High-pier partially cable-stayed bridges, with their significant pier heights and relatively low structural stiffness and stability, experience pronounced vehicle–bridge coupling effects during vehicle transit, influencing their dynamic response and safety. This study developed a co-simulation analysis program using easy language and ANSYS to investigate the dynamic behavior of a prestressed concrete five-tower partially cable-stayed bridge under vehicle–bridge interaction, considering factors such as vehicle speed, bridge deck grade, and cable force. The research findings indicate that a reduction in bridge deck grade leads to increases in peak dynamic responses and impact factors, with the dynamic amplification factor showing a deteriorating trend across all cross-sections. Structural responses fluctuate with vehicle speed and exhibit sensitivity to speed variations, with the maximum response observed at a speed of 80 km/h. Adjusting cable forces can reduce the impact factor: a 5% change in cable tension causes the mid-span impact factor to drop sharply from 0.38 to 0.04, a substantial decrease of 89.5%. The structural system can exert an impact on the impact factor by as much as several times: while the dynamic displacement and bending moment of the fixed system are smaller than those of the continuous beam system, its impact factor is as high as 4.22 times that of the continuous beam system. Additionally, dynamic responses are closely related to the position of the fixed bearing, with responses near the fixed bearing being reduced. Notably, the maximum impact factors of critical sections all exceed the 0.05 limit specified in the code for this type of bridge, with values of 0.54 at the mid-span, 0.91 at the pier top, and 0.43 at the tower top anchor zone. This indicates that the provisions regarding dynamic amplification factors in the current code are inappropriate for such bridges. The difference in impact factors between bridge components can reach 2.12 times, this indicates that specific impact factors should be assigned to individual components to achieve an optimal balance between safety and economic performance. Full article

Structural health monitoring (SHM) is vital for ensuring structural integrity by continuously evaluating conditions through sensor data. However, sensor anomalies caused by external disturbances can severely compromise the effectiveness of SHM systems. Traditional anomaly detection methods face significant challenges due to reliance on large labeled datasets, difficulties in handling long-term dependencies, and issues stemming from class imbalance. To address these limitations, this study introduces a hierarchical attention Transformer (HAT)-based method specifically designed for sensor anomaly detection in SHM applications. HAT leverages hierarchical temporal modeling with local and global Transformer encoders to effectively capture complex, multi-scale anomaly patterns. Evaluated on a real-world dataset from a large cable-stayed bridge, HAT achieves superior accuracy (96.3%) and robustness even with limited labeled data (20%), significantly outperforming traditional models like CNN, LSTM, and RNN. Additionally, this study visualizes the convergence process of the model, demonstrating its fast convergence and strong generalization capabilities. Thus, the proposed HAT method provides a practical and effective solution for anomaly detection in complex SHM scenarios. Full article

Although through tied-arch bridges exhibit strong structural robustness, collapse incidents triggered by the progressive failure of hangers still occasionally occur. Given that such bridges are unlikely to collapse due to the damage of a single or multiple hangers under the serviceability limit state, this study focuses on the failure safety limit state. Using the Nanfang’ao Bridge with inclined hangers and the Liujiang Bridge with vertical hangers as case studies, this paper investigates the dynamic response and failure modes of the residual structures when single or multiple hangers fail and initiate progressive collapse of all hangers. The results demonstrate that the configuration of hangers significantly influences the distribution of structural importance coefficients and the load transmission paths. Under identical failure scenarios, the Nanfang’ao Bridge with inclined hangers remains stable after the failure of four hangers without experiencing progressive collapse, whereas the Liujiang Bridge with vertical hangers undergoes progressive failure following the loss of only three hangers, which indicates that inclined hanger configurations offer superior resistance to progressive collapse. Based on the aforementioned analysis, the LS-DYNA Simple–Johnson–Cook damage model was employed to simulate the collapse process. The extent of damage and ultimate failure modes of the two bridges differ significantly. In the case of the Nanfang’ao Bridge, following the progressive failure of the hangers, the bridge deck system lost lateral support, leading to excessive downward deflection. The deck subsequently fractured at the mid-span (1/2 position) and collapsed in an inverted “V” shape. This failure then propagated to the tie bar, inducing outward compression at the arch feet and tensile stress in the arch ribs. Stress concentration at the connection between the arch columns and arch rings ultimately triggered global collapse. For the Liujiang Bridge, failure initiated with localized concrete cracking, which propagated to reinforcing bar yielding, resulting in localized damage within the bridge deck system. These observations indicate that progressive stay cable failure serves as the common initial triggering mechanism for both bridges. However, differences in the structural configuration of the bridge deck systems, the geometry of the arch ribs, and the constraint effects of the tie bar result in distinct failure progression patterns and ultimate collapse behaviors between the two structures. Thereby, design recommendations are proposed for through tied-arch bridges, from the aspects of the hanger, arch rib, bridge deck system, and tie bar, to enhance the resistance to progressive collapse. Full article

To enhance the bearing capacity of cable–pylon anchorage zones in cable-stayed bridges, this paper proposes the integral steel wall plate (IWP) structure and investigates the structural performance of its application in anchorage zones with a steel anchor beam and with a steel anchor box. The proposed structure contains an end plate, a surface plate, and several perforated side plates, forming steel cabins that encase the concrete pylon wall, where the steel and concrete are connected by perfobond connectors on side plates. A half-scaled experiment and a finite element analysis were first conducted on the IWP with the steel anchor beam to study the deformation at the steel–concrete interface, as well as the stress distribution in steel plates and rebars. The results were compared with experimental data of a conventional type of anchorage zone. Then, finite element models of anchorages with steel anchor boxes were established based on the geometries of an as-built bridge, and the performance of the IWP structure was compared with conventional details. Finally, the effects of plate thickness and connector arrangement were investigated. Results show that the proposed IWP structure offers excellent performance when applied with an anchor beam or anchor box, and it can effectively reduce principal tensile stress on the concrete pylon wall compared with conventional anchorage details. Full article

The displacement of bridge towers is relatively large under strong wind action. Changes in tower displacement can reflect the usage status of the bridge towers. Therefore, it is necessary to conduct performance warning research on tower displacement under strong wind action. In this paper, the triple standard deviation method, multiple linear regression method, and interpolation method are used to preprocess monitoring data with skipped points and missing anomalies. An improved multi-rate data fusion method, validated using simulated datasets, was applied to correct monitoring data at bridge tower tops. The fused data were used to feed predictive models and generate structural performance alerts. Spectral analysis confirmed that the fused displacement measurements achieve high precision by effectively merging the low-frequency GPS signal with the high-frequency accelerometer signal. Structural integrity monitoring of wind-loaded bridge towers used modeling residuals as alert triggers. The efficacy of this proactive monitoring strategy has been quantitatively validated through statistical evaluation of alarm accuracy rates. Full article

The corrosion of high-strength steel wires is a key factor impacting the durability and reliability of cable-stayed bridges. In this study, the corrosion pit features on a high-strength steel wire, which had been in service for 27 years, were extracted and modeled using three-dimensional point cloud data obtained through 3D surface scanning. The Otsu method was applied for image binarization, and each corrosion pit was geometrically represented as an ellipse. Key pit parameters—including length, width, depth, aspect ratio, and a defect parameter—were statistically analyzed. Results of the Kolmogorov–Smirnov (K–S) test at a 95% confidence level indicated that the directional angle component (θ) did not conform to any known probability distribution. In contrast, the pit width (b) and defect parameter (Φ) followed a generalized extreme value distribution, the aspect ratio (b/a) matched a Beta distribution, and both the pit length (a) and depth (d) were best described by a Gaussian mixture model. The obtained results provide valuable reference for assessing the stress state, in-service performance, and predicted remaining service life of operational stay cables. Full article

This study aims to develop an integrated wireless monitoring system named MANTiS-32, which leverages an open-source platform to enable autonomous modular operation, high-speed large-volume data transmission via Wi-Fi, and the integration of multiple complex sensors. The MANTiS-32 system is composed of ESP32-based MANTiS-32 hubs connected to eight MPU-6050 sensors each via RS485. Four MANTiS-32 hubs transmit data to a main PC through an access point (AP), making the system suitable for real-time monitoring of modal information necessary for structural performance evaluation. The fundamental performance of the developed MANTiS-32 system was validated to demonstrate its effectiveness. The evaluation included assessments of acceleration and frequency response measurement performance, wireless communication capabilities, and real-time data acquisition between the MANTiS-32 hub and the eight connected MPU-6050 sensors. To assess the feasibility of using MANTiS-32 for performance monitoring, a flexible model cable-stayed bridge, representing a mid- to long-span bridge, was designed. The system’s ability to perform real-time monitoring of the dynamic characteristics of the bridge model was confirmed. A total of 26 MPU-6050 sensors were distributed across four MANTiS-32 hubs, and real-time data acquisition was successfully achieved through an AP (ipTIME A3004T) without any bottleneck or synchronization issues between the hubs. Vibration data collected from the model bridge were analyzed in real time to extract dynamic characteristics, such as natural frequencies, mode shapes, and damping ratios. The extracted dynamic characteristics showed a measurement error of less than approximately 1.6%, validating the high-precision performance of the MANTiS-32 wireless monitoring system for real-time structural performance evaluation. Full article

Cable force distribution in cable-stayed bridges critically impacts structural safety and efficiency, yet traditional optimization methods struggle with unconventional designs due to nonlinear mechanics and computational inefficiency. This study proposes a hybrid approach combining Response Surface Methodology (RSM) and Multi-Objective Particle Swarm Optimization (MOPSO) to overcome these challenges. RSM constructs surrogate models for strain energy and mid-span displacement, reducing reliance on finite element analysis, while MOPSO optimizes Pareto solution sets for rapid cable force adjustment. Validated through an engineering case, the method reduces the main girder’s max bending moment by 8.7%, mid-span displacement by 31.2%, and strain energy by 7.1%, improving stiffness and mitigating stress concentrations. The response surface model demonstrates prediction errors of 0.35% for strain energy and 5.1% for maximum vertical mid-span deflection. By synergizing explicit modeling with intelligent algorithms, this methodology effectively resolves the longstanding efficiency–accuracy trade-off in cable force optimization for cable-stayed bridges. It achieves over 80% reduction in computational costs while enhancing critical structural performance metrics. Engineers are thereby equipped with a rapid and reliable optimization framework for geometrically complex cable-stayed bridges, delivering significant improvements in structural safety and construction feasibility. Ultimately, this approach establishes both theoretical substantiation and practical engineering benchmarks for designing non-conventional cable-stayed bridge configurations. Full article

Optimizing cable forces in cable-stayed bridges is challenging due to structural nonlinearity and the limitations of traditional methods, which often focus on isolated performance indicators. This study proposes an integrated framework combining Gaussian process regression (GPR) with an enhanced whale optimization algorithm improved by the Salp Swarm Algorithm (EWOSSA). GPR is first used to model the nonlinear relationship between cable forces and structural responses. The EWOSSA then efficiently optimizes the GPR-based model to identify optimal cable forces. A case study on a cable-stayed bridge with a 2 × 145 m main spans demonstrates the effectiveness of the proposed approach. Compared with conventional methods such as the internal-force equilibrium and zero-displacement methods, the EWOSSA-GPR framework achieves superior performance across multiple structural metrics. It ensures a more uniform cable force distribution, reduces girder displacements, and improves bending moment profiles, offering a comprehensive solution for optimal structural performance in cable-stayed bridges. Full article

Under prolonged loading and various environmental factors, the performance of stay cables gradually deteriorates, which impacts the safety of the bridge structure. To investigate the influence of cable damage on the static performance of cable-stayed bridges, a finite element model of a cable-stayed bridge with damaged cables was established. The element death method is used to simulate cable damage, examining the impact of various damage scenarios on the static performance of the cable-stayed bridge. The objective is to identify cable locations that have a greater impact on the structure, providing a basis for assessing the bridge’s safety and developing cable replacement strategies. The research indicates that damage to long cables has a more significant impact on the static performance of the cable-stayed bridge compared to damage to short cables. Additionally, damage to the side span cables has a more pronounced effect on the structure than damage to the mid-span cables. The influence of cable damage on cable forces is primarily reflected on the same side of the cable plane within the same bridge tower as the damaged cable. Changes in cable forces result in variations in the deflection of the main girder and the displacement of the main tower. When multiple cables are damaged, the impact on the static performance of the structure is similar to that of single-cable damage. In instances of longitudinal symmetric damage and adjacent cable impairment, the cables transition into a critical state, resulting in more pronounced alterations in the deflection of the main girder and the displacement of the main tower. Original symmetric damage has a relatively small impact on the static performance of the entire bridge, so it is recommended to adopt a symmetric approach for cable replacement projects. Considering the impact of damage to a single cable and multiple cables on the static structure, it is possible to initially determine the location and extent of the cable damage. Based on the damage patterns, a cable replacement plan can be designed. It is recommended to use a symmetry-based approach for the cable replacement, as this method results in minimal impact on the overall static performance of the bridge, thereby ensuring the safety of the bridge structure. Full article

Cable-stayed bridge cables experience significant tension over time, making the bridge cables prone to corrosion and fatigue. The direct measurement of cable length is not a standard capability in most current structural health monitoring systems, nor is long-term monitoring of cable changes. Bridge displacements are caused by both dynamic loads (wind and traffic) and quasi-static factors, primarily temperature. This study filtered out dynamic responses by the three-sigma rule, multiple linear regression, interpolation method, and not-a-number calibration. Monitoring data were used to analyze the bridge’s thermal field distribution and the time-dependent variation of tower displacements. Correlation analysis revealed a strong linear correlation between air temperature and quasi-static tower-girder displacements. This research proposes to use the tower-girder distance (effective cable length) to represent the length of the cable, take the thermal expansion coefficient of the effective length of the cable as the quantitative index for long-term monitoring, and take its error as the performance early warning indicator. This method effectively monitors cable health and provides damage warnings. Full article

Finite element (FE) model updating based on the response surface method using load test data of a cable-stayed bridge. This paper presents a case study of a cable-stayed bridge in which the FE model is refined using the response surface method based on experimental data from dead load and dynamic load tests. The elastic modulus and density of the main girder, tower, and cables are selected as the parameters to be updated, while the mid-span deflection and the first three vertical natural frequencies serve as the responses. The D-optimal experimental design is employed to generate test samples, and F-test analysis is performed to assess the significance of the parameters. The response surface equation is fitted using the least squares method, and the model’s accuracy is subsequently validated. The results show that the discrepancies between the FE model updating, and the experimental data are less than 3% for all responses, indicating a high degree of accuracy. This refined model demonstrates the effectiveness of the response surface method for improving the FE representation of the bridge. It can be applied in the field of damage detection, offering considerable practical value for bridge health monitoring. Full article

At present, the research on bridge structure health monitoring mainly focuses on discovering existing structural damage and less on predicting when the damage will occur in the future. This paper proposes a fatigue damage prognosis method for the main girders of cable-stayed bridges based on wavelet neural networks (WNNs). This method integrates WNN with multi-scale finite element modeling to predict fatigue damage progression. First, the theoretical foundation and implementation algorithms of the WNN are elaborated on and applied to forecast the future load environments of cable-stayed bridges. Subsequently, multi-scale finite element models are employed to derive stress influence lines for critical fatigue-prone regions in the main girder of the cable-stayed bridge. Finally, fatigue reliability methods are utilized to predict the fatigue reliability indices, service life, and failure probabilities of critical fatigue details. The proposed prognosis method in this paper can accurately predict the future operation conditions and remaining service life of bridge structures so as to provide a more reasonable maintenance strategy for bridge structures. Full article

Commonly, accelerometers are used to determine the tension force in cables through an indirect process; however, it is necessary to know the mechanical parameters of each element, such as mass and length. Typically, obtaining or measuring these parameters is not feasible. Therefore, this research proposed an alternative methodology to indirectly estimate them based on historical information about the so-called classic instruments (accelerometers and hydraulic jack). This case study focused on the Rio Papaloapan Bridge located in Veracruz, Mexico, a structure that has experienced material casting issues due to inadequate heat treatment in some cable top anchor over its lifespan. Thirteen cables from the structure were selected to evaluate the proposed methodology, yielding results within 3.8% of difference compared to direct tension estimation generated by a hydraulic jack. Furthermore, to enhance data collection, this process was complemented using a computer vision methodology. This involved remotely measuring the vibration frequency of cables from high-resolution videos recorded with a smartphone. The non-contact method was validated in a laboratory using a vibrating table, successfully estimating oscillation frequencies from video-recording with a fixed camera. A field test on eight cables of a bridge was also conducted to assess the performance and feasibility of the proposed method. The results demonstrated an RMS Error of approximately 2 mHz and a percentage difference in the tension force estimation below 3% compared to an accelerometer measurement approach. Finally, it was determined that this composed methodology for indirect tension force determination is a viable option when: (1) cables are challenging to access; (2) there is no line of sight between the camera and cables outside the bridge; (3) there is a lack of information about the mechanical parameters of the cables. Full article

Long-term processes, manifesting themselves in slow geometrical alterations and changes in internal forces, have been known and observed to take place mainly in large bridges made of prestressed concrete, but they also occur, albeit to a smaller degree, in steel bridges. Two sets of data, coming from, respectively, multi-year geodetic surveys and the structural health monitoring of a cable-stayed bridge (forces in its stays), were compared. Using the collocation method, displacements consistent with the results of the geodetic measurements were input into a numerical model of the bridge. Then, changes in the forces in the stays, which should accompany the displacements, were computed. The computed changes were compared with the actual changes in the mean force values in the stays of the bridge recorded over an eight-year period of its structural health monitoring. The two sets of data were found to be not in satisfactory good agreement. The main factors making it difficult to reach full agreement were the very small relative values of the observed geometrical alterations (the deformation, i.e., the increase in deflection, of the 375 m long span amounting merely 10–15 mm after eight years of periodic measurement) and the very small changes (amounting to about 0.5% for 8 years of monitoring) in the mean forces in the stays, as well as the possible mistakes in the survey. Despite these difficulties, the employed collocation method proved to be effective. It was also found that the long-term geometrical alterations and the changes in the forces in the stays do not adversely affect the safety of the bridge and its use. Full article
