Robotic-assisted therapy is an increasingly vital approach for upper-limb rehabilitation, offering consistent, high-intensity training critical to neuroplastic recovery. However, current control strategies often lack robustness against uncertainties and external disturbances, limiting their efficacy in dynamic, real-world settings. Addressing this gap, this study proposes a novel control framework for the iTbot—a 2-DoF end-effector rehabilitation robot—by integrating differential flatness theory with a derivative-free Kalman filter (DFK). The objective is to achieve accurate and adaptive trajectory tracking in the presence of unmeasured dynamics and human–robot interaction forces. The control design reformulates the nonlinear joint-space dynamics into a 0-flat canonical form, enabling real-time computation of feedforward control laws based solely on flat outputs and their derivatives. Simultaneously, the DFK-based observer estimates external perturbations and unmeasured states without requiring derivative calculations, allowing for online disturbance compensation. Extensive simulations across nominal and disturbed conditions demonstrate that the proposed controller significantly outperforms conventional flatness-based control in tracking accuracy and robustness, as measured by reduced mean absolute error and standard deviation. Experimental validation under both simple and repetitive physiotherapy tasks confirms the system’s ability to maintain sub-millimeter Cartesian accuracy and sub-degree joint errors even amid dynamic perturbations. These results underscore the controller’s effectiveness in enabling compliant, safe, and disturbance-resilient rehabilitation, paving the way for broader deployment of robotic therapy in clinical and home-based environments. Full article

To minimize mechanical damage caused by an apple picking robot end-effector during the apple grasping process, and on the basis of optimizing the minimum stable grasping force of apple, a variable impedance control strategy based on a reinforcement learning deep deterministic policy gradient (DDPG) algorithm is proposed to achieve compliant grasping control for apples. Firstly, according to the apple contact force model, the gradient flow algorithm is adopted to optimize grasping force in terms of the friction cone, force balancing condition, and stability assessment index and to obtain a minimum stable grasping force for apples. Secondly, based on the analysis of the influence of impedance parameters on the control system, a variable impedance control based on the DDPG algorithm is designed, with the reward function adopted so as to improve the control performance. Then, the improved control strategy is used to train the optimized impedance control. Finally, simulation and experimental results indicate that the proposed variable impedance control outperforms the traditional impedance control by reducing the peak grasping force from 4.49 N to 4.18 N while achieving a 0.6 s faster adjustment time and a 0.24 N narrower grasping force fluctuation range. The improved impedance control successfully tracks desired grasping forces for apples of varying sizes and significantly reduces mechanical damage during apple harvesting. Full article

In circular production lines, issues such as positional errors, manufacturing errors at different square groove workstations, and the accumulation of errors during continuous assembly reduce the assembly success rate and limit efficiency. To address these challenges in assembling square groove parts, this study focuses on the jamming and wedging problems encountered during the assembly of square grooves and square parts. It analyzes typical assembly hole searching contact situations and proposes corresponding strategies. Based on the relative geometric relationships between the assembly workpieces, the entire assembly process is divided into three stages: pre-assembly, hole search contact adjustment, and insertion. Due to the complexity of predicting assembly forces and the uncertainty of workstation assembly in circular production lines, this study emphasizes the hole search contact adjustment stage. An innovative vertical hole search strategy is proposed and compared with the Archimedes spiral search method. This strategy models the contact between the end effector and the environment as a mass–damping–spring second-order system, achieving compliant assembly of square holes through admittance control. By analyzing the admittance parameters using control variables, the optimal admittance parameters are determined, and the admittance parameter pattern is applied in the experiments. Experimental results on the square hole assembly platform show that, under the optimal admittance parameters, the vertical hole search strategy significantly reduces search time and improves efficiency. Compared to the traditional Archimedes spiral hole search strategy, the average search adjustment time was increased by 5.8 s, improving efficiency by 46.4%, and the desired assembly outcomes were achieved. Full article

This paper addresses the problems of valve-turning operation in rescue environments where a wheeled mobile manipulator (WMM) is employed, including the possible occurrence of large internal forces. Rather than attempting to obtain the exact position of the valve, this paper presents a solution to two main problems in robotic valve-turning operations: the radial position deviation between the rotation axes of the tool and the valve handle, which may cause large radial forces, and the possible axial displacement of the valve handle as the valve turns, which may lead to large axial forces. For the former problem, we designed a compliant end-effector with a tolerance of approximately 3.5° (angle) and 9.7 mm (position), and provided a hybrid passive/active compliance method. For the latter problem, a passivity-based force tracking algorithm was employed. Combining the custom-built compliant end-effector and the passivity-based control method can significantly reduce both the radial and the axial forces. Additionally, for valves with different installation types and WMMs with different configurations, we analyzed the minimum required number of actuators for valve turning. Simulation and experimental results are presented to show the effectiveness of the proposed approach. Full article

Soft grippers, a rapidly growing subfield of soft robotics, utilize compliant and flexible materials capable of conforming to various shapes. This feature enables them to exert gentle yet, if required, strong gripping forces. In this study, we elaborate on the material selection and fabrication process of gripping fingers based on the dielectric elastomer actuation technique. We study the effects of mixing the silicone elastomer with a silicone thinner on the performance of the actuators. Inspired by nature, where the motion of end-effectors such as soft limbs or fingers is, in many cases, directed by a stiff skeleton, we utilize backbones for translating the planar actuation into a bending motion. Thus, the finger does not need any rigid frame or pre-stretch, as in many other DEA approaches. The idea and function of the backbone strategy are demonstrated by finite element method simulations with COMSOL Multiphysics^® 6.5. The paper describes the full methodology from material choice and characterization, design, and simulation to characterization to enable future developments based on our approach. Finally, we present the performance of these actuators in a gripper demonstrator setup. The developed actuators bend up to 68.3° against gravity, and the gripper fingers hold up to 10.3 g against gravity under an actuation voltage of 8 kV. Full article

When addressing the technical challenges of achieving precise force tracking during the local polishing process of polishing robots, controlling the contact state between the robot and the workpiece surface is essential. To this end, a contact motion-planning strategy based on dynamic systems is designed to generate trajectory routes during local polishing. The trajectory simulation of the local modulation dynamic system is achieved through the employment of the support vector regression (SVR) algorithm with a Gaussian kernel, facilitating the learning process. The feasibility and stability of planning local paths are validated using the local modulation dynamic system. To maintain a constant contact force between the end-effector polishing robot and the workpiece, an integral adaptive impedance control strategy is utilized, enabling the robot’s compliant control. Subsequently, an experimental system for the polishing robot is constructed in order to verify the effectiveness of the motion-planning system. The experimental results demonstrate that the proposed motion-planning approach is applicable in practical polishing processes, ensuring smooth contact and maintaining the desired contact force when scanning nonlinear surfaces, and thus showcasing stability and practicality. Full article

Since robotic arms operating close to people are becoming increasingly common, there is a need to better understand how they can be made safe when unintended contact occurs, while still providing the required performance. Several actuators and methods for improving robot safety are studied and compared in this paper. A robotic arm moving its end effector horizontally and colliding with a person’s head is simulated. The use of a conventional electric actuator (CEA), series elastic actuator (SEA), pneumatic actuator (PA) and hybrid pneumatic electric actuator (HPEA) with model-based controllers are studied. The addition of a compliant covering to the arm and the use of collision detection and reaction strategies are also studied. The simulations include sensor noise and modeling error to improve their realism. A systematic method for tuning the controllers fairly is proposed. The motion control performance and safety of the robot are quantified using root mean square error (RMSE) between the desired and actual joint angle trajectories and maximum impact force (MIF), respectively. The results show that the RMSE values are similar when the CEA, SEA, and HPEA drive the robot’s first joint. Regarding safety, using the PA or HPEA with a compliant covering can reduce the MIF below the safety limit established by the International Organization for Standardization (ISO). To satisfy this ISO safety limit with the CEA and SEA, a collision detection and reaction strategy must be used in addition to the compliant covering. The influences of the compliant covering’s stiffness and the detection delay are also studied. Full article

Without mechanical compliance robots rely on controlled environments and precision equipment to avoid clashes and large contact forces when interacting with an external workpiece, e.g., a peg-in-hole (PiH) task. In such cases, passive compliance devices are used to reduce the insertion force (and in turn the robot payload) while guiding corrective motions. Previous studies in this field are limited to small misalignments and basic PiH geometries inapplicable to prevalent robotic and autonomous systems (RASs). In addition to these issues, our work argues that there is a lack of a unified approach to the development of passive compliance systems. To this end, we propose a higher-level design approach using robust engineering design (RED) methods. In a case study, we demonstrated this general approach with a Taguchi design framework, developing a remote centre compliant (RCC) end-effector for robotic train fluid servicing. For this specific problem, a pseudo-rigid-body model (PRBM) is suggested in order to save enormous computation time in design, modelling, and optimisation. Our results show that the compliant end-effector is capable of significantly reducing the insertion force for large misalignments up to 15 mm and 6 degrees. Full article

In order to enhance the automation level and achieve high precision in the ultrasonic strengthening of aviation blade surfaces, this study focuses on investigating the intelligent control strategy and optimizing the machining parameters for robotic ultrasonic surface strengthening. By designing an intelligent compliance control method, the end-effector can achieve the compliant output of contact force. The fuzzy PID control method is used to optimize the regulation performance of the compliant force control system. This compliance control strategy enables the optimization of the compliance device, effectively improving the static and dynamic characteristics of the compliance controller. Based on this, an experimental method (RSM) is designed to analyze the interaction effects of contact force, feed rate, and repetition times on the surface quality of the blade. The optimal combination of robotic strengthening parameters is determined, providing a practical reference for the application of robotic compliance control in the ultrasonic strengthening of aviation blade surfaces. Full article

In this paper, the problem of making a safe compliant contact between a human and an assistive robot is considered. Users with disabilities have a need to utilize their assistive robots for physical human–robot interaction (PHRI) during certain activities of daily living (ADLs). Specifically, we propose a hybrid force/velocity/attitude control for a PHRI system based on measurements from a six-axis force/torque sensor mounted on the robot wrist. While automatically aligning the end-effector surface with the unknown environmental (human) surface, a desired commanded force is applied in the normal direction while following desired velocity commands in the tangential directions. A Lyapunov-based stability analysis is provided to prove both the convergence as well as passivity of the interaction to ensure both performance and safety. Simulation as well as experimental results verify the performance and robustness of the proposed hybrid controller in the presence of dynamic uncertainties as well as safe physical human–robot interactions for a kinematically redundant robotic manipulator. Full article

In order to satisfy the requirement of the automatic ultrasonic strengthening of an aviation blade surface, this paper puts forward a robotic compliance control strategy of contact force for ultrasonic surface strengthening. By building the force/position control method for robotic ultrasonic surface strengthening., the compliant output of the contact force is achieved by using the robot’s end-effector (compliant force control device). Based on the control model of the end-effector obtained from experimental determination, a fuzzy neural network PID control is used to optimize the compliance control system, which improves the adjustment accuracy and tracking performance of the system. An experimental platform is built to verify the effectiveness and feasibility of the compliance control strategy for the robotic ultrasonic strengthening of an aviation blade surface. The results demonstrate that the proposed method maintains the compliant contact between the ultrasonic strengthening tool and the blade surface under multi-impact and vibration conditions. Full article

This paper presents a universal approach to shaping the mechanical properties of the interaction between a collaborative robot and its environment through an end-effector Cartesian compliance shaping. More specifically, the focus is on the class of kinematically redundant robots, for which a novel redundancy reconfiguration scheme for online optimization of the Cartesian compliance of the end-effector is presented. The null-space reconfiguration aims to enable the more efficient and versatile use of collaborative robots, including robots with passive compliant joints. The proposed approach is model-based and gradient-based to enable real-time computation and reconfiguration of the robot for Cartesian compliance while ensuring accurate position tracking. The optimization algorithm combines two coordinate frames: the global (world) coordinate frame commonly used for end-effector trajectory tracking; and the coordinate frame fixed to the end-effector in which optimization is computed. Another attractive feature of the approach is the bound on the magnitude of the interaction force in contact tasks. The results are validated on a torque-controlled 7-DOF KUKA LWR robot emulating joint compliance in a quasi-static experiment (the robot exerts a force on an external object) and a peg-in-hole experiment emulating an assembly task. Full article

The contact force between the polishing tool and the workpiece is crucial in determining the surface quality in robotic polishing. Different from rigid end-effectors, this paper presents a novel compliant end-effector (CEE) for robotic polishing using flexible beams. The flexibility of the CEE helps to suppress the excessive displacement caused by the inertia of the polishing robot and avoids damaging the polishing tool and workpiece surface. In addition, the contact force can also be precisely estimated via the measurement of the CEE’s displacement using a capacitive position sensor. The design, modeling and experimental validation of the CEE are presented. Firstly, the analytical model of the CEE is established using the stiffness matrix method. Subsequently, the analytical model is verified by finite element analysis. Further, a prototype is manufactured, and its characteristics and performance are experimentally tested. The equivalent stiffness is measured to be 0.335 N/μm, and the first natural frequency along its working direction is 42.1 Hz. Finally, the contact force measurement using the CEE is compared with a force sensor. Under open-loop condition, the resolution of the contact force measurement is found to be 0.025 N, which makes the fine tuning of the contact force possible in robotic polishing. Full article

Composite structures in aeroplanes are often thin-walled and lightweight, resulting in significant compliance, which presents a handling and assembly challenge due to the associated part deformations. In order to counteract these deformations, the parts are held in their specified geometry using stiff and correspondingly heavy fixtures or jigs. Mobile industrial robots are very versatile and widely used in industrial volume production, but they are limited in their payload capacity. High-rate production of large aerospace modules requires highly automated flexible assembly processes. The approach presented in this paper is to combine mobile units with lightweight assembly jigs that have the capability of deformation compensation. The subject of the study is a high-rate assembly process for flap modules using an Autonomous Industrial Mobile Manipulator (AIMM) and a lightweight end effector. The end effector has a shape compensation function, implemented by an integrated Stewart platform, which enables the compensation of manufacturing tolerances as well as gravity effects. The compensation function is used in a closed loop and counteracts shape deviations by appropriate fixture shape adjustments. The paper reports on the conceptual design of the assembly scenario, the design of the end effector, its realization and the successful experimental demonstration at 1:1 scale. Full article

A nonlinear stiffness actuator (NSA) can achieve high torque/force resolution in the low stiffness range and high bandwidth in the high stiffness range. However, for the NSA, due to the imperfect performance of the elastic mechanical component such as friction, hysteresis, and unmeasurable energy consumption caused by former factors, it is more difficult to achieve accurate position control compared to the rigid actuator. Moreover, for a compliant robot with multiple degree of freedoms (DOFs) driven by NSAs, the influence of every NSA on the trajectory of the end effector is different and even coupled. Therefore, it is a challenge to implement precise trajectory control on a robot driven by such NSAs. In this paper, a control algorithm based on the Terminal Sliding Mode (TSM) approach is proposed to control the end effector trajectory of the compliant robot with multiple DOFs driven by NSAs. This control algorithm reduces the coupling of the driving torque, and mitigates the influence of parametric variation. The closed-loop system’s finite time convergence and stability are mathematically established via the Lyapunov stability theory. Moreover, under the same experimental conditions, by the comparison between the Proportion Differentiation (PD) controller and the controller using TSM method, the algorithm’s efficacy is experimentally verified on the developed compliant robot. The results show that the trajectory tracking is more accurate for the controller using the TSM method compared to the PD controller. Full article
