As artificial intelligence (AI) advances, deep learning models are shifting from convolutional architectures to transformer-based structures, highlighting the importance of accurate floating-point (FP) calculations. Compute-in-memory (CIM) enhances matrix multiplication performance by breaking down the von Neumann architecture. However, many FPCIMs struggle to maintain high precision while achieving efficiency. This work proposes a high-precision hybrid floating-point compute-in-memory (Hy-FPCIM) architecture for Vision Transformer (ViT) through post-alignment with two different CIM macros: Bit-wise Exponent Macro (BEM) and Booth Mantissa Macro (BMM). The high-parallelism BEM efficiently implements exponent calculations in-memory with the Bit-Separated Exponent Summation Unit (BSESU) and the routing-efficient Bit-wise Max Finder (BMF). The high-precision BMM achieves nearly lossless mantissa computation in-memory with efficient Booth 4 encoding and the sensitivity-amplifier-free Flying Mantissa Lookup Table based on 12T Triple Port SRAM. The proposed Hy-FPCIM architecture achieves 23.7 TFLOPS/W energy efficiency and 0.754 TFLOPS/mm² area efficiency, with 617 Kb/mm² memory density in 28 nm technology. With almost lossless architectures, the proposed Hy-FPCIM achieves an accuracy of 81.04% in recognition tasks on the ImageNet dataset using ViT, representing a 0.03% decrease compared to the software baseline. This research presents significant advantages in both accuracy and energy efficiency, providing critical technology for complex deep learning applications. Full article

Multipliers are crucial components in digital processing and the arithmetic logic unit (ALU) of central processing unit (CPU) design. As the data bit length increases, the number of partial products in the multiplication process increases, resulting in an increased summation time for the partial products. Consequently, the speed of the multiplier circuit is adversely affected by increased time delays. In this article, we present a combined radix-4 Booth encoding module that employs metal–oxide–semiconductor (MOS) transistors that share common control signals to reduce the transistor count. In HSPICE simulations, the functionality of the proposed circuit architecture was verified, and the number of transistors used was successfully reduced. Full article

A multi-modulus architecture based on the radix-8 Booth encoding of a modulo (2ⁿ − 1) multiplier, a modulo (2ⁿ) multiplier, and a modulo (2ⁿ + 1) multiplier is proposed in this paper. It uses the original single circuit and shares many common circuit characteristics with a small extra circuit to carry out multi-modulus operations. Compared with a previous radix-4 study, the radix-8 architecture can increase the modulation multiplication encoding selection from three codes to four codes. This reduces the use of partial products from ⌊n/2⌋ to ⌊n/3⌋ + 1, but it increases the operation complexity for multiplication by three circuits. A hard multiple generator (HMG) is used to address this problem. Two judgment signals in the multi-modulus circuit can be used to perform three operations of the modulo (2ⁿ − 1) multiplier, modulo (2ⁿ) multiplier, and modulo (2ⁿ + 1) multiplier at the same time. The weighted representation is used to reduce the number of partial products. Compared with previously reported methods in the literature, the proposed approach can achieve better performance by being more area-efficient, being faster, consuming low power, and having a lower area-delay product (ADP) and power-delay product (PDP). With the multi-modulus HMG, the proposed modified architecture can save 34.48–55.23% of hardware area. Compared with previous studies on the multi-modulus multiplier, the proposed architecture can save 22.78–35.46%, 4.12–11.15%, 12.59–24.73%, 27.88–38.88%, and 20.49–27.85% of hardware area, delay time, dissipation power, ADP, and PDP, respectively. Xilinx field programmable gate array (FPGA) Vivado 2019.2 tools and the Verilog hardware description language are used for synthesis and implementation. The Xilinx Artix-7 XC7A35T-CSG324-1 chipset is adopted to evaluate the performance. Full article

The residue number system is widely used in applications such as communication systems, cryptography, digital filters, digital signal processors, fault-tolerant detection, and so on. This paper proposes a multifunction modulo (2ⁿ ± 1) multiplier based on the radix-4 Booth encoding scheme that can operate both modulo (2ⁿ − 1) and modulo (2ⁿ + 1) multipliers using the same hardware structure with only one control signal. A novel modulo (2ⁿ ± 1) multiplier based on radix-4 Booth encoding is proposed that can achieve superior performance, with low power, fast operation, high area efficiency, and low area-delay product (ADP) and power-delay product (PDP) compared with similar modified Booth-encoding methods. In addition, by integrating the separate modulo functions of the modulo (2ⁿ − 1) multiplier and modulo (2ⁿ + 1) multiplier into a single multifunction modulo (2ⁿ ± 1) multiplier, the proposed method can save up to 52.59% (n = 16) of hardware area, up to 5.45% (n = 32) of delay time, up to 49.05% (n = 16) of dynamic power, up to 50.92% (n = 32) of ADP, and up to 50.02% (n = 32) of PDP compared with the original separate circuits merged together. Furthermore, the operation ranges of the multiplicand and multiplier of the proposed modulo (2ⁿ + 1) multiplier and modulo (2ⁿ − 1) multiplier are {0, 2ⁿ + 1} and {0, 2ⁿ}, respectively, which are wider than for other reported hardware structures. The hardware area, power consumption, and delay time are simulated and verified using Verilog HDL and Xilinx FPGA (Field Programmable Gate Array) Vivado tools. The Xilinx Artix-7 XC7A35T-CSG324-1 FPGA chipset is adopted in the proposed work. Full article

Bit-serial multiply-accumulate units (MACs) play a crucial role in various hardware accelerator applications, including deep learning, image processing, and signal processing. Despite the advantages of bit-serial MACs, such as a small footprint, full hardware utilization, and high frequency, their serial nature can lead to high latency and potentially compromised performance. This study investigates the potential of bit-serial solutions by applying Booth encoding to bit-serial multipliers within MACs to enhance area and power efficiencies. We present two types of bit-serial MACs based on radix-2 and radix-4 Booth encoding multipliers, respectively. Their performance is assessed through simulations and synthesis results, demonstrating the benefits of the proposed approach. The radix-4 Booth bit-serial MAC improves power and area efficiencies compared to the original bit-serial MAC. Operating at TSMC 90 nm and 150 MHz, our design exhibits a remarkable 96.39% reduction in area-power-product (APP). Moreover, the prototype verification on a Xilinx Kintex-7 FPGA proved successful. The proposed solution offers significant advantages in energy efficiency, area reduction, and APP, making it a promising candidate for next-generation hardware accelerators in offline inference, low-power devices, and other applications. Full article

In this paper, we propose an area- and power-efficient reconfigurable architecture for multifunction evaluation based on an optimized piecewise linear (PWL) method. The proposed segmentor automatically divides nonlinear functions into the fewest segments with a predefined maximum absolute error (MAE) and fractional bit width of the slope. In addition, a multiplier was optimized via Booth encoding to reduce the number of rows in the partial product matrix. Compressors were used to shorten the critical path. The results of application-specific integrated circuit (ASIC) implementation reveal that all metrics of the proposed architecture are improved for single functions, without any compromise. Moreover, reconfigurable technology was introduced for implementing multiple functions while reusing computing resources. Compared to a corresponding architecture without reuse, the area and power of this reconfigurable architecture are reduced by 37.48% and 45.60%, respectively, at the same frequency. Full article

The data movement between the processing and storage units has been one of the most critical issues in modern computer systems. The emerging Resistive Random Access Memory (RRAM) technology has drawn tremendous attention due to its non-volatile ability and the potential in computation application. These properties make them a perfect choice for application in modern computing systems. In this paper, an 8-bit radix-4 non-volatile parallel multiplier is proposed, with improved computational capabilities. The corresponding booth encoding scheme, read-out circuit, simplified Wallace tree, and Manchester carry chain are presented, which help to short the delay of the proposed multiplier. While the presence of RRAM save computational time and overall power as multiplicand is stored beforehand. The area of the proposed non-volatile multiplier is reduced with improved computing speed. The proposed multiplier has an area of 785.2 $\mathsf{\mu }$m${}^2$ with Generic Processing Design Kit 45 nm process. The simulation results show that the proposed multiplier structure has a low computing power at 161.19 $\mathsf{\mu }$W and a short delay of 0.83 ns with 1.2 V supply voltage. Comparative analyses are performed to demonstrate the effectiveness of the proposed multiplier design. Compared with conventional booth multipliers, the proposed multiplier structure reduces the energy and delay by more than 70% and 19%, respectively. Full article

Pterygium is an eye condition that is prevalent among workers that are frequently exposed to sunlight radiation. However, most of them are not aware of this condition, which motivates many volunteers to set up health awareness booths to give them free health screening. As a result, a screening tool that can be operated on various platforms is needed to support the automated pterygium assessment. One of the crucial functions of this assessment is to extract the infected regions, which directly correlates with the severity levels. Hence, Group-PPM-Net is proposed by integrating a spatial pyramid pooling module (PPM) and group convolution to the deep learning segmentation network. The system uses a standard mobile phone camera input, which is then fed to a modified encoder-decoder convolutional neural network, inspired by a Fully Convolutional Dense Network that consists of a total of 11 dense blocks. A PPM is integrated into the network because of its multi-scale capability, which is useful for multi-scale tissue extraction. The shape of the tissues remains relatively constant, but the size will differ according to the severity levels. Moreover, group and shuffle convolution modules are also integrated at the decoder side of Group-PPM-Net by placing them at the starting layer of each dense block. The addition of these modules allows better correlation among the filters in each group, while the shuffle process increases channel variation that the filters can learn from. The results show that the proposed method obtains mean accuracy, mean intersection over union, Hausdorff distance, and Jaccard index performances of 0.9330, 0.8640, 11.5474, and 0.7966, respectively. Full article

A low complexity digital VLSI architecture for the computation of an algebraic integer (AI) based 8-point Arai DCT algorithm is proposed. AI encoding schemes for exact representation of the Arai DCT transform based on a particularly sparse 2-D AI representation is reviewed, leading to the proposed novel architecture based on a new final reconstruction step (FRS) having lower complexity and higher accuracy compared to the state-of-the-art. This FRS is based on an optimization derived from expansion factors that leads to small integer constant-coefficient multiplications, which are realized with common sub-expression elimination (CSE) and Booth encoding. The reference circuit [1] as well as the proposed architectures for two expansion factors α† = 4.5958 and α′ = 167.2309 are implemented. The proposed circuits show 150% and 300% improvements in the number of DCT coefficients having error ≤ 0:1% compared to [1]. The three designs were realized using both 40 nm CMOS Xilinx Virtex-6 FPGAs and synthesized using 65 nm CMOS general purpose standard cells from TSMC. Post synthesis timing analysis of 65 nm CMOS realizations at 900 mV for all three designs of the 8-point DCT core for 8-bit inputs show potential real-time operation at 2.083 GHz clock frequency leading to a combined throughput of 2.083 billion 8-point Arai DCTs per second. The expansion-factor designs show a 43% reduction in area (A) and 29% reduction in dynamic power (P_D) for FPGA realizations. An 11% reduction in area is observed for the ASIC design for α† = 4.5958 for an 8% reduction in total power (P_T ). Our second ASIC design having α′ = 167.2309 shows marginal improvements in area and power compared to our reference design but at significantly better accuracy. Full article
