Aggressive technology scaling has led to a significant increase in manufacturing process variations and transistor aging effects, which critically degrade the performance of radio frequency (RF) circuits. These reliability challenges are particularly pronounced in voltage-controlled oscillators (VCOs), where phase noise and operating frequency stability are compromised. While design strategies incorporating micro-electromechanical systems (MEMS) actuators enhance VCO performance by leveraging MEMS varactors or inductors with substantially higher quality factors (Q), this benefit is progressively undermined over time by process variations and aging-induced shifts in the threshold voltage and carrier mobility of the VCO’s transistors. This work presents an ultra-low-power current-reuse voltage-controlled oscillator (VCO) designed to maintain stable performance under process variability and reliability-induced parameter shifts. Robust operation is achieved using a self-detecting–correcting (SDC) bias scheme that senses performance drift and applies corrective feedback through body-bias control in the VCO core. Analytical relations are derived to describe the impact of threshold voltage and mobility variations, and the approach is validated via post-layout simulations in a 130 nm complementary metal-oxide semiconductor (CMOS). Under 18% variations in threshold voltage and carrier mobility, the proposed SDC scheme preserves oscillation frequency, phase noise, and figure of merit (FoM) while also mitigating the intrinsic output amplitude imbalance of conventional current-reuse VCOs. Monte Carlo analysis (500 runs) demonstrates low sensitivity to fabrication uncertainty, with a standard deviation below 0.14 dBc/Hz for phase noise, 210 kHz for oscillation frequency, and 0.4 dBc/Hz for FoM. The VCO operates from a 0.9 V supply, consumes 175 μW, and achieves −124 dBc/Hz phase noise at 1 MHz offset near 2.4 GHz (FoM ≈ −199 dBc/Hz). Full article

To address carrier-phase loss of lock and long-term drift in frequency-offset estimation that may arise from time-of-arrival (TOA) measurements in enhanced Loran (eLoran) timing receivers under low signal-to-noise ratio (SNR) and moderate-to-high dynamics, this paper proposes a joint TOA and carrier-phase measurement and tracking method. First, transmitter identification and group repetition interval (GRI) lock are achieved by exploiting the periodic repetition of pulse groups, and epoch folding is applied to enhance effective SNR. Then, a sub-sample TOA observation is constructed via a three-stage progressive refinement procedure: energy-matching coarse estimation, coherent cross-correlation, and parabolic peak interpolation. In parallel, baseband phase observations are obtained through coherent downconversion and accumulation. A unified state-space model incorporating TOA bias, TOA drift rate, baseband phase, and frequency offset is further established to enable joint Kalman filtering of TOA and phase. Moreover, an innovation-likelihood-weighted parallel multiple-model filter combined with measurement-noise covariance inflation is introduced to suppress outlier observations. Simulations show that the TOA estimate converges within about 1 s while maintaining phase continuity and stable frequency-offset estimation, and that the proposed method achieves superior overall robustness and long-term stability compared with a conventional Costas loop. Full article

The integration of satellite and terrestrial networks within the same spectrum is a key enabler for extending mobile connectivity in future communication systems. In this context, the Direct Connectivity between Mobile Satellite Service and International Mobile Telecommunications user equipment (DC-MSS-IMT) paradigm, currently under study within the International Telecommunication Union foresees the use of terrestrial IMT frequency bands by satellite systems to directly serve conventional mobile devices. This paper presents an experimental study to assess the coexistence between a terrestrial 5G-NR receiver and a co-channel interfering signal representative of a Low Earth Orbit (LEO) satellite downlink. A controlled laboratory setup in a conducted configuration was implemented to ensure repeatability and accurate control of interference conditions. Measurements were performed over four carrier frequencies representative of IMT bands (763 MHz, 1482 MHz, 2150 MHz, and 2635 MHz), considering different traffic load conditions (100% and 50%) and Doppler shifts associated with satellite motion. The interference impact was evaluated in terms of receiver desensitization, defined as the increase in the total received power relative to the baseline noise level. The results show that a 1 dB desensitization threshold is consistently reached when the interfering signal power is approximately 5–6 dB below the receiver noise floor, corresponding to an interference-to-noise ratio (I/N) of about −6 dB. This behavior is observed across all tested frequency bands, traffic conditions, and Doppler scenarios, indicating limited sensitivity to frequency offsets within the considered range. The findings confirm the validity of commonly adopted coexistence criteria and provide experimentally derived reference values to support ongoing regulatory and technical studies on spectrum sharing between satellite and terrestrial IMT systems. Full article

To address limitations in the modulation-quality analysis of high-order Quadrature Amplitude Modulation (QAM) signals, including insufficient timing synchronization accuracy, challenges in carrier recovery, and coupling between synchronization errors and parameter estimation, a cascaded digital baseband processing framework tailored for measurement scenarios is proposed. The proposed framework is designed to integrate synchronization recovery and parameter measurement. In the timing synchronization stage, a feedforward open-loop structure based on the Oerder–Meyr (OM) algorithm is employed to estimate the optimal sampling instants rapidly. In the carrier synchronization stage, a two-stage recovery structure is constructed, comprising coarse frequency offset estimation based on polarity decision and fine synchronization using an improved frequency–phase detector (FPD), thereby achieving both robust acquisition of large frequency offsets and high-precision compensation of residual errors. On this basis, a unified modulation quality evaluation model is established, enabling the joint estimation of the Error Vector Magnitude (EVM) and the Modulation Error Ratio (MER), as well as amplitude, phase, and frequency errors, within a consistent analytical framework. System-level validation of 256 QAM and 1024 QAM signals is conducted using a MATLAB R2021b-based simulation platform. The results demonstrate that stable synchronization recovery can be achieved under timing, frequency, and phase perturbations, yielding well-defined constellation diagrams. In terms of parameter estimation, the relative errors of all evaluated metrics are maintained within 2%, which is significantly below the conventional 5% measurement criterion. Further analysis indicates that the proposed method maintains strong robustness across varying signal-to-noise ratios (SNRs) and sampling rates. The results confirm that the proposed cascaded processing framework effectively unifies synchronization recovery and modulation quality analysis, significantly improving parameter estimation accuracy while maintaining high synchronization precision. This approach provides a practical and efficient solution for high-order QAM signal testing and measurement systems. Full article

Co-channel interference (CCI) remains a critical factor affecting link reliability in narrowband wireless systems, especially in scenarios with intensive frequency reuse, overlapping coverage, and dense terminal access. Existing interference detection methods are either computationally simple but insufficiently sensitive to short-term spectral variations, or highly accurate but dependent on labeled data and nontrivial inference resources. To address this issue, this paper proposes a lightweight CCI detection method in the FFT domain based on spectrum-jump analysis. The proposed method does not rely on absolute power growth as the primary interference indicator. Instead, it tracks the temporal inconsistency of dominant spectral-bin indices across consecutive FFT frames and converts recurrent peak-bin migration into an interference decision through a short-window counting mechanism. The method is computationally efficient, interpretable, and suitable for real-time deployment without offline model training. SDR-based measurements are combined with controlled repeated experiments to assess detector performance under varying signal-to-noise ratio (SNR), interference-to-signal ratio (ISR), carrier-frequency offset (CFO), multi-peak ambiguity, and two-path Rayleigh fading conditions. On the measured SDR record, the proposed method captures all interference-positive windows after the marked onset, while the controlled SNR/ISR experiments yield an overall detection probability of 96.0% over 250 CCI trials with no false alarms over 250 normal trials. ROC and precision–recall analyses further show that the selected threshold lies within a broad validation plateau. The results also reveal clear applicability boundaries: when the CFO approaches zero, when the interference is very weak, or when multiple stationary peaks have nearly equal power, dominant-bin migration may be weak or ambiguous. Therefore, the proposed approach is a low-complexity online detector for CCI cases that induce observable FFT-bin instability, and it can also serve as a front-end trigger for more advanced interference analysis modules. Full article

Cell-free network architectures are a promising candidate for sixth-generation (6G) communications, as densely distributed access points (APs) flexibly accommodate traffic demands and mitigate inter-cell interference. In practical cell-free systems employing direct-conversion receivers, however, performance is severely degraded by analog front-end impairments such as in-phase/quadrature (IQ) imbalance and carrier frequency offset (CFO). Conventional orthogonal frequency division multiplexing (OFDM)-based algorithms address these impairments separately, but their joint impact is insufficiently mitigated because IQ imbalance and CFO mutually interfere, leaving residual errors when either is estimated first. To overcome this, we extend our previously proposed adaptive compensation scheme based on time-frequency interferometry-OFDM (TFI-OFDM) by introducing a decision-feedback mechanism. Preliminary CFO estimation and compensation are first performed to suppress inter-symbol interference (ISI), followed by joint estimation and compensation of IQ imbalance and CFO via decision feedback, achieving accurate channel estimation with low pilot overhead. Simulation results demonstrate that the proposed scheme effectively mitigates the mutual interference of both impairments, achieving bit-error-rate (BER) performance close to an ideal impairment-free system. These results confirm that TFI-OFDM-based joint compensation with decision feedback is a promising approach for practical 6G cell-free deployments. Full article

The rapid development of 6G wireless networks requires ultra-high data rates that traditional microwave frequencies cannot support. Photonics-assisted terahertz (THz) technologies offer a promising solution by combining high-capacity optical fibers with wideband wireless transmission. However, as bandwidth expands, sampling frequency offset (SFO) becomes a critical issue that degrades signal quality in single-carrier systems. This paper evaluates the performance of two main compensation methods within a photonics-assisted THz system operating at 320 GHz. We compare the Gardner clock recovery algorithm and the Digital Interpolation Compensation Algorithm (DICA) across various modulation formats and offset levels. Our findings indicate that the Gardner algorithm is effective for low-order modulation when the SFO is below 100 ppm, but its performance fails outside this range. Conversely, the DICA provides robust compensation up to 1000 ppm regardless of the modulation format, provided that the exact offset value is known. Without proper compensation, the system BER increases significantly as the SFO grows. These results demonstrate the complementary nature of these two algorithms and provide a practical guide for selecting compensation strategies in future high-speed THz communication links. Full article

A low-overhead joint synchronization and channel estimation method for conventional CP-OFDM systems is developed to mitigate the error accumulation of stage-wise processing under multipath fading and carrier frequency offset (CFO). The joint estimation of symbol timing offset (STO), CFO, and channel parameters is formulated in a least-squares framework, and the analytical elimination of the channel vector reduces the original three-dimensional optimization to a two-dimensional search. In addition, reusable common terms and a precomputable pseudoinverse-related operator are exploited to reduce redundant online computations. Simulation results show that, under different signal-to-noise ratio (SNR) and normalized CFO conditions, the method achieves higher perfect synchronization probability and lower root-mean-square error (RMSE) for STO, CFO, and channel estimation than conventional CP-based baselines, while providing a favorable trade-off between estimation accuracy and computational complexity. Full article

In the open-winding motor fed by a common DC bus, unbalanced inverter common-mode voltage (CMV), zero-sequence components of the permanent magnet flux linkage, and the PWM dead-time effect can induce a zero-sequence current (ZSC) through the inherent current path. For an open-winding five-phase permanent magnet synchronous motor (OW-FPPMSM) applied in an aerospace rocket starter-generator system, two ZSC suppression strategies based on zero-sequence voltage (ZSV) generation mechanisms are proposed in this paper, which improve motor performance in a simple and efficient manner. In the first strategy, the conventional method is modified to enable asynchronous operation of the two inverters, thereby generating the required ZSV pulses. The switching order and time offset between the two inverters are determined by the reference ZSV. The second strategy employs basic voltage vectors with larger magnitudes, resulting in higher DC bus voltage utilization. By adjusting the switching sequence of the second inverter, the ZSC components at the carrier frequency are eliminated. Both strategies also achieve the injection of the third-harmonic current. Finally, the two strategies are further analyzed in terms of the modulation index and ZSV modulation range. Simulation and experimental results verify the effectiveness of the ZSC suppression strategies. Full article

Signal synchronization is one of the core aspects of communication, ensuring that the receiver accurately decodes the signals transmitted by the sender. However, in the diverse application scenarios and broad spectrum range of 5G new radio (NR), the performance of traditional estimation algorithms often deteriorates as frequency offset increases and noise interference intensifies. This work focuses on the estimation of time offset, cell sector identifier (ID), and frequency offset in 5G mobile communication systems. We leverage the advanced learning capabilities and adaptability of a convolutional neural network (CNN) to optimize the estimation process. Additionally, we incorporate a long short-term memory (LSTM) network to capture the dynamic variations in time-varying channels. The results demonstrate that the proposed neural network exhibits significant advantages in estimation performance. Full article

High-power jamming may drive the radio-frequency (RF) front end of a satellite receiver into a nonlinear regime, thereby invalidating the linear superposition assumption underlying conventional excision and blanking methods. We formulate dual-receiver direct-sequence spread-spectrum (DSSS) anti-jamming as a nonlinear source-separation problem in complex baseband using stacked I/Q observations. We then propose a time-domain separator that jointly estimates the desired DSSS signal and the jammer on a designated reference receiver. The separator combines a multi-scale convolutional front end with a Transformer encoder and is pretrained on synthetic nonlinear mixtures that include multi-tone or burst jamming as well as typical satellite impairments, including Doppler/carrier-frequency offset (CFO), phase noise, multipath, and additive white Gaussian noise (AWGN). Robustness under high-jammer-to-signal-ratio (JSR) conditions is improved through high-JSR oversampling and JSR-aware loss reweighting. After Stage I supervised pretraining on labeled synthetic mixtures, an optional Stage II mixture-only adaptation step further refines the separator using nonlinear reconstruction consistency and lightweight communication-motivated priors. Across 1000 test mixtures with JSRs from −5 to 15 dB, SNRs from 15 to 25 dB, and cubic coefficients $a\in \left[\mathrm{0,0.5}\right]$, the proposed method improves the desired-signal scale-invariant signal-to-noise ratio (SI-SNR) from −4.79 dB for the mixture baseline to 13.32 dB after supervised pretraining and to 17.73 dB after mixture-only blind fine-tuning. Over the same test set, the failure rate (SI-SNR < 0 dB) decreases from 60.7% to 2.3%. Full article

High-precision Doppler measurement is essential for deep-space Unified X-band (UXB) tracking systems, yet digital implementations suffer from finite word-length quantization errors that degrade performance. This study analyzes frequency offset errors in UXB transponder systems, focusing on the phase-locked loop (PLL) and system-level digital processing. A digital system model is presented, featuring an FFT-based coarse acquisition and a digital Costas loop for carrier synchronization. The simulation results reveal that 32-bit quantization yields unacceptable frequency offset errors. By extending critical paths to 48 bits, the system reduces frequency offset error by approximately 2¹⁶ and achieves sub-0.01 mm/s velocity accuracy, significantly improving coherence and meeting deep-space measurement requirements. Full article

This paper presents a novel dual-mode memristor-based ring oscillator designed for energy-efficient, wireless biomedical signal conditioning systems. The proposed architecture leverages a compact DTMOS memristor emulator, consisting of only two transistors and one capacitor, to replace the conventional NMOS pull-down devices in a three-stage PMOS ring oscillator. This integration enables two distinct operating modes within a single compact core: a fixed-frequency mode for stable clock generation and carrier synthesis, and a programmable chirp mode for frequency-modulated signal generation. The fixed-frequency mode achieves continuous tuning from 3.142 GHz to 4.017 GHz via varactor control, with an ultra-low power consumption of only 111 µW at 4.017 GHz. The chirp mode generates linear frequency sweeps starting from 0.8 GHz, with the sweep range independently controllable through the state capacitor value and the pulse width of the control signal (SW_Chirp). Designed in a standard 0.18 µm CMOS process, the oscillator exhibits a low phase noise of −87.82 dBc/Hz at a 1 MHz offset for the three-stage configuration, improving to −94.3 dBc/Hz for the five-stage design. The overall frequency coverage spans 0.8–4.017 GHz, representing a 133.6% fractional range. The calculated figure of merit (FoM) is −169.45 dBc/Hz. Experimental validation using a discrete CD4007 prototype confirms the oscillation principle, while comprehensive simulations demonstrate robust performance across process corners and temperature variations. With its zero-static-power memristor core, wide tunability, and dual-mode reconfigurability, the proposed oscillator is ideally suited for multi-standard wireless biomedical applications, including implantable telemetry, neural stimulation, ultra-wideband (UWB) transmitters, and non-contact vital sign monitoring. Full article

Ambient backscatter systems enable passive sensing and information transfer by utilizing the reflection and modulation of incident radio-frequency (RF) signals. However, in real-world scenarios involving non-cooperative targets such as off-the-shelf printed circuit boards (PCBs), the backscattered signal is extremely weak and often obscured by strong direct-path self-interference (SI) at the receiver. This issue becomes even more severe when unintentional PCB structures act as radiating elements. In this work, we explore ambient backscatter leakage from a compromised PCB using a realistic measurement setup that includes separated transmit and receive antennas and a direct-conversion Universal Software Radio Peripheral (USRP)-based receiver. We demonstrate that residual carrier frequency offset (CFO), caused by oscillator mismatch and hardware imperfections, can spread the dominant SI in the baseband and completely mask the weak backscattered signal. To solve this problem, a software-based post-processing framework is applied. This method leverages the complex baseband representation enabled by the homodyne receiver to jointly manage the carrier and SI components without relying on intermediate-frequency processing or prior knowledge of the target signal parameters. Experimental results show that this approach significantly improves the detectability of weak backscattered baseband information that would otherwise be concealed within the raw I/Q data. This study emphasizes the importance of CFO-aware digital processing in ambient backscatter systems and offers new insights into unintended electromagnetic leakage mechanisms from commercial PCB platforms. Full article

The existing research on frequency diverse arrays (FDAs) predominantly concentrates on narrowband uniform linear frequency diverse arrays (ULFDAs). The uniform circular array presents advantages, such as a small aperture and omnidirectional scanning. In practical underwater acoustic environments, multi-carrier narrowband signals are commonly utilized. Nevertheless, current studies lack theoretical analysis and exploration of the performance of narrowband uniform circular frequency diverse arrays (UCFDAs). This paper, utilizing a UCFDA sonar transmit and single-element receive model, introduces narrowband signals employing a multi-carrier design. Through the time-domain convolution of signals output from matched filters, we deduce the general expression of the ambiguity function and its properties for UCFDA sonar within the narrowband framework. Simulations employing rectangular pulses are executed to validate the accuracy of the derived analytical expression of the ambiguity function. Moreover, we conduct a comparative analysis of the ambiguity function shapes for UCFDA sonar with linear frequency offset models, natural logarithmic frequency offset models, and multi-carrier UCFDA sonar. This analysis reveals that the nonlinear characteristics of the natural logarithmic frequency offset model effectively eliminate the periodically appearing ambiguity peaks in the ambiguity function of traditional linear frequency offset UCFDA sonar. Furthermore, the multi-carrier design significantly diminishes the sidelobe level in the zero-Doppler cut and has higher robustness under noise conditions. Full article
