudinal rebars were fabricated. In this test program, the longitudinal and shear reinforcement ratios were considered as the test variables. The HS-LWCC beams were compared with ordinary high-strength concrete (HSC) beams with a compressive strength of 89.3 MPa to determine their differences; the beams had the same reinforcement configuration. The test results indicated that the initial stiffness and shear capacity of the HS-LWCC beams were lower than those of the HSC beams. These results suggested that the low shear resistance of the HS-LWCC beams led to brittle failure. This was attributed to the beams’ low elastic modulus under compression and the absence of a coarse aggregate. Furthermore, the difference in the shear capacity of the HSC and HS-LWCC beams slightly decreased as the shear reinforcement ratio increased. The diagonal compression strut angle and diagonal crack angle of the HS-LWCC beams with shear reinforcement were more inclined than those of the HSC beams. This indicated that the lower shear resistance of the HS-LWCCs could be more effectively compensated for when shear reinforcement is provided and the diagonal crack angle is more inclined. The ultimate shear capacities measured in the tests were compared with various shear design provisions, including those of ACI-318, EC2, and CSA A23.3. This comparison showed that the current shear design provisions considerably overestimate the contribution of concrete to the shear capacity of HS-LWCC beams. Full article

Graphene foam composite is a promising candidate for advanced thermal management applications due to its excellent mechanical strength, high thermal conductivity, ultra-high porosity and huge specific surface area. In this study, a three-dimensional physical model was developed in accordance with the dodecahedral structure of graphene foam composite. A comprehensive numerical simulation was carried out to investigate the fluid flow and convective heat transfer in open-cell graphene foam composite by using ANSYS Fluent 2021 R1 commercial software. Research results show that, as porosity increases, the pressure gradient for graphene foam composite with circular and triangular cross-section struts is reduced by 65% and by 77%, respectively. At a given porosity of 0.904, when the inlet velocity increases from 1 m/s to 5 m/s, the pressure gradient is increased by 11.3 times and 13.8 times, and the convective heat transfer coefficient is increased by 54.5% and 43% for graphene foam composite with circular and triangular cross-section struts, respectively. Due to the irregularity of the skeleton distribution, the pressure drop in Y direction is the highest among the three directions, which is 8.7% and 17.4% higher than that in the Z and X directions at the inlet velocity of 5 m/s, respectively. The convective heat transfer coefficient in the Y direction is significantly lower than that along the X and Z directions. Furthermore, triangular cross-section struts induce a greater pressure drop but offer less effective heat transfer compared to circular struts. The research findings may provide critical insights into the design and optimization of graphene foam composites, and promote their potential for efficient thermal management and gas/liquid purification in engineering applications. Full article

Co-continuous interlocking lattice structures usually present superior compressive properties and energy absorption characteristics. In this study, co-continuous interlocking polydimethylsiloxane/polylactic acid (PDMS/PLA) lattice composites were designed with different strut diameters, and successfully manufactured by combining the fused deposition modeling (FDM) technique and the infiltration method. This fabrication method can realize the change and control of structure parameters. The effects of the strut diameter on the compressive properties and energy absorption behavior of PDMS/PLA lattice composites were investigated by using quasi-static compression tests. The compressive properties of the co-continuous interlocking PDMS/PLA lattice composites can be adjusted in a narrow density range by a linear correlation. The energy absorption density of the co-continuous interlocking PDMS/PLA lattice composites increases with the increase in the PLA strut diameter and presents a higher efficiency peak and wider plateau region. The PLA lattice acts as a skeleton and plays an important role in bearing the compressive load and in energy absorption. The indexes of the compressive properties/energy absorption characteristics and PLA volume fraction of co-continuous interlocking PDMS/PLA lattice composites show linear relationships in logarithmic coordinates. The effect of the PLA volume fraction increasing on the plateau stress is more sensitive than the compressive strength and energy absorption density. Full article

Graphene foam prepared by the chemical vapor deposition method is a promising thermal interfacial material. However, the thermal properties of graphene foam highly depend on the experimental fabrication conditions during the chemical vapor deposition process. Aiming to reveal how to prepare the appropriate graphene foam for the various thermal management scenarios, the influence of experimental conditions on thermal properties of graphene foam was investigated. Furthermore, the contribution of thermal conductivity and thermal radiation to the effective thermal coefficient of graphene foam was carried out for comparison. The research results showed that the porosity and the cross-section shape of the struts of the growth template were two critical factors affecting the thermal transport of graphene foam, especially with the increase of temperature. In addition, the deposition time of graphene determined the wall thickness and affected the thermal conductivity directly. The thermal radiation contributed more than thermal conductivity when the temperature climbed continuously. Comparatively, the effective thermal coefficient of graphene foam composite with high porosity and circular-shape struts was much superior to that of others at high temperature. The research findings provide important guidance for graphene foam fabrication and its applications in the field of thermal management. Full article

The significance of rheology in the context of bio three-dimensional (3D) printing lies in its impact on the printing behavior, which shapes material flow and the layer-by-layer stacking process. The objective of this study is to evaluate the rheological and printing behaviors of polycaprolactone (PCL) and dimethyl sulfone (DMSO₂) composites. The rheological properties were examined using a rotational rheometer, employing a frequency sweep test. Simultaneously, the printing behavior was investigated using a material extrusion 3D printer, encompassing varying printing temperatures and pressures. Across the temperature range of 120–140 °C, both PCL and PCL/DMSO₂ composites demonstrated liquid-like behavior, with a higher loss modulus than storage modulus. This behavior exhibited shear-thinning characteristics. The addition of DMSO₂ 10, 20, and 30 wt% into the PCL matrix reduced a zero-shear viscosity of 33, 46, and 74% compared to PCL, respectively. The materials exhibited extrusion velocities spanning from 0.0850 to 6.58 mm/s, with velocity being governed by the reciprocal of viscosity. A significant alteration in viscosity by temperature change directly led to a pronounced fluctuation in extrusion velocity. Extrusion velocities below 0.21 mm/s led to the production of unstable printed lines. The presence of distinct viscosities altered extrusion velocity, flow rate, and strut diameter. This phenomenon allowed the categorization of pore shape into three zones: irregular, normal, and no-pore zones. It underscored the importance of comprehending the rheological aspects of biomaterials in enhancing the overall quality of bio-scaffolds during the 3D printing process. Full article

This study investigates the effect of scaffold architecture on bone regeneration, focusing on 3D-printed polylactic acid–bioceramic calcium phosphate (PLA-bioCaP) composite scaffolds in rabbit femoral condyle critical defects. We explored two distinct scaffold designs to assess their influence on bone healing and scaffold performance. Structures with alternate (0°/90°) and helical (0°/45°/90°/135°/180°) laydown patterns were manufactured with a 3D printer using a fused deposition modeling technique. The scaffolds were meticulously characterized for pore size, strut thickness, porosity, pore accessibility, and mechanical properties. The in vivo efficacy of these scaffolds was evaluated using a femoral condyle critical defect model in eight skeletally mature New Zealand White rabbits. Then, the results were analyzed micro-tomographically, histologically, and histomorphometrically. Our findings indicate that both scaffold architectures are biocompatible and support bone formation. The helical scaffolds, characterized by larger pore sizes and higher porosity, demonstrated significantly greater bone regeneration than the alternate structures. However, their lower mechanical strength presented limitations for use in load-bearing sites. Full article

The choice of material, manufacturing process, and molding tool significantly affects the quality, environmental impact, and cost efficiency of composite components. Producing one-piece hollow profiles with smooth inner surfaces and undercuts presents major challenges for conventional mold concepts. There is yet no thorough review of shape-variable mandrels in composite manufacturing to be found in the literature. This paper provides an overview of research on shape memory polymers and other shape-variable materials used in tooling applications for composite manufacturing. This work covers shape memory, heat shrink, and other deformable tooling concepts that enable the production of one-piece Type V pressure vessels, air intake ducts, or curved struts and tubes. A systematic literature review in combination with a state-of-the-art open-source active learning tool ASReview is conducted. Fifteen relevant studies were identified. Research on shape-variable tooling is mainly conducted by three research groups in the USA and the PRC. The tooling is mostly made of unreinforced thermosets, especially styrene-based ones. Thermoplastic resins are less common, and reinforcements limit the usable elongation in the temporary shape. The shape variability is either a shape memory and/or a softening process, which, in all studies, is activated by heating. Release agents are widely used to ease demolding. No ecological or economical assessment of the manufacturing methods was conducted in the reviewed studies. Three fields for further research that could be identified are as follows: (1) thorough ecological end economical assessment of shape-variable mandrels in comparison with conventional tooling; (2) thermoplastic shape memory polymer mandrels; and (3) further investigation of simulation capabilities for shape memory mandrels. Full article

This paper optimizes the design of a novel large-span cable-supported steel–concrete composite floor system in a simply supported single-span, single-strut configuration, aiming for cost-effective solutions and minimal steel consumption. The optimization considers various cross-sectional dimensions, adhering to building standards and engineering practices, and is based on a non-linear programming (NLP) algorithm. Parameters of live loads ranging from 2 to 10 kN/m² and spans from 20 to 100 m are considered. The optimization results show that cable-supported composite floors with a single strut exhibit robust economic feasibility for spans of less than 80 m and live loads under 8 kN/m². Compared to conventional composite floors with welded I-beams, the cable-supported system offers more cost-effective cross-sections and reduces steel consumption. The savings in economically equivalent steel consumption range from 20% to 60%. Discussion on the area ratio of cables to steel beam in the optimal cross-section reveals that the secondary load-bearing system (i.e., bending of the main beam with an effective span length of L/2) may require more steel in cases of ultra-large spans. Therefore, the economical efficiency of cable-supported composite beams with multiple struts and smaller effective span lengths warrants further exploration in future studies. Full article
