Search Results (24)

In optical communication systems, optical half-band filters are essential for efficient spectral separation, necessitating stringent performance criteria such as a wide spectral range, low insertion loss, and minimal crosstalk. This paper proposes a broadband optical half-band filter based on a cascaded Mach–Zehnder Interferometer (MZI) structure, which effectively improves spectral separation by enhancing flatness and sharpness at transition edges through the optimization of delay line length differences and phase compensation values. The results demonstrate that the proposed design achieves an insertion loss below 0.45 dB and inter-band crosstalk under −20.7 dB over a 40 nm bandwidth, with a roll-off of 2.2 dB/nm between 1517 nm and 1528 nm. The findings highlight the technical advantages of cascaded MZI structures in achieving high-precision spectral separation, offering a valuable reference for the development of future high-performance optical communication networks and integrated optical devices. Full article

The 2 μm wavelength is ideal for light detection and ranging and gas sensing due to its eye-safe operation, strong molecular absorption targeting, and low atmospheric scattering—critical for environmental monitoring and free-space communications. The existing 2 μm systems rely on mechanical beam steering, which limits speed and reliability. Integrated photonic solutions have not yet been demonstrated in this wavelength. We propose a focal plane array design to address these challenges. Compared to optical phased arrays requiring complex phase control for each antenna, FPAs have a simple switch-based control and high suppression of background noise. Although FPAs need an external lens for beam collimation, they significantly reduce system complexity. This study introduces a compact, low-loss 1 × 8 focal plane array operating in the 2 μm range, employing a cascaded Mach–Zehnder interferometer switch array on a silicon nitride platform. The device demonstrates a field of view of 16.8°, background suppression better than 17 dB, and excess loss of −1.4 dB. This integrated photonic beam steering solution offers a highly promising, cost-effective approach for rapid beam switching. This integrated photonic beam steering solution offers a highly promising, cost-effective approach for rapid beam switching. Full article

Microwave sources based on ultrastable lasers and optical frequency combs (OFCs) exhibit ultralow phase noise and ultrahigh-frequency stability, which are important for many applications. Herein, we present a microwave source that is phase-locked to an ultrastable continuous-wave laser, with a relative frequency instability of 7 × ${10}^{-16}$ at 1 s. An Er:fiber-based OFC and an optic-to-electronic converter with low residual noise are employed to confer optical frequency stability on the 9.6 GHz microwave signal. Instead of using the normal cascaded Mach–Zehnder interferometer method, we developed a microwave regeneration method for converting optical pulses into microwave signals to further suppress the additional noise in the optic-to-electronic conversion process. The microwave regeneration method employs an optical-to-microwave phase detector based on a fiber-based Sagnac loop to produce the error signal between a 9.6 GHz dielectric resonator oscillator (DRO) and the OFC. The 9.6 GHz microwave (48th harmonic of the comb’s repetition rate) signal with the frequency stability of the ultrastable laser was achieved using a DRO that was phase-locked to the optical comb. Preliminary evaluations showed that the frequency instability of the frequency synthesizer from the optical to the 9.6 GHz microwave signal was approximately 2 × ${10}^{-15}$ at 1 s, the phase noise was $-106$ dBc Hz⁻¹ at 1 Hz, and the timing noise was approximately 9 as Hz^−1/2 (phase noise approx. $-125$ dBc Hz⁻¹). The 9.6 GHz signal from the photonic microwave source exhibited a short-term relative frequency instability of 2.1 × ${10}^{-15}$ at 1 s, which is 1.5 times better than the previous results. Full article

In this study, we propose a novel design for a NAND gate using a single semiconductor optical amplifier (SOA) followed by a delay interferometer (DI). This streamlined configuration significantly reduces complexity and cost compared to conventional methods, which typically require cascading multiple SOA-Mach–Zehnder interferometers (SOA-MZIs) for NAND gate implementation. Our approach directly generates the NAND logic output with a single SOA and DI, simplifying the overall design. The gate’s performance is evaluated at 80 Gb/s, achieving a high-quality factor (QF) of 10.75. We also analyze the impact of key parameters to optimize the gate’s functionality. Furthermore, we assess the effect of amplified spontaneous emission on the QF, providing a more comprehensive evaluation of the system’s performance. This research paves the way for more efficient and cost-effective complex optical logic circuit solutions. Full article

In this study, we demonstrate high-extinction stop-band photonic filters based on Mach–Zehnder interferometer (MZI)-coupled silicon nitride (Si₃N₄) resonators fabricated using I-line lithography technology. Leveraging the low-loss silicon nitride waveguide, our approach enables the creation of stable, high-performance filters suitable for applications in quantum and nonlinear photonics. With destructive interference at the feedback loop, photonic filters with an extinction ratio of 35 dB are demonstrated with four cascaded MZI-coupled resonators. This cascading design not only enhances the filter’s extinction but also improves its spectral sharpness, providing a more selective stop-band profile. Experimental results agree well with the theoretical results, showing linear scaling of extinction ratios with the number of cascaded MZI-coupled resonators. The scalability of this architecture opens the possibility for further integration and optimization in complex photonic circuits, where high extinction ratios and precise wavelength selectivity are critical for advanced signal processing and quantum information applications. Full article

A novel vernier effect filter is designed utilizing two cascaded Mach–Zehnder interferometers (MZIs). Integrating the filter into an erbium-doped fiber laser (EDFL), the tunability of laser wavelength is achieved. Each MZI comprises two sequentially interconnected 3 dB optical couplers (OCs), where the incoming light is initially split into two arms at the first OC and subsequently recombined at the second OC. Interference occurs due to the optical path difference between these two beams. Notably, the two MZIs exhibit closely matched free spectral ranges (FSRs), leading to the formation of a broadened envelope in the superimposed spectrum. By delicately adjusting the optical path difference between the two arms of one MZI, a little drift of the interference spectrum is induced. This small amount of drift, in turn, triggers a significant movement of the envelope, giving rise to the so-called vernier effect. Integrating the vernier effect filter into an EDFL, the wavelength of the fiber laser can be tuned from 1542.56 nm to 1556.62 nm, with a tuning range of 14.06 nm. Furthermore, by employing a high-precision stepper motor, a remarkable tuning accuracy of 0.01 nm is attainable. The side mode suppression ratio of all wavelengths is above 55 dB. In comparison to reported tunable fiber lasers utilizing MZI filters, the proposed fiber laser in this study offers enhanced precision and a more user-friendly tuning process. Full article

Tunable diode laser spectroscopy (TDLS) is a measurement technique with high spectral resolution. It is based on tuning the emission wavelength of a semiconductor laser by altering its current and/or its temperature. However, adjusting the wavelength leads to a change in emission intensity. For applications that rely on modulated radiation, the challenge is to isolate the true spectrum from the influence of extraneous instrumental contributions, particularly residual intensity and wavelength modulation. We present a novel approach combining TDLS with interferometric techniques, exemplified by the use of a Mach–Zehnder interferometer, to enable the separation of intensity and wavelength modulation. With interferometrically enhanced intensity modulation, we reduced the residual wavelength modulation by 83%, and with interferometrically enhanced wavelength modulation, we almost completely removed the residual derivative of the signal. A reduction in residual wavelength modulation enhances the spectral resolution of intensity-modulated measurements, whereas a reduction in residual intensity modulation improves the signal-to-noise ratio and the sensitivity of wavelength-modulated measurements. Full article

Optical fiber sensors consist of multiple Mach–Zehnder (MZ) interferometers and are common in the protection of different compounds. These sensors are very sensitive to any intrusion or threat. However, the spatial resolution is proportional to the number of MZ interferometers along the sensor. Consequently, a long sensor with a high resolution can be costly. In this paper, we suggest replacing the cascaded MZ interferometers with a couple of adjacent fibers, each of which have a harmonically varying refractive index. In this theoretical study, it is shown that two fibers with varying refractive indices demonstrate a sensitivity equivalent to that of multiple MZ interferometers. Furthermore, when the coupling coefficient between the fibers is weak, an analytical expression can be derived for the transmission between the fibers. This transmission reveals a quantization rule for which the light coupling between the two fibers vanishes. Full article

This research explores the forefront of all-optical data processing systems through the utilization of carrier reservoir semiconductor optical amplifiers (CR-SOAs). Recent advancements have showcased the successful design and implementation of CR-SOA-based combinational systems, incorporating pivotal elements like half adders, half subtractors, digital-to-analog converters, latches, header recognition, and header processors. These breakthroughs signify a significant stride towards the realization of faster and more efficient optical logic systems. This study delves into the distinctive characteristics of CR-SOA-based Mach–Zehnder interferometer (MZI) functioning as an XOR gate, emphasizing their transformative potential in information processing. By integrating them into the architecture of an all-optical 4-bit parity generator and checker, the research underscores the practicality of CR-SOA technology in all-optical processing, offering unprecedented speeds and facilitating enhanced data processing capabilities at a remarkable speed of 120 Gb/s return-to-zero pulses. In evaluating the performance of the proposed scheme, the research employs the quality factor metric. This assessment not only yields quantitative insights into the efficacy of CR-SOA-based logic systems but also establishes a critical benchmark for their practical implementation. The study further explores the impact of key data signals and CR-SOA parameters on this metric. The outcomes demonstrate the ability of the CR-SOA-based MZI to cascade and form more intricate logic circuits, thereby highlighting the versatility and potential of this innovative approach in advancing the landscape of all-optical data processing. Full article

In this paper, a temperature sensing scheme with a miniature MZI structure based on the principle of inter-mode interference is proposed. The sensing structure mainly comprises single mode–coreless–multimode–coreless–single mode fibers (SCMCSs), which have been welded together, with different core diameters. The light beam has been expanded after passing through the coreless optical fiber and is then coupled into a multimode optical fiber. Due to the light passing through the cladding and core mode of the multimode optical fiber with different optical paths, a Mach–Zehnder interferometer is formed. Moreover, due to the thermo-optic and thermal expansion effects of optical fibers, the inter-mode interference spectrum of a multimode fiber shifts when the external temperature changes. Through theoretical analysis, it is found that the change in the length of the sensing fiber during temperature detection has less of an effect on the sensitivity of the sensing structure. During the experiment, temperature changes between 20 and 100 °C are measured at sensing fiber lengths of 1.5 cm, 2.0 cm, 2.5 cm, 3.0 cm, 3.5 cm, and 4.0 cm, respectively, and the corresponding sensitivities are 65.98 pm/°C, 72.70 pm/°C, 67.75 pm/°C, 66.63 pm/°C, 74.80 pm/°C, and 72.07 pm/°C, respectively. All the corresponding correlation coefficients are above 0.9965. The experimental results indicate that in the case of a significant change in the length of the sensing fiber, the sensitivity of the sensing structure changes slightly, which is consistent with the theory that the temperature sensitivity is minimally affected by a change in the length of the sensing fiber. Therefore, the effect of the length on sensitivity in a cascade-based fiber structure is well solved. The sensing scheme has an extensive detection range, small size, good linearity, simple structure, low cost, and high sensitivity. It has a good development prospect in some detection-related application fields. Full article

Caffeine is the most widely consumed stimulant and is the subject of significant ongoing research and discussions due to its impact on human health. The industry’s need to comply with country-specific food and beverage regulations underscores the importance of monitoring caffeine levels in commercial products. In this study, we propose an alternative technique for caffeine analysis that relies on mid-infrared laser-based photothermal spectroscopy (PTS). PTS exploits the high-power output of the quantum cascade laser (QCL) sources to enhance the sensitivity of the mid-IR measurement. The laser-induced thermal gradient in the sample scales with the analytes’ absorption coefficient and concentration, thus allowing for both qualitative and quantitative assessment. We evaluated the performance of our experimental PTS spectrometer, incorporating a tunable QCL and a Mach–Zehnder interferometer, for detecting caffeine in coffee, black tea, and an energy drink. We calibrated the setup with caffeine standards (0.1–2.5 mg mL⁻¹) and we benchmarked the setup’s capabilities against gas chromatography (GC) and Fourier-transform infrared (FTIR) spectroscopy. Quantitative results aligned with GC analysis, and limits of detection matched the research-grade FTIR spectrometer, indicating an excellent performance of our custom-made instrument. This method offers an alternative to established techniques, providing a platform for fast, sensitive, and non-destructive analysis without consumables as well as with high potential for miniaturization. Full article

An interference filter is designed by cascading two Mach-Zehnder interferometers (MZIs), which is then utilized in the construction of a wavelength interval adjustable dual-wavelength Erbium-doped fiber laser (EDFL). Each MZI consists of two 3 dB optical couplers (OCs) connected in series. The input light is split into two arms at the first OC and recombined at the second OC. The first MZI (MZI 1) has a smaller free spectral range (FSR) and is used for selecting the output wavelength of the laser. The second MZI (MZI 2) has a larger FSR and forms an envelope structure on the comb-like spectrum of MZI 1. By adjusting the optical path difference between the two arms of MZI 2, the FSR of the envelope can be changed, thereby altering the interval of the output wavelengths. The implemented filter is inserted into the EDFL to achieve stable dual-wavelength output. By stretching one arm of MZI 2, the interval of the dual-wavelength can be adjusted from 4.64 to 13.94 nm, with the side-mode suppression ratio of over 44 dB for all wavelengths. Full article

A simple and novel hybrid interferometer based on the antiresonance (AR) effect and Mach–Zehnder interference (MZI), which enables simultaneous measurement of temperature and strain, is proposed and investigated. The sensor is made by cascading a 30 cm section of a few-mode fiber (FMF) and a 3.376 mm hollow-core fiber (HCF) through a single-mode fiber (SMF). The FMF and SMF are fused without misalignment to excite two stable modes, thereby forming a Mach–Zehnder interferometer. Concurrently, the introduction of HCF can effectively excite the AR effect, which is manifested in the transmission spectrum as two different dips at the same time caused by the difference in the two physical mechanisms, showing diverse responses to both external temperature and strain. This difference can be used to construct a cross-coefficient matrix to implement the simultaneous measurement of temperature and strain. The experimental results demonstrate that the AR effect and MZI correspond to strain sensitivities of –0.87 and –2.29 pm/µε, respectively, and temperature sensitivities of 15.68 and –13.93 pm/°C, respectively. Furthermore, the sensor is also tested for repeatability, and the results show that it has good repeatability and great potential in sensing applications. Full article

Silicon photonics (SiPh) are considered a promising technology for increasing interconnect speed and capacity while decreasing power consumption. Mode division multiplexing (MDM) enables signals to be transmitted in different orthogonal modes in a single waveguide core. Wideband MDM components simultaneously supporting wavelength division multiplexing (WDM) and orthogonal frequency-division multiplexing (OFDM) can significantly increase the transmission capacity for optical interconnects. In this work, we propose, fabricate and demonstrate a wideband and channel switchable MDM optical power divider on an SOI platform, supporting single, dual and triple modes. The switchable MDM power divider consists of two parts. The first part is a cascaded Mach–Zehnder interferometer (MZI) for switching the data from their original TE₀, TE₁ and TE₂ modes to different modes among themselves. After the target modes are identified, mode up-conversion and Y-branch are utilized in the second part for the MDM power division. Here, 48 WDM wavelength channels carrying OFDM data are successfully switched and power divided. An aggregated capacity of 7.682 Tbit/s is achieved, satisfying the pre-forward error correction (pre-FEC) threshold (bit-error-rate, BER = 3.8 × 10⁻³). Although up to three MDM modes are presented in the proof-of-concept demonstration here, the proposed scheme can be scaled to higher order modes operation. Full article

A stable, single, and dual-wavelength erbium-doped fiber laser (EDFL), based on two Mach–Zehnder interferometers (MZIs), arranged in a cascade configuration, was proposed for experimental purposes. Both MZIs were assembled by splicing a capillary hollow-core fiber (CHCF) section between two multimode fibers (MMFs) segments. The novelty of this single and dual-wavelength EDFL is that the switchable operation of the laser is achieved by thermally tuning the interference pattern of one MZI and not by adjusting the polarization state inside the fiber ring cavity. The maximum measured value of SNR was 58.9 dB for the single and dual-wavelength laser emissions. Moreover, the stable output power exhibited by this EDFL, in terms of minimal power and wavelength fluctuations, at 0.05 dB and 10 pm, was detected during the single and dual-wavelength operation. It is worth noticing that switching is achieved at exact wavelength locations with a separation of 1.8 nm and not randomly, as reported by other works. These features make this switchable EDFL an appealing candidate for application in optical fiber communication systems and fiber sensing. Full article
