Search Results (17)

Traditional vehicle emergency braking research suffers from inaccurate maximum road adhesion coefficient identification and suboptimal wheel slip ratio control. To address these challenges in electronic hydraulic braking systems’ anti-lock braking technology, firstly, this paper proposes a CDOA-SENet-CNN neural network to precisely estimate the maximum road adhesion coefficient by monitoring and analyzing the braking process. Secondly, correlation curves between peak adhesion coefficients and ideal slip ratios are established using the Burckhardt model and CarSim 2020, and the estimated maximum adhesion coefficient from the CDOA-SENet-CNN network is used with these curves to determine the optimal slip ratio for the single-neuron integral sliding mode control (SNISMC) algorithm. Finally, an SNISMC control strategy is developed to adjust the wheel slip ratio to the optimal value, achieving stable wheel control across diverse road surfaces. Results indicate that the CDOA-SENet-CNN network rapidly and accurately estimates the peak braking surface adhesion coefficient. The SNISMC control strategy significantly enhances wheel slip ratio control, consequently increasing the effectiveness of vehicle brakes. This paper introduces an innovative, stable, and efficient solution for enhancing vehicle braking safety. Full article

It is estimated that 10% to 20% of road accidents are related to fatigue, with accidents caused by drowsiness up to twice as deadly as those caused by other factors. In order to reduce these numbers, strategies such as advertising campaigns, the implementation of driving recorders in vehicles used for road transport of goods and passengers, or the use of drowsiness detection systems in cars have been implemented. Within the scope of the latter area, the technologies used are diverse. They can be based on the measurement of signals such as steering wheel movement, vehicle position on the road, or driver monitoring. Driver monitoring is a technology that has been exploited little so far and can be implemented in many different approaches. This work addresses the evaluation of a multidimensional drowsiness index based on the recording of facial expressions, gaze direction, and head position and studies the feasibility of its implementation in a low-cost electronic package. Specifically, the aim is to determine the driver’s state by monitoring their facial expressions, such as the frequency of blinking, yawning, eye-opening, gaze direction, and head position. For this purpose, an algorithm capable of detecting drowsiness has been developed. Two approaches are compared: Facial recognition based on Haar features and facial recognition based on Histograms of Oriented Gradients (HOG). The implementation has been carried out on a Raspberry Pi, a low-cost device that allows the creation of a prototype that can detect drowsiness and interact with peripherals such as cameras or speakers. The results show that the proposed multi-index methodology performs better in detecting drowsiness than algorithms based on one-index detection. Full article

This paper presents an analysis of the risk of neck injury in vehicle occupants as a consequence of an impact. A review of the formulation of indexes that are used in the assessment and investigation of neck injury risk is discussed with the aim of providing a new, more appropriate index using suitable sensorized equipment. An experimental analysis is proposed with a new driver monitoring device using low-cost sensors. The system consists of wearable units for the head, neck, and torso where inertial measurement sensors (IMU) are installed to record data concerning the occupant’s head, neck, and torso accelerations while the vehicle moves. Two laser infrared distance sensors are also installed on the vehicle’s steering wheel to record the position data of the head and neck, as well as an additional IMU for vehicle acceleration values. To validate both the device and the new index, experiments are designed in which different sensorized volunteers reproduce an emergency braking maneuver with an instrumented vehicle at speeds of 10, 20, and 30 km/h before the beginning of any braking action. The neck is particularly sensitive to sudden changes in acceleration, so a sudden braking maneuver is enough to constitute a potential risk of cervical spine injury. During the experiments, large accelerations and displacements were recorded as the test speed increased. The largest accelerations were obtained in the experimental test at a speed of 30 km/h with values of 19.17, 9.57, 9.28, and 5.09 m/s² in the head, torso, neck, and vehicle, respectively. In the same experiment, the largest displacement of the head was 0.33 m and that of the neck was 0.27 m. Experimental results have verified that the designed device can be effectively used to characterize the biomechanical response of the neck in car impacts. The new index is also able to quantify a neck injury risk by taking into account the dynamics of a vehicle and the kinematics of the occupant’s head, neck, and torso. The numerical value of the new index is inversely proportional to the acceleration experienced by the vehicle occupant, so that small values indicate risky conditions. Full article

As a key transportation equipment in the construction of long tunnels with large slope, the material hoisting system plays an important role in the transportation of materials in sloping shafts. This paper proposes a parameterized calibration scheme for the hoisting system based on the structure and working principle of the hoisting system, taking the wire rope, hoist, motor and overhead wheel as the research objects, and according to the relevant industry specifications and numerical calculation methods. Based on the structural design and functional analysis of the hoisting system, a reasonable control system, monitoring system and safety protection devices are designed, and the calibration scheme and the designed system are introduced into the Dianzhong water diversion project for verification. The parameters of each component of the hoisting system were calculated as follows: maximum breaking tension value of wire rope 490.29 KN, drum diameter 2000 mm, motor hoisting power 213.7 KW, and the system design was as follows: control system selects frequency conversion electric control method, safety protection device selects ZDC30-2.5 anti-running device. The results show that: the hoisting system components structure parameters meet the specification requirements—safety protection devices can effectively prevent the occurrence of sports car slippage and man-car jumping rail overturning accident—to meet the requirements of the construction period transport capacity and transport safety. The relevant experience can provide the basis for the design of a material hoisting system for a similar inclined shaft construction. Full article

The wheelset coaxial wheel diameter difference is one of the most common wheel faults of railway vehicles. The existence of the wheelset coaxial wheel diameter difference may lead to the off-load operation of vehicles, resulting in abnormal wheel tread wear, leading to the deterioration of the wheel–rail contact relationship, resulting in the deterioration of the vehicle’s operating stability and comfort, and even leading to an increase in the derailment coefficient, affecting the running safety. In order to monitor the freight car wheelset coaxial wheel diameter difference online, a vehicle–track coupling dynamics model based on a trackside detection method was established, and the response of rail lateral displacement under the condition of the wheelset coaxial wheel diameter difference was analyzed. The results show that the existence of the wheelset coaxial wheel diameter difference can lead to a deviation in the vehicle’s run, with an increase in the wheelset coaxial wheel diameter difference and an increase in the lateral offset of wheelset increases. The impact of vehicle unbalance loading on the lateral movement of the wheelset is much smaller than that of the wheelset coaxial wheel diameter difference. The existence of the wheelset coaxial wheel diameter difference can be better reflected by detecting the wheelset’s lateral displacement. On straight line, the variation of lateral displacement has no infection of vehicle speed, but shows a quadratic growth trend with the wheelset coaxial wheel diameter difference. Based on this, the mapping relationship between the wheelset coaxial wheel diameter difference and wheelset lateral displacement can be obtained. Through a mapping relationship, the size of the wheelset coaxial wheel diameter difference can be reversed precisely through the detection of a trackside lateral movement monitoring system. The reliability of the identification method was verified with a specific test on the trackside monitoring system. Full article

Today’s cars have dozens of sensors to monitor vehicle performance through different systems, most of which communicate via vehicular networks (CAN). Many of these sensors can be used for applications other than the original ones, such as improving the driver experience or creating new safety tools. An example is monitoring variables that describe the driver’s behavior. Interactions with the pedals, speed, and steering wheel, among other signals, carry driving characteristics. However, not always all variables related to these interactions are available in all vehicles; for example, the excursion of the brake pedal. Using an acquisition module, data from the in-vehicle sensors were obtained from the CAN bus, the brake pedal (externally instrumented), and the driver’s signals (instrumented with an inertial sensor and electromyography of their leg), to observe the driver and car information and evaluate the correlation hypothesis between these data, as well as the importance of the brake pedal signal not usually available in all car models. Different sets of sensors were evaluated to analyze the performance of three classifiers when analyzing the driver’s driving mode. It was found that there are superior results in classifying identity or behavior when driver signals are included. When the vehicle and driver attributes were used, hits above 0.93 were obtained in the identification of behavior and 0.96 in the identification of the driver; without driver signals, accuracy was more significant than 0.80 in identifying behavior. The results show a good correlation between vehicle data and data obtained from the driver, suggesting that further studies may be promising to improve the accuracy of rates based exclusively on vehicle characteristics, both for behavior identification and driver identification, thus allowing practical applications in embedded systems for local signaling and/or storing information about the driving mode, which is important for logistics companies. Full article

This article describes the design of a smart steering wheel intended for use in unobtrusive health and drowsiness monitoring. The aging population, cardiovascular disease, personalized medicine, and driver fatigue were significant motivations for developing a monitoring platform in cars because people spent much time in cars. The purpose was to create a unique, comprehensive monitoring system for the driver. The crucial parameters in health or drowsiness monitoring, such as heart rate, heart rate variability, and blood oxygenation, are measured by an electrocardiograph and oximeter integrated into the steering wheel. In addition, an inertial unit was integrated into the steering wheel to record and analyze the movement patterns performed by the driver while driving. The developed steering wheel was tested under laboratory and real-life conditions. The measured signals were verified by commercial devices to confirm data correctness and accuracy. The resulting signals show the applicability of the developed platform in further detecting specific cardiovascular diseases (especially atrial fibrillation) and drowsiness. Full article

With the further development of highly automated vehicles, drivers will engage in non-related tasks while being driven. Still, drivers have to take over control when requested by the car. Here, the question arises, how potentially distracted drivers get back into the control-loop quickly and safely when the car requests a takeover. To investigate effective human–machine interactions, a mobile, versatile, and cost-efficient setup is needed. Here, we describe a virtual reality toolkit for the Unity 3D game engine containing all the necessary code and assets to enable fast adaptations to various human–machine interaction experiments, including closely monitoring the subject. The presented project contains all the needed functionalities for realistic traffic behavior, cars, pedestrians, and a large, open-source, scriptable, and modular VR environment. It covers roughly 25 km², a package of 125 animated pedestrians, and numerous vehicles, including motorbikes, trucks, and cars. It also contains all the needed nature assets to make it both highly dynamic and realistic. The presented repository contains a C++ library made for LoopAR that enables force feedback for gaming steering wheels as a fully supported component. It also includes all necessary scripts for eye-tracking in the used devices. All the main functions are integrated into the graphical user interface of the Unity^® editor or are available as prefab variants to ease the use of the embedded functionalities. This project’s primary purpose is to serve as an open-access, cost-efficient toolkit that enables interested researchers to conduct realistic virtual reality research studies without costly and immobile simulators. To ensure the accessibility and usability of the mentioned toolkit, we performed a user experience report, also included in this paper. Full article

Electrification of powertrain systems offers numerous advantages in the global trend in vehicular applications. A wide range of energy sources and zero-emission propulsion in the tank to wheel significantly add to electric vehicles’ (EV) attractiveness. This paper presents analyses of the energy balance between micro-photovoltaic (PV) installation and small electric vehicle in real conditions. It is based on monitoring PV panel’s energy production and car electricity consumption. The methodology included energy data from real household PV installation (the most common renewable energy source in Poland), electric vehicle energy consumption during real driving conditions, and drivetrain operating parameters, all collected over a period of one year by indirect measuring. A correlation between energy produced by the micro-PV installation and small electric car energy consumption was described. In the Winter, small electric car energy consumption amounted to 14.9 kWh per 100 km and was 14% greater than summer, based on test requirements of real driving conditions. The 4.48 kW PV installation located in Poznań produced 4101 kWh energy in 258 days. The calculation indicated 1406 kWh energy was available for EV charging after household electricity consumption subtraction. The zero-emission daily distance analysis was done by the simplified method. Full article

This article is about the Human-Centered Design (HCD), development and evaluation of an Artificial Intelligence (AI) algorithm aiming to support an adaptive management of Human-Machine Transition (HMT) between car drivers and vehicle automation. The general principle of this algorithm is to monitor (1) the drivers’ behaviors and (2) the situational criticality to manage in real time the Human-Machine Interactions (HMI). This Human-Centered AI (HCAI) approach was designed from real drivers’ needs, difficulties and errors observed at the wheel of an instrumented car. Then, the HCAI algorithm was integrated into demonstrators of Advanced Driving Aid Systems (ADAS) implemented on a driving simulator (dedicated to highway driving or to urban intersection crossing). Finally, user tests were carried out to support their evaluation from the end-users point of view. Thirty participants were invited to practically experience these ADAS supported by the HCAI algorithm. To increase the scope of this evaluation, driving simulator experiments were implemented among three groups of 10 participants, corresponding to three highly contrasted profiles of end-users, having respectively a positive, neutral or reluctant attitude towards vehicle automation. After having introduced the research context and presented the HCAI algorithm designed to contextually manage HMT with vehicle automation, the main results collected among these three profiles of future potential end users are presented. In brief, main findings confirm the efficiency and the effectiveness of the HCAI algorithm, its benefits regarding drivers’ satisfaction, and the high levels of acceptance, perceived utility, usability and attractiveness of this new type of “adaptive vehicle automation”. Full article

Damages of different kinds that can be inflicted to a parked car. Among them, loosening of the car wheel bolts is difficult to detect during normal use of the car and is at the same time very dangerous to the health and life of the driver. Moreover, in patents and publications, only little information is presented about electronic sensors available for activation from inside of the car to inform the driver about the mentioned dangerous situation. Thus, the main aim of this work is the proposition and examination of a sensing device using of a wireless accelerometer head to detect loosening of wheel fixing bolts before ride has been started. The proposed sensing device consists of a wireless accelerometer head, an assembly interface and a receiver unit. The assembly interface between the head and the inner part of the rim enables the correct operation of the system. The data processing algorithm developed for the receiver unit enables the proper detection of the unscrewing of bolts. Moreover, the tested algorithm is resistant to the interference signals generated in the accelerometer head by cars and men passing in close distance. Full article

This paper focuses on a thorough summary of vital function measuring methods in vehicles. The focus of this paper is to summarize and compare already existing methods integrated into car seats with the implementation of inter alia capacitive electrocardiogram (cECG), mechanical motion analysis Ballistocardiography (BCG) and Seismocardiography (SCG). In addition, a comprehensive overview of other methods of vital sign monitoring, such as camera-based systems or steering wheel sensors, is also presented in this article. Furthermore, this work contains a very thorough background study on advanced signal processing methods and their potential application for the purpose of vital sign monitoring in cars, which is prone to various disturbances and artifacts occurrence that have to be eliminated. Full article

Unobtrusive in-vehicle health monitoring has the potential to use the driving time to perform regular medical check-ups. This work intends to provide a guide to currently proposed sensor systems for in-vehicle monitoring and to answer, in particular, the questions: (1) Which sensors are suitable for in-vehicle data collection? (2) Where should the sensors be placed? (3) Which biosignals or vital signs can be monitored in the vehicle? (4) Which purposes can be supported with the health data? We reviewed retrospective literature systematically and summarized the up-to-date research on leveraging sensor technology for unobtrusive in-vehicle health monitoring. PubMed, IEEE Xplore, and Scopus delivered 959 articles. We firstly screened titles and abstracts for relevance. Thereafter, we assessed the entire articles. Finally, 46 papers were included and analyzed. A guide is provided to the currently proposed sensor systems. Through this guide, potential sensor information can be derived from the biomedical data needed for respective purposes. The suggested locations for the corresponding sensors are also linked. Fifteen types of sensors were found. Driver-centered locations, such as steering wheel, car seat, and windscreen, are frequently used for mounting unobtrusive sensors, through which some typical biosignals like heart rate and respiration rate are measured. To date, most research focuses on sensor technology development, and most application-driven research aims at driving safety. Health-oriented research on the medical use of sensor-derived physiological parameters is still of interest. Full article

This review provides an overview of unobtrusive monitoring techniques that could be used to monitor some of the human vital signs (i.e., heart activity, breathing activity, temperature and potentially oxygen saturation) in a car seat. It will be shown that many techniques actually measure mechanical displacement, either on the body surface and/or inside the body. However, there are also techniques like capacitive electrocardiogram or bioimpedance that reflect electrical activity or passive electrical properties or thermal properties (infrared thermography). In addition, photopleythysmographic methods depend on optical properties (like scattering and absorption) of biological tissues and—mainly—blood. As all unobtrusive sensing modalities are always fragile and at risk of being contaminated by disturbances (like motion, rapidly changing environmental conditions, triboelectricity), the scope of the paper includes a survey on redundant sensor arrangements. Finally, this review also provides an overview of automotive demonstrators for vital sign monitoring. Full article

Typical active safety systems that control the dynamics of passenger cars rely on the real-time monitoring of the vehicle sideslip angle (VSA), together with other signals such as the wheel angular velocities, steering angle, lateral acceleration, and the rate of rotation about the vertical axis, which is known as the yaw rate. The VSA (also known as the attitude or “drifting” angle) is defined as the angle between the vehicle’s longitudinal axis and the direction of travel, taking the centre of gravity as a reference. It is basically a measure of the misalignment between vehicle orientation and trajectory; therefore, it is a vital piece of information enabling directional stability assessment, such as in transience following emergency manoeuvres, for instance. As explained in the introduction, the VSA is not measured directly for impracticality, and it is estimated on the basis of available measurements such as wheel velocities, linear and angular accelerations, etc. This work is intended to provide a comprehensive literature review on the VSA estimation problem. Two main estimation methods have been categorised, i.e., observer-based and neural network-based, focussing on the most effective and innovative approaches. As the first method normally relies on a vehicle model, a review of the vehicle models has been included. The advantages and limitations of each technique have been highlighted and discussed. Full article
