Search Results (18)

Background: Biomechanical and neuromuscular differences between falls and recoveries have been well-studied; however, the cortical correlations remain unclear. Using mobile brain imaging via electroencephalography (EEG), we examined differences in sensorimotor beta frequencies between falls and recoveries during an unpredicted slip in walking. Methods: We recruited 22 young adults (15 female; 18–35 years) who experienced a slip (65 cm) during walking. Raw EEG signals were band-pass filtered, and independent component analysis was performed to remove non-neural sources, eventually three participants were excluded due to excessive artifacts. Peak beta power was extracted from three time-bins: 400 milliseconds pre-, 0–150 milliseconds post and 150–300 milliseconds post-perturbation from the midline (Cz) electrode. A 2 × 3 Analysis of Covariance assessed the interaction between time-bins and group on beta power, followed by Independent and Paired t-tests for between and within-group post hoc comparisons. Results: All participants (n = 19) experienced a balance loss, seven experienced a fall. There was a time × group interaction on beta power (p < 0.05). With no group differences pre-perturbation, participants who experienced a fall exhibited higher beta power during 0–150 milliseconds post-perturbation than those who recovered (p < 0.001). However, there were no group differences in beta power during 150–300 milliseconds post-perturbation. Conclusions: Young adults exhibiting a greater increase in beta power during the early post-perturbation period experienced a fall, suggesting a higher cortical error detection due to a larger mismatch in the expected and ongoing postural state and greater cortical dependence for sensorimotor processing. Our study results provide an overview of the possible cortical governance to modulate slip-fall/recovery outcomes. Full article

This paper presents a symmetry-driven broadband circularly polarized magnetoelectric dipole antenna with bandpass filtering response, where the principle of symmetry is strategically employed to enhance both radiation and filtering performance. The antenna’s circular polarization is achieved through a symmetrical arrangement of two orthogonally placed metallic ME dipoles combined with a phase delay line, creating balanced current distributions for optimal CP characteristics. The design further incorporates symmetrical parasitic elements—a pair of identical inverted L-shaped metallic structures placed perpendicular to the ground plane at −45° relative to the ME dipoles—which introduce an additional CP resonance through their mirror-symmetric configuration, thereby significantly broadening the axial ratio bandwidth. The filtering functionality is realized through a combination of symmetrical modifications: grid slots etched in the metallic ground plane and an open-circuited stub loaded on the microstrip feed line work in tandem to create two radiation nulls in the upper stopband, while the inherent symmetrical properties of the ME dipoles naturally produce a radiation null in the lower stopband. This comprehensive symmetry-based approach results in a well-balanced bandpass filtering response across a wide operating bandwidth. Experimental validation through prototype measurement confirms the effectiveness of the symmetric design with compact dimensions of 0.96${\lambda }_0$ × 0.55${\lambda }_0$ × 0.17${\lambda }_0$ (${\lambda }_0$ is the wavelength at the lowest operating frequency), demonstrating an impedance bandwidth of 66.4% (2.87–5.05 GHz), an AR bandwidth of 31.9% (3.32–4.58 GHz), an average passband gain of 5.5 dBi, and out-of-band suppression levels of 11.5 dB and 26.8 dB at the lower and upper stopbands, respectively, along with good filtering performance characterized by a gain-suppression index (GSI) of 0.93 and radiation skirt index (RSI) of 0.58. The proposed antenna is suitable for satellite communication terminals requiring wide AR bandwidth and strong interference rejection in L/S-bands. Full article

Underwater object detection with Synthetic Aperture Sonar (SAS) images faces many problems, including low contrast, blurred edges, high-frequency noise, and missed small objects. To improve these problems, this paper proposes a high-accuracy underwater object detection algorithm for SAS images, named the HAUOD algorithm. First, considering SAS image characteristics, a sonar preprocessing module is designed to enhance the signal-to-noise ratio of object features. This module incorporates three-stage processing for image quality optimization, and the three stages include collaborative adaptive Contrast Limited Adaptive Histogram Equalization (CLAHE) enhancement, non-local mean denoising, and frequency-domain band-pass filtering. Subsequently, a novel C2fD module is introduced to replace the original C2f module to strengthen perception capabilities for low-contrast objects and edge-blurred regions. The proposed C2fD module integrates spatial differential feature extraction, dynamic feature fusion, and Enhanced Efficient Channel Attention (Enhanced ECA). Furthermore, an underwater multi-scale contextual attention mechanism, named UWA, is introduced to enhance the model’s discriminative ability for multi-scale objects and complex backgrounds. The proposed UWA module combines noise suppression, hierarchical dilated convolution groups, and dual-dimensional attention collaboration. Experiments on the Sonar Common object Detection dataset (SCTD) demonstrate that the proposed HAUOD algorithm achieves superior performance in small object detection accuracy and multi-scenario robustness, attaining a detection accuracy of $95.1\%$, which is $8.3\%$ higher than the baseline model (YOLOv8n). Compared with YOLOv8s, the proposed HAUOD algorithm can achieve $6.2\%$ higher accuracy with only $50.4\%$ model size, and reduce the computational complexity by half. Moreover, the HAUOD method exhibits significant advantages in balancing computational efficiency and accuracy compared to mainstream detection models. Full article

In equine surface electromyography (sEMG), challenges related to the reliability and interpretability of data arise, among other factors, from methodological differences, including signal processing and analysis. The aim of this study is to demonstrate the filtering–induced changes in basic signal features in relation to the balance between signal loss and noise attenuation. Raw sEMG signals were collected from the quadriceps muscle of six horses during walk, trot, and canter and then filtered using eight filtering methods with varying cut–off frequencies (low–pass at 10 Hz, high–pass at 20 Hz and 40 Hz, and bandpass at 20–450 Hz, 40–450 Hz, 7–200 Hz, 15–500 Hz, and 30–500 Hz). For each signal variation, signal features—such as amplitude, root mean square (RMS), integrated electromyography (iEMG), median frequency (MF), and signal–to–noise ratio (SNR)—along with signal loss metrics and power spectral density (PSD), were calculated. High–pass filtering at 40 Hz and bandpass filtering at 40–450 Hz introduced significant filtering–induced changes in signal features while providing full attenuation of low–frequency noise contamination, with no observed differences in signal loss between these two methods. Other filtering methods led to only partial attenuation of low–frequency noise, resulting in lower signal loss and less consistent changes across gaits in signal features. Therefore, filtering–induced changes should be carefully considered when comparing signal features from studies using different filtering approaches. These findings may support cross-referencing in equine sEMG research related to training, rehabilitation programs, and the diagnosis of musculoskeletal diseases, and emphasize the importance of applying standardized filtering methods, particularly with a high–pass cut–off frequency set at 40 Hz. Full article

The use of surface electromyography (sEMG) in equine locomotion research has increased significantly due to the essential role of balanced, symmetrical, and efficient movement in riding. However, variations in sEMG signal processing for forelimb extensor muscles across studies have made cross-study comparisons challenging. This study aims to compare the sEMG signal characteristics from carpal extensor muscles under different filtering methods: raw signal, low-pass filtering (10 Hz cut-off), and bandpass filtering (40–450 Hz cut-off and 7–200 Hz cut-off). sEMG signals were collected from four muscles of three horses during walking and trotting. The raw signals were normalized and filtered separately using a 4th-order Butterworth filter: low-pass 10 Hz, bandpass 40–450 Hz, or bandpass 7–200 Hz. For each filtered signal variant, eight activity bursts were annotated, and amplitude, root mean square (RMS), median frequency (MF), and signal-to-noise ratio (SNR) were extracted. Signal loss and residual signal were calculated to assess noise reduction and data retention. For m. extensor digitorum lateralis and m. extensor carpi ulnaris, bandpass filtering at 40–450 Hz resulted in the lowest signal loss and the highest amplitude, RMS, MF, and SNR after filtering. However, variations were observed for the other two carpal extensors. These findings support the hypotheses that the characteristics of myoelectric activity in equine carpal extensors vary depending on the filtering method applied and differ among individual muscles, thereby guiding future research on sEMG signal processing and, consequently, equine biomechanics. Since both noise and its reduction alter raw sEMG signals, potentially affecting data analysis, this study provides valuable insights for improving the reliability and reproducibility of equine biomechanics research across different sEMG studies. Full article

In this paper, a novel broadband balanced-to-balanced (BTB) filtering power divider (FPD) utilizing the half-mode substrate-integrated waveguide and spoof surface plasmon polariton (HMSIW-SSPP) hybrid transmission line is introduced. Initially, a new HMSIW-SSPP unit cell is proposed, demonstrating a lower upper cut-off frequency compared to the classical HMSIW-SSPP unit cell. Building upon this unit cell, a bandpass BTB FPD is devised employing dual-layer stacked substrates, enabling independent control over the passband’s lower and upper cut-off frequencies through specific physical dimensions. Additionally, the incorporation of isolation resistors and defected ground structures in the BTB FPD enhances differential-mode isolation and common-mode (CM) suppression between output ports. A manufactured and tested BTB FPD prototype validates this design method, showcasing a broad fractional bandwidth of 52.31% (6.72–11.48 GHz), output port isolation surpassing 14.25 dB, and transmitted CM suppression exceeding 34.05 dB. Full article

This paper introduces a novel nothing-on-road (NOR) bridge weigh-in-motion (BWIM) approach with deep learning (DL) and non-invasive ground-based radar (GBR) time-series data. BWIMs allow site-specific structural health monitoring (SHM) but are usually difficult to attach and maintain. GBR measures the bridge deflection contactless. In this study, GBR and an unmanned aerial vehicle (UAV) monitor a two-span bridge in Germany to gather ground-truth data. Based on the UAV data, we determine vehicle type, lane, locus, speed, axle count, and axle spacing for single-presence vehicle crossings. Since displacement is a global response, using peak detection like conventional strain-based BWIMs is challenging. Therefore, we investigate data-driven machine learning approaches to extract the vehicle configurations directly from the displacement data. Despite a small and imbalanced real-world dataset, the proposed approaches classify, e.g., the axle count for trucks with a balanced accuracy of 76.7% satisfyingly. Additionally, we demonstrate that, for the selected bridge, high-frequency vibrations can coincide with axles crossing the junction between the street and the bridge. We evaluate whether filtering approaches via bandpass filtering or wavelet transform can be exploited for axle count and axle spacing identification. Overall, we can show that GBR is a serious contender for BWIM systems. Full article

A balanced bandpass filter (BPF) with a wide differential mode (DM) bandwidth and steep DM passband selectivity and high common-mode (CM) block based on slotline stub-loaded resonators (SSLRs) is designed in this brief. The proposed SSLR, which is composed of a half-wavelength slotline resonator and a shorted slot stub loaded at the symmetrical plane, is applied to achieve a broad DM passband with a center frequency at 5.1 GHz and a 3 dB bandwidth of 92%. Meanwhile, two transmission zeros (TZs) are introduced to realize a steep DM passband selectivity. The center frequency and bandwidth of the DM passband can be adjusted by changing the dimensions of SSLRs and the gaps between them. Meanwhile, one narrow notched band with a 3 dB bandwidth of 4.9% is realized by employing one coupled quarter-wavelength short-circuited stub at the input ports. In addition, the DM stopband with a rejection level of 10 dB can be extended to 20 GHz. The designed balanced broadband filter is stimulated by a U-shaped microstrip line to slotline transition structure, which can realize wideband a CM block with a high suppression level without influencing the DM one, and this can reduce the design complexity. In order to prove the idea, a balanced broadband filter is designed and measured. The predicted results of S parameters are compared with the measured ones, and a good agreement is achieved. Full article

A balanced bandpass filter (BPF) with an improved frequency selectivity for differential-mode (DM) excitation and high rejection for common-mode (CM) excitation is proposed in this paper. Two half-wavelength stepped impedance resonators (SIRs) are employed based on mixed electric and magnetic couplings to realize a DM passband centered at 2.48 GHz. The center frequency and bandwidth can be easily controlled by optimizing the dimensions of SIRs and the coupling between them, respectively. Meanwhile, two transmission zeros (TZs) are generated based on the mixed electric and magnetic couplings and are independently controlled by tuning the coupling strength. Moreover, a wide DM stopband can be realized by optimizing the SIRs. The proposed balanced BPF is fed by balanced U-type microstrip–slotline transition structures, which can achieve high wideband CM rejection without influencing the DM responses, and the design complexity can be clearly reduced. Finally, a balanced BPF is fabricated, and a good agreement between the simulation and the measurement is observed, which verifies the design method. Full article

Plants, like most living organisms, spontaneously emit photons of visible light. This ultraweak endogenous chemiluminescence is linked to the oxidative metabolism, with lipid peroxidation constituting a major source of photons in plants. We imaged this signal using a very sensitive cooled CCD camera and analysed its spectral characteristics using bandpass interference filters. In vitro oxidation of lipids induced luminescence throughout the visible spectrum (450–850 nm). However, luminescence in the red spectral domain (>640 nm) occurred first, then declined in parallel with the appearance of the emission in the blue-green (<600 nm). This temporal separation suggests that the chemical species emitting in the blue-green are secondary products, possibly deriving from the red light-emitting species. This conversion did not seem to occur in planta because spontaneous chemiluminescence from plant tissues (leaves, roots) occurred only in the red/far-red light domain (>640 nm), peaking at 700–750 nm. The spectrum of plant chemiluminescence was independent of chlorophyll. The in vivo signal was modulated by cellular detoxification mechanisms and by changes in the concentration of singlet oxygen in the tissues, although the singlet oxygen luminescence bands did not appear as major bands in the spectra. Our results indicate that the intensity of endogenous chemiluminescence from plant tissues is determined by the balance between the formation of luminescent species through secondary reactions involving lipid peroxide-derived intermediates, including singlet oxygen, and their elimination by metabolizing processes. The kinetic aspects of plant chemiluminescence must be taken into account when using the signal as an oxidative stress marker. Full article

This article presents a new K-band absorptive bandpass filter (ABPF) based on a microwave balanced recursive architecture. The proposed structure was configured using two passive microwave hybrid couplers, two conventional bandpass filters (BPFs), and a recursive path control module consisting of a phase shifter and an optionally variable gain amplifier. Using the proposed structure, stable return characteristics that were insensitive to the output load variation in the passband, a reduction in standing wave due to absorption in the stopband, and potentially high reliability could be achieved. Furthermore, since the same BPFs were reused, the electrical filtering order within the given physical BPF stages could be increased effectively. The proposed architecture was verified by comparing it with the performance of the conventional two-stage cascaded BPF. The measured results showed a 3 dB passband at 280 MHz with the center frequency at 19.9 GHz and improved roll-off characteristics. Furthermore, the stopband showed the reflectionless characteristic with the return loss being better than 7 dB. Full article

Short-range ultra-wideband (UWB) radar sensors belong to very promising sensing techniques that have received vast attention recently. The M-sequence UWB sensing techniques for radio detection and ranging feature several advantages over the other short-range radars, inter alia superior integration capabilities. The prerequisite to investigate their capabilities in real scenarios is the existence of physically available hardware, i.e., particular functional system blocks. In this paper, we present three novel blocks of M-sequence UWB radars exploiting application-specific integrated circuit (ASIC) technology. These are the integrated 15th-order M-sequence radar transceiver on one chip, experimental active Electronic Communication Committee (ECC) bandpass filter, and miniature transmitting UWB antenna with an integrated amplifier. All these are custom designs intended for the enhancement of capabilities of an M-sequence-based system family for new UWB short-range sensing applications. The design approaches and verification of the manufactured prototypes by measurements of the realized circuits are presented in this paper. The fine balance on technology capabilities (Fc of roughly 120 GHz) and thoughtful design process of the proposed blocks is the first step toward remarkably minimized devices, e.g., as System on Chip designs, which apparently allow broadening the range of new applications. Full article

A new dual-band balanced bandpass filter based on magnetically coupled open-loop resonators in multilayer technology is proposed in this paper. The lower differential passband, centered at the Global Positioning System (GPS) L1 frequency, 1.575 GHz, was created by means of two coupled resonators etched in the middle layer of the structure, while the upper differential passband, centered at a Wi-Fi frequency of 2.4 GHz, was generated by coupling two resonators on the top layer. Magnetic coupling was used to design both passbands, leading to an intrinsic common-mode rejection of 39 dB within the lower passband and 33 dB within the upper passband. Simulation and measurement results are provided to verify the usefulness of the proposed dual-band differential bandpass filter. Full article

Differentially driven devices represent a highly promising research field for radio frequency (RF), microwave (MW), and millimeter-wave (mmWave) designers and engineers. Designs employing differential signals are essential elements in low-noise fourth-generation (4G) and fifth-generation (5G) communications. Apart from the conventional planar MW components, differential–fed balanced microstrip filters, as promising alternatives, have several advantages, including high common-mode rejection, low unwanted radiation levels, high noise immunity, and wideband harmonic suppression. In this paper, a comprehensive and in-depth review of the existing research on differential-fed microstrip filter designs are presented and discussed with a focus on recent advances in this research and the challenges facing the researchers. A comparison between different design techniques is presented and discussed in detail to provide the researchers with the advantages and disadvantages of each technique that could be of interest to a specific application. Challenges and future developments of balanced microstrip bandpass filters (BPFs) are also presented in this paper. Balanced filters surveyed include recent single-, dual-, tri-, and wide-band BPFs, which employ different design techniques and accomplish different performances for current and future wireless applications. Full article

This work presents a reconfigurable RF converter for DVB-T television applications using triple-play over GPON. The system takes the DVB-T input, a wavelength division multiplexing (WDM) signal with spectral inversion in the range from 47 $\mathrm{M}$ $\mathrm{Hz}$ –1000 $\mathrm{M}$ $\mathrm{Hz}$ , up-converts its frequency to the band-pass of a highly selective surface-acoustic wave (SAW) filter centered at $1.3$ $\mathrm{G}$ $\mathrm{Hz}$ , and then down-converts it so that it is compatible with the antenna input of conventional television sets. The designed RF converter incorporates two pairs of frequency synthesizer and mixer, based, respectively, on an integer-N phase-locked loop (PLL) with two LC-tank VCOs with 128 coarse tuning bands in the range from 1.35 $\mathrm{G}$ $\mathrm{Hz}$ –2.7 $\mathrm{G}$ $\mathrm{Hz}$ , and a double-balanced Gilbert cell, modified for better impedance matching and improved linearity. It is fed with regulated supplies compensated in temperature and programmed by an I ${}^2$ C interface operating on five 16-bit registers. This work presents the experimental characterization of the whole system plus selected cells for stand-alone testing, which have been fabricated in a $0.18$ $\mathrm{m}$ CMOS process. Full article
