Search Results (55)

Soft body armor (SBA) remains an essential component of first responder protection. However, most SBA design concepts do not adequately address the unique performance, morphological, and psychological needs of women as first responders. In this review, female-specific designs of ballistic-resistant panels, material systems, and SBA performance testing are critically examined. The paper also explores innovations in shaping and design techniques, including darting, dartless shape construction, modular assembly, and body scanning with CAD integration to create contoured and structurally stable panels with improved coverage, reduced bulk, and greater mobility. In addition, the review addresses broadly used and emerging dry textile fabrics and fiber-reinforced polymers, considering various innovations, such as 3D warp interlock weave, shear thickening fluid (STF) coating, nanomaterials, and smart composites that improve energy dissipation and impact tolerance without sacrificing flexibility. In addition, the paper also examines various emerging ballistic performance testing standards and their revisions to incorporate gender-specific standards and measures their ability to decrease trauma effects and maintain flexibility and practical protection. Finally, it identifies existing challenges and areas of future research, such as optimizing multi-layer systems, addressing fatigue behavior, and improving multi-angle and low-velocity impact performance while providing avenues for future sustainable, adaptive, and performance-optimized body armor. Full article

Dynamic stab resistance is a critical property for protective textiles and fibrous composites used in body armor and protective gear applications. This is also a very complex property that depends on various factors, including material properties, structural design, and external impact conditions. This review paper presents an in-depth investigation into the dynamic stab impact response and performance of textile and composite materials, focusing on the influences of various endogenous and exogenous parameters. Material-level factors, including material type and properties, fiber orientation, yarn density, textile architecture, chemical treatments, and coatings, are reviewed. In addition, the influence of external conditions, including impact velocity and energy, blade shape and type, impact condition, and impact angles on the stab resistance of the protective materials are discussed. The interplay of these factors significantly affects penetration resistance, energy absorption, and trauma mitigation. This paper further discusses different stab resistance testing methods and standards on various kinds of protective materials and relatively compared the efficiencies of each. Current challenges on flexibility versus protection and future research directions necessary to realize advances in protective textiles with dynamic stab resistance are debated. The present comprehensive analysis gives useful insights to engineers, manufacturers, researchers, and standard makers for selecting, developing, and testing protective textiles and fibrous composite materials with improved stab protection applications. Full article

The development of efficient and sustainable armor systems is crucial for protecting bodies and vehicles. In this study, epoxy composites reinforced with natural lignocellulosic fibers (NLFs) from carnauba (Copernicia prunifera) were produced with 0, 10, 20, 30, and 40% fiber volume fractions. Their ballistic performance was evaluated by measuring residual velocity and absorbed energy after impact with 7.62 mm ammunition, as well as their application in a multilayer armor system (MAS). Scanning electron microscopy (SEM) was used to analyze fracture regions, and explicit dynamic simulations were performed for comparison with experimental tests. Residual velocity tests indicated a limit velocity (V_L) between 213 and 233 m/s and absorbed energy (E_abs) between 221 and 264 J, surpassing values reported for aramid fabric. All formulations showed indentation depths below the National Institute of Justice (NIJ) limit, with the 40% fiber sample achieving the lowest depth (31.2 mm). The simulation results correlated well with the experimental data, providing insight into deformation mechanisms during a level III ballistic event. These findings demonstrate the high potential of carnauba fibers in epoxy-based polymer composites, particularly as an intermediate layer in MAS, offering a sustainable alternative for ballistic protection. Full article

The aim of this work is to comparatively analyze, using numerical simulation, the impact behavior of aramid fabric. A layered panel was impacted by two projectiles specific to the NIJ protection level HG1. The protection level in this study is based on NIJ Standard 0123.00. This standard is used to establish protection levels. The two projectiles specific to the NIJ HG1 protection level are 9 mm Luger and .357 Mag FMJ. Law enforcement personnel use body armor designed to protect the torso. With the help of numerical simulation, the mechanisms of destruction of the aramid fabric on impact are identified. The protection performance is analyzed as a function of the influence of the number of layers and the projectile velocity variation. The fabric is modeled at the yarn level, with each yarn consisting of hundreds or even thousands of fibers. Simulations are performed at the yarn level, since fiber-level modeling is difficult to implement due to high computational resource requirements. The material properties for the yarn, as well as for the projectiles, are selected from the literature. The results show that only the 20-layer fabric panel impacted by the 9 mm Luger FMJ RN 9 mm FMJ RN projectile at 398 m/s meets the protection requirements of the NIJ standard (NIJ HG1 protection level). In contrast, panels impacted at 436 m/s, or those with fewer layers, show rapid stress wave propagation, severe deformation, and complete perforation, indicating insufficient energy dissipation. This study highlights the critical role of impact velocity, projectile geometry, and number of layers in determining ballistic resistance. These findings contribute to the development of more effective ballistic protective equipment, highlighting the need for optimized layer configurations and improved material properties to meet NIJ standards under different impact conditions. Full article

The material properties and structural characteristics of ballistic composites are crucial to their ballistic performance. A numerical model of a 1.1 g FSP penetrating a UHMWPE target plate was established in this paper. The numerical results show that the failure process of the body armor target plate primarily involves shear failure, interlayer delamination, and tensile failure. Based on this, further research was conducted on the influence of material properties and structural characteristics on the ballistic limit velocity of the UHMWPE armor plate. Furthermore, the study evaluates the effects of elastic modulus, tensile strength, shear strength, number of layers, and interlayer strength on the ballistic limit velocity of UHMWPE body armor. The findings reveal that the ballistic limit velocity is most sensitive to changes in shear strength, with variation rates ranging from −18% to +11%, showing an approximate positive correlation, while the elastic modulus has the smallest impact on ballistic limit velocity, with variation rates ranging from −2% to +4%. Additionally, appropriate interlayer strength can improve the ballistic limit velocity of the body armor to a certain extent. This study provides theoretical methods and recommendations for optimizing anti-penetration performance of UHMWPE body armor. Full article

The development of ballistic materials has improved very rapidly in the last few years. Body armor plays an important role in protecting individuals during military threats. Body armor can be divided into hard and soft variants depending on the trade-offs between protection levels and wearer agility. Current research aims to optimize strength-to-weight ratios by using different combinations of synthetic or natural fibers or their combinations to achieve increasingly demanding requirements for ballistic materials. Moreover, it examines the various types of fibers utilized in the construction of body armor, ranging from traditional materials like metal and ceramic to synthetic and natural fibers. This paper discusses ongoing research efforts aimed at further enhancing the performance of these materials, such as the incorporation of modified natural fibers into advanced composite systems. The review provides a comprehensive analysis of the current state of the materials utilized in ballistic protection. Full article

Shear thickening fluids (STFs) have garnered attention as potential enhancers of protective capabilities and for the optimization of Kevlar^® armor design. To assess the possible shear thickening properties and potential application in ballistic protection, ten formulations were developed by employing polyethylene glycol (PEG) or polypropylene glycol (PPG), along with fumed silica or Aerosil HDK^®. Rheological characterization facilitated the identification of formulations displaying shear thickening behavior. The potential integration of the selected shear thickening fluids (STFs) into Kevlar^®-based composites was investigated by studying the impact resistance of Kevlar^® soft armor structures. Also, high-velocity impact testing revealed that the distance between aramid layers plays a crucial role in the impact resistance effectiveness of Kevlar^®–STF composite structures and that there is a very narrow domain between optimal and undesired scenarios in which STF could facilitate the penetration of Kevlar. The introduction of STF between the Kevlar sheets disrupted this packing and the energy absorption capacity of the material was not improved. Only one formulation (PEG400, Aerosil 27 wt.%) led to a less profound traumatic imprint and stopped the bullet when it was placed between layers no.1 and no.2 from a total of 11 layers of Kevlar XP. These experimental findings align with the modeling and simulation of Kevlar^®–STF composites using Ansys simulation software (Ansys® AutoDyn 2022 R2). Full article

The optimization of the process of polymer film orientational drawing using the local heater was investigated. One of the problems with this technology is that the strength of the resulting fibers differs significantly from the theoretical estimates. It is assumed that one of the reasons is related to the peculiarity of this technology, when at the point of drawing the film is heated only on one side, which creates a temperature difference between the sides of the film in contact with the heater and the non-contact sides of the film in the air. Estimates show that even a small temperature difference of just 1 °C between these surfaces leads to a significant difference in the rate of plastic deformation of the corresponding near-surface layers. As a consequence, during hardening, in the stretching region, tensile stress is concentrated on the “cold” side of the film, and this effect can presumably lead to the generation of more defects overthere. It has been suggested that defects arising during first stage of hardening, namely, neck formation, can serve as a trigger for the formation of defects such as kink bands on the “cold” side with further orientational strengthening due to plastic deformation of the resulting fibrillar structure, at the boundaries of which microcracks are formed, leading to rupture of the oriented sample. The numerical calculation of heat propagation due to heat conduction in the film from the local surface of the heater is carried out and the temperature distribution along the thickness and width of the film during drawing is found. The temperature difference in the heated layer of the film between the contact and non-contact sides with the heater was calculated depending on the thickness of the film and the speed of its movement along the heater. It was found that the most homogeneous temperature distribution over the film thickness, which is required, by default, for the synchronous transformation of the unoriented initial folded lamellar structure into a fibrillar structure, is observed only for films with a thickness of less than 50 μm. The calculation allows us to scientifically justify the choice of orientation drawing speed and optimal thickness of the oriented polymer film, which is extremely important, for example, for obtaining super-strong and high-modulus UHMWPE filaments used in products for various purposes: from body armor to sports equipment and bioimplants, Full article

The development of Ballistic Protection Vests (BPVs) has gained significant attention, particularly focusing on the design of Ballistic Protection Soft Panels (BPSPs), which are crucial to the overall size and configuration of these vests. Despite their critical role, there is a noticeable lack of a standardized design method for surface area patterns of BPSPs in the existing literature. The findings indicate that the National Institute of Justice (NIJ) standard 0101.06 Ballistic Test Templates (BTTs) are only partially applicable to the design of BPSP patterns. While the NIJ standard 0101.06 provides a useful framework, it requires adaptation to meet the specific needs of regional body types and the practicalities of BPV manufacturing. This research aims to address this gap by assessing the suitability of NIJ BTTs for the design of BPSPs and BPVs and to develop a standardized pattern design methodology along with a method for calculating the surface area of the soft amour prior to its creation. Results have to be achieved ready for the production of BPSP patterns tailored to the body types of regional soldiers while adhering to relevant standards and soldier’s physical comfort, thereby saving time and resources for manufacturers and researchers. In this study, we evaluated the applicability of the NIJ standard 0101.06 BTT for configuring these templates into the cutting patterns of BPSPs. To achieve this, patterns for BPSPs were designed and the feasibility of using NIJ BTTs for their configuration was analyzed. The research process involved a comprehensive literature review, an analysis of the dimensions of existing BPV soft panels, and a comparison with NIJ standard 0101.06 BTT. The design and scaling of the panel patterns were executed using computer-aided design (CAD) systems and evaluated through both physical fitting on mannequins and virtual fitting using the Clo3D program. The developed pattern-making methodology includes size specifications tailored to regional covers, incorporating a coefficient K identified to calculate the BPSP surface area prior to design. This approach not only ensures better fitting for the physical comfort and protection of soldiers but also saves time and resources in the manufacturing process of BPSPs. The proposed design methodology offers a significant step forward in standardizing BPSP patterns, promising enhanced protection and efficiency in BPV manufacturing. Full article

Medieval combat sport is a form of mixed martial art in which combatants engage in fighting using offensive and defensive equipment while dressed in full armor. The sport is considered extremely taxing, making it nearly impossible to maintain the same level of performance. However, this form of sport has not been thoroughly analyzed, and its impact on human physical response is largely unknown. To address this gap, the study reported here aimed to introduce and test a procedure for analyzing human physical responses within the framework of the sport. To accomplish this, two experienced combatants were asked to engage in a series of strikes, performed in the form of a set duel simulating a professional fight competition. The kinematic aspect of the procedure was examined using motion analysis with the help of an IMU suit, while the physiological aspect was evaluated based on blood lactate levels and heart rate measurements. Furthermore, an ergometer test conducted in a laboratory setting aimed to determine the lactate threshold. The duel results showed noticeable decreases in the kinematic aspects of the strikes, such as the velocity of impact, and a dramatic rise in physiological aspects, such as heart rate and blood lactate levels. During the duel sets, the blood lactate surpassed the threshold level, and at the end, the heart rate exceeded the maximum age-related level. Practicing medieval combat sport has been shown to impose an extreme physical load on the bodies of combatants, noticeably affecting their performance levels. Full article

This paper presents research on several factors influencing the stabbing behaviour of stratified panels made of aramid fabric Twaron^® SRM509 Teijin Aramid BV (Arnhem, The Netherlands). The inputs in the test campaign were the number of layers, the impact energy, and the sample size. Tests were performed on small samples (130 mm × 130 mm) on an Instron^® CEAST 9350 drop-tower impact system (Norwood, MA, USA) and on larger samples (400 mm × 400 mm) using a test installation with the same values of the impact energy. Knife type S1 was used, with the geometry recommended in NIJ Standard 0115.00 Stab Resistance of Body Armor SEM, and macro photography investigations revealed the failure mechanisms of panel, layers and fibres. A very important conclusion of this study regarding the stabbing performance of fabric Twaron^® SRM 509 in particular, but also in general for panels for body protection is that a research study could start on small size samples, with an accurately instrumented machine, in order to establish the influence of significant factors of stab resistance (energy level, number of layers in a panel, etc.), as these samples are less expensive and less time consuming, but the study should be continued to examine larger size samples. The obtained data are useful for the prototype. Full article

The incorporation of ductile reinforcements into ceramics helps restrain crack deflection, which can enhance ceramics’ toughness and overcome the matrix’s brittleness. In this paper, we produced a ceramic composite reinforced by carbon fibers coated by multi-wall carbon nanotubes (shortened by C_f-MWCNT/SiC composites) for enhanced impact resistance at a high strain rate that commonly occurs in composite materials used in astronautics, marine, and other engineering fields. The fabrication process involves growing multi-wall carbon nanotubes (MWCNTs) on a carbon fiber woven fabric (C_f) to create the fibril/fabric hybrid reinforcement. It is then impregnated by polymer solution (precursor of the ceramics), forming composites after the pyrolysis process, known as the liquid polymer infiltration and pyrolysis (PIP) technique. To assess the impact resistance of the C_f-MWCNT/SiC under high-strain rate compressions, the split Hopkinson pressure bar (SHPB) technique is employed. Since the failure behavior of the C_f-MWCNT/SiC composites in the absence of the ductile phase is not well understood, the study employs the Hilbert–Huang transform (HHT) to analyze the stress–time curves obtained from the SHPB experiments. By applying the HHT, we obtained the frequency–time spectrum and the marginal Hilbert spectrum of the stress signals. These analyses reveal the frequency characteristics of the C_f-MWCNT/SiC composite and provide insights into the relationship between transformed signal frequency and fracture behavior. By understanding the dynamic fracture behavior and frequency response of the C_f-MWCNT/SiC, it becomes possible to enhance its impact resistance and tailor its performance for specific protective requirements. Therefore, the findings of this study can guide the future design and optimization of C_f-MWCNT/SiC structures for various protective applications, such as body armor, civil structures, and protections for vehicles and aircraft. Full article

Despite recent advances in the molecular knowledge of amphistome trematodes, most genera known from fish remain to be genetically characterized. This is the case for Kalitrema, a genus of the speciose family Cladorchiidae and the type of Kalitrematinae. The type and only species of this genus, Kalitrema kalitrema Travassos, 1933, was originally proposed based on two specimens found in an armored suckermouth catfish from Brazil, and its phylogenetic position has not been evaluated. In this study, paramphistomes found in Hypostomus alatus (2/9; 22.2%) and Hypostomus francisci (4/143; 2.8%) from the Paraobepa River (São Francisco River basin), Minas Gerais, Brazil, between December 2019 and November 2021, were subjected to morphological study. The parasites were identified in low intensity of infection [1.2 (1–2)] and redescribed as K. kalitrema. This species exhibits unique features such as a linguiform body with a circular ridge near the anterior end and a deep, median notch present at the posterior extremity of the body, apparently dividing the body into two lobes. A subset of specimens was further subject to phylogenetic analyses based on the most densely sampled markers, the nuclear ribosomal RNA (28S and ITS2) and mitochondrial cox1, which revealed the inclusion of K. kalitrema in a Neotropical clade of fish paramphistomes. The most comprehensive phylogenetic tree, based on the 28S dataset, confirmed K. kalitrema as an independent, early diverging lineage among Neotropical fish cladorchiids. However, the monophyly of Kalitrematinae was not sustained, given that species of the other kalitrematine genera Pseudocladorchis and Iquitostrema included in the phylogenetic analysis fell in a distinct clade with other fish cladorchiids. As a result, we propose here a narrower concept for Kalitrematinae sensu stricto, accommodating only Kalitrema (type genus) until a more natural subfamilial or familial classification is provided. Full article

Poly(p-phenylene terephthalamide) (PPTA) and ultra-high-molecular-weight polyethylene (UHMWPE) are high-performance polymer materials largely used for body armor applications. Although composite structures from a combination of PPTA and UHMWPE have been created and described in the literature, the manufacture of layered composites from PPTA fabrics and UHMWPE films with UHMWPE film as an adhesive layer has not been reported. Such a new design can provide the obvious advantage of simple manufacturing technology. In this study, for the first time, we prepared PPTA fabrics/UHMWPE films laminate panels using plasma treatment and hot-pressing and examined their ballistic performance. Ballistic testing results indicated that samples with moderate interlayer adhesion between PPTA and UHMWPE layers exhibited enhanced performance. A further increase in interlayer adhesion showed a reverse effect. This finding implies that optimization of interface adhesion is essential to achieve maximum impact energy absorption through the delamination process. In addition, it was found that the stacking sequence of the PPTA and UHMWPE layers affected ballistic performance. Samples with PPTA as the outermost layer performed better than those with UHMWPE as the outermost layer. Furthermore, microscopy of the tested laminate samples showed that PPTA fibers exhibited shear cutting failure on the entrance side and tensile failure on the exit side of the panel. UHMWPE films exhibited brittle failure and thermal damage at high compression strain rate on the entrance side and tensile fracture on the exit side. For the first time, findings from this study reported in-field bullet testing results of PPTA/UHMWPE composite panels, which can provide important insights for designing, fabricating, and failure analysis of such composite structures for body armors. Full article

Shear thickening fluid (STF) is a dense colloidal suspension of nanoparticles in a carrier fluid in which the viscosity increases dramatically with a rise in shear rate. Due to the excellent energy absorption and energy dissipation of STF, there is a desire to employ STFs in a variety of impact applications. In this study, a comprehensive review on STFs’ applications is presented. First, several common shear thickening mechanisms are discussed in this paper. The applications of different STF impregnated fabric composites and the STF’s contributions on improving the impact, ballistic and stab resistance performance have also been presented. Moreover, recent developments of STF’s applications, including dampers and shock absorbers, are included in this review. In addition, some novel applications (acoustic structure, STF-TENG and electrospun nonwoven mats) based on STF are summarized, to suggest the challenges of future research and propose some more deterministic research directions, e.g., potential trends for applications of STF. Full article
