Search Results (895)

High-power-density LEDs can achieve many functions that are difficult for traditional light sources and conventional LEDs to realize, pushing the semiconductor lighting technology chain to a new level. Increasing the number of chips is an effective approach to improving the light output capability of LED devices. In this study, five high-power-density LED devices with different chip numbers (4, 9, 16, 25, and 64 chips) were fabricated using the same blue LED chips, and the effects of chip number on the light output capability, spatial light distribution characteristics, and spatially correlated color temperature distribution characteristics of high-power-density LED devices were systematically investigated. The temperature distribution characteristics of the internal chips were further analyzed in combination with infrared thermal imaging results. The results show that increasing the chip number significantly enhances the total light output capability of the device; however, due to the influence of thermal coupling among chips, the saturation current and saturated luminous intensity of devices with different chip numbers are not proportional to the chip number. Increasing the number of chips in the device does not alter the intrinsic spatial emission pattern. Under optical saturation conditions, the luminous intensity distribution curves of all five devices exhibit Lambertian spatial light distribution characteristics. In terms of correlated color temperature, the CCT of all devices increases with increasing current per chip, and devices with more chips exhibit higher CCT values and a faster increasing trend. The spatial CCT distribution results show that the correlated color temperature of the device reaches its maximum in the normal direction, decreases with increasing testing angle, and exhibits good spatial symmetry. The thermal imaging results show that devices with more chips exhibit higher average chip temperatures and a relatively more uniform temperature distribution, which improves the spatial CCT uniformity of the device to some extent. Full article

Droplet microfluidics has been widely used in biological, chemical, and medical research owing to its advantages of miniaturization, high throughput, and low reagent consumption. However, limited sensitivity and optical path length in on-chip absorbance detection remain major challenges for droplet-based microfluidic analysis. Traditional absorbance detection suffers from low sensitivity due to the extremely short optical path in microfluidic channels, while existing optical path extension methods have drawbacks such as complex fabrication, easy droplet rupture, or strict incident angle requirements. To address these issues, this study developed a droplet microfluidic absorbance detection platform integrating optical fibers, on-chip micromirrors, external fluidic actuation, and an absorbance detection module. Microchannel sidewalls filled with low-melting-point metal act as mirrors; the multi-reflection optical path, combined with optical fibers and micromirrors, compensates for insufficient light manipulation and effectively extends the absorption path length, improving sensitivity and accuracy. Using this method, the detection limit for methylene blue solution was 20 μM, and the sensitivity for Escherichia coli (E. coli) suspension was doubled compared with traditional Nanodrop OD600 measurement. This device features low fabrication difficulty and cost and stable detection, providing a proof-of-concept strategy for enhanced absorbance detection in droplet microfluidic systems. Full article

Optical coherence tomography (OCT) is a non-invasive, high-resolution imaging technique widely used in medical diagnosis, biomedical research and other fields. It plays an important role in the early detection and accurate diagnosis of diseases. The superluminescent light-emitting diode (SLED) is the ideal light source for OCT systems, where the stability of its drive current and operating temperature directly determines the imaging quality of OCT. Existing driving and temperature control schemes for similar light sources predominantly rely on microcontrollers or field programmable gate arrays (FPGAs), a reliance which often results in complex system architectures and difficulties in balancing simplicity with control precision. To address these issues, a stable and compact SLED source driver module designed for OCT was developed in this study, integrating both a constant-current drive circuit and a temperature control circuit. The negative feedback control and improved current-limiting protection are employed in the constant-current drive circuit to maintain stable SLED operation and reduce the circuit footprint. A miniature dedicated temperature control chip is adopted in the temperature control circuit. The operating temperature of the SLED is acquired by linearizing the negative temperature coefficient (NTC) thermistor value and regulated through a proportional-integral-derivative (PID) compensation circuit. The size of the fabricated module (including casing) is less than 10 × 8 × 3 cm³. Experimental results show that the driver module achieves a drive current control accuracy of 0.1% and a temperature control accuracy of 0.01 °C. The output optical power fluctuation is less than 0.005 mW and the average axial resolution for OCT is 6.5992 μm with a standard deviation of 0.0107 μm. This light source driver module successfully balances control precision with structural simplicity, demonstrating excellent applicability in OCT systems. Full article

The on-chip detection of circularly polarized light is pivotal for advancing applications in quantum optics, information processing, and spectroscopic sensing. However, conventional chiral metasurfaces often suffer from complex multilayer fabrication, material incompatibility, or modest performance, hindering their integration with photonic circuits. Here, we introduce a monolithic all-silicon metasurface that overcomes these limitations through a singular structural innovation. By strategically truncating four corners of a conventional Z-shaped meta-atom, we induce a hybridization of optical modes that profoundly enhances chiral light–matter interaction. This deliberately engineered perturbation yields a colossal circular dichroism with an extinction ratio exceeding 66 dB, a performance that surpasses existing state-of-the-art designs by approximately three orders of magnitude. Furthermore, the proposed metasurface exhibits remarkable fabrication robustness, owing to its single-layer architecture and CMOS-compatible material. We demonstrate that this exceptional metasurface can be directly integrated with a Mercury Cadmium Telluride (MCT) photodetector to form a highly efficient, compact circular polarization detector. Our work provides a simple yet powerful paradigm for creating high-performance chiral photonic devices, paving the way for their widespread adoption in integrated optoelectronics. Full article

Chiral bound states in the continuum (BIC) metasurfaces have emerged as a promising platform for enhancing light–matter interactions, which have potential applications in advanced photonic and quantum information devices. However, simultaneously achieving near-perfect circular dichroism and highly efficient nonlinear conversion with highly symmetric structures in metasurfaces remains an open challenge. In this work, we design a $C_4$-symmetric chiral metasurface composed of eight elliptical silicon nanorods on a ${\mathrm{SiO}}_2$ substrate, where monocrystalline silicon is used as the nonlinear optical material. By combining simulations and nonlinear time-domain coupled-mode theory (TCMT), we discovered that both the optimal chirality and the nonlinear conversion efficiency can be attained simultaneously due to the critical coupling between the metasurface mode and the quasi-BIC mode. Meanwhile, a near-perfect circular dichroism (CD = 0.99) and a high nonlinear conversion efficiency of $7\times {10}^{-5}$ under a radiation intensity of $5{\mathrm{kW}/\mathrm{cm}}^2$ are numerically achieved due to the robustness of bound states in the continuum. This work offers a promising route toward high-performance chiral nonlinear photonic components, which is of great importance for the development of ultra-compact optical devices such as circular polarization detectors, chiral sensors, and nonlinear photonic chips for integrated optical and quantum information systems. Our research not only contributes to the fundamental understanding of chiral metasurfaces but also provides a practical approach for achieving high-efficiency nonlinear optical devices. Full article

Diabetic retinopathy (DR) is more than a capillary disorder. Diabetes affects neurons, glial cells, vascular cells, and immune signals within the retinal neurovascular unit (NVU). Retinal neurovascular coupling (NVC) is a useful functional marker of NVU integrity because it reflects the rise in local blood flow that follows neural activity. Many human flicker-light studies report smaller vessel dilation or weaker flow responses in diabetes. This finding can appear even in patients without clear fundus lesions. When NVC is reduced, retinal tissue may receive less oxygen. Lower oxygen delivery can raise oxidative stress and promote inflammation. These changes can then worsen vascular injury. This review describes key NVC pathways and diabetes-related NVU changes in Müller glia, astrocytes, microglia, pericytes, and endothelial cells. The review highlights sympathetic activation as a common stress signal. Pain, anxiety, perioperative stress, and sleep loss can increase sympathetic activity and circulating catecholamines. In the diabetic retina, vascular reserve is often limited. Under these conditions, catecholamines can increase mural cell constriction, reduce nitric oxide (NO)-dependent relaxation, and increase endothelial activation and barrier strain. These effects can shift the baseline state of glial and immune cells and further weaken NVC. The review also summarizes translational tools that can test these links. These tools include heart rate variability, standardized NVC protocols with diameter and flow measures, and retinal organoid and organ-on-a-chip platforms with controlled adrenergic exposure. The review discusses perioperative care packages that reduce stress responses, protect sleep, and manage glucose as practical ways to support retinal microcirculation. More longitudinal human studies are still needed. Retina-specific perioperative endpoints are also needed to clarify causality and to guide intervention trials. Full article

Photonic crystal waveguides (PhCWs) have emerged as a leading platform for integrated optical sensing due to their ability to engineer dispersion, enhance light–matter interaction, and exploit slow-light effects. This review provides a comprehensive analysis of the fundamental physics, performance metrics, device architectures, and application domains that define the current state of PhCW-based sensing. Key mechanisms governing sensitivity, figure of merit, detection limit, and dynamic range are examined, with emphasis on the intrinsic trade-offs introduced by slow-light operation, including disorder-induced scattering, linewidth broadening, and thermal susceptibility. Advances in dispersion engineering, such as hole shifting, gentle confinement, and width modulation, are highlighted alongside novel architectures including slot PhCWs, hybrid material platforms, and plasmonic–photonic configurations. Their respective capabilities in enhancing analyte overlap, improving spectral stability, and expanding functional integration are critically assessed. Emerging applications in biochemical detection, environmental monitoring, and nanoscale particle sensing further illustrate the versatility of PhCWs within modern optofluidic and lab-on-chip systems. The review concludes by outlining key challenges and future directions, including disorder-resilient slow-light design, inverse-engineered structures, and platform-level integration, which collectively chart a path toward next-generation high-performance photonic crystal sensing technologies. Full article

Serial flow cytometry was recently introduced as a method that can estimate measurement uncertainty (i.e., imprecision, the coefficient of variation of repeated measurements of individual particles) independent from population characteristics. Replication of light sources and detectors at multiple sites along a flow cytometer’s microchannel requires more equipment and can complicate detector synchronization. Here, we introduce amplitude modulation to encode each region of a serial cytometer with a unique carrier frequency, which enables demultiplexing of the combined signal incident on a single photodetector by fast Fourier transform (FFT) peak magnitude. To facilitate validation of detection, matching, and uncertainty quantification of fluorescence signals, we designed a microfluidic amplitude modulation (AM) serial flow cytometer that has ground truth detectors on individual regions (serial cytometry) in parallel with the combined channel detection for AM demultiplexing. With this report, we present metrics for event detection and dynamic range, prevalence and processing of overlapping detections, region-decoding accuracy, process yield, and uncertainty quantification on a brightness ladder of calibration microspheres. Despite being operated with reduced light intensities, the AM cytometer was capable of high-fidelity performance in comparison to conventional serial cytometry. For events above the detection limit, over 97% were analyzed. Both conventional and AM serial cytometers achieved median imprecisions in the range of 0.53% to 2.1% after outlier removal, which was well below the inherent intensity distribution of any of the microsphere subpopulations. Overall, AM cytometry supports uncertainty quantification and temporal analyses of serial cytometry data with a reduced number of photodetectors, which offers simplification of chip design with multiple measurement regions and wide-field detectors. Full article

The significant disparity between the size and electronegativity of N and group-V (P, As, Sb) atoms in dilute III–V-Ns remains a cornerstone for developing the next-generation electronics. Variations in the structural, optical, and phonon properties of the quaternary GaAs_1−x−ySb_yN_x alloys are being used for improving the high-performance photovoltaic energy and optoelectronic technologies. Bandgap ${\mathrm{E}}_{\mathrm{g}}$ tunability has assisted efficient light emission/detection to cover the crucial optical fiber wavelengths for the low-cost integrated chips in data communications and sensing devices. The lattice dynamical properties of these materials are critical for assessing the reliability to evaluate the performance of long-wavelength lasers, photodetectors, and multi-junction solar cells. Our systematic Raman measurements on high-quality MBE grown $\mathrm{G}\mathrm{a}{\mathrm{A}\mathrm{s}}_{0.946}{\mathrm{S}\mathrm{b}}_{0.032}{\mathrm{N}}_{0.022}$/GaAs samples have detected ${\mathsf{\omega }}_{\mathrm{T}\mathrm{O}\left(\mathsf{\Gamma }\right)}^{\mathrm{G}\mathrm{a}\mathrm{A}\mathrm{s}}$ and ${\mathsf{\omega }}_{\mathrm{T}\mathrm{O}\left(\mathsf{\Gamma }\right)}^{\mathrm{G}\mathrm{a}\mathrm{A}\mathrm{s}}$ phonons along with a high frequency N_As local mode near ~476 cm⁻¹. Weak phonon structures on both sides of the broad 476 cm⁻¹ band are interpreted forming a complex N_As–Ga–Sb_As defect center. Using a realistic rigid-ion model in the Green’s function framework, the simulations of impurity modes for isolated and complex defects have provided corroboration to the experimental data. Full article

Lensless on-chip microscopy enables high-throughput, wide-FOV imaging; however, the Bayer color filter array (CFA) in standard color sensors spatially multiplexes spectral channels, introducing sub-sampling and spectral crosstalk that degrade phase retrieval. We propose a Wirtinger Poly-Gradient Solver (WPGS) for quantitative phase reconstruction with Bayer-filtered color sensors under sequential Red–Green–Blue Light-Emitting Diode (RGB-LED) illumination. The method combines Transport of Intensity Equation (TIE)-based initialization with polychromatic Wirtinger optimization to suppress CFA-induced artifacts and enable pixel super-resolution (PSR). Experiments resolve a $2.76 \mu \mathrm{m}$ linewidth using a $1.85 \mu \mathrm{m}$ pixel-pitch sensor, exceeding the nominal Nyquist limit imposed by pixel sampling. We further demonstrate label-free imaging of HeLa cells and unstained tissue sections, supporting high-throughput digital pathology and offering potential for longitudinal biological observation. Full article

Spectrometers are essential tools for revealing the interaction between light and matter and analyzing the composition and state of materials, widely employed in scientific research, industrial inspection, and biomedicine applications. With the continuous expansion of application scenarios, higher demands are placed on the miniaturization, integration, and portability of spectrometers. This paper proposes and implements a reconfigurable silicon photonic on-chip spectrometer based on cascaded multi-stage Mach–Zehnder interferometers (MZIs). This structure achieves efficient sampling of the input spectrum by applying adjustable phase shifts to each MZI stage to construct different spectral responses. Combined with a convex optimization algorithm incorporating differential operators, the unknown input signals are decomposed into sparse and smooth components, achieving high-accuracy reconstruction. Experimental results show that the proposed five-stage MZI design with a total of 216 sampling channels achieves a spectral reconstruction resolution of 5 pm over the wavelength range from 1500 nm to 1600 nm. Moreover, the spectrometer exhibits consistently low reconstruction errors for broadband spectra, sparse spectra, and their hybrid spectral profiles. This research demonstrates excellent comprehensive performances in device structure design, phase modulation strategy, and reconstruction algorithm, providing an effective solution for realizing low-power, small-footprint, and high-precision on-chip spectral analysis. Full article

The inherently high-voltage-length product (V_πL) of thin-film lithium niobate (TFLN) modulators in the O-, C-, and L-telecom bands restricts further scaling of photonic integrated circuits’ bandwidth density, driving their migration toward shorter operating wavelengths. Nevertheless, the corresponding grating couplers, as critical optical input/outputs (optical I/Os) interfaces, remain largely undeveloped. Here, we demonstrate an 850 nm TFLN grating coupler designed based on topological unidirectional guided resonance (UGR). By breaking C₂ symmetry of the unit cell and precisely tailoring its geometry, we achieve unidirectional upward radiation with a 63.7 dB up/down intensity ratio. Subsequent apodization of groove widths and periods enables precise control of the electrical field distribution in both real and momentum spaces. This yields a vertical-cavity surface-emitting laser (VCSEL)-matched, highly fabrication-tolerant TFLN grating coupler that attains, to the best of our knowledge, the highest simulated coupling efficiency of −0.6 dB without mirrors or hybrid materials. This work delivers a high-efficiency, layout-flexible, and complementary metal oxide semiconductor (CMOS)-compatible optical I/Os solution for short-wavelength TFLN modulators with low V_πL. It offers substantial engineering value and broad applicability for on-chip light source integration and high-bandwidth-density short-reach optical interconnects. Full article

Carpinus betulus is an important ornamental landscape tree species with colorful foliage. It is widely used in landscaping due to its upright tree shape, significant seasonal changes, and good tolerance to pruning. Propagation methods for C. betulus include grafting, cutting, and seeding. However, the germination rate of seeding is low, and the rooting of cuttings is difficult; moreover, plant tissue culture techniques are complex, and the key technologies have not been disclosed. Grafting has therefore become the primary means of propagation. However, enabling the rapid reproduction of C. betulus through appropriate grafting methods and in appropriate environments remains an urgent issue to be addressed. In this study, Carpinus turczaninowii was used as a rootstock to graft C. betulus, and the effects of the grafting periods, technique, and environmental conditions on the survival rate of grafted C. betulus were discussed. The results showed that branch grafting (cleft graft and whip-and-tongue graft) performed in March to April and August to November resulted in the highest survival rates, whereas budding grafts (chip budding and patch budding) were more suitable in May and June. Increasing ambient humidity was a key measure for improving graft survival rates and germination rates. In terms of grafting survival rate, germination rate, and leaf growth, humidification and treatment with 60–70% light transmission had better results than treatment with natural humidity or 20–30% light transmission and full light treatment under humidification conditions. Under low-light conditions, increasing air humidity had a particularly pronounced effect on promoting the growth of grafted seedling branches. In the future, further research should be conducted on the molecular mechanism mediated by soil environment and temperature changes for the successful grafting of C. betulus, providing a theoretical basis for the propagation and cultivation of C. betulus. Full article

With the widespread application of high-power thick-film-substrate light-emitting diode (LED) packages, the performance of high-power LED modules has been continuously improved, making thermal management an increasingly critical issue. To enhance the heat dissipation performance of LED modules, this study investigates the effects of different heat dissipation structures on the temperature field using a finite element-based thermal simulation method, based on the thermal management enhancement characteristics of the LED. A thermal simulation model of the LED was established, and the thermal characteristics and temperature field characterization of its components were analyzed. Our results revealed significant temperature differences at various positions of the LED, particularly near the bottom surface of the heat sink and the contact surface with the LED chips, where the heat flux density exhibited notable variations. Properly adjusting the spacing between LEDs effectively reduced the maximum temperature of the module, with the optimal spacing determined to be approximately 19 mm. To further improve heat dissipation, pin-fin arrays were added to the heat sink, leading to a reduction of 8.79 K in the maximum temperature and 9.67 K in the minimum temperature of the LED module, which significantly enhanced the heat dissipation performance. The optimization measures effectively improved the temperature field characterization of the LED, contributing to enhanced performance and an extended lifespan of the LED module. Full article

Although the polarization state, as a key physical dimension of light, plays an irreplaceable role in many frontier fields such as quantum communication and chiral sensing, traditional photodetectors are limited by the inherent optical isotropy of materials and thus are unable to directly distinguish circular polarization information. This paper numerically reports a miniature circular polarization photodetector based on chiral metasurfaces, which achieves an excellent extinction ratio of up to 31 dB through the collaborative regulation of geometric displacement manipulation and tilt angle operation. This device utilizes the symmetry-breaking effect to construct significantly different transmission spectral responses between left circularly polarized light (LCP) and right circularly polarized light (RCP). Our research not only provides a high-performance implementation solution for on-chip polarization detection but also opens up new paths for the future development of quantum optics, integrated sensing, and ultra-compact polarization optical systems. Full article
